IMPORTANT SAFETY INFORMATION

Precautions

Please read this manual carefully before using your PLUS Data Projector and keep the manual handy for future reference.
This User’s Manual applies to the U5-632h, U5-732h, U5-532h and U5-512h Data Projectors. The resolution differs from model to
model, and not all models have the high brightness black/white mode or the PC mouse function. This User’s Manual describes the
U5-632h (the full-function model). Also note that the included remote control unit differs from model to model.
Please check the resolution, functions and type of remote control unit on the table below.

Model Resolution (Full Functions)

U5-632h
U5-732h
U5-532h
U5-512h

Applicable projectors will be indicated by Applicable Projector: U5-XXX placed at the description location.

TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PLUS SERVICE PERSONNEL.

This symbol warns the user that uninsulated voltage within the unit may have sufficient magnitude to cause electric
shock. Therefore, it is dangerous to make any kind of contact with any part inside of this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been
included. Therefore, it should be read carefully in order to avoid any problems.

The above cautions are given on the bottom of the product.

1024⳯768 (XGA)
1024⳯768 (XGA)
1024⳯768 (XGA)

800⳯600 (S-VGA)

Black/White

mode

嘷
ⳮ
嘷
ⳮ

CAUTION

Type of included remote control unit

Wireless remote control unit with laser pointer (w/ PC
mouse function)
Wireless remote control unit (w/o laser pointer or PC
mouse function)

嘷: Function included ⳮ: Function not included

WARNING

TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE THIS UNIT’S
GROUNDED PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THREE PRONGS CAN BE FULLY
INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. ALL SERVICING MUST
BE DONE BY QUALIFIED PLUS SERVICE PERSONNEL.

Applicable Projector: U5-632h/U5-732h

CAUTION

Do not look at the laser pointer’s light source.

Be sure to heed the following. Pointing the laser beam at
the eyes could lead to reduced vision or vision impairment.

• Never look at the laser pointer’s light source.

• Do not point the laser beam at people.

• Do not let children use the laser pointer.

Hg: Lamp in This Product Contains Mercury. Dispose of Lamp According to Local, State or Federal Law.

WARNING

This is a class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.

RF Interference

WARNING

The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by
PLUS Vision in this manual. Failure to comply with this government regulation could void your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.

This label is located on the side of the remote control.

DOC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

E-2

IMPORTANT SAFETY INFORMATION

Important Safeguards

These safety instructions are to ensure the long life of the unit and to prevent fire and shock. Please read them
carefully and heed all warnings.

Installation

• For best results, use the unit in a darkened room.

• Place the unit on a flat, level surface in a dry area away from dust and moisture.

• Do not place the unit in direct sunlight, near heaters or heat radiating appliances.

• Exposure to direct sunlight, smoke or steam can harm internal components.

• Handle the unit carefully. Dropping or jarring can damage internal components.

• Do not place heavy objects on top of the unit.

Power Supply

• The unit is designed to operate on a power supply of 100 – 120/220 – 240 V 50/60 Hz AC. Ensure that your
power supply fits these requirements before attempting to use the unit.

• Handle the power cable carefully and avoid excessive bending. A damaged cord can cause electric shock or
fire.

• Disconnect the power cable (mains lead) from the power outlet after using the unit.
Before disconnecting the power cable, make sure that the STANDBY indicator lights in amber (not blinking or
in green).

Cleaning

• Disconnect the power cable (mains lead) from the unit.

• Clean the cabinet of the unit periodically with a damp cloth. If heavily soiled, use a mild detergent. Never use
strong detergents or solvents such as alcohol or thinner.

• Use a blower or lens paper to clean the lens, and be careful not to scratch or mar the lens.

• Clean the ventilation slots and speaker grills on the unit periodically using a vacuum cleaner. If accumulated
dust blocks the ventilation slots, the unit will overheat, which may cause the unit to malfunction.
Use a soft brush attachment when using the vacuum cleaner. Do not use a hard attachment, such as a crevice
tool, to prevent the damage to the unit.

Lamp Replacement

• Be sure to replace the lamp when the Status indicator comes on. If you continue to use the lamp after 2000
hours of usage, the lamp will turn off.

Fire and Shock Precautions

• Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the buildup of heat inside
the unit. Allow at least 10 cm (3 inches) of space between the unit and walls.

• Prevent foreign objects such as paper clips and bits of paper from falling into the unit. Do not attempt to retrieve
any objects that fell into the unit. Do not insert any metal objects such as a wire or screwdriver into the unit. If
something should fall into the unit, immediately disconnect the power cable from the unit and have the object
removed by a qualified PLUS service person.

• Do not place any liquids on top of the unit.

Cautions on Handling the Storage Case

• Do not put anything other than the unit or its accessories in the storage case. Paper clips, staples or other metal
or foreign objects getting inside could cause fire or electric shock.

