Page 1
Product Brief
NVIDIA T4 70W LOW PROFILE
PCIe GPU ACCELERATOR
PB-09256-001_v05 | April 2020
Page 2
Version
Date
Authors
Description of Change
DOCUMENT CHANGE HISTORY
PB-09256-001_v05
01 October 24, 2018 SL, SM Initial Release
02 November 1, 2018 SL, SM Updated ECC information
03 December 19, 2018 AN, SM General product update
04 March 13, 2020 SL, SM
05 April 15, 2020 SL, SM Updated part numbers in Table 1
Updated “Overview” section with T4 qualified
servers statement
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | ii
Page 3
TABLE OF CONTENTS
Overview ........................................................................................... 1
Specifications ...................................................................................... 3
Product Specifications ......................................................................... 3
Environmental and Reliability Specifications ............................................ 5
Airflow Direction Support ...................................................................... 5
Design Discussion ................................................................................. 6
Form Factor ...................................................................................... 6
Extenders ........................................................................................ 6
Support Information .............................................................................. 7
Planned Certifications .......................................................................... 7
Agencies .......................................................................................... 7
Languages ........................................................................................ 8
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | iii
Page 4
LIST OF FIGURES
Figure 1. NVIDIA T4 Tensor Core GPU ......................................................... 2
Figure 2. NVIDIA T4 Board Dimensions ........................................................ 6
LIST OF TABLES
Table 1. Product Specifications ............................................................... 3
Table 2. Memory Specifications ............................................................... 4
Table 3. Software Specifications.............................................................. 4
Table 4. Board Environmental and Reliability Specifications ............................. 5
Table 5. Languages Supported ................................................................ 8
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | iv
Page 5
OVERVIEW
The NVIDIA® T4 is a single-slot, low-profile, 6.6-inch PCI Express Gen3 Universal Deep
Learning Accelerator based on the TU104 NVIDIA graphics processing unit (GPU). The
T4 has 16 GB GDDR6 memory and a 70 W maximum power limit. The T4 is offered as a
passively cooled board that requires system air flow to operate the card within its
thermal limits. NVIDIA supports x8 and x16 PCI Express for the T4.
NVIDIA T4 is a universal deep learning accelerator ideal for distributed computing
™
environments. Powered by NVIDIA Turing
multi-precision performance to accelerate deep learning and machine learning training
and inference, video transcoding, and virtual desktops. As part of the NVIDIA AI
Platform, T4 supports all AI frameworks and network types, delivering dramatic
performance and efficiency that maximize the utility of at-scale deployments.
NVIDIA T4 boards are shipped with ECC and page retirement enabled by default.
For general design and system qualification guidance, refer to the System Design Guide
for NVIDIA Enterprise GPU Products Design Guide (DG-07562-001).
For best performance with NVIDIA
qualified for T4 that meets the thermal and airflow requirements for NVIDIA T4. Refer
to the following website for the latest list of qualified T4 servers:
https://www.nvidia.com/en-us/data-center/tesla/tesla-qualified-servers-catalog/
T4, make sure that you use a server that has been
Tensor Cores, T4 provides revolutionary
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 1
Page 6
Figure 1. NVIDIA T4 Tensor Core GPU
Overview
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 2
Page 7
SPECIFICATIONS
PRODUCT SPECIFICATIONS
Table 1 provides the product specifications for the NVIDIA T4.
Table 1. Product Specifications
Specification Description
Product SKU PG183 SKU 200
NVPN: 699-2G183-0200-xxx
Order part numbers: (See Notes)
• 900-2G183-0000-000
• 900-2G183-0000-001
Total board power 70 W (default)
GPU SKU TU104-895
PCI IDs Device ID: 0x1EB8
Vendor ID: 0x10DE
Sub-Vendor ID: 0x10DE
Sub-System ID: 0x12A2
GPU clocks
VBIOS
PCI Express interface PCI Express 3.0 ×16 x8
Thermal cooling solution Passive
Weight Board 301 Grams
Base 585 MHz
Maximum Boost 1590 MHz
EEPROM size 8 Mbit
UEFI Supported
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 3
Page 8
Specifications
Specification
Description
Specification Description
Full Height Bracket with screws 17 Grams
Half Height Bracket with screws 10 Grams
Notes:
T4 70W, LP bracket, P/N 900-2G183-0000-000 (LP bracket installed, ATX included as an accessory)
T4 70W, ATX bracket, P/N 900-2G183-0000-000 (ATX bracket installed, LP included as an accessory)
-000 has low profile bracket preinstalled while -001 has ATX bracket preinstalled. The brackets are not
single wide full size. The brackets are single wide low profile.
