Polycom READIVOICE User Manual

ReadiVoice

Release Notes

v2.56.0

Copyright 2005 by Polycom, Inc.
All Rights Reserved

Polycom, the Polycom logo, Voyant, and ReadiVoice are registered trademarks of Polycom, Inc. Any other
trademarks appearing in this document are the property of their respective owners.

The information in this document is the sole intellectual property of Polycom, Inc., and may not be copied,
transcribed, distributed, or used for any other purpose without prior written permission from Polycom, Inc.

The information in this document is subject to change without notice.

Catalog No. 3725-70002-009G2

Proprietary and Confidential

The information contained herein is the sole intellectual property of Polycom, Inc. No distribution,
reproduction or unauthorized use of these materials is permitted without the express written consent of
Polycom, Inc. Information contained herein is subject to change without notice and does not represent
commitment of any type on the part of Polycom, Inc. Polycom and are registered trademarks of
Polycom, Inc.

Notice

While reasonable effort was made to ensure that the information in this document was complete and accurate
at the time of printing, Polycom, Inc., cannot assume responsibility for any errors. Changes and/or
corrections to the information contained in this document may be incorporated into future issues.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 2 Confidential and Proprietary

Table of Contents

Introduction................................................................................................................................ 5

1

2 What’s New in ReadiVoice v2.56.0..........................................................................................5

2.1 Windows Operator Production Availability............................................................ 5

2.2 Multiple Subscriber Access Numbers .......................................................................6

3 Other Enhancements and Changes in ReadiVoice v2.56.0...................................................7

3.1 Moderator API Changes.............................................................................................. 7

3.2 CAPI Changes............................................................................................................... 8

3.3 Configuration and Implementation Changes...........................................................9

3.4 SNMP changes............................................................................................................ 10

3.5 Database Changes ...................................................................................................... 10

3.6 PSPI Changes .............................................................................................................. 10

3.7 InnoVox Changes....................................................................................................... 10

3.8 Routing Interface Changes........................................................................................ 10

4 ReadiVoice v2.55.0................................................................................................................... 11

4.1 Conferencing API (CAPI).......................................................................................... 11

4.2 Multi-language Prompts ........................................................................................... 12

4.3 Blast Dial Enhancement............................................................................................. 13

4.4 External ID B Field .....................................................................................................15

4.5 HP OpenView MIB Access .......................................................................................15

5 Other Enhancements and Changes in ReadiVoice v2.55.0.................................................15

5.1 Moderator Branding .................................................................................................. 15

5.2 Moderator API Changes............................................................................................ 16

5.3 Configuration and Implementation Changes.........................................................18

5.4 Database Changes ...................................................................................................... 18

5.5 CDR Changes.............................................................................................................. 19

5.6 PSPI Changes .............................................................................................................. 20

5.7 InnoVox Changes....................................................................................................... 20

5.8 Routing Interface Changes........................................................................................ 20

6 ReadiVoice v2.53.1................................................................................................................... 21

6.1 Database Changes ...................................................................................................... 21

6.2 CDR Changes.............................................................................................................. 21

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 3 Polycom, Inc.

6.3 Routing Interface Changes........................................................................................ 21

7 ReadiVoice v2.53.0................................................................................................................... 22

7.1 Larger System Configurations.................................................................................. 22

7.2 Intelligent Network Call Routing Interfaces ..........................................................23

8 Other Enhancements and Changes in ReadiVoice v2.53.0.................................................24

8.1 Automatic Gain Control............................................................................................ 24

9 Upgrading to ReadiVoice v2.56.0..........................................................................................24

10 Software Versions.................................................................................................................... 25

11 Known Limitations..................................................................................................................26

11.1 ReadiVoice v2.56.0 ..................................................................................................... 26

11.2 Innovox v4.21.0........................................................................................................... 27

11.3 ReadiVoice v2.53.1 ..................................................................................................... 27

11.4 InnoVox v4.13.0 ..........................................................................................................29

11.5 ReadiVoice v2.50.4 ..................................................................................................... 29

12 Resolved Issues ........................................................................................................................ 29

12.1 ReadiVoice v2.56.0 ..................................................................................................... 29

12.2 Innovox v4.21.0........................................................................................................... 42

12.3 ReadiVoice v2.53.1 ..................................................................................................... 45

12.4 InnoVox v4.13.0 ..........................................................................................................48

12.5 Resolved in ReadiVoice v2.53.0................................................................................ 48

12.6 Resolved in InnoVox v4.12.0.....................................................................................49

12.7 Resolved in ReadiVoice v2.52.0................................................................................ 50

12.8 Resolved in InnoVox v4.10.0.....................................................................................53

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 4 Confidential and Proprietary

1 Introduction

These release notes describe the new and enhanced features in the ReadiVoice v2.56.0 software. They also
document the important issues resolved in and the known limitations of this release.

Thoroughly review these release notes prior to installing or upgrading this product. A more up-to­date version of these release notes may be available. Please contact your account manager to
verify that you have the most recent version.

If you have questions or require more information about this release, please contact Polycom Product
Management at 1-888-447-1087, ext. 5003, or 1-303-223-5003, or Polycom Global Services (Customer Support)
at 1-800-827-7782 or 1-303-223-5223.

2 What’s New in ReadiVoice v2.56.0

ReadiVoice v2.56.0 is feature release. The following table lists the new features in this release.

Feature/Enhancement

Windows Operator Production Availability
Windows Operator Link to Provisioning
Multiple Subscriber Access Numbers PSPI Call
ACM Applications Accessing CDR Data

Note: ReadiVoice v2.56.0 is only available for ReadiVoice PSTN systems. ReadiVoice IP on InnoVox 4000 media servers is

supported with ReadiVoice v2.53.x.

This section describes each new feature in detail. Section 3 describes the enhancements to existing features.
Section

The sections below address the new features and functions. Where appropriate, each section includes:

• Feature description

• Information about provisioning, configuration, and implementation

• Voice prompts added or modified

• Database, PSPI, and CDR changes

• Conferencing API (MAPI, Java and XML) changes

Note: If a feature section doesn’t include a specific subtopic, such as “Voice Prompts,” there are no changes of that type

3 describes other enhancements and changes.

associated with the feature.

2.1 Windows Operator Production Availability

Feature Description

The Windows Operator is made available to all customers in this release. The Windows Operator has all of
the functionality of the browser-based Java Operator. However, unlike the Java Operator, the Windows
Operator can connect to up to three ReadiVoice servers, so an operator can perform tasks for multiple

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 5 Polycom, Inc.

ReadiVoice systems simultaneously. In addition, since it’s a native Windows program, the Windows
Operator offers enhanced performance.

Note: ReadiVoice v2.56.0 is expected to be the final release in which the Java Operator is supported.Please contact your

Polycom account manager if you have questions concering the phase out of the Java Operator.

System Requirements

The Windows Operator application requires a PC with:

• A 2 GHz or better processor, 512 MB RAM (1 GB recommended), and at least 100 MB free disk space.

• Windows 2000 or Windows XP operating system.

• Internet Explorer 5.5 or later (needed only for installation and for accessing the ReadiVoice Provisioning

interface).

• Network connectivity to the ReadiVoice server (CACS) from which to get the application.

• Network connectivity to the other ReadiVoice servers, if the operator station will monitor multiple

ReadiVoice systems.

Installation and Configuration

To install the Windows Operator application, you simply click a link to download the self-extracting client
and follow the prompts. See the ReadiVoice Windows Operator Guide for complete installation and operation
instructions.

Windows Operator Linked to Provisioning

The production release of Windows Operator provides operators with a quick way to change account settings
for a subscriber. The Windows Operator GUI now has a link to the Edit Subscriber provisioning page.
Subscribers’ names appear as a red link. If required, the operator will be prompted to enter a provisioning
username and password. When successful, the system displays the provisioning page for the chosen
subscriber. (1-4281834)

2.2 Multiple Subscriber Access Numbers

Feature Description

ReadiVoice v2.56.0 makes it possible to assign a subscriber four or more access number sets at the same time
via a new PSPI (Provisioning Stored Procedure Interface) procedure called AddSubAndANString.
(1-1XERY/1-6028520) Each access number set consists of an access number, a hidden number, a shared flag
identifying the type of access number (private or shared), and a number type (Toll, Toll-free, etc.).

AddSubAndANString is similar to AddSubAndAN_v2550(), but the three sets of access number parameters
have been replaced by AccessNumberString, which can contain up to 720 characters. Assuming ten-digit
phone numbers, this enables a single stored procedure call to assign up to 27 access numbers to a subscriber.
(This string supports a minimum of 10 access numbers.)

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 6 Confidential and Proprietary

PSPI Requirements

In the stored procedure call, each access number requires four parameters, delimited by commas. Each set of
four parameters must be delimited by pipes. None of them can be left blank. The layout is as follows:

accessNum1,hiddenNum1,sharedFlag1,numberType1|accessNum2,hiddenNum2,sharedFlag2,
numberType2|...

The procedure first adds the subscriber to the database. Then, it parses the string, validates the parameters,
and puts them into a temporary table. Then, the procedure adds each access number to the database (if it
doesn’t already exist), removes it from the temporary table, and assigns it to the subscriber. Next, the
procedure puts the new data into the CacsEventUpdate table. Finally, the CACS updates the call router
with the data from the temporary table.

The new files created to support this stored procedure call are AddSubAndANString.sp,
IU_AddPhoneNum.sp, and IU_AssignNumToSub.sp. The new table created to support this stored
procedure call is PSPIAccNumHolder.

Note: ReadiVoice v2.56.0 is a transition release that supports both the AddSubAndAccNum and AddSubAndANString

stored procedures. ReadiVoice v2.60.0 will support only AddSubAndANString.

3 Other Enhancements and Changes in ReadiVoice v2.56.0

3.1 Moderator API Changes

Note: ReadiVoice v2.56.0 is a transition release that supports the Conferencing API (CAPI), the Java Moderator API (MAPI), the

XML-API, and Application Control Modules (ACM). ReadiVoice v2.60.0 will support only CAPI.

MAPI EVENT Description

WR_CONNECT

ADDED. This event was missing in RV2550 MAPI. It has been
added to current release, and it allows the moderator application to
join chairperson to participant.

LOCK_TYPE_CHANGED

REMOVED. It is a new event introduced in 2550. It causes customer
implemented web moderators to fail due to its unexpected
occurrences. The event has been filtered out, and is no longer
returned to MAPI client application.

ACM_CHAN_ENTER

ACM_CHAN_ENTER now has a PartType parameter (of type
PART_TYPE enum) that tells what type of participant the channel
entering ACM is (PT_SUBSCRIBER, PT_PARTICIPANT). This
saves ACM developers from having to register for a conference and
iterate through the conference's participant list to find participant

type.
File: MESSAGE_SENDER.java
Method: sendACM_QUERY_APP

Query for ACM data now includes the passed bridge ID parameter in

the query string. The method arguments have not changed.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 7 Polycom, Inc.

MAPI EVENT Description

CURRENT_CONF_INFO2

This fix alters ACM MAPI clients that were receiving

CURRENT_CONF_INFO events: It adds a new XBOOL type and a

new CCI enum value to MAPI. If an ACM application was receiving

CURRENT_CONF_INFO before, its handler should be changed to

receive CURRENT_CONF_INFO2 (a child class of

CURRENT_CONF_INFO). In the handler changing the method:

void handle CURRENT_CONF_INFO (CURRENT_CONF_INFO

event) to handleCURRENT_CONF_INFO2

(CURRENT_CONF_INFO2 event) should be all the modification

needed (logic will still be the same as the #2 is a child of the

original).
CAPI Changes to address ACM

Billing Code requirements.

New event added has been added to XML API and CAPI:

SET_CONF_USER_DATA, also CONF_INFO now has a new field:

UserData. The functionality has been added to support future

development of ACM applications.