• Do not swing the storage case around when the unit is inside. Also do not force objects that are too large to fit
into the storage case. Doing so could scratch or damage the unit.

When Moving the Unit

• When moving the unit to a different place, put it in the included storage case and place the storage case in an
insulating package to protect against falls and shocks.

• If there are paper clips, staples or other metal or foreign objects inside the storage case, the objects could get
inside the unit while the unit is being moved, causing fire or electric shock when the power is turned on.

CAUTION – HOT!

The area around the exhaust vents is hot during and immediately after image projection.
To avoid burns, keep your hands away from this area.
Wait until the exhaust vents area cools off before touching it.

Do not look into the lens while the unit is on. Serious damage to your eyes could result.

E-3

Major Features

䡵 Lightweight high-intensity projector

The synergy of the DLP™ (Digital Light Processing) display system and our own optical design serve to improve the optical
utilization efficiency. The three primary colors (RGB) required in color expression are reproduced with one DLP™ chip. These
factors have enabled a design that offers both high intensity and small size/lightweight features.

䡵 Sharp, clear picture

The DLP™ display system affords RGB color fidelity and inconspicuous gaps between the individual dots, thereby permitting
the display of small characters and diagrams with distinct clarity.

䡵

Industry’s first B/W mode for switching from the color mode to an image with a stronger brightness

Applicable Projector: U5-632h/U5-532h

When projecting documents, spreadsheets or other mostly black and white data, the image can be projected with stronger
brightness than in the color mode by switching to the “Color B/W Switching” in the menu settings. This function is a first for a
projector, and takes advantage of the features of high contrast rate DLP projectors.

䡵 Powerful functions for presentations

A wide variety of easy-to-set functions have been built into the projector, from a digital keystone correction function (used
when making settings) that corrects picture distortion, to an auto adjustment function that automatically identifies the PC
signal.
A presentation timer that supports presentations and a security lock function protecting against unauthorized projection have
also been added.

䡵 High contrast ration of 2000:1

Use of a new generation of DLP™ chip devices has given birth to an amazing 2000:1 high contrast ratio.
By widening the difference of brightness between black and white, you can see a degree of sharpness that is greater than just
the brightness based on specifications.

䡵 Beautiful reproduction of high-quality images from DVD

Faithful reproduction of color tones gives rise to the display of natural images. High-quality images such as those from DVD
and digital high-definition television broadcasts bring out the display capabilities that are an essential strength of the DLP™
display system projector.

䡵 Econo-mode switch function for the lamp output

Using the lamp Econo-mode will extend the life of the lamp and lower the power consumption.
By switching the lamp mode to suit your operating environment, you will save on lamp cost as well as contribute to energy
conservation and ecology.

E-4

Table of Contents

IMPORTANT SAFETY INFORMATION ................................................................................... E-2

Major Features ....................................................................................................................... E-4

Table of Contents ................................................................................................................... E-5

Checking the Supplied Accessories .................................................................................... E-7

Names of the Main Unit Parts ............................................................................................... E-9

Names of the Remote Control Parts/Preparing the Remote Control .............................. E-11

Names of Parts/Preparing the Remote Control Unit

Included with the U5-632h and U5-732h ................................................................... E-11

Names of Parts/Preparing the Remote Control Unit

Included with the U5-532h and U5-512h ................................................................... E-12

Remote Control Range ............................................................................................. E-12

The Procedure Up to Projecting to the Screen ................................................................. E-13

Placement Guide .................................................................................................................. E-14

U5-632h Screen Size and Projection Distance ......................................................... E-14

U5-732h Screen Size and Projection Distance ......................................................... E-15

U5-532h/U5-512h Screen Size and Projection Distance .......................................... E-16

Connecting Personal Computers and Video Equipment .................................................. E-17

Connections with Personal Computer ....................................................................... E-17

Connect the projector’s RGB connector using the included RGB signal cable. .. E-17

To Output the External Output Signal of a Notebook Computer ......................... E-18

Connections with Composite Signals ........................................................................ E-19

Video Equipment with VIDEO Connectors .......................................................... E-19

Video Equipment with S-VIDEO Connectors ...................................................... E-19

Connections with Component Signals ....................................................................... E-20

When the Video Equipment Has a YCbCr Connector or YPbPr Connector ........ E-20

Connections with the AUDIO Jack ............................................................................ E-21

Connections with the RGB OUT Connector .............................................................. E-22

Power Cable Connections and Switching the Power On/Off ........................................... E-23

Operating ................................................................................................................... E-23

Finishing .................................................................................................................... E-25

Adjustment of the Projection Screen ................................................................................. E-26

Adjustment of the Projection Screen ......................................................................... E-26

Making Adjustments with the Adjusters .............................................................. E-27

General Operation ................................................................................................................ E-28

Input Selection .......................................................................................................... E-28

Automatic Adjustment ............................................................................................... E-28

