Благодарим Вас за выбор продукции, выпускаемой под торговой маркой “POLARIS”. Наши
изделия разработаны в соответствии с высокими требованиями, предъявляемыми к качеству,
функциональности и дизайну. Многолетний опыт производства по европейским стандартам,
использование современных материалов, новых конструктивных решений и технологий
гарантируют надежность в эксплуатации и долговечность водонагревателя. Мы уверены, что Вы
будете довольны приобретением изделия торговой марки “POLARIS”.
Перед началом эксплуатации прибора внимательно прочитайте данную инструкцию, в которой
содержится важная информация, касающаяся Вашей безопасности, а также рекомендации по
правильному использованию прибора и уходу за ним.
Сохраните инструкцию вместе с гарантийным талоном, кассовым чеком, по возможности,
картонной коробкой и упаковочным материалом.
Оглавление
Назначение и область применения ....................................................................................................... 3
Техническое описание ........................................................................................................................... 3
Общие указания по безопасности данного прибора ............................................................................. 3
Специальные указания по безопасности данного прибора .................................................................. 4
Описание прибора ................................................................................................................................. 5
• все моделипоставляютсяспредохранительнымклапаном, контрольнойлампочкой,
индикатором температуры, 4-кнопочными включателеми режима нагрева.
Общие указания по безопасности
• Прибор предназначен исключительно для использования в быту.
• Прибор должен быть использован только по назначению.
• Установку прибора могут осуществлять только квалифицированные специалисты.
• Запрещается использовать водонагреватель при наличии воздуха в трубах.
• Прибор предназначен для использования внутри помещений с температурой от 5° Сдо
35°С.
• Прибор предназначен для использования внутри помещений с низкой влажностью.
• Рекомендуется установить фильтр на входном патрубке прибора, если качество воды не
соответствует Санитарным правилам и нормам, принятым в регионе Вашего проживания.
Производитель не несет ответственности за поломку водонагревателя, если она
обусловлена использованием загрязненной воды.
• Во избежаниеудараэлектрическимтокомзапрещаетсясниматьзащитнуюпанель
что прибор рассчитан на напряжение, используемое в сети.
• Любое ошибочное включение лишает Васправа на гарантийное обслуживание.
• Прибор может быть включен только в сеть с заземлением. Для обеспечения Вашей
безопасности заземление должно соответствовать установленным электротехническим
нормам. Не пользуйтесь нестандартными источниками питания или устройствами
подключения.
• Перед включением прибора в сеть убедитесь, что он находится в выключенном состоянии.
• Использование прибора детьми и людьми с ограниченными способностями возможно
только под непосредственным наблюдением и контролем
• Не используйтеприборвнепомещений. Предохраняйтеприборотжары, прямых
солнечных лучей, ударов об острые углы, влажности (ни в коем случае не погружайте
прибор в воду). Не прикасайтесь к прибору влажными руками. При намокании прибора
сразу отключите его от сети.
• По окончании эксплуатации, чистке или поломке прибора всегда отключайте его от сети.
• Неквалифицированный ремонт представляет прямую опасность для пользователя.
3
• Не производитеремонтприборасамостоятельно. Ремонтдолженпроизводитьсятолько
Монтаж прибора производит покупатель за свой счет.
Компания «POLARIS» не несет ответственности за неполадки, вызванные неверной установкой и
пренебрежительным отношением к рекомендациям данного руководства, а именно:
Электрическое подсоединение должно выполняться в соответствии с правилами раздела.
Предохранительный клапан, входящий в комплект поставки, нельзя заглушать или заменять.
Для подключения электрического кабеля отвинтите 5 саморезов с тыльной стороны прибора и
снимите переднюю панель. Затем, присоедините кабель к электрической колодке (L,N), которая
находится в верхней части прибора, а провод заземлите к клемме с символом
Установку рекомендуется производить с помощью специалистов, имеющих необходимую
квалификацию.
Подключите водонагреватель к отдельному электрическому трехжильному медному проводу
сечением 2.5 мм, с установленным автоматом на 25 ампер.
Водонагреватель подключается к однофазному источнику питания через двухполюсный
выключатель. Жилы провода подсоединяются по цветам. Необходимо следить, чтобы желтая жила
заземления была подсоединена правильно и прочно.
