Instruction manual
Electric glass door lock
Touch-to-open
Operating instructions draft | 09-2017_v1
OPERATING INSTRUCTIONS
Touch to open electric glass door lock
1
Content
1 General
1.1 Performance Description as per the Building Product Ordinance
1.2 EC Declaration of Conformity
2
3
4
2 Description of the Electric Glass Door Lock
2.1 Technical Data
2.2 Function
5
6
6 Removal & Disposal 19
7 Approved Handles 19
4 Installation
4.1 Installation of the Door Hinges
4.2 Installing the Glass Door Lock
10
12
13
5 Operation and Maintenance
5.1 Troubleshooting
5.2 Emergency Release
5.3 Cleaning
5.4 Replacing the Batteries
14
15
16
17
17
3 Security
3.1 Intended Use
3.2 Unintended Use
8
8
9
2
OPERATING INSTRUCTIONS
Touch to open electric glass door lock
1 General
Please read through these operating instructions carefully before fitting or using the
product. They contain important instructions on safety which help to avoid risks, errors and
malfunctions. Keep the instructions in a safe place.
The manufacturer's warranty is voided in any case of change, extension and modification
(mechanical or electrical) of the electric glass door lock, opening the casing, or damage
caused by use of force.
The scope of supply includes:
• the electric glass door lock
• four AA Mignon alkaline batteries (1.5 V)
• three M5 x 16 countersunk screws with 3mm hexagon socket
• a design trim panel for the inside of the hinge
• a design trim panel for the outside of the hinge
• two office hinges with hinge pins
• two cover caps with clamping plates
• two frame parts
• four M6 x 20 countersunk screws with 4mm hexagon socket
3
1.1 Declaration of Performance
Declaration of Performance as per Annex III of (EU)
Ordinance no. 305/2011 (Building Product Ordinance)
1. Type:
2. Intended use:
3. Manufacturer:
4. Authorised representative:
5. System for evaluation and verification
of performance:
6. Harmonised standard:
7. Declared performance:
Electric glass door lock
Touch to open - EGS1
Motorised actuation of the latch in
single-leaf, interior glass doors
Baugruppentechnik Pollmeier GmbH,
Hövelrieger Str. 26, D-33161 Hövelhof
. / .
4
EN 14846:2008
Feature Performance
Use category:
Continuous operability and load on latch
Door mass and closing force
Suitability for use in fire protection/smoke protection doors
Security
Corrosion resistance, temperature, humidity
Protection and drill open resistance
Protection of electrical function
Protection against electrical manipulation
N/A*
S
N/A*
0
None
0
0
0
1
8. Legally binding declaration
The performance of the above mentioned product as per no. 1 complies with the declared
performance as per no. 7. The manufacturer stated above is exclusively responsible for
creating this declaration in compliance with (EU) Ordinance no. 305/2011.
* Deviates from the standard as a glass door lock
Hövelhof, 1 June 2017
4
1.2 EC Declaration of Conformity
EC Declaration of Conformity BGP 09-2017
pursuant to the EC Machinery Directive 2006/42/EC
to which this Declaration relates, complies with all applicable provisions of EC Directive
2006/42/EC – Machinery Directive.
The machine also complies with the provisions of EU Directive 2004/108/EC - Electromagnetic Compatibility - and adheres to the protection objectives of the Low Voltage Directive
2006/95/EC as per Annex I, no. 1.5.1 of Machinery Directive 2006/42/EC.
The technical documentation exists in full; the operating instructions which belong to the
machine exist in the original version.
The authorised representative for compiling the technical documentation is:
Development Department, Baugruppentechnik Pollmeier GmbH, Hövelrieger Strasse 26,
33161 Hövelhof, Germany
Designation:
Type:
Serial number:
Touch to open electric
glass door lock - EGS1
See product label
Baugruppentechnik Pollmeier GmbH, Hövelrieger Str. 26, 33161 Hövelhof, Germany,
hereby declares in sole responsibility that the following machine
OPERATING INSTRUCTIONS
Touch to open electric glass door lock
Hövelhof, 1 June 2017