Selection of Aspect Ratio .......................................................................................... E-29

Freezing a Moving Picture ......................................................................................... E-30

Cancelling Video and Audio Temporarily ................................................................... E-30

Lamp Mode ............................................................................................................... E-30

Keystone.................................................................................................................... E-31

Adjustment of the Volume .......................................................................................... E-31

Enlargement of the Image and Video Movement ...................................................... E-32

Using the Presentation Timer .................................................................................... E-33

Using the Laser Pointer ............................................................................................. E-34

Performing Mouse Operations on the Computer

with the Remote Control Unit .................................................................................... E-35

Controlling the Projector from a Computer ................................................................ E-36

Use as a High-Brightness Monochrome Projector .................................................... E-36

Protecting the Projector with the Security Lock ......................................................... E-37

Using the Quick Menu ............................................................................................... E-39

Menu Operation Method ...................................................................................................... E-40

Performing Menu Operations .................................................................................... E-42

List of Item Names Offering Input Selection and Adjustments/Settings .................... E-45

Image ..................................................................................................................................... E-47

Brightness / Contrast / Color / Tint / Sharpness ........................................................ E-47

Picture Adj. / Fine Picture / H Position / V Position .................................................... E-47

Reset ......................................................................................................................... E-48

E-5

Table of Contents

Color ...................................................................................................................................... E-49

Quick Color Adj. ........................................................................................................ E-49

Gamma ..................................................................................................................... E-49

Color Temp. ............................................................................................................... E-50

White ......................................................................................................................... E-50

Color Space .............................................................................................................. E-50

White Balance ........................................................................................................... E-51

View ....................................................................................................................................... E-52

Aspect ....................................................................................................................... E-52

Filter .......................................................................................................................... E-52

Vertical Flip ................................................................................................................ E-53

Keystone.................................................................................................................... E-53

Keystone Save .......................................................................................................... E-53

Setup ..................................................................................................................................... E-54

Color B/W Switching ................................................................................................. E-54

Auto Source............................................................................................................... E-54

Auto Power Off .......................................................................................................... E-54

Menu Position............................................................................................................ E-55

Lamp Mode ............................................................................................................... E-55

Input Format .............................................................................................................. E-56

Presentation Timer .................................................................................................... E-56

Option ................................................................................................................................... E-57

Language .................................................................................................................. E-57

On Screen ................................................................................................................. E-57

Background ............................................................................................................... E-57

Startup Screen .......................................................................................................... E-58

Security Lock ............................................................................................................. E-58

Info......................................................................................................................................... E-59

Status ........................................................................................................................ E-59

Factory Default .......................................................................................................... E-59

Lamp Timer Reset ..................................................................................................... E-59

Resolution / Frequency ............................................................................................. E-60

Lamp Timer ............................................................................................................... E-60

When an Indicator is Lit or Flashing .................................................................................. E-61

Troubleshooting ................................................................................................................... E-62

Cleaning ................................................................................................................................ E-63

Replacing the Lamp Cartridge ............................................................................................ E-64

Specifications ....................................................................................................................... E-67

Table of Supported Frequency ........................................................................................... E-71

Cabinet Dimensions ............................................................................................................ E-72

E-6

Checking the Supplied Accessories

Remove the main unit and the accessories from the box and check that the following items are included.

Wireless remote control unit with laser pointer [1] /
Size AAA batteries [2]

Applicable Projector: U5-632h/U5-732h

This controls the projector. (See Page E-11.)

4

M

ZOO

3

L

VO

12

TIMER

EL

C

CAN

MUTE

-CLICK/
R

Q

QUICK

AUTO

LASER

VIDEO

MENU

RGB

STANDBY

ENTER

FREEZE

* The wireless remote control is sold separately for the U5-

532h and U5-512h.
VR-100 remote mouse set (sold separately)
(Ordering code: 28-052)

Wireless remote control unit
(includes one button battery) [1]

Applicable Projector: U5-532h/U5-512h
This controls the projector. Please remove the transportation
insulation sheet at time of purchase. (See Page E-12.)

R

E

IM

T

T

C

E

M

P

S

O

A

TO

U

A

TN ZO

O

C

E

Q

K

IC

U

Q

U

R

EN

E

L

M

T

E

N

C

E

N

A

C

B

G

R

Y

B

D

N

A

T

S

LKS

O

V

TE

U

M

1234

ZE

E

E

R

F

O

E

ID

V

S-Video cable (Mini DIN 4-pin plug, 2 m / 6.6 feet) [1]

Applicable Projector: U5-632h/U5-732h/U5-532h
This cable is used in the connection of video equipment that
has an S-video connector. Connections are described on Page
E-19.

No. 777704000

Video cable (RCA pin plug, 2 m / 6.6 feet) [1]

Applicable Projector: U5-632h/U5-732h/U5-532h
This cable is used in the connection of video equipment that
has a video connector. Connections are described on Page
E-19.

