Polaroid T737 User Manual

User Guide
t737 7.0 Megapixel Digital Camera
DIGITAL QUALITY, POLAROID SIMPLICITY™
www.polaroid.com
Product Overview
1. Shutter button
2. Auto Focus Assistant LED
3. Flash
4. Function LED
5. Power LED
6. Power button
7. Speaker
8. Lens
9. Microphone
10. Zoom out / Thumbnail button
11. Mode button
12. Menu button
13. LCD Screen
14. LCD Screen On/Off button
15. Zoom in button
16. Flash LED
17. Battery LED
18. Wrist strap holder
19. S Button
20. Self-timer / Up button
21. Macro / Left button
22. Delete / Down button
23. Flash / Right button
24. Play / Pause / OK / Edit button
25. Tripod mount
26. AV / USB port
27. Battery / SD card door
2
1
2
3
4
10 11 12
13
14
20
21
22
25
26
27
Polaroid t737 Digital Camera User Guide
www.polaroid.com
23
24
Table of Contents
5 6
7
8
9
15 16 17
18
19
1 Getting Started ..........................................................................6
• Camera Package Contents .........................................................7
• Attaching the Wrist Strap ..........................................................8
• Installing the Batteries ...............................................................8
• Using Your Batteries .................................................................9
• Charging the Batteries ...............................................................9
• Checking the Battery Level ......................................................11
• Turning the Camera On and Off ...............................................11
2 Camera Settings ........................................................................12
• Checking Camera Status ........................................................12
• Capture Modes ......................................................................12
• Playback Mode .......................................................................15
• Camera Modes ....................................................................... 16
• How to Navigate Menus ..........................................................16
• Setup Menu .......................................................................... 17
• Setting Date and Time ...........................................................18
• Setting Auto Power Off ..........................................................19
• Setting the Beep Sound On / Off ..............................................20
• Adjusting Volume Control ........................................................ 20
• Setting the Display Language .................................................21
• Setting the Date Stamp On / Off .............................................22
• Adjusting the LCD Brightness ...................................................22
• Turning Sequence Number On / Off ..........................................23
• Restting to Default Settings ....................................................24
• Cancelling the Startup Image ..................................................25
• Setting Function LED .............................................................26
• Choosing the Media for Storage ...............................................28
• Turning the Information Display On/Off .....................................29
3 Taking Pictures .........................................................................31
• Taking Pictures in Normal Mode ...............................................31
Polaroid t737 Digital Camera User Guide www.polaroid.com
3
• Taking Pictures in Macro Mode ................................................33
• Taking Pictures in Different Scene Shooting Modes ....................34
• Setting Flash Mode ................................................................36
• Setting Self-timer ...................................................................38
• Taking Continuous Pictures .....................................................39
• Setting the Picture Resolution and Compression .........................40
• Setting the Sharpness ............................................................43
• Zoom Feature .......................................................................44
• Turning the Auto-Focus Assist Beam On and Off ........................46
• Specifying the Quick Review Period .........................................47
• Selecting Focus Area ..............................................................48
• Setting Exposure Compensation ...............................................49
• Setting the ISO .....................................................................50
• Setting White Balance ............................................................. 51
• Setting Shutter Speed. ............................................................52
• Setting Light Metering .............................................................53
4 Recording Video Clips ................................................................54
• Recording Video Clips ............................................................54
• Setting Video Resolution .........................................................55
• Setting Exposure Compensation for Video Clips .........................56
• Setting White Balance for Video Clips .......................................57
5 Managing Pictures and Video Clips ..............................................58
• Reviewing Pictures ................................................................58
• Reviewing Pictures and Video Clip Files in Thumbnail ................58
• Magnifying & Trimming the Displayed Picture ............................59
• Playing a Video Clip on LCD Screen ..........................................59
• Protecting/Unprotecting Pictures and Video Clips ......................60
• Running a Slide Show ............................................................. 61
• Copy to Card ........................................................................ 62
• Copy from Card ....................................................................63
• Editing Pictures .....................................................................64
• Rotating the Displayed Picture .................................................66
• Image Cropping ...................................................................... 67
• Color Enhancing the Image ......................................................68
• Red-eye Removal ....................................................................70
• Deleting Pictures or Video Clip ................................................71
4
Polaroid t737 Digital Camera User Guide
www.polaroid.com
• Viewing Pictures and Video Clips on a TV ................................73
6 Print Settings ............................................................................75
• About PictBridge ....................................................................75
• About DPOF .........................................................................83
7 Using the SD (Secure Digital) Card ..............................................85
• Using the SD Card .................................................................. 85
• Formatting a SD card .............................................................88
8 Installing the Software onto a Computer ......................................89
• Installing the Software ............................................................ 89
• Software Included with Your Camera ........................................90
• About ArcSoft Panorama Maker® 4 ...........................................92
• Computer System Requirements ...............................................96
9 Transferring Pictures and Video Clips to a Computer ......................97
• Before Transferring Files ..........................................................97
• Connecting to Your Computer ..................................................97
• Transferring Pictures and Video Clips to a Computer ...................98
10 Troubleshooting Problems ....................................................... 100
11 Getting Help ......................................................................... 103
• Polaroid Online Services ........................................................103
• ArcSoft Software Help ..........................................................103
12 Appendix .............................................................................. 104
• Technical specifications ........................................................104
• Storage Capacities ................................................................106
• Uninstalling Polaroid t737 Driver (PC only) ............................... 109
• Camera Default Settings ........................................................111
• Tips, Your Safety & Maintenance ...........................................112
• Regulatory Information ..........................................................113
Polaroid t737 Digital Camera User Guide www.polaroid.com
5
1 Getting Started
Thank you for selecting the new Polaroid t737 digital camera for your imaging needs. The t737 comes equipped with a powerful 7.0 Megapixels CCD sensor, 3.0-inch bright color LTPS TFT LCD, high quality optics and many manual settings and options.
Outstanding features that your t737 digital camera has:
• A high quality glass lens system for exposures from 4 inches to infinity including 3 times optical and 4 times digital zoom modes.
• Built-in flash with 4 modes (Auto, Red-eye Reduction, Flash on and Flash off).
• Free to edit your images and print your pictures by Pictbridge.
• Large 3.0 inch LCD screen for easier image preview and review.
• Convenient multiple shooting modes for more accurate reproduction of pictures.
• Camera Package Contents
t737
Rechargeable
Li-battery
AC Adapter
Quick Start Guide
The CD-ROM includes
Polaroid t737 Camera Driver (PC)
Arcsoft Panorama Maker® 4 (PC & Mac)
ArcSoft PhotoStudio® 5.5 (PC) / 4.3 (Mac)
ArcSoft VideoImpression® 2 (PC & Mac)
Adobe® Acrobat® Reader™ (PC & Mac)
User Guide (in PDF format)
Quick Start Guide Guide de Démarrage rapide Schnellanleitung Guida Rapida Guía Rápida de Inicio Guia de Início Rápido
ML 0403 Part no.: OM837657 R1
First Class Postage Required
Post Of ce will
not deliver
without proper
postage
Digital Imaging Products 201 Burlington Road Bedford, MA 01730-1434
Printed in China
Registration Card
Skin
Wrist Strap
Battery Charger
6
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
USB Cable
AV Cable
7
• Attaching the Wrist Strap
1
2
• Installing the Batteries
One Lithium rechargeable battery is supplied with the product. For a detailed guideline on battery usage, please see “Using Your Batteries” on page 9.
1. Open the camera battery door by pushing it outwards as illustrated.
2. Insert the batteries as shown, ensuring you follow the +/- signs
correctly.
3. Close the battery door by pressing it downwards and then sliding it
towards the camera to lock.
• Using Your Batteries
Limit the following activities that reduces battery life:
• Reviewing your pictures on the LCD screen.
• Excessive use of the flash.
WARNING!
• The battery should be replaced by an adult.
• Use recommended or equivalent type of battery only.
• Insert the battery in the correct orientation.
• Remove exhausted battery from the camera immediately.
• Do not short the supply terminals.
• Please dispose the battery properly.
• Remove battery from the camera when not in use.
These instructions should be retained for future reference.
• Charging the Battery
After purchase and before use, charge the battery for 8 hours initially and about 2.5 hours for subsequent charging.
1. Install the battery as shown, and press the battery downwards onto the charger till you hear a click sound. Make sure the battery is securely seated in the battery slot.
a
b
8
b
Polaroid t737 Digital Camera User Guide
a
b
a
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
9
• Checking the Battery Level
(POWER)
2. Connect the plug to the charger as shown and connect the adapter to the household power outlet.
Battery Charge LED in Red Charge is in progress.
Battery Charge LED in Green Charge is complete.
NOTE:
• The AC adapter will stop operation once the battery is fully charged. It is
recommended to disconnect the AC adapter from the charger when the battery charge LED turns green.
• Only use the included AC adapter with the battery charger. Otherwise,
damage may occure.
Only use the supplied Lithium Ion rechargeable battery with the camera. This rechargeable battery should last for the life of the camera, but as is the case with all rechargeable batteries the actual charge held may decline with use. Should it ever become necessary to replace the rechargeable battery, please contact your distributor or visit www.polaroid.com for
more information on replacement or backup batteries.
Check the battery power level before taking pictures.
1. Turn on the camera.
2. Check the battery power level that appears on the LCD screen.
Battery power is full.
Battery power is adequate.
Battery power is low.
Batter power is exhausted. Please
replace the battery.
• Turning the Camera On and Off
1. Press the (POWER) button to turn on
the camrea.
2. Press the
turn the power off.
(POWER) button again to
00012
10
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
11
2 Camera Settings
• Checking Camera Status
Turn on the camera, view the camera LCD screen to check which camera settings are active. Those particular features whose icons are not displayed are not activated.
