Page 1
™
RESERVE
TOWER SPEAKERS
Flagship-quality sound, elegant and refined looks, true value
FPO
www.polkaudio.com
Page 2
R500 Compact
Floorstanding Speaker
Slim and powerful, fits into any décor
The R500 slim and elegant floorstanding tower delivers
impactful sound in a compact design that fits beautifully
into any décor.
SPECIFICATIONS
Transducer 1" Ring Radiator
Two 5 ¼” Turbine Cone
Minimum Impedance 3.9Ω
Sensitivity 87dB
Designed for R900 Yes
Frequency Response 49Hz - 36kHz
Dimensions
and Weight
Consumer Benefits
Amazing Sound and Elegance
With a slim and elegant design, the Reserve line has a minimal
elegance that will fit into any décor. Inheriting Polk’s flagship
transducer array, the R500 produces exceptional sound that rivals
competitor speakers that sell for twice the price. Hi-Res certified,
the Reserve R500, is designed for today’s two-channel music
listening as well as multi-channel 3D audio found in movies, sports,
and video game soundtracks.
Polk Newly Patented X-Port
Polk’s newly patented X-Port incorporates an Eigentone Filter
(ETF) offering distortion-free, effortless bass. Consisting of a set
of closed-pipe absorbers that are specifically tuned to catch
and eliminate traditional speaker distortions. X-Port ensures
that the upper bass and mid-range are free of port and cabinet
resonances for smooth, detailed audio.
(W)255.4mm x (H)1044.5mm x
(D)348.8mm
(W)10.1” x (H)41.1” x (D)13.7”
39Ibs/17.7kg
High Definition Pinnacle Ring Radiator Tweeter
Over 40 years of tweeter innovation, design and prototyping has
led to the development of the new 1” high definition Pinnacle
ring radiator tweeter. Developed by Polk Audio, it delivers ultraclear, crisp highs without unwanted coloration or distortions.
The Pinnacle tweeter features a finely tuned waveguide that
dramatically improves the dispersion of high frequency energy
ensuring a broad “sweet spot” while the critically damped rearchamber helps defeat any unwanted resonances.
Dual 5.25” Turbine Cones
Polk developed the Turbine cone specifically for our flagship
products to ensure the natural reproduction of the mid-range,
to which human ears are particularly sensitive. These Turbine
cones combine Polk’s proprietary foam core and molded Turbine
geometry which dramatically increases stiffness and damping,
without adding mass. You will hear every detail and experience a
smooth, detailed mid-range and effortless bass.
Features
• Pinnacle Tweeter: The new ring radiator tweeter design
dramatically improves dispersion while delivering clear, crisp
and natural highs
• Dual Turbine Cones: Deliver smooth and incredibly detailed
mid-range imaging
• Polk Patented X-Port: closed-pipe absorbers that are specifically
tuned to catch and eliminate traditional speaker distortions
• Anti-diffraction Magnetic Grilles: Acoustically inert grilles
offer a clean aesthetic without sacrificing sound
• Versatile Feet: Depending on your room, use carpet-friendly
feet with built-in spikes or rubber boots to maximize stability
on hard floor surfaces; each foot can be individually leveled
and adjusted
• Power Recommendation: 100W or more per channel power
amplification is recommended to experience the best quality
and performance
• Built to Last: Industry-leading, premium 5-year warranty
Turbine Cone Drivers Pinnacle Tweeters X-Port
Polk Audio is a DEI Holdings, Inc. Company. Polk Audio, Polk, are registered trademarks of Polk Audio, LLC. / The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. / Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
/ For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, Digital Surround, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries.
/ © 2020 DTS, Inc. ALL RIGHTS RESERVED. / Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. / The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Polk Audio is under license. / Other trademarks and trade names are those of their respective owners
www.polkaudio.com
Page 3
R600 Floorstanding
Loudspeaker
Beauty, value, and exceptional bass
The elegant R600 floorstanding loudspeaker delivers
powerful bass performance and sounds better than
speakers offered at twice the price.
SPECIFICATIONS
Transducer 1" Ring Radiator
Two 6 ½” Turbine Cone
Minimum Impedance 4.0Ω
Sensitivity 87.5dB SPL
Designed for R900 Yes
Frequency Response 38Hz - 38kHz
Dimensions
and Weight
Consumer Benefits
Amazing Sound and Elegance
With a slim and elegant design, the Reserve line has a minimal
elegance that will fit into any décor. Inheriting Polk’s flagship
transducer array, the R600 produces exceptional sound that rivals
competitor speakers that sell for twice the price. Hi-Res Audio
certified, the Reserve R600 is designed for today’s two-channel
music listening as well as multi-channel 3D audio found in movies,
sports, and video game soundtracks.
Dual 6.5” Turbine Cones
Polk developed the Turbine cone specifically for our flagship
products to ensure the natural reproduction of the mid-range,
to which human ears are particularly sensitive. These Turbine
cones combine Polk’s proprietary foam core and molded Turbine
geometry which dramatically increases stiffness and damping,
without adding mass. You will hear every detail and experience a
smooth, detailed mid-range and effortless bass.
