Polaroid CIU-01035B User Manual
10.0 Megapixel Digital Camera
i1035
User’s Manual
Questions?
Need Some Help?
This manual should help you
understand your new product.
or visit
www.polaroid.com/support.
If you still have questions, call
our help line found on the
insert with this icon:
DIGITAL QUALITY, POLAROID SIMPLICITY™
2
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
Product Overview
1. Shutter button
2. Power on LED
3.
Flash
4.
Self-timer LED / AF LED
5.
Microphone
6.
Power button
7.
Speaker
8. USB port
9. Lens
6
8
9
7
1
4
3
5
2
10. Zoom out/ Thumbnail button
11. Mode button
12.
Self-timer / Up button
13. Macro / Left button
14. LCD screen
15. LCD screen on/ off button
16. Scene mode button
17. Zoom in button
18. Flash LED
19. Menu button
20. Wrist strap holder
21.
Flash / Right button
22. OK
button
23. Delete / Down button
10
11
12
13
15
16
17
19
20
22
23
18
14
21
24. Tripod mount
25. Battery / SD card door
24
25
3
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
Table of Contents
Product Overview ...........................................................................2
Table of Contents ...........................................................................3
1 Getting Started. .......................................................................... 6
• Camera Package Contents .........................................................7
• Attaching the Wrist Strap ..........................................................8
• Installing and Removing the Battery ............................................8
• Using Your Batteries .................................................................9
• Checking the Battery Level ......................................................10
• Turning the Camera On and Off ...............................................10
2 Camera Settings ........................................................................11
• Checking the Camera Status ................................................... 11
• Capture Modes ......................................................................11
• Playback Mode .......................................................................14
• Camera Modes ....................................................................... 15
• How to Navigate Menus .......................................................... 15
• Setup Menu .......................................................................... 16
• Setting Date and Time ...........................................................17
• Setting Auto Power Off ..........................................................18
• Setting the Beep Sound.. .........................................................19
• Adjusting the Volume control.. ................................................. 19
• Setting the Display Language ................................................. 20
• Setting the Date Stamp. .......................................................... 21
• Adjusting the LCD Brightness ...................................................21
• Turning Sequence Number On / Off ..........................................22
• Resetting back to Factory Defaults. .......................................... 23
• Cancelling the Startup Image. .................................................. 24
• Choosing the Media for Storage ............................................... 25
• Turning the Information Display On/Off .....................................26
3 Taking Pictures ......................................................................... 28
• Taking Pictures in Normal Mode ...............................................28
• Taking Pictures in the Macro Mode ...........................................30
• Taking Pictures in Different Scene Shooting Modes ....................31
4
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting Flash Mode .................................................................34
• Setting the Self-timer .............................................................. 36
• Setting the Picture Resolution and Compression .........................37
• Setting the Sharpness .............................................................40
• Zoom Feature. .......................................................................41
• Turning Digital Zoom On and Off ..............................................43
• Turning the Auto-focus Assist Beam On and Off ........................44
• Specifying the Quick Review Period .........................................45
• Selecting the Focus Area... ......................................................46
• Setting the Smile Detection Feature........ ..................................47
• Setting the Blink Detection Feature....... .................................... 48
• Setting the Face Tracking Feature.... ........................................49
• Setting the Exposure Compensation ..........................................50
• Setting the ISO... ................................................................... 51
• Setting the White Balance .......................................................52
• Setting the Shutter Speed.... ...................................................53
• Setting the Light Metering.... ...................................................54
4 Recording Video Clips ................................................................55
• Recording Video Clips. ............................................................55
• Setting Video Resolution ......................................................... 56
• Setting Exposure Compensation for Video Clips .........................57
• Setting White Balance for Video Clips .......................................58
5 Managing Pictures and Video Clips .............................................. 59
• Reviewing Pictures. ................................................................ 59