No. 777703000

RGB signal cable
(Mini D-sub 15-pin, 2 m / 6.6 feet) [1]

This is used in making connections with a personal computer.
See Page E-17 about connections.

No. 777709000

Power cable (1.8 m / 5.9 feet) [1]

This power cable supplies power to the unit. See Page E-23
about connections.

Audio cable (Mini plug, 2 m / 6.6 feet) [1]

Applicable Projector: U5-632h/U5-732h/U5-532h
This cable is used with equipment that has phono type audio
jacks. Connections are described on Page E-21.

No. 777705000

Audio conversion adapter (Mini-jack/ RCA pin plug, 15 cm
/ 0.5 feet) [1]

Applicable Projector: U5-632h/U5-732h/U5-532h
This cable is used with equipment whose audio connector is
of the phono pin type. Connections are described on Page
E-21.

No. 777706000

E-7

Checking the Supplied Accessories

USB cable (type A, 2 m / 6.6 feet) [1]

Applicable Projector: U5-632h/U5-732h
Used to perform mouse operations on a computer using the
projector’s remote control unit. Connections are described on
Page E-35.

No. 777707000

* The wireless remote control is sold separately for the U5-

532h and U5-512h.
VR-100 remote mouse set (sold separately)
(Ordering code: 28-052)

Storage case (for projector and accessories) [1]

This case is designed to hold the projector itself and its acces­sories.
Use it when storing the projector.

User’s Manual (CD-ROM edition) [1]
User’s Manual (Simplified Edition) [1]
Security Sheet [1]
Security Label [1]

HOW TO PUT THE PROJECTOR INTO THE STORAGE CASE

Close the lens shutter or lens cap before putting the projec­tor in its case, then fasten the projector in place with the
Velcro belt. Place the accessories in the storage pocket.

Velcro strap

Pocket

Cable storage pouch [1]

E-8

D

B

Names of the Main Unit Parts

D

B

Applicable Projector: U5-632h

STANDBY

STANDBY

Zoom ring [E-26]

Focus ring [E-27]

Exhaust vents

Remote control
sensor [E-12]

Applicable Projector: U5-732h

Zoom ring [E-26]

Lens

N
A

T

S

S

U

T

A
T

S

STATUS

SOURCE

AUTO

Ventilation slots

Adjuster button [E-27]
(Also on opposite side)

Exhaust
vents

Remote control
sensor [E-12]

Focus ring [E-27]

Lens

Lens cap

N

A

T

S

Y

B

D

Applicable Projector: U5-532h/U5-512h

Zoom ring [E-26]

N
A

T

S

S

U

T

A

T

S

Exhaust
vents

Focus ring [E-27]

Lens cap
Remove before use. Attach
the lens cap after use to
protect the lens.

Ventilation slots

Lens

Lamp cover [E-65]

Lens cap

Adjusters [E-27]

E-9

Names of the Main Unit Parts

STATUS indicator [E-23, 61]

STANDBY indicator [E-23, 61]

STANDBY button [E-23]

AUTO button [E-28]

SOURCE button [E-28]

Remote control sensor [E-12]

AC IN connector [E-23]

STATUS

STANDBY

STANDBY

AUTO

SOURCE

STATUS

STANDBY

STANDBY

AUTO

RGB

S VIDEO

VIDEO

AUDIO

MOUSE

SOURCE

P

C

C

O

N

T

R

O

L

Speaker

Built-in security slot

Ventilation slots

MOUSE connector [E-35]

Applicable Projector: U5-632h/U5-732h/U5-532h

(See description below.)

AUDIO connector [E-21]

RGB

S VIDEO

VIDEO

AUDIO

MOUSE

VIDEO connector [E-19]

PC CONTROL connector (D-Sub 9-pin) [E-36]

Applicable Projector: U5-512h

S-VIDEO connector [E-19]

RGB connector [E-17, 20]

RGB OUT connector (Mini D-sub 15-pin) [E-22]

Built-in Security Slot

This security slot supports the MicroSaver Security System manufactured by
Kensington Microware Inc.

PC CONTROL

RGB OUT

E-10

Names of the Remote Control Parts/Preparing the Remote Control

There are two types of remote control units included with the U5 series of projectors. Both types are described below.
Refer to the description (and diagram) for the remote control unit included with your projector.

Precautions
Handling of the Remote Control

* Do not drop the remote control or handle it inappropriately.
* Do not expose the remote control to water or other liquids. Should the remote control become wet, wipe it dry

immediately.
* Try to avoid use in hot and/or humid locations.
* Please keep button batteries out of the reach of children. If a battery is swallowed, promptly obtain the medical care

of a doctor.
* Remove the batteries from the remote control when it is not going to be used for a long period.
* Some operations (such as menu operations) are available only through the use of the remote control and attention

should be given to its careful handling.

