PIN and Proximity Reader
For Access Control Systems
(CR-R885-A)
Installation and Operating Instructions
Version 1.0
TABLE OF CONTENTS
Installation ............................................................................2
Technical Specifications .......................................................3
Feedback ..............................................................................5
Programming ........................................................................5
Card/Code Options ...............................................................6
Keypad Communication Format ...........................................6
Transfer Limit for 4-bits Buffered Format .............................7
Display on Card Read ..........................................................7
Keypad Lockout ....................................................................8
26-bit Wiegand Card Family Code Setting ...........................8
Reader’s Interface ................................................................9
Check-in Supervision ...........................................................9
Buzzer Setting ....................................................................10
Face Light Intensity ............................................................10
Face Light Operation ..........................................................10
Face Light Colour ...............................................................10
Changing the Installer Code ...............................................11
Panic Alarm ........................................................................11
Resetting to Default ............................................................11
Card Presentation Test ......................................................12
Warranty ............................................................................. 12
PosiPin 1
INSTALLATION
For PosiPin to function correctly with the access co ntrol system,
some programming may be required in the controller or control
panel of the host system. For further instructions, refer to the
appropriate manual. Only explanations directly concerning
PosiPin’s programming will be included in this manual.
Selecting an Installation Site:
• Avoid wiring the PosiPin c ables in t he same con duit as AC po wer
cables, lock power or sig nal wiring.
• Reader wiring mu st rema in a m inim um of 30c m (12 in) aw ay from
other wiring, such as wiring for AC power, computer data,
telephones, electric locks, etc.
• Avoid sites within 1.1m (3.5ft) of computer monitors or CRTs.
• Avoid sites near sources of broad spectrum EMI noise, such as
motors, pumps, generators, DC to AC converters, AC switching
relays, power supplies, and light dimmers.
• Avoid sites near potential sourc es of R F si gn als , such as cellular
phones, two-way radios, etc.
Mounting and Wiring
After selecting a site for the PosiPin, use the mounting plate as a
guide to drill two hol es to s ec ure th e m oun tin g pl ate and a hole for
the cable 0.95c m to 2.54cm (0.375in to 1in) wide. Place a grom met
around the edge of the hol e fo r the cable. Prepare PosiPin’s c abl e
by cutting the cable jac ket b ack 3 .17 5cm (1.25in ) and st ripping the
wires back 0.635cm (0.25in). Splice PosiPin’s wires with a
recommended cable wire. Route the cable to the controller and
connect as shown in Figure 1: Connection drawing on page 4.
2 Installation and Operating Instructions
Mounting on Metal Surfaces
Although the read range may slightly decrease, PosiPin can be
mounted on metal. However, do not box in or surround the card
reader with any kind of metal. If the reader must be installed in a
metal enclosure, ensure that the face of the card reader is not
covered and that at least 1.6" (4cm) remain between the card
reader and the metal on all sides of the card reader.
TECHNICAL SPECIFICATIONS
Input Voltage: Typical: 13.8Vdc, min.: 11.0Vdc, max: 14.5Vdc
Input Current: Typical: 65mA @ 12.5Vdc, with card: 105mA
Consumption: Typical: 812mW @ 12.5Vdc, with card 1.31mW
Frequency: Exciter Field: 125KHz Pulse Modulated, receive low:
Operating Temp: -35°C (-31°F) to +65°C (+149°F)
Output formats: Reader: 26- and 37-bit Wiegand
Cable Distance: 152.4m (500ft.)
Suggested Cables: 22AWG, 0.8mm, Multi-conductor, Alpha 5196, 5198
Indicators: Beeper, red LED, green LED, red or green Face Light
Weight: 280g (9.8 oz.)
Material: Black, UV resistant, ABS plastic
Dimensions: 99.5mm (5.75in.) x 118.5mm (2in.) x 19.5mm (1in.)
12.500KHz, Receive high: 15.625KHz
Keypad: 8-, 26- and 37-bit Wiegand, 4-bit with or
without parity, and 4 bits buffered with or without parity
18AWG, 1.2mm, Multi-conductor, Alpha 5386, 5388
Belden 9553, 18AWG, 6-conductor, stranded w/
overall shield
PosiPin 3
Figure 1: Connection drawing
4 Installation and Operating Instructions
FEEDBACK
Visual Feedback: When information is entered on the reader’s
keypad, the red and/or green LEDs will flash, remain constant or
extinguish depending on the ope rati on.
Confirmation Beep: When an operation is successfully entered,
the reader emits a rapid series of beep tones (“beep-beep-beepbeep-beep”).
