Polar Electro M460 Getting Started Manual

Wear the comfortable strap and connector around your chest to get
your heart rate accurately and in real time on your M460.

* If you bought your M460 without a heart rate sensor, not to worry,
you can buy one at any time.

How to get started Get to know your M460 H10 heart rate sensor

• Browse through the menu by pressing UP or DOWN.

• Start a training session and conrm selections with the START button.

• Return, pause and stop with the BACK button.

• Lock buttons in time view by pressing and holding LIGHT.

Bike mount

You can install the bike mount
either on the stem of your bike,
or on the left or right hand side
of the handle bar.

1. Place the rubber base on the
stem/handlebar.

2. Position the bike mount on

the rubber base so that the

POLAR logo is in line with the
handlebar.

3. Secure the bike mount onto
the stem/handlebar with the
O-ring.

4. Align the ledges on the back
of the M460 with the slots

on the bike mount and turn
clockwise until the M460 is

in place.

Set up your new Polar M460 in the Polar Flow web service. The M460 is in
storage mode, and it wakes up in the setup. To get the most accurate and
personal training data, it’s important that you’re precise with the settings

in the setup.

1. Go to ow.polar.com/start and download the Polar FlowSync software,
which you need to connect your M460 to the Flow web service.

2. Open the installation package and follow the on-screen instructions for

installing the software.

3. Once the installation is complete, FlowSync opens automatically and
asks you to connect your Polar product.

4. Plug in your M460 to your computer’s USB port with the USB cable. It
may take a few minutes for your M460 to wake up and start charging.
Let your computer install any suggested USB drivers.

5. The Flow web service will be opened automatically in your internet

browser. Create a Polar account or sign in if you already have one.

6. Click Done to synchronize your settings between the M460 and the

Polar Flow web service. FlowSync status will change to completed,
once the synchronization is done.

7. If there’s a rmware update available for your M460, we recommend
you install it during the setup.

1. Moisten the electrode area of

the strap.

2. Clip the strap around your chest
and adjust the strap to t snugly.

3. Attach the connector.

4. Before your rst training session,
you need to pair the heart rate

sensor with your M460. Wear

your heart rate sensor and press
START. Then wait for the sensor
pairing request and choose Yes.

LIGHT BACK UP DOWN

After training, detach the heart rate sensor connector and rinse
the strap under running water to keep it clean. For more detailed
instructions, see the M460 support pages at support.polar.com/

en/M460.

Do not charge the device when the USB port is wet.

Training with your M460

Press START and choose your sport. Go outdoors and away from tall
buildings and trees to catch the GPS satellite signals. Keep your M460
still with the display facing upwards until it nds the GPS satellite
signal. When the signal is found, OK is displayed.

Press START again when you’re ready to go.

Choose your favorite sports and the information you want to
follow during your sessions in the Polar Flow app or web service.

During training

Take a lap: Press START during a session.

Lock a zone: To lock/unlock the heart rate zone you are currently in,

press and hold START. If your heart rate goes outside the locked zone,
you will be notied with audio feedback.

Change Settings in Quick Menu: Press and hold LIGHT to open the

Quick menu. You can change certain settings without pausing the
training recording.

Pause and stop training

Press BACK to pause your training session. To continue training, press
START. To stop the session, press and hold BACK when paused until
Recording ended is displayed.

You can also pair a new sensor in Settings > General settings> Pair and
sync > Pair other device.

Diary

Tests

Settings

Interval

timer

Favorites

START

Start

Cycling

Wed, 3.6.

Strava Live

Segments

Key features

Polar M460 offers a host of unique features to help you train better.

Here you can nd a summary of the most important ones.

INTEGRATED GPS

With integrated GPS, M460 tracks your speed, distance, altitude and
route. You can view your route on a map in the Polar Flow App or Flow
web service after your session. The Back-to-start feature directs you to

your starting point.

BAROMETER

In addition to altitude, your M460 measures comprehensive data such
as ascent/descent, incline/decline, real-time VAM (mean ascent velocity)
and altitude compensated calories.

FRONT LIGHT

The function of the front light on the top edge of the M460 is to improve
your visibility to others on the road. It’s an intelligent feature that you
can set to turn on automatically when it gets dark.

TRAINING GUIDANCE

M460 is packed with Polar’s unique Smart Coaching features that offer
the best possible guidance on how to develop your training as well as
helpful feedback on your progress.

SMART NOTIFICATIONS

The smart notications feature allows you to get alerts about incoming
calls, messages and notications from your smartphone onto your
M460. To receive notications, pair your M460 with Flow app. Set smart
notications on from your M460 settings or from Flow app.

You’ll get a summary of your training session on your M460 right after
you’ve stopped training. Get a more detailed analysis in the Flow app or in
the Flow web service.