Names of Parts/Preparing the Remote Control Unit
Included with the U5-632h and U5-732h

Names of the Remote Control Parts

1
2
3

4

STANDBY

RGB

5

VIDEO

LASER

AUTO

QUICKMENU

Q

6

R-CLICK/

MUTE

CANCEL

TIMER

ENTER

FREEZE

7

12

VOL

8

ZOOM

34

10

11

12

13

14

15

16

9

1. Infrared transmitter [E-12]

2. Laser transmitter [E-34]

3. L-CLICK button [E-35]

4. STANDBY button [E-23, 25]

This button is used to switch ON the power
and set the unit to the STANDBY mode.

5. Buttons used for input selection
[E-28]

RGB button and VIDEO button (VIDEO /
S-VIDEO)

6. Buttons used for menu operations
[E-40]

The , , and buttons are the
select (왖, 왔, 왗 and 왘) buttons.

7. FREEZE button [E-30]

(Freezes moving pictures)

8. VOL button [E-31]

(Volume adjustment)

9. Number buttons [E-37]

(Used for the security lock.)

10. LASER button [E-34]

(Turns the laser point on and off)

Applicable Projector:
U5-632h/U5-732h

11. AUTO button [E-28]

(Automatic adjustment of the RGB moving
image)

12. QUICK button [E-39]

(Displays a simplified menu)

13. Buttons used for the PC mouse
function [E-35]

(JOG button and R-CLICK button)

14. TIMER button [E-33]

(Presentation timer time setting display)

15. MUTE button [E-30]

(Temporarily cancels the video and audio)

16. ZOOM button [E-32]

(Digital zoom adjustment)

Note:

If a button on the remote control unit is held
in continuously for approximately 30 seconds,
signal transfer will be suspended. To resume
transferring signals, press the button again.
Also, to use the jog button after signal trans­fer has been suspended, first press any other
button, then press the jog button.

Inserting the Batteries

When using the remote control for the first time, install the batteries that were supplied.

Slide the battery compartment

1

cover (located on the bottom
of the remote control) and pull
off.

CAUTION

When replacing batteries, purchase two of the same type of AAA battery.
Heed the regulations in effect in your region on the disposal of spent batteries.

Insert the batteries to match

2

the “+” and “–” as indicated in-
side the compartment.

(A) Leaving a little space in the front, close

3

the lid, (B) then with the back pressed tightly,
(C) press the lid towards the front.

E-11

(A)

(C)

(B)

Names of the Remote Control Parts/Preparing the Remote Control

CR2025

Names of Parts/Preparing the Remote Control Unit
Included with the U5-532h and U5-512h

Names of the Remote Control Parts

2

1

1. Infrared transmitter [E-12]

9

2. STANDBY button [E-23, 25]

This button is used to switch ON the power

3

STANDBY

RGB

VIDEO

4

FREEZE

5

1234

6

VOL KSTN ZOOM

7

MENU

ENTER

CANCEL QUICK

ECO AUTO

MUTE

ASPECT

TIMER

Q

and set the unit to the STANDBY mode.

10

3. Buttons used for input selection
[E-28]

11

RGB button and VIDEO button (VIDEO /
S-VIDEO)

12

4. MUTE button [E-30]

(Temporarily cancels the video and audio)

13

5. Number buttons [E-37]

(Used for the security lock.)

6. FREEZE button [E-30]

14

(Freezes moving pictures)

7. VOL button [E-31]

(Volume adjustment)

8

15

8. KSTN button [E-31]

(Keystone correction adjustment)

Button Battery Replacement

Using the remote control for the first time

The battery compartment is fitted with a transportation insulation sheet at the time of shipping. Pull out
the sheet and remove it. The remote control is now ready for use.

Replacement Method

(A) With the knob pressed to the

1

right side, (B) draw out the battery

case.

(A)

(B)

CAUTION

Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type (CR2025) recommended by the manufacturer.
Dispose of used batteries according to your local regulations.

Remove the old battery and install

2

a new button battery with (+) side
facing upward in the battery
holder.

CR2025

CR2025

Purchase a CR2025 type battery for replacement.

9. Buttons used for menu operations
[E-40]

The

, , and buttons are the

select (왖, 왔, 왗 and 왘) buttons.

10. QUICK button [E-39]

(Displays a simplified menu)

11. ECO button [E-30]

(Selection of lamp mode)

12. AUTO button [E-28]

(Automatic adjustment of the RGB moving
image)

13. ASPECT button [E-29]

(Selects the vertical and horizontal ratio of
the screen)

14. TIMER button [E-33]

(Presentation timer time setting display)

15. ZOOM button [E-32]

(Digital zoom adjustment)

Insert the battery holder into the

3

remote control and push in until
the battery holder closes with a
“click” sound.

Applicable Projector:
U5-532h/U5-512h

Remote Control Range

Point the infrared transmitter of the remote control toward the remote control sensor located at the front or rear of the main unit
and operate. Reception of the remote control signal should generally be possible within the range illustrated below.

