PLUS Vision U5-732 User Manual
DATA PROJECTOR
U5
-
732
User’s Manual
SOURCE
AUTO
STANDBY
STANDBY
STATUS
4
M
O
ZO
3
L
R
E
VO
12
IM
T
E
T
U
CANCEL
M
R-CLICK/
E
Z
E
E
R
F
R
E
Q
T
N
K
E
IC
U
Q
O
T
U
A
R
E
O
U
S
E
N
A
ID
L
E
V
M
B
G
R
Y
B
D
N
A
T
S
IMPORTANT
* DLP™ (Digital Light Processing) and DMD (Digital Micromirror Device) are registered trademarks of Texas Instru-
ments Incorporated (U.S.A.).
* VGA and XGA are trademarks or registered trademarks of International Business Machines Corporation (U.S.A.).
* S-VGA is a registered trademark of Video Electronics Standards Association.
* Microsoft, Windows, and PowerPoint are registered trademarks of Microsoft Corporation (U.S.A. and other countries).
* Macintosh is a trademark of Apple Computer Inc. (U.S.A.).
Note that even in the absence of explanatory notes, serious attention is paid to the trademarks of the various companies
and to the product trademarks.
U5-732
IMPORTANT SAFETY INFORMATION
Precautions
Please read this manual carefully before using your PLUS Data Projector and keep the manual handy for future
reference.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PLUS SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the unit may have sufficient magnitude to
cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside of this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this
unit has been included. Therefore, it should be read carefully in order to avoid any problems.
The above cautions are given on the bottom of the product.
WARNING
TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE
THIS UNIT’S GROUNDED PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THREE
PRONGS CAN BE FULLY INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. ALL SERVICING MUST BE DONE BY QUALIFIED PLUS SERVICE PERSONNEL.
WARNING
This is a class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
RF Interference
WARNING
The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT
those specified by PLUS Vision in this manual. Failure to comply with this government regulation could void
your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
DOC Compliance Notice
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
CAUTION
Do not look at the laser pointer’s light source.
Be sure to heed the following. Pointing the laser beam at
the eyes could lead to reduced vision or vision impairment.
• Never look at the laser pointer’s light source.
• Do not point the laser beam at people.
• Do not let children use the laser pointer.
This label is located on the side of the remote control.
Hg: Lamp in This Product Contains Mercury. Dispose of Lamp According to Local, State or Federal Law.
E-2
IMPORTANT SAFETY INFORMATION
Important Safeguards
These safety instructions are to ensure the long life of the unit and to prevent fire and shock. Please read them
carefully and heed all warnings.
Installation
• For best results, use the unit in a darkened room.
• Place the unit on a flat, level surface in a dry area away from dust and moisture.
• Do not place the unit in direct sunlight, near heaters or heat radiating appliances.
• Exposure to direct sunlight, smoke or steam can harm internal components.
• Handle the unit carefully. Dropping or jarring can damage internal components.
• Do not place heavy objects on top of the unit.
Power Supply
• The unit is designed to operate on a power supply of 100 – 120/220 – 240 V 50/60 Hz AC. Ensure that your
power supply fits these requirements before attempting to use the unit.
• Handle the power cable carefully and avoid excessive bending. A damaged cord can cause electric shock or
fire.
• Disconnect the power cable (mains lead) from the power outlet after using the unit.
Before disconnecting the power cable, make sure that the STANDBY indicator lights in amber (not blinking or
in green).
Cleaning
• Disconnect the power cable (mains lead) from the unit.
• Clean the cabinet of the unit periodically with a damp cloth. If heavily soiled, use a mild detergent. Never use
strong detergents or solvents such as alcohol or thinner.
• Use a blower or lens paper to clean the lens, and be careful not to scratch or mar the lens.
• Clean the ventilation slots and speaker grills on the unit periodically using a vacuum cleaner. If accumulated
dust blocks the ventilation slots, the unit will overheat, which may cause the unit to malfunction.
