POLTI aEspresso Crema User Manual

7a

7

2

5

4

8

3

Fig.1

Fig.2

1

10

11

6

1

1

9

2

3

Fig.3

2

Fig.4

M0S10908 1U01

@ESPRESSO

PRECAUTIONS

KEEP THESE INSTRUCTIONS

• Read these instructions for use carefully before using the appliance. Any use
which does not comply with these instructions will invalidate the warranty.

• The wiring system to which the appliance is connected must always comply with
the laws in force.

• Before connecting the appliance, make sure that the mains voltage is the same
as the voltage indicated on the data label of the appliance and that the power out-

ENGLISH

let is connected to earth.

• Always turn off the appliance at the on/off switch before unplugging it.

• If the appliance is left unused, disconnect it from the mains. Never leave the ap­pliance unattended with the cable plugged into the mains.

• Always make sure the appliance is unplugged before performing maintenance
work of any kind.

• Do not pull the power cable out of the socket, but grasp the plug itself to avoid
damage to the socket.

• Do not allow the power cable to be twisted, crushed, stretched, or come into con­tact with sharp or hot surfaces.

• Do not use the appliance if the power cable or other important parts are dam­aged.

• Do not use electric extension leads that are not authorized by the manufacturer,
as they may cause damage or fire.

• If it is necessary to replace the power supply cable, please refer to the nearest
Polti authorised service centre, since the use of a special tool is necessary.

• Never touch the appliance with wet hands or feet with the cable plugged into the
mains.

• Do not use the appliance when barefoot.

• Do not use the appliance near a bathtub, shower or container full of water.

• Never immerse the appliance, the cable or the plugs in water or another liquid.

• Use of the appliance in places where there is a danger of explosions is prohibited.

• Do not use the product with toxic substances.

• Do not lay the hot appliance on surfaces sensitive to heat.

• Do not leave the appliance exposed to wind or rain.

• Do not place the appliance near a live element, an electric stove or any other
source of heat.

8

@ESPRESSO

• Do not expose the appliance to extreme temperatures.

• Never let children or people who are not familiar with how the appliance works
use it.

• Do not press the buttons hard or with a pointed object such as a pen.

• Always rest the appliance on a stable surface.

• In case of accidental fall of the appliance it is necessary to have it checked by an
authorized Service Centre as the internal safety features may have been af­fected.

• In case of breakdown or malfunction switch off the appliance and never attempt
to disassemble it, but refer to an authorized Service Centre.

• In order to avoid prejudicing the safety of the appliance, use only original spare
parts and accessories approved by the manufacturer.

• Do not wind the power cable around the appliance, especially when the appli­ance is still hot.

• It is necessary to keep the appliance in horizontal position during operation.

• Check that there is water in the reservoir before turning on the machine.

• To fill the water reservoir use only fresh, clean water, never use sparkling mineral
water, demineralised water, distilled water, milk or other liquids.

• During refilling with water, switch off and disconnect the appliance from the
mains.

• Do not wash coffee machine accessories in the dishwasher.

• WARNING: the capsule is automatically pushed into the compartment when

the door (7a) is closed, pushing it as far as it will go. Never push the ca­psule in with your fingers.

• The presence of water in the capsules collection drawer is normal and is due to
emptying of the circuit after making each cup.

• This appliance is not intended for use by persons (including children) with re­duced physical, sensory or mental capabilities, or lack of experience and knowl­edge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• The appliance must not be used if it has fallen, been dropped or when it has visi­ble signs of damage or leaks.

• If the supply cord is damaged, it must be replaced by the manufacturer, its ser­vice agent or similarly qualified persons in order to avoid a hazard.

ENGLISH

9

@ESPRESSO

Read these instructions carefully before using the appliance.

KEY

1) Water reservoir

2) Reservoir lid

3) Main switch

4) ON/OFF indicator light

5) “Out of water” light

ENGLISH

6) Coffee dispenser

CORRECT USE OF THE

PRODUCT

This appliance is intended to be used in
household and similar applications such as:

• Staff kitchen areas in shops, offices and
other working environments;

• Farm houses;

• By clients in hotels, motels and other resi­dential type environments;

• Bed and breakfast type environments.

Please read the instructions carefully and
keep them, as they could be useful to you in
the future.

Polti S.p.A declines liability for any dam­age or accident derived from any use of
this appliance which is not in conformity
with the instructions contained in this
manual.

7) Capsule compartment

7a) Capsule compartment door

8) Dispenser switch

9) Used capsules collection drawer /

Drip tray

10) Power supply cable

11) Cleaning capsule

ATTENTION

Directive 2002/96/EC (Waste Electrical and
Electronic Equipment - WEEE): information
for users
This product complies with EU Directive
2002/96/EC.

The crossed-out wastebasket sym­bol on the appliance means that at
the end of its useful lifespan, the
product must be disposed of sepa-

rately from ordinary household wastes.

The user is responsible for delivering the ap­pliance to an appropriate collection facility at
the end of its useful lifespan. Appropriate
separate collection to permit recycling, treat­ment and environmentally compatible dis­posal helps prevent negative impact on the
environment and human health and promotes
recycling of the materials making up the prod­uct. For more information on available collec­tion facilities, contact your local waste collec­tion service or the shop where you bought
this appliance.

This unit conforms with EC-directives 2004/108/CE (EMC) and 2006/95/CE (low volta­ge).

Polti S.p.A. reserves the right to change equipment or accessory specification without
prior notice.

