Ice Maker
User Manual
[Revision 2.0 May 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this
manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE ©2017 Polycool
Ice Maker
E&OE © 2017 Polycool 2
Safety
When using electrical appliances, basic safety precautions should always be followed, including the following:
• Electric shock/electrocution hazard - NEVER immerse the electrical cord or appliance body in water.
• Indoor use only - do not use outdoors.
• The appliance must be used on flat, level surfaces only.
• Some surfaces of the appliance may become hot during use (especially the cooling system components).
• Allow at least 150mm (6") of clearance around the appliance and do not use the appliance near sources of
heat (ovens etc).
• It is recommended to use only bottled, filtered or tap water that is suitable for drinking. Do not use any
other type of liquid, such as fruit juice.
• Do not use water that has remained in the appliance for a period of time – it is recommended to always use
fresh water at each use.
• Unplug from the electrical supply while not in use, when assembling and before cleaning.
• Supervision is necessary when using the appliance near children.
• Do not allow children to operate or play with the appliance.
• Lift/carry the unit by holding the body with both hands. Do not allow the unit to tilt >45° when being moved
or transported, otherwise, damage to the compressor may result.
• Do not use the unit if it causes a circuit breaker to trip – have it inspected and repaired at an authorized
service center or by a qualified technician. Never try to replace parts or repair the unit by yourself.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge. All users should have adequate training in safely
operating the product or be under supervision of a person responsible for their safety
• Do not operate the appliance if the cord or plug is damaged.
• This appliance is for domestic use only.
Before First Use
• Check that the voltage indicated on the rating label corresponds to the mains voltage.
• Thoroughly clean all parts except the body in warm soapy water, then rinse and dry.
• Place the appliance where it is to be used, open all covers and allow to stand for a minimum of 2 hours
before connecting to power
Ice Maker
E&OE © 2017 Polycool 3
Table of Contents
Safety ............................................................................................................................................. 2
Before First Use ........................................................................................................................................... 2
Parts Identification ........................................................................................................................ 4
Operation ....................................................................................................................................... 5
Water Filling ................................................................................................................................................. 5
Console and Functions ................................................................................................................................ 5
Making Ice .................................................................................................................................................... 6
Care and Maintenance .................................................................................................................. 6
Troubleshooting ............................................................................................................................ 7
Specifications ............................................................................................................................... 8
Ice Maker
No.
Name
No.
Name
1
Body
3
Control Panel
2
Ice / Water Reservoir Cover
4
Drain Port
1 4 3
2
Parts Identification
E&OE © 2017 Polycool 4
Ice Maker
Control
Description
START
Press to switch the appliance ON and begin making ice.
STOP
Press to switch the appliance OFF.
SELECT
Press to select the required ice cube size. The lamp next to the "size" icons illuminates to show the
current selection. Note that larger cubes take longer to produce, however, also melt at a slower
rate. For higher ambient temperatures, large is recommended.
ADD WATER
Illuminates if the water reservoir empty – add water to the machine. Machine may also beep.
ICE FULL
Illuminates if the ice reservoir is full. When full, no more ice is produced. Machine may also beep.
A
B
Operation
Water Filling
It is recommended to use only bottled, filtered or tap water that is suitable for drinking. Do not
use any other type of liquid, such as fruit juice. • Do not use water that has remained in the
appliance for a period of time – it is recommended to always use fresh water at each use.
1. Disconnect the appliance from the mains electrical supply.
2. Open the ice / water reservoir cover (A).
3. Use a suitable container to fill the water reservoir to just beneath
the ice tray (B).
4. Close the water reservoir cover and reconnect the appliance to the
mains electrical supply.
Console and Functions
The appliance features a display that provides you with information, such as current function, when more
water is required etc, The console activates as soon as the appliance is connected to the electrical supply.
E&OE © 2017 Polycool 5
Ice Maker
This image shows water in the
ice making tray and ice forming
on the cooling elements. When
the ice cubes are ready, the
remaining water is returned to
the water reservoir, the ice drops
from the cooling elements and is
shifted to the ice reservoir by a
"comb".
Making Ice
If ice is made and left in the appliance, it may eventually melt – when melted, the water returns to the
water reservoir. Be careful to avoid overflow from the water reservoir due to melted ice adding to the
current reservoir contents. • Ensure that adequate water is in the water reservoir when making ice. • It takes
several minutes to create each batch of ice cubes, and this is also affected by the ambient temperature – do
not expect instant ice to be available. To monitor ice production, view it through the "window" in the ice / water
reservoir cover – do not allow the cover to remain open, and close it as soon as possible in order to retain
ice-cold temperatures in the ice reservoir. • Note that the size of the ice cubes may vary for the first few ice
making cycles.