• Reviewing Pictures and Video Clip Files in Thumbnail .................. 59
• Magnifying & Trimming the Displayed Picture ............................60
• Playing a Video Clip on LCD Screen ..........................................60
• Protecting/Unprotecting Pictures and Video Clips ......................61
• Running a Slide Show .............................................................62
• Copy to a Memory Card .........................................................63
• Copy from a Memory Card.. ....................................................64
• Deleting Pictures or Video Clip ................................................65
• Image Cropping... ................................................................... 67
• Dynamic Lighting... ................................................................68
• Red-eye Correction... ..............................................................69
• Saving Your Pictures Using SAVE... ..........................................70
5
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Saving Your Pictures Using SAVE AS... .....................................71
• Exiting the Editing Menu... .......................................................72
• Viewing Pictures and Video Clips on a TV...... ...........................73
6 Print Settings ............................................................................ 74
• Printing Procedures .................................................................74
• About DPOF .......................................................................... 83
7 Using the SD (Secure Digital) Card ..............................................85
• Using the SD Card .................................................................. 85
• Formatting a SD card ..............................................................88
8 Installing the Software onto a Computer ......................................89
• Installing the Software ............................................................89
• Software Included with Your Camera ........................................91
• About ArcSoft Panorama Maker® 4 ...........................................92
• Computer System Requirements ...............................................96
9 Transferring Pictures and Video Clips to a Computer ....................97
• Before Transferring Files ..........................................................97
• Connecting to Your Computer .................................................. 97
• Transferring Pictures and Video Clips to a Computer ...................99
10 Troubleshooting Problems ....................................................... 101
11 Getting Help .........................................................................104
• Polaroid Online Services ........................................................ 104
• ArcSoft Software Help ..........................................................104
12 Appendix .............................................................................. 105
• Technical specifications ........................................................105
• Storage Capacities ................................................................107
• Uninstalling Polaroid i1035 Driver (PC only) ............................. 112
• Camera’s Default Settings .....................................................113
• Tips, Your Safety & Maintenance ........................................... 115
• Regulatory Information .......................................................... 115
6
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
1 Getting Started
Thank you for selecting the new Polaroid i1035 digital camera for your
imaging needs. Incorporated with Polaroid’s sophisticated technology,
your exquisitely compact camera will offer a powerful range of high-end,
easy-to-use functions. It will allow you to capture those special occasions
with life-like clarity and beautiful color renditions.
Outstanding features that your i1035 digital camera has:
• A high quality glass lens system for well exposed sharp pictures from
0.5m to infinity including a 4X digital zoom mode
• Built-in flash with four modes (Auto, Red-eye reduction, Off and
Always on)
• Adjust your picture’s resolution for printing or emailing
• Automatic white balance and exposure compensation to suit lighting
conditions
• PictBridge capability to plug-and-print your images
• Large 3.0 inch LCD screen for easier image preview and review.
7
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Camera Package Contents
The CD-ROM includes
Polaroid i1035 Camera Driver (PC)
Arcsoft Panorama Maker® 4 (PC & Mac)
ArcSoft PhotoStudio® 5.5 (PC) / 4.3 (Mac)
ArcSoft VideoImpression® 2 (PC & Mac)
Adobe® Acrobat® Reader™ (PC & Mac)
User Guide (in PDF format)
Warranty Cardi1035 Quick Start Guide
USB CableWrist Strap
2 x AA Battery
Quick Start Guide
Guide de Démarrage rapide
Guida Rapida
Guía Rápida de Inicio
Guia de Início Rápido
XX XXXX
Part no.: XXXXXXXXX
Printed in China
Schnellanleitung
8
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Attaching the Wrist Strap
1 2
• Installing and Removing the Battery
1. Open the camera’s battery/SD card door by pushing it outwards as
illustrated.
2. Insert the batteries as shown.
3. Close the battery/SD card door by pressing it downwards then slide it
back to lock.
a
b
1 2 3
a
b
4. To remove the batteries, slide the battery lock in the direction of the
arrow and the batteries will eject out of the battery compartment.
5. Pull the batteries with your finger in the direction of the arrow.
a
b
1 2
9
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Using Your Batteries
Our laboratory testing has shown that our digital camera models comply
with industry standard battery consumption levels (Camera & Imaging
Products Association commonly known as CIPA).