• Capture Modes
Still Image Mode
22
21
20
19
18 17
1234
3
2
2
F 5.2 1/8
00012
3072X2304
5 6
7 8
9
10
11 12
13
No. Description Icon Ref. Page
5 Number of Remaining Picture 00012
6 Image Resolution 3072 X 2304 40
7 Compression
8 Sharpness
9 Internal Memory/ SD Card
10 Focus Mark
11 Shake Warning
12 Histogram
13 Current Shutter Speed 1/8
14 Battery Power Level 11
15 Optical & Digital Zoom Bar
16 Digital Zoom Factor X 1.0 ............ X 4.0 44
17 F No. F 5.2
18 Light Metering
, ,
, ,
/
41
43
45
53
16
No. Description Icon Ref. Page
1 Shooting Mode
2 Flash Mode
3 Self-timer
4 Macro Mode
12
15
, , ,
,
2, 10
Polaroid t737 Digital Camera User Guide
14
34
36
38
33
www.polaroid.com
19 Shutter Speed
20 White balance
21 ISO Sensitivity
22 Exposure Compensation Value
Polaroid t737 Digital Camera User Guide www.polaroid.com
52
51
50
49
13
Video Mode
4
1
2
640X480
5
6
• Playback Mode
1 2
10
3
4
11
3
7
No. Description Icon Ref. Page
1 Video Mode 54
2 Exposure
3 White balance
56
57
4 Record indicator
5 Recorded Time 00:00:03
6 Video Size 640 X 480 / 320 X 240 55
7 Battery Power Level
14
Polaroid t737 Digital Camera User Guide
11
www.polaroid.com
04/12/06
F 5.2 1/8
789
5
6
12
13
No. Description Icon Ref. Page
1 Playback mode
Protect 60
2
3 File Number 100-0012.JPG
4 Resolution 3072 X 2304
5
Displayed Date and time
04/12/06 12:30
6 Battery Power Level 11
Shutter Speed 1/8
7
F No. F 5.2
8
Printed Time 04/12/06
9
Video Mode
10
Play Time 00:00:53
11
Stop
12
13 Play and Pause
/
Polaroid t737 Digital Camera User Guide www.polaroid.com
04/12/06 12:30
58
15
• Camera Modes
The camera has three working modes, Capture mode, Playback mode and Video mode. Pressing the mode button switches among these modes.
• How to Navigate Menus
Mode Button
• Setup Menu
You can change the basic settings of the camera in Capture mode and Video mode.Here we take the
1. Press the
button and press the button to
enter setup menu.
2. Press the and buttons to scroll up and down through menu bars.
mode for an example.
Menus are used to select capture and play settings, as well as other camera settings like the Date/Time and Auto Power Off.
1. Press the
button to enter Menu Settings. Press the button and press the button to enter setup settings.
2. Press the and buttons to scroll up and down through menu bars.
3. Press the button to enter. Press the button to back to menu bars.
4. Press the and buttons to select options.
5. Press the button to confirm your choice.
16
Polaroid t737 Digital Camera User Guide
Menu Button
Resolution
3072 X 2304
2816 X 2112 2048 X 1536 1600 X 1200
640 X 480
Menu Settings
SETUP
Date /Time
Auto Power Off Beep Sound Volume Video System
Off On
LCD
Setup Settings
www.polaroid.com
3. Press the button to enter. Press the button to back to menu bars.
Menu button
4. Press the and buttons to select options.
5. Press the button to confirm your choice.
6. Press the button to exit the setup menu.
SETUP
Date /Time
Auto Power Off Beep Sound Volume Video System
1/3
Off On
LCD
1/3
Polaroid t737 Digital Camera User Guide www.polaroid.com
Date /Time
.
2006.12.04
12:00:00 YY.MM.DD
17
• Setting the Date and Time
1. Access the setup menu.
2. Press or button to select (DATE / TIME).
3. Press the
4. Press the or button to select a field, such year, month, day, hour, minute, and date format.
5. Press or button to adjust the value in the field and select the date format.
button to enter.
Date /Time
Auto Power Off Beep Sound Volume Video System
2006.12.04
12:00:00 YY/MM/DD
Date /Time
.
SETUP
Off On
LCD
• Setting Auto Power Off
The camera performs the following power save operation to conserve battery power.
1. Access the setup menu.
2. Press the or button to select (Auto
1/3
Power Off).
3. Press the
button to enter.
Date /Time
Auto Power Off
Beep Sound Volume Video System
4. Press or to select the desired setting.
SETUP
Off
On
LCD
1/3
Auto Power Off
Off 1 MIN 3 MIN
6. Press the button to confirm your choice.
NOTE:
• This setting is also available in (Video) mode.
18
Polaroid t737 Digital Camera User Guide
www.polaroid.com
5. Press the button to confirm your choice.
1 MINUTE / 3 MINUTES The camera is designed to switch off
automatically to save battery life after the specified period of inactivity.
OFF The power saving function is not active.
NOTE:
Auto power off is automatically disabled under any one of the following conditions:
While the camera is recording a video clip.
While the camera is running a slide show.
Polaroid t737 Digital Camera User Guide
19
www.polaroid.com
• Setting the Beep Sound On / Off
The beep sound can be turned on and off in the SETUP menu. When the beep sound is turned on, the camera will beep when you press any of the buttons.
1. Access the setup menu.
2. Press the
or button to select (Beep
Sound).
3. Press the button to enter.
4. Press the or button to select the desired setting.
Date /Time Auto Power Off
Beep Sound
Volume Video System
SETUP
Off
On
LCD
1/3
Beep Sound
Off
On
5. Press the button to confirm your choice.
• Adjusting Volume Control
Volume can be adjusted for beep sounds and video clips.
SETUP
1. Access the setup menu.
2. Press the
or button to select (Volume).
3. Press the button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Date /Time Auto Power Off Beep Sound
Volume
Video System
Off On
LCD
1/3
Volume
• Setting the Display Language
Under this setting, you can select the language you prefer for the LCD screen.
1. Access the setup menu.
2. Press the or button to select (LANGUAGE).
3. Press the button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Language
Date Stamp LCD Brightness Format Sequence No.
English
Deutsch Français Español Italiano
SETUP
English
12/3/06
Internal Memory
Off
2/3
Language
1/2
Language
Português
日本语
简体中文
2/2
20
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
21
• Setting the Date Stamp On / Off
Use the date stamp setting to imprint the date on your pictures. Make sure the date is correct before setting the date stamp on.
1. Access the setup menu.
2. Press the or button to select (Date Stamp).
3. Press the button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Language
Date Stamp
LCD Brightness Format Sequence No.
SETUP
English
12/3/06
Internal Memory
Off
2/3
Date Stamp
Date Time
Date
Off
• Turning Sequence Number On / Off
The instructions below shows how to select the way file numbers are assigned.
1. Access the setup menu.
2. Press the or to select ICON (Sequence No.).
3. Press the
button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Language Date Stamp LCD Brightness Format
Sequence No.
SETUP
English
12/3/06
Internal Memory
Off
2/3
Sequence No.
Off
On
• Adjusting the LCD Brightness
This setting enables you to adjust the brightness for the LCD screen.
1. Access the setup menu.
2. Press the or to select ICON (LCD Brightness).
3. Press the
button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
22
Polaroid t737 Digital Camera User Guide
Language Date Stamp
LCD Brightness
Format Sequence No.
Internal Memory
.
LCD Brightness
www.polaroid.com
SETUP
English
12/3/06
Off
ON The file numbers are reassigned to the start each time when any images are
removed from the memory card or internal memory is formatted. New images recorded on the memory card with existing files are given the next available number.
OFF A file number is assigned to a recorded image and memorized and images
recorded onto a memory card start from the next number.
2/3
Polaroid t737 Digital Camera User Guide
23
www.polaroid.com
• Restting to Default Settings
Default setting can be restored by the following steps (For more guidelines, please see “Camera Default Settings” on page 110).
1. Access the setup menu.
2. Press the or to select ICON (Default Settings).
3. Press the
button to enter.
Default Setting
Opening Front LED Setting Storage Media
4. Press the or button to select the desired setting.
Return Menu Setting
To Defaults?
5. Press the button to confirm your choice.
NOTE:
Selecting CANCEL will cancel the operation and exit from the menu window.
SETUP
On
Auto
Default Setting
Cancel
OK
• Canceling the Startup Image
A startup animation image appears on the LCD screen for a few econds when the camera is turned on.
You may cancel displaying the startup image according to the following steps:
3/3
1. Access the setup menu.
2. Press the
or to select ICON
(Opening).
3. Press the
button to enter.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Default Setting
Opening
Front LED Setting Storage Media
SETUP
On
Auto
3/3
Opening
Off
On
24
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
25
• Setting Function LED
1. Access the setup menu.
2. Press the or to select ICON (Front LED Setting).
3. Press the
4. Press the or button to select the desired setting.
button to enter.
Default Setting Opening
Front LED Setting
Storage Media
SETUP
On
Auto
Self-Timer
Front LED
5. Press the or to select Self-Timer.
Power On/Off
Self-Timer
6. Press the button to enter.
3/3
7. Press the or button to select the desired setting.
8. Press the button to confirm your choice.
LED Self-Timer
Off
On
Power On and Off
5. Press the or to select Power On/Off.
6. Press the button to enter.
7. Press the or button to select the desired setting.
8. Press the button to confirm your choice.
26
Polaroid t737 Digital Camera User Guide
Front LED
Power On/Off
Self-Timer
Power On/Off
Off
On
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
27
• Choosing the Media for Storage
You can choose your preferred media for images or video clips storage.
1. Access the setup menu.
2. Press the or to select ICON (Storage Media).
Default Setting Opening Front LED Setting
Storage Media
SETUP
On
Auto
• Turning the Information Display On/Off
Press the button each time switches the LCD screen to the next display mode in the following mode.
3. Press the
button to enter.
4. Press the or button to select the desired setting.
Storage Media
Auto
Int. Memory
SD Card
3/3
5. Press the button to confirm your choice.
Auto The images or video clips will be stored in your
camera automatically.
Int. Memory The images or video clips will be stored in internal
memory first.
SD Card The images or video clips will be stored in SD card
first.
28
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Still Image Mode
00012
Press Press
F 5.2 1/8
Polaroid t737 Digital Camera User Guide www.polaroid.com
LCD Screen On/Off Button
00012
Press
29
Video Mode
3 Taking Pictures
Playback Mode
100-0013.AVI
Press
Press
Press Press
Press Press
F 5.2 1/8
Press
100-0013.AVI
Press
Press
640X480
Before you take pictures, please read this note fi rst:
NOTE:
Never remove the batteries while a picture is being saved. Doing so will prevent the current picture from being saved and may corrupt other pictures already stored on the camera’s internal memory or a memory card.
