Poly 211423-04 User Manual
Savi 8200 Series
Wireless Headset System
User Guide
Contents
DECT Information 3
DECT Enhanced Security 3
Overview 4
Base and Headset Basics 4
Accessories 5
Hook up your system 6
Desk phone setup details 6
Position Your Base 7
Fit and charge 8
Customize Your Headset 8
Charge Your Headset 8
Talk Time 8
Headset Battery Status 8
Pair your headset 9
Auto Connect Feature 9
Load software 10
The basics 11
Headset Controls 11
Power on your headset 11
Make, answer, end calls 11
Change your default phone line 12
Get a dial tone 12
Adjust volume 12
Mute 12
Transfer mobile audio 12
Audio streaming 12
ANC 12
Optimize audio quality 12
Mini conference call 12
Set up a conference call 12
Change voice prompt language 13
More Features 14
Base Subscription Button 14
Troubleshooting 16
Headset 16
Desk Phone 17
Mobile 17
Softphone 17
Appendix 19
Plantronics Hub
System Requirements 20
configurable settings 19
Support 21
2
DECT Information
DECT 6.0 products should never be used outside the region in which they were originally
purchased and intended to be used.
The enclosed DECT 6.0 wireless product uses restricted wireless radio frequencies which vary by
country. DECT 6.0 devices are generally authorized for use in The Americas. Use of this DECT 6.0
product in unauthorized countries is a violation of law, may disrupt telecommunications networks
and devices, and can subject you to fines and penalties by regulatory agencies.
DECT Enhanced Security
Plantronics is a member of the DECT Forum and has fully adopted their recommendations for
enhancements to security within all DECT products.
Plantronics DECT-based products now fully incorporate the latest recommendations on Enhanced
Security from the DECT Forum and ETSI. These improvements cover registration, authentication,
authorization and encryption procedures. Plantronics DECT products are now secure against all
the known vulnerabilities that were highlighted by the public announcements of the Chaos
Council in 2009.
Plantronics Savi 8200 Series DECT products have been tested against and passed the DECT
Forum security certification requirements and consequently have been granted 'DECT Forum
security' logo certification.
Plantronics products using the new enhanced version of DECT that includes these security
improvements are marked on the base with the DECT Forum security logo.
3
1 2 3 4
5
6
7
8 9 10
11 12 13
14
1
2
3
4
5
6
Overview
Base and Headset Basics
Base
Power jack
1
Handset lifter jack
2
Telephone interface cable jack
3
USB port
4
Desk phone speaking volume
5
Desk phone configuration switch
6
Desk phone listening volume
7
Headset
Volume wheel
1
Call button
2
Mute
3
Be safe
Please read the safety guide for important safety, charging, battery and regulatory information
before using your new headset.
Computer button
8
Mobile phone button
9
Desk phone button
10
Incoming call ringer
11
Bluetooth pairing button/LED
12
Subscription button/LED
13
Charging LED
14
Headset LED
4
Power button
5
ANC (Active Noise Canceling)
6
4
Accessories
1 Electronic hookswitch cable (EHS cable) Electronically and automatically answers/ends a desk
phone call. Enables remote call control with your headset.
2 HL10 lifter Automatically lifts handset and returns it to the cradle. Enables remote call control
with your headset.
5
Hook up your system
Using the diagram, connect your headset system.
Desk phone setup details
Choose a desk phone setup A, B or C and connect cables.
A Desk phone (standard)
USE
• Connect one end of the telephone interface cable to the back of the base
• Disconnect the handset coil cord from the base of the desk phone and re-connect it to the
telephone interface cable junction box.
• Finally connect the remaining end of the telephone interface cable into the open handset port
on the desk phone.
NOTE If your phone has a built-in headset port, you should only use the headset port if you will
not be using the HL10 lifter. In this configuration, you must press both the headset button on your
phone and the call control button on the headset to answer or end calls.
6
B Desk phone + EHS cable (sold separately)
See the user guide at plantronics.com/accessories for details.
USE
C Desk phone + HL10 lifter (sold separately)
See the user guide at plantronics.com/accessories for details.
USE
Position Your Base
The minimum recommended separation between your desk phone and the base is 6 inches.
The minimum recommended separation between the base and computer is 12 inches. Incorrect
position can cause noise and interference problems.
7