Enhance your training experience and achieve a more complete
understanding of your performance with the following accessories:

• Adjustable Front Bike Mount gives you the best viewing angle and
an easy access to your bike computer. You can attach the unit either
around the handlebar or the stem of your bike.

• Speed sensor Bluetooth® Smart measures your cycling speed/pace
and distance accurately even on the most demanding routes. Useful
for indoor cycling. M460 shows the current, average and maximum
values of your speed.

• Cadence sensor Bluetooth® Smart measures your cycling cadence
as revolutions per minute. M460 shows the current, average and
maximum values of your cadence.

Customize with accessories

/polarglobal

POLAR M460

Getting Started Guide

English

APP STORE IS A S ERVICEM ARK OF AP PLE INC.
GOOGLE PL AY IS A TRAD EMARK OF G OOGLE INC.
STRAVA LIV E SEGMENT S IS A TRAD EMARK OF S TRAVA, IN C.
TRAININGP EAKS I S A TRADEM ARK OF TR AININGPE AKS, L LC
NP®, IF® AND TS S® ARE TR ADEMAR KS OF TRA ININGPE AKS, LLC A ND ARE USE D WITH
THE PERMISS ION. LEA RN MORE AT HT TP://W WW.TR AININGPE AKS.CO M.

To change the heart rate sensor battery:

For safety reasons, please ensure you use the correct battery (CR2025).

Technical specification

M460

BATTERY T YPE
OPERATING TIME
OPERATING TEMPERATURE
WATER RESI STANCE
MATERIALS
BIKE MOUNT MAT ERIAL S

POLAR H10 HEART RATE SENSOR

BATTERY T YPE
BATTERY SE ALING RI NG
OPERATING T EMPERATU RE
WATER RESI STANCE
CONNECTOR
STRAP

RECHARGE ABLE 385 MAH, 4, 35V BATT ERY
UP TO 16 HOURS WIT H GPS

-10 °C TO +50 °C / -4 °F TO 122 °F
IPX7 (RAIN PROOF, NOT SUI TABLE FOR S WIMMING)
PC+GF, ABS, P C, PMMA, T PU
POM

CR2025
O-RING 20.0 X 1. 0 MATERIA L FPM

-10 °C TO +50 °C / 14 °F TO 122 °F
30 M
POLYAMIDE
POLYAMIDE, PO LYURETH ANE, EL ASTANE ,
POLYESTER

1. Lever the battery cover open by using a

small at-headed tool.

2. Remove the old battery from the battery

cover.

3. Insert the new battery (CR2025) inside the

cover with the negative (-) side outwards.

4. Align the ledge on the battery cover with

the slot on the connector and press the
battery cover back into place. You should

hear a snap.

After training

POLAR EL ECTRO OY
PROFESSO RINTIE 5
FI-9044 0 KEMPELE
TEL [phone]
FAX [phone]
WWW.POLAR.COM

MANUFACTURED BY COMPATIBLE WITH

Learn more at support.polar.com/en/M460

GPS BIKE COMPUTER

COMPATIBILITY WITH 3RD PARTY POWER SENSORS

Your M460 is compatible with a number of 3rd party power sensors.
Please check the full compatibility table from support.polar.com/en/3rd-

party-sensors.

COMPATIBILITY WITH TRAININGPEAKS®

After connecting your TrainingPeaks
and Polar Flow accounts you can
sync your training sessions from
M460 to TrainingPeaks. You can see
your Training Stress Score® (TSS®),
Intensity Factor® (IF®) and Normalized Power® (NP®) on your M460
during training.

STRAVA LIVE SEGMENTS® ON YOUR M460

To receive alerts in M460 when approaching one of

your favorite Strava segments you need to:

1. Connect your Strava Premium and Polar Flow

accounts.

2. Select the segments you wish to download to Polar Flow in Strava.

3. Select the Strava segments you wish to see on your M460 in Polar Flow.

4. Sync your M460.

Learn more at support.polar.com/en/strava.

VIEW YOUR TRAINING DATA AT A
GLANCE ON THE MOBILE APP

Get the Polar Flow app on the App
Store

SM

or Google PlayTM. Sync your
M460 with Flow app after training
and get an instant overview and
feedback on your training result and
performance.

POLAR FLOW WEB SERVICE FOR
MORE DETAILED ANALYSIS

Sync your training data to the Flow
web service with your computer or
via Flow app. In the web service you
can track your achievements, get
guidance and see a detailed analysis
of your training results and activity.
Find all this and more at ow.polar.

com.

Road cycling

Monday, Feb 13, 2017, 12:04

1:21:08

Duration

37.17km

Distance

Notes

Ascent

370m

Speed avg

28.0km/h

Speed max

50.8km/h

17965261.01 ENG 06 /2017 10011