Use a soft brush attachment when using the vacuum cleaner. Do not use a hard attachment, such as a crevice
tool, to prevent the damage to the unit.
Lamp Replacement
• Be sure to replace the lamp when the Status indicator comes on. If you continue to use the lamp after 2000
hours of usage, the lamp will turn off.
Fire and Shock Precautions
• Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the buildup of heat inside
the unit. Allow at least 10 cm (3 inches) of space between the unit and walls.
• Prevent foreign objects such as paper clips and bits of paper from falling into the unit. Do not attempt to retrieve
any objects that fell into the unit. Do not insert any metal objects such as a wire or screwdriver into the unit. If
something should fall into the unit, immediately disconnect the power cable from the unit and have the object
removed by a qualified PLUS service person.
• Do not place any liquids on top of the unit.
Cautions on Handling the Storage Case
• Do not put anything other than the unit or its accessories in the storage case. Paper clips, staples or other metal
or foreign objects getting inside could cause fire or electric shock.
• Do not swing the storage case around when the unit is inside. Also do not force objects that are too large to fit
into the storage case. Doing so could scratch or damage the unit.
When Moving the Unit
• When moving the unit to a different place, put it in the included storage case and place the storage case in an
insulating package to protect against falls and shocks.
• If there are paper clips, staples or other metal or foreign objects inside the storage case, the objects could get
inside the unit while the unit is being moved, causing fire or electric shock when the power is turned on.
CAUTION – HOT!
The area around the exhaust vents is hot during and immediately after image projection.
To avoid burns, keep your hands away from this area.
Wait until the exhaust vents area cools off before touching it.
Do not look into the lens while the unit is on. Serious damage to your eyes could result.
E-3
Major Features
䡵 Lightweight high-intensity projector
The synergy of the DLP™ (Digital Light Processing) display system and our own optical design serve to improve the optical
utilization efficiency. The three primary colors (RGB) required in color expression are reproduced with one DMD (Digital
Micromirror Device of high precision). These factors have enabled a design that offers both high intensity and small size/
lightweight features.
䡵 Sharp, clear picture
The DLP™ display system affords RGB color fidelity and inconspicuous gaps between the individual dots, thereby permitting
the display of small characters and diagrams with distinct clarity.
䡵 Powerful functions for presentations
A wide variety of easy-to-set functions have been built into the projector, from a digital keystone correction function (used
when making settings) that corrects picture distortion, to an auto adjustment function that automatically identifies the PC
signal.
A presentation timer that supports presentations and a security lock function protecting against unauthorized projection have
also been added.
䡵 High contrast ratio of 2000:1
Use of a new generation of DMD devices has given birth to an amazing 2000:1 high contrast ratio.
By widening the difference of brightness between black and white, you can see a degree of sharpness that is greater than just
the brightness based on specifications.
䡵 Beautiful reproduction of high-quality images from DVD
Faithful reproduction of color tones gives rise to the display of natural images. High-quality images such as those from DVD
and digital high-definition television broadcasts bring out the display capabilities that are an essential strength of the DLP™
display system projector.
䡵 Econo-mode switch function for the lamp output
Using the lamp Econo-mode will extend the life of the lamp and lower the power consumption.
By switching the lamp mode to suit your operating environment, you will save on lamp cost as well as contribute to energy
conservation and ecology.