• Taking Pictures in Normal Mode
You can take pictures at approximately 20 inches to infinity (50 cm to infinity).
NOTE:
Most settings are saved by the camera when the power is turned off so that the same setting is automatically available when the power is turned on again. Make sure you verify your settings when turning the camera on again.
1. Press the button to set the camera to Still Image mode.
2. Frame your subject using the LCD screen.
3. Press the Shutter button halfway to set the exposure and focus. The camera automatically detects the subject. The camera highlights the focus mark in green, indicating the camera focus is locked on the subject.
00012
3072 X 2304
Focus mark
30
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Shutter speed
Polaroid t737 Digital Camera User Guide www.polaroid.com
31
NOTE:
(Still Image) mode is the capture mode by default.
• When the camera’s focus mark are in red, there is difficulty in focusing the subject. Release the Shutter button, recompose the scene and press the Shutter button halfway to reset the focus.
• The LCD screen will show you the aperture value and shutter speed at which you take the picture.
• If the shutter speed is slow or that the image maybe blurred, the shake warning icon use of a tripod is recommended.
may appear on the LCD screen. To avoid this situation, the
4. Hold the camera steady and slowly press the shutter button down to take your image.
• Taking Pictures in Macro Mode
Use this mode to capture subjects close to the lens:
Wide Angle: 0.33 ~ 1.64 ft (10 cm ~ 0.5 m) Telephoto: 0.33 ~ 1.64 ft (10 cm ~ 0.5 m)
1. Press the button to set the camera to Still Image mode.
2. Press the button and the on the LCD screen.
3. Capture procedures are the same as for taking a picture in the normal capture mode. See page 31.
icon appears
Macro Button
00012
3072 X 2304
32
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
33
• Taking Pictures in Different Scene Shooting Modes
Select a mode that is suitable to your shooting conditions:
1. Press the button to set the camera to Still Image mode.
Night Portrait Used for many subjects in picture with background out of focus
Sunset Used for sunset scene
Children Used for brightly lit scenes when children are moving
2. Press the
button.
3. Press the or button to select the desired setting.
4. Press the button.
5. Capture procedures are the same as for taking a picture in the normal capture mode.
Display Option Description
Automatic
Maunal Allows your to manually setup your camera’s settings
Face Tracking Used for outlining faces in your picture
Landscape Used for taking scenic pictures
Portrait Used for one person picture with background out of focus
Sport Used at sporting events to capture subjects moving
Night Landscape Used for taking long distant subjects at night
Use this setting for most scenes - the camera decides the camera settings
S Button
Automatic
For general picture-taking.
Automatically set parameters for the scene
Pet Used for taking pictures of pets
Collection Used for taking pictures of paintings in Macro mode without fl ash
Flower Used to take close-up pictures of fl owers
Food Used to take pictures of food with increased color
Fireworks Used to pictures of fi reworks
Party Used for taking indoor pictures of many people
Snow & Beach Used for taking pictures for snow and beach scenes
Autumn Used for taking pictures in the autumn season
Water Used for taking pictures of moving water in bright light
Splashing Water Used for taking pictures of splashing water in bright light
Text
Panorama Used for taking panorama pictures from left to right
Sepia Used for taking pictures to produce an antique (brownish) look
B&W Used for taking black-and-white pictures
Vivid
Used for taking pictures of black and white text with increased contrast
Used for taking pictures to produce increased contrast and color saturatio
34
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
35
Neutral Used for taking pictures for a neutral scene
Red Filterd Used for taking pictures to produce a reddish picture
The camera has four flash modes (default setting is Auto Flash). Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows.
Green Filterd Used for taking pictures to produce a greenish picture
Blue Filterd Used for taking pictures to produce a bluish picture
• Setting Flash Mode
Flash Range: Normal: Wide Angle: 1.64 ~ 6 ft (50 cm ~ 1.8 m) Telephoto: 1.64 ~ 3.3 ft (50 cm ~ 1 m) Marco: 0.33 ~ 1.64 ft (0.1 m ~ 0.5 m)
1. Press the
2. Press the button to cycle through the flash settings and select the
one you need. The icon (according to the flash setting you selected) will appear on the LCD screen.
button to set the camera to Still Image mode.
00012
Flash Button
Display Option Description
A
Auto fl ash
Flash Off
Flash Always On
Red-eye Reduction
The fl ash fi res automatically as needed. Use this setting to take most pictures.
The fl ash does not fi re. Use this setting for outdoor pictures or where fl ash is prohibited or may be distracting. Also use when shooting toward a refl ective surface, such as a window or mirror. If you do not have enough light when using this setting, your pictures will be too dark.
The fl ash fi res for every picture. Use this setting in high-contrast situations to provide fi ll-light or use it indoors in low light.
The fl ash fi res a few times before taking your picture to reduce the red-eye phenomenon.
NOTE:
• Flash modes are only used in still image shooting.
• Never touch or block the fl ash with your fi ngers.
36
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
37
• Setting Self-timer
Your camera is designed with a self timer function which will allow you to take pictures with a count down of 2 or 10 seconds.
• Taking Continuous Pictures
Continuous pictures mode lets you continuously take pictures untill the current memory is full.
1. Press the
button to set the camera to Still Image mode.
2. Press the button to select self-timer.
00012
Self-timer Button
Display Option Description
Off Record a single image
2-SEC Take a picture after a count down of 2 seconds
10-SEC Take a picture after a count down of 10 seconds
Continuous
Press the shutter button all along, the camrea will take photos automatically
3. Capture procedures are the same as for taking a picture in the normal
capture mode. See page 31.
NOTE:
• This feature is only available in Still Image mode.
• Place the camera on a fl at surface or use a tripod when using the self-timer function
1. Press the button until you see
2. Select
and press the button.
icon.
3. Press the shutter button all along, the camrea will take photos automatically.
NOTE:
• The flash is automatically disabled in the
(Continuous) mode.
00012
38
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
39
• Setting the Picture Resolution and Compression
Picture resolution refers to the number of pixels in a digital picture. Picture quality depends on the JPEG file compression that the camera applies when the picture is taken. Higher resolution and less compression makes better quality and occupies more memory space. Smaller size and normal quality pictures are easier to email while larger size and fine quality pictures are better for printing.
Resolution setting
1. Press the
button to set the camera
to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select
4. Press the
button to enter.
(Resolution).
5. Press the or button to select the desired setting.
6. Press the button to confirm your choice.
Resolution
Compression Sharpness Digital Zoom AF-Assist Beam
3072×2304
2816×2112 2048×1536 1600×1200
STILL
3072×2304
Super Fine
Soft
On Off
1/2
Resolution
640×480
Compression setting
1. Press the button to set the camera to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select
ICON
(Compression).
4. Press the
button to enter.
5. Press the or button to select the desired
setting.
6. Press the button to confirm your
choice.
Resolution
Compression
Sharpness Digital Zoom AF-Assist Beam
Super Fine
Normal
STILL
3072×2304
Super Fine
Soft
On Off
1/2
Compression
Fine
40
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
41
The chart below indicates the approximate numbers of pictures you can expect the camera to hold at different resolution and quality setting based on the 11MB memory card. You can expand the memory using a commercially available memory card. Please refer to “Capacity of SD Card” on page 106 for further details.
Compression
Resolution
3072 X 2304 9 25 34
2816 X 2112 11 28 42
2048 X 1536 20 54 78
1600 X 1200 32 88 127
640 X 480 173 502 701
Super Fine
Fine
Normal
NOTE:
Scene complexity affects a picture’s fi le size. For example, a picture of trees in autumn has a larger fi le size than pictures of blue sky at the same resolution and quality setting. Therefore, the number of picture or the length of video clips you can store on a memory card may vary. The number of pictures on the LCD screen is for reference only.
• Setting the Sharpness
Use the sharpness setting to highlight or blend the edges of subjects in pictures.
1. Press the button to set the camera to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select
ICON
Resolution Compression
Sharpness
Digital Zoom AF-Assist Beam
(Sharpness).
4. Press the
button to enter.
5. Press the or button to select the desired
setting.
6. Press the button to confirm your
choice.
STRONG Increases contrast on the edge of the picture. Image color noise
may occur in the recording image.
NORMAL The edges of the image are sharp, this is suitable for printing.
SOFT Softens the edge of the picture, creating a “soft focus”
effect.
STILL
3072×2304 Super Fine
Soft
On Off
1/2
Sharpness
Strong
Normal
Soft
42
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
43
• Zoom Feature
There are two types of zoom in this camera: optical zoom and digital zoom. Optical zoom alters the focal distance , and its factor range is 1X to 3X. Digital zoom is activated after you reach the maximum optical zoom (3X). It enlarges the part of the image at the centre of the image screen. Digital zoom factor range is 1X to 4X. These zoom features let you zoom in the central area of an image and photograph only the enlarged portion of the picture.
NOTE:
• Using the digital zoom may cause a decrease in image quality.
Turn Digital Zoom On/Off
1. Press the button to set the camera to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select
ICON (Digital
Zoom).
Resolution Compression Sharpness
Digital Zoom
AF-Assist Beam
STILL
3072×2304
Super Fine
Soft
On
Off
1/2
To Zoom In and Out
1. Set the camera to Still Image mode.
2. Press the to zoom in the subject, or press the button to return to original zoom status. While you press the or button, a red square will show on the zoom status bar as illustrated. The yellow square in the bar indicates the zoom status. “T” stands for “Tele” and “W” stands for “Wide”. Keep the button pressed, and the camera switches from optical zoom to digital zoom when it reaches the maximum optical zoom.
3. Now you can takes pictures and review them under the zoom setting you just made. The zoom setting will remain after pictures are taken.
If you want to take a normal size picture, please use the button.
Zoom W Button
(Thumbnail)
T Button
Zoom
(Digital zoom)
Digital zoom status
00012
4. Press the
button to enter.
5. Press the or button to select the desired setting.
6. Press the button to confirm your choice.
44
Polaroid t737 Digital Camera User Guide
Digital
Off
On
www.polaroid.com
Optical Zoom
Digital Zoom
Yellow Square
NOTE:
Zoom feature is available in mode.
Using the digital zoom may cause a decrease in image quality.
