Smart Camera Gateway
The Z-Wave FHD IP Camera is a Smart Home Solution on a
Camera (SoC). This is an IP camera with Z-Wave controller/gateway
functions integrated inside. With this camera, you can
control/monitor all Z-Wave devices in your house through your
iPhone/iPad and Android mobiles/pads.
The basic setup of this camera is truly 1-2-3 :
1. Connect the camera to the network
2. Download the app POPP HOME into your iPhone/iPad or
Android
3. View video by the camera ID/password
Z-Wave technology is an innovative wireless communication
protocol for smart home usage. With this technology integrated, the
Z-Wave camera can easily control/monitor all Z-Wave devices,
including door-lock, curtain, lighting, power plug, electronics and
sensors.
The push notification is supported, so that you will get the
notification from your iPhone/iPad and Android once there is any
events detected through the motion detection or sound detector on
the camera, even when your mobile is on sleep mode.
The SD card recording is supported, and you could playback the
recorded video on your iPhone/iPad and Android. You could also do
the SD card recording only when there is motion or sound detection
to save the SD card storage size. The motion and sound detected
recording has a 5 seconds pre-recording, so that you will always
catch the critical moment.
The Time Lapse Recording is supported. The camera can do time
lapse recording on the SD card and you can playback the recorded
time lapse video on the mobile or tablet remotely, anywhere. This is
more convenient than traditional time lapse camera which can only
be played back by removing the SD card to a computer.
The NAS and cloud storage is supported. You can record the
video files into any normal NAS devices or to your Dropbox account.
And you can playback those recorded video files remotely on your
mobile devices or computers.
For day & night usage, there is an IR cut on the camera, IR filter is
on for day and off for night. The lens is wide angle up to 140 degree.
Two-way audio is supported. You can monitor the synchronized
video/audio and talk to or warn the people around the camera from
your iPhone/iPad and Android once you got the push notification.
There is a built-in speaker so that you could connect any high power
speaker to the camera for your needs.
The WPS(WiFi Protected Setup) is supported. You could set up
the WiFi connection of the camera with the router by clicking the
WPS button on the camera and on the router at the same time. No
more complicated WiFi configuration.
The Z-Wave IP camera is ideal for your smart home usage,
integrating the usage of all the available Z-Wave devices in the
market will make the application infinite and make your home life out
of your imagination.
Features
Ø Camera with Z-Wave controller/gateway functions
integrated.
Ø Support Zwave devices control, room control and scene
control.
Ø Control up to 60 Z-Wave devices.
Ø Control up to 20 rooms, each room allows max of 60
devices.
Ø Control up to 30 scenes, each scene allows 6 events
and 12 actions.
Ø Allows alarm notification for each Z-Wave devices and
each scene.
Ø Plug & play by ID/password, no IP address or DNS
settings.
Ø H.264 video compression
Ø Two mega-pixel(Full HD) for up to 1920x1080
resolution at 30 fps.
Ø Day and night video with high power IR led.
Ø Two way audio, internal speaker.
Ø SD card video recording with 5 seconds of pre-
recording..
Ø Time lapse video recording
Ø 2.4G Hz WiFi with WEP and WPA/WPA2 security
support.
Ø WPS (WiFi Protected Setup) support.
Ø Triple video streaming on PC, mobile and SD card
recording.
Ø Night mode control – support automatic, manual and
scheduled modes.
Ø Connect up to 8 users simultaneously
Ø Push notification on iPhone/iPad and Android for
motion and sound detection.
Ø Email alarm message for motion and sound detection.
Ø Event scheduling.
Ø Video recording on NAS device.
Ø Cloud storage on Dropbox
Ø Internal real time clock
Ø Watchdog function to prevent system failure.
Specifications
Models
Z-Wave FHD IP camera
Power
DC 5V, 1.5A
Processors
RISC CPU, hardware video processing and
compression.
Network interface
Ethernet 10BaseT/100BaseTX, Auto-MDIX,
RJ-45
Wireless interface
2.4G Hz WiFi
Range : 100 meters, line of sight
Full HD
Resolution 1920x1080
Z-Wave module
Sigma Design 500 series module
Tx RF Power : -26 ~ 2 dBm.
Range: 100 meters open site
Radio frequency : 868.42 MHz for Europe
Image sensor
RGB 2 Mega 1/2.7 inch CMOS sensor
Automatic exposure control, automatic white
balance, automatic gain control, automatic
brightness control.
Light sensitivity
0.2 Lux ( IR LED off )
0 Lux (with 10 meters IR LED on)
Automatically turn on the IR LED on low light
environment.
Lens
M12, 2.8 mm, F1.8, viewing anglehorizontal:140°,
fixed iris. focus range: 50 cm to infinity
Buttons
One reset button, to factory default settings
One WPS button for automatic WiFi setup
Indicators
One LED for Internet connection status
indication
One LED for Ethernet connection indication
One LED for SD card recording indication
Video compression
H.264, high profile
Video streaming
Separate frame
rate/resolution/bandwidth settings for
PC and mobile.
Video settings
Resolution: (Full HD)1920x1080, 1280x720, 640x360
Bandwidth : 64k, 128k, 256k, 512k, 768k, 1M, 1.2M, 1.5M,
2M, 3M bps
Frame rate : 1~5, 10, 15, 20, 25, 30 fps
Audio
Built-in microphone for audio monitoring
Built-in 0.5W speaker for alarm and halfduplex two-way audio.
Audio compression: G.711
Security
Web management username/password
protection
Video display ID/password protection
WiFi WEP and WPA/WPA2 security mode
Installation,
management and
maintenance
Plug & play by ID/password.
Video management software-CamView for
video access and multi-camera management
Firmware upgrades via FTP
Web browsing
Built-in web server for standard web browser
access
Video display on IE browser
Video snapshot on any browser
Supported
protocols
IPv4, HTTP, TCP, ICMP, RTSP, RTP, UDP,
RTCP, SMTP, SNTP, FTP, DHCP, ARP, DNS,
PPPoE, etc.
Accessories
(included)
Power adaptor, RJ45 Ethernet cable, quick
installation guide, ID/Password card.
App
App POPP HOME for Android and iPhone/iPad
Users
Up to 8 simultaneous unicast users
(depends on video settings)
Alarm and event
management
Events triggered by motion and sound
detection
Email/ftp alarm message
Push notification on iPhone/iPad and Android
devices.
Dimensions
(HxWxD) and
weight
116 x 57 x 31 mm, bracket included
129 g, incl. camera bracket, excl. power
adaptor
Approvals
EMC - CE, FCC Part 15 Subpart B Class B
Wireless RF - CE, FCC Part 15 Subpart C
Power supply: CE, FCC, UL, EN 60950
Operating
conditions
0-50 °C
Humidity 20 – 80% RH (non-condensing)