E-4
Table of Contents
IMPORTANT SAFETY INFORMATION ................................................................................... E-2
Major Features ....................................................................................................................... E-4
Table of Contents ................................................................................................................... E-5
Checking the Supplied Accessories .................................................................................... E-7
Names of the Main Unit Parts ............................................................................................... E-9
Names of the Remote Control Parts/Preparing the Remote Control .............................. E-11
Names of Parts/Preparing the Remote Control Unit ................................................. E-11
Remote Control Range ............................................................................................. E-13
The Procedure Up to Projecting to the Screen ................................................................. E-14
Placement Guide .................................................................................................................. E-15
Screen Size and Projection Distance ........................................................................ E-15
Connecting Personal Computers and Video Equipment .................................................. E-18
Connections with Personal Computer ....................................................................... E-18
Connect the projector’s RGB connector using the included RGB signal cable. .. E-18
To Output the External Output Signal of a Notebook Computer ......................... E-19
Connections with Composite Signals ........................................................................ E-20
Video Equipment with VIDEO Connectors .......................................................... E-20
Video Equipment with S-VIDEO Connectors ...................................................... E-20
Connections with Component Signals ....................................................................... E-21
When the Video Equipment Has a YCbCr Connector or YPbPr Connector ........ E-21
Connections with the AUDIO Jack ............................................................................ E-22
Power Cable Connections and Switching the Power On/Off ........................................... E-23
Operating ................................................................................................................... E-23
Finishing .................................................................................................................... E-25
Adjustment of the Projection Screen ................................................................................. E-26
Adjustment of the Projection Screen ......................................................................... E-26
Making Adjustments with the Adjusters .............................................................. E-27
General Operation ................................................................................................................ E-28
Input Selection .......................................................................................................... E-28
Automatic Adjustment ............................................................................................... E-29
Freezing a Moving Picture ......................................................................................... E-30
Cancelling Video and Audio Temporarily ................................................................... E-30
Adjustment of the Volume .......................................................................................... E-31
Enlargement of the Image and Video Movement ...................................................... E-32
Using the Presentation Timer .................................................................................... E-33
Using the Laser Pointer ............................................................................................. E-34
Performing Mouse Operations on the Computer
with the Remote Control Unit .................................................................................... E-35
Controlling the Projector from a Computer ................................................................ E-36
Protecting the Projector with the Security Lock ......................................................... E-37
Using the Quick Menu ............................................................................................... E-39
Menu Operation Method ...................................................................................................... E-40
Performing Menu Operations .................................................................................... E-42
List of Item Names Offering Input Selection and Adjustments/Settings .................... E-45
Image ..................................................................................................................................... E-47
Brightness / Contrast / Color / Tint / Sharpness ........................................................ E-47
Picture Adj. / Fine Picture / H Position / V Position .................................................... E-47
Reset ......................................................................................................................... E-48
E-5
Table of Contents
Color ...................................................................................................................................... E-49
Quick Color Adj. ........................................................................................................ E-49
Gamma ..................................................................................................................... E-49
Color Temp. ............................................................................................................... E-50
White ......................................................................................................................... E-50
Color Space .............................................................................................................. E-50
White Balance ........................................................................................................... E-51
View ....................................................................................................................................... E-52
Aspect ....................................................................................................................... E-52
Filter .......................................................................................................................... E-52
Vertical Flip / Horizontal Flip ...................................................................................... E-53
Keystone.................................................................................................................... E-53
Keystone Save .......................................................................................................... E-53
Setup ..................................................................................................................................... E-54
Auto Source............................................................................................................... E-54
Auto Power Off .......................................................................................................... E-54
Menu Position............................................................................................................ E-55
Lamp Mode ............................................................................................................... E-55
Input Format .............................................................................................................. E-56
Presentation Timer .................................................................................................... E-56
Option ................................................................................................................................... E-57
Language .................................................................................................................. E-57
On Screen ................................................................................................................. E-57
Background ............................................................................................................... E-57
Startup Screen .......................................................................................................... E-58
Security Lock ............................................................................................................. E-58
Info......................................................................................................................................... E-59
Status ........................................................................................................................ E-59
Factory Default .......................................................................................................... E-59
Lamp Timer Reset ..................................................................................................... E-59
Resolution / Frequency ............................................................................................. E-60
Lamp Timer ............................................................................................................... E-60
When an Indicator is Lit or Flashing .................................................................................. E-61
Troubleshooting ................................................................................................................... E-62
Cleaning ................................................................................................................................ E-63
Replacing the Lamp Cartridge ............................................................................................ E-64
Specifications ....................................................................................................................... E-67
Table of Supported Frequency ........................................................................................... E-68
Cabinet Dimensions ............................................................................................................ E-69
E-6
Checking the Supplied Accessories
Remove the main unit and the accessories from the box and check that the following items are included.