Polaroid t737 Digital Camera User Guide www.polaroid.com
45
• Turning the Auto-Focus Assist Beam On and Off
Under this setting, you can turn the Auto-Focus assist beam on or off. When it is turned on, the focus assistant lamp gives out a strong beam and helps the camera easily focus on the subject.
1. Press the
to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select Assist Beam).
4. Press the
5. Press the or button to select the desired setting.
6. Press the button to confirm your choice.
button to set the camera
button to enter.
ICON (AF-
Resolution Compression Sharpness Digital Zoom
AF-Assist Beam
STILL
3072×2304 Super Fine
Soft
On
Off
1/2
AF-Assist Beam
Off
On
• Specifying the Quick Review Period
A quick review of pictures is available to set with options of 2 seconds and 5 seconds. Below shows how to change the option.
1. Press the button to set the camera to Still Image mode.
2. Press the button to enter menu bar.
3. Press the or to select
ICON (Quick
Review).
4. Press the
button to enter.
5. Press the or button to select the desired
setting.
6. Press the button to confirm your
choice.
Quick Review
Focus Area
2 Seconds
5 Seconds
STILL
Off
Single AF
2/2
Quick Review
Off
46
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
47
• Selecting Focus Area
1. Press the button to set the camera to Still Image mode.
2. Press the button to enter menu bar.
Quick Review
Focus Area
STILL
Off
Single AF
• Setting Exposure Compensation
You can adjust the exposure compensation value (EV) within the range of -2EV to +2EV in order to compensate for current lighting conditions. This setting can be used to obtain better result when shooting with backlighting, indirect indoor lighting, a dark background, and so on.
3. Press the or to select
Area).
4. Press the
button to enter.
5. Press the or button to select the desired
ICON (Focus
2/2
Focus Area
Single AF
3-Point AF
setting.
6. Press the button to confirm your
choice.
SINGLE AF The camera uses the middle AF window to automatically
set the focus. When the shutter button is pressed halfway, the camera starts focusing until it “locks” onto you subject. Keep your subject centered on the LCD display. When the best focus position has been selected, a green graphic will be displayed on the LCD screen.
3-POINTS AF The camera uses three AF windows (left, center and right)
to automatically set the focus. When the shutter button is pressed halfway, the camera starts focusing until it “locks” onto your subject. When the best focus position has been selected, a green graphic will be displayed on the LCD screen.
1. Press the button to set the camera
Exposure
to Still Image mode.
2. Press the button.
3. Current option is
“EXPOSURE”.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
NOTE:
• A higher EV value is used for light-colored and backlit subjects. A lower EV value
is better for dark-colored and shooting outdoors on a clear day.
• When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even if performing exposure compensation.
48
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
49
• Setting the ISO
This function enables you to change the camera’s sensitivity to light by selecting the different ISO values. ISO is a measure of how quickly your camera reacts to light. The higher the ISO value, the less light the camera needs to make an exposure, allowing the same exposure to be achieved with higher shutter speeds or smaller apertures. In a digital camera, higher ISO value allows higher shutter speed, at the expense of mottled or grain appearing in the final picture.
1. Press the Still Image mode.
2. Press S button to set the camera to Manual Mode (see P34). Press the confirm.
3. Press the
4. Press the
5. Press the or button to select the desired setting.
6. Press the
AUTO The camera’s sensitivity is automatically changed by
80/100/200/400 In the same lighting condition, the higher the ISO value
NOTE:
• Higher ISO speeds increase the image noise. To get better images, use as low
as ISO speed as possible.
button to set the camera to
button to
button once again.
or button to select “ISO”.
button to confirm your choice.
different lighting value or subject brightness.
is, the faster the shutter speed will be.
S Button
ISO
• Setting White Balance
Selecting the right type of white balance can help to make the color of a subject appear more natural under the type of lighting that is available.
1. Press the Still Image mode.
2. Press the button.
3. Press the or button to select BALANCE”.
4. Press the or button to select the desired setting.
5. Press the button to confirm your choice.
Option Description
NOTE:
This setting is also available in (Video) mode.
button to set the camera to
White Balance
“WHITE
Auto
Automatic adjustment. Use this for most picture taking scenes.
Outdoor sunny day
Clody
Outdoors, shade of a building or partly cloudy / some sun during the day
Indoors, illuminated by light bulbs
Indoors, illuminated by incandescent lighting
Neutral standard fl uorescent
Indoors, illuminated by cool white fl uorescent lighting
50
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
51
• Setting Shutter Speed
1. Press the button to set the camera to Still Image mode.
2. Press S button to set the camera to Manual Mode (see P34). Press the confirm.
button to
Shutter Speed
• Setting Light Metering
Use the light metering setting to ensure that the proper amount of light enters into the camera lens.
1. Press the Still Image mode.
2. Press the button.
button to set the camera to
Light Metering
3. Press the button once again.
4. Press the or button to select (Shutter Speed).
5. Press the
or button to select the
desired setting.
6. Press the button to confirm your choice.
52
Polaroid t737 Digital Camera User Guide
www.polaroid.com
3. Press the or button to select (Light Metering).
4. Press the
or button to select the desired
setting.
5. Press the button to confirm your choice.
Option Description
Evaluates the lighting conditions throughout the picture to give an optimum picture exposure. Ideal for general picture taking.
Evaluates the lighting conditions of the subject centered on the LCD screen. Ideal for backlit subjects.
Similar to Center, except the metering is concentrated on a smaller area of the subject centered on the LCD. Ideal when an exact exposure of a specifi c area in the picture is needed.
Polaroid t737 Digital Camera User Guide www.polaroid.com
Average
53
4 Recording Video Clips
• Recording Video Clips
Use the Video mode to record video clips with audio. The remaining time that can be recorded will decrease in seconds while recording.
1. Press the
button to set the camera to (Video mode).
• Setting Video Resolution
Video resolution refers to the number of pixels in a digital video clip. Video clip quality depends on the file resolution that the camera applies when the video clip is recorded. Higher resolution makes better quality while occupying more memory space.
1. Press the button to set the camera to (Video mode).
Resolution
VIDEO
640X480
NOTE:
The icon will appear on the LCD screen, indicating the Video mode is activated.
2. Frame your subject using the LCD screen.
3. Press the Shutter button to start recording.
4. Press the Shutter button again to stop recording, or recording stops when the current memory is full.
5. Press the or button to zoom in or out the subject.
NOTE:
Digital zoom feature is not available in (Video) mode.
54
Polaroid t737 Digital Camera User Guide
00:00:53 640X480
www.polaroid.com
2. Press the button.
3. Press the button to select (Resolution).
4. Press the button to enter.
Resolution
640X480
320X240
5. Press the and button to select the desired setting.
6. Press the button.
Here are the approximate length of video clips you can expect the camera to hold at each setting based on the 16MB memory card. You can expand the memory with a commercially available memory card. Please refer to “Capacity of SD Card” on page 90 for further details.
Resolution: 640 X 480 Approx. 0.35 minute (30 fps) 320 X 240 Approx. 0.8 minutes (30 fps)
NOTE:
is the default value, suitable for viewing on TV. is suitable for viewing on PC.
Polaroid t737 Digital Camera User Guide www.polaroid.com
55
• Setting Exposure Compensation for Video Clips
You can adjust the exposure compensation value (EV) within the range of –2EV to +2EV in order to compensate for current lighting conditions. This setting can be used to obtain better result when shooting with backlighting, indirect indoor lighting, a dark background, and so on.
1. Press the (Video mode).
2. Press the button.
3. Current option is
button to set the camera to
(Exposure).
Exposure
• Setting White Balance for Video Clips
Selecting the right type of white balance can help to make the color of a subject in the video clip appear more natural under the type of lighting that is available.
1. Press the to
(Video mode).
2. Press the
button to set the camera
button.
3. Press the and button to select (White Balance).
Exposure
White Balance
4. Press the or button to select the desired setting.
5. Press the
button.
NOTE:
A higher EV is best used for light-colored subjects and backlit subjects. A lower EV is best for dark-colored subjects and for shooting outdoors on a clear day.
When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even if performing exposure compensation.
56
Polaroid t737 Digital Camera User Guide
www.polaroid.com
4. Press the or button to select the desired setting.
5. Press the button.
Option Description
Automatic adjustment. Use this for most picture taking scenes.
Outdoor sunny day
Cloudy
Cloudy outdoors, shade of a building or partly cloudy / some sun during the day
Indoors, illuminated by light bulbs
Indoors, illuminated by incandescent lighting
Neutral standard fl uorescent
Indoors, illuminated by cool white fl uorescent lighting
Polaroid t737 Digital Camera User Guide www.polaroid.com
Auto
57
5 Managing Pictures and Video Clips
NOTE:
The camera automatically saves the image as a new fi le after rotating, resizing and adding a voice memo to it. Make sure there is suffi cient memory before editing an image.
• Reviewing Pictures
1. Press the button to set the camera to Playback mode.
• Magnifying & Trimming the Displayed Picture
4.0X
1. Press the button to set the camera to Playback mode.
2. Use the or buttons to select a picture.
3. Press to magnify the select picture.
4. Press the , , or button to move around the magnified
picture.
5. Press the button to view the picture in the original size.
2. Use the
and buttons to view the pictures
taken.
• Reviewing Pictures and Video Clip Files in Thumbnail
You can view up to 9 picture and video clip files at a time on the LCD screen by using the thumbnail function.
1. Press the button to set the camera to Playback mode.
2. Press the button and up to 9 thumbnail
files appear on the LCD screen .
3. Press the , , or button to select a
thumbnail file.
4. Press the or button to view the file in
full screen.
58
Polaroid t737 Digital Camera User Guide
1
4
7
3
2
6
5
9
8
4/9
www.polaroid.com
6. Press the button to set the image trimming.
7. Press the button again to trim the selected image and save it as a new one.
• Playing a Video Clip on LCD Screen
1. Press the button to set the camera to Playback mode.
2. Press the and buttons to select the desired video clip.
3. Press the button to start playing the video clip.
4. Press the button again to pause.
5. Press the button to stop the video clip.
100-0012.JPG 100-0013.AVI
Polaroid t737 Digital Camera User Guide www.polaroid.com
59
• Protecting/Unprotecting Pictures and Video Clips
1. Press the button to set the camera to Playback mode.
2. Press
3. Press the
button.
or button to select
“PROTECT”.
