DATA SHE ET

Polycom® VVX® D60 Wireless Accessory

The ideal wireless companion for your
immediate workspace

The Polycom® VVX® D60 Wireless Handset complements the Polycom® VVX®
series of Business Media Phones by oering the convenience of a cordless solution
as a simple add-on device. The V VX D60 Wireless Handset oers the same SIP
features as the VVX desk phones and is an ideal solution for small businesses, retail
environments or administrative personnel that need to collaborate while moving
throughout the day.

Maximize productivity

Whether deployed in a business environment that requires workers to move around
or in a small oce with no dedicated receptionist, the V VX D60 Wireless Handset
helps teams communicate with ease, whether talking to customers or with each other.

Familiar user experience

Users familiar with VVX business media phones will also feel comfortable using the
VVX D60 Wireless Handset as they both leverage the same robust feature set and
user experience of the Polycom UC Sof tware. This commitment to commonality
across devices means the VVX D60 will increase end-user satisfaction, shorten
training time and reduce the number of support calls for IT sta and service providers.

Stress-free installation and setup

The VVX D60 Wireless Handset oers a straightforward installation experience. With
the same device provisioning and management process as the VVX desk phones,
the VVX D60 is the easiest cordless solution to deploy.

Benefits

• Combines the freedom of wireless
communication with business
features usually reserved for
desk bound users

• Work space mobility—
The freedom to take your
conversation wherever you go

• Easy to use, easy to navigate with
the high-resolution color display
and simple navigation buttons

• Best-in-class deployment,
configuration and administration
through a web-based
configuration tool

• Leverage previous IT infrastructure
investments—deploy VVX D60
business media phones on your
existing network without needing to
upgrade your call control platform

Market-leading open standards interoperability

Designed for enhanced interoperability, the VVX D60 Wireless Handset leverages
and complements your existing IT investments. With the broadest call server
interoperability in the industry, the Polycom V VX D60 Wireless Handset can become
a flexible and future-proof addition to any organization’s unified
communications strategy.

Flexible solution

The Polycom V VX D60 Wireless Handset can be paired to any VVX Business Media
Phone models deployed in a wide range of Open SIP environments.

DATA SHEET Polycom VVX D60 Wireless Accessory

Polycom VVX D60 product
specifications

Open Application Platform

• Bundled with Polycom UC Software:

- Corporate directory access
using LDAP

• Visual conference management

Network and Provisioning

• Provisioning via VVX1

• SIP protocol support

• SDP

Security

• 802.1X authentication and EAPOL

• Media encr yption via SRTP

• Transport layer security

• Encrypted configuration files

• Digest authentication

• Password login

• Support for URL syntax with password for
boot server address

• HTTPS secure provisioning

• Support for signed software executables

IETF SIP (RFC 3261 and
companion RFCs)

• Two-port Ethernet switch

- 10/100Base-TX across LAN and PC por t

- Conforms to IEEE802.3-2005 (Clause

40) for physical media attachment

- Conforms to IEEE802.3-2002 (Clause

28) for link partner auto-negotiation

• Manual or dynamic host configuration
protocol DHCP network setup

• Time and date synchronization
using SNTP FTP/TFTP/HTTP/HTTPS
server-based central provisioning for
mass deployments

• Provisioning and call server redundancy
supported

2

• QoS suppor t – IEEE 802.1p/Q tagging
(VLAN), Layer 3 TOS, and DHCP

• LLDP-MED for VLAN discovery

• Network address translation – support
for static configuration and “Keep-Alive”
SIP signaling

• RTCP and RTP support

• Event logging

• Syslog

• Status and statistics reporting

• IPv4

• TCP

• UDP

• DNS-SRV

Frequency

• 1920-1930 MHz

• 1880-1900 MHz

1

1

1

1

• 1880-1895 MHz

• 1896-1903 MHz

• 1910-1920 MHz (post FCS)

• 1921-1930 MHz (post FCS)

• 1786-1791 MHz (post FCS)

Range

• Indoor: 165ft (50m)

• Outdoor: 980f t (300m)

Size

• Base station size: 6.3 x 2.75 x 5.0 in
(16 x 7 x 12.5 cm) (W x H x D)

• Handset size: 2 x 6.7 x 1 in
(5 x 17 x 2.5 cm) (W x H x D)

• Handset charger size: 3.75 x 2.20 x 3.35
in (9.5 x 5.5 x 8.5 cm) (W x H x D)

Handset User Interface Features

• 2 in color TFT LCD display
(resolution 178 x 220 pixel)

• Voicemail support

2

• Unicode UTF-8 character suppor t.
Multilingual user interface including
Chinese, Danish, Dutch, English (Canada/

1

US/UK), French, German, Italian,
Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Slovenian, Spanish
and Swedish