Водонагреватель подключается к однофазному источнику питания через двухполюсный
выключатель. Этот выключатель устанавливается отдельно от водонагревателя. Водонагреватель
должен быть надежно заземлен.
Внимание: Перед включением прибора в электросеть проверьте заполнение прибора
водой, откройте вентиль для поступления воды в прибор, на выходе из прибора
должна пойти равномерная струя воды без воздушных пузырей.
Проверьте работу электрической схемы водонагревателя, пустив через него воду и устанавливая
регулятор мощности в различные положения (1-2-3-4).
Не допускается подавать на вход водонагревателя воду с температурой выше 35°С, что может
привести к перегреву воды.
6
Принципиальнаясхемаподключения
* Заземляющий провод подсоединяется к клемме с символом .
1. Подключение приборапроизводится через двухполюсный автоматический выключатель.
2. Номинальные электрические параметрыавтоматического включателядолжны быть не
меньшеэлектрическихпараметровнагревателя.
3. Водонагревательдолжен быть надежно заземлен.
4. Дляэлектрического питанияприборанеобходимо использовать источники энергии с
напряжением 220 вольтичастотой 50Гц.
5. Вцепи электропитания следует установить устройство защитного отключения (УЗО).
вода сразу начнет нагреваться и на дисплее, будет отображаться температура воды.
Последовательно включая режимы нагрева, Вы можете подобрать оптимальную температуру
воды.
- По окончании эксплуатации – закройте запорный вентиль: подача воды прекратится, и
нагреватель автоматически отключится от сети.
9
- Чтобы вновь включить нагреватель достаточно открыть запорный вентиль и из душа польется горячаяводаустановленнойтемпературы.
* Помните, что температура воды также зависит от потока (расхода) воды: чем сильнее
поток воды, тем ниже температура и наоборот. Таким образом, при необходимости Вы
можете дополнительно регулировать температуру воды с помощью запорного вентиля.
Замерзание системы
Если существует вероятность промерзания прибора и образования льда внутри прибора –
обязательно дождитесь полного оттаивания прибора. В противном случае прибор выйдет из строя
при попытке включения в сеть.
Техническое обслуживание и ремонт
Текущий ремонт и техническое обслуживание должны выполняться специалистами,
имеющими необходимую квалификацию.
Перед проведением любой операции по ремонту или обслуживанию отключите прибор от
электрической сети!
Регулярное обслуживание
Чтобы обеспечить долгую службу нагревателя, рекомендуется регулярно прочищать фильтр на
входе воды и душевую насадку.
Регулярно проверяйте состояние соединительных шлангов, проводов и розеток. В случае
обнаружения любых повреждений – немедленно отключите прибор от сети и обратитесь в
специализированный сервисный центр для устранения неполадок.
Технические характеристики
Модель
Mercury 5.3 OD
Mercury 5.3 SD
Класс электрической защиты: I
Класс влагозащищенности: IP X4
Напряжение Мощность Макс. сила
тока
220. В, 50Гц 1,3 – 5,3
кВт
220 В, 50Гц 1,3 – 5,3
кВт
24,1. А 4 л/мин. до 8 атм.
24,1 А4 л/мин. до 8 атм.
Производительн
ость при ∆ t =
20 . С
Рабочее
давление
Информация о сертификации
Прибор сертифицирован на соответствие нормативным документам РФ.
Расчетный срок службы изделия: 5 лет
Гарантийный срок: 1 год со дня покупки
Производитель:
ООО "Текстон Корпорэйшн"
1201 Маркет Стрит, Вилмингтон 19801, штат Делавэр, США
Настоящая гарантия предоставляется изготовителем в дополнение к правам потребителя,
установленным действующим законодательством, и ни в коей мере не ограничивает их.
Настоящая гарантия действует в течение 12 месяцев, с даты приобретения изделия, и
подразумевает гарантийное обслуживание изделия в случае обнаружения дефектов, связанных с
материалами и работой. В этом случае потребитель имеет право, среди прочего, на бесплатный
ремонт изделия. Настоящая гарантия действительна при соблюдении следующих условий:
1. Гарантийное обязательство распространяется на все модели, выпускаемые компанией
«Texton Corporation LLC» встранах, где предоставляется гарантийное обслуживание
(независимо от места покупки).