4. Press the button to enter.
5. Press the or button to select the desired setting.
6. Press the button.
Protect
Slide Show Copy To Card Copy From Card
PLAYBACK
2 SEC
Protect
Off
On
• Running a Slide Show
The slide show function enables you to view all picture and video clip files stored in the current memory repeatedly one by one on the LCD screen.
1. Press the Playback mode.
to
2. Press
button.
3. Press the or button to select
button to set the camera
“Slide
Show”.
4. Press the
button to enter.
5. Press the or button to select the
desired setting.
6. Press the
button.
Protect
Slide Show
Copy To Card Copy From Card
PLAYBACK
2 SEC
Slide Show
2 SEC
5 SEC 8 SEC
OFF To remove protection from the selected protected file. The
icon will disappear from the LCD screen.
ON To protect the selected file. The icon will appear on the
LCD screen.
60
Polaroid t737 Digital Camera User Guide
www.polaroid.com
The slide show will automatically run from the currently displayed picture after you press the button. Press the
button to stop the slide
show.
2 ,5, 8 SECONDS Every picture will continually exist on the LED at
an interval of 2,5,8 seconds.
NOTE:
The slide show will keep running as long as there is power. We
recommend the use of AC power for an extended period use.
Polaroid t737 Digital Camera User Guide www.polaroid.com
61
• Copy to Card
This setting allows you to copy pictures and video clips stored in the internal memory to a memory card.
• Copy From Card
This setting allows you to copy pictures and video clips stored in the memory card to internal memory.
1. Insert an SD card into the camera.
2. Turn on the camera.
Set the camera’s storage
media to internal memory (see P28) .
3. Press the button to set the camera to
Playback mode.
4. Press
5. Press the
button.
or button to select “Copy To
Card”.
6. Press the
button to enter.
Protect Slide Show
Copy To Card
Copy From Card
PLAYBACK
2 SEC
Copy To Card
This Image
All Images
7. Press the or button to select the desired setting.
8. Press the
button.
THIS IMAGE Copy the selected picture or video clip. Please select the
picture or video you want to copy before pressing the
button.
ALL IMAGE Copy all pictures and video clips stored in the current
memory.
1. Insert an SD card into the camera.
2. Turn on the camera.
3. Press the to
Playback mode.
4. Press
button.
button to set the camera
5. Press the or button to select
Protect Slide Show
Copy To Card
Copy From Card
“Copy
PLAYBACK
2 SEC
Copy From Card
This Image
All Images
From Card”.
6. Press the button to enter.
7. Press the or button to select the desired setting.
8. Press the
button.
THIS IMAGE Copy the selected picture or video clip. Please select the
picture or video you want to copy before pressing the
button.
ALL IMAGE Copy all pictures and video clips stored in the current
memory.
62
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
63
• Editing Pictures
The editing pictures function enables you to edit all pictures stored in the current memory one by one on the LCD screen.
1. Press the
2. Press the
or button to select one picture you want to manage.
3. Press the button.
button to set the camera to Playback mode.
Rotate
8. Select
icon and press the button to save the changed picture
to a new file in internal memory.
Save As
Save As
Save The Image To...?
Cancel
OK
4. Use
or button to select different
editing functions.
Rotating Fuction
Cropping Function
Enhancing Function
Red-eye Removal Function
5. Press or button to select icon and press the
button to save the changed picture. The picture will replace the original file.
6. Press the or
button to select the
desired setting.
7. Press the button.
64
Polaroid t737 Digital Camera User Guide
Save
Save
Save The Image?
Cancel
OK
www.polaroid.com
9. Select icon and press the button.A confirm information window will be shown on LCD screen if original file was changed. Otherwise, system will go back to up menu without editing.
Exit Exit
Save
Save As
Exit
Cancel
SAVE The edited picture will be saved in memory and replace the
original file.
SAVE AS A new picture will be created and saved onto the internal
memory or SD Card.
EXIT The original picture will be reserved without any editing.
Polaroid t737 Digital Camera User Guide www.polaroid.com
65
• Rotating the Displayed Picture
The currently displayed picture can be rotated for a better review angle on the LCD screen.
1. Press the
2. Press the
or button to select one picture you want to manage.
3. Press the button.
4. Current option is
button to set the camera to Playback mode.
(ROTATE).
• Image Cropping
1. Press the button to set the camera
Playback mode.
to
2. Press the picture you want to manage.
3. Press the button.
4. Press the (Crop).
or button to select one
or button to select
Crop
5. Press the
6. Press the
button.
or button to select the desired setting.
7. Press the button.
Rotate
Return
NOTE:
• The original fi le may be retrieved by selecting the icon on the function bar and press the
• A new fi le will be created and saved onto the memory card by selecting the
icon on the function bar and press the button.
66
button.
Polaroid t737 Digital Camera User Guide
www.polaroid.com
5. Press the
6. Use the , , the rectangle around. Use the or
button.
or buttons to move
Zoom
button to zoom in or out the rectangle.
7. Press the button.
8. Press the
or button to select the
desired setting.
9. Press the
button.
Crop This Image to...?
Cancel
OK
Zoom
NOTE:
• The original fi le may be retrieved by selecting the icon on the function bar and press the button.
• A new fi le will be created and saved onto the memory card by selecting the
icon on the function bar and press the button.
Polaroid t737 Digital Camera User Guide www.polaroid.com
Move
Move
67
• Color Enhancing the Image
1. Press the button to set the camera Playback mode.
to
Color Enhance
Option 3 Level enhancement. To enhance per channel contrast
maximizes the tonal range in each channel to produce a more dramatic correction.
2. Press the
or button to select one
picture you want to manage.
3. Press the
4. Press the
button.
or button to select (Color
Enhance).
5. Press the
button.
Return
Option 1
6. Press the or button to select the
desired setting.
7. Press the button.
Option 1 Color enhancement. To find the average lightest and darkest
pixels in an image and uses them to maximize contrast while minimizing clipping.
Option 2 Contrast enhancement. To enhance monochromatic contrast
clips all channels identically. This preserves the overall color relationship while making highlights appear lighter and shadows darker.
NOTE:
• The original fi le may be retrieved by selecting the icon on the function bar and press the button.
• A new fi le will be created and saved onto the memory card by selecting the
icon on the function bar and press the button.
68
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
69
• Red-eye Removal
Under this setting, red-eye glare in your subject’s eyes may be removed from the image.
1. Press the
2. Press the or button to select one picture you want to manage.
3. Press the button.
4. Press the or button to select eye Removal).
5. Press the button.
NOTE:
• The original fi le may be retrieved by selecting the icon on the function bar and press the button.
• A new fi le will be created and saved onto the memory card by selecting the
icon on the function bar and press the button.
button to set the camera to Playback mode.
Red Eye Remove
(Red-
Return
• Deleting Pictures or Video Clip
1. Press the button to set the camera to Playback mode.
Deleting a Single Picture or Video Clip
2. Press the or button to select the picture or
video clip you want to delete.
3. Press the
4. Press the or button to select the desired
setting.
5. Press the button.
6. Press the or button to select the desired
setting.
7. Press the button to confirm your choice.
button.
This Image
All
Erase This ?
Cancel
OK
70
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
71
Deleting All Pictures and Video Clips
2. Press the
button.
3. Press the or button to select “All”.
This Image
All
• Viewing Pictures and Video Clips on a TV
To set the video output system:
The video output signal (NTSC or PAL) can be switched to accommodate different signal systems. For example, NTSC for U.S.A., Canada, Taiwan, Japan, etc. and PAL for Europe, Asia (excluding Taiwan), etc.
4. Press the button.
5. Press the button.
6. Press the or button to select the desired
Erase All Images & Videos ?
Cancel
OK
setting.
7. Press the button to confirm your choice.
SINGLE Delete a selected unprotected option.
ALL Delete all the unprotected files in the current memory.
NOTE:
• Protected les cannot be deleted. Remove protection before
deleting.
• All deleted pictures and video clips cannot be recovered.
You can change the video output system according to the following steps:
SETUP
1. Access the setup menu.
2. Press the or button to select
(Video
System).
3. Press the
button to enter.
4. Press the or button to select the desired
setting.
Date /Time Auto Power Off Beep Sound Volume
Video System
Off On
LCD
1/3
Video System
LCD
NTSC PAL
5. Press the button to confirm your choice.
6. Press the button to exit the menu.
Video System
Please Connect To TV Before Confi rm
Cancel
OK
72
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
73
Connecting to a TV
When the camera is connected to a TV, the LCD screen is not active and the TV screen now performs as the LCD screen.
1. Connect the camera to a TV via the video cable (supplied yellow cable for video and white cable for audio) as illustrated.
2. Select the correct video system.
6 Print Settings
• About PictBridge
PictBridge is a new industry standard that allows you to print images directly from a PictBridge enable digital still camera to a PictBridge compatible printer without using a photo editing software or a computer.
Printing Procedures
1. Preparing the camera and the printer.
Camera Be sure battery level is full before printing.
Printer Refer to the user guide that comes with your
printer and make preparations (paper, ink cassette, cartridge, etc.) as required.
3. Set the camera mode to . and you can review all the pictures and video clips stored in the current memory on the TV.
NOTE:
• It is recommended to use AC adapter when the camera is connected to a TV.
• Shooting operation (taking pictures, recording video, playing back) is available when the camera is connected to a TV.
74
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Turn on the camera and the printer.
2. Selecting PictBridge mode Access the setup menu to enable the USB port. Refer to page 78 for details.
3. Connecting the camera to the printer Refer to "Camera / Printer Connection" on page 78 for details.
4. Select print settings. Use the camera's function and navigation buttons to select the print settings. Refer to page 79 for details.
5. Printing Press the button to start printing.
Polaroid t737 Digital Camera User Guide www.polaroid.com
75
Canceling Printing
List of Error Messages
Press the
button to cancel printing the print job. The printer will stop
printing and eject the paper.
Printing Errors
If for some reasons an error occurs during or before printing, press button to exit and reconfigure printing settings.
Please refer to the printer’s user guide for the solutions. Printing may resume once the problem is solved.
NOTE:
Printing operation may still fail with some errors even if you press the
button after selecting “CONTINUE”. In that case, select “CANCEL” and press the
button.