The change form ULONG -> LONG in RV2550 MAPI may have broken some customer's code. Because
LONG_TYPE was the base for both LONG and ULONG, Java could not auto cast between these types (UINT
as well). The problem has been corrected. ULONG now inherits from LONG instead of the common base
class LONG_TYPE. This allows Java to easily cast down the tree from ULONG to LONG to LONG_TYPE.

3.2 CAPI Changes

CAPI EVENT Description

ACM_CALL_ENTERED

PLAY_NAME

VALIDATE_MODERATOR_LOGIN

MessageSender interface
CastorMessageSender

SET_CONF_USER_DATA
CONF_INFO

CAPI Changes to address ACM
Billing Code requirements.

ACM_CALL_ENTERED now has a PartType parameter to inform as

to the type of participant a channel is entering ACM.

PLAY_NAME event now has a PartPlayTo parmeter that tells what

participant to play part(s) name(s) to (-1 == subscriber).

New event added: VALIDATE_MODERATOR_LOGIN to check

parameters that could be used in a moderator login and return a

matching subscriber ID in a SUBSCR_ID event, or NACK with a bad

login NACK reason. This should be of particular use to application

login type developers. Note: this is not a session event, no login

required of any type (see REQ_SYSTEM_INFO event for similar

behavior).

MessageSender interface and CastorMessageSender changed to

add the extra PlayToPartId parameter (due to the limited scope of

usage of CAPI it was decided an interface change would not be

overly taxing to CAPI developers over having multiple playName

sender methods).

SET_CONF_USER_DATA event has been added to XML API and

CAPI. CONF_INFO now has a new field: UserData. The functionality

has been added to support future development of ACM applications.

New event added has been added to XML API and CAPI:

SET_CONF_USER_DATA, also CONF_INFO now has a new field:

UserData. The functionality has been added to support future

development of ACM applications.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 8 Confidential and Proprietary

3.3 Configuration and Implementation Changes

Windows Operator

Windows Operator is now the default operator application. (PTR: 1-6143907) The "activate" configuration
parameter has been set to 1. The parameter is located in odprocrc.defaults configuration template file.
Configuration file change:

[modules]
[opupdater]
activate = 1
[]
[]

Conferencing API—Configurable Timeout Value

CAPI sessions now have a configurable timeout value. (PTR: 1-5953477) The parameter is located in
odprocrc.defaults configuration template file. The default timeout value is 120 seconds. Configuration file
change:

[modules]
[csc]
timeout = 120
[]
[]

Conferencing API—Check Script Change

In ReadiVoice v2.55.0, CAPI introduced a new Application user type. To further support this user type, ECR
1-5998401 in ReadiVoice v2.56.0 implements a change to the output of the ReadiVoice “check” script so that
the script more accurately reflects the Application sessions and Moderator sessions currently active on the
system.

The output of the “check” script identifies the sessions logged into the system, for example:

Operators logged in: 0
Moderators logged in: 0
Applications logged in: 1

Each application that is logged into the system increments the Applications session counter. However, when
an application registers for subscriber events, it also becomes a push_moderator. In this case, the application
increments both the Moderators session counter and Applications session counter.

So, for every subscriber for which an application registers, the Moderators session counter is incremented.
For example, if an application registers for three separate subscriber events, the “check” script shows:

Operators logged in: 0
Moderators logged in: 3
Applications logged in: 1

As the application unregisters for subscriber events, the Moderators session counter adjusts accordingly.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 9 Polycom, Inc.

3.4 SNMP changes

Application Login type was introduced in RV2550. (PTR: 1-5998401) New SNMP variable
(sysNumAppsActive) has been added to track the number of logged applications.

New MIB entry:

sysNumAppsActive OBJECT-TYPE

SYNTAX Unsigned32

MAX-ACCESS read-only

STATUS current

DESCRIPTION

"Specifies a number of applications logged into the system"

::= { sysOperatorInfo 6 }

The ReadiVoice SNMP MIB can be found in file: /web/snmp/srconf/mgr/conferencenow.mib

3.5 Database Changes

See section 2.2 Multiple Subscriber Access Numbers (1-1XERY/1-6028520)

3.6 PSPI Changes

From ReadiVoice v2.55.0 to v2.56.0

AddSubAndANString See section 2.2 Multiple Subscriber Access Numbers (1-1XERY/1-6028520)

3.7 InnoVox Changes

There were no major feature additions to this release.

3.8 Routing Interface Changes

• SS7_ATT – recompiled against new SS8 library, version 1.4.01

• SS7_DMS -– recompiled against new SS8 library, version 1.4.01

• SS7_DMS_100 – recompiled against new SS8 library, version 1.4.01

• MCI_ROUTING – fixed the ASN.1 component of the MCI routing module to function properly with the

GCC compiler.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 10 Confidential and Proprietary

4 ReadiVoice v2.55.0

ReadiVoice v2.55.0 was a feature release. The following table identifies its new features.

Feature/Enhancement

Conferencing API
Multi-language Prompts
Blast Dial with Recorded Subscriber Name
New External ID B filed
HP OpenView MIB Access

Notes:

– ReadiVoice v2.55.0 is only available for ReadiVoice PSTN systems. ReadiVoice IP on InnoVox 4000 media

servers is supported with ReadiVoice v2.53.x.

– In ReadiVoice v2.55.0, the Windows Operator was a beta release for development and testing purposes only.

For that release, the Java Operator was the only operator interface supported for production systems.

This section describes each new feature in detail. Section 3 describes the enhancements to existing features.
Section 4 describes other enhancements and changes.

4.1 Conferencing API (CAPI)

Feature Description

As a transition, ReadiVoice v2.55.0 (and v2.56.0) supports a new Conferencing API (CAPI) along with the
current Java MAPI, XML API, and Application Control Mode (ACM) programming interfaces. CAPI extends
the functionality of MAPI, XML-API, and ACM interfaces by adding new commands and responses such as
CONF_START and CONF_END. ReadiVoice v2.60.0 will support only CAPI.

Notes: We recommend that you first certify and implement your current MAPI or XML-API clients or ACM applications. Then you

can migrate them to CAPI and roll them out in a subsequent release. The ReadiVoice v2.55.0 CAPI user documentation
includes detailed CAPI migration and implementation documentation, as well as transition examples.

The Conferencing API was developed so that in the future you can access new functionality without having
to support a new API. To extend functionality, CAPI supports a new user type—Application—which is like a
super-moderator that can monitor several conferences at once. The CAPI architecture and how it
encompasses both the Java MAPI and the XML-API are described in detail in the CAPI Developer’s Guide. In
these release notes, we describe just the important new functionality that CAPI enables.

At a high-level:

• CAPI encapsulates the server components from the conferencing application, making it easier to write

and maintain CAPI clients

• CAPI is XML-based, allowing developers to write clients in a variety of programming languages. Java

utility files and event files are provided, as well.

• A conference can have multiple subscriber and participant logins.

• Log4j and Apache Common Logging have been used to provide logging functionality.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 11 Polycom, Inc.

• CAPI uses XML for all transport. Use of XML allows for better backward-compatibility between different

versions of ReadiVoice.

• An ACM event set is provided to allow CAPI clients to interface with external applications.

• Asynchronous and synchronous functionality is available. Asynchronous event notifications for

conference and participants allow for instant notification for any change in participant or conference
state. Notification that requires that some information be generated and returned is sent asynchronously
through a second connection.

At the event level:

• CAPI allows third-party applications to register (APP_REGISTER_CONFS_ACTIVITY event) or

unregister (APP_UNREGISTER_CONFS_ACTIVITY event) for conference start and stop notifications.
When so registered, third-party applications receive a CONF_STARTED event when a conference has
started and CONF_ENDED event when a conference has ended.

• CAPI allows third-party applications to retrieve a list of current conferences. In response to a request for

an active conference list, each media server sends a conference list that includes the start time of each
conference. The third-party application must be prepared to accept a conference list for each media server
in the system.

• The BIG_CONF_INFO event now includes:

– Two subscriber user fields (User Field A, User Field B)
– Two billing user fields (Billing User Field A, Billing User Field B)
– Two External ID fields (External ID and the new External ID B fields)

Compatibility

Existing MAPI clients are compatible with ReadiVoice v2.55.0 with CAPI. However, CAPI clients are not
compatible with pre-v2.55.0 versions of ReadiVoice. To implement CAPI, you must upgrade to RV v2.55.0.

Implementation

The CAPI Developer’s Guide describes how to develop and implement a CAPI client and provides information
useful in migrating an existing MAPI or XML API client to CAPI.

4.2 Multi-language Prompts

Feature Description

In ReadiVoice releases previous to v2.55.x, the conferencing system could use the same audio (.wav) files any
number of times as required to support ReadiVoice call flows. This design supported system efficiency, but
somewhat hindered system flexibility—especially support for multi-language prompts.

In ReadiVoice v2.55.x, almost every unique call for a .wav file calls a unique .wav file. To support this
redesign, ReadiVoice engineering created a new prompt naming scheme and replicated those .wav files that
are used in multiple call flows into multiple .wav files. In addition, a small number of .wav files were
concatenated (joined together) and edited to create new .wav files.

Another issue—multi-digit numbers in different languages have different grammar syntax rules. ReadiVoice
v2.55.0 includes application-level changes necessary to meet these language-specific grammar rules.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 12 Confidential and Proprietary

Refer to the ReadiVoice Custom Prompt Conversion Guide for more information about the new prompt naming
scheme and prompt changes. Refer to the ReadiVoice Administration & Maintenance Guide for a complete list of
prompts and a complete call flow reference.

Implementation

If your ReadiVoice systems use the default ReadiVoice prompt set, the RV v2.55.x system upgrade procedure
automatically manages the change from the old scheme to the new scheme. ReadiVoice engineering has
provided a tool that you can run to automatically update the default prompt set (i.e. the one located in
/rahome/bridge/sound/1) to match the new list of mandatory prompts. The tool will also log any errors it
detects including:

• A list of missing .wav files. (A wav file is missing if the tool needed that file to create the needed output

files.)

• A list of the files that need manual modification (rewording, concatenation)

• A list of the final output files that were not able to be created due the first two conditions

If your ReadiVoice systems use custom prompt sets, you may have to edit, or possibly re-record, a subset of
your custom .wav files before upgrading your systems. The ReadiVoice Custom Prompt Conversion Guide
contains the information you need to prepare your custom prompt sets for the upgrade.

4.3 Blast Dial Enhancement

Feature Description

The Blast Dial feature has been enhanced to allow the system to play a recorded name to the called parties
invited to join a conference via Blast Dial. This allows called parties to easily identify who is inviting them to
join a conference.

Voice Prompts

This feature required the creation of the two new and unique prompts:

File Default prompt

do_blast_dial_subname_announce_.wav

Silence—This is a prefix prompt that allows you to
customize this feature

do_blast_dial_subname_announce.wav

"… is calling you to join an audio conference. Please
press one to join the conference."

You can find these prompts in the call flow illustrated previously.

Provisioning

To implement this feature, a subscriber must be provisioned for the Name Record feature in the Conference
Options. When Name Record is on and a subscriber has started a conference and recorded his/her name, the
system uses the recorded name to customize the greeting it plays to the called parties.

Limitations

The feature is only applicable to Blast Dials initiated via the Java and XML APIs. Single-line dial-outs
initiated via the API or via DTMF, do not connect point-to-point, so a subscriber joins with .

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 13 Polycom, Inc.

Call Flow

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 14 Confidential and Proprietary

4.4 External ID B Field

Feature Description

ReadiVoice v2.55.0 implements a new External ID B field. This field has been added to the Subscriber
database and has many of the properties of the existing External ID field (i.e., it has a maximum length of 30
characters and it is written into CDRs for the subscriber’s conferences). Unlike the existing External ID field,
the system does not check the contents of the External ID B field.

Provisioning

The External ID B field can be provisioned using the Provisioning GUI, the "Quick Provisioning" GUI page,
and PSPI.