Handset Audio Features

• Full-duplex conversations, acoustic echo
cancellation and background
noise suppression

• Frequency response – 150 Hz – 7 kHz for
handset, optional headset and hands­free speakerphone modes

• Narrowband Codecs: G.711 (A-law and
μ-law), G.729AB

• Wideband Codec: G.722

• Individual volume settings with visual
feedback for each audio path

• Voice activity detection

• Comfort noise generation

• DTMF tone generation (RFC2833,
in-band and SIP INFO)

• Low-delay audio packet transmission

• Adaptive jitter buers

• Packet loss concealment

Handset Call Handling Features

• Multiple Lines Support for Handsets
(5 lines per HS)

• Up to 4 simultaneous calls

• Up to 5 handsets

• Shared call/bridged line appearance

• Distinctive incoming call treatment/
call waiting

• Call timer and call waiting

• Call transfer, hold, divert (forward), pickup

• Called, calling, connected
party information

• Local 3-way audio conferencing

• 1-touch speed dial, redial

• Remote missed call notification

• Do not disturb function

• Intercom

Headset and Handset Compatibility

• Dedicated 2.5 mm headset port

• External 2.5 mm to 3.5 mm
headset adapter

• Compliant with ADA Section 508 Subpart
B1194.23 (all)

• Hearing aid compatible handset for
magnetic coupling to hearing aids

Handset Power

• External universal AC adapter
(5V 6W DC)

Handset Battery

• 1 Ni-MH 800 –mAh (2.4V ) AAA battery
(rechargeable)

• 10 hours talk time

• 100 hours standby time

Polycom VVX D60 Base Station
comes with:

• VVX D60 wireless handset

• VVX D60 wireless base station

• Network (LAN) cable

• Wireless handset belt clip

• Wireless handset 2.5 mm to 3.5 mm
headset adapter

• Battery pack

• Quick start guide

• Power adapter (some SKUs are PoE only,
so the power supply may be ordered
separately)

Polycom VVX D60 Wireless Handset
comes with:

• Handset

• Charger

• 2.5 mm to 3.5mm headset adapter

• Quick start guide

• Power adapter

Approvals

• FCC

2

• IC RSS

• CE

• Israel COMM

• Japan Radio Law Certificate

• AU/NZ RCM

• Hong Kong HKCA

• Singapore IDA TS CT-CTS

• Tai w an NCC

• ROHS compliant

DATA SHEET Polycom VVX D60 Wireless Accessory

Safety

• UL 60950-1

• CE Mark

• CAN/CSA C22.2 No 60950-1

• EN 60950-1

• IEC 60950-1

• AS/NZS 60950.1

Operating Conditions

• Temperature: 0 to 40°C (+32 to 104° F)

• Relative humidity: 25% to 90%,
noncondensing

Storage Temperature

• -40 to +65 °C (-40 to +149°F)

Part Numbers

VVX D60 Base Station

• 2200-17821-001 - (PoE), Countries: NA

• 2200-17821-015 - (PoE), Countries: EEA ,
ANZ, UK

• 2200-17821-023 - (PoE), Countries:
Tai w a n

• 2200-17821-002 - (PoE), Countries: Japan

Post FCS

• 2200-17821-212 - (PoE), Countries: Brazil

• 2200-17821-010 - (PoE), Countries:
Argentina

• 2200-17821-016 - (PoE), Countries: Korea

VVX D60 Wireless Handset

• 2200-17825-001 - Countries: NA

• 2200-17825-015 - Countries: EEA,
ANZ, UK

• 2200-17825-023 - Countries: Taiwan

• 2200-17825-002 - Countries: Japan

Post FCS

• 2200-17825-212 - Countries: Brazil

• 2200-17825-010 - Countries: Argentina

• 2200-17825-016 - Countries: Korea

• 2200-17825-030 - Countries:
South Africa

Weight

• Base station weight: 0.574 lbs (0.26 kg)

• Handset: 0.272 lbs (0.12 kg)

• Handset charger: 0.16 lbs (0.07 kg)

Unit Box Dimensions / Weight

Base Station

• 8 x 3..5 x 8.65 in (20.5 x 9 x 22 cm)
(W x H x D)

• 1.87 lbs (0.85 kg)

Handset

• 8 x 3.75 x 6.1 in (20.5 x 9.5 x 15.5 cm)
(W x H x D)

• 1.226 lbs (0.56 kg)

Master Carton Quantity

• 10

Country of Origin

• China

Warranty

• 1 year

1. Compatible with VVX 300/310/400/410/500/600.
Please note: the V VX 101/201/1500 and
Expansion Modules are not currently supported.

2. Most software-enabled features and

capabilities must be supported by the server.
Please contac t your IP PBX/soft switch
vendor or service provider for a list of
supported features.

3. Requires UC Sof tware 5.4. 3 or greater
on host phone.
