OWNER’S MANUAL SUPPLEMENT
1999 440 XCR SP
PN 9915344

IMPORTANT: This is a supplement to your owner’s manual. This information should remain with your owner’s

manual at all times.

Specifications

440 XCR SP

Body Style Edge

Rider Capacity 1

Coolant Capacity (qts) 3

Chaincase Oil Capacity (oz.) 9

Dry Weight ± 4lbs. 455

Fuel Tank Capacity
(U.S. Gallons)

Gearcase Oil
Capacity (oz.)

Height (in.) 40.25

Length (in.) 111.5

Oil Capacity (Quarts) 3.7

Ski Center Distance (in.) 41

Width (in.) 46.5

Brake Type Liq Cooled Hyd Disc

Drive Clutch
Center Distance

Clutch Type P-85

Track Length 121

Track Width 15

Drive Chain Length 74P (3/4)

Reverse
Transmission

Sprocket Ratio 21:41

12.5

Not
Applicable

11.5

Accessory

Headlight Type Halogen

Headlight (watts) Voltage H = 120

L= 110

Indicator Lights Oil / Brake / Accessory / Hi

Beam

Thumbwarmer Standard Hi/Lo

Handwarmer Standard - Multi-Range

1

440 XCR SP

Engine Model # S44-44-99A1

Alternater Output 12V 280W

Bore x Stroke (mm) 66 x 64

Displacement 438

Carburetor/Throttle Body 2 Mikuni

Carburetor Model TMX 34

Main Jet 320

Pilot Jet 22.5

Jet Needle J8-6GL63-61

Needle jet Q-8

Cutaway 2.0

Air Screw 1.25 Turns

Idle RPM ± 200 1800

Cooling Liquid

Cylinders 2

Ignition Timing 30° @ 3000

Ignition Type Digital CDI

Oil Injection Yes

Spark Plug RN57YC Champ

Front Type Edge

IFS Shocks/Spring Adj. FOX IFP / Threaded Adjust

Rear Type Edge

Front Torque Arm
Limiter

Rear torque Arm
Limiter

Front Track Shock FOX IFP/Threaded Adjust

Rear Track Shock FOX IFP/Remote Reservoir

Electronic Fuel Gauge Not Available

Electric Start Not Available

Low Oil Indicator Standard

Parking Brake Standard

Speedometer Standard, not installed

Tachometer Standard

Easy Throttle Accessory

Wear Strips 3/4² Cooler Strips

Quick Adjust

Accessory for Ice Racing

with clicker adjustable
compression dampening

2

Your Polaris snowmobile is
equipped with a tool pouch
clip which is located inside
of the flap on the back of the
seat. Using this clip will se­cure the tools, preventing
them from freely bouncing
around during snowmobile use.

1999 440 XCR SP
Engine Model: S44-44-99A1

AMBIENT

TEMPERATURE

0-900

(0-3000)

900-1800

Altitude

Meters

(Feet)

(3000-6000)

1800-2700

(6000-9000)

2700-3700

(9000-12000)

#3 jet needle position for all

Below -20°F
Below -29°C

330

300 280 260 240

260 250 230 230

230 220 200 190

Tool Pouch

Tool Clip

-20°Fto+10°

-29°Cto-12°C

+10°F-+40°F

-12°C-+5°C

Above +40°F

320 290 270

Above +5°C

- Production Setting

PN 9915344 Rev 01 11/98

Printed in U.S.A.