4.5 HP OpenView MIB Access

Feature Description

In ReadiVoice v2.55.0 the ReadiVoice, Informix, and Veritas MIBs are made externally accessible to HP
OpenView. No updates or modifications were made to the ReadiVoice core MIB. See the ReadiVoice
Administration & Maintenance Guide for information about the ReadiVoice MIB. The Informix and Veritas
MIBs are documented by their respective owners.

5 Other Enhancements and Changes in ReadiVoice v2.55.0

5.1 Moderator Branding

If your company brands the ReadiVoice Moderator with your company logo, please note that the default
image file size has changed from 37x77 pixels to 35x146 pixels (HxW). See “Customizing and Branding Your
ReadiVoice System” in the ReadiVoice Administration & Maintenance Guide for information on updating the
default image file.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 15 Polycom, Inc.

5.2 Moderator API Changes

Note: ReadiVoice v2.55.0 and v2.56.0 are transition releases that supported the Conferencing API (CAPI), the Java Moderator

API (MAPI), the XML-API, and Application Control Modules (ACM). ReadiVoice v2.60.0 will support only CAPI.

MAPI EVENT Description

SET_CONF_SECURITY_NUM.java

In previous versions of ReadiVoice, each dial-out to subscriber
required sending of SET_SECURITY_NUM. There were different
problems with this approach; especially with timing and the fact that
SET_SECURITY_NUM sending was required otherwise the
conference could end up crippled.

To resolve this, a new SET_CONF_SECURITY_NUM event was
introduced. It can be sent at any time a conference is running and
it's not required.

Guidelines for applications regarding SET_SECURITY_NUM and
SET_CONF_SECURITY_NUM:

• New applications that don't need to set up any conference
security code: No sending of either event is necessary.

• New applications that need to set up a conference security
code: use SET_CONF_SECURITY_NUM. It can be sent at any
time even when no subscriber is in conference.

• Legacy applications that don't need to set up any conference
security code: Remove all the code sending
SET_SECURITY_NUM. Neither SET_SECURITY_NUM nor
SET_CONF_SECURITY_NUM need to be sent during dial-outs
or at any other time.

• Legacy applications that need to set up a conference security
code: Replace SET_SECURITY_NUM with
SET_CONF_SECURITY_NUM. But make sure that
SET_CONF_SECURITY_NUM is sent before the subscriber
joins conference otherwise some participants may join
conference without entering the conference security code.

• Legacy applications that need to set up a conference security
code and their source code has not been changed: They will
work as before but conferences may run with no conference
security code even when a code is specified in
SET_SECURITY_NUM. SET_SECURITY_NUM processing
usually ignores the sent-in CSC.

A good time to send SET_CONF_SECURITY_NUM is as soon as
the conference starts (or before a dial-out to the subscriber is
initiated). Otherwise there is no guarantee for blast dial-outs to the
subscriber that every single caller entered the conference security
code during his call flow. For non-blast dialouts to the subscriber it is
enough to send SET_CONF_SECURITY_NUM before JOIN_CONF
is sent.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 16 Confidential and Proprietary

MAPI EVENT Description

DIAL_FAIL_REASON.java Additional error codes added:

DIAL_INVALID_ARGS:

• when QUICK_DIAL is sent with a participant type other than
PT_SUBSCRIBER

• when ConfId in a dial out event specifies an operator instead of
a regular subscription

DIAL_NO_PERM

• when the dial-out capability is disabled

DIAL_NO_CONF

• when a dial-out event is sent and there is no running conference

DIAL_CONF_ENDING

• when a dial-out event is sent and the conference is ending

BIG_CONF_INFO.java

New member variable: LONG PromptSet – prompt set ID used by
the conference

CONFERENCE_END.java

New member variable: STRING_ ExternalIdB – user defined data,
ECR: 1-5345819

CONF_STARTED.java

New member variable: STRING_ ExternalIdB – user defined data,
ECR: 1-5345819

New member variable: LONG StartTime – conference start time

Several MAPI events have been modified to provide more consistent data type representation of ReadiVoice
internal and database types.

MAPI EVENT Member variable Old Type RV 2550 Type

ACM_CDR.java

SeqId ULONG LONG
TimeBegin ULONG LONG
TimeEnd ULONG LONG
NumDigits ULONG LONG ACM_GET_DTMF.java

TimeOut ULONG LONG
ACM_HEARTBEAT.java SeqId ULONG LONG
ACM_HEARTBEAT_ACK.java SeqId ULONG LONG

PreConfFlag ULONG LONG ACM_OPTION.java

PriorityLevel ULONG LONG
BIG_CONF_INFO.java

RequestCount UINT LONG

StartTime ULONG LONG

nParts UINT LONG

PromptSet New member LONG
CALL_FAILED.java SequenceNumber ULONG LONG
CONFERENCE_END.java ExternalIdB New member STRING_

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 17 Polycom, Inc.

MAPI EVENT Member variable Old Type RV 2550 Type

ExternalIdB New member STRING_ CONF_STARTED.java

StartTime New member LONG

ExtDelay ULONG LONG DIAL_CALL.java

SequenceNumber ULONG LONG
GUI_MODERATOR_LOGIN.java SequenceNumber ULONG LONG
LOGIN_NACK.java SequenceNumber ULONG LONG
MOD_LOGIN_ACK.java SequenceNumber ULONG LONG
PARTICIPANT_INFO.java

PORT_KNOWN.java SequenceNumber ULONG LONG

ChanBoard UINT LONG

ChanNum UINT LONG

ChanSpan UINT LONG

ExtDelay ULONG LONG QUICK_DIAL.java

SequenceNumber ULONG LONG

5.3 Configuration and Implementation Changes

Multi-language Voice Prompt Support Configuration (RV25509354)

The ive.ini configuration file has been modified to reflect new multi-language voice prompt support. The
[DisconnectMsg] section contains updated .wav file names for multi-language voice prompt support.

Dial Out API Security (ECR 1-4577304)

In the ive.ini configuration file, a new DtmfDialingControlEnabled parameter has been added into
the [MiscConfig] section. The default is active or on (1). This parameter will allow the normal dial out
menu commands (once a participant is dialed and talking 1-to-1 with a subscriber) to work. If set to off (0),
DTMF commands—join participant to the conference, join participant and dial out someone else, hook
participant and put subscriber back into conference—will not be recognized.

You may set DtmfDialingControlEnabled to off (0) and disable the eCMD_DIAL_OUT (i.e., comment out
the line in the ive.ini [DTMF_CMDS] section). When this is done, the only way to dial out and join a
participant to conference is via the RV APIs (MAPI/CAP/ACMI).

Instore functionality disabled

The instore module has been removed from the odprocrc configuration file as its functionality was not
utilized and is no longer available.

5.4 Database Changes

External ID B Field in CDR Database (ECR 1-5345819)

The subscriber_info table has a new ExternalIdB field. A new index, called SI_ExternalIdB, has also been
added. The details have been described in section 3.3.2.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 18 Confidential and Proprietary

Several stored procedures have been created were created to support this change. See PSPI Changes on page

20.

Invalid Name Record and Roll Call Combination (PTR 1-5593604)

The stored procedures are now checked for an invalid Name Record and Roll Call combination—Name
Record=ON and configurable, while RollCall=Name and not configurable. This is not a valid combination, to
prevent users from turning Name Record off without changing RollCall to off.

Several stored procedures were modified to enforce the above rule. See

PSPI Changes on page 20.

Conferencing API’s New ‘Application’ User Type (ECR 1-5487601)

We have added a new user type into ReadiVoice, as part of CAPI development. The new user type is called
Application Type. The description of this new user type can be found in CAPI development documentation.
The UserType field has been extended as a result.

Table Users now accept value 7 as valid input for UserType field (it only accept 0,1,2,3,4,5, and 6 before).

5.5 CDR Changes

ACM Data Storage Enhancements (ECR 1-4571804)

Previously Application Control Mode (ACM) allowed users to insert two pieces of information into the CDR
database: an ACM Pin and an ACM Conference Code. ReadiVoice v2.55.0 offers a more flexible solution, one
that allows you to collect additional information from ACM end-users and save the information in the
acm_cdr_data table of the CDR database. The acm_cdr_data table contains acm_name and acm_value,
which gives you the freedom to send data with whatever keyword you wish. These data can be easily
retrieved for processing at a later time.

(External ID B Field in CDR and CNOW Databases (ECR 1-5345819)

Some of our customers keep subscription information in their master databases. The subscription information
will be ported over the ReadiVoice database through the use of PSPI, or CGI GUI. Customers would like the
subscription to have a field that could be used as a reference to the record in the master database.
Additionally, they would like the conference CDR record to contain this reference, to make billing process
easier. External Id B is created in both CDR and CNOW database for this purpose. Table cdr_post_conf in
CDR database now has a new field, called externalid_b, which is a string of 30 characters.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 19 Polycom, Inc.

5.6 PSPI Changes

From ReadiVoice v2.50.0 to v2.55.0

AddSubAndAN_v2500
AddSubAndAN_v2320
AddSubAndAN_v2130
AddSubAndAN_v2110
UpdateSub_v2110
UpdateSub_v2130
UpdateSub_v2320
UpdateSub_v2500
AddSubAndAN_v2550 Identical to AddSubAndAN_v2500, with the addition of ExternalidB field
UpdateSub_v2550 Identical to UpdateSub_v2500, with the addition of ExternalidB field
GetSub_v2550 Identical to GetSub_v2500, with the addition of ExternalidB field
GetSubBEIdB

The stored procedures are now checked for invalid Name Record and Name
Announce combination.

If Name Record is turned on, and is configurable, while RollCall is Name, and is
not configurable, is not a valid combination, since users can turn Name Record
off, while RollCall can not be changed (PTR 1-5593604)

It is used to search and extract subscription information, based on External Id B
field.

5.7 InnoVox Changes

T1s are able to be loop-timed in a T3

InnoVox engineering added support for loop-timing of T1s within a T3. The InnoVox 4000 bridge can be
configured to specify either loop-timing or sourced. The default option will be loop-timed.

Monitoring

The InnoVox chassis now supports monitoring of power supplies and fans from the redundant VMS cards in
the chassis. Software was added to log failures and notify ReadiVoice whenever a monitored component has
failed, and to identify the specific component that has failed down to the power supply or fan number.

5.8 Routing Interface Changes

The following routing interface modules were modified as part of the porting effort to use the GCC 3.4.2
compiler. Additional changes were made to improve overall data type consistency. The changes are not
intrusive and are limited to naming convention, ex. INT and LONG have been changed to INT32.

• SS7_ATT

• SS7_DMS

• SS7_DMS_100

• TCP_ROUTING

• MCI_ROUTING

• VRI_ROUTING - modified to improve build process

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 20 Confidential and Proprietary

6 ReadiVoice v2.53.1

ReadiVoice v2.53.1 was a maintenance release that addressed defects identified since the release of
ReadiVoice v2.53.0.

6.1 Database Changes

The Informix 9.3 installation package 0009 has been modified to pick up new settings in the onconfig.* files.
The new Informix 9.3 installation package 0015 has the following modifications:

onconfig.conferencenow.4cpu.1gig_ram

• set PHYSFILE to 10000

• set CLEANERS to 127

• set LRUS to 127

all onconfig.conferencenow*

• set ON_RECVRY_THREADS to 30

6.2 CDR Changes

6.3 The purgeCDR.pl script has been changed to address PTR# 1-5345823.
See the

Defect Description Workaround

1-4684820

1-4782347

ReadiVoice v2.50.4

During fail-over scenario, a new caller may start a conference on a
different bridge if the bridge with the original conference has not yet
finished re-synchronization process.

Subscriber dial out to the participant fails if the conference termination
feature is trying to end the conference. Even if subscriber reset the
termination timer, both participant and subscriber will not be able to join
the conference.

(if available)

None

None

Resolved Issues section on page 29.

