Polsen HPA-4X2 User manual

-4X2

4-CHANNEL STEREO REFERENCE

HEADPHONE
AMPLIFIER

PRODUCT
MANUAL

1

4-CHANNEL

STEREO REFERENCE

HEADPHONE AMPLIFIER

2

HPA-4X2

THANK YOU FOR CHOOSING POLSEN.

The Polsen HPA-4X2 Stereo Reference Headphone Amplier is a compact and powerful headphone
amplier that can withstand the rigors of professional use. It is ideal for studio recording, stage
monitoring, or any application where multiple headphone connections are needed.

The four ¼-inch TRS stereo headphone outputs each have their own volume control, and each channel
has an individual amplier circuit that offers maximized output levels with low and minimal distortion.
Wide frequency response guarantees full-range stereo sound, and there is no loss of signal when all
four headphones are connected. The ¼-inch TRS and stereo RCA inputs accommodate a wide variety
of input sources. The mini plug cable used with a mini plug adapter lets the HPA-4X2 use a handheld
media player or smartphone as an input source, and the mini plug adapters allow monitoring with
earbuds.

Among the benefits you’ll enjoy:

• Durable and compact. Easy to use.

• High output level for precise monitoring at high volume

• Low noise circuitry

• ¼-inch TRS and RCA inputs

• Four headphone jacks each with independent volume

controls

• Wide frequency response (20 Hz-20 kHz) for full-range
stereo sound

• Stereo/mono switch provides options for monitoring
playback

• Link feature to daisy chain additional headphone
ampliers.

PRECAUTIONS

• Please read and follow these instructions and keep this
manual in a safe place.

• Exposure to high sound levels can cause permanent
hearing loss. Avoid listening at high volumes for
extended periods of time.

• Use only the correct, recommended voltage.

• Use only the power adapter included with this product.

• Clean this product with only a soft, dry cloth.

• Make sure that this product is intact and that there are

no missing parts.

• All photos are for illustrative purposes only.

3

OVERVIEW

1. Volume knobs

2. ¼" TRS stereo input jack

3. RCA inputs

4. ¼" TRS stereo headphone output jacks

5. Power LED

6. Stereo/mono switch

7. DC 12V power input

8. DC 12V/150mA power supply

9. 1/8" (3.5 mm) stereo mini to 1/4" TRS stereo adapter (4)

10. Stereo mini male to stereo mini male cable

4

7.

1.

5.

4.

8.

6.

9.

10.

2.

3.