Wireless remote control unit with laser pointer [1] /
Size AAA batteries [2]
This controls the projector. (See Page E-11.)
4
ZOOM
3
VOL
12
TIMER
CANCEL
MUTE
R-CLICK/
ZE
E
RE
Q
QUICK
AUTO
LASER
VIDEO
RGB
STANDBY
F
ENTER
MENU
RGB signal cable
(Mini D-sub 15-pin, 2 m / 6.6 feet) [1]
This is used in making connections with a personal computer.
See Page E-18 about connections.
No. 777709000
S-Video cable (Mini DIN 4-pin plug, 2 m / 6.6 feet) [1]
This cable is used in the connection of video equipment that
has an S-video connector. Connections are described on Page
E-20.
No. 777704000
Video cable (RCA pin plug, 2 m / 6.6 feet) [1]
This cable is used in the connection of video equipment that
has a video connector. Connections are described on Page E-
20.
No. 777703000
Audio cable (Mini plug, 2 m / 6.6 feet) [1]
This cable is used with equipment that has phono type audio
jacks. Connections are described on Page E-22.
No. 777705000
Power cable (1.8 m / 5.9 feet) [1]
This power cable supplies power to the unit. See Page E-23
about connections.
Audio conversion adapter (Mini-jack/ RCA pin plug, 15 cm
/ 0.5 feet) [1]
This cable is used with equipment whose audio connector is
of the phono pin type. Connections are described on Page E-
22.
No. 777706000
USB cable (type A, 2 m / 6.6 feet) [1]
Used to perform mouse operations on a computer using the
projector’s remote control unit. Connections are described on
Page E-35.
No. 777707000
E-7
Checking the Supplied Accessories
Storage case (for projector and accessories) [1]
This case is designed to hold the projector itself and its accessories.
Use it when storing the projector.
User’s Manual (CD-ROM Edition) [1]
User’s Manual (Simplified Edition) [1]
HOW TO PUT THE PROJECTOR INTO THE STORAGE CASE
Close the lens shutter or lens cap before putting the projector in its case, then fasten the projector in place with the
Velcro belt. Place the accessories in the storage pocket.
Velcro strap
Pocket
E
C
R
U
O
S
O
T
U
A
Y
B
D
N
A
T
S
Y
B
D
N
A
T
S
S
U
T
A
T
S
Cable storage pouch [1]
“WARNING”
Handling the cables supplied with this product,
will expose you to lead, a chemical known to the
State of California to cause birth defects or other
reproductive harm.
Wash hands after handling.
E-8
Names of the Main Unit Parts
STANDBY
STANDBY
Zoom ring [E-26]
Focus ring [E-27]
Exhaust vents
Remote control
sensor [E-13]
Lens
STATUS
SOURCE
AUTO
Ventilation slots
Adjuster button [E-27]
(Also on opposite side)
Lens cap
Remove before use. Attach
the lens cap after use to
protect the lens.
Ventilation slots
Lamp cover [E-65]
Adjusters [E-27]
E-9
Names of the Main Unit Parts
STATUS indicator [E-23, 61]
STANDBY indicator [E-23, 61]
STANDBY button [E-23]
AUTO button [E-28]
SOURCE button [E-28]
Remote control sensor [E-13]
AC IN connector [E-23]
STATUS
STANDBY
STANDBY
AUTO
SOURCE
STATUS
STANDBY
STANDBY
AUTO
RGB
S VIDEO
VIDEO
AUDIO
MOUSE
SOURCE
PC CONTROL
Speaker
Built-in security slot
Ventilation slots
(See description below.)