Applicable Projector: U5-532h/U5-512hApplicable Projector: U5-632h/U5-732h

Remote control infrared transmitter Remote control infrared transmitter

Remote control

20°

20°

5m/16.4feet

infrared transmitter

30°

6m/19.7 feet

5° 5°

Remote control sensor Remote control sensor

30°

5m/16.4feet

Side View Top View

3m/9.8 feet

Remote control sensor

5° 5°

Note

* Exposure of the main unit’s remote control sensor or the remote control infrared transmitter to bright light or the obstruction of the signal

by an obstacle located in the pathway may prevent operation.
* The remote control will not function when the battery is exhausted.

E-12

Remote control
infrared transmitter

6m/19.7 feet

Remote control sensor

Side View Top View

3m/9.8 feet

The Procedure Up to Projecting to the Screen

Perform setup adjustments in the following order.

1 Position the projector

Determine the locations to set up the screen and the projector.
See “Placement Guide” on Page E-14.

2 Connect the video equipment and personal computer

Connect your equipment to the projector.

When making connections with the personal computer’s RGB connector, see “Connections with
Personal Computer” on Page E-17.

When making connections with the video equipment’s video connector or an S-video connector,
see “Connections with Composite Signals” on Page E-19.

When making connections with the video equipment’s YCbCr connector or YPbPr connector,
see “Connections with Component Signals” on Page E-20.

When playing the audio through the built-in speaker of the projector, see “Connections with the
AUDIO Jack” on Page E-21.

Monitoring the analog RGB input signal, see “Connections with the RGB OUT Connector” on
Page E-22.

3 Opening the lens cap

4 Connecting the power cable and switching on the power

See “Operating” on Page E-23.
See “Finishing” on Page E-25.

5 When selecting the language of menu displays, etc.

(Only when the power is first switched on following purchase)

See “When [Menu Language Select] Is Displayed Upon Switching On the Power” on Page E-24.

Applicable Projector: U5-512h

6 Switching on the power of the personal computer and video equipment

7 Properly adjust the projection image to the screen

See “Adjustment of the Projection Screen” on Page E-26.

8 Selecting input equipment

See “Input Selection” on Page E-28.

9 Adjust the screen or video image

Adjust the image to the optimum condition as required.
See the Table of Contents for the adjustment items.

About DLP projectors

Though careful attention is paid to providing optimum quality, please note that with DLP type projectors, in rare cases there may
be black spots or bright spots among the picture elements.

Note:

* Please purchase a screen.
* A component cable (order code 28-690), which is available separately, is required to connect a DVD player or other equipment with YCbCr

connectors.
* A component cable (order code 28-690), which is available separately, is required to connect high definition (HD) video equipment or other

equipment with YPbPr connectors.

E-13

Placement Guide

• Use this information as a guide to find out about the screen size when the projector is placed at a certain location, or
to find out the approximate size of a screen that will be required.

• Refer to the projection distance table for your projector model.

• When suspending the projector from the ceiling, change the projection method. See “Vertical Flip” on E-53.

U5-632h Screen Size and Projection Distance

• The projection distance over which focussing is adjustable is 1.20 m (3.94 feet) to 9.59 m (31.46 feet). The projector
should be placed within this range.

Screen Size Designation (Inches)

300"

Height from center of
lens to top edge of
the projection

h1

Height from center of
lens to bottom edge
of the projection

h2

–26.18)

7.97

–31.46)

–9.59(26.15

Unit: m (feet)

Width

Screen size (Diagonal)

Height

60"

38.4"

1.20
(3.94)

1.57–1.90(5.15–6.23)

Lens surface of
the main unit

80"

120"

100"

2.10

180"

150"

–8.33)

–2.54(6.89

–3.18(8.66

2.64

200"

3.17

250"

–10.43)

–12.50)

–3.81(10.40

3.97

–15.68)

–4.78(13.02

4.77

–18.80)

–5.73(15.65

–6.38(17.39

5.30

–20.93)

6.64

–7.98(21.78

Screen Size

Designation (Inches)

Screen Size Width x Height Projection Distance Height h1 Height h2

(m) (feet)

(m) (feet) (m) (feet) (m) (feet)

Wide – Tele Wide – Tele

38.4"

60"

80"

100"

120"

150"

180"

200"

250"

300"