6.4 Routing Interface Changes

6.5 TCP_ROUTING has changed to address PTR#: 1-5875601. See the
ReadiVoice v2.50.4

Defect Description Workaround

(if available)

1-4684820

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 21 Polycom, Inc.

During fail-over scenario, a new caller may start a conference on a
different bridge if the bridge with the original conference has not yet
finished re-synchronization process.

None

Defect Description Workaround

(if available)

1-4782347

Resolved Issues section on page 29.
SS7 (AT&), SS7 DMS 500, and SS7 DMS 100 were recompiled against the new version (v1.3.1.7) of the D7

libraries

Subscriber dial out to the participant fails if the conference termination
feature is trying to end the conference. Even if subscriber reset the
termination timer, both participant and subscriber will not be able to join
the conference.

None

7 ReadiVoice v2.53.0

ReadiVoice v2.53.0 is a feature release. The following table identifies its new features and indicates on which
InnoVox media servers the features are available.

Feature/Enhancement InnoVox 480 InnoVox 4000

Larger system configurations Available Available
ReadiVoice-IP support Not Available* Available
Intelligent Network Call Routing interfaces support Available Available

This section describes each new feature in detail. Section 3 describes the enhancements to existing features.
Section 4 describes other enhancements and changes.

The sections below address the new features and functions. Where appropriate, each section includes:

• Feature description

• Information about provisioning, configuration, and implementation

• Voice prompts added or modified

• Database, PSPI, and CDR changes

• Moderator API (Java and XML) changes

Note: If a feature section doesn’t include a specific subtopic, such as “Voice Prompts,” there are no changes of that type

associated with the feature.

7.1 Larger System Configurations

Feature Description

ReadiVoice v2.53.0 supports larger system configurations on both the InnoVox 480 and InnoVox 4000 media
servers. Customers may expand their InnoVox 480 media server configuration to a total of 5760 ports (12
bridges). Customers may expand their InnoVox 4000 media server configuration to a total of 6048 ports
(across 3 bridges).

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 22 Confidential and Proprietary

The following table identifies the CACS hardware required for the three supported InnoVox 4000
configurations.

Configuration Small CACS Medium CACS Large CACS

Server Model

Sun Fire V120 server
(or equivalent)

Netra 20 or Netra 1125 server
(or equivalent)

Sun Fire V480 server

(or equivalent)
# of CPUs 1 2 4
RAM 512 MB 512 MB 2GB

PSTN Not supported Up to 2016 ports Up to 6048 ports InnoVox 4000
IP

Not supported in a

Up to 1008 ports Up to 2016 ports
production
environment

PSTN Up to 480 ports Up to 1920 ports Up to 5760 ports InnoVox 480
IP* Not supported Not supported Not supported

* ReadiVoice-IP on InnoVox 480 is available only to customers with current deployments and is supported
with RV v2.50.6. All new customers requesting ReadiVoice IP will be supported on ReadiVoice v2.53.0 on
InnoVox 4000 IP.

Note: All bridges within a media server configuration must be of the same type.

Assigning Translation Numbers

Because ReadiVoice v2.56.0 supports a larger number of ports and a larger number of conferences, you
should reassess the number of translation numbers you have available to your ReadiVoice systems. To do so,
use the following formula:

# of translation numbers = max # of conferences * # of access classes

Where the number of translation numbers does not exceed the number of ports.

So, for example, if you have a 480-port bridge where the maximum number of conferences is 160, and you
have two access classes (e.g., Toll & Toll Free), then you may need up to 320 translation numbers. Or if you
have a 4032-port bridge where the maximum number of conferences is 1344, and you have two access classes,
then you may need up to 2688 translation numbers.

Note: You may operate with fewer translation numbers, but you run the risk of running out of translation numbers during peak

periods.

7.2 Intelligent Network Call Routing Interfaces

ReadiVoice v2.53.0 supports all currently implemented Intelligent Network Call Routing (INCR) interfaces,
including:

• SS7 (as implemented by carriers AT&T, Global Crossing, and Global Crossing for Nortel networks)

• TCP/IP Routing

• VRI (as implemented by carrier Telcordia)

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 23 Polycom, Inc.

8 Other Enhancements and Changes in ReadiVoice v2.53.0

8.1 Automatic Gain Control

Automatic Gain Control (AGC) is now supported on InnoVox 4000 media servers. AGC defaults to on.

Configuration

In the sysx.ini file, enableAgc is a new line that defaults to TRUE (even if the line is missing) which
means AGC is enabled. Although not recommended, AGC can be disabled by adding the following line to
the sysx.ini file in the [systemDefault][inlineConditioners] section:

[inlineConditioners]

enableAgc = FALSE

Setting this value to FALSE will disable all AGC on the media server following the next boot.

9 Upgrading to ReadiVoice v2.56.0

From v2.5x.x

The software upgrade from ReadiVoice v2.5x.x to ReadiVoice v2.56.0 is a simple update procedure; however,
Polycom Global Services may also use the roll out of ReadiVoice v2.56.0 as an opportunity to perform
InnoVox 4000 card upgrades, which are required to take full advantage of new ReadiVoice v2.55.0 features.
Your Polycom representative will discuss card upgrades with you prior to upgrading your systems.

From Earlier Versions

To upgrade from a ReadiVoice version that is earlier than v2.5x.x, Polycom Global Services may upgrade
your system using a multiple-upgrade process, verifying that the new features and functions introduced in
each upgrade are functional before installing ReadiVoice v2.55.0.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 24 Confidential and Proprietary

10 Software Versions

The table below shows the software versions of the bridge binaries, server software, and ReadiVoice
packages included in this release. For each, it also indicates in which ReadiVoice release the current version
was introduced.

Software Module/Component Version Updated In

InnoVox v4210e v2.56.0 Platform
Boot code

(bootrom.bin, hmodfpga.bin)

Server

HA

SDK MAPI, CAPI, PSPI v2.56.0 v2.56.0
Other

components

Routing
Interfaces

Packages

Solaris 8-vU7-2/04 v2.55.0
Sun patches 6/30/05 V2.56.0
Java (runtime) 1.3.1 and 1.4.2 V2.52.0 and v2.53.0
Intelligent Network Call Routing

(AT&T, Global, Nortel)
HA v2.04.0 v2.55.0
Veritas Foundation Suite 4.0 v2.55.0
Veritas Informix Agent 1.30.1 v2.50.0/v2.32.5
MTS v2.10.0 v2.50.0 IWatch
Patrol 3.4 v2.50.0/v2.32.5

VbootP v1-33 v2.56.0
SUA V1-78 v2.56.0
DynamicSoft 2 V1-14 v2.55.0
SS7 (AT&T) v1-12 (D7 1.4.0.1) v2.56.0
SS7 DMS 500 v1-10 (D7 1.4.0.1) v2.56.0
SS7 DMS 100 v1-13 (D7 1.4.0.1) v2.56.0
TCP Routing V1-11 v2.55.0
MCI Routing v1-13 v2.56.0
Telcordia (VRI) v1-14 v2.55.0
VTIGNUsrc (GNU source code) 0003 v2.30.0
VTIinf (Informix) 9.30/0015 v2.53.1
VTIsnmp (SNMP Agent) 15.3/0004 v2.56.0
VTIapache (Apache server) 1.3.28/0001 v2.50.0
VTItools (Perl) 5.00502/0008 v2.30.0

v1-33 v2.55.0

1.4.0.1 v2.56.0

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 25 Polycom, Inc.

11 Known Limitations

11.1 ReadiVoice v2.56.0

Defect Description Workaround

(if available)

1-6090793

1-5591501

1-5898239

1-5754109

1-5763016 CSM will not allow hard disable of span when span is already in alarm. None
1-5877104

1-5619401

1-5677668

1-6172109
1-6299765

1-5556809

XML API - Incorrect type and event name for LOGIN_NACK (Found in
releases since ReadiVoice v2.55.0.)

Some moderators will not be automatically logged out once the
moderator application stops responding to heartbeats.

A double click to join a participant in the waiting room from the
moderator will cause the moderator to be disconnected.

The SNMP variable sysNumBridgesActive may loose correct count
during bridge maintenance session.

Callers calling in an performing the following steps will find problems:
Callers call in and enter a passcode, they wait for the subscriber, the
subscriber calls in, changes the conference to conference continue,
and adds a conference security code, the sub finds he/she has
incorrectly entered the conference security code and abandon the call,
the participants on “hold” are asked for the conference security code
but do not enter it and are disconnected, the subscriber calls back in
(presumably to set the correct security code), the conference is still
running, the subscriber abandons the call again and subsequent callers
to the conference will get dead air or a please standby wave. All
functions as expected except for the subsequent callers getting please
standby after the sub abandons the call for the second time.

Under extreme load mplex may suffer from internal mutex timeouts that
result in some events being dropped. The root cause is not known at
this time. mplex recovers when the load decreases and becomes fully
operational again.

Improperly configured sockcap, or a sockcap that cannot communicate
with the configured cards for an extended length of time may core.
This does not effect conferencing, only logging

During security scan performed with Nessus tool ReadiVoice
processes core.

Windows Operator; The icons on the Server screen under the Bridge
Column need mouse over description added to them. There is
currently no explanation for what these icons mean. Also, clicking on
any one of the three has the same result - all three disappear and
nothing appears to happen.

None

None

None

rastop/restart after
bridge maint is
completed

None

None

None

Currently no work
around is
available,
engineering team
is working on the
resolution.

None

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 26 Confidential and Proprietary

11.2 Innovox v4.21.0

Defect Description Workaround

(if available)

1-5203434

1-3889515

1-3728503 Occasional reports of conferences not ending on the b ridge.

1-6245239 3210 PMODs do not support VOIP.

1-6199311

When a PTI switch failover occurs (InnoVox 4000 only) under heavy
load, there is an extremely rare scenario that can happen in which the
internal bridge switches, the PTI4411s, end up in a locked state and the
bridge must be rebooted to correct the problem.

In some instances, the loss of a D-channel may cause some cards to
not register GREEN again. Rebooting the card will resolve this issue.

There is an issue with bridges containing 3210 PMODs that results in
talker updates not being accurately displayed on the GUIs for large
conferences (over 15 participants).

None

Reboot the
affected card(s).

None –
engineering is
currently
investigating.

The IV4000
supports VoIP.

Engineering is
currently
investigating, but
until another
solution is found,
only IV480
bridges containing
6X PMODs and
RV2506 and
above support
large conference
talker updates.

11.3 ReadiVoice v2.53.1

The following tables describe the known limitations for ReadiVoice v2.53.1.

Windows Operator Issues

Defect Description Workaround

(if available)

1-5560053

1-5560004

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 27 Polycom, Inc.

Entire conference line must be highlighted to see conf details, which is
different than when using Java Operator

Operator requests list too far on the right to be seen without scrolling
From the all conferences screen, the operator is required to take extra
time to scroll to the right to see requests. It would be more efficient to
have some of these columns locked at a certain width or even better to
have an option to auto-size the columns based on what is contained in
each field.

None

None

Defect Description Workaround

(if available)

1-5556809

The icons on the Server screen under the Bridge Column need some

None
sort of key or mouse over description added to them. There is
currently no explanation for what these icons mean. Also, clicking on
any one of the three has the same result - all three disappear and
nothing appears to happen.

1-5554572

On the Win Op console main server screen tool bar, there is an icon
that, when clicked, gives the operator the ability to ignore operator

None. Resolved in

v2.56.0.
requests for that bridge. The ability should exist to disable this icon.

1-5554539

1-5585636

Win Op; bridges, conf view, main server screen all do not show
pending op request

Windows Operator; movement between conf details and all conf

None. Resolved in

v2.56.0.