All digital cameras are high drain products. For the best performance and
prolonged battery life, we recommend the use of high capacity batteries
designed for such applications.
Here are some helpful hints to extend battery life considerably by limiting
the following activities:
• Reviewing the pictures on the LCD Screen
• Using the optical viewfinder (if your camera has one) to frame the
subject when taking pictures
• Excessive use of the flash
• Remove batteries from your camera when not in use to prevent battery
leakage.
WARNING!
• Batteries should be replaced by an adult.
• Use recommended or equivalent type of batteries only.
• Insert the batteries in the correct orientation.
• Remove exhausted batteries from the camera immediately.
• Do not short the supply terminals.
• Please dispose of the batteries properly.
• Do not touch the lens when the camera hangs due to low battery.
Please replace the batteries and power on the camera.
These instructions should be retained for future reference.
10
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Checking the Battery Level
Check the battery power level before taking pictures.
1. Turn on the camera.
2. Check the battery power level that appears on the LCD screen.
Battery power is full.
Battery power is adequate.
Battery power is low.
Battery power is exhausted. Please
replace the battery.
• Turning the Camera On and Off
1. Press the (POWER) button until the
Power on LED screen turns on.
2. Press the (POWER) button again to turn
the power off.
11
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
2 Camera Settings
• Checking the Camera Status
Turn on the camera, view the camera’s LCD screen to check which
camera settings are active. Those particular features whose icons are not
displayed are not activated.
• Capture Modes
Still Image Mode
20
21
14
12
15
5
6
7
8
9
1 2 3 4
13
11
10
16
17
18
19
22 23 24
No. Description Icon Ref. Page
1 Capture Mode
11
2 Flash Mode
, , ,
37
3 Self-timer and Burst
2, 10
39
4 Macro Mode 30
12
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
No. Description Icon Ref. Page
5
Number of Remaining
Pictures
00001 ---
6 Image Resolution 3648 X 2736 37
7 Compression
, ,
38
8 Sharpness
, ,
40
9 Internal Memory/ SD Card
/
25
10 Focus Frame ---
11 Shaking Warning
---
12 Battery Power Level 10
13
Aperture Value and Shutter
Speed
This indicates the aperture size and
shutter speed the camera has calculated
for an image. For example, f5.2 @ 1/8
second.
---
14 Optical & Digital Zoom Bar 41
15 Digital Zoom Factor X 1.0 ............ X 4.0 43
16 Histogram ---
17 Light Metering 54
18 Shutter Speed
1
1000
1
500
1
250
1
125
1
60
1
30
1
15
1
8
141
2
1”
AUTO
53
19 White Balance 52
20 ISO Sensitivity
AUTO
80 100 200 400 800
1600
51
21
Exposure Compensation
Value
50
22 Smile Delection Mode 49
23 Blink 47
24 Face Tracking 48
13
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
Video Mode
1 2
3
4
5
6
8
7
No. Description Icon Ref. Page
1 Video Mode 55
2. Recording Indicator ---
3 Recording Time 00:00:06 ---
4 Video Size 640x480, 640x424, 640x360
320x240
56
5 Battery Power Level 10
6 Optical Zoom Bar ---
7 White Balance 58
8 Exposure Compensation Value 50
14
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Playback Mode
7
8
10 9
1 2
3
4
5
6
No. Description Icon Ref. Page
1 Playback Image 59
2 Protect 61
3 File Number 100-0013 ---
4 Resolution 3648 X 2736 ---
5 Displayed Date and time
2007/01/01
00:30
---
6 Battery Power Level 10
7 Playback Video 59
8 Play Time 00:00:05 ---
9
Stop
60
10 Play and Pause
/
60
15
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Camera Modes
The camera has three working modes, Capture
mode, Playback mode and Video mode.
Pressing the mode button switches among
these modes.
• How to Navigate Menus
Menus are used to select capture and play settings, as well as other
camera settings like the Date/Time and Auto Power Off.
1. Press the button to enter Menu
Settings.