(W)280.7mm x (H)1063.8mm x
(D)381.6mm
(W)11” x (H)41.9” x (D)15”
47.3Ibs/21.5kg
High Definition Pinnacle Ring Radiator Tweeter
Over 40 years of tweeter innovation, design and prototyping has
led to the development of the new 1” high definition Pinnacle
ring radiator tweeter. Developed by Polk Audio, it delivers ultraclear, crisp highs without unwanted coloration or distortions.
The Pinnacle tweeter features a finely tuned waveguide that
dramatically improves the dispersion of high frequency energy
ensuring a broad “sweet spot” while the critically damped rearchamber helps defeat any unwanted resonances.
Dual 6.5” Turbine Cones
Polk developed the Turbine cone specifically for our flagship
products to ensure the natural reproduction of the mid-range,
to which human ears are particularly sensitive. These Turbine
cones combine Polk’s proprietary foam core and molded Turbine
geometry which dramatically increases stiffness and damping,
without adding mass. You will hear every detail and experience a
smooth, detailed mid-range and effortless bass.
Power Port 2.0
Polk’s new Power Port 2.0 is the latest version of our successful
Power Port technology. In addition to Power Port’s carefully
engineered port design that smooths the flow of air as it exits
the cabinet through the port, X-Port adds a set of closed-pipe
absorbers that are specifically tuned to unwanted cabinet and
port resonances. Together, these two technologies combine to
function as Power Port 2.0 to deliver smooth, detailed audio.
Features
• Pinnacle Tweeter: The new ring radiator tweeter design
dramatically improves dispersion while delivering clear, crisp
and natural highs
• Dual Turbine Cones: 6.5” Turbine cones deliver smooth and
incredibly detailed mid-range imaging
• Power Port 2.0 (patent pending): Innovative new port design
enables effortless bass to play lower and louder than
traditionally ported speakers
• Anti-diffraction Magnetic Grilles: Acoustically inert grilles
offer a clean aesthetic without sacrificing sound
Turbine Cone Drivers Pinnacle Tweeters Power Port 2.0
Polk Audio is a DEI Holdings, Inc. Company. Polk Audio, Polk, are registered trademarks of Polk Audio, LLC. / The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. / Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
/ For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, Digital Surround, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries.
/ © 2020 DTS, Inc. ALL RIGHTS RESERVED. / Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. / The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Polk Audio is under license. / Other trademarks and trade names are those of their respective owners
www.polkaudio.com
Page 4
R700 Premium Stereo
Floorstanding Loudspeaker
Flagship-quality sound, elegant and refined
looks, true value
The R700 flagship floorstanding loudspeaker showcases
unbelievably refined elegance and sound. Features Polk’s
flagship drivers and delivers deep, effortless bass by
combining Power Port and brand new, patent-pending
X-Port technology to create Power Port 2.0..
SPECIFICATIONS
Transducer 1" Ring Radiator
6 ½” Turbine Cone
Dual 8" Woofers
Minimum Impedance 3.6Ω
High Resolution Pinnacle Ring Radiator Tweeter
Over 40 years of tweeter innovation, design and prototyping has
led to the development of the new 1” high definition Pinnacle
ring radiator tweeter featured on Polk’s flagship Legend series.
Developed by Polk Audio, it delivers ultra-clear, crisp highs
without unwanted coloration or distortions. The Pinnacle tweeter
features a finely tuned waveguide that dramatically improves
the dispersion of high frequency energy ensuring a broad “sweet
spot” while the critically damped rear-chamber helps defeat any
unwanted resonances.
Sensitivity 88dB SPL
Designed for R900 Yes
Frequency Response 38Hz - 37kHz
Dimensions and Weight
For One Speaker
(sold in pairs)
Consumer Benefits
Refined Elegance and Amazing Sound
The new R700 flagship floorstanding loudspeaker is ideal for
design-forward consumers who want their speakers to blend in
with their surroundings. With a bold, rich sound, the flagship
1” Pinnacle tweeter and 6.5” Turbine cone combine with Power
Port 2.0 to bring life to any room. Immerse yourself in your favorite
musical recordings or your weekly movie night with the new Polk
Reserve R700 flagship tower.
(W)329.3mm x (H)1185.9mm x
(D)404mm
(W)12.96” x (H)46.69” x (D)15.91”
(W)320.7mm x (H)1143.8mm x
(D)428.3mm
(W)12.6” x (H)45” x (D)16.9”
77.89Ibs/35.39kg
Power Port 2.0
Polk’s new Power Port 2.0 is the latest version of our successful
Power Port technology. In addition to Power Port’s carefully
engineered port design that smooths the flow of air as it exits
the cabinet through the port, X-Port adds a set of closed-pipe
absorbers that are specifically tuned to unwanted cabinet and
port resonances. Together, these two technologies combine to
function as Power Port 2.0 to deliver smooth, detailed audio.
Combined with dual 8” woofers you’ll get louder, cleaner bass
while minimizing turbulence and port noise.
