AROMA 850 - 800
ENGLISH
Fig.1
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
M
L
A
B
D
E
C
J
F
G
K
I
H
J1
Fig.2
Aroma 850
Aroma 800
3
6
READING KEYS
A) Pitcher lid
B) Pitcher
C) Boiler
D) Disk filter
E) Gasket
F) Base
G) Power cable
H) Illuminated functioning switch.
I) Safety valve
J) Funnel filter
J1) Adapter disk for 3 cups (only Aroma 850)
K) Separator disk
L) Supply tube
M) Tube gasket
This apparatus conforms with EC 89/336 directive modified by 93/68 (EMC) and 73/23 directive, modified by 93/68 ( low voltage)
POLTI S.p.A, reserves the right without prior notice to
introduce technical and construction changes as it considers necessary.
PPRREECCAAUUTTIIOONNS
S
KEEP THESE INSTRUCTIONS
• Read these instructions for use carefully before
using the appliance.
• Use which does not comply with these instructions
will invalidate the warranty.
• The wiring system to which the appliance is connected must always comply with the laws in force.
• Before connecting the appliance, make sure that the
mains voltage is the same as the voltage indicated
on the data label of the appliance and that the power
outlet is connected to earth.
• Always turn off the appliance at the on/off switch
before unplugging it.
• If the appliance is left unused, always disconnect it
from the mains. Never leave the appliance unattended with the cable plugged into the mains.
• Always make sure the appliance is unplugged before
performing maintenance or cleaning of any kind.
• Do not pull the power cord out of the socket, but
grasp the plug itself to avoid damage to the socket.
• Do not allow the power cord to be twisted, crushed,
stretched, or come into contact with sharp or hot surfaces.
• Do not use the appliance if the power cable or other
important parts are damaged.
• Do not use electric extension leads that are not
authorized by the manufacturer, as they may cause
damage or fire.
• If it is necessary to replace the power supply cable,
please refer to the nearest Polti authorised service
centre, since the use of a special tool is necessary.
• Never touch the appliance with wet hands or feet
with the cable plugged into the mains.
• Do not use the appliance when barefoot.
• Do not use the appliance near a bathtub, shower or
container full of water
• Never immerse the appliance, the cable or the plugs
in water or any other liquid.
• Use of the appliance in places where there is a danger of explosions is prohibited.
• Do not use the product with toxic substances.
• Do not lay the hot appliance on surfaces sensitive to
heat.
• Do not leave the appliance exposed to wind or rain.
• Do not place the appliance near a live element, an
electric stove or any other source of heat.
• Do not expose the appliance to extreme temperatures
• Never let children or people who are not familiar with
how the appliance works use it.
• Do not press the buttons hard or with a pointed
object such as a pen.
• Always rest the appliance on a stable surface.
• In case of accidental fall of the appliance it is necessary to have it checked by an authorized Service
Centre as the internal safety features may have been
affected.
• In case of breakdown or malfunction switch off the
appliance and never attempt to disassemble it, but
refer to an authorized Service Centre.
• In order to avoid prejudicing the safety of the appliance, use only original spare parts and accessories
approved by the manufacturer.
• Do not wind the power cord around the appliance,
especially when the appliance is still hot.
• Do not put any detergent or chemical substance in
the boiler.
• This machine has been manufactured to “make coffee”. Do not use other extracts, cocoa powders,
camomile, or other herb teas as they could block up
the holes in the filter.
• When using the appliance do not touch the hot surfaces.
• The packing elements (plastic bags, polystyrene
foam, etc.) should be kept out of the reach of children
as they are a safety hazard.
• Moka is only to be used with the stand provided.
Never rinse the boiler
under the tap and never
immerse it in water.
AROMA 850 - 800
ENGLISH
CCOORRRREECCTT
PPRROODDUUCCTT
UUSSE
E
This appliance is intended for household use only
according to the descriptions and instructions contained in this user manual. Please read these instructions carefully and keep them, they could be useful in
the future.
WWAARRNNIINNGGS
S
• This appliance has been built in keeping with the current regulations on the recycling.
• It is recommended not to throw in the domestic rubbish the protective packaging materials used in
transportation but to deliver them to the appropriate
collecting centre.
• We recommend only the use of original spare parts.
• Polti S.p.A. disclaims all responsibility in case of
accident due to the use of this appliance which is
not in keeping with the present directions for
use.
PPLLEEAASSEE
NNOOTTE
E
All our products are rigorously tested before leaving the
factory.
IINNSSTTAALLLLAATTIIOON
N
Place the appliance on a work surface away from
water.
HHOOWW
TTOO
PPRREEPPAARREE
TTHHEE
CCOOFFFFEEE
E
IMPORTANT:
• Do not use the coffee maker without water.
• Do not use hot water to speed up coffee making.
• Use just fresh and clean water; do not use salt waters
or waters rich in limestone as they will change the
coffee taste.
• Use good quality, medium-ground coffee for your
mocha coffee maker.
• The first time the coffee maker is used all the
accessories and the inside of the boiler should be
washed with hot water; then make and throw
away a few servings of coffee before proper use
for consumption.
