Polypipe PB4CTC RF User Manual
Digital 4 Channel RF Timer
User Guide PB4CTC RF
PB42CTC RF APRIL 2012
EFFECTIVE: 1ST APRIL 2012
April 2012
CONTENTS
Overview .............................................................................................................................03
1 Battery access and user controls ...........................................................................................04
1.1 Keyboard ......................................................................................................................04
1.2 Displays and LED ...........................................................................................................04
2 First time installation ...........................................................................................................04
2.1 Setting time and date ....................................................................................................04
3 Channel initiation ...............................................................................................................05
4 Selecting a preset programme .............................................................................................05
4.1 Creating a user defined programme ...............................................................................05
5 Manual programme override ...............................................................................................06
5.1 Holiday mode ................................................................................................................06
5.2 Off mode & frost protection ...........................................................................................06
6 Hidden installer menu .........................................................................................................07
7 Technical specification .........................................................................................................07
8 Fault diagnosis ....................................................................................................................07
9 Pre-set programmes P1 - P9 .................................................................................................08
02
03
OVERVIEW
The PB4CTC RF can be used to control up to four separate heating zones
and can be used in mixture of both underfloor heating and radiator systems.
Used in conjunction with either the PB2ZM RF or the PB1ZM* master units
the PB4CTC RF time clock operates entirely by radio frequency.
*When used with the PB1ZM unit an additional RF receiver (PB REC RF)
will be required.
This user guide provides user settings and programming details. These and the
advanced settings can also be downloaded from www.ufch.com in A4 format.
