ML15
User Guide
Page 2
Contents
What's in the box 3
Headset overview 4
Be safe 4
Pair 5
Get paired 5
Pair another phone 5
Pair Another Phone 5
Reconnect 5
Charge and
Charge 6
Adjust the
The basics 7
Power 7
Make/Take/End Calls 7
Volume 7
Decipher the lights 7
Technical
Support 9
fit 6
fit 6
Specifications 8
2
Page 3
What's in the box
Headset
Optional ear loop
USB charge cable*
NOTE *Contents may vary by product.
3
Page 4
Headset overview
Power
Pair
Call answer/end
Be safe
Charge port
Headset LED (indicator light)
Please read the safety guide for important safety, charging, battery and regulatory information
before using your new headset.
4
Page 5
PLT_ML15
0000
Pair
Get paired
Pair another phone
The first time you power on your headset, the pairing process begins.
1 Press and hold the Call button until the LEDs flash red and blue.
2 Activate Bluetooth
®
on your phone and set it to search for new devices.
• iPhone Settings > Bluetooth > On*
• Android Settings > Bluetooth: On > Scan for devices*
NOTE *Menus may vary by device.
3 Select “PLT_ML15.” If necessary, enter four zeros (0000) for the passcode or accept the
connection. Once successfully paired, the LEDs stop flashing.
After pairing your headset to your phone, you may want to pair another phone.
1 Ensure your headset is powered off.
2 Press and hold the Call button until the indicator light flashes both red and blue.
3 Activate Bluetooth on your phone and set it to search for new devices.
4 Select “PLT_ML15.”
If necessary, enter four zeros (0000) for the passcode or accept the connection.
Pair Another Phone
Reconnect
Once successfully paired, the headset indicator lights stop flashing.
After pairing your headset to your phone, you may want to pair another phone.
1 Power on your headset.
2 Press and hold the Call
3 Activate Bluetooth on your phone and set it to search for new devices.
4 Select “PLT_ML15.”
button until the indicator light flashes red and blue.
If necessary, enter four zeros (0000) for the passcode or accept the connection.
Once successfully paired, the headset indicator lights stop flashing.
Your Bluetooth headset has up to 10 meters effective range. If you lose connection, your headset
will try to reconnect. If your headset doesn’t reconnect, tap the Call
button or manually
connect through the phone’s Bluetooth device menu.
5
Page 6
R
L
Charge and fit
Charge
Adjust the fit
Your new headset has enough power to pair and make a few calls. It takes 2 hours to fully charge
the headset; the indicator light turns solid blue once charging is complete.
The universal-fit eartip has a thin loop that bends to gently tuck into the contours of either ear.
To adjust the fit, you can rotate the eartip on the headset or add the optional clip-on earloop.
6
Page 7
The basics
Power
Make/Take/End Calls
Volume
Decipher the lights
To power on or off, press the Call button until the indicator light flashes blue once (on) or
red once (off).
Answer or end a call
Tap the Call button.
Redial
To dial your last number you dialed, double-tap the Call
Voice dial
If your phone supports voice-activated dialing, press and hold the Call
wait for the phone prompt and then tell the phone to dial the number of a stored contact.
Adjust the volume on your phone to control your headset volume.
Your headset has an indicator light
button press.
Some examples of what you will see are:
• Solid red until charging complete and then solid blue
• Flashing red and blue during pairing
• Double red flash when battery low
• Double blue flash at incoming call
that flashes in response to a change in status or after a
button.
button for 2 seconds and
7
Page 8
Technical Specifications
Talk Time
Standby Time
Operating Distance
(Range)
Headset Weight
Charge Connector
Battery Type
Charge Time
(Maximum)
Power
Requirements
Bluetooth Version
Bluetooth Profiles
Operating
Temperature
Up to 6 hours
Up to 9 days
Up to 33 feet (10 meters) from phone or table, Class II
9 grams
Micro USB charging
Rechargeable non-replaceable lithium ion polymer
2 hours for full
5V DC – 80 mA
Bluetooth v3.0
Hands-Free Profile v1.5 (HFP), Headset Profile v1.1 (HSP), Simple Secure Pairing
(SSP)
32°F - 102°F (0 - 40°C)
Storage
Temperature
Charging
Temperature
32°F - 102°F (0 - 40°C)
32°F - 104°F (0 - 40°C)
8
Page 9
Support
EN
Tel: 0800 410014
AR
Tel: +44 (0)1793 842443*
CS
Tel: +44 (0)1793 842443*
DA
Tel: 80 88 46 10
DE
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
EL
Tel: +44 (0)1793 842443*
ES
Tel: 900 803 666
*Support in English
FI
Tel: 0800 117095
FR
Tel: 0800 945770
GA
Tel: 1800 551 896
HE
Tel: +44 (0)1793 842443*
HU
Tel: +44 (0)1793 842443*
IT
Tel: 800 950934
NL
NL 0800 7526876
BE 0800 39202
LUX 800 24870
NO
Tel: 80011336
PL
Tel: +44 (0)1793 842443*
PT
Tel: 0800 84 45 17
RO
Tel: +44 (0)1793 842443*
RU
Tel: 8-800-100-64-14
Tel: +44 (0)1793 842443*
SV
Tel: 0200 21 46 81
TR
Tel: +44 (0)1793 842443*
For warranty details, go to plantronics.com/warranty.
NEED MORE HELP?
plantronics.com/support
Plantronics, Inc. Plantronics BV
345 Encinal Street
Santa Cruz, CA 95060
United States
©
2015 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics is under license. All
other trademarks are the property of their respective owners.
Patents: US D681,602; D699,215; CN ZL201230490196.9; EM 002109645; and TW D157594.
205483-06 (07.15)