Premium Cabinets Built for Better Performance
Polk believes cabinets should be beautiful and add nothing to the
playback. Polk Reserve cabinets, braces, and internal enclosures
are precisely engineered to minimize unwanted internal standing
waves and eliminate unwanted resonances. Laser Doppler
Vibrometer (LDV) designed, the advanced precision point to
point braced cabinets with individual enclosures mid and lowfrequency transducers combined with new Cabinet Resonance
Control (CRC) eliminate unwanted panel resonances.
Features
• Pinnacle Tweeter: The new ring radiator tweeter design
dramatically improves dispersion while delivering clear, crisp,
and natural highs
Turbine Cone Drivers Pinnacle Tweeters Power Port 2.0
Polk Audio is a DEI Holdings, Inc. Company. Polk Audio, Polk, are registered trademarks of Polk Audio, LLC. / The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. / Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
/ For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, Digital Surround, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries.
/ © 2020 DTS, Inc. ALL RIGHTS RESERVED. / Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. / The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Polk Audio is under license. / Other trademarks and trade names are those of their respective owners
www.polkaudio.com
Page 5
R900 Height Module
Easily add next generation, 3D sound to
your home theater
Designed to perfectly complement the Reserve series, this
optional height module adds exceptionally realistic sound
without the hassle of installing speakers in the ceiling. The R900
is fully compatible with all the latest next gen home theater
codecs: Dolby Atmos, DTS, DTS:X, DTS:X Virtual, Dolby Atmos
Height Virtualization Technology, IMAX Enhanced, and Auro-3D.
SPECIFICATIONS
Transducer 0.75" Ring Radiator
4” Turbine Cone Midrange
Minimum Impedance 4.2Ω
Sensitivity 85.5dB SPL
(When wall mounted)
Frequency Response 70Hz – 32kHz
(When wall mounted)
Dimensions and
Weight
Consumer Benefits
Versatile Placement
The Polk Reserve R900 height module is Dolby Atmos certified
and designed to meet DTS:X specification. With the ability to
wall mount or place on top of a compatible Reserve speaker, this
height module allows convenient flexibility. Flip the switch on the
back of the speaker to select the desired position and the speaker
will automatically adapt to the optimal performance.
New 4” Turbine Cone Midrange Driver
Using the same patented Turbine Cone as the Reserve line, this
height module is timbre matched and positioned in the array to
deliver an incredibly immersive Dolby Atmos and DTS:X experience.
(W)166mm x (H)158.3mm x (D)320mm
(W)6.5” x (H)6.2” x (D)12.6”
6.6Ibs/3kg
High Resolution Pinnacle Ring Radiator Tweeter
Over 40 years of tweeter innovation, design and prototyping has
led to the development of the new 1” high definition Pinnacle
ring radiator tweeter. Developed by Polk Audio, it delivers ultraclear, crisp highs without unwanted coloration or distortions.
The Pinnacle tweeter features a finely tuned waveguide that
dramatically improves the dispersion of high frequency energy
ensuring a broad “sweet spot” while the critically damped rearchamber helps defeat any unwanted resonances.
Vertical Transducer Array
A vertical transducer array allows flexible placement either on a
wall or placed directly on top of a compatible Reserve speaker. A
vertical dispersion pattern directs sound perfectly to the correct
area of the ceiling into the optimal listening area. You will enjoy
exceptionally realistic overhead sound in a comfortable and
convenient listening area without the hassle of installing speakers
in your ceiling.
Completely Sealed Enclosure
The R900 features a fully sealed enclosure to prevent resonances
and distortions.
Timbre Matched for Unmatched- Performance
Designed with the same driver components of the Reserve series
speakers, you can mix and match to create the ultimate home
theater set up.
Features
• Pinnacle Tweeter: The new ring radiator tweeter design
dramatically improves dispersion while delivering clear, crisp
and natural highs
• Turbine Cone: Delivers smooth and incredibly detailed mid-
range imaging
• Anti-diffraction Magnetic Grilles: Acoustically inert grilles offer
a clean aesthetic without sacrificing sound
• Supports the Latest Immersive Codecs: Delivers 3D audio found
in Dolby Atmos, Dolby Atmos height virtualization, DTS, DTS:X,
DTS Virtual:X and IMAX Enhanced soundtracks
• Flexible Placement: The R900 can be wall mounted or placed on
top of any compatible Reserve speaker
• Perfect Match: Designed and perfectly timber-matched
to beautifully complement the Polk Reserve line; add to
compatible bookshelf or tower speaker for a perfectly
immersive home theater experience.
Turbine Cone Drivers
Polk Audio is a DEI Holdings, Inc. Company. Polk Audio, Polk, are registered trademarks of Polk Audio, LLC. / The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. / Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
/ For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, Digital Surround, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries.
/ © 2020 DTS, Inc. ALL RIGHTS RESERVED. / Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. / The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Polk Audio is under license. / Other trademarks and trade names are those of their respective owners
Pinnacle Tweeters
www.polkaudio.com
Loading...