None
summary different in Win Op

After an op request is answered and op has the part in the private conf,
then clicks on either the "All Conferences" or "Bridge #" folder, the conf
is highlighted, but if the op clicks on another line and there are several
confs on the bridge, it is difficult to find the conf again. Win Op should
display the conf details screen for the call the op is working on when
either "bridge" or "all conferences" windows are accessed. The Ja va
Op currently has tabs that can be clicked on to go back and forth
between the conf list and conf detail screen. One reason for doing this
would be to find out how many ports the bridge has reserved for the
conf instead of looking it up in IMGS, to see conf status etc

1-5585615

The two icons to connect and disconnect the operator voice path are
identical. Ops believes this may be confusing to the Coordinators and

None. Resolved in

v2.56.0.
requests they be different and/or have a label underneath the icon.

1-5546011 Windows operator required stop/start to function properly

None. Resolved in

v2.56.0.

Moderator Issues

Defect Description Workaround

(if available)

1-5576417

When doing "add participants" via the dial out on the Polycom Web

None
Moderator, and entering a name for the dialed out participant, the dial
out correctly adds the participant to the conference list and correctly
shows their name shows them "In Menus". After the participant
presses 1 to join the conference, the conference list line correctly goes
from "In Menus" to "In Conf", BUT the participants name disappears
form the "name / ID" fiels and has to be reentered via the "rename"
button".

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 28 Confidential and Proprietary

Other Issues

Defect Description Workaround

(if available)

1-5817042

CSM does not always refresh when spans are recovered during
maintenance.

A reboot of the
core and app
processors
affected

11.4 InnoVox v4.13.0

The following tables describe the known limitations for InnoVox 4.13.0.

Defect Description Workaround

(if available)

1-3889515

1-5065516

If a span loses its D-channel, some spans on the card may not register
GREEN for several days. Some spans may recover eventually, but
some are stuck in the YELLOW alarm state. Rebooting the card will fix
the issue. It will be improved in future release

In the event of loss of data network, currently we require all
conferences and channels to end before returning to normal service. It
will be improved in future release.

Card reboot

End all current
conferences and
channels.

11.5 ReadiVoice v2.50.4

Defect Description Workaround

(if available)

1-4684820

1-4782347

During fail-over scenario, a new caller may start a conference on a
different bridge if the bridge with the original conference has not yet
finished re-synchronization process.

Subscriber dial out to the participant fails if the conference termination
feature is trying to end the conference. Even if subscriber reset the
termination timer, both participant and subscriber will not be able to join
the conference.

None

None

12 Resolved Issues

12.1 ReadiVoice v2.56.0

The following table summarizes the defects addressed since ReadiVoice v2.55.0.

Defect or

ECR #

1-6202165

Moderator frequently becomes
automatically unregistered for talk slots
on their conference.

Description Resolution

Fixed. BIS module

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 29 Polycom, Inc.

Defect or

Description Resolution

ECR #

1-5448906

Anonymous participants are not

Fixed
announced with conference roll call but
they are announced with private roll call.

1-5546011

Windows operator required stop/start to
function properly

Windows operator had several fixes introduced,

as the result it operates properly and no longer

requires restarts.

1-5554539
1-5039401

Windows Operator - The server,
conference, and bridge lists do not have

Fixed
accurate information about the number of

requests.

1-5619401

mplex restarted after about 850

Fixed
concurrent logins

1-5777916

Operator is announced as anonymous

Fixed
rather than operator when joining a
conference

1-5883403 Backing up of large files(>2GB) Fixed
1-5554572

On the Win Operator console main server
screen tool bar, there is an icon that,
when clicked, gives the operator the
ability to ignore operator requests for that
bridge. The ability should exist to disable
this icon.

Added

WinOp.RemoteGui.DisableIgnoreRequest into

operator.exe.config file.

If this flag value is "false", the Answer Request

and Ignore Request button is available as usual,

allowing operator to ignore op requests.

If this flag valus is set to "true", both Answer

Request and ignore Request button will be

disabled. Operator cannot disable/enable it.

The default value is "false".

The configuration setting can be found and

modified in file: C:\Program

Files\Polycom\WinOp.Installer/Operator.exe.con

fig, line: <add

key="WinOp.RemoteGui.DisableIgnoreRequest

" value="false" />

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 30 Confidential and Proprietary

Defect or

ECR #

1-5936001

1-6051908
1-6051920

1-6106424

1-6133905

1-6044001

Description Resolution

A timing hole exists in the HTML
moderator application where if a
subscriber is dialed out and then
disconnected just before the line is joined
to conference, and another subscriber is
dialed out the application still thinks the
new subscriber is the old disconnected
subscriber. Therefore all the commands
to the new subscriber line are sent to the
old one instead of the new one (mute,
WR processing, hook, etc...). This
causes these actions to not be processed
and in most cases results in an API
NACK.

SS8 has found that their D7 stack 1.3.1.7
has a critical error with transaction timers.
They have implemented a Bug ­CRSnn10653 - that removed timer’s
timeouts for transactions that stop getting
communications from the switch.

ROUTING: GTW Routing Interface fails
when odproc starts up

There has been occurance of CPU panic
on RV HA system. Sun declared that the
CPU panic has been resolved and the fix
is included in newer patch version.

When a caller is entering WR there is a
small chance that if the conference is
being unlocked at that moment the caller
does not learn that. So he enters WR
even though the conference has been
unlocked.

The callers already in WR will be moved
to conference; new callers will also join
conference. Just this caller stays in WR.

If the WR notification is on the subscriber
will be notified that somebody is in WR
even though the conference is locked.
Repeated conference unlocking will not
help.

Conference re-locking and unlocking will
release the caller from WR. Or if the
subscriber presses #5 (to process callers
in WR) the caller will get processed. Or
the caller will time out in WR and get
disconnected

When multiple subscriber entries existed in the

moderator participant list the subscriber Id used

would be that of the last subscriber entry. As a

result an old, disconnected subscriber entry

could be used rather than the one currently

online. The fix was implemented by ignoring

subscriber entries in the participant list which

have a status of 'Disconnected'

Fixed

Fixed

RV2560 has been validated with 6/22/05 patch

set.

Fixed

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 31 Polycom, Inc.

Defect or

ECR #

1-6045001

1-6164513

1-6191243

1-6191256

1-6191263

1-4281834

Description Resolution

When the subscriber dials in and
changes WR option from 'on entry' to 'off'
in account options and there are callers in
WR the callers in WR stay in WR.

The subscriber can use #5 to process the
callers but he is not notified that there is
somebody in WR nor the participant
count include the callers in WR.
Conference re-locking and unlocking
does not help.

Callers dialing in after WR option change
are not affected and join the conference
as expected.

The change form ULONG -> LONG in
MAPI may have broken some customer's
code. Because LONG_TYPE was the
base for both LONG and ULONG, Java
could not auto cast between these types
(UINT as well).

WR_CONNECT event is missing in csc.
As the result, customer implemented web
moderator cannot connect chairperson to
participant.

New MAPI event
LOCK_TYPE_CHANGED causes
customer implemented web moderator to
fail.

MAPI: Participant type is overwritten by
an old value.

Windows Operator: auto link to edit
subscriber provisioning screen

Fixed

Fixed an incompatibility between pre 2550

MAPI clients and 2550+ MAPI backend

regarding the treatment of LONG/ULONG/UINT

data types.

ULONG now inherits from LONG instead of the

common base class LONG_TYPE. This allows

Java to easily cast down the tree from ULONG

to LONG to LONG_TYPE.

WR_CONNECT has been added.

The event has been filtered out, and is no

longer returned to MAPI client application.

MAPI file Conference.java: function

updatePartfromAddressBook: removed the

statement that updates participant's type to

what was there earlier

The link to edit subscriber account has been

added. The subscriber names will show as red

in the grid. When clicked, the provisioning page

for that subscriber will pop up.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 32 Confidential and Proprietary

Defect or

ECR #

1-1XERY
1-6028520

1-6062204

Description Resolution

Create an Informix database procedure to
receive and assign 1 or more access
number sets to a subscriber id. Each set
would consist of access number, hidden
number and number type. The procedure
call parameter list could consist of flag for
access number verification, flag for load
cr, carriier id, subscriber id and access
number set.

Update /rahome/bin/check script to
include information about network card
setup, specifically HALF/FULL duplex
status. The script should display warning
if NIC is not FULL DUPLEX.

Created stored procedure AddSubAndANString.

This stored procedure is very similar to all other

AddSubAndAN pspi calls, with one exception. It

does not have input parameters for

AccessNumber1, hiddenNumber1, ... but it does

have a string, called AccessNumString instead.

this string is 720 characters long, and have

enough space for a minimum of 10 access

numbers to be put in there. The PSPI call will

parse the string to get all the needed

information. This string format is:

accNum1,hiddenNum1,sharedFlag1,numberTyp

e1|accNum2,hiddenNum2,sharedFlag2,number

Type2|accNum3,hiddenNum3,sharedFlag3,num

berType3

Each access number info group consists of

access number, hidden number, sharedFlag (0

or private number, 1 for shared number), and

number type (Toll, Toll-free, ...). Each field is

separated by comma. None of them can be left

blank.

The bar (|) delimiter is used to separate

between each access number info group.

New Files:

IU_AddPhoneNum.sp

IU_AssignNumToSub.sp

New Table :

PSPIAccNumHolder

All NIC interfaces are listed with their duplex

status. Warning message is displayed if not all

network interfaces are set to FULL DUPLEX

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 33 Polycom, Inc.

Defect or

Description Resolution

ECR #

1-6090960 API Improvements for v2560

1-4786411

When viewing the details of a conf (Conf
View - in java operator)
the user should be able to switch to the
bridges or groups and come back to
details without having to reselect the
desired conf to view details.

MAPI change: ACM_CHAN_ENTER now has a

PartType parameter (of type PART_TYPE

enum) that tells what type of participant the

channel entering ACM is (PT_SUBSCRIBER,

PT_PARTICIPANT). This saves ACM

developers from having to register for a

conference and iterate through the conf's part

list to find participant type.

CAPI changes:

1) ACM_CALL_ENTERED now has a PartType

parameter to inform as to the type of participant

a channel is entering ACM.

2) PLAY_NAME event now has a PartPlayTo

parmeter that tells what participant to play

part(s) name(s) to (-1 == subscriber).

3) Playing a private roll call of a part or all parts

from a conference to a specific line now

functions properly (like MAPI

PART_ROLLCALL)

4) MessageSender interface and

CastorMessageSender changed to add the

extra PlayToPartId parameter (due to the limited

scope of usage of CAPI it was decided an

interface change would not be overly taxing to

CAPI developers over having multiple

playName sender methods).

5) New event added:

VALIDATE_MODERATOR_LOGIN to check

parameters that could be used in a moderator

login and return a matching subscriber ID in a

SUBSCR_ID event, or NACK with a bad login

NACK reason. This sould be of particular use

to application login type developers. Note: this

is not a session event, no login required of any

type (see REQ_SYSTEM_INFO event for

similar behavior).

6) MessageSender (interface) and

CastorMessageSender were modified to send

the new login validation event.

Added a "Return to the Last-Viewed

Conference" button to the toolbar. Click this

button from anywhere to return to the

conference last viewed. The "last-viewed"

conference is a conference last seen in the

Detailed View area.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 34 Confidential and Proprietary

Defect or

ECR #

1-5029667

1-5042190

1-5856311

1-5998401

1-6143907

Description Resolution

By default requests are answered in the
order received. If the operator sorts any
of the columns in the list of requests there
is no way to get back to the original order
received.

WinOp - The tree on the left hand side
should reflect where in the tree you are in
the right panel

CAPI Changes to address ACM Billing
Code requirements.

Application Login type was added in
RV2550. Number of current application
logins should be reflected in SNMP
interface.

Windows operator is now the default, it
should be always activated.

Added a "Request Time" column to the

"Operator Requests" table so user can sort

requests by time received.

Fixed. Clicking on the "viewlastconf' button,

request answer panel, or answering a request

will highlight the respective server.

new event added has been added to XML API

and CAPI: SET_CONF_USER_DATA, also

CONF_INFO now has a new field: UserData.

The functionality has been added to support

future development of ACM applications.