Switch the ice making function ON using the START button. When on, the appliance draws water up from the
water reservoir into the cooling unit, creates the ice, drains excess water back into the water reservoir, then
moves the ice into the ice collection tray. Use the supplied scoop to collect the ice.
Care and Maintenance
• After use, drain the appliance by removing the drain cap on the rear of the unit until no water remains.
Re-install drain cap and open reservoir covers approximately halfway and leave open. This helps
thoroughly dry the inside of the appliance and helps prevent corrosion of surfaces.
• After each use, clean the inside of the appliance with a cloth and a solution of water and a small amount of
vinegar. Do not use detergents, solvents or chemicals.
• When the appliance is in use, ensure that the reservoir cover is fully closed.
• Regularly remove any accumulated dust from the air vents and cooling holes in the body of the machine.
• If required, clean the appliance body with a damp cloth. Do not use detergents, solvents or chemicals.
E&OE © 2017 Polycool 6
Ice Maker
Possible Fault
Action
No electrical supply
Check that mains electricity is available and the appliance is properly connected to it.
No water
Press STOP button. Add adequate water to water reservoir. Wait 3 minutes, then restart the
ice making function (press START button).
Ice collection tray full
Remove ice from the tray to allow appliance to produce ice.
Air in water system
Remove the drain cap from rear of appliance and allow several drops of water to escape
before re-installing the cap.
Ambient temperature too high
Operate unit in a cooler area. Ensure that heat sources (ovens etc) are at least 150mm (6")
away from the appliance.
Cooling or control unit faulty
Have appliance inspected and repaired by an authorised service centre or technician.
Possible Fault
Action
Ambient temperature or temperature
of water in reservoir too low
Operate in a warmer area.
Possible Fault
Action
Ice shifting "comb" blocked
A build-up of ice may be preventing the "comb" from moving. Press STOP button. Gently move
the comb slightly, and check that the machine is horizontal. Wait 3 minutes, then restart the ice
making function (press START button).
Possible Fault
Action
Input voltage fault
Check input voltage to appliance and ensure it is compatible.
Troubleshooting
Some maintenance activities described may be beyond the scope of some users. For procedures
that you are not comfortable with or have the tools or experience for, have the unit serviced by a
service centre or qualified technician.
The following information may assist in identifying a problem and rectifying it.
Ice not being produced.
Ice sticking together.
ICE FULL and ADD WATER indicators on at same time.
Compressor unit noisy / buzzing.
E&OE © 2017 Polycool 7
Ice Maker
Input Voltage
240VAC / 50Hz
Water Reservoir Capacity
3.2l
Ice Output Capacity
18 to 20kg per 24 hours
Refrigerant Agent
R134a
Dimensions
400mm (h) x 375mm (w) x 400mm (d)
Weight
Approximately 13.5kg without liquids
Specifications
E&OE © 2017 Polycool 8
Ice Maker
E&OE © 2017 Polycool 9
Some experts believe the incorrect or prolonged use of almost any product could cause serious
injury or death. For information that may reduce your risk of serious injury or death, consult the
points below and additionally, the information available at www.datastreamserver.com/safety
• Consult all documentation, packaging and product
labelling before use. Note that some products feature
online documentation which should be printed and kept
with the product.
• Check product for loose / broken / damaged / missing
parts, wear or leaks (if applicable) before each use.
Never use a product with loose / broken / damaged /
missing parts, wear or leaks (if applicable).
• Products must be inspected and serviced (if applicable)
by a qualified specialist every 6 months assuming
average residential use by a person of average weight
and strength, above average technical aptitude, on a
property matching average metropolitan specification.
Intended use outside these guidelines could indicate the
product is not suitable for intended use or may require
more regular inspection or servicing.
• Ensure all possible users of the product have completed
an industry recognized training course before being given
access to the product.
• The product has been supplied by a general merchandise retailer that
may not be familiar with your specific application or your description of
the application. Be sure to attain third-party approval for your application
from a qualified specialist before use regardless of prior assurances by
the retailer or its representatives.
• This product is not intended for use where fail-safe operation is
required. As with any product (take an automobile, aircraft, computer or
ball point pen for example), there is always a small chance of technical
issues that needs to be repaired or may require replacement of the
product or a part. If the possibility of such failure and the associated time
it takes to rectify could in any situation inconvenience the user, business
or employee then the product is not suitable for your requirements. This
product is not for use where incorrect operation or a failure of any kind,
including but not limited to a condition requiring product return,
replacement, service by a technician or replacement of parts could
cause a financial loss, loss of employee time or an inconvenience
requiring compensation.
• If this item has been purchased in error after considering the points
above, simply contact the retailer directly for details of their returns
policy, if required.
©2017 Polycool. All rights reserved. No part of this document, including descriptive content, concepts, ideas,
diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying, scanning or recording, or any information storage and retrieval system, without
express permission or consent from the publisher.
