PolyJohn Grandstand PSW1-2000, PSW2-1000 HandStand 2 User Manual

PSW1-2000 - Handstand 2

January -2018

Page 1 of 4

PSW1-2000

Grandstand™

Wash Stand with Wheels

User Manual

The PSW1-2000 Grandstand™ sink is easily transportable
with a built-in handle and rubber treaded wheels.
Designed for use where convenient hand washing

is desired or required, such as ofces, classrooms,

construction sites, festivals, food service locations,

etc., to be used indoors or out. The compact design
allows it to be used most anywhere. Ideal where
space is limited. Shipped fully assembled.

General Overview

Specications

Height 62 in 157.5 cm

Width 18 in 45.5 cm

Depth 22 in 55.9 cm

Fresh Water Capacity 15.5 gal 58.7 L

Gray Water Capacity 19 gal 72 L

Pump Capacity (per stroke) 2  oz 59.14 ml

Soap Dispenser Capacity 30  oz 887 ml

Number of Single Dispenses 992 992

Paper Towel Capacity

1 Roll or 500 Single Fold

(2 packs - Georgia Pacic 23504)

Weight Empty 47 lb 21.3 kg

Weight Full 177 lb 80 kg

Power Requirement 110 V 15 Amp

Nominal Water Temp 110

o

POLYJOHN

USA

PolyJohn Enterprises Corp

2500 Gaspar Ave.

Whiting, IN 46394

Phone: [phone]

Fax: [phone]
www.polyjohn.com

[e-mail]

POLYJOHN

WORLDWIDE

PolyJohn (UK) Ltd.

Equinox 1 Audby Lane

Wetherby, England LS22 7RD

Phone: [phone]

Fax: [phone]

www.polyjohn.co.uk

[e-mail]

POLYJOHN

CANADA

PolyJohn Canada

P.O. Box 2300

199 Forest Plain Rd.

Orillia, Ontario LV3 6S2

Phone: [phone]

Fax: [phone]

www.polyjohncanada.ca

[e-mail]

All materials, including resin, pigments
and additives used to make the plastic
components as well as the plumbing
components that come in contact with
the fresh water are U.S. FDA food grade
compliant.

PSW1-2000 - Handstand 2

January -2018

Page 2 of 4

Emptying Fresh Water

Drain the fresh water by unscrewing the
1” plug located at the bottom of the sink,
to the left of the foot pump. Tighten the

plug when nished.

Emptying Gray Water

Wheel the sink to a proper and approved
drain location. Pull the hose out from
the rib on the back of the holding tank,
remove the hose cap and empty the gray

water. Replace the cap when nished.

Filling with Fresh Water

Unscrew the 1” ll plug located at the top, left

hand side of the wash basin. Insert a standard

3/4” garden or similar type hose and ll with a

few gallons of fresh water to perform a system
check. Depress the pump a few times to “prime”
it (the pump has a built-in check valve that will hold

a prime between uses). If needed, continue lling

to the top (which is the 15.5 gallon water level ca-
pacity). Tighten the plug when nished.

Fresh Water
Fill Plug

Fresh Water
Drain Plug

Operation Directions

Paper Towel Dispenser

These dispensers are designed to accept towels that are no wider than 9-1/2” wide,
whether using single, multi-fold, or a roll towel. The recommended towels are the

Georgia Pacic #23504 - single fold towel or the Baywest Ecosoft #46200 - roll towel.

Opening the Paper Towel Dispenser

Position your hands on both sides of the

dispenser cover (as shown). While pulling

out on both sides lift up the cover and pull

down towards yourself .

Filling the Dispenser

Filling with Fold Towels: Place the package

of towels on the towel tray with the fold of the

towel facing downward. Pull the rst towel through the

middle opening of the paper towel tray. Close the cover.

Filling with a Roll of Towels: Place the roll of towels on the spindle with the roll of
towels coming off towards you with the arrow end of the spindle facing towards the
right. Place the spindle into the right side of the dispenser rst. Place the left side
of the spindle into the groove on the left side of the dispenser and push down in
place. Feed the roll of towels over the front of the paper towel tray. Close the cover.

PSW1-2000 - Handstand 2

January -2018

Page 3 of 4

Parts Drawings - Exploded Views

PC-000795 Serial ID Plate

(2) PC-000105 Rivets

PC-100421 - Drain Plug Assy

PC-000241 - 1” O-Ring
PC-000418 - UniSeal
PC-100421B - Drain Plug Body
PC-100421P - Drain Plug

PC-000581G - Sink Tap

(2) PC-000107 - Rivet
(2) PC-000106 - Washer

PC-000554 - 1" Fill Plug

PC-000345 - 1” O-Ring

PSE2-0001

Sink Tank

PS02-0003 - Foot Pump Plate

(2) PC-000147 - Screw

CT38-003

3/8" Tubing x 3" Long

PC-000415

Rubber UniSeal

CH075-037 - 3/4"