New SNMP variable (sysNumAppsActive) has

been added to track application login count.

New MIB entry:

sysNumAppsActive OBJECT-TYPE

SYNTAX Unsigned32

MAX-ACCESS read-only

STATUS current

DESCRIPTION

"Specifies a number of applications

logged into the system"

::= { sysOperatorInfo 6 }

The ReadiVoice SNMP MIB can be found in file:

/web/snmp/srconf/mgr/conferencenow.mib

The "activate" configuration parameter has

been set to 1. The parameter can be found in

odprocrc.defaults configuration template file.

Configuration file change:

[modules]

[opupdater]

activate = 1

[]

[]

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 35 Polycom, Inc.

Defect or

ECR #

1-5953477

1-6070744

1-6200072

1-5811201

Description Resolution

CAPI - csc timeout value for session
timeouts needs to be added to the
odprocrc.defaults file.

MAPI-When conf security code is set via
MAPI, inbound callers are not prompted
to enter security code

ACM MAPI - ACM Dial out gets an
unrecognized event

Conference continuation is toggled to the
correct value only after the first caller
calls in to a MAPI started conference

Added timeout = 120 to odprocrc.defaults and

odproc creator script for session timeout (in

seconds).

1) Verify that the time out is in the

odproc.defaults file.

2) Run the creator script to make a odropcrc,

verify that the value is in the csc section.

Configuration file change:

[modules]

[csc]

timeout = 120

[]

[]

MAPI changes:

1) added CONF_SECURITY_NUM_CHANGED

event to MAPI. This event is notification to

MAPI clients that the conference security

number has been changed. A message handler

for this event will have to be added in the client

code to avoid an exception if the new event is

received.

2) Modified the deprecated

SET_SECURITY_NUM event to behave just

like the new SET_CONF_SECURITY_NUM

(see 2550 release notes for details).

3) Also the MESSAGE_SENDER query for

ACM data now includes the passed bridge ID

parameter in the query string.

This fix alters ACM MAPI clients that were

receiving CURRENT_CONF_INFO events: It

adds a new XBOOL type and a new CCI enum

value to MAPI. If an ACM application was

receiving CURRENT_CONF_INFO before, it's

handler should be changed to receive

CURRENT_CONF_INFO2 (a child class of

CURRENT_CONF_INFO). In the handler

changing the method: void handle

CURRENT_CONF_INFO

(CURRENT_CONF_INFO event) to

handleCURRENT_CONF_INFO2(CURRENT_C

ONF_INFO2 event) should be all the

modification needed (logic will still be the same

as the #2 is a child of the original).

Now working as expected.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 36 Confidential and Proprietary

Defect or

ECR #

1-5029663

1-5039401

1-5546042

1-5554519

1-5554549

1-5554562
1-5091485

Description Resolution

WinOp - default locked conference
behavior allows the operator to enter a
locked conference without being required
to "ring" the conference first.

WinOp - The server, conference, and
bridge lists do not have accurate
information about the number of
requests.

Win Op; play participant name icon
actually plays conference roll call

Win Op; button to change Waiting Room
features should be disabled

Win Op; Operator bell continues to play
even after the participant has cancelled
the request and disconnected the phone
line.

Win Op; talker field never updated when
a part is talking (always shows false)

"Join" button is replaced with "Ring" button

when conference is locked. As soon as the

conference is unlocked the "Join" button is

restored.

The Java Operator default method of is to "ring"

the conference unless the system is configured

to allow the operator to unlock a conference.

To match the Java Operator functionality a new

configuration is added. AllowUnlock in

operator.exe.config file allows or prevents the

operator from unlocking the conference. By

default the setting is false and operators are

prevented from unlocking the conference.

The configuration setting can be found and

modified in file: C:\Program Files\Voyant

Technologies\WinOp.Installer/Operator.exe.conf

ig, line: <add key="WinOp.Client.AllowUnlock"

value="false" />

However, operators can still lock a conference

regardless of the field setting.

Fixed; affected modules: opinterface, operator

GUI client

modified modules: opinterface, OPQManager,

operator GUI client

Participant name is played into the operator's

established voice path. If the operator does not

have a voice path the application will prompt the

operator to establish one.

modified modules: opinterface, operator GUI

client

modified modules: operator GUI client

modified modules: operator GUI client

Fixed

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 37 Polycom, Inc.

Defect or

ECR #

1-5554582

1-5556915

1-5560014

1-5560024

1-5560066

1-5560076

1-5585626

1-5585650

1-5598008

Description Resolution

Win Op; Operator bell does not ring
steady for an operator request ( it should
be steady like java operator)

Win Op; Operator is not warned that
should leave the current conference
before answering request from a different
one.

Win Op; true/false wording on quickstart
is inconsistent

On the conference view screen, the
quickstart feature is represented with
true/false values, the Java Operator uses
yes and no. Consistent behavior is
desired.

Win Op: In case of failed dial out operator
can not cancel the call (cancel button
does not work)

Win Op; The following actions should
have an "Are you sure, yes/no"
confirmation dialog added to them in the
operator GUI: Disconnect participant,
End conference button, Listen only
button, Mute all button, and mute button.

Win Op; Windows Operator ConfDetail
screen contains buttons with images
rather then text labels.

Win Op; The disconnect server icon is
right next to the connect operator voice
path icon. This could lead to accidentally
logging out of the server.

Win Op; Participant status not always
correctly updated.

Win Op; Hyperlink is needed from the
subscriber ID column to the provisioning
page

Bell interval changed to one second. New

configuration setting has been added to allow

further tuning of the bell interval.

The configuration setting can be found and

modified in file : C:\Program Files\Voyant

Technologies\WinOp.Installer/Operator.exe.conf

ig, line: <add

key="WinOp.Bell.DelayInMilliseconds"

value="1000" />

modified modules: operator GUI client

A message has been added requiring operators

to leave a conference or one-to-one before

answering a new request.

modified modules: operator GUI client

Rather then displaying yes/no or true/false the

quickstart feature is now represented with GUI

checkbox component.

modified modules: operator GUI client

Modified modules: opinterface, operator GUI

client

Modified modules: operator GUI client

Modified modules: operator GUI client

Connect and disconnect to server buttons have

been swapped so that the connect to server is

closest to the connect voice path.

modified modules: operator GUI client

Lock button has been disabled unless

subscriber is in conference or the conference is

in quick start mode.

modified modules: operator GUI client

Modified modules: operator GUI client

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 38 Confidential and Proprietary

Defect or

ECR #

1-5763205
1-4788207

1-5513851

1-5556904

1-5894701
1-5212204

1-5619604
1-5872466

1-5612901

1-4577304

Description Resolution

If the power supply on the bridge goes
down and comes back up, the SNMP and
check script does not display the correct
status.

DmsDnisAdmin.pl script failed; The script
has not been updated after the move
from CTI to VTI package, contains
references to outdated info.

The Status column on Conference and
Bridge tab should not show SubscriberID.
It is redundant, since there is already an
ID column.

Moderator may be in muted state after
recorder dialout

Win Op; Op voice path line does not
disconnect if Windows Operator screen is
closed

/rahome should be mounted with support
for large files. In a standard non-HA
install, the /rahome partition is mounted
with large file support, but in a standard
HA install it is not.

Allow Moderator API to provide ability to
bypass default dialout callflow

There were two separate problems that led to

this. The SNMP had a type mismatch with

regards to the event it received during cycling of

Power Supply. The bridge also failed to send

RGV during PS coming back up.

Script updated to reflect new perl module.

The SubID removed from status column.

Bridge scripts

Fixed

Resolved in HA2040

New ive.ini DtmfDialingControlEnabled

parameter in the MiscConfig section. Default is

active or on (1). This parameter will allow the

normal dial out menu commands (once a

participant is dialed and talking 1-to-1 with a

subscriber) to work. If set to off (0) DTMF

commands to join participant to conference, join

participant and dial out someone else, hook

participant and put subscriber back into

conference, will not be recognized.

To fulfill this ECR the customer may set this

parameter to off (0) and disable the

eCMD_DIAL_OUT (comment out that line in the

ive.ini's DTMF_CMDS section). This will totally

disable DTMF dialouts for the system (note the

appropriate wav files telling the subscriber the

available DTMF commands to use for initiating

dial out, and once dial out is initiated to join

participant to conference, hook, should be

replaced). Once this is done the only way to

dial out and join a participant to conference is

via the RV APIs (MAPI/CAPI).

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 39 Polycom, Inc.

Defect or

ECR #

1-4889301

1-5612401

1-5593604

1-5585615

1-3710603

Description Resolution

Putting span in blue alarm, then
immediately putting it back into green
alarm will cause the span to never come
up. Rebooting the card seems to be the
only way to revive the span.

gzip binary included with 2.32.2 RV
system will not support >2G files

Moderator app appears to change
database, violating API rule sets. See
attached Doc from customer.

The subscriber account started out with
"name record" on and entry
announcement set to "name announce".

Under "Account Options" in the HTML
Moderator GUI, when we turn off "name
record", the GUI shows that entry
announcement option is set to "tones" ­which is correct. However this new
announcement option does not get set in
the database, so anyone who later loads
this subscriber setting in the Subscriber
Provisioning page will get an error
because of this rule violation.

Win Op; connect and disconnect icons
are identical but should be different or at
least be labeled

Capability for using * as well as # key as
the prefix for activating In-Conference
ACM application

The Green Alarm button is deactivated

immediately after the Blue Alarm request is

issued. Since a blue alarm indication from the

bridge does not mean that the signaling is

complete on the far end, a timer was added of

10 seconds before reactivating the "Green

Alarm" button.

Gzip 1.3.5 has been added to the RV install as

a separate package (SMCgzip). Gzip 1.3.5

supports large files (>4GB files).

The stored procedures are now checked for

invalid Name Record and Name Announce

combination.

If Name Record is turned on, and is

configurable, while RollCall is Name, and is not

configurable, is not a valid combination, since

users can turn Name Record off, while RollCall

can not be changed.

The following stored procedures are modified to

enforce the above rule:

AddSubAndAN_v2500

AddSubAndAN_v2320

AddSubAndAN_v2130

AddSubAndAN_v2110

UpdateSub_v2500

UpdateSub_v2320

UpdateSub_v2130

UpdateSub_v2110

Disconnect button' has been removed and

replaced with 'connect button' toggle. Pressing

the 'connect button' once will connect the GUI to

the server and clicking again will disconnect.

Modified CGI to only allow the following DTMF

command: *n, or #n, where n is a number from

0-9

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 40 Confidential and Proprietary

Defect or

Description Resolution

ECR #

1-3710616

Allow participant name to be recorded in
CDR

Prior to 2550, MAPI users can set participant

names in current conference by using

PARTICIPANT_INFO event. Once the

conference ends, participant names get

discarded, and cannot be retrieved for viewing

later. Customers have asked for the entered

name to be saved in CDR database, so they

can be retrieved. In 2.55.0 release, participant

names are now saved into part_last field in

cdr_post_part table.

1-4701103

When *3 is executed to change options,

Bridge scripts
there is a 3 second delay on the play of
the wav file.

1-4934061 /rahome/etc/vbootp.db is world readable Permissions set to 0600
1-5136516

SNMP - HP OpenView access to the
ReadiVoice, Informix, and Veritas MIBs

Veritas MIB file can be found at

/etc/VRTSvcs/snmp/vcs.mib. The Informix MIB

files are under /usr/informix/snmp/. ReadiVoice

MIBs are under /etc/srconf/mgr/.

1-5486347

Duplicate dates with snmp log files, ex.
log files from November 1 and Jan 11th
have the same time stamp.

The cyclelogs_hist and cyclelogs_sn files have

been modified to change the date time stamp in

the file name to have underscores between all

relevant portions of the date/timestamp.

1-5091461

Windows Operator - The number of

Fixed
conferences appears to be incrementing
twice when a subscriber starts
conference But only decrementing one
when the subscriber leaving.

