Property
Testing method
Typical value
Density
ASTM D792 (ISO 1183, GB/T 1033)
1.17 – 1.24 (g/cm3 at 21.5˚C)
Glass transition temperature
DSC, 10 °C/min
61 (°C)
Vicat Softening temperature
ASTM D1525 (ISO 306 GB/T 1633)
62 (˚C)
Melt index
210 °C, 2.16 kg
5-8 (g/10 min)
Melting temperature
DSC, 10 °C/min
149 (˚C)
Crystallization temperature
DSC, 10 °C/min
112 (˚C)
Property
Testing method
Typical value
Young’s modulus (X-Y)
ASTM D638 (ISO 527, GB/T 1040)
1879 ± 109 (MPa)
Tensile strength (X-Y)
ASTM D638 (ISO 527, GB/T 1040)
28.1 ± 1.3 (MPa)
Elongation at break (X-Y)
ASTM D638 (ISO 527, GB/T 1040)
1.4 ± 0.3 (%)
Bending modulus
ASTMD790 (ISO 178, GB/T 9341)
2119 ± 60 (MPa)
Bending strength
ASTMD790 (ISO 178, GB/T 9341)
48.0 ± 1.9 (MPa)
Charpy impact strength
ASTM D256 (ISO 179, GB/T 1043)
12.2 ± 1.03 (kJ/m2)
Parameter
Nozzle temperature
190 - 230 (˚C)
Build Surface material
BuildTak®, Glass, Blue Tape
Build surface treatment
Glue, Magigoo
Build plate temperature
25-60 (˚C)
Cooling fan
Turned on
Printing speed
60 (mm/s)
Raft separation distance
0.2 (mm)
Retraction distance
1 (mm)
Retraction speed
20 (mm/s)
Recommended environmental temperature
Room temperature - 45 (˚C)
Threshold overhang angle
45 (˚)
Recommended support material
PolySupport™ and PolyDissolve™ S1
Nov. 2018
Technical Data Sheet
Version 4.0
PolyMax™ PLA
PolyMax™ PLA is an incredibly easy-to-print filament with improved mechanical properties, making it an excellent
alternative to ABS.
Physical Properties
Tested with 3D printed specimen of 100% infill
Mechanical Properties
All testing specimens were printed under the following conditions:
nozzle temperature = 205 °C, printing speed = 60 mm/s, build plate temperature = 40 °C, infill = 100%
All specimens were conditioned at room temperature for 24h prior to testing
Recommended printing conditions
Based on 0.4 mm nozzle and Simplify 3D v.4.0. Printing conditions may vary with different nozzle diameters
www.polymaker.com
Nov. 2018
20.00
4*R25
10.00
150.00
114.00
80.00
4.00
Z axis
60.00
80.00
10.00
4.00
Z axis
45.00°
80.00
10.00
4.00
Z axis
Impact direction
Technical Data Sheet
Tensile testing specimen; ASTM D638 (ISO 527, GB/T 1040)
Version 4.0
Flexural testing specimen; ASTMD790 (ISO 178, GB/T 9341)
Impact testing specimen; ASTM D256 (ISO 179, GB/T 1043)
Disclaimer:
The typical values presented in this data sheet are intended for reference and comparison purposes only. They
should not be used for design specifications or quality control purposes. Actual values may vary significantly with printing
conditions. End- use performance of printed parts depends not only on materials, but also on part design, environmental
conditions, printing conditions, etc. Product specifications are subject to change without notice.
Each user is responsible for determining the safety, lawfulness, technical suitability, and disposal/recycling
practices of Polymaker materials for the intended application. Polymaker makes no warranty of any kind, unless
announced separately, to the fitness for any use or application. Polymaker shall not be made liable for any damage, injury
or loss induced from the use of Polymaker materials in any application.
