Polaris Scrambler 9921298 User Manual
WARNING
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
A card containing important ATV safety information should be attached
to the owner’s manual on the next page. If you cannot locate this card,
or if it has been removed, please call 1-800-342-3764 for assistance.
WELCOME
Thank you for purchasing a Polaris vehicle, and welcome to our
world-wide family of Polaris owners. We proudly produce an exciting
line of utility and recreational products.
S Snowmobiles
S All-terrain vehicles (ATVs)
S RANGER utility vehicles
S Victory motorcycles
We believe Polaris sets a standard of excellence for all utility and
recreational vehicles manufactured in the world today. Many years of
experience have gone into the engineering, design, and development of
your Polaris vehicle, making it the finest machine we’ve ever
produced.
For safe and enjoyable operation of your vehicle, be sure to follow the
instructions and recommendations in this owner’s manual. Your
manual contains instructions for minor maintenance, but information
about major repairs is outlined in the Polaris Service Manual and
should be performed only by a Factory Certified Master Service Dealer
(MSD) Technician.
Your Polaris dealer knows your vehicle best and is interested in your
total satisfaction. Be sure to return to your dealership for all of your
service needs during, and after, the warranty period.
We also take great pride in our complete line of apparel, parts and
accessories, available through our online store at
www.purepolaris.com. Have your accessories and clothing delivered
right to your door!
1
Copyright 2007 Polaris Sales Inc. All information contained within this publication is
based on the latest product information at the time of publication. Due to constant
improvements in the design and quality of production components, some minor
discrepancies may result between the actual vehicle and the information presented in this
publication. Depictions and/or procedures in this publication are intended for reference
use only. No liability can be accepted for omissions or inaccuracies. Any reprinting or
reuse of the depictions and/or procedures contained within, whether whole or in part, is
expressly prohibited.
Printed in U.S.A.
2008 Scrambler 500 4X4 Owner’s Manual P/N 9921298
2
TABLE OF CONTENTS
VEHICLE IDENTIFICATION NUMBERS 5.......
SAFETY 6...................................
FEATURES AND CONTROLS 31...............
OPERAT ION 43..............................
EMISSION CONTROL SYSTEMS 61............
MAINTENANCE 62...........................
SPECIFICATIONS 110........................
POLARIS PRODUCTS 113....................
TROUBLESHOOTING 114.....................
WARRANTY 118.............................
MAINTENANCE LOG 122.....................
INDEX 125...................................
3
4
VEHICLE IDENTIFICATION NUMBERS
Record your ATV’s identification numbers and key number in the
spaces provided. Remove the spare key and store it in a safe place. An
ignition key can be duplicated only by ordering a Polaris key blank
(using your key number) and mating it with one of your existing keys.
The ignition switch must be replaced if all keys are lost.
31XX
1
Vehicle Model Number:
Frame VIN (1):
Engine Serial Number (right front side of engine crankcase):
Key Number (2):
2
5
SAFETY
Operator Safety
WARNING
Failure to follow the warnings contained in this manual can result
in serious injury or death.
A Polaris ATV is not a toy and can be hazardous to operate. This
vehicle handles differently than other vehicles, such as
motorcycles and cars. A collision or rollover can occur quickly,
even during routine maneuvers like turning, or driving on hills or
over obstacles, if you fail to take proper precautions.
Read and understand your owner’s manual and all warnings
before operating a Polaris ATV.
Age Restrictions
This vehicle is an ADULT VEHICLE ONLY. Operation is prohibited
for anyone under 16 years of age.
Know Your Vehicle
As the operator of the vehicle, you are responsible for your personal
safety, the safety of others, and the protection of our environment.
Read and understand your owner’s manual, which includes valuable
information about all aspects of your vehicle, including safe operating
procedures.
Safety Training
ATV safety training i s a top priority for Polaris. When you purchased
your new ATV, your dealer instructed you on the authorized ATV
RiderCourse
This training is included in the purchase price of your ATV. Polaris
strongly encourages you and your eligible family members who will be
riding the ATV to take the ATV RiderCourse
provided with printed materials that explain safe operating procedures.
You should review this information on a regular basis.
If you purchased a used Polaris ATV, you can take the ATV
RiderCourse
or by visiting www.atvsafety.org. Purchasers of a used Polaris ATV
will be charged for this training.
A Polaris ATV is an off-road vehicle. Familiarize yourself with all
laws and regulations concerning the operation of the ATV in your area.