10

@ESPRESSO

THE CAPSULE SYSTEM

The machine is designed exclusively for use
with the "Aroma Polti" capsule. Each capsule
contains just the right amount and just the
right grind to obtain the best espresso coffee
in a few seconds. The wrapper on the cap­sule is made of polypropylene, an excellent
material for use in contact with foodstuff. It is
hygienic, convenient, and very resistant to
high temperatures.
The capsule system is not only very convenient
and easy to use, it guarantees all the freshness
and aroma of freshly roasted coffee, so that
you can enjoy your favourite blend.

Use with capsules other than "Aroma
Polti" capsules will result in forfeiture of
the warranty.

SET UP - PREPARATION OF

THE MACHINE

• Carefully remove the machine and the ac­cessories from the package.

• Open the lid, remove the water reservoir (1)
(fig.1) and wash it with clean cold water.

• Fill the reservoir (1) with clean cold water
only, put it back into the machine and close
the lid.
Do not fill the reservoir with carbonated wa­ter or any other liquid.

• Insert the power cable plug (10) into a
suitable earthed socket.

• Turn on the appliance by pressing the main
switch (3). The ON/OFF indicator light will
come on (4).

• The machine will be ready for use about 2
minutes after it is turned on.

• The maximum quantity of coffee that is pos­sible to make is of about 50 ml.

MAKING COFFEE

• Put a cup under the coffee dispenser (6).
The coffee dispenser (6) may be removed
for cleaning or when using a recipient taller
than an espresso cup. Follow the instruc­tions in the “MAINTENANCE” section to re­move it.

• Open the capsule compartment door (7a)
and put a capsule in the compartment (7),
in the position suggested by its shape
(fig.2).

• Close the door, pushing it all the way.

• WARNING: the capsule is automatically
pushed into the compartment when the
door (7a) is closed, pushing it as far as
it will go. Never push the capsule in with
your fingers.

• Press the dispenser switch (8) to have the

coffee come out after a while. When you
have the desired quantity of coffee, press
the switch (8) again to stop dispensing. In
this way you can make longer or shorter
coffee, as you wish, by controlling the
amount dispensed.

• The used capsule automatically falls into

the collection drawer (9) when a new one is
placed in the compartment (7).

Empty the used capsules drawer fre­quently to ensure that used capsules do
not block the exit passage.

NOTE: before switching on the appliance at

the switch (8), make sure that you have in­serted the capsule for the drink you wish to
make, or an empty capsule if you intend to
clean the appliance. If you have not placed
any capsule in it, the water that is dispensed
will not come out of the coffee dispenser (6)
but fall into the used capsules drawer (9).

ENGLISH

WARNING: The first time you use the appli­ance, it is important to do a washing cycle us­ing a cleaning capsule provided as described
in the "MAINTENANCE" section.

MAINTENANCE

• Always unplug the appliance before per­forming any maintenance operations.

• Clean the outside of the appliance with a
damp cloth only. Never use solvents or de­tergents, as they could damage the plastic
surface.

11

@ESPRESSO

• Clean the coffee dispenser (6) periodically

and whenever the machine has not been
used for a long time. To remove it from the
appliance, turn it clockwise as far as it will
go and remove it from its housing (Fig.3).
Rinse it in running water and put it back on
the appliance.

• To clean the brewing elements and to help
maintain your Polti capsule coffeemaker,
use a cleaning capsule at least every 2/3
days. Cleaning is done in exactly the same

ENGLISH

way as making coffee: just put the cleaning
capsule in the machine and make sure
there is enough water available for a cup of
coffee (Fig. 4).

TIPS: Place a dish underneath the outlet to
collect water.

• Empty and clean the drip tray (9) regularly,
by removing it from its housing.

To clean and maintain your Polti capsule cof­feemaker, we recommend using the Clean
Espresso cleaning kit (item code PAEU0176).
Clean Espresso cleans and protects, exten­ding the life of your coffeemaker thanks to two
new, specifically designed formulas (decal­cifying and degreasing).

Clean Espresso is available at
www.aromapolti.com

12

PROBLEM CAUSE SOLUTION

Both ON indicator light (4)
and “out of water” light (5)
are off.

Both ON indicator light (4)
and “out of water” light (5)
are on.

Both ON indicator light (4)
and “out of water” light (5)
are on during coffee dis­pensing.

The used capsules drawer
(9) does not close (do not
force it)

The appliance appears to
work properly, but it does
not dispense coffee

Coffee comes out cold

The machine jams and wa­ter comes out of the
capsules collection drawer

The machine does not
make coffee the first time it
is turned on or after filling
the reservoir

@ESPRESSO

TROUBLESHOOTING

The appliance is not plugged
in

The main switch (3) is off

The water reservoir (1) is
empty or incorrectly inserted.

The water reservoir (1) is
empty.

The drawer is full of used
capsules

No capsule in the compart­ment.
Empty capsule for cleaning in
the compartment.

The appliance has not
reached the optimal operat­ing temperature

The capsules collection draw­er is full

The reservoir has not been
inserted correctly, or the
appliance is initially unable to
obtain water

Plug the power cable into a suit­able power outlet

Turn on the main switch

Fill the water reservoir (1).
Check that the reservoir has been
inserted correctly.

ENGLISH

Stop coffee dispensing, fill the
reservoir, put in a new capsule
and start coffee dispensing again.

Empty the drawer and put it back
in the appliance.

Put the right capsule in the com­partment and repeat the process.

Wait a few minutes to allow the
appliance to reach operating tem­perature.

Empty the capsules collection
drawer

Insert the reservoir correctly and
make sure it has been completely
filled

13