SETUP
1/3
Resolution
Menu Settings
Setup Settings
1/2
3648X2736
3648X2432
3648X2048
3264X2448
3072X2304
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
2. Press the button.
3. Press the and buttons to scroll
up and down through menu bars.
4. Press the button to enter. Press the
button to back to menu bars.
5. Press the and buttons to select
options.
6. Press the button to confirm your
choice.
16
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setup Menu
You can change the basic settings of the camera in Capture and Video
modes. Here we take the mode for an example.
1. Press the button and press the
button to enter setup menu.
Menu Button
2. Press the button.
3. Press the
and buttons to scroll
up and down through menu bars.
4. Press the button to enter. Press the
button to back to menu bars.
5. Press the and buttons to select
options.
6. Press the button to confirm your
choice.
7. Press the button to exit the setup
menu.
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
SETUP
1/3
.
Date /Time
2007.01.01
00:00:00
YY.MM.DD
17
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting the Date and Time
1. Access the setup menu.
2. Press or button to select
(Date / Time).
3. Press the button to enter.
4. Press the or button to select a field,
such as year, month, day, hour, minute,
and date format.
5. Press or button to adjust the
value in the field and select the date
format.
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
SETUP
1/3
.
Date /Time
2007.01.01
00:00:00
YY.MM.DD
6. Press the button to confirm your
choice.
NOTE:
• This setting is also available in
(Video) mode.
Need help with your digital camera?
Call our toll-free customer service number. Look for the insert with this icon:
Or visit www.polaroid.com.
18
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting Auto Power Off
The camera performs the following power save operation to conserve
battery power.
1. Access the setup menu.
SETUP
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
1/3
.
Auto Power Off
Off
1 Minute
3 Minutes
2. Press the or button to select
(Auto Power Off).
3. Press the button to enter.
4. Press or to select the desired
setting.
5. Press the button to confirm your
choice.
1 MINUTE The camera is designed to power off
automatically to save battery life after the
specified period of inactivity.
3 MINUTES The camera will enter power saving mode
automatically after 1 minute’s inactivity and
power off after 3 minutes’ inactivity.
OFF The power saving function is not active.
NOTE:
Auto power off is automatically disabled under any one of the following
conditions:
• While the camera is recording a video clip.
• While the camera is running a slide show.
19
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting the Beep Sound
The beep sound can be turned on and off in the SETUP menu. When the
beep sound is turned on, the camera will beep when you press any of the
buttons.
1. Access the setup menu.
2. Press the or button to select
(Beep Sound).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
SETUP
1/3
.
Beep Sound
Off
On
• Adjusting the Volume Control
Volume can be adjusted for beep sounds and video clips.
1. Access the setup menu.
2. Press the or button to select
(Volume).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Date /Time
Auto Power Off 1 Minute
Beep Sound On
Volume
Video System LCD
1/3
.
Volume
20
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting the Display Language
Using this setting, you can select the language you prefer for the LCD
screen.
1. Access the setup menu.
2. Press the or button to select
(Language).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Language English
Date Stamp Off
LCD Brightness
Format Internal Memory
Sequence No. Off
2/3
Language
1/4
English
Deutsch
Français
Español
Italiano
Language
2/4
Português
日本语
简体中文
Nederlands
Polski
21
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Setting the Date Stamp
Use the date stamp setting to imprint the date on your pictures. Make sure
the date is correct before setting the date stamp to be on.
1. Access the setup menu.
2. Press the or button to select
(Date Stamp).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Language English
Date Stamp Off
LCD Brightness
Format Internal Memory
Sequence No. Off
2/3
Date Stamp
Date / Time
Date
Off
• Adjusting the LCD Brightness
This setting enables you to adjust the brightness for the LCD screen.
1. Access the setup menu.
2. Press the or to select (LCD
Brightness).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Language English
Date Stamp Off
LCD Brightness
Format Internal Memory
Sequence No. Off
2/3
LCD Brightness
22
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Turning Sequence Number On / Off
The instructions below show how to select the way file numbers are
assigned.