We strongly advise you to strictly follow the recommended
maintenance program outlined in your owner’s manual. This
preventive maintenance program is designed to ensure that all critical
components on your vehicle are thoroughly inspected at specific
intervals.
sm
available to you and your eligible family members.
sm
.Youwerealso
sm
by calling ATV Enrollment Express at (800) 887-2887
6
SAFETY
Operator Safety
The following signal words and symbols appear throughout this
manual and on your ATV. Your safety is involved when these words
and symbols are used. Become familiar with their meanings before
reading the manual.
The safety alert symbol, on your vehicle or in this manual, alerts
you to the potential for personal injury.
WARNING
The safety alert warning indicates a potential hazard that may
result in serious injury or death.
CAUTION
The safety alert caution indicates a potential hazard that may
result in minor personal injury or damage to the vehicle.
CAUTION
A caution indicates a situation that may result in damage to the
vehicle.
NOTE:
A note will alert you to important information or instructions.
7
SAFETY
Operator Safety
WARNING
Serious injury or death can result if you do not follow these
instructions and procedures, which are outlined in further detail
within your owner’s manual.
S Read this manual and all labels carefully, and follow the operating
procedures described.
S Never operate an ATV without proper instruction. Take a training
course. Purchasers of a new Polaris ATV and their eligible family
members are entitled to take the ATV RiderCourse
Enrollment Express at (800) 887-2887 or visit www. atvsafety.org for
information on enrollment in the ATV RiderCourse
S Never allow anyone under 16 years of age to operate this ATV.
S Never permit a guest to operate the ATV unless the guest has read
this manual and all product labels and has completed a certified safety training course.
S Always avoid operating an ATV on paved surfaces, including side-
walks, driveways, parking lots, and streets.
S Never operate an ATV on a public street, road or highway, including
a dirt or gravel road.
S Never operate an ATV without wearing an approved helmet that fits
properly. Always wear eye protection (goggles or face shield),
gloves, boots, a long-sleeved shirt or jacket, and long pants.
S Never consume alcohol or drugs before or while operating an ATV.
S Never operate at excessive speeds. Travel at speeds appropriate for
the terrain, visibility and operating conditions, and your experience.
S Never attempt wheelies, jumps or other stunts.
S Always inspect your ATV before each use to make sure it’ s in safe
operating condition. Always follow the inspection and maintenance
procedures and schedules outlined in your owner’s manual.
S Always keep both hands on the handlebars and both feet on the foot-
rests of the ATV during operation.
S Always travel slowly and use extra caution when operating on unfa-
miliar terrain. Be alert to changing terrain conditions.
S Never operate on excessively rough, slippery, or loose terrain.
S Always follow proper turning procedures as described in this manu-
al. Practice turning at low speeds before attempting to t urn at faster
speeds. Do not turn at excessive speeds.
sm
. Contact ATV
sm
.
8
SAFETY
Operator Safety
S Always have the ATV inspected by an authorized Polaris dealer if
it’s been involved in an accident.
S Never operate on hills too steep for the ATV or for your abilities.
Practice on smaller hills before attempting larger hills.
S Always follow proper procedures for climbing hills. Check the ter-
rain carefully before ascend a hill. Never climb hills with excessively slippery or loose surfaces. Shift your weight forward. Never open
the throttle suddenly or make sudden gear changes. Never go over
the top of a hill at high speed.
S Always follow proper procedures for going downhill and for braking
on hills. Check the terrain carefully before you start down a hill.
Shift your weight backward. Never go down a hill at high speed.
Avoid going down a hill at an angle, which would cause the vehicle
to lean sharply t o one side. Travel straight down the hill when possible.
S Always follow proper procedures for crossing the side of a hill.
Avoid hills with excessively slippery or loose surfaces. Shift your
weight to the uphill side of the ATV. Never attempt to turn the ATV
around on any hill until you’ve mastered (on level ground) the turning technique outlined in this manual. Avoid crossing the side of a
steep hill when possible.
S Always use proper procedures if you stall or roll backwards while
climbing a hill. To avoid stalling, maintain a steady speed when
climbing a hill. If you stall or roll backwards, follow the special procedure for braking described in this manual. Always dismount on the
uphill side, or to either side if the ATV is pointed straight uphill.
Turn the ATV around and remount following the procedure described in this manual.
S Always check for obstacles before operating in a new area. Never
attempt to operate over large obstacles, such as rocks or fallen trees.