2. Изделие должно быть приобретено исключительно дляличных бытовых нужд. Изделие
должно использоваться в строгом соответствии с инструкцией по эксплуатации с
соблюдением правил и требований по безопасности.
3. Обязанности изготовителяпо настоящей гарантии исполняются продавцами –
уполномоченными дилерами изготовителя и официальными обслуживающими (сервис)
центрами. Настоящая гарантия не распространяется на изделия, приобретенные у
неуполномоченных изготовителем продавцов, которые самостоятельно отвечают перед
потребителем в соответствии с законодательством.
4. Настоящая гарантия не распространяется на дефекты изделия, возникшие в результате:
5. Настоящая гарантия действительна по предъявлении вместе с оригиналом настоящего
талона, оригиналом товарного чека, выданного продавцом, и изделия, в котором
обнаружены дефекты.
6. Настоящая гарантия действительна только для изделий, используемых для личных
бытовых нужд, и не распространяется на изделия, которые используются для
коммерческих, промышленных или профессиональных целей.
По всем вопросам гарантийного обслуживания изделий Поларис обращайтесь к ближайшему
официальному продавцу POLARIS.
* Адреса авторизованных обслуживающих центровна сайте Компании: www.polar.ru
11
Electric Instant Water Heater
POLARIS
MERCURY 5.3 OD и MERCURY 5.3 SD
Manual instruction
Thank you for choosing the products made under POLARIS brand name. All the electric
appliances are made with great professional skills and with use of high quality materials. There is no
doubt that you will appreciate all the options and will be charmed with the modern design of our
products.
Before use the appliance, please, read the manual instruction carefully. It contains important
information regarding correct use of the appliance and it’s maintenance.
Keep the manual instruction with warranty card, sales check and packing materials.
Content
Function and field of application ............................................................................................................ 13
Special safeguards ................................................................................................................................. 14
Part Kitting ............................................................................................................................................. 15
Unit operation ....................................................................................................................................... 19
Technical maintenance and repair ........................................................................................................... 19
Guarantee information ............................................................................................................................ 20
Guarantee Bond ...................................................................................................................................... 21
12
Function and field of application
• A function of the electric instant water heater is to supply hot water to user, while he is at home, at
the country side or in any other places.
• The reliability of operation and service life of the unit are proved by years of manufacture
experience according to European standards, advanced technologies and modern constructional
materials.
• The up-to-date bio-design let you install the unit in every interior successfully.
Technical description
• the heating efficiency of the quartz element is up to 98%;
• the absence of metal materials that can contacts with water guarantees you personal safety;
• induction pressure sensor doesn’t let the heater run without water supply;
• the build-in thermostat switch off the appliance when the water temperature reach at 55°С level;
• all models of the unit are supplied with safety valve, light indicator, temperature indicator and 4-
mode power regulator.
Essential safeguards
• This appliance is intended for household use only.
• Do not use for other than intended use.
• Only qualified specialists are to install the appliance.
• It is forbidden to use a water heater if there is an air in the pipes.
• The appliance is intended for internal use accommodations with the temperature 5° С till 35°С.
• The appliance is intended for internal use accomodations with the low humidity.
• It is strongly recommended to use a filter in the supplying pipe. The manufacturer has no
responsibility for water pollution that can cause a damage of the unit.
• It is forbidden to remove the unit cover; it can cause an electric shock.
• Before plugging the device in outlet, please make sure, that the voltage in the ac source agrees
with technical characteristics of the appliance.
• The wrong use conflicting with the safeguards deprives the customer of the right for warranty
service.
• The appliance may be plugged in just the power net with ground connection. For your safety, the
ground connection must correspond with state rules and standards. Do not use non-standard power
supplies and connecting appliances.
• When plugging in, be sure, that the appliance is switched off.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Do not use outdoors. Protect the unit from the extreme temperature, direct sunlight, sharp corner
shocks, moisture (never immerse into water). Do not touch with wet hands. In case of contact with
water immediately unplug it.
• In case of storing, cleaning or damaging please unplug the unit.
• Unqualified repair is direct danger for user.
