Indoors
Battery Operated
Decoration
LED Christmas candles with
remote control, set of 20
Item no. 1678568
Intended use
The 20 battery-operated LED candles are designed to provide
decorative lighting in indoor areas . Each is operated by one
AAbattery. You can use the remote control to select a number of
dierent modes (e.g. constant, dim or flicker mode).
For safety and approval purposes, you must not rebuild and/or
modify this product. Using the product for purposes other than
those described above may damage the product. In addition,
improper use can cause hazards such as a short circuit or fire.
Read the instructions carefully and store them in a safe place.
Make this product available to third parties only together with its
operating instructions.
This product complies with statutory national and European
regulations. All company and product names are trademarks of
their respective owners. All rights reserved.
Delivery content
• Christmas candles, set of 20
• Remote control (incl. CR2025 button cell)
• Operating Instructions
Safety instructions
Read the operating instructions and safety information
carefully. If you do not follow the safety instructions
and information on proper handling in this manual, we
assume no liability for any resulting personal injury
or damage to property. Such cases will invalidate the
warranty/guarantee.
a) Persons / Product
• This product is not a toy. Keep it out of the reach of children
and pets.
• Do not leave packaging material lying around carelessly, as it
may become dangerous playing material for children.
• Always check the product for damages before use. Should you
discover any damage, cease use of the product.
• Protect the product from extreme temperatures, direct sunlight,
strong jolts, high humidity, moisture, flammable gases, vapours
and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, stop
using it and prevent unauthorized use. Safe operation can no
longer be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in poor ambient
conditions or
– has been subjected to any serious transport-related stress.
• Always handle the product carefully. Jolts, impacts or a fall even
from a low height may damage the product.
• The LED heats up during use. Keep the product away from
highly combustible materials while operating.
• This product is designed to be used indoors only.
• Do not expose the remote control to high humidity or moisture.
• Warning, LED light:
– Do not look directly at the LED light!
– Do not look into the beam directly or with optical instruments!
b) Batteries
• Correct polarity must be observed while inserting the batteries.
• Remove the batteries if you are not using the product for a
long period of time to prevent damage due to leaks. Leaking
or damaged batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves to handle
corrupted batteries.
• Batteries must be kept out of reach of children. Do not leave
batteries lying around, as there is risk, that children or pets
swallow them.
• Batteries must not be dismantled, short-circuited or thrown into
fire. Never recharge non-rechargeable batteries. There is a risk
of explosion!
c) Miscellaneous
• Maintenance, modifications and repairs must be done by a
technician or an authorized repair center.
• If you have questions which remain unanswered by these
operating instructions, contact our technical support service or
other technical personnel.
Operating Instructions
Page 2
Product overview
1.8 cm
2
3
4
5
6
Remote control
1 IR transmitter
1
2 ON button
3 SL button
9
8
12 cm
7
ON+ SL
OFF- FL
LED Remote Control
4 OFF button
5 FL button
6 Battery compartment
(backside)
7 - button
8 + button
9 IR receiver
(notdepicted)
4.2 cm
Operation
The product must not be used in or under water.
Do not operate the product if it is still in its packaging.
Do not hang any objects from the product and do not
cover the product.
The LEDs are not replaceable.
1. Remove the product from the packaging.
2. Hold the candle and turn the candle head anticlockwise to
open the battery compartment.
3. Insert one AA battery into the candle, ensuring that you
insert the negative pole (-) first. We recommend using highquality batteries.
4. Turn the candle head clockwise as far as it will go to close the
battery compartment.
5. Ensure that the candle is in a secure position in the candle
holder.
6. Follow steps 2 to 5 to put all the other candles into operation.
7. Attach the candles, for example, to your Christmas tree.
Ensure stability when clamping the candles onto branches of
the tree.
8. Use the remote control to control the candles (see “Remote
control”).
9. Turn o the candles using the remote control and then
remove the batteries when not using the candles for a longer
period of time.
Replace the battery if the LED does not turn on.
Remote control
Pull the safety strip from the battery compartment (6) of the
remote control before first time use.
• Ensure that there are no objects between the IR transmitter (1)
and the candles.
• If the candles do not turn on at the same time, move closer to
the candles and ensure that the remote control is pointing in
the right direction.
• The operating range of the remote control depends on the
ambient conditions and the battery capacity.
• Replacing the battery is required when the operating range of
the remote control drops significantly or if the candles cannot
be operated when pressing any button.
• Remove the battery holder from the battery compartment (6)
as shown on the back of the remote control, and then remove
the old battery.
• Insert a coin cell battery of type CR2025 into the battery holder,
making sure the positive terminal (“+” marking on the battery)
faces up.
• Slide the battery holder back into the battery compartment
until it clicks into place.
Description of buttons
ON button (2)
Turn on candles / constant lighting
function
OFF button (4) Turn o candles
+ (8) / - button (7) Increases / decreases the brightness
SL (3) / FL button (5) Slow / fast flickering mode
Care and cleaning
• Turn o the product and let it cool down suciently before
cleaning. Remove the batteries before cleaning.
• Under no circumstances use aggressive cleaning agents,
cleaning alcohol or other chemical solutions, as the material can
be attacked as a result, or the function can even be impaired.
• To clean, use a clean, dry, lint-free cloth. For stubborn dirt,
slightly dampen the cloth with water. Allow the product to dry
completely before continued use.
Technical data
a) Per candle
Protection type .................. IP20
Power supply ....................... 1 x 1.5 V battery, type AA
LED power ............................ 0.06 W
Luminous colour ................ Warm White
Operating conditions ...... 0 to +40 °C / 0 – 90 % RH
Storage conditions ........... 0 to +40 °C / 0 – 90 % RH
Weight .................................... 13 g
b) Remote control
Power supply ....................... 1 x 3 V lithium battery, type CR2025
Range ...................................... max. 5 m
Disposal
a) Product
Electronic devices are recyclable waste and must not
be placed in household waste. Always dispose of the
product according to the relevant statutory regulations.
Remove any inserted batteries and dispose of them
separately from the product.
b) Batteries
You as the end user are required by law (Battery
Ordinance) to return all used batteries. Disposing of
them in the household waste is prohibited.
Batteries that contain hazardous substances are labelled with
this symbol to indicate that disposal in household waste is
forbidden. The abbreviations for heavy metals in batteries are: Cd
= Cadmium, Hg = Mercury, Pb = Lead (indicated on the battery,
e.g. below the waste icon on the left).
Used batteries can be returned to local collection points, our
stores or battery retailers.
You thus fulfil your statutory obligations and contribute to the
protection of the environment.