Always follow proper procedures when operating over obstacles as
described in this manual.
S Always be careful of skidding or sliding. On slippery surfaces like
ice, travel slowly and use extra caution to reduce the chance of skidding or sliding out of control.
S Avoid operating the ATV through deep or fast-flowing water. If it’s
unavoidable, travel slowly, balance your weight carefully, avoid sudden movements, and maintain a slow and steady forward motion. Do
not make sudden turns or stops, and do not make sudden throttle
changes.
9
SAFETY
Operator Safety
S Wet brakes m ay have reduced stopping ability. Test your brakes after
leaving water. If necessary, apply them lightly several times to allow
friction to dry out the pads.
S Always check for obstacles or people behind the ATV before operat-
ing in reverse. When it’s safe to proceed in reverse, move slowly and
avoid turning at sharp angles.
S Always use the size and type of tires specified for your ATV, and
always maintain proper tire pressure.
S Never modify an ATV through improper installation or use of acces-
sories.
S Never exceed the stated load capacity for your ATV. Cargo must be
properly distributed and securely attached. Reduce speed and follow
the instructions in this manual for carrying cargo or towing. Allow a
greater distance for braking.
S Always remove the i gnition key when the vehicle is not in use to
prevent unauthorized use or accidental starting.
FOR MORE INFORMATION ABOUT ATV SAFETY, call the Consumer Product Safety Commission at 1-800-638-2772, or visit
www.cpsc.gov, visit www.atvsafety.org, or call
Polaris at 1-800-342-3764.
Equipment Modifications
We are concerned for the safety of our customers and for the general
public. Therefore, we strongly recommend that consumers do not
install on a Polaris ATV any equipment that may increase the speed or
power of the vehicle, or make any other modifications to the vehicle
for these purposes. Any modifications to the original equipment of the
vehicle create a substantial safety hazard and increase the risk of bodily
injury.
The warranty on your Polaris ATV is terminated if any equipment has
been added t o the vehicle, or if any modifications have been made to
the vehicle, that increase its speed or power.
NOTE: The addition of certain accessories, including (but not limited
to) mowers, blades, tires, sprayers, or large racks, may
change the handling characteristics of the vehicle. Use only
Polaris-approved accessories, and familiarize yourself with
their function and effect on the vehicle.
10
Operator Safety
WARNING
POTENTIAL HAZARD
Operating this ATV without proper instruction.
WHAT CAN
The risk of an accident is greatly increased if the operator does
not know how to operate the ATV properly in different situations
and on different types of terrain.
HOW TO AVOID THE
Beginning and inexperienced operators should complete the ATV
RiderCourse
then regularly practice the skills learned in the course and the
operating techniques described in the Owner’s Manual.
For more information about the ATV RiderCourse
Enrollment Express at (800) 887-2887 or visit www.atvsafety.org.
HAPPEN
HAZARD
sm
offered by Polaris through the SVIA. They should
sm
WARNING
POTENTIAL HAZARD
Failure to follow the age recommendations for this ATV.
WHAT CAN
Severe injury and/or death could occur if a child under the
minimum age recommendation operates an ATV.
Even though a child may be within the recommended age group
for operating some ATVs, he/she may not have the skills,
abilities, or judgment needed to operate an ATV safely and could
be susceptible to accident or injury.
HOW TO AVOID THE
No one under the age of 16 should operate a Polaris ATV.
HAPPEN
HAZARD
SAFETY
contact ATV
11
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Carrying a passenger on an
ATV.
WHAT CAN
Carrying a passenger
greatly reduces the
operator’s ability to balance
and control the ATV, which
could cause an accident
and injury to the
operator and/or passenger.
HOW TO AVOID THE
Never carry a passenger. The purpose of the long seat is to
allow the operator to shift position as needed during operation. It
is not intended for carrying passengers.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Operating an ATV
on paved
surfaces, including
sidewalks, paths,
parking lots, and
driveways.
WHAT CAN
ATV tires are designed for
off-road use. Operating on
paved surfaces may
seriously affect the handling and
control of the ATV and could result in loss of control, accident,
and/or injury.
HOW TO AVOID THE
Avoid operating the ATV on pavement. If it’s unavoidable, travel
slowly and avoid sudden turns or stops.
HAPPEN
HAZARD
12
Operator Safety
WARNING
POTENTIAL HAZARD
Operating this ATV on
public streets, roads or
highways.
