Polsen ULW-16-HHT User Manual
-16
16-CHANNEL
CAMERA-MOUNTABLE UHF
WIRELESS
SYSTEM
PRODUCT
MANUAL
16-CHANNEL
CAMERA-MOUNTABLE
UHF WIRELESS SYSTEM
2
ULW-16
THANK YOU FOR CHOOSING POLSEN.
The Polsen ULW-16 and ULW-16-HL are 16-channel camera-mountable UHF wireless systems
designed to transmit audio more than 100 feet. Engineered to be exceptionally quiet, and with
many professional features like headphone monitoring, line input, and frequency agility, both
systems are ideal for EFP (electronic eld production), ENG (electronic news gathering), DSLR, and
other video applications that can benet from the advantages of a user-friendly wireless system.
With its impressive 105 dB signal-to-noise ratio, the ULW-16 and ULW-16-HL deliver pristine
audio transmission for broadcast-quality recordings. You can choose from 16 channels to avoid
interference. Up to ve systems (or more under optimum conditions) can be used simultaneously
in the same location.
The receiver features a line output and included XLR cable for professional cameras. It also
includes a cable for DSLR and consumer camcorders that have a 1/8″ mic input. A headphone
jack and volume control allows you to monitor the transmission signal in real time at a
comfortable volume.
The ULW-16 system includes a transmitter that features a variable-level control that lets you
adjust the transmission level. It’s also equipped with a line input that enables the transmission
of such devices as an audio mixer. The system offers a choice of omnidirectional lavalier
microphones: the 0.20″ PL4 lavalier providing exible positioning options, and the 0.14″ PL5 mini
lavalier for more discreet microphone placement. Both provide excellent wind and noise rejection.
The included windscreen can be used to reduce vocal plosives (pops) and wind noise,
and the mics can be readily placed on a collar, necktie, or costume with the included
tie clip.
The ULW-16-HL system includes a sturdy, broadcast-quality handheld transmitter
ideal for a variety of applications such as news reporting or recording interviews.
It features a mic capsule with a cardioid polar pattern ideal for video applications
where background noise can be problematic such as outdoors, on trade show oors,
or at live events. The channel selector button makes it easy to switch between the
unit’s 16 UHF channels, effectively minimizing frequency interference. An integrated
foam windscreen under the mic grille serves the dual purpose of minimizing vocal
pops and wind noise, and protecting the mic capsule from moisture.
CONTENTS
Introduction ................................................ 2-3
Overview ...................................................... 4-6
Precautions .....................................................6
Installing Batteries ........................................ 7
Operating Instructions .......................... 8-10
Both systems operate in the UHF 500 MHz bandwidth assuring less susceptibility to
interference than VHF systems and greater reliability at longer distances. Operating
in this bandwidth also ensures that the ULW-16 and ULW-16-HL systems are “future
proof” and meet current and known future FCC regulations.
With features like easy-to read LED indicators, front panel access to batteries, and
included accessories, Polsen’s ULW-16 and ULW-16-HL are designed with the user
in mind. Professionals and enthusiasts alike will benet from its ease of operation,
durability, sensible ergonomics, and portability.
Please read and follow these instructions and keep this manual in a safe place.
Mounting ..................................................11-12
Stage Direction and Talent Cueing ........13
Troubleshooting ..................................... 14-17
Specications .........................................18-19
One-Year Limited Warranty .................... 20
3
33
OVERVIEW
10.
Transmitter Receiver
18.
4.
2.
17.
3.
1.
9.
6.
5.
7.
8.
11.
12.
13.
14.
15.
24.
25.
20.
19.
21.
22.
26.
16.
23.
27.
28.
4
Transmitter
1. Level control
Receiver
15. Headphone-level control
2. TX LED
3. Microphone input
4. Antenna
5. Line-level input
6. Channel indicator LED
7. Channel up/down buttons
8. Battery compartment panel
9. Belt clip
10. Charging contacts
11. PL4/PL5 omnidirectional microphone
12. Tie clip
13. Windscreen
14. AA batteries (4)
16. RF LED
17. Headphone output
18. Antenna
19. Audio output (line level)
20. Channel indicator LED
21. Channel up/down buttons
22. Battery compartment panel
23. Locking wheel
24. Mounting foot
25. 1/4″-20 threaded socket
26. Charging contacts
27. Line to mic attenuator cable
28. Line-level output cable
5
5
Handheld Transmitter
1.
1. Grille and windscreen
3.
2. Mic capsule
PRECAUTIONS
• Exposure to high sound levels can cause
permanent hearing loss. Avoid listening at high
3. Anti-roll ring
2.
4.
5.
6.
4. LCD display
5. Channel indicator
volumes for extended periods of time.
• Keep this product away from water and any
ammable gases or liquids.
7.
10.
11.
8.
6
9.
12.
6. Battery use meter
7. Power switch
8. Battery cover
9. Battery compartment
10. Channel selector button
11. Gain level control
12. Antenna
• Handle this product with care.
• Clean this product with only a soft, dry cloth.
• Keep this product away from children.
• Use only parts provided by the manufacturer.
• All photos are for illustrative purposes only..