0.78⳯0.59

1.22⳯0.91

1.63⳯1.22

2.03⳯1.52

2.44⳯1.83

3.05⳯2.29

3.66⳯2.74

4.06⳯3.05

5.08⳯3.81

6.10⳯4.57

2.56 ⳯ 1.92

4.00 ⳯ 3.00

5.33 ⳯ 4.00

6.67 ⳯ 5.00

8.00 ⳯ 6.00

10.00 ⳯ 7.50

12.00 ⳯ 9.00

13.33 ⳯10.00

16.67 ⳯12.50

20.00 ⳯15.00

—– 1.20

1.57 – 1.90

2.10 – 2.54

2.64 – 3.18

3.17 – 3.81

3.97 – 4.78

4.77 – 5.73

5.30 – 6.38

6.64 – 7.98

7.97 – 9.59

—– 3.94

5.15 – 6.23

6.89 – 8.33

8.66 – 10.43

10.40 – 12.50

13.02 – 15.68

15.65 – 18.80

17.39 – 20.93

21.78 – 26.18

26.15 – 31.46

0.69

1.08

1.43

1.79

2.15

2.69

3.23

3.59

4.48

5.38

2.26

3.54

4.69

5.87

7.05

8.83

10.60

11.78

14.70

17.65

0.10

0.16

0.22

0.27

0.32

0.40

0.49

0.54

0.67

0.81

0.33

0.52

0.72

0.89

1.05

1.31

1.61

1.77

2.20

2.66

* There is a tolerance of ±5% due to design values.
* This table uses the lens apex and lens center as references and requires that the projector be in a horizontal condition

(with front and rear adjusters fully withdrawn).

E-14

Placement Guide

U5-732h Screen Size and Projection Distance

• The projection distance over which focussing is adjustable is 1.20 m (3.94 feet) to 13.81 m (45.31 feet). The projector
should be placed within this range.

Screen Size Designation (Inches)

300"

Height from center of
lens to top edge of
the projection

h1

Height from center of
lens to bottom edge
of the projection

h2

40"

33"

27"

250"

200"

150"

120"

100"

80"

60"

1.20

ST
A

T
U
S

S
T
A

N
D
B
Y

S
T

A
N
D
B

(3.94)

Y

A

U
T
O

S
O

R

U

G

R

B

C
E

S
V
I
D
E
O

V
I
D
E
O
A
U

D
I
O
M
O
U

S
E

P
C
C
O
N

T
R
O
L

1.23–1.48

Lens surface of
the main unit

(4.04–4.86)

1.49–1.80
(4.89–5.91)

2.26–2.73
(7.41–8.96)

3.03

–11.98)

–3.65(9.94

3.80–4.57(12.47

–14.99)

–18.04)

5.73–6.88(18.80

4.57–5.50(14.99

–22.57)

7.65–9.19(25.10

–30.15)

9.57–11.50(31.40

–37.73)

11.50–13.81(37.73

–45.31)

Unit: m (feet)

Width

Screen size (Diagonal)

Screen Size

Designation (Inches)

Screen Size Width x Height Projection Distance Height h1 Height h2

(m) (feet)

(m) (feet) (m) (feet) (m) (feet)

Wide – Tele Wide – Tele

27"

33"

40"

60"

80"

100"

120"

150"

200"

250"

300"

0.56⳯0.41

0.67⳯0.50

0.81⳯0.61

1.21⳯0.91

1.62⳯1.21

2.03⳯1.52

2.43⳯1.82

3.04⳯2.28

4.06⳯3.04

5.08⳯3.81

6.09⳯4.57

1.83 ⳯ 1.35

2.19 ⳯ 1.64

2.65 ⳯ 2.00

3.96 ⳯ 2.98

5.31 ⳯ 3.96

6.66 ⳯ 4.98

7.97 ⳯ 5.97

9.97 ⳯ 7.48

13.32 ⳯ 9.97

16.66 ⳯12.50

19.98 ⳯14.99

—– 1.20

1.23 – 1.48

1.49 – 1.80

2.26 – 2.73

3.03 – 3.65

3.80 – 4.57

4.57 – 5.50

5.73 – 6.88

7.65 – 9.19

9.57 – 11.50

11.50 – 13.81

—– 3.94

4.04 – 4.86

4.89 – 5.91

7.41 – 8.96

9.94 – 11.98

12.47 – 14.99

14.99 – 18.04

18.80 – 22.57

25.10 – 30.15

31.40 – 37.73

37.73 – 45.31

0.48

0.59

0.72

1.07

1.43

1.79

2.14

2.68

3.58

4.48

5.38

1.57

1.94

2.36

3.51

4.69

5.87

7.02

8.79

11.75

14.70

17.65

0.07

0.09

0.11

0.16

0.22

0.27

0.32

0.40

0.54

0.67

0.81

0.23

0.30

0.36

0.52

0.72

0.89

1.05

1.31

1.77

2.20

2.66

* There is a tolerance of ±5% due to design values.
* This table uses the lens apex and lens center as references and requires that the projector be in a horizontal condition

(with front and rear adjusters fully withdrawn).

Height

E-15

Placement Guide

U5-532h/U5-512h Screen Size and Projection Distance

• The projection distance over which focussing is adjustable is 1.20 m (3.94 feet) to 13.36 m (43.83 feet). The projector
should be placed within this range.

