APPLICATION
All Axys Snowmobiles
BEFORE YOU BEGIN
Read these instructions and check to be sure all parts and tools are accounted for.
Please retain these installation instructions for future reference and parts ordering
information.
KIT CONTENTS
This Kit includes:
REF QTY PART DESCRIPTION PART NUMBER
1 1 Polyester Undercover
-
1 Instructions 9927801
TOOLS REQUIRED
No Tools Required
IMPORTANT
Your AXYS UNDERCOVER KIT is exclusively designed for your vehicle. Please read the installation instructions
thoroughly before beginning. Installation is easier if the vehicle is clean and free of debris. For your safety, and to
ensure a satisfactory installation, perform all installation steps correctly in the sequence shown.
ASSEMBLY TIME
Approximately 5 minutes
Instr 9927801 Rev 01 2016-07 Page 1 of 2
P/N 2881981
AXYS UNDERCOVER KIT
Instr 9927801 Rev 01 2016-07 Page 2 of 2
INSTALLATION INSTRUCTIONS
NOTE
Polaris undercover is a soft, protective, removable,
washable 100% polyester cover. Please wash
undercover whenever it becomes dirty. Dirt and grit
will harm the surface of your machine.
1. Park the machine and turn the key to 'OFF'
position. Remove the key from the vehicle.
2. Drape the undercoverqover the front of the
machine then pull the elasticized edge over the
windshield as shown.
3. Use the side release buckle straps (A) sewn to the
cover to secure undercover down. Feed the
webbing strap down through the footwell (B) as
shown and connect the buckles.
Cinch tight by pulling any excess slack (C).
CAUTION
Never trailer covered unit with just the undercover
q
installed.