• You should not repair the appliance by yourself. It must be done just by qualified specialists of our
service center.
• Only original spare parts may be used for repair.
13
• Attention: Expressly prohibited to use portable extension pieces, tee-joints and others non-
standard electric devices for water heater connection.
• The heater is to be connected to a separate three-wire cable. The unit is to be connected to a single
wire power supply using a double pole automatic switch rated for 25 А.
• A protective cutout device is to be installed to the power-supply circuit. Please contact an
authorized specialist.
• The wires are to be connected according to the colors. It is necessary to assure the correct and firm
connection of yellow grounding wire. Heat-resistant cables should be used.
• The grounding cable is to be connected directly to the ground of the customer’s grounding source
using a special separate cable.
• Only supplied accessories can be used at outlet of heater.
• Before the operating please make sure that the unit is full of water and there is no air inside.
Special safeguards
• Only qualified specialists should install or repair the appliance. You should not repair the
appliance by yourself.
• The grounding should be made in appropriate way. It is forbidden to use water, gas supplying
pipes or sewerage system pipes to ground the socket outlet.
It forbidden:
• to leave the operating unit without supervision;
• to use a damaged unit (control panel damage, power cord or power supply damage);
• to remove the front cover, while the unit is switched in the electric circuit;
• to set a stop valve in the hot water outlet;
• to make the adjustment of any devices, except the water supply with valve head;
• to switch on the appliance if there is a possibility of the freezing of water in the water heater;
• Close supervision is necessary when any appliance is used near children.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
14
Description
Mercury 5.3 SD
Heating mode
indicator
Heating mode
buttons
Shower adapting
Mercury 5.3 OD
Heating mode
indicator
Heating mode
buttons
Shower adapting
pipe
Parts kitting
1. Electric Instant Water Heater
2. Shower head
3. Flexible hose
4. Rubber ring
5. Holder
6. Safety valve
7. Manual instruction
8. Service centers list
9. Warranty card
Display
Display
Water outlet
Water inlet Water outlet
Water inlet
Power cord
Faucet with safety
Power cord
Faucet with safety
valve
15
Mounting
The unit mounting is at buyer’s expense.
The «POLARIS» company has no responsibility for malfunctions caused by incorrect installation or
carelessness attitude to the right method is mentioned below. Please pay attention to the next:
Electrical connection should be made according to the instruction.
It is forbidden to replace or deactivate the safety valve supplied with the unit.
For power cord connection, please unfasten 5 screws on the back panel of the unit and remove the front
cover. Connect the power cord to (L, N) contact at the top of the unit and connect the grounding cord to
the clinch with -symbol.
This device must be installed by a licensed electrician.
Connect water heater to separate three-wire cooper cable (section 2.5mm) with installed automatic cutout
for 25 A.
The unit is to be connected to a single wire power supply using a double pole automatic switch. The wires
are to be connected according to the colors. It is necessary to assure the correct and firm connection of
yellow grounding wire.
Automatic switch should be installed separately with water heater. The appliance may be plugged in just
the power net with ground connection.
Attention: Before the operating please make sure that the unit is full of water. Open the valve for the
water inflow into, there should be even water jet without any air bubbles on water outlet. Check the
operation of the electric scheme of a water heater, after releasing through it water and setting power
control in different positions (1-2-3-4).
It is not allowed to supply the water with the temperature higher than 35°C, which can lead to overheating
of water.
Electric circuit diagram
* Connect the grounding cord to the -symbol clinch.
16
1. The unit should be connected with power supply using a double wire automatic switch.
2. The rated electrical characteristics of automatic switch should not be less than rated electrical
characteristics of the unit.
3. The unit should be grounded safely.
4. Please use current source with 220 V voltage and 50Hz frequency.
5. A protective cutout device should be installed to the power-supply circuit. Please contact
authorized specialists.
Wall mounting
Wall
Elastic insert Wall
1 2 3
1. Affix the mounting plate to the wall and make pencil notes for future holes. Make sure the unit
position is directly vertical.
2. Drill screw holes.
3. Fix elastic inserts into holes for an appropriate fastening.
4. Mount accurately the back panel of the unit on the wall.
5. Install the unit on the mounting plate and fix it with 4 screws.
17
Water supply connection
ATTENTION: Inlet pipes are marked blue while outlet pipes are marked red.
