PolyVision fuse User Manual
Part number 2002327-001 Rev C
©2012 PolyVision Corporation
All rights reserved
PolyVision
®
fuse™ Visualizer
User Guide
fuse Visualizer
Table of contents
Overview ........................................................................................................................................................ 3
What is fuse? .............................................................................................................................................. 3
Register your product ................................................................................................................................. 3
Preparing to use fuse ..................................................................................................................................... 4
What comes in the box ............................................................................................................................... 4
Install the fuse software .............................................................................................................................. 4
System requirements ............................................................................................................................... 4
fuse installation: Windows ........................................................................................................................ 5
fuse installation: Linux .............................................................................................................................. 5
fuse installation: Macintosh ...................................................................................................................... 6
Install the fuse camera ................................................................................................................................ 6
USB cable connection ............................................................................................................................. 6
ēno option: install the magnetic icon strip ................................................................................................ 7
Using fuse Visualizer ....................................................................................................................................... 8
Three ways to use fuse ............................................................................................................................... 8
Getting started ............................................................................................................................................ 8
fuse application toolbar icons ..................................................................................................................... 8
Displaying the desired image ...................................................................................................................... 9
Camera LED lighting ................................................................................................................................ 9
Rotate ...................................................................................................................................................... 9
Auto Focus .............................................................................................................................................. 9
Zoom in ................................................................................................................................................. 10
Zoom out ............................................................................................................................................... 10
Zoom the selection ................................................................................................................................ 10
Screen Lock .......................................................................................................................................... 10
Reset ..................................................................................................................................................... 10
Capturing images ..................................................................................................................................... 10
Capture a snapshot ............................................................................................................................... 10
Video capture ........................................................................................................................................ 11
Copy ...................................................................................................................................................... 11
Print ....................................................................................................................................................... 11
Enhancing snapshots and printed images ............................................................................................. 11
fuse application settings ........................................................................................................................... 12
Getting help ........................................................................................................................................... 13
Full Screen mode ...................................................................................................................................... 13
Hiding and viewing the fuse application toolbar ..................................................................................... 13
Automatic application updates ................................................................................................................. 13
Care and maintenance ................................................................................................................................. 14
Cleaning the fuse camera ......................................................................................................................... 14
Cleaning the lens ...................................................................................................................................... 14
Lighting..................................................................................................................................................... 14
FCC compliance ....................................................................................................................................... 14
Warranty ...................................................................................................................................................... 15
Index ............................................................................................................................................................ 16
2 of 16 User Guide
2002327-001 Rev C
fuse Visualizer
Overview
Congratulations on your purchase of the PolyVision® fuse™ Visualizer. This manual describes how to
install and use the fuse Visualizer and software application.
What is fuse?
The PolyVision® fuse Visualizer provides the functions of a document camera, scanner, and web
cam in a small desktop footprint with only one USB cable connection to your computer. The USB
cable connection provides power to fuse and enables you to save digital images or video files from
the fuse camera directly to the computer where fuse software is installed.
You can use fuse alone, or add multiple features by integrating fuse with the PolyVision ēno™
interactive whiteboard and a projector. With fuse and ēno you can:
• view live images from fuse projected on the interactive whiteboard, annotate images using the ēno
stylus, and capture everything as a digital image on your computer
• control fuse features directly from the whiteboard using a small magnetic icon strip
Register your product
By registering your product, you receive enhanced customer service with information on software
upgrades.
To register your PolyVision product:
• Register on-line at:
http://register.polyvision.com
PolyVision 3 of 16
2002327-001 Rev C
fuse Visualizer
5
Preparing to use fuse
What comes in the box
1. fuse desktop camera
2. magnetic icon strip
3. USB cable
4. Software CD
5. Quick Reference Guide
1
2
4
Install the fuse software
System requirements
Your computer must have:
• 512 MB RAM
Your Windows-based computer must have:
• Intel Core 2 CPU or equivalent
• Windows 7, Vista or XP with SP 3
• Available USB 2.0 port
Your Macintosh computer must have:
• OS X release 10.5 or later
• Available USB 2.0 port
Your Linux system must have:
3
• Ubuntu 10.04 or later, Fedora 14 or later
• Available USB 2.0 port
4 of 16 User Guide
2002327-001 Rev C
fuse Visualizer
fuse installation: Windows
To install the PolyVision fuse software in Windows:
1. Insert the PolyVision fuse Visualizer Installation CD in your computer.
Or,
1. Download the fuse software from the internet at http://www.polyvision.com/
2. Double-click “My Computer” on your desktop.
3. Double-click the disk named “fuse Visualizer.”
4. Double-click the Windows folder to open it.
5. Double-click the language folder that matches your operating system.
6. Double-click “PolyVision_fuse_Setup_language.exe.” Installation begins.
7. Follow the prompts you see on the screen to install the fuse software on your computer.
8. Connect the USB cable provided with fuse to your computer. The New Hardware Wizard
dialog appears.
9. Click the radio button beside “No, not this time.”
10. Click “Next.” The Security Alert Driver Installation dialog appears.
11. Click “Yes.” The Wizard automatically completes the installation.
12. Click “Finish.”
To uninstall fuse software in Windows:
1. Click “Start” at the lower left corner of the task bar.
2. Choose “All Programs” from the menu.
3. Choose “fuse Visualizer” from the menu.
4. Choose “Remove fuse Visualizer.”
fuse installation: Linux
To install the fuse software in Linux:
1. Insert the PolyVision fuse Visualizer Installation CD in your computer.
2. Double-click the drive named “fuse Visualizer” that appears on your desktop.
3. Double-click the “Linux” folder.
4. Double-click the language folder that matches your operating system.
5. Right-click “PolyVision_fuse_Setup_language” and choose “Properties.”
6. On the “Permissions” tab, click the “Allow executing file as program” check box.
7. Click “Close.”
8. Double-click “Setup.” Installation begins.
9. Follow the prompts you see on the screen to complete the installation.
To uninstall the fuse software using Linux:
1. In a terminal window, enter:
sudo /usr/bin/PolyVision/ fuse software /uninstall
2. Enter your root password.
PolyVision 5 of 16
2002327-001 Rev C