MOUSE connector [E-35]
AUDIO connector [E-22]
RGB
S VIDEO
VIDEO
AUDIO
MOUSE
VIDEO connector [E-20]
S-VIDEO connector [E-20]
RGB connector [E-18, 21]
Built-in Security Slot
This security slot supports the MicroSaver Security System manufactured by
Kensington Microware Inc.
PC CONTROL
PC CONTROL connector
(D-Sub 9-pin) [E-36]
E-10
Names of the Remote Control Parts/Preparing the Remote Control
Refer to the description (and diagram) for the remote control unit included with your projector.
Names of Parts/Preparing the Remote Control Unit
Names of the Remote Control Parts
Infrared transmitter [E-13]
Laser transmitter [E-34] L-CLICK button [E-35]
STANDBY button [E-23, 25]
This button is used to switch ON
the power aand set the unit to the
STANDBY mode.
Buttons used for input selection
[E-28]
RGB button and VIDEO button
(VIDEO / S-VIDEO)
Buttons used for menu operations
[E-40]
The , , and buttons are
the select (왖, 왔, 왗 and 왘) buttons.
FREEZE button [E-30]
(Freezes moving pictures)
VOL button [E-31]
(Volume adjustment)
Number buttons [E-37]
(Used for the security lock.)
STANDBY
RGB
ENTER
FREEZE
12
VOL
34
VIDEO
MUTE
ZOOM
LASER
AUTO
QUICKMENU
Q
R-CLICK/
CANCEL
TIMER
LASER button [E-34]
(Turns the laser point on and off)
AUTO button [E-28]
(Automatic adjustment of the RGB
moving image)
QUICK button [E-39]
(Displays a simplified menu)
Buttons used for the PC mouse
function [E-35]
(JOG button and R-CLICK button)
TIMER button [E-33]
(Presentation timer time setting
display)
MUTE button [E-30]
(Temporarily cancels the video and
audio)
ZOOM button [E-32]
(Digital zoom adjustment)
Note:
If a button on the remote control unit is held in continuously for approximately 30 seconds, signal transfer will be suspended. To resume
transferring signals, press the button again.
Also, to use the jog button after signal transfer has been suspended, first press any other button, then press the jog button.
E-11
Names of the Remote Control Parts/Preparing the Remote Control
Inserting the Batteries
When using the remote control for the first time, install the batteries that were supplied.
Slide the battery compartment cover (located on the
1
bottom of the remote control) and pull off.
(A) Leaving a little space in the front, close the lid, (B)
3
then with the back pressed tightly, (C) press the lid
towards the front.
(A)
(C)
(B)
Insert the batteries to match the "+" and "–" as indi-
2
cated inside the compartment.
* When replacing batteries, purchase two of the same type of AAA battery.
* DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
E-12
Names of the Remote Control Parts/Preparing the Remote Control
Remote Control Range
Point the infrared transmitter of the remote control toward the remote control sensor located at the front or rear of the main unit
and operate.
Reception of the remote control signal should generally be possible within the range illustrated below.
Side View
Remote control
infrared transmitter
6m/19.7feet
20°
20°
5m/16.4feet
30°
30°
5m/16.4feet
5° 5°
Remote control
sensor
Top View
3m/9.8feet
STANDBY
STATUS
AUTO
STANDBY
SOURCE
Remote control
Remote control
infrared transmitter
sensor
Precautions
Handling of the Remote Control
* Exposure of the main unit's remote control sensor or the remote control infrared transmitter to bright light or the
obstruction of the signal by an obstacle located in the pathway may prevent operation.
* Do not drop the remote control or handle it inappropriately.
* Do not expose the remote control to water or other liquids. Should the remote control become wet, wipe it dry
immediately.
* Try to avoid use in hot and/or humid locations.
* Please keep button batteries out of the reach of children. If a battery is swallowed, promptly obtain the medical care
of a doctor.
* Remove the batteries from the remote control when it is not going to be used for a long period.
* Some operations (such as menu operations) are available only through the use of the remote control and attention
should be given to its careful handling.