A stop valve can be installed only in the water inlet.
It is absolutely forbidden to set any shutoff devices in the hot water outlet, it can damage the unit.
Supplying pipe should be stand the working pressure up to 8 atm. and more than 65°C temperature.
Electrical circuitry
Control panel
Power cord
Transformer
Grounding
Safety fuse Resistor
Heating mode
button
К1 – К4
18
Unit operation
The first use
1. Make sure that the heating mode button is in off mode
2. Please open the faucet with safety valve to let the water in – wait till the water running.
3. Make sure there are no leaks from the unit.
4. Use the lower heating mode button to switch on the unit – the water starts to heat up and current
temperature is shown on the display. Choose a desirable temperature by pressing mode buttons.
5. To switch off the unit please close the faucet to cut the water supply, the unit will automatically
turn off.
6. For the next use just open the faucet and the water will be already hot according to the preset
temperature.
* Take into consideration that the water temperature depends on water flow, the more water the lower
temperature and vise versa. So you can also change the water temperature using the water faucet for flow
regulation.
Unit freezing
In case of frozen water in the unit, please wait until the complete defrosting of the unit and the inside
water. Whereas the turning on can damage the unit.
Attention:
• Close supervision is necessary when any appliance is used near children.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Technical maintenance and repair
Maintenance and repair must be made only by qualified specialists.
Before maintenance or repair please unplug the unit!
Regular service
For extension unit service-life it is recommended to clean the inlet filter and shower attachment.
A regular check is needed for connecting pipes, cords and power supply. In case of damage finding please
immediately unplug the unit and contact a service center for solving the problem
Specifications
Model
Mercury 5.3 OD
Mercury 5.3 SD
Electricity leakage protection level: I
Water leakage protection level: IP X4
Voltage and
frequency
220 V, 50Hz 1,3 – 5,3
220 V, 50Hz 1,3 – 5,3
Power Max.
kilowatt
kilowatt
Water Flow at ∆ t
Current
strength
24,1 А. 4 l/min. up to 8 atm.
24,1 А. 4 l/min. up to 8 atm.
= 20°С
Working pressure
19
Guarantee information
The article was certificated under normative documents of Russia.
Projected service life of the article: 5 years
Length of warranty: 1 year from the acquisition date
Manufacturer:
Texton Corporation LLC
1201 Market Street, Wilmington de.19801, State of Delaware, USA
20
Guarantee Bond
Article: Instant Water Heater Model: Mercury 5.3SD,
Mercury 5.3OD
The guarantee is offered by manufacturer in addition to customer’s rights and does in no way restrict
them.
The guarantee is valid for the term of 12 months from the date of purchase. It ensures warranty
service in case of flaws of materials or manufacture. In that case the customer has the right, among others,
to have free repair of the product. The guaranty is valid under the following conditions:
1. The guarantee is valid for all appliances produced by “Texton Corporation LLC”, in the countries
where the guaranty service can be rendered by official service centers (non depending where the
purchase was made).
2. The appliance must be bought under intention for household use only. The appliance should be
used in strict accordance with the operating instruction and safety regulations.
3. Warranty services are only to be carried by authorized dealers of manufacturer only in official
service centers. The insurance arrangements are not valid if the purchase was made from
unauthorized dealers, who are to respond to consumers on their own, what is regulated under
Legislation.
4. The guaranty is not valid in the following cases:
• Chemical, mechanical damage of the article or any other kind of impact, as well as
penetration of outside objects into the body of the article;
• The abuse as a result of a wrong use, which conflicts with the manual instruction, as well
as incorrect installation and non-observance of safety regulations;
• Wear-out of parts of decoration, lamps, cells, protecting screen, dustbins, straps and other
dated parts;
• Repairs made by unauthorized firms and dealers *;
5. The guarantee is valid upon presentation of the original of guarantee bond, the original of cash-
memo and the article, that is out of service.
6. The guarantee is valid if the article had been used in private household purpose. The guarantee is
not valid if the article had been used in commercial, industrial or professional purposes.
Please contact us if you have any question about warranty services
* You are welcome to our website, where you can find addresses of authorized service centers: www.polar.ru
21
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