PAPER IS EMPTY Paper cassette runs out of paper.
PAPER IS NOT LOADED Paper is not loaded or incorrectly loaded.
PAPER IS NOT EJECTED Paper is not ejected correctly.
MEDIA ERROR Paper is not detected, paper is skewed, or roll paper
PAPER IS JAMMED The paper is jammed during printing.
PAPER IS NEARLY EMPTY Paper cassette almost runs out of paper.
PAPER TYPE IS NOT SUPPORTED
INK EMPTY Ink cassette is out of ink.
INK LOW Ink cassette is almost empty.
WASTE INK RESERVOIR FULL Waste ink reservoir is full.
HARDWARE FATAL ERROR A serious error occurs with the printer’s hardware.
PRINTER IS BUSY The printer is busy with other print jobs from another
PRINTER IS OCCUPIED The printer is performing maintenance or occupied by
COVER IS OPENED The printer’s cover is open or not securely closed.
NO MARKING AGENT Some print information is missing during printing, e.g.
INK COVER IS OPENED The printer’s ink cover is open or not securely closed.
NO INK CARTRIDGE No ink cartridge is loaded.
SPECIFIED INFO IS TOO LARGE Image information is too large to process.
FILE DECODE ERROR Picture format of specifi ed image cannot be decoded.
cannot be cut or torn off
Paper type or size is not supported by the printer or paper found in the printer does not match request.
source.
other external device.
missing print head.
76
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
77
Selecting PictBridge Mode
5. System will enter Pictbridge menu automatically.
1. Press the camera to Playback mode.
2. Press the button and press the
button to set the
PRINT SETTING
DPOF
Pictbridge
button to enter print setting.
3. Press or button to select the PICTBRIDGE option.
NOTE:
To print a single image, select the image before enabling PictBridge
mode.
Camera / Printer Connection
4. Plug Series A of the USB cable into the marked socket on your
printer. Plug AV/USB/DC of the USB cable into the port on your camera. Location of USB socket will vary from printer to printer.
USB port
To Printer
Pictbridge
Please Connect To Device
Device Is Connect
This Image
All Images
All Index
NOTE:
• “ DEVICE IS CONNECTED” displays on the LCD screen, indicating
a proper connection to the printer.
• Do not connect the USB cable to the camera until PictBridge is enable
and when prompted by the “PLEASE CONNECT TO DEVICE” screen. Or if you already have connected the cable to the camera, do not plug into printer until prompt to do so. Not following this sequence will result in connection failure.
Selecting Print Settings
1. Press or button to select the print mode.
This Image
All Images
All Index
Pictbridge
2. The following options are available.
THIS IMAGE Print the selected image in the camera’s internal memory or a memory card
ALL PRINT Print all images in the camera’s internal memory or a memory card
ALL INDEX All images in the camera’s internal memory or a memory card are given an
according to specified settings. Use the left or right button to designate the image you want to print before selecting the print settings.
according to the specified settings.
index and printed according to the specified settings.
78
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
79
NOTE:
• To print a single image, select the image before enabling PictBridge.
• Print settings are confi gured for images only. Make sure there are
no video clips or other fi le besides images in the memory before printing.
• Not all printers will support all these print options. Please refer to the
printer user guide for options available.
3. Press the button to select the print settings.
No.of Copy
01
Default Default Default Default
Number of Copies Print Layout File Name On/Off Date Stamp On/Off Paper Size
Specifying the Number of Copies
Press the
or button to specify the number of copies (from 1 to 99) you want to print for the selected image or all images.
NOTE:
“01” is the default setting.
Selecting Print Layout
1. Press the or button to select “N-UP
LAYOUT”.
2. Press the
or button to specify the
number of printed images on a page.
01
Default Default Default Default
01
Default
Default Default Default
NO.of Copy
N-Up Layout
Select a setting item using the up or down button and select setting contents using the left or right button.
NOTE:
The camera’s print settings are not supported by some printers. The LCD
screen shows those settings that are available for the currently connected printer.
80
Polaroid t737 Digital Camera User Guide
www.polaroid.com
DEFAULT Print settings differ according to the printer model. 1/2/4/6/8 Specify the number of printed images on a page. BORDERLESS Print right to the edge of the page.
Setting the File Name On/Off
1. Press the
or button to select “FILE
NAME”.
2. Press the
or button to select
“DEFAULT”, “ON” or “OFF”.
File name
01 Default
Default
Default Default
DEFAULT Print settings differ according to the printer model. ON Add the file name to the printed image. OFF Print without the file name.
Polaroid t737 Digital Camera User Guide www.polaroid.com
81
Setting the Date Stamp On/Off
1. Press the or button to select “DATE STAMPING”.
2. Press the or button to select “DEFAULT”, “ON” or “OFF”.
Date Stamping
01 Default Default
Default
Default
• About DPOF
DPOF stands for “Digital Print Order Format”, which is a format for recording on a memory card or other medium which digital camera images should be printed and how many copies of the image should be printed. You can print on a DPOF-compatible printer or at a professional print service from the memory card in accordance with the file name and number of copies settings recorded on the card.
DEFAULT Print settings differ according to the printer model. ON Add the date stamp to the printed image. OFF Print without the date stamp.
Selecting Paper Size
1. Press the
or button to select
“SIZE”.
2. Press the or button to select the paper size.
The following paper sizes are
supported: 8” x 10”, 4” x 6”, A4, A6,
01 Default Default Default
Default
11” x 17”, B5, postcard and default.
DEFAULT Print settings differ according to the printer model.
Printing
1. Press the
button.
2. Press the or button to select “OK”.
3. Press the button.
Press the button to return to the print setting window.
82
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Size
With this camera, you should always select images by viewing them on the LCD screen. Do not specify images by file name without viewing the file contents.
NOTE:
• Print settings are confi gured for images only. Make sure there are no video clips or other fi le besides images in the memory before printing.
1. Insert an SD card into the camera.
2. Turn on the camera.
3. Press the
button to set the camera
DPOF
Pictbridge
PRINT SETTING
to Playback mode.
4. Press the button and press the button to enter print setting.
Select Images
All Images
DPOF
5. Press or button to select the DPOF option.
6. Press the button to enter.
Polaroid t737 Digital Camera User Guide www.polaroid.com
83
7. Press the or button to select the desired setting.
7 Using the SD (Secure Digital) Card
8. Press the button.
Print 05 Images?
9. Specifying the number of printing copy using the or button.
10. Press the button.
11. Remove the memory card from the camera and insert it into the printer’s card slot (as illustrated). Location of the card slot may vary from printer to printer model.
NOTE:
Make sure you turn off the camera before inserting or removing a
memory card.
12. Press the Print button on the printer to start printing.
SELECT IMAGES The selected picture in the memory card will be
printed up to 99 copies.
• Using the SD Card
Your camera comes with built-in flash memory for storing pictures and video clips. You can expand the memory using a Polaroid SD card (sold separately) (up to 4GB). The camera senses whether a memory card is inserted, and automatically saves pictures and video clips accordingly. Note that you cannot save pictures or video clips to the built-in flash memory while a memory card is installed in the camera. See pages 106 to 107 for storage capacities.
Memory card precautions:
1. Use only a SD memory card with this camera.
2. Electrostatic charge, electrical noise, and other phenomena can cause data corruption or even loss. Always make sure that you always back up important data on other media (MO disc, computer hard drive, etc.).
3. If a memory card starts to behave abnormally, you can restore normal operation by formatting it. However, we recommend that you always take along with more than one memory card whenever using the camera far away from your home or office.
4. We recommend that you format a memory card when using it for the first time, or whenever the card you are using seems to be the cause of abnormal pictures. Remember to format a memory card if it was used in another digital camera or other devices.
ALL IMAGES All pictures in the memory card will be printed up to
99
84
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
85
IMPORTANT!
• Make sure you turn off the camera before inserting or removing a memory
card.
• Be sure to orient the card correctly when inserting it. Never try to force a memory card into the slot when you feel resistance.
• SD memory cards have a write protection switch that you can use to protect les from accidental deletion. However, you must remove the write protection whenever you want to record new fi les onto it, format it, or delete its fi les.
• Files contained in the SD card recorded by other cameras may confl ict with the t737 camera, and valuable data in your existing SD card may be distorted or lost when the card is inserted in the t737 camera. We strongly recommend the user to use a new or formatted Polaroid (not included) SD card for the t737 camera. The manufacturer is not liable for losing or corrupting any valuable data or fi les in your SD card due to improper operation.
Inserting a SD card
1. Turn off the camera.
2. Open the SD card door by pushing it outwards as illustrated.
3. Insert the SD card and ensure the card is inserted the correct position
as illustrated.
4. Close the SD card door by pressing it downwards and slide it back to
lock.
Removing the SD card
To remove the SD card, turn off your camera and open the SD card door. Gently push the SD card inwards and then release it. The SD card will eject out of the SD card slot.
1
a
b
IMPORTANT!
• Never insert any other object into the camera’s SD card slot. Doing so creates the risk of damage to the camera and card.
• Should water or any foreign objects ever get into the card slot, immediately turn off the camera, remove the battery or disconnect the AC adapter, and contact your dealer or the nearest service provider.
• Never remove a card from the camera while the camera is powered on. Doing so can cause the picture or video recording operation to fail, and even damage the memory card.
2
1
a
b
2
3
b
a
The icon will appear on the LCD screen when a SD card is inserted into the camera.
86
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
87
• Formatting a SD card
Formatting a memory card erases all data stored on it, including the protected ones. Removing the SD card during formatting may damage the card.
1. Insert an SD card into the camera.
Language
2. Turn on the camera.
3. Access the setup menu.
4. Press the
5. Press the
or button to select (FORMAT).
button to enter.
Date Stamp LCD Brightness
Format
Sequence No.
Internal Memory
6. Press the or button to select the desired setting.
7. Press the button.
8. Press the or button to select the desired setting.
9. Press the button to confirm your choice.
IMPORTANT!
• SD cards formatted in another camera, computer or other devices may not work
properly. It is recommended to format SD cards with your t737 camera.
• Note that data deleted by formatting operation cannot be recovered. Make
sure you do not have any useful data currently stored on a memory card before you format it.
SETUP
English
12/3/06
Off
2/3
Format
SD Card
Format
Format Memory All Data Delete?