Rejection Beep: When the system reverts to a previous status or
an operation is inc orrectly entered, th e reader e mits one long bee p
tone (“beeeeeeeeeep”).
PROGRAMMING
Ensure that corresponding programming is completed in the
control panel or controller connected to the PosiPin. To program:
] key for 4 seconds.
1. Press and hold the [
The reader emits a confirmation beep and the green LED illuminates.
2. Enter the [
(default:000000) Reader emits a confirmation beep and the green LED
flashes.
INSTALLER CODE
3. Enter the 3-digit [
Reader emits a confirmation beep and the green LED stops flashing.
4. Enter the required [
The reader emits a confirmation beep and the green LED flashes.
CLEAR
SECTION
DATA
]. Press the [
]. Press the [
]. Press the [
ENTER
ENTER
ENTER
] key.
] key.
] key.
5. To program another section, repeat steps 3 and 4. To exit
] key for 4 sec.
programming mode, press and hold the [
The reader emits a rejection beep and the green LED extinguishes.
CLEAR
PosiPin 5
CARD/CODE OPTIONS
Section [001]
[001] - Default: [3]
[001][001]
[3]
[3][3]
PosiPin can function as a reader, a keypad or as both combined.
Enter Description
[0]
[1]
[2]
Keypad and reader disabled.
For programming only.
Reader only enable d. A u se r m us t p res ent a valid
card to the reader for Access Granted.
Keypad only enabled. A user must enter a valid
code on the keypad for Access Granted.
Keypad and reader ena ble d. A us er m ust pr ese nt
[3]
a valid card and enter a valid code for Access
Granted.
KEYPAD COMMUNICATION FORMAT
Section [002]
[002] - Default: [1]
[002][002]
[1]
[1][1]
PosiPin must use the same keypad communication format as the
controller.
Enter Description
[0] 8-bit Wiegand
[1] 26-bit Wiegand (also see section [006])
[2] 37-bit Wiegand
[3] 4 bits without parity
[4] 4 bits with parity
[5]
4 bits buffered without parity
(also see section [003])
[6] 4 bits buffered with parity (also see section [003])
6 Installation and Operating Instructions
TRANSFER LIMIT FOR 4-BITS BUFFERED FORMAT
Section [003]
[003] - Default: [00]
[003][003]
[00]
[00][00]
This feature sets the number of digits retained in memory before
the data is sent to the controll er. For example, if section [003] is set
at 05, PosiPin will trans mit once 5 digits are entered on the keypa d.
This featu re only applies wh en the format prog rammed in
Section [002] is set for Option [5]: 4 bits buffered without
parity or Option [6]: 4 bits buffered with parity.
Enter Description
[01] to [11]
[01] to [10]
If section [002] is Option [5]: 4 bits buffered
without parity
If section [002] is Option [6]: 4 bits buffered with
parity.
DISPLAY ON CARD READ
Section [004]
[004] - Default: [3]
[004][004]
[3]
[3][3]
PosiPin’s response to a card being presented to the reader can be
adjusted according to the installat ion’s requirements.
Enter Description
[0] Display on Card Read disabled
[1] Red Status LED flashes
[2] Green Sta tus LED flashes
[3] Red and green Status LEDs flash
[4] Face Light flashes
[5] Face Light and red Status LED flash
[6] Face Light and green Status LED flash
[7] Face Light and both Status LEDs flash
PosiPin 7
KEYPAD LOCKOUT
Section [005]
[005] - Default: [0]
[005][005]
[0]
[0][0]
The PosiPin keypad c om es w i th a f eature that will lo ck th e ke ypa d
for 60 seconds when an installer code is entered incorrectly 3
consecutive times.
Enter Description
[0] Keypad Lockout disabled
[1] Keypad Lockout enabled
26-BIT WIEGAND CARD FAMILY CODE SETTING
Section [006]
[006] - Default: [000]
[006][006]
[000]
[000][000]
When the keypad is enabled, the card’s family code must be
programmed in order for the keypad to recognize the user’s PIN.
When a user enters a PIN on the key pad, PosiPin w ill automaticall y
add the family code prog ram me d in section [006] to the beginning
of the PIN before transmittin g the data to the co ntrolle r. Ther efore,
also ensure that all cards to be used with the PosiPin contain the
same family code.
This feature only applies when the communication format
programmed in Section [002] is set for Option [1]: 26-bit
Wiegand.
