Polyscience VSCR-150AC2E, VSCR-150AC1B User Manual
150 SERIES
VACUUM SEALING SYSTEM
USER’S GUIDE
110-877 081913
CONTENTS
Important Safeguards ....................... 3
Introduction ............................... 5
Controls & Components ..................... 6
Controller Overview......................... 7
Set-Up ................................... 8
Electrical Power.......................... 8
Making a Heat-Seal Bag from a Roll .......... 9
Opening & Closing Vacuum Comparment Lid.... 10
Day-to-Day Operation ....................... 10
Turning the Unit On ....................... 10
Automatic Vacuuming & Sealing ............. 11
Manual Vacuuming & Sealing ............... 12
Extending the Seal Time ...................12
Canceling the Vacuum or Sealing Process...... 12
Vacuum Sealing Canisters & Bottles .......... 13
Cleaning & Storage ....................... 14
Troubleshooting ...........................15
Technical Specifications ..................... 16
Replacement Bags & Rolls ................... 17
Disposal .................................. 17
Warranty.................................. 18
www.cuisinetechnology.com 2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Do not touch hot surfaces.
2. Do not operate this Vacuum Sealer with a damaged power cord
or plug, or if it has been dropped, damaged or malfunctions.
Return the Vacuum Sealer to PolyScience for examination and/
or repair.
3. Do not let power cord touch hot surfaces or hang over the edge
of table or counter.
4. Unplug from electrical outlet when not in use.
5. To avoid the possibility of personal injury, always unplug the
Vacuum Sealer from the electrical outlet before cleaning the
unit.
6. Do not immerse Vacuum Sealer or power cord in water or any
other liquid.
7. Do not touch the vacuum chamber lid, vacuum chamber or seal
bar while the unit is operating.
8. Do not use an extension cord with this Vacuum Sealer.
9. This Vacuum Sealer is intended for indoor use only; do not use
outdoors.
10. Do not let this Vacuum Sealer come in direct contact with food.
All foods should be placed in FDA approved boilable bags or
canisters.
11. Carefully review the safety section in included literature.
12. This appliance should not be used by children. To avoid
accidental injury, close supervision is necessary when this
appliance is used where children may be present.
13. Do not operate in the presence of explosive and/or flammable
fumes.
14. Do not use this Vacuum Sealer for other than the intended
purpose.
15. Do not use this Vacuum Sealer on wet or hot surfaces or near a
heat source.
16. To disconnect, turn any control “Off,” then unplug directly from
electrical outlet; do not disconnect by pulling on the power cord.
17. Household use only.
18. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a responsible person responsible for their safety.
19. Use only heat-seal bags, accessories and attachments.
20. Read all instructions carefully.
3
PolyScience Vacuum Sealing Systems
SAVE THESE INSTRUCTIONS
WARNING: The Vacuum Sealer is equipped with
a two-prong polarized power cord. Connect the
appliance only to earthed (grounded) power sockets.
Do not use appliance with a grounding adapter.
Contact a qualified electrician if the plug does not fit
into the electrical outlet you intend on using.
WARNING: Be careful not to touch or come in
contact with the Seal Bar when the Vacuum
Compartment Lid is open as it may be hot.
Never press the Seal button when the Vacuum
Compartment Lid is open as this will apply heating
power to the Seal Wire and can present a burning
hazard.
WARNING: Vacuum packaging is not a substitute
for refrigeration or freezing. Any perishable foods
!
!
that require refrigeration must still be refrigerated or
frozen after vacuum packaging. Vacuum packaging is
not a substitute for canning.
WARNING: Never vacuum package garlic or fungi
(such as mushrooms). A dangerous chemical
reaction takes place when air is removed, causing
these foods to be dangerous if ingested.
WARNING: As with any storage container, it is
!
It is important to note that vacuum packaging cannot reverse the
deterioration of foods; it can only slow down changes in quality. It is
difficult to predict how long foods will retain their flavor, appearance
or texture since it depends on the age and condition of the food
when it was vacuum packaged.
www.cuisinetechnology.com 4
important to inspect food that has been vacuum
packaged for spoilage prior to consumption.
INTRODUCTION
Thank you for choosing the PolyScience 150 Series Vacuum
Sealer. It is one of the easiest to use vacuum packaging systems
available. With this Vacuum Sealer, you will now be able to
keep food fresher and for longer periods of time in your freezer,
refrigerator and pantry. You can also use your Vacuum Sealer
to quickly marinate meats, poultry and fish or pickle fruits and
vegetables.
The PolyScience 150 Series Vacuum Sealer effectively removes
air and extends freshness up to five times longer than normal
preservation methods. As a result, it significantly extends food
life, maintains food quality, reduces freezer burn and decreases
food waste and costs.
Compact and lightweight, your Vacuum Sealer’s sleek design and
intuitive operation makes it extremely easy to use and ensures a
tight, positive seal every time.
We recommend that you begin operating your Vacuum Sealer
immediately to confirm that it is operating properly. In the unlikely
event that the unit was damaged during shipping or does not
operate properly, contact:
PolyScience
6600 W. Touhy Avenue
Niles, IL 60714 USA
Phone:
Email:
Be sure to activate your new PolyScience Vacuum Sealer warranty at
www.cuisinetechnology.com
5
1.800.229.7569
1.847.647.0611
culinary@polyscience.com
PolyScience Vacuum Sealing Systems
CONTROLS & COMPONENTS
Vacuum Compartment Lid
Control Panel
Accessory Port
Seal Foam
Seal Wire
Lower Seal Gasket
www.cuisinetechnology.com 6
Upper Seal Gasket
Lid Locks