Cancel
OK
8 Installing the Software onto a Computer
• Installing the Software
For Windows® Users:
IMPORTANT!
• Please backup all the necessary data before any driver and software installation.
• The CD-ROM is tested and recommended to use under English Windows OS.
• Please restart the computer after installing the software.
• If you don’t know how to perform the software installation, please read the “ReadMe” fi le in the CD fi rst.
IMPORTANT! (For Windows® 98SE)
Windows® 98SE needs to install your digital camera Driver for Mass Storage
function. After the installation, please restart the Windows before connecting the camera to the PC.
IMPORTANT! (For Windows® Me, 2000, XP & Vista)
Directly plug-in the camera to transfer and play the pictures and video clips.
No need to install the driver.
IMPORTANT!
To experience higher performance in graphics and sound when you’re watching
video clips on your PC, it is recommended to install the DirectX ver. 9.0 or above. It can be downloaded from http://www.microsoft.com/directx.
PC
88
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
89
1. Before you begin, close all other software applications open on your computer.
2. Insert the CD supplied into the computer CD-ROM Drive.
3. The CD User Interface Screen will automatically launch.
4. With the mouse, click on each software interface button in turn and follow the on screen instructions.
NOTE:
If the setup screen does not appear
after loading the CD, then you can manually start it by double clicking the “My Computer” icon on your desktop, then double clicking the icon for the CD-ROM drive. When the CD­ROM window opens, double click the “INSTALL-E.EXE” icon.
For Macintosh Users:
Open & Close
Mac
• Software Included with Your Camera
The t737 software CD contains the following software:
Polaroid t737 Camera Driver Plug & Play removable disk
Easy to use, just plug the camera to a computer and use it as a removable disk. Use the ArcSoft® PhotoStudio® to edit and print the Pictures.
ArcSoft® PhotoStudio® Picture Editing Software
ArcSoft® PhotoStudio® is an easy-to-use and powerful image-editing software loaded with everything you need to fix, print, and get creative with your digital pictures. This program gives you quick access and all­at-once enhancement to the pictures on your computer, for example, removing red-eye and cloning objects to a different picture. Add special effects or place them in cards, calendars, frames and fantasy templates. ArcSoft® PhotoStudio® also includes a wide variety of printing options.
ArcSoft VideoImpression® 2 Movie Making Software ArcSoft VideoImpression® is an easy-to-use video editing software program. The program enables users to create and edit new videos using existing video and image files - making desktop video presentations for home, business, and the Web.
1. Before you begin, close all other software applications open on your
computer.
2. Insert the CD supplied into the computer CD-ROM Drive.
3. Double click the CD-ROM icon “Polaroid”.
4. Install the software included.
90
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Adobe® Acrobat® Reader™ .PDF File Reading Software
Adobe® Acrobat® Reader lets you view and print Adobe Portable Document format (PDF) files on all major computer platforms, as well as fill in and submit Adobe PDF forms online.
Polaroid t737 Digital Camera User Guide www.polaroid.com
91
ArcSoft Panorama Maker® 4 Pictures Stitching Software
Like magic, ArcSoft Panorama Maker® 4 turns any series of overlapping photos into a gorgeous panoramic image in just seconds. The program does most of the work for you by automatically selecting an entire group of pictures with one click, automatically organizing the photos into the proper order, then seamlessly stitching the photos into a panoramic masterpiece that you can print, share or post to the web. Create horizontal, vertical and 360° panorama pictures all within this one amazing program.
• About ArcSoft Panorama Maker® 4
How to Shoot Photos for Panoramas?
Whether you’re a beginner or a seasoned professional, shooting photos for panoramas can be tricky business. To make things easier, the program includes a tutorial entitled “How to Shoot Photos for Panoramas” in the “Help” menu along with a printable checklist that you can take with you when you go out to shoot.
How to stitch the photos into a panoramic photo? (PC & Mac)
1. Shoot some photos for panoramas by Polaroid digital camera (please see “How to Shoot Photos for Panoramas”).
2. Open ArcSoft Panorama Maker® 4, select the source photos. You can check the “Auto-Select by Group”, then click one of the photos, ArcSoft Panorama Maker® 4 can auto select the related photos. Check the “Stitch as” according to the source photos capturing orientation. Then click the Next button
3. On this interface, you may crag and drop the thumbnails to change the order, and then click the Stitch button when ready.
92
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
93
4. ArcSoft Panorama Maker® 4 is processing in just seconds.
5. A panoramic image was stitched, but you may use Crop and Straighten functions to fine-tune the panorama.
5. Then save or print out the gorgeous panoramic image as follow.
94
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
95
• Computer System Requirements
For acceptable picture transferring and editing performance, we recommend the following minimum requirements;
For Windows® Users
• Compatible with Microsoft® Windows® 98SE, Me, 2000, XP or Vista
• Pentium® III 450 MHz or equivalent processor
• USB Port
• 128MB RAM (256MB recommended)
• DirectX 9.0 or higher
• 500MB free disk space
• Color monitor with high color (16-bit) graphic capability or higher
• CD-ROM drive
• Standard mouse and keyboard
• Stereo speakers
PC
9 Transferring Pictures and Video Clips to a Computer
• Before Transferring Files
IMPORTANT! - FOR PC USERS
BEFORE YOU CONNECT YOUR DIGITAL CAMERA TO THE COMPUTER, MAKE
SURE THAT YOU HAVE INSTALLED THE SOFTWARE FROM THE ENCLOSED CD. PLEASE REFER TO “8 Installing the Software Onto a Computer”.
• Connecting to Your Computer
Connect the camera directly to your computer
For Macintosh Users
• Mac® OS Version 9.2~X
• PowerMac G3 or higher
• USB Port
• 128MB RAM (256MB recommended )
• 500MB Free disk space
• Color monitor with high color (16-bit) graphic capability or higher
• CD-ROM drive
• Standard mouse and keyboard
• Stereo speakers
96
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Mac
1. Turn on the camera.
2. Plug the
labelled end of the USB cable into the marked
socket on your computer.
3. Plug the other end of the USB cable into the port on your camera.
4. An interface “New Hardware Found” will show on the computer desktop.
5. A removable disk drive will be installed onto your computer automatically.
Polaroid t737 Digital Camera User Guide www.polaroid.com
97
• Transferring Pictures and Video Clips to a Computer
NOTE:
The Mass Storage mode is the default setting when the docking is connected
with a TV set or a computer.
For Windows® Users
NOTE:
You can transfer pictures and video clips in any mode.
1. Turn on the camera
2. Connect the camera to a computer via the USB cable.
3. Double click on “My Computer” on your PC desktop and you will see a “Removable Disk” drive.
4. Double click “Removable Disk” -> double click “DCIM”-> double click any directory folder under “DCIM”.
5. All the pictures, video and audio clips are in the directory folder. Highlight the pictures, video and audio clips and drag them to a folder of your choice. You can also create sub folders to group them or use the Arcsoft software to edit and manage the pictures, video or audio clips.
PC
For Macintosh Users
NOTE:
For Mac user, directly plug-in the camera, no need to install the driver.
Mac
1. Turn on the camera.
2. Set the camera to Playback mode.
3. Connect the camera to Mac via the USB cable, the systems will automatically recognize the MASS STORAGE drive. (System will automatically create a Mass Storage named “DIGITALCAM”).
NOTE:
This Drive name will vary from different version of Mac OS system.
4. Double click the folder “DIGITALCAM” to enter sub-folder “DCIM”.
5. Double click the folder “DCIM” and then any subfolder inside.
6. You can copy the pictures and video clips from this directory folder and paste to the hard disk.
98
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
99
10 Troubleshooting Problems
The troubleshooting guide is designed to help you. If problems continue, please contact customer support. Details are provided under “Getting Help”.
I receive an error message when I am installing “Polaroid t737 Camera Driver”.
I cannot upload images to my computer.
I cannot run the “Polaroid t737 Camera Driver”.
My CD Installation wizard does not work.
Symptom Problem Solution
“Polaroid t737 Camera Driver” does not load.
Connection failure. Check all cable connections are secured.
Camera Driver is not installed.
Confl ict with another camera driver or capture device.
The auto installation le is switched off or The CD-ROM is disconnected.
Shut down all other applications and attempt to reinstall the driver.
Check to see if the USB in your BIOS is activated. Please refer to Polaroid web site to activate the USB in the BIOS.
You need to install the camera driver for Windows 98SE systems.
If you have another camera installed on your computer, remove it and it’s driver completely from your system to avoid confl icting with it.
* For Win98se/Me user: Go to the computer desktop. Right click on “My Computer”. Click “Properties”. Select “Device Manager”. Double click on “CD_ROM”, double click on “CD-R (normally the manufacturer’s name. Click on “Settings”. Ensure both “Auto insert notifi cation” and the “disconnect” are ticked. If you change the settings the computer will ask you to restart your PC. Click “Yes”. * For WinXP user: Go to the computer desktop. Double click on “My Computer”. Right click “CD Driver” and select “Properties”. Click “Autoplay”. Ensure “Prompt me each time to choose an action“ is ticked. Click “OK” to exit. * For Win Vista user: Go to “Control Panel / Hardware and Sound / AutoPlay”, then set “Software and games” to “Install or run grogram” or “Ask me every time”. Click “Save” button to exit.
Symptom Problem Solution
Images are not shown on TV.
The video clip (AVI) fi le cannot be played.
The camera is detected by the Windows and works properly. But a driver letter of the Removable disk is not created.
I cannot activate my Digital Camera by pressing the Power switch.
Camera does not turn on. Battery is not oriented
Camera suddenly powers off.
Image is not recorded when the shutter button is pressed.
Camera powers off during self-timer countdown.
LCD screen image is out of focus.
Recorded pictures are not saved in memory.
Video cable is not connected correctly.
DirectX version is lower than
9.0
The removable disk crashes with the network drives.
Insuffi cient battery power or battery is missing.
correctly.
Battery is dead.
Auto Power Off function is activated.
Battery is dead
Camera is turned off.
Flash unit is charging.
Memory is full.
Battery is dead. Recharge the battery.
Macro mode is being used for far subjects.
Still image mode is being used for near subjects.
Removing the memory card before the save operation is complete.
Or
Or
.