WHAT CAN
The ATV could collide
with another vehicle.
HOW TO AVOID THE
Never operate the ATV on any
public street, road or highway,
including dirt and gravel roads. In many states
it’s illegal to operate ATVs on public streets, roads and highways.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Operating this ATV without
wearing an approved
helmet, eye protection and
protective clothing.
WHAT CAN
Operating an ATV without
an approved helmet
increases the risk of a
severe head injury or
death in the event of an
accident.
Operating without eye protection could result in an accident and
could increase the chance of a severe injury in the event of an
accident.
HOW TO AVOID THE
Always wear an approved helmet that fits properly.
Always wear eye protection (goggles or face shield), gloves,
boots, long-sleeved shirt or jacket, and long pants.
HAPPEN
HAZARD
SAFETY
13
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Operating the ATV after consuming
alcohol or drugs.
WHAT CAN
Consumption of alcohol and/or drugs
could seriously affect operator
judgment. Reaction time may be slower
and operator balance and perception
could be affected.
Consuming alcohol and/or drugs before
or while operating an ATV could result in
an accident causing severe injury or death.
HOW TO AVOID THE
Never consume alcohol or drugs before or while operating an
ATV.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Operating the ATV at excessive speeds.
WHAT CAN
Excessive speed increases the operator’s chance of losing
control of the ATV, which can result in an accident.
HOW TO AVOID THE
Always operate the ATV at a speed that’s proper for the terrain,
visibility and operating conditions, and your experience.
HAPPEN
HAZARD
14
Operator Safety
WARNING
POTENTIAL HAZARD
Attempting wheelies, jumps
and other stunts.
WHAT CAN
Attempting stunts increases
the chance of an accident,
including an overturn.
HOW TO AVOID
HAZARD
Never attempt wheelies,
jumps, or other stunts. Avoid
exhibition driving.
HAPPEN
THE
WARNING
POTENTIAL HAZARD
Failure to inspect the ATV before operating.
Failure to properly maintain the ATV.
WHAT CAN
Poor maintenance increases the possibility of an accident or
equipment damage.
HOW TO AVOID THE
Always inspect your ATV before each use to make sure it’s in
safe operating condition.
Always follow the inspection and maintenance procedures and
schedules described in the owner’s manual.
HAPPEN
HAZARD
SAFETY
15
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Removing hands from the handlebars or feet from the footrests
during operation.
WHAT CAN
Removing even one hand or foot can reduce ability to control the
vehicle or could cause loss of balance and ejection from the ATV.
If the operator’s foot is not firmly planted on the footrest, it could
come into contact with the rear wheels and lead to accident or
injury.
HOW TO AVOID THE
Always keep both hands on the handlebars and both feet on the
footrests of the ATV during operation.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Failure to use extra
caution when operating
the ATV on unfamiliar
terrain.
WHAT CAN
Unfamiliar terrain may
contain hidden rocks,
bumps, or holes that could
cause loss of control or
overturn.
HOW TO AVOID THE
Travel slowly and use extra caution when operating on unfamiliar
terrain. Always be alert to changing terrain conditions.
HAPPEN
HAZARD
16
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Failure to use extra
caution when operating on
excessively rough,
slippery or loose terrain.
WHAT CAN
Operating on excessively
rough, slippery or loose
terrain could cause loss of
traction or loss of control,
which could result in an
accident or overturn.
HOW TO AVOID THE
Do not operate on excessively rough, slippery or loose terrain
until you’ve learned and practiced the skills necessary to control
the ATV on such terrain.
Always use extra caution on rough, slippery or loose terrain.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Turning improperly.
WHAT CAN
Improper turns could cause loss of control and lead to a collision
or overturn.
HOW TO AVOID THE
Always follow proper procedures for turning as described in the
owner’s manual.
Practice turning at slow speeds before attempting to turn at faster
speeds.
Never turn at excessive speed.
HAPPEN
HAZARD
17
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Operating on excessively steep hills.
WHAT CAN
The vehicle may overturn.
HOW TO AVOID THE
Never operate on hills too steep for the ATV or for your abilities.
Never operate the ATV on hills steeper than 25_.
Practice on smaller hills before attempting large hills.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Climbing hills improperly.
WHAT CAN
Improper hill climbing could
cause loss of control or
overturn.
HOW TO AVOID
HAZARD
Always follow proper
procedures for climbing
hills as described in the
owner’s manual.
Always check the terrain
carefully before ascending
any hill.