Drain Hose 37" Long

CT38-046 - Tubing

3/8" O.D. x 46" Long

PC- 000339

Elbow 3/8" Tube x 3/8" Npt

PC-000325 - Straight

1" Npt x 3/4" Barb

PC-000351 - #10

Hose Clamp

PC-000600 - Baby Foot Pump

(4) PC-000102 - Rivet Small Flange
(4) PC-000106 - Washer

PSE2-1000 - PARTS DIAGRAM

http://www.polyjohn.com/pc-000600

http://www.polyjohn.com/pc-100421

http://www.polyjohn.com/pc-000581G

http://www.polyjohn.com/pc-000554

http://www.polyjohn.com/pse2-0001

http://www.polyjohn.com/ps02-0003

http://www.polyjohn.com/ct38-003

http://www.polyjohn.com/pc-000415

http://www.polyjohn.com/ch075-037

http://www.polyjohn.com/ct38-046

http://www.polyjohn.com/pc-000325

http://www.polyjohn.com/pc-000351/

http://www.polyjohn.com/pc-000339

http://www.polyjohn.com/pc-000795

http://www.polyjohn.com/pc-000102

http://www.polyjohn.com/pc-000147

http://www.polyjohn.com/pc-000106

http://www.polyjohn.com/pc-000241

http://www.polyjohn.com/pc-000418

http://www.polyjohn.com/pc-100421b

http://www.polyjohn.com/pc-100421p

http://www.polyjohn.com/pc-000107

http://www.polyjohn.com/pc-000106

http://www.polyjohn.com/pc-000345

http://www.polyjohn.com/pc-000105

Soap Dispenser

To ll the soap dispenser, open it by turning the lid counter
clockwise and lift up. Fill with 30 uid ounces (or desired

amount) of liquid soap, place the lid back on, and turn clock­wise to lock the lid in place. To remove the dispenser for
cleaning, remove the lid, and locate the tab on the middle of
the mounting plate at the rear of the dispenser. Push in on
it, and slide the dispenser up, and off. The lid can be secured
back on the dispenser for storage.

Winterizing

• Drain all water from the tanks.

• Flush tank with a solution of chlorine and water.

• Depress the foot pump to run the clorine solution through the lines.

• Drain all water from the tanks and while the drains are open, continue to pump
the foot pumps to clear all of the liquids from the lines.

PSW1-2000 - Handstand 2

January -2018

Page 4 of 4

www.polyjohn.com/pc-000222

www.polyjohn.com/pc-000105

www.polyjohn.com/paper-towel-dispenser

www.polyjohn.com/pc-000105

www.polyjohn.com/pc-000106

www.polyjohn.com/pc-000213

www.polyjohn.com/psw1-0021

www.polyjohn.com/psw1-0001

www.polyjohn.com/pc-000417

www.polyjohn.com/pc-100316

www.polyjohn.com/pc-000354

www.polyjohn.com/ch100-0435

www.polyjohn.com/pc-000354

www.polyjohn.com/pc-000376

www.polyjohn.com/pc-000313

www.polyjohn.com/pc-000377

www.polyjohn.com/pc-000111

www.polyjohn.com/pc-000110

www.polyjohn.com/pc-000106

www.polyjohn.com/pc-000102

www.polyjohn.com/pc-100146

www.polyjohn.com/pc-100451

www.polyjohn.com/pc-000417

www.polyjohn.com/euro-sink

www.polyjohn.com/pc-000175

www.polyjohn.com/pc-000140

www.polyjohn.com/pc-000123

www.polyjohn.com/liquid-soap-dispenser

www.polyjohn.com/pc-000105

www.polyjohn.com/pc-000106

PSE2-1000

Euro Wash Stand
Complete

(2) PC-000175 - Screw
(2) PC-000140 - Nut
(4) PC-000123 - Washer

TD04-1000 - Paper Towel

Dispenser

(4) PC-000105 Rivet
(4) PC-000106 Washer

PC-000417

3/4” Uni-Seal

Not Shown

PC-000222 - Spring Clip

(2) PC-000105 - Rivets

PSD1-1000 Soap

Dispenser

(3) PC-000105 - Rivet
(3) PC-000106 - Washer

PSW1-0001

- Wash Stand W/Wheels Tank

PC-000377

- 3/4” Garden Hose Cap

PC-000313

- Rubber Hose Washer

PC-000376

- Fitting 1” x 3/4” MGHT

PC-000354

- Hose Clamp

CH100-0435

1”I.D. x 43.5” Long

PC-000354 - Hose Clamp

PC-100316 - Elbow

1” Barb x 1” Barb

PC-000417 - 3/4” Uni-Seal

PSW1-0021 - Axle

PC-000213 - Wheel,

Rubber Tread

PC-100451 - 4” Hatch and Cap

(1) PC-100146 - 12” Tether
(4) PC-000102 - Rivet
(3) PC-000106 - Washer
(1) PC-000110 - Rivet
(1) PC-000111 - Washer

Parts Drawing - Exploded View

Cleaning and Maintenance

Use a mild soap to clean all surfaces and component parts.

Minor scratches and abrasions can be lightly sanded or scrubbed with a
mild abrasive cleaner (such as “Soft Scrub”) that contains calcium carbonate,
hypochlorate bleach and detergents. Be sure to follow the cleaning product

directions since these ingredients may cause hazardous gases when mixed with

other chemicals. Rinse the cleaned area and buff with a conventional wax.

Some light scratches may also be hidden by using an industrial hot air gun.

To keep the water fresh add a “Fresh Sink Tablet” (chlorinated tablet)(our part

number CK01-0030) each time the sink is lled with water.