PPRREEPPAARRIINNGG
TTHHEE
CCOOFFFFEEEE
MMAAKKEER
R
1. Make sure that the coffee maker has cooled down
and unscrew the pitcher (B), keeping the boiler still
(C) (fig.1), DO NOT lever the handle upwards.
2. Take off the Funnel filter (J) and fill the boiler with
fresh water.
Aroma 850:
• If you wish to prepare 6 cups of coffee, fill the boiler up to the notch 6.
• If you wish to prepare 3 cups instead, fill the boiler
up to the notch 3 (fig.2).
Aroma 800:
• Fill the boiler with fresh water up to the
notch (fig.2).
3. Insert the funnel filter (J) in the boiler (fig.3). If you
wish to prepare 3 cups (only
Aroma 850
), insert the
adapter disk(J1) as well in the funnel filter (J) (fig.4).
4. Fill the funnel filter (J) with ground coffee, do not
press it or exceed the filter level.
5. Distribute the ground coffee uniformly and remove
any excess of coffee from the edge of the filter.
6. Screw up the coffee maker in the opposite direction
to point 1, avoiding to lever the handle upwards.
Make sure to tighten the pitcher correctly (B) Do it
firmly but do not force it too tight (fig.1).
7. Insert the separator disk (K) on the supply tube (L),
tongue it correctly (fig.5). Pay attention to the arrow,
which MUST point in the same direction as the coffee delivery (fig.6).
8. Close the pitcher lid (A).
9. Connect the power cable (G) to a power socket of
the correct voltage.
10. Insert the coffee maker on the base (F) correctly
(fig.7).
11. Press the functioning switch (H). The appliance
starts to function and the switch (H) becomes illuminated.
12. The coffee will come up after a few minutes. Once
coffee delivery is over, the switch (H) returns to the
original position and turns off.
N.B: If at any time the coffee maker gets separated from
the base, the switch (H) returns to the original position
and turns off. To bring the appliance back into use, just
repeat the steps as previously described.
SSEEPPAARRAATTOORR
DDIISSKK
((KK))
FFUUNNCCTTIIOON
N
The separator disk allows to create a “double room”
within the pitcher lid (B).
The “double room” permits to keep the coffee tempera-
ture constant longer, and to maintain unchanged the
coffee’s organic properties.
GGEENNEERRAALLMMAAIINNTTEENNAANNCCEE
AADDVVIICCE
E
• Always unplug the power cable from the electricity
before doing any appliance maintenance or cleaning.
• Make sure that the appliance has cooled down after
The coffee maker must be
operated exclusively by plugging into the electrical supply
and never by resting it on lit
gas rings or hot plates.
AROMA 850 - 800
ENGLISH
use before doing any maintenance or cleaning.
• Every so often clean the inside of the supply tube (L)
letting clean hot water run through it.
• Regularly check the disk filter (D), the gasket (E) and
the tube gasket (M). Replace only with original spare
parts if there are signs of wear or deterioration.
• Periodically check that the holes in the disk filter (D)
are not blocked. Clean it with a pin if necessary.
• Do not wash any coffee maker part in the dishwasher.
• Do not use acids or solvents to clean the exterior of
the appliance, just a damp cloth, making sure that
the water does not wet the electrical parts of the appliance.
• Never rinse the boiler under the tap and never
immerse it in water.
AROMA 850 - 800
ENGLISH
TTRROOUUBBLLEESSHHOOOOTTIINNG
G
Problem Cause Solution
No coffee is released No water in the boiler Fill the boiler with fresh water
The coffee takes a
long time to be
released
The coffee used is not the right type
The disk filter is blocked.
The coffee has been pressed.
Scale presence into the boiler.
Use ground coffee for Mocha coffee maker
Clean the disk filter as described in the “General
maintenance advice” paragraph.
Do not press the ground coffee.
Remove the scale from the lower vessel
Coffee leaks from the
edges of the boiler.
The disk filter is blocked
The gasket is burned or torn
The coffee maker has not been started
correctly.
Clean the disk filter as described in the “General
maintenance advice” paragraph.
Replace the gasket.
Start the coffee maker correctly.
AROMA 850 - 800
ENGLISH
FOR YOUR OWN SAFETY READ FOLLOWING INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO
CONNECT THIS UNIT TO THE MAINS.
MMAAIINNSS
((AACC))
OOPPEERRAATTIIOON
N
This unit is designed to operate on 240V, 50 Hz current only. Connecting it to other power sources may damage the
unit.
WARNING - This appliance must be earthed.
This appliance may be fitted with a non-rewireable plug, if it is necessary to change the fuse in a non-rewireable plug
the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement,
available from the appliance manufacturer, is obtained. It is important that the colour of the replacement fuse cover
corresponds with the colour marking on the base of the plug.
If the plug needs to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off
and an appropriate plug fitted following the wiring instruction (below). The plug removed must be disposed of safely as insertion into a 13A socket is likely to cause an electrical hazard.
IMPORTANT
These wires in this mains lead are coloured in accordance with the following code.
• Green-and-yellow: Earth • Blue: Neutral •Brown: Live
As the colours of the wires in the mains leads of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the letter "E" or by the earth symbol or green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter "N" or coloured
black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter "L" or coloured
red.
GREEN
&
YELLOW
(Earth)
BLUE
(Neutral)
FUSE
(13 amp)
BRAWN
(Live)