Table 2 provides the memory specifications for the NVIDIA T4.
Table 2. Memory Specifications
Specification Description
Maximum memory clock 5001 MHz
Memory size 16 GB
Memory bus width 256 bits
Peak Memory bandwidth Up to 320 GBytes/s
Table 3 provides the software specifications.
Table 3. Software Specifications
SR-IOV support Supported; 16 VF (virtual functions)
Base address (physical function) BAR0: 16 MB
BAR1: 256 MB
BAR3: 32 MB
Base address (virtual function) BAR0: 4 MB, 32-bit (16 VF x 256K)
BAR1: 4 GB, 64-bit (16 VF x 256M)
BAR3: 512 MB, 64-bit (16 VF x 32M)
Message Signaled Interrupts MSI-X Supported
MSI Not Supported
PCI class code 0x03 - Display Controller
PCI sub-class code 0x02 - 3D Controller
ECC support Configurable (Enabled by default)
SMBus (8-bit address) GPU 0: 0x9E (write), 0x9F (read)
SMBus direct access Supported
SMBPBI (SMBus Post Box Interface) Supported
Zero Power Supported
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 4
Page 9
Specifications
Specification
Condition
Environmental and Reliability Specifications
Table 4 provides the environment conditions specifications for the NVIDIA T4.
Table 4. Board Environmental and Reliability Specifications
Operating temperature 0 °C to 50 °C
Storage temperature -40 °C to 75 °C
Operating humidity 5% to 90% relative humidity
Storage humidity 5% to 95% relative humidity
Mean time between failures (MTBF)
Uncontrolled environment: TBD at 35 °C
Controlled environment: TBD at 35 °C
AIRFLOW DIRECTION SUPPORT
The T4 supports bi-directional airflow either from left to right, or from right to left. CFM
requirements are identical for both airflow directions.
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 5
Page 10
DESIGN DISCUSSION
FORM FACTOR
The NVIDIA T4 board is a half-height, half-length card. The dimensions are shown in
Figure 2.
Figure 2. NVIDIA T4 Board Dimensions
EXTENDERS
NVIDIA does not offer extenders for the Tesla T4.
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 6
Page 11
SUPPORT INFORMATION
PLANNED CERTIFICATIONS
Windows Hardware Quality Lab (WHQL): Windows 10
Ergonomic requirements for office work W/VDTs (ISO 9241)
EU Reduction of Hazardous Substances (EU RoHS)
Joint Industry guide (J-STD) / Registration, Evaluation, Authorization, and Restriction
of Chemical Substance (EU) – (JIG / REACH)
Halogen Free (HF)
EU Waste Electrical and Electronic Equipment (WEEE)
AGENCIES
Australian Communications and Media Authority and New Zealand Radio Spectrum
Management (RCM)
Bureau of Standards, Metrology, and Inspection (BSMI)
Conformité Européenne (CE)
Federal Communications Commission (FCC)
Industry Canada - Interference-Causing Equipment Standard (ICES)
Korean Communications Commission (KCC)
Underwriters Laboratories (cUL, UL)
Voluntary Control Council for Interference (VCCI)
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 7
Page 12
LANGUAGES
Table 5. Languages Supported
Support Information
Languages
English (US) Yes Yes
English (UK) Yes Yes
Arabic Yes
Chinese, Simplified Yes
Chinese, Traditional Yes
Czech Yes
Danish Yes
Dutch Yes
Finnish Yes
French (European) Yes
German Yes
Greek Yes
Hebrew Yes
Hungarian Yes
Italian Yes
Japanese Yes
Korean Yes
Norwegian Yes
Polish Yes
Portuguese (Brazil) Yes
Portuguese (European/Iberian) Yes
Russian Yes
Slovak Yes
Slovenian Yes
Spanish (European) Yes
Spanish (Latin America) Yes
Swedish Yes
Thai Yes
Turkish Yes
Note:
1
Microsoft Windows 7, Windows 8, Windows 8.1, Windows 10, Windows Server
2008 R2, Windows Server 2012 R2 and Windows 2016 are supported.
Windows1
Linux
NVIDIA T4 70W Low Profile PCIe GPU Accelerator PB-09256-001_v05 | 8
Page 13
Notice
The information provided in this specification is believed to be accurate and reliable as of the date provided. However, NVIDIA
Corporation (“NVIDIA”) does not give any representations or warranties, expressed or implied, as to the accuracy or completeness
of such information. NVIDIA shall have no liability for the consequences or use of such information or for any infringement of
patents or other rights of third parties that may result from its use. This publication supersedes and replaces all other specifications
for the product that may have been previously supplied.
NVIDIA reserves the right to make corrections, modifications, enhancements, improvements, and other changes to this
specification, at any time and/or to discontinue any product or service without notice. Customer should obtain the latest relevant
specification before placing orders and should verify that such information is current and complete.
NVIDIA products are sold subject to the NVIDIA standard terms and conditions of sale supplied at the time of order
acknowledgement, unless otherwise agreed in an individual sales agreement signed by authorized representatives of NVIDIA and
customer. NVIDIA hereby expressly objects to applying any customer general terms and conditions with regard to the purchase of
the NVIDIA product referenced in this specification.
NVIDIA products are not designed, authorized or warranted to be suitable for use in medical, military, aircraft, space or life support
equipment, nor in applications where failure or malfunction of the NVIDIA product can reasonably be expected to result in personal
injury, death or property or environmental damage. NVIDIA accepts no liability for inclusion and/or use of NVIDIA products in such
equipment or applications and therefore such inclusion and/or use is at customer’s own risk.
NVIDIA makes no representation or warranty that products based on these specifications will be suitable for any specified use
without further testing or modification. Testing of all parameters of each product is not necessarily performed by NVIDIA. It is
customer’s sole responsibility to ensure the product is suitable and fit for the application planned by customer and to do the
necessary testing for the application in order to avoid a default of the application or the product. Weaknesses in customer’s product
designs may affect the quality and reliability of the NVIDIA product and may result in additional or different conditions and/or
requirements beyond those contained in this specification. NVIDIA does not accept any liability related to any default, damage,
costs or problem which may be based on or attributable to: (i) the use of the NVIDIA product in any manner that is contrary to this
specification, or (ii) customer product designs.
No license, either expressed or implied, is granted under any NVIDIA patent right, copyright, or other NVIDIA intellectual property
right under this specification. Information published by NVIDIA regarding third-party products or services does not constitute a
license from NVIDIA to use such products or services or a warranty or endorsement thereof. Use of such information may require a
license from a third party under the patents or other intellectual property rights of the third party, or a license from NVIDIA under
the patents or other intellectual property rights of NVIDIA. Reproduction of information in this specification is permissible only if
reproduction is approved by NVIDIA in writing, is reproduced without alteration, and is accompanied by all associated conditions,
limitations, and notices.
ALL NVIDIA DESIGN SPECIFICATIONS, REFERENCE BOARDS, FILES, DRAWINGS, DIAGNOSTICS, LISTS, AND OTHER DOCUMENTS
(TOGETHER AND SEPARATELY, “MATERIALS”) ARE BEING PROVIDED “AS IS.” NVIDIA MAKES NO WARRANTIES, EXPRESSED, IMPLIED,
STATUTORY, OR OTHERWISE WITH RESPECT TO THE MATERIALS, AND EXPRESSLY DISCLAIMS ALL IMPLIED WARRANTIES OF
NONINFRINGEMENT, MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE. Notwithstanding any damages that customer
might incur for any reason whatsoever, NVIDIA’s aggregate and cumulative liability towards customer for the products described
herein shall be limited in accordance with the NVIDIA terms and conditions of sale for the product.
Trademarks
NVIDIA, the NVIDIA logo, and NVIDIA Turing are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and
other countries. Other company and product names may be trademarks of the respective companies with which they are associated.
Copyright
© 2018, 2020 NVIDIA Corporation. All rights reserved.
www.nvidia.com
Loading...