1-5340744

Operator incorrectly shows zero
conferences even though it shows ports

Fixed. BIS module has been modified to

properly handle resync process.
in use. This situation may occur after the
network connection has been lost and
restored between the bridge and the
CACS server.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 41 Polycom, Inc.

12.2 Innovox v4.21.0

Defect or

ECR #

1-5905671

1-6014431

1-6037401

1-6179601

1-4466809

1-4428013
1-5501916
1-5501901
1-5596701

Description Resolution

I/O card does not put spans into alarm
when the VCE is removed or rebooted.

log strings reported as MAJOR can be
changed to MINOR; also, make
EXCEPTION more unique

Callers turned away with syserr 503
message

The batteries for the flash on the
CPC4401 boards have a 14-16 month
life, as they are drawing power even
when the board is inserted into a live
bridge. This is a defect in the board,
and the impact is minimized in RV2550
(IV4200) and beyond, as the key
information has been moved off the
flash.

A bug was fixed in the genvoice
program which calculated the header
length incorrectly, overwriting the first 2
bytes of the data and creating an
unusable WAV file.

Several issues relating to the port
counts on the bridge were fixed

The I/O card and its two corresponding VCEs did
not always accurately receive status change
messages from each other when one of them had
either rebooted, locked up or was removed from
the chassis. In such cases, the port capacity
would not change or the spans were not put into
alarm thus causing issues like dead air or the
wrong capacity. Code was added to make sure
that each card will handle situations where the
other card has encountered an issue.

A couple of log strings reported as MAJOR were
changed to MINOR since this severity more
accurately reflected their impact, and their
frequency was causing the escalation file to
become large. Also, the log that is generated
when processor exceptions occur at the OS level
was changed to make the string unique so that it
wouldn't be associated with IVE exception
logging.

Due to a software bug, there were instances
when Callers dialing into a conference were
receiving a 503 error message from ReadiVoice.
This occurred because the associated resource
allocation request was being ignored. The code
was fixed to avoid this issue.

Software fix included in the release. PTI card
swap may be required.

Fixed

Fixed

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 42 Confidential and Proprietary

Defect or

ECR #

Description Resolution

1-4478406

1-3905305

1-4777206

1-4777280
1-3648201

1-4850401

1-5297317

1-5340312

1-5343257

A bug was fixed on the T3 card that
caused the T1s to stay in a BLUE
alarm state at boot time in certain
circumstances. Code was added to
correct the error.

File access across the network was
fixed on the VCE to prevent excessive
delays during network outages.

When loading a DSP manually using
the xdspiLoadImg xhelp command, an
error sometimes occurred leaving the
card in an unusable state where a
reboot was necessary to recover. The
code was corrected to prevent this from
happening.

The 6201 DSPs on the PMOD can
sometimes lock up or lose
synchronization on the second stream
into the conference DSP when the
clocks are double-driven for short
periods. Code was added to detect an
out-of-sync condition and self-correct.
Also, monitoring was added so that a
DSP could be reloaded if it was
determined to be dead.

An issue on the 480 platform caused
cards to not communicate with each
other. Code was added to correct the
problem.

A critical log that happened at startup
was removed because it complained
about an issue that did not really exist.

Channels could leave conference but
not be correctly removed by the
conference which caused confusion
and could lead to “bleed through” to
other conferences. Code was added to
address this issue.

Most NETI messages were changed to
use RESRCHNDL instead of
board/span/ts to make searching the
logs easier and more consistent.

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 43 Polycom, Inc.

Defect or

ECR #

Description Resolution

1-5430943

1-1PTUZ/
1-1SRHG

1-1WMUD

1-X34S

1-5534923

1-5822701

1-5229679

An issue where power supplies and/or
fans that had failed at boot time did not
reporting the failure to ReadiVoice.
Code was added to correct the
problem.

Fixed multiple issues with BAPI losing
the registration for events from the
bridge which might cause zero-part
conferences.

A feature was added to be able to loop­time all T1s within a T3.

For ISDN spans, an issue sometimes
occurred where after a shutdown was
issued, calls to the span might get
dead-air. An issue in the code was
fixed to resolve this issue.

Customers experiencing one-way
audio on a VOIP system (VCE only).
This issue was resolved.

Channels that were offhook during an
alarm are left in a bad state after the
alarm clears. The code was changed
to make sure that the state of the
channel is cleaned up properly when
the span goes into alarm.

The DSP check script for 6201
sometimes returns "false positive"
failure indications. The DSP check
script was modified to address the
issue.

Lost events from bridge: A problem
existed where events from the bridge
were sometimes lost causing
ReadiVoice to lose sync with the
bridge. Potentially this might cause
zero-participant conferences. A fix was
added to ensure reliable delivery of
events from the bridge to ReadiVoice.

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

Fixed

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 44 Confidential and Proprietary

Defect or

ECR #

Description Resolution

Changes to sockcap logs: In previous

Fixed
releases, bridge logs referenced the
board, span, and timeslot for select
network events (offhook, onhook, etc. ).
This information was logged
inconsistently. With IV4200, this
information will be listed in a consistent
manner to aid in troubleshooting.

12.3 ReadiVoice v2.53.1

The following table summarizes the defects addressed since ReadiVoice v2.53.0.

Defect or

ECR #

1-4889403

CDR Purge process is too slow, and cannot catch up
once behind. In some releases archive does not work
correctly. There is no way to do bulk cleans during
maintenance periods. Processed flag must be set to
purge.

1-4891901

sysx_creator does not setup T3 I/O card to sync
clock with the network.

1-5042801

vbootp2sockcap puts the switch card IP address into
sockcap.conf

1-5067701

Old Infostore (internal data collection depository)
history files are never purged.

1-5098101

When an operator logs in, only 11 bridges can be
viewed on the screen. Operator only requests bridge
information for number of bridges that can be viewed.
If a 12th bridge is added, one bridge will be missing.

1-5102701

Names of participants in waiting room are played
during conference roll call. Private roll call correctly
only plays the names of participants in conference.

1-5240724 The report output directory is customer specific.

Description Resolution

Fixed

Additional steps were added to
sysx_creator. It will now ask for the
card number used to clock the
system. Multiple card can be
specified.

vbootp2sockcap has been modified
to skip and not allow for the switch
card IP address to be added to
sockcap.conf.

/rahome/bin/cleanuplogs modified to
purge old Infostore files.

The Java Operator code has been
modified to send the register event
when bridge_up event is received
and not depend on the bridges being
viewable.

Bridge script

Added -l option to
/rahome/utils/engReport to allow
users to specify the output directory.
The default output directory is still
/rahome/bin/attReports for back
compatibility.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 45 Polycom, Inc.

Defect or

Description Resolution

ECR #

1-5311612

In CDRs, part_actual_end is 0 for participants that
don't actually join conference. It shows as N/A and
Incomplete on the CDR screen.

1-5345823

purgeCDR will delete active conferences. The
purgeCDR looks for conferences with end time < xxx,
where xxx > 0. By default, running conference has
end time =0, which fits into the logic. This causes
active conferences to be deleted.

1-5448504

Waiting Room participants joined to locked
conference being recorded are not played recording
wave file "This conference is now being recorded"

1-5468413

High number of reserved ports causes calls to be
turned away. The reserved pool holds one port per
conference on the new version of code

1-5471301

Upgrade to D7 1.3.1.7 SS7 routing interfaces that
use the SS7 network and D7 software now utilize the
D7 version 1.3.1.7.

1-5546026

stop/start of opinterface leaves opinterface and
wcapimsock log with wrong permissions; logs are
readable by root only and should be able to be read
by cnow

1-5546304

additional ODBC connections setup in
onconfig.conferencenow (DBSERVERALIAS) and
sqlhosts lost with upgrade

1-5562406 dial out from a locked conference gives an error

Dial out from a locked conference was made
available in 2500. The dial out is performed, but
when the dialed party answers the phone, they hear
conf_locked.wav and are disconnected.

1-5569401

RV 2530 upgrade from 2506; sysx.ini is automatically
created from existing file but the following fields do
not come over correctly:

cacheUpdateFrequency
updatePollFrequency
iniUpdatePollFrequency

1-5582404

DIAL_CALL Unable to Dial out when Quick Start is
disabled and subscriber is not in the cenference

1-5671901

No error indication when using one-click to join a
locked conference.

1-5671913

One-Click URL allows participant to join a conference
locked by WR on entry.

Bridge scripts

/rahome/cdr/purgeCDR.pl

Bridge script

Call Router module.

modules affected:
/rahome/lib/att_ss7_module.so
/rahome/lib/dms_500_ss7_module.so
/rahome/lib/dms_100_ss7_module.so

/rahome/bin/start-opinterface

Allow customers to configure their
own specific environment in
.custtchsrc which is sourced at the
end of .tcshrc.
Modified : /rahome.tcshrc

Bridge script

/rahome/templates/sysxIniMerge

Bridge script

cmod module

Bridge script

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 46 Confidential and Proprietary

Defect or

ECR #

1-5675707

1-5689401

1-5710401

1-5766101

1-5828901

1-5850603

1-5890803

1-5253401

1-5875601

1-5927904

1-5927934

Description Resolution

Recorder line gets disconnected when subscriber is
not in conference.

Roll Call feature does not work properly if custom
prompt sets are missing

Customer has received reports of participants who
get "one-way audio" in conference. The participant
goes into conference and they are able to hear the
others participants, but they are not able to be heard.
However, it appears that other participants within the
conference have no problems. This has occurred at
least twice to two different participants and two
different conferences.

Conf Profile DB Loading does not expect Billing Id to
be from external application ( rather then from Billing
table in CNOW database)

SNMP does not report consistently the same IP
address for bridge, it appears that any of the card Ips
may be reported as the bridge IP

Moderator login fails in case when Access Code is
not used (private numbers or two passcode callflow)

Conference continuation is working differently in
2530 compared to 2506. If auto continuation is set to
on and the subscriber configurable is set to off in
2506 the continuation works. In 2530 it does not.

D7 panics cpu if one link is down and you issue an
ebs_stop – need new version of D7 - 1.3.1.7

On a non dedicated routing networks sometimes the
close system call on a socket takes upto 4 seconds
to return.

Subscriber and participants joined conference with
music (single occurrence)

Exceptions are logged in the escalations log due to
name record throwing an exception when a user hits
pound quickly without recording their name.

Recorder cannot be the the first line
to join the conference unless the
Quick Start option is ON.
Resolve in CSC module.

Bridge scripts

VOIP bridge scripts

profile.ec

BIS module modified to consistently
report the IP address of the lowest
slot ID.

database access layer.

Bridge scripts

SS7 Routing modules:
SS7( AT&T)
SS7 DMS 500
SS7 DMS 100
tcp_routing module

Bridge scripts
Bridge scripts

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 47 Polycom, Inc.

12.4 InnoVox v4.13.0

The following table summarizes the defects addressed since InnoVox v4.12.0.

Defect or

ECR #

1-5458704
1-5456958

This defect leads to a communication failure with the IP card. A patch
was received from Motorola to address this issue.

Description Resolution

12.5 Resolved in ReadiVoice v2.53.0

The following table summarizes the defects addressed since ReadiVoice v2.52.0.

Defect or

ECR #

1-5277505

1-4703543

1-4716201

1-4717801

1-4629701 Moderator lets user log in with invalid access code.

1-4819241
1-4819237

1-4837601

1-4799532

1-4969301

1-4770004

1-5028026

1-4742721

VoIP: If participant enters access code incorrectly three times and the
system is configured to route the call to an operator, the operator is
unable to connect to the participant.

In fixed access, private number system with 2 passcode call flow, an
access number is assigned to multiple bridges when a subscriber is
created in the default group.

A process used to support the Windows Operator (wcapimsock) is
started even if Windows Operator is disabled.

On 3x2016 port PSTN system, Java operator shows all but 100
conferences.