E-13
The Procedure Up to Projecting to the Screen
Perform setup adjustments in the following order.
1 Position the projector
Determine the locations to set up the screen and the projector.
See “Placement Guide” on Page E-15.
2 Connect the video equipment and personal computer
Connect your equipment to the projector.
When making connections with the personal computer’s RGB connector, see “Connections with
Personal Computer” on Page E-18.
When making connections with the video equipment’s video connector or an S-video connector,
see “Connections with Composite Signals” on Page E-20.
When making connections with the video equipment’s YCbCr connector or YPbPr connector,
see “Connections with Component Signals” on Page E-21.
When playing the audio through the built-in speaker of the projector, see “Connections with the
AUDIO Jack” on Page E-22.
3 Opening the lens cap
4 Connecting the power cable and switching on the power
See “Operating” on Page E-23.
See “Finishing” on Page E-25.
5 When selecting the language of menu displays, etc.
(Only when the power is first switched on following purchase)
See “When [Menu Language Select] Is Displayed Upon Switching On the Power” on Page E-24.
6 Switching on the power of the personal computer and video equipment
7 Properly adjust the projection image to the screen
See “Adjustment of the Projection Screen” on Page E-26.
8 Selecting input equipment
See “Input Selection” on Page E-28.
9 Adjust the screen or video image
Adjust the image to the optimum condition as required.
See the Table of Contents for the adjustment items.
About DLP projectors
Though careful attention is paid to providing optimum quality, please note that with DLP type projectors, in rare cases there may
be black spots or bright spots among the picture elements.
Note:
* Please purchase a screen.
* A component cable (order code 28-690), which is available separately, is required to connect a DVD player or other equipment with YCbCr
connectors.
* A component cable (order code 28-690), which is available separately, is required to connect high definition (HD) video equipment or other
equipment with YPbPr connectors.
E-14
Placement Guide
• Use this information as a guide to find out about the screen size when the projector is placed at a certain location, or
to find out the approximate size of a screen that will be required.
• Refer to the projection distance table for your projector model.
• When suspending the projector from the ceiling, change the projection method. See “Vertical Flip” on E-53.
Screen Size and Projection Distance
• The projection distance over which focussing is adjustable is 1.20 m (3.94 feet) to 13.81 m (45.31 feet). The projector
should be placed within this range.
Screen Size Designation (Inches)
300"
Height from center of
250"
200"
lens to top edge of
the projection
40"
33"
1.20
(3.94)
60"
1.23–1.48
(4.04–4.86)
27"
S
T
A
T
U
S
S
T
A
N
D
B
Y
S
T
A
N
D
B
Y
A
U
T
O
S
O
R
U
G
R
B
C
E
S
V
I
D
E
O
V
I
D
E
O
A
U
D
I
O
M
O
U
S
E
P
C
C
O
N
T
R
O
L
Lens surface of the
main unit
80"
120"
100"
–1.80
1.49
(4.89
150"
–5.91)
–2.73
–8.96)
2.26
(7.41
3.03–3.65(9.94–11.98)
–4.57(12.47
3.80
–14.99)
–5.50(14.99
4.57
–18.04)
–6.88(18.80
5.73
–22.57)
7.65
–30.15)
–9.19(25.10
–11.50(31.40
9.57
h1
Height from center of
lens to bottom edge
of the projection
h2
–37.73)
–13.81(37.73
11.50
–45.31)
Unit: m (feet)
E-15
Placement Guide
Width
Screen size (Diagonal)
Screen Size
Designation (Inches)
27"
33"
40"
60"
80"
100"
120"
150"
200"
250"
300"
* There is a tolerance of ±5% due to design values.
* This table uses the lens apex and lens center as references and requires that the projector be in a horizontal condition
(with front and rear adjusters fully withdrawn).
