POLAROID CKA-00301S, CSA-00302S User Manual
FCC Compliance Statement:
This device complies with Part 15 of the FCC Rules. Operation is subjected to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in residential installations.
This equipment generates, uses, and can radiate radio frequency energy, and
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio or television
equipment reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Move the equipment away from the receiver.
-Plug the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/television technician for additional
suggestions.
You are cautioned that any change or modications to the equipment not expressly
approved by the party responsible for compliance could void Your authority to
operate such equipment.
* Environment:
Do not throw the product away with the normal household waste at the end of its life.
Bring it to an ofcial collection point for recycling.
By doing this you will help to preserve the environment.
Welcome:
Thanks for purchasing this product. Much time and effort has gone
into this product’s development, and our hope is it will give you many
years of trouble-free service.
Safety Notice:
1. Do not disassemble the camera; otherwise the warranty will be
voided.
2. Avoid all contact with water, and dry hands before using.
3. Do not expose the camera to high temperature or leave it in direct
sunlight. Doing so may damage the camera.
4. Use the camera with care. Avoid pressing hard on the camera
body.
5. For your own safety, avoid using the camera when there is a storm
or lightning.
6. Do not use batteries of different types. Doing so may lead to the
potential for serious damage.
7. Remove the batteries during long periods of non-use, as a
deteriorated battery may affect the functionality of the camera.
8. Remove the battery if it shows signs of leaking or distortion.
9. Use only the accessories supplied by the manufacturer.
10. Keep the camera out of the reach of small children.
1
1
2
3
4
5
1
Mode Switch
2
Viewnder
3
Reset Button
4
Directional Pad
5
LCD Panel
6
TV-out Connector
Need help with your digital camera?
Call our toll-free customer service number. Look for the insert with this icon:
Or visit www.polaroid.com.
7
Shutter Button
8
Start/Pause Button
9
Playback/Turbo Button
10
Flash Toggle/B Button
11
Strap Holder
12
Delete/A Button
2
6
7
8
9
10
11
12
Parts of the camera - 2
14
13
Bottom View
16
13
Lens
14
Flash Strobe
15
Speaker
16
USB Port
17
Bottom Cover (Battery / Memory Card Slot inside)
15
17
3
Loading the battery
Please use two AAA batteries.
1. Loosen the 2 screws and remove the battery/card compartment
cover as indicated.
2. Load the batteries into the battery compartment with + and - ends
correctly installed.
3. Re-install the cover.
2
2
1
Inserting the SD/MMC card (optional)
1. Loosen the 2 screws and remove the battery/card compartment
cover.
2. Insert the card as shown in the illustration until it reaches the end
of the slot.
3. When using a SD card, the camera’s built-in memory will become
inaccessible.
4. To remove the SD card, gently push the card until it pops up.
5. Re-install the cover.
4
1
Turning on/off the camera
PGG
Turning on the camera:
Slide the mode switch to CAMERA ( ) or
GAME ( ) mode to power on the camera.
Turning off the camera:
Slide the mode switch to the OFF position to
power off the camera.
Battery life indicator
Icon Description
Full battery life
Half battery life
Empty battery life
5
Reading LCD indicators
Camera preview:
Number of
pictures
Zoom ratio
Flash mode
Mode icon
Playback thumbnail view:
Highlight box
Current images
in memory
Playback full view:
6
SD card inserted
Battery life
Number of
pictures
SD card inserted
Battery life
Number of
pictures
SD card inserted
Battery life
Taking a still picture
1. Slide the mode switch to CAMERA ( ) mode to power on the
camera.
1. Use the directional pad ( ) to zoom in or zoom out the screen.
2. Press the Shutter button on the top of the camera to take a
still picture.
: You can press the B button to toggle ash mode. Use ash if the
environment is too dark.
Playing back your pictures
1. While in CAMERA ( ) mode, press the Playback/T button.
2. Use the directional pad ( ) to shift between images.
3. You can press the Playback/T button twice to enter thumbnail
mode.
4. Use the directional pad to select a picture and press the Playback/T
button to view the picture in full-screen mode.
5. Press the Shutter button to return to CAMERA preview mode.
To delete a picture
1. You must be in the Playback mode.
2. Select a picture and press the Delete/A button.
You will see a prompt window.
3. Select and press the Delete/A button to
conrm the deletion.
4. If you wish to cancel, select .
Need help with your digital camera?
Call our toll-free customer service number. Look for the insert with this icon:
Or visit www.polaroid.com.
Deleting a picture
7
Playing games on a TV
By connecting your camera and TV via the accessory AV cable, you
can play the built-in games directly on your TV, enjoying the great
entertainment the camera has to offer.
AV Mode
AudioVideo
1. Turn on your TV and switch to the appropriate AV input mode.
2. Connect the audio and video ends of the AV cable to the TV.
3. Slide the mode switch to GAME ( ) mode to power on the
camera.
4. Connect the other end of the AV cable to your camera.
TV-Out
Connecting the camera to your PC
1. Slide the mode switch to CAMERA ( ) mode to power on the
camera.
2. Connect the camera to your computer via the USB cable, and
the camera will become a removable disk in your computer.
3. You can copy les from the camera to your computer, and vice
versa.
8
Playing games - 1
Slide the mode switch to
GAME ( ) mode, and you
can select any of the 8 built-in
games for your entertainment.
Basic operations in the games:
Game Description
Step up to the free throw line and try to
break the record of 20 baskets (1 point
each) within the time limit. Watch the
power bar at the top right of the screen,
when it reaches the level you want, press
the shoot button to throw the ball.
Basketball
Bounce
A Button, Turbo next to A: Shoot a basket
You’ll need quick reexes and more than
a little luck in this challenging game! Use
the four paddles to bump the ying ball
away from the wall. If it hits the side of the
board, it’s game over!
Directional Pad: 4 directions
Start/Pause
Turbo Button
B Button
A Button
9
Playing games - 2
10
Game Description
Fancy Match
Happy Diamond
Jewel Master
Move around the board and ip over tiles,
trying to nd two that match. When you
nd a pair, they will disappear! Clear all
the tiles before time runs out to win. Be
careful not to bump into the enemies on
the board!
Directional Pad: 4 directions
A Button, Turbo next to A: Select
Make the diamond blocks disappear by
moving them around until two with the
same image are together. When all the
blocks are gone, you advance to the
next level!
Directional Pad: 8 directions
A Button, Turbo next to A: Hold on the
selection
B Button, Turbo next to B: Undo your
last action
As the jewels fall in groups of three, try
to line up jewels of the same shape and
color. Try your best to wipe off all the
jewels of the same color and shape.
Directional Pad: Left and Right
A Button, B button, Turbo: change
sequence of three jewels
Down direction: Accelerate
