Polk Audio Magnify MaxSR User guide

Maximum-Performance True 5.1
Home Theater Sound Bar System
www.polkaudio.com
Specifications
Drivers (4) 1˝ x 3˝ (25 x 75mm) full-range drivers,
(2) 0.75” (19mm) tweeters and (1) 1˝ (25mm) center channel driver 8˝ (200mm) ported, wireless subwoofer (1) 3˝ round driver in each SR1 wireless rear speaker
Inputs (3) built-In 4K HDMI inputs (HDCP 2.2
compliant), (1) HDMI (ARC) output, optical input for TV audio, AUX 3.5mm, Bluetooth, Google Home featuring Chromecast for audio, Ethernet (RJ45) for music streaming
Frequency Response 35Hz - 20kHz
Included in Box MagniFi MAX sound bar
Wireless Subwoofer (2) Polk SR1 wireless rear speakers Deluxe remote control (2) AAA batteries Sound bar power adapter with power cord Subwoofer power cord
6.5' (2m) high-speed HDMI cable 6' (1.8m) Optical cable 6' (1.8m) 3.5mm AUX cable (2) wall-mounting brackets (screws and
fasteners not included) Sound bar wall-mount template Literature
Wall Mountable Yes
SKU # AM8414
INTL: AM8415
UPC 747192128241
INTL: 747192128258
Warranty 1 Year Amplifiers / 3 Years Speakers
Dimensions Bar: 43"W x 2.09"H x 3.78"D
1092.4mm W x 53.1mm H x 96mm D
Sub: 12.11"W x 14.53"H x 14.62"D
307.6mm W x 369.2mm H x 371.4mm D
The Polk MagniFi MAX SR maximum-performance true 5.1 home theater sound bar system provides bigger, more dynamic surround sound than traditional sound bars—and is optimized to make movies, TV, sports and music come alive. It features patented SDA surround technology for a wider, more immersive listening experience and Polk VoiceAdjust technology for crystal clear dialogue—and it’s equipped with Polk Smart Remote technology, so it works with your TV’s remote control right out of the box. Includes a wireless subwoofer and two Polk SR1 wireless rear speakers for true surround sound—plus, HDMI (4k compatible) and optical cables for quick and easy setup. And, Google Chromecast Built-in and Bluetooth technologies let you stream all of your favorite music. Compatible with most major TV manufacturers.
Features
Patented Polk SDA Surround Technology
Creates an expansive soundstage and detailed stereo image, while delivering a natural multi-dimensional sound experience you would expect from a concert or theater by eliminating cross-talk found in all other sound bars and TV speakers.
Polk VoiceAdjust Technology
Customize the voice levels in the sound bar however you prefer to reproduce clear, crisp dialogue and never miss a single word of your favorite movie, TV show or sporting event.
Google Chromecast Built-in
Stream music from your favorite apps over Wi-Fi, connect to your Google Home speaker and control your music with voice commands via Google Assistant.
True 5.1 Wireless Surround Sound
Seven driver array, the included powerful wireless subwoofer and two Polk SR1 wireless rear speakers create an immersive multi-dimensional sound via 5.1 Dolby Digital, DTS and exclusive Polk SDA surround technology for an incredible room-filling listening experience.
Built-in Remote Control Compatibility
Control volume and mute with most Samsung, LG, Vizio, and Sony TV remotes (works with both optical HDMI connection), as well as most CEC enabled TVs – no programming or learning required.
Low-Profile
Slim design won’t block your TV’s remote sensor.
Exclusive Full Complement Deep Bass Technology
Included 8˝ ported wireless subwoofer give you a massive boost of core-pounding deep bass impact that takes home theater and music listening to a whole new level.
Movie, Music and Sport Modes
One button preset EQ settings for Movies, Music and Sports optimize the sound bar and subwoofer to ensure you get the clearest dialogue, big surround sound and deep bass for the best audio and home theater experience.
Night Mode
Lowers the bass and increases VoiceAdjust delivering clear dialogue all without raising the master volume.