Screen Size Width x Height Projection Distance Height h1 Height h2
0.56⳯0.41
0.67⳯0.50
0.81⳯0.61
1.21⳯0.91
1.62⳯1.21
2.03⳯1.52
2.43⳯1.82
3.04⳯2.28
4.06⳯3.04
5.08⳯3.81
6.09⳯4.57
Height
(m) (feet)
1.83 ⳯ 1.35
2.19 ⳯ 1.64
2.65 ⳯ 2.00
3.96 ⳯ 2.98
5.31 ⳯ 3.96
6.66 ⳯ 4.98
7.97 ⳯ 5.97
9.97 ⳯ 7.48
13.32 ⳯ 9.97
16.66 ⳯12.50
19.98 ⳯14.99
(m) (feet) (m) (feet) (m) (feet)
Wide – Tele Wide – Tele
—– 1.20
1.23 – 1.48
1.49 – 1.80
2.26 – 2.73
3.03 – 3.65
3.80 – 4.57
4.57 – 5.50
5.73 – 6.88
7.65 – 9.19
9.57 – 11.50
11.50 – 13.81
—– 3.94
4.04 – 4.86
4.89 – 5.91
7.41 – 8.96
9.94 – 11.98
12.47 – 14.99
14.99 – 18.04
18.80 – 22.57
25.10 – 30.15
31.40 – 37.73
37.73 – 45.31
0.48
0.59
0.72
1.07
1.43
1.79
2.14
2.68
3.58
4.48
5.38
1.57
1.94
2.36
3.51
4.69
5.87
7.02
8.79
11.75
14.70
17.65
0.07
0.09
0.11
0.16
0.22
0.27
0.32
0.40
0.54
0.67
0.81
0.23
0.30
0.36
0.52
0.72
0.89
1.05
1.31
1.77
2.20
2.66
E-16
Placement Guide
Installation Height of Projection Screen [Reference]
Once the installation location and position have been decided, the projection height should be checked. In the case of large
screen sizes, there are instances where the image cannot be projected within the floor to ceiling height.
The required installation height can be found using the following formula:
[Height from center of lens to top edge of the projection] m (feet) + 0.05m (0.16 feet) + Stand height
Example: Using a 150" 4:3 screen and placing the projector horizontally, the required installation height will be
2.68m (8.79 feet) + 0.05m (0.16 feet) = 2.73m (8.95 feet) (without a stand)
An installation room with a height of 2.4m (7.87 feet) will have insufficient room height even when the projector is placed on
the floor. (Note that the rear adjusters can be raised to lower the projection screen image.)
Lens center
Screen size vertical dimension
h2 dimension
Approx. 0.05 m (0.16 feet)
Stand dimension
Screen size top
edge dimension
measured from
floor
E-17
Connecting Personal Computers and Video Equipment
Connecting this unit with a personal computer permits presentation data to be projected as a large screen display at
conferences, lectures, and on other occasions. Furthermore, connecting this unit to a DVD player or other video equipment source in combination with an audio/video amplifier and speaker system will allow you to enjoy convincing home
theater.
Connections with Personal Computer
Please check the following before making connections with the personal computer.
• A suitable resolution for the U5-732 is 1024 ⳯ 768 dots (XGA) and the maximum displayable resolution is 1280 ⳯ 1024 dots
(S-XGA).
Make changes to a displayable resolution at the personal computer side. Please check with “Table of Supported Frequency” on
Page E-68.
• The setting method for the personal computer will differ depending on the specific model. Please read the personal computer
instruction manual or the on-line help information, or contact the manufacturer of your personal computer.
Connect the projector’s RGB connector using the included RGB signal cable.
• When making connections with the RGB connector of the projector, please make the connection via the supplied RGB signal
cable.
• The projector has been set to “Auto” at the factory; however, if it does not project, please change the input setting to “RGB”
using the menu sequence of [Setup] → [Input Format] → [RGB].
See “Input Format” on Page E-56.
• If the USB cable is connected to the projector’s MOUSE connector, mouse operations can be performed on the computer from
the projector’s remote control unit.
See “Performing Mouse Operations on the Computer with the Remote Control Unit” on Page E-35.