Never operate the ATV on hills steeper than 25_.
Never climb hills with excessively slippery or loose surfaces.
Shift your weight forward.
Never open the throttle suddenly while traveling uphill. The ATV
could flip over backwards.
Never go over the top of any hill at high speed. An obstacle, a
sharp drop, or another vehicle or person could be on the other
side of the hill.
HAPPEN
THE
18
Operator Safety
WARNING
POTENTIAL HAZARD
Traveling downhill
improperly.
WHAT CAN
Improperly descending a hill
could cause loss of control
or overturn.
HOW TO AVOID
HAZARD
Always follow proper
procedures for traveling
down hills as described in
the owner’s manual. NOTE:
A special technique is
required when braking while
traveling downhill. See page 55.
Always check the terrain carefully before descending a hill.
Shift your weight backward.
Never travel down a hill at high speed.
Avoid traveling down a hill at an angle, which would cause the
vehicle to lean sharply to one side. Travel straight down the hill
when possible.
HAPPEN
THE
SAFETY
19
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Improperly crossing hills and
turning on hills.
WHAT CAN
Improperly crossing or
turning as hills could cause
loss of control or overturn.
HOW TO AVOID
HAZARD
Neverattempttoturnthe
ATV around on any hill until
you’ve mastered the turning
technique (on level ground)
as described in the owner’s
manual. See page 56. Use
extra caution when turning
on any hill.
Avoid crossing the side of a steep hill.
When crossing the side of a
Always follow proper procedures as described in the owner’s
manual.
Avoid hills with excessively slippery or loose surfaces.
Shift your weight to the uphill side of the ATV .
HAPPEN
THE
hill:
20
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Stalling, rolling backwards
or improperly dismounting
while climbing a hill.
WHAT CAN
The vehicle could overturn.
HOW TO AVOID
HAZARD
Maintain steady speed
when climbing a hill.
If all forward speed is
Keep your weight uphill.
Apply the single lever brake gradually.
When fully stopped, apply the auxiliary rear brake as well, then
lock the parking brake.
If the ATV begins rolling
Keep weight uphill.
Never apply engine power.
Never apply the auxiliary rear brake while rolling backwards.
Apply the single-lever brake gradually.
When fully stopped, apply the auxiliary rear brake as well, and
then lock the parking brake.
Dismount on uphill side, or to either side if ATV is pointed straight
uphill.
Turn the ATV around and remount, following the procedure
described in the owner’s manual. See page 56.
HAPPEN
THE
lost:
backwards:
21
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Improperly operating over obstacles.
WHAT CAN
Operating over obstacles could cause loss of control or overturn.
HOW TO AVOID THE
Before operating in a new area, check for obstacles.
Avoid operating over large obstacles such as rocks and fallen
trees when possible. If unavoidable, use extreme caution and
always follow proper procedures as outlined in the owner’s
manual.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Skidding or sliding.
WHAT CAN
Skidding or sliding can cause loss of control.
If the tires regain traction unexpectedly, the ATV could overturn.
HOW TO AVOID THE
On slippery surfaces such as ice, travel slowly and use extra
caution to reduce the chance of skidding or sliding out of control.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Improperly operating in reverse.
WHAT CAN
The ATV could collide with an obstacle or person, resulting in
severe injury.
HOW TO AVOID THE
Before shifting into reverse gear, always check for obstacles or
people behind the ATV. When it’s safe to proceed, back slowly.
22
HAPPEN
HAZARD
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Operating the ATV through deep or fast-flowing water.
WHAT CAN
Tires may float, causing loss of traction and loss of control, which
could lead to an accident or overturn.
HOW TO AVOID THE
Avoid operating the ATV through deep or fast-flowing water. If it’s
unavoidable to enter water that exceeds the recommended
maximum depth (see page 57), travel slowly, balance your weight
carefully, avoid sudden movements, and maintain a slow and
steady forward motion. Do not make sudden turns or stops, and
do not make sudden throttle changes.
Wet brakes may have reduced stopping ability. Always test the
brakes after leaving water. If necessary, apply them several
times to let friction dry out the pads.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Operating this ATV with improper tires, or with improper or
uneven tire pressure.
WHAT CAN
Use of improper tires, or operation of the ATV with improper or
uneven tire pressure, could cause loss of control or accident.
HOW TO AVOID THE
Always use the size and type of tires specified for the ATV.
Always maintain proper tire pressure as specified.