VoIP: If a resync occurs when there are calls that were originated via
dialout, the dialout calls will be disconnected.

On large systems deployed with InnoVox 480s, during a resync test
with a large CDR database, there may be a delay of several minutes
before conferences can start after the bridge has logged back in.

VoIP: During internal load test, an instance of SUA core was
experienced due to a failed write() system call.

VoIP: SIP hold does not stop RTP traffic. If an endpoint places the
SUA on hold by re-inviting SUA to 0.0.0.0 port 0, then the RTP stream
coming from the RV side should stop until another invite re­establishes.

VoIP: SIP trace information may be printed to the xterm where RV was
started if using TCP transport.

VoIP: Failure to store final bridge port information in persistant store
may lead to a period of rogue RTP that ultimately gets cleaned up.
This is because the IVR port is stored and used during a resync.

CDR data sending from ACM manager is not in sync with CDR
Manager, causing the events to be dropped.

Description Resolution

Motorola software.

BIS

This issue was not
reproduceable.

Windows
Operator startup
script

This issue was not
reproduceable.

Call router, CSCS,
and opqueuemgr

SUA

CDR processing

SUA

Bridge script

SUA (Dynamicsoft
SIP stack)

SUA

Fixed

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 48 Confidential and Proprietary

Defect or

ECR #

1-4138121

1-4888653

1-24C00
1-1M2Z9

1-3684801

1-20YK

1-4508238

1-4508227

Description Resolution

Subscriber is left in sub-conference if operator disconnects without
putting subscriber back in conference first.

Operator GUI is showing participant in music line state after participant
has been sent to operator after incorrect security called, then placed
back into call flow, then entering conference.

Quick Provisioning page has no default labels for Waiting Room and
Listen Only features.

System configuration page may provide a success message when
invalid data is entered.

After pressing *9 to change entry and exit tones, the subscriber must
press “2” before changing entry/exit options.

VoIP: If there is an active conference and the Ethernet cables are
disconnected while a participant disconnects, then after the cables are
reconnected new calls to the same conference may not be placed in
the same conference.

VoIP: If some of the RTP cables are disconnected from the bridge,
some calls will receive dead air or only first prompt.

Operator needs to
place subscriber
back into
conference before
disconnecting.

This issue was not
reproducible in
this release.

Post
install/upgrade,
update the labels
on the Quick
Provisioning page
with the .htmlrc
file.

Refresh the
System
Configuration
page and validate
setting.

None

This is resolved
with the InnoVox
4000 hardware.

This is resolved
with the InnoVox
4000 hardware.

12.6 Resolved in InnoVox v4.12.0

Defect or

ECR #

1-4878001

The Ethernet switches in the InnoVox
4000 bridge may not fail over properly.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 49 Polycom, Inc.

Description Resolution

For PSTN bridges and VoIP development
bridges, the PTI 4401 switch card may be used.
For VoIP bridges, the PTI 4411 switch card is
recommended for production usage.

12.7 Resolved in ReadiVoice v2.52.0

The following table summarizes the defects addressed since ReadiVoice v2.50.0.

Defect or

Description Resolution

ECR #

1-4888653 Operator GUI is showing incorrect line state Not reproducible in v2.52.0.
1-4024451

Odproc core dumps when subscription is used a second

BIS
time in an environment using fixed access, private
numbering, translation numbers with prefix.

1-4280211

Conferences fail under load. This issue has also been

Bridge scripts
experienced as a delay between access code collection
and the playing of the “thank you” prompt.

This was caused by a problem with RPC messages
between the bridge and the Sun. When this error occurs
under load an unusual amount of logging is sent to stdout
causing excessive CPU utilization on the bridge.

1-4173501

When the operator dials out from a conference without a

Operator
subscriber, the name they put in for the dial out is given to
all existing parts in the conference.

1-4510601

Provisioner is unable to change subscriber's account

EditSubscriber CGI
status to 2 (Deleted) in database from GUI.

1-4594763

1-4116413

Failure to receive conf_profile in timely manner results in
syserr 105.

Web moderator will allow selection of conference option

Call router, BIS, conference

profile manager

Moderator, CSC
"Name Announce" without selection of "Name Record".

1-4228901

Sun does not respond to ARP requests when bridge is

Failover script
being booted.

1-4698737

Two conferences may share the same translation number

Call router
on a routed system with fixed translation numbers.

1-4508209

The following logs have incorrect permissions (readable
and writeable only by root) after failover: sua.log,

SUA, startup scripts, vbootp,

sockcap
suatraceXX.log, vbootp.log, boottrace.log, escalations.log.

1-4280211 There are noticeable delays between prompts. Bridge script
1-4024451

In a routed system, odproc cores when the subscriber

BIS
attempts to start another conference.

1-3713353

One-click URL does not work when provisioning accounts

CSC
since participant PIN is not populated.

1-4443155

If the first caller to a conference decides to hang up

BIS, Call Router
before getting to conference, the conference may result in
being split between two bridges, or a syserror 105 may
result for future callers.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 50 Confidential and Proprietary

Defect or

Description Resolution

ECR #

1-4009341

Odproc cores due to partID being set with inappropriate

CDR
value “INIT”. This can be caused by a participant dialing
into music hold, awaiting subscriber. Subscriber dials in
and locks conference before going into conference. When
entry timeout is exceeded, participant is disconnected.
CDR containing “INIT” as participant ID is sent.

1-4116413

Name record should be automatically selected if name

Moderator and CSC
announcement is enabled.

1-4594713
1-4576722

With translation number type set to Fixed + 3-digit, wrong
translation numbers may be used and incorrect dialed

Call Router
number placed in CDRs.

1-4002602

1-4443905

Subscribers unable to login to Moderators due to
“Moderator already logged in” errors.

TCP routing: if MaxSockets is reached, lack of error

Opqueue manager, mplex,

CSC

TCP routing interface
handling causes routing interface to hang or exit.

1-4247801

Subscriber is unable to return to the main conference if

Bridge scripts
s/he disconnects a participant during one-on-one.

1-3679803
1-4568503

1-4247003

Routed system is returning busy due to conference full
rather when it should return busy due to bridge full.

Participant status changes from OP to CO when it should

Call router

BIS
remain CO.

1-4070302

Participant is disconnected when participant and

Bridge scripts
subscriber are admitted together to conference from one­on-one.

1-4093334 SNMP MIB no longer returns bridge IP address. SNMP agent
1-3872107 E.164 format is required for VoIP dialouts. SIP User Agent
1-4116401

Roll call plays the names of participants in Waiting Room

Bridge scripts
and participants that have been locked out of the
conference.

1-4165812 Changing lock state does not work properly. BIS, Bridge scripts
1-4185101 Dialouts to recorder occasionally fail. Bridge scripts
1-4339701

A channel that attempted to join the conference while it

Odsoundplay
was in the process of ending was not terminated normally.

1-3824710

The sysx_creator.pl does not correctly configure

sysx_creator.pl
maxProcessorConfs on cards with 3210 DSP resources.

1-4408744

CDR manager throws an error and exits when there are

CDR
more than one number groups associated with a
subscriber.

1-22YBF

The system should not play any wav files to the channel

Bridge scripts, BIS
of a recorder. Recorder should only record what is being
played to the conference.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 51 Polycom, Inc.

Defect or

ECR #

1-22QQR/
1-4219661

1-1M2Z9

1-1Q8Z1

1-4651743
1-1W8Z5

1-3972601

1-22YBN/
1-4219661

1-4173501

1-4636720
1-4594753

1-4548531

1-4232501

1-20YK

1-3791750

Description Resolution

Subscriber PIN, subscriberdetail.clientsubA,
subscriberdetail.clientsubB, billinginfo.clientbilla,
billinginfo.clientbillb, subscribergroupID, and conferenceID
should be added to the list of available options to transmit
in the recorder dialout string.

Listen Only quick provisioning has no description after
upgrade.

The changeHostName.pl script is referencing the old web
directories on RV v2400.

In some cases, records for cdr_end_conf are not created.
These are caused by timing conditions relating to an
attempted late entry to the conference.

If there is exactly one page of subscribers displayed on
the Subscriber page, and the user clicks the ‘>’ link, SQL
errors are displayed.

Need to be able to configure if the recorder line will enter
a conference as muted or unmuted.

When the operator dials out from a conference without a
subscriber, the name entered for the dialout is displayed
for all existing participants in the conference.

Debug stacks are presented if the InformedActive ports
(ports believed to be in use by BIS) exceeds the
ActivePorts (ports believed to be in use by Call Router).

If participant arrives before the subscriber, and Waiting
Room is enabled, the late_subscriber.wav is played when
participant enters conference. This wav should be played
when participant enters Waiting Room.

With autocontinuation off, quick start off, enable
conference continuation during call flow. If the moderator
is used to dialout to a participant, and then the subscriber
disconnects, if the subscriber dials back in, the toggle
button indicates that conference continuation is not
enabled when it actually is enabled.

Subscriber is required to press “2” unnecessarily to
change entry/exit types.

ReadiVoice IP: The SIP ‘Invite to Hold’ capability is not
compatible with some SIP applications.

BIS, database

Upgrade merge utility

changeHostName.pl

CDR

SearchSub CGI

Bridge scripts, BIS

SUA

Call Router

Bridge scripts

Bridge scripts

Bridge scripts

Invite to Hold was removed in

RV v2520 in SUA.

ReadiVoice v2.56.0 Release Notes 3725-70002-009G2
Polycom, Inc. Page 52 Confidential and Proprietary

12.8 Resolved in InnoVox v4.10.0

Defect or

ECR #

1-4312201

1-4176801

1-4657901

1-4781701

1-4777280
1-4727703

1-3648201

1-4605939

1-4611001

1-4478406

1-5810115
1-1WXG6

Description Resolution

Timing issue caused span that was placed in blue alarm to
be displayed as “disabled”.

Clock arbitration exits when ticks roll over (after about 49
days).

There was a scenario seen on the InnoVox 4000 platform
where a core processor locked up in production, believing
it was accessing invalid memory.

There were instances when an invalid request was being
sent to a DSP and it was trying to perform them instead of
rejecting them. New edits are in place, and the DSP
software now rejects these requests.

DSPs resynchronizations may not be successful on the
second stream. When a DSP detects it is out of
synchronization with the primary clock, it initiates a
resynchronization process to realign itself. During this
resynchronization, the first of the two streams of data
being output from the DSP is checked to verify the process
was successful. There were rare instances where the
second stream was actually not valid, and the
resynchronization that was thought to be successful was
not.

A scenario was found where a DSP, in the process of
resynchronizing itself was waiting on a response that it
never received. In the unusual situation where this occurs,
conferences on that DSP are lost.

Following an upgrade of 480 bridge, a full bridge reboot
may result in one or more cards suspended due to
clocking flux that is underway during a boot.

Long pauses may be experienced during roll call playing
due to competing requests to play prompts.

The T3 alarm clear indication received from the switch is
not timed as expected by the bridge, leaving the bridge in
an alarm state.

If an operator answers a request and the participant
disconnects before the operator does, the operator will
have difficulty answering the next request and an
exception is printed in the bridge logs.

Changed the way we deal with

the acknowledgment packets

for disable vs. busy span

commands.

Updated tick arithmetic to

handle the roll over. Don’t let

ticks fall below 1.

This has been fixed by a PLD

change that is now available

with a card swap.

DSP software was modified to

address this issue.

A change was inserted to

ensure both streams are valid

prior to considering a

resynchronization a

successful.

A change was made to ensure

that the main processor can

watch the DSP and, if it sees it

is in an unresponsive state, re-

initialize it.

Innstart script was modified to

introduce delay to allow clock

to stabilize before starting

drivers.

Ctrlproc was modified to

address this issue.

The timing has been changed

to eliminate this problem.

Additional RPC added for

channels to address missed

notification.

3725-70002-009G2 ReadiVoice v2.56.0 Release Notes
Confidential and Proprietary Page 53 Polycom, Inc.