Enter Description
[0] to [255] Cards’ Family Code
8 Installation and Operating Instructions
READER’S INTERFACE
Section [007]
[007] - Default: [0]
[007][007]
[0]
[0][0]
The reader component of the PosiPin must be pro grammed to use
the same reader communication format as the controller.
Enter Description
[0] 26-bit Wiegand
[1] 37-bit Wiegand
CHECK-IN SUPERVISION
Section [008]
[008] - Default: [0]
[008][008]
[0]
[0][0]
This feature only applies when the communication format
programmed in Section [002] is set for Option [1]: 26-bit
Wiegand or Option [2]: 37-bit Wiegand.
When no actions are perform ed on the PosiPin for a period of time,
it will communicate its stat us to the controlle r ev ery 3 0 seconds by
sending a code to confirm its presence (26-bit Wiegand =
255:65535; 37-bit Wiegand = 65535:65535). If the PosiPin does
not communicate it s status ev ery 30 secon ds, the contro ller can be
programmed to generate an alarm.
Enter Description
[0] Check-in Supervision disabled
[1] Check-in Supervision enabled
PosiPin 9
BUZZER SETTING
Section [101]
[101] - Default: [3]
[101][101]
[3]
[3][3]
The number of beep tones emitted as a response to a card being
presented to the reader can be adjusted from 0 (disabled) to 7 (7
rapid beep tones).
Enter Description
[0] to [7] Number of beep tones per response
FACE LIGHT INTENSITY
Section [102]
[102] - Default: [4]
[102][102]
[4]
[4][4]
The Face Light’s illumination can be adjusted according to the
installation’s requirem en ts from 0 (exting ui she d) to 8 (brighte st) .
Enter Description
[0] to [8] Face Light’s intensity level
FACE LIGHT OPERATION
Section [103]
[103] - Default: [1
[103][103]
[1]
[1[1
The Face Light can be s et to re ma in il lum in ate d continually or can
follow the Status LEDs’ state.
Enter Description
[0] Face Light constant
[1] Face Light follows Status LEDs
10 Installation and Operating Instructions
FACE LIGHT COLOUR
Section [104]
[104] - Default: [0]
[104][104]
[0]
[0][0]
The Face Light’s colour can be red or green as desired.
This feature only applies when Face Light Operation
programmed in Se ction [103] is set for Opti on [0]: Face Light
constant.
Enter3 Description
[0] Red Face Light
[1] Green Face Light
CHANGING THE INSTALLER CODE
Section [200]
[200] - Default: 000000
[200][200]
The Installer Code is used to enter PosiPin’s programming mode.
The Installer Code is six digits long where each digit can be any
value from 0 to 9.
PANIC ALARM
A panic code can be generated and tran smitted to the contro ller by
pressing an d hol din g the [
CLEAR
] and [
] keys for 2 seconds
ENTER
(26-bit Wiegand = 255:65534; 37-bit Wiegand = 65535:65534).
This feature only applies when the communication format
programmed in Section [002] is set for Option [1]: 26-bit
Wiegand or Option [2]: 37-bit Wiegand.
PosiPin 11
RESETTING TO DEFAULT
To reset PosiP in to factor y defaul ts, disc onnect it s power supp ly.
Press and hold the [1] and [2] keys simultaneously while reconnecting its power supply.
CARD PRESENTATION TEST
Present the card to the reader as shown in the figu re below . Place
the card parallel to the PosiPin reader and move it toward the
reader until the card code displ ays on the control ler screen . At this
point, the card is read, decoded, data transmitted to the controller
and the controller has responded accordingly. To read the card
again, remove and re-insert the card into the reader's field.
12 Installation and Operating Instructions
WARRANTY
The Seller warrants its products to be free from defects in
materials and workman ship under normal use for a peri od of one
year. Except as specifically stated herein, all express or implied
warranties whatsoever, statutory or otherwise, including without
limitation, any imp lied warranty of mercha ntability and fitness for
a particular purpose, are expressly excluded. Because Seller
does not install or connect the products and because the
products may be used in conjunction with products not
manufactured by Seller, Seller cannot guarantee the
performance of the s ecurity sy stem. Seller o bligation and liability
under this warranty is expre ssly lim ited to re pairin g or replacin g,
at Seller's option, any product not meeting the specifications. In
no event shall the Seller be liable to the buyer or any other
person for any loss or damages whether direct or indirect,
consequential or incidental, including without limitation any
damages for lost profits stolen goods or claims by any other
party caused by defective goods or otherwise arising from the
improper, in corre ct or othe rwise fa ulty ins tallati on or use of the
merchandise sold.
Printed in Canada 04/2001
PPINEI-00
Loading...