HAPPEN
HAZARD
23
SAFETY
Operator Safety
WARNING
POTENTIAL HAZARD
Operating the ATV with improper modifications.
WHAT CAN
Improper installation of accessories or modification of the ATV
may cause changes in handling which could lead to an accident.
HOW TO AVOID THE
Never modify the ATV through improper installation or use of
accessories. All parts and accessories added to the vehicle must
be genuine Polaris Industries Inc. or equivalent components
designed for use on this ATV and should be installed and used
according to approved instructions. See your authorized Polaris
ATV dealer for more information.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Overloading the ATV or carrying/towing cargo improperly.
WHAT CAN
Overloading and towing can cause changes in vehicle handling,
which could lead to loss of control or an accident.
HOW TO AVOID THE
Never exceed the stated load capacity for this ATV.
Cargo should be properly distributed and securely attached.
Reduce speed when carrying cargo or pulling a trailer. Allow a
greater distance for braking.
Always follow the instructions in the owner’s manual for carrying
cargo or pulling a trailer. See page 48.
HAPPEN
HAZARD
WARNING
POTENTIAL HAZARD
Operating on frozen bodies of water.
WHAT CAN
Severe injury or death can result if the ATV and/or the operator
fall through the ice.
HOW TO AVOID THE
Never operate the ATV on a frozen body of water.
24
HAPPEN
HAZARD
SAFETY
Operator Safety
WARNING
Leaving the keys in the ignition can lead to unauthorized use of
the vehicle resulting in serious injury or death. Always remove
the ignition key when the vehicle is not in use.
WARNING
After any overturn or accident, have a qualified service dealer
inspect the entire vehicle for possible damage, including (but not
limited to) brakes, throttle and steering systems.
WARNING
Safe operation of this rider-active vehicle requires good
judgement and physical skills. Persons with cognitive or physical
disabilities who operate this vehicle have an increased risk of
overturn and loss of control, which could result in severe injury or
death.
CAUTION
Exhaust system components are very hot during and after use of
the vehicle. Hot components can cause serious burns and fire.
Do not touch hot exhaust system components. Always keep
combustible materials away from the exhaust system. Use
caution when traveling through tall grass, especially dry grass.
25
SAFETY
Fuel Safety
WARNING
Gasoline is highly flammable and explosive under certain
conditions.
S Always exercise extreme caution whenever handling gasoline.
S Always refuel with the engine stopped, and outdoors or in a well
ventilated area.
S Do not smoke or allow open flames or sparks in or near the
area where refueling is performed or where gasoline is stored.
S Do not overfill the tank. Do not fill the tank neck.
S If gasoline spills on your skin or clothing, immediately wash it off
with soap and water and change clothing.
S Never start the engine or let it run in an enclosed area.
Engine exhaust fumes are poisonous and can cause loss of
consciousness or death in a short time.
S Turn the fuel valve off whenever the ATV is stored or parked.
WARNING
The engine exhaust from this product contains chemicals known
to cause cancer, birth defects or other reproductive harm.
Operate this vehicle only outdoors or in well-ventilated areas.
26
1
SAFETY
Safety Decals and Locations
Warning decals have been placed on the ATV for your protection. Read
and follow the instructions of the decals on the ATV carefully. If any
of the decals depicted in this manual differ from the decals on your
ATV, always read and follow the instructions of the decals on the ATV.
If any decal becomes illegible or comes off, contact your Polaris dealer
to purchase a replacement. Replacement safety decals are provided by
Polaris at no charge. The part number is printed on the decal.
Discretionary Warning (1)
WARNING
S Never operate this vehicle on
HILLS steeper than 25 degrees
25°. To prevent flipover on
hilly terrain, when going up or
down, use throttle and brakes
gradually.
S REVERSE operation can be
dangerous, even at low speeds.
Steering becomes difficult. To
prevent flipover, avoid sudden
braking or sharp turns.
S Use OVERRIDE for reverse
speed limiter with caution. To
prevent loss of control, never activate
override button with open throttle.
S PARKING BRAKE may relax when used
for more than 5 minutes. When parking on grades, leave shift in forward.
2
Clutch Cover Warning ( 2)
WARNING
NO STEP
S Moving parts hazard under belt-clutch guard. To prevent serious injury, do
not operate vehicle with guard removed.
S Do not modify engine or clutch. Doing so can cause part failure, possible im-
balance, and excessive engine RPM, which can result in serious injury or
death.
27
Loading...