1. Access the setup menu.
2. Press the or to select
(Sequence No.).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Language English
Date Stamp Off
LCD Brightness
Format Internal Memory
Sequence No. Off
2/3
Sequence No.
Off
On
ON The file numbers are reassigned to the start each time when any images are
removed from the memory card or internal memory is formatted. New images
recorded on the memory card with existing files are given the next available
number.
OFF A file number is assigned to a recorded image and memorized and images
recorded onto a memory card start from the next number.
23
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Resetting back to Factory Defaults
If would like to go back to the original camera settings do the following
steps: (For more guidelines, please see “Camera Default Settings” on page
113).
1. Access the setup menu.
2. Press the or to select ICON
(Default Settings).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Default Setting
Opening On
Storage Media Auto
3/3
Default Setting
Return menu setting
to default?
Cancel
OK
NOTE:
Selecting CANCEL will cancel the operation and exit from the menu
window.
Need help with your digital camera?
Call our toll-free customer service number. Look for the insert with this icon:
Or visit www.polaroid.com.
24
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Cancelling the Startup Image
A startup animation image appears on the LCD
screen for a few seconds when the camera is
turned on.
You may cancel displaying the startup image
by performing the following steps:
1. Access the setup menu.
2. Press the or to select
(Opening).
3. Press the button to enter.
4. Press the or button to select the
desired setting.
5. Press the button to confirm your
choice.
SETUP
Default Setting
Opening On
Storage Media Auto
3/3
Opening
Off
On
25
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Choosing the Media for Storage
You can choose your preferred media for images or video clips storage.
1. Access the setup menu.
2. Press the or to select
(Storage Media).
3. Press the button to enter.
4. Press the or button to select
the desired setting.
5. Press the button to confirm your
choice.
SETUP
Default Setting
Opening On
Storage Media Auto
3/3
Storage Media
Auto
Internal Memory
SD Card
Auto Images and video clips are stored on SD card if
present otherwise the camera selects internal
memory.
Internal Memory The images or video clips will be stored in internal
memory first.
SD Card The images or video clips will be stored in SD card
first.
26
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Turning the Information Display On/Off
Press the button each time switches
the LCD screen to the next display mode in
the following mode.
LCD Screen On/Off Button
Still Image Mode
Press Press
Press
27
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
Video Mode
Press
Press
Press
Playback Mode
Press Press
Press
Press
Press Press
28
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
3 Taking Pictures
Before you take pictures, please read this note first:
NOTE:
Never open the battery/SD card door while a picture is being saved. Doing so
will prevent the current picture from being saved and may corrupt other pictures
already stored on the camera’s internal memory or a memory card.
• Taking Pictures in Normal Mode
You can take pictures at approximately 1.6 feet (50cm) to infinity.
NOTE:
Most settings are saved by the camera when the power is turned off, so that the
same setting is automatically available when the power is turned on again. Make
sure you verify your settings when turning the camera on again.
1. Press the button to set the camera to Still Image mode.
2. Frame your subject while viewing the LCD screen.
3 Press the Shutter button halfway to set the exposure and focus.
Auto Focus LED
Focus Frame
Shutter Speed
Aperture Value
29
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
NOTE:
•
(Still Image) mode is the capture mode by default.
• The LCD screen will show you the aperture value and shutter speed at which
you take the picture.
• If the shutter speed is slow or that the image maybe blurred, the shake
warning icon may appear on the LCD screen. To avoid this situation, the
use of a tripod is recommended or turn on the ash.
4. Hold the camera steady and slowly press the shutter button down to
take your image.
30
Polaroid i1035 Digital Camera User Guide
www.polaroid.com
• Taking Pictures in the Macro Mode
Use this mode to capture subjects very close to the lens:
Wide Angle: 0.3 ~ 1.6 ft (10 cm ~ 50 cm)
Telephoto: 1.1 ~ 2.6 ft (35 cm ~ 80 cm)
1. Set the camera to Still Image mode.
2. Press the button and the icon appears
on the LCD screen.
3. Capture procedures are the same as for
taking a picture in the normal capture
mode. See page 28.
Macro
Loading...