Or
Or
Or
Make sure the video cable is connected to the TV “Video In” socket.
Install DirectX 9.0 or above. Visit http://www. microsoft.com/directx for more details.
Disconnect the crashed network drive and reserve this drive letter for the camera.
Recharge the battery or install the battery.
Orient the battery correctly.
Recharge the battery.
Turn the camera on.
Recharge the battery.
Turn the camera on.
Wait until fl ash unit charging fi nishes.
Delete images you no longer need, or use another memory card.
Set the camera to Still Image mode.
Set the camera to Macro mode for subjects this
the lens:
close to Wide Angle: 0.32 ft~ 2.6 ft (0.1 m ~ 0.8 m) Telephoto: 0.3 ft ~ 2.6 ft (0.09 m ~ 0.8 m)
Do not remove the memory card before the save operation is complete.
Or
Or
Or
Or
Or
100
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
101
Symptom Problem Solution
Colour of the playback pictures is different from the picture on the LCD screen during recording.
Pictures are not displayed. A memory card with non-DCF
I cannot erase pictures. All the pictures in memory are
There is no response from the camera while pressing any buttons.
Sunlight or light from another source is shining directly into the lens during recording.
pictures recorded with another camera is loaded in the camera.
protected.
The LCD screen is frozen or the camera stopped responding.
TV out
Symptom Problem Solution
LCD screen does not appear on the screen of the connected television
Images do not display in color on TV.
There is a problem with the camera-TV connection
TV setup is wrong
Video system is incompatible.
Wrong system selection. Change to NTSC or PAL.
Or
Or
Position the camera so sunlight does not shine directly onto the lens.
This camera cannot display non­DCF pictures recorded onto a memory card used by another digital camera.
Unprotect the pictures you want to delete.
Remove and re-install the battery or batteries to reset the camera. Your valuable data stored in the camera will not be lost.
Use the optional video cable to connect the camera to the TV
Consult the documentation of the TV and put it in its video mode
Select the proper video output system.
Or
Or
11 Getting Help
• Polaroid Online Services
Website: http://www.polaroid.com
• ArcSoft Software Help
For United States For Latin America
ArcSoft HQ Support Center E-mail:latinsupport@arcsoftsupport.com (Fremont, CA 94538) Tel.: 1-510-979-5599 Fax: 1-510-440-7978 E-mail: support@arcsoftsupport.com Web: http://www.arcsoft.com/en/support/
For Europe For China
ArcSoft Europe Support Center ArcSoft China Support Center (Ireland) (Hangzhou) Tel.: +353-(0) 61-702087 Tel.: +86-571-88210575 Fax: +353-(0) 61-702001 E-mail: support@arcsoft.com.cn E-mail: eurosupport@arcsoft.com Web: http://www.arcsoft.com.cn/new/support
For Japan For Taiwan
ArcSoft Japan Support Center (Tokyo) ArcSoft Taiwan Support Center (Taiwan) Tel.: +81-3-5795-1392 Tel.: +886-(0) 2-2506-9355 Fax: +81-3-5795-1397 Fax: +886-(0) 2-2506-8922 E-mail: support@arcsoft.jp E-mail: support@arcsoft.com.tw Web: http://www.arcsoft.jp Web: www.arcsoft.com.tw
Visit http:// www.arcsoft.com for technical support and frequently asked questions (FAQ’s).
“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation, Waltham, MA, USA.
Please also refer to the help fi les & User Guides that accompany the
enclosed applications. For further information and support, please visit our website: http://www.polaroid.com
102
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
103
• Technical specifi cations
Sensor • Sensor:
Lens • Aperture: f 3.3~5.67
LCD Screen 3.0” LTPS color panel
Built-in
Flash
Exposure
Control
ISO Speed Auto, 80,100,200,400
- 1/2.5 inch
- 7.0 Megapixels CCD
• Focal Length: 6.48 ~ 18.87 mm
• Focal Distance
- Normal Focus: 0.33 ft to (10 cm to ) (The focusing range is the distance from the lens surface
to the subject.)
- Macro Focus: Wide Angle: 0.33 ft~ 1.64 ft (0.1 m ~ 0.5 m) Telephoto: 0.33 ft ~ 1.64 ft (0.1 m ~ 0.5 m)
• Modes
- OFF/Auto/Red Eye Reduction/On
• Range Flash Range for Normal mode: Wide Angle: 1.64 ft ~ 6 ft ( 0.5 m ~ 1.8 m ) Telephoto: 1.64 ft ~ 3.3 ft ( 0.5 m ~ 1 m ) Flash Range for Macro mode: Wide Angle: 0.33 ft~ 1.64 ft (0.1 m ~ 0.5 m) Telephoto: 0.33 ft ~ 1.64 ft (0.1 m ~ 0.5 m)
-/+2.0 EV in 0.3 step
12 Appendix
Shutter
Mechanical shutter 1/1000 sec ~ 2 sec
Speed
White Balance
Storage
Auto / Daylight / Cloudy / Shade / Incandescent / Tungsten / Fluorescent-F / Fluorescent-N
• Internal Memory: 11 MB Nand Flash
• External Memory
-supports SD card up to 4 GB (not included)
Self-timer 2 sec/ 10 sec
File Format • Still Image
- EXIF 2.2 compatible format (JPEG compression) DCF compatible, Support DPOF
• Video Clip: AVI
Power Supply Li-Ion Rechargeable battery (820mAh)
Tripod Socket Yes
Connectivity With computer via USB cable (included)
With TV via TV cable (included)
Dimension
• Size:
- (W) 105 mm x (D) 58 mm x (H) 23 mm
• Weight:
Approximately 140g excluding batteries and card
Operating System
• For Windows Users: Microsoft Windows 98SE, Me 2000, XP or Vista
• For Macintosh Users: Mac OS 9.2 ~ X
104
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
105
• Storage Capacity of SD Card
The charts below indicate the approximate numbers of pictures and length of video clips the camera can hold at each setting based on the internal memory and different capacities of SD card.
Recordable Images
Units: Images
Resolution Quality Internal Memory 32MB SD 64MB SD 128MB SD
9112142
3072 X 2304
2816 X 2112
2048 X 1536
1600 X 1200
640 X 480
25 29 59 118
34 43 86 172 11 14 28 56
28 35 70 140
42 51 102 204 20 25 50 100
54 67 134 168
78 98 196 392 32 39 78 156
88 111 222 444
127 158 316 632 173 215 430 860
502 620 1240 2480
701 867 1734 3468
Resolution Quality 256MB SD 512MB SD 1G SD 2G SD
94 188 376 752
3072 X 2304
2816 X 2112
2048 X 1536
1600 X 1200
640 X 480
239 478 956 1912
360 720 1440 2880 118 236 472 944
294 588 1176 2352
426 852 1704 3408 209 418 836 1672
551 1102 2204 4408
805 1610 3220 6440 327 654 1276 2552
903 1806 3612 7224
1295 2590 5180 10360 1758 3516 7032 14064
5061 10122 20244 40488
6942 13884 27768 55536
NOTE:
Super fi ne Fine
Normal
106
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
107
Recordable Video Length
Resolution Video clips can be taken
11MB Internal Memory 43”
1’12”
32MB SD
64MB SD
128MB SD
256MB SD
512MB SD
1GB SD
2GB SD
NOTE:
640x480
320x240
• Scene complexity affects a picture’s fi le size. For example, a picture of trees in autumn has a larger fi le size than a picture of blue sky at the same resolution and quality setting. Therefore, the number of pictures and length of video clips you can store on a memory card may vary.
43”
1’55”
1’25”
3’53”
2’58”
8’08”
5’56”
16’16”
11’52”
32’32”
23’44”
65’4”
47’28”
130’8”
• Uninstalling Polaroid t737 Driver (PC only)
For Windows® 98SE Users
NOTE:
The following driver uninstall procedure is for Windows 98SE user only because
only Windows 98SE needs to install the t737 driver.
1. Open Add/Remove Program Properties in Control Panel and select “Polaroid Digital Camera” program, then click “Add/Remove”.
2. The following dialogue box appears, please click “Yes” to confirm removing the camera driver.
3. The un-installation program runs automatically, please restart your computer when it is finished.
PC
108
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
109
• Camera Default Settings
Camera Mode Description Default
Still Image Mode Image Resolution 3072 X 2304
Compression Super Fine
Sharpness Normal
Digital Zoom Off
AF-Assist Beam Off
Quick Review 2 Sec
Focus Area Single AF
Shake Warning ---
Flash Mode Auto Flash
Exposure Compensation 0
ISO ---
White Balance for Pictures Auto
Shutter Speed ---
Light metering Average
Video Mode Video Resolution 640 X 480
White Balance for Video Clips Auto
Exposure 0
Setup Mode Capture mode Still Image
Date / Time DD.MM.YY
Auto Power Off 1 MIN
Beep Sound On
Volume 2
Video System LCD
Language English
Date Stamp Date
LCD Brightness ----
Format Internal Memory
Sequence No. Off
Opening On
LED Setting ----
Storage Media Auto
Playback Mode Protect Off
Slide Show 2 Sec
NOTE:
The default language for the LCD screen may vary with the different shipment
destinations.
110
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Polaroid t737 Digital Camera User Guide www.polaroid.com
111
• Tips, Your Safety & Maintenance
Your Camera should only be operated within the following environment.
• 32 - 104º Fahrenheit; 0 - 40º Celsius
• 15% - 90% relative humidity, non condensing
The battery life or image quality may be affected when the camera is oper­ated outside these conditions.
• Regulatory Information
FCC Notice
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Camera Cautions
• NEVER immerse any part of the camera or its accessories into any fluid or liquid.
• ALWAYS disconnect the camera from your PC or TV before cleaning it.
• ALWAYS remove dust or stains on the camera with a soft cloth dampened with water or neutral detergent.
• NEVER place hot items on the surface of the camera.
• NEVER attempt to open or disassemble the camera as this will affect any warranty claim.
112
Polaroid t737 Digital Camera User Guide
www.polaroid.com
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
Polaroid t737 Digital Camera User Guide www.polaroid.com
113
Shielded cable must be used with this unit to ensure compliance with the Class B FCC limits.
Under the environment with electrostatic discharge, the product may malfunction and require user to reset the product.
US 0407
Part No.: OM3568US003
Loading...