MONITOR OUT
Personal
computer
RGB signal cable (Supplied item)
Note:
* Before making connections, check the power of the projector and the equipment to be connected is switched off.
* When projection will be with a notebook computer connected, knowledge will be required for the cable connection and notebook computer
startup procedure as well as the operation that follows startup. Please consult the instruction manual of your notebook computer or the online help.
E-18
Connecting Personal Computers and Video Equipment
To Output the External Output Signal of a Notebook Computer
When projection will be with a notebook computer connected, knowledge will be required for the cable connection and notebook
computer startup procedure as well as the operation that follows notebook startup. Please consult the instruction manual of your
notebook computer or the on-line help while performing the following procedure.
Check whether a signal is being sent from the notebook computer to the projector.
1
An indication appearing on the liquid crystal display of the notebook computer does not necessarily mean that an external
output signal is being output.
REFERENCE: When “Resolution” or “Frequency” is not displayed under “Info.” on the menu of the projector, this means that
the external output signal is not being output from the personal computer. See “Resolution/Frequency” on Page E-60.
Should a sign not be output from the notebook computer, please try the operation described below.
2
For an IBM PC/AT compatible computer, press the [Fn] key plus any one of the [F1] to [F10] keys. (See the table below.)
Manufacturer Model Key
DELL All computers Fn + F8
EPSON All computers Fn + F8
FUJITSU All computers Fn + F10
iiyama All computers Fn + F3
IBM All computers Fn + F7
NEC All computers Fn + F3
Panasonic All computers Fn + F3
SHARP All computers Fn + F5
SONY All computers Fn + F7
SOTEC All computers Fn + F3–F5
TOSHIBA All computers Fn + F5
Victor All computers Fn + F10
Note: Table information is current to December 2003.
Note:
When the liquid crystal display of the notebook computer and the projector are displayed at the same time, the projected image might not be
correct even though the liquid crystal display shows a correct indication. Should this occur, stop the simultaneous display of the notebook
computer and try the mode with external output only. Try an operation such as that described in aforementioned Step 2 and try closing the
liquid crystal panel which might result in external output only.
E-19
Connecting Personal Computers and Video Equipment
Connections with Composite Signals
Video Equipment with VIDEO Connectors
• Make the connection to the VIDEO connector of the projector using the supplied Video cable.
• The input setting of the VIDEO connector has been set to “Auto” at the factory; however, if the projector does not project, please
change the input setting to “Your Country’s Television Broadcast System” using the menu sequence of [Setup] → [Input Format]
→ [Video].
See “Input Format” on Page E-56.
Video Equipment with S-VIDEO Connectors
• Make the connection to the S-VIDEO connector of the projector using the supplied S-video cable.
• The input setting of the S-VIDEO connector has been set to “Auto” at the factory; however, if the projector does not project,
please change the input setting to “Your Country’s Television Broadcast System” using the menu sequence of [Setup] → [Input
format] → [S-Video].
See “Input Format” on Page E-56.
Video deck, DVD player, document
camera, etc.
Video cable (Supplied item)
S-Video cable (Suppled item)
VIDEO
S-VIDEO
E-20
Connecting Personal Computers and Video Equipment
Connections with Component Signals
When the Video Equipment Has a YCbCr Connector or YPbPr Connector
• The projector has been set to “Auto” at the factory; however, if it does not project, please change the input setting to “Compo-
nent” using the menu sequence of [Setup] → [Input Format] → [RGB].
See “Input Format” on Page E-56.
• When projecting the YCbCr signal or YPbPr signal, if the color of the overall image strongly leans toward being greenish or
another color, change the setting under the menu of [Color] → [Color Space].
See “Color Space” on Page E-50.
Component cable (Available as an option)
Order code: 28-690
Green
Blue
Red
Green
Blue
Red
Component cable (Available as an option)
Order code: 28-690
COMPONENT
CrCbY
COMPONENT
PrPbY
E-21
Loading...