Screen Size Designation (Inches)

300"

Height from center of
lens to top edge of

250"

200"

180"

150"

the projection

h1

Height from center of
lens to bottom edge
of the projection

27.6"

40"

1.20
(3.94)

1.46–1.75(4.79

60"

2.20

100"

80"

–5.74)

–2.65(7.22

120"

–8.69)

–3.54(9.65

2.94

–11.61)

–4.43(12.04

3.67

–14.53)

–5.33(12.04

4.43

–14.53)

5.54

–21.88)

–6.67(18.18

–8.00(21.88

6.67

–26.25)

–8.90(24.28

7.40

–29.20)

9.62

–36.52)

–11.13(31.56

h2

–13.36(36.48

11.12

–43.83)

Width

Unit: m (feet)

Lens surface of
the main unit

Screen Size

Designation (Inches)

Screen Size Width x Height Projection Distance Height h1 Height h2

(m) (feet)

(m) (feet) (m) (feet) (m) (feet)

Screen size (Diagonal)

Wide – Tele Wide – Tele

27.6"

40"

60"

80"

100"

120"

150"

180"

200"

250"

300"

0.56⳯0.42

0.81⳯0.61

1.22⳯0.91

1.63⳯1.22

2.03⳯1.52

2.44⳯1.83

3.05⳯2.29

3.66⳯2.74

4.06⳯3.05

5.08⳯3.81

6.10⳯4.57

1.84 ⳯ 1.38

2.67 ⳯ 2.00

4.00 ⳯ 3.00

5.33 ⳯ 4.00

6.67 ⳯ 5.00

8.00 ⳯ 6.00

10.00 ⳯ 7.50

12.00 ⳯ 9.00

13.33 ⳯10.00

16.67 ⳯12.50

20.00 ⳯15.00

—– 1.20

1.46 – 1.75

2.20 – 2.65

2.94 – 3.54

3.67 – 4.43

4.43 – 5.33

5.54 – 6.67

6.67 – 8.00

7.40 – 8.90

9.62 – 11.13

11.12 – 13.36

—– 3.94

4.79 – 5.74

7.22 – 8.69

9.65 – 11.61

12.04 – 14.53

14.53 – 17.49

18.18 – 21.88

21.88 – 26.25

24.28 – 29.20

31.56 – 36.52

36.48 – 43.83

0.49

0.72

1.07

1.43

1.79

2.15

2.69

3.22

3.59

4.48

5.38

1.61

2.36

3.51

4.69

5.87

7.05

8.83

10.56

11.78

14.70

17.65

0.07

0.11

0.16

0.21

0.27

0.32

0.40

0.48

0.54

0.67

0.81

0.23

0.36

0.52

0.69

0.89

1.05

1.31

1.57

1.77

2.20

2.66

* There is a tolerance of ±5% due to design values.
* This table uses the lens apex and lens center as references and requires that the projector be in a horizontal condition

(with front and rear adjusters fully withdrawn).

Height

E-16

Connecting Personal Computers and Video Equipment

Connecting this unit with a personal computer permits presentation data to be projected as a large screen display at
conferences, lectures, and on other occasions. Furthermore, connecting this unit to a DVD player or other video equip­ment source in combination with an audio/video amplifier and speaker system will allow you to enjoy convincing home
theater.

Connections with Personal Computer

Please check the following before making connections with the personal computer.

• A suitable resolution for the U5-512h is 800 ⳯ 600 dots (S-VGA) and the maximum displayable resolution is XGA (1024 ⳯ 768

dots).

• A suitable resolution for the U5-632h/U5-732h/U5-532h is 1024 ⳯ 768 dots (XGA) and the maximum displayable resolution is
S-XGA (1280 ⳯ 1024 dots).
Make changes to a displayable resolution at the personal computer side. Please check with “Table of Supported Frequency” on
Page E-71.

• The setting method for the personal computer will differ depending on the specific model. Please read the personal computer
instruction manual or the on-line help information, or contact the manufacturer of your personal computer.

Connect the projector’s RGB connector using the included RGB signal cable.

• When making connections with the RGB connector of the projector, please make the connection via the supplied RGB signal
cable.

• The projector has been set to “Auto” at the factory; however, if it does not project, please change the input setting to “RGB”
using the menu sequence of [Setup] → [Input Format] → [RGB].
See “Input Format” on Page E-56.

• If the USB cable is connected to the projector’s MOUSE connector, mouse operations can be performed on the computer from
the projector’s remote control unit. Applicable Projector: U5-632h/U5-732h
See “Performing Mouse Operations on the Computer with the Remote Control Unit” on Page E-35.

MONITOR OUT

Personal
computer

RGB signal cable (Supplied item)

Note:

* Before making connections, check the power of the projector and the equipment to be connected is switched off.
* When projection will be with a notebook computer connected, knowledge will be required for the cable connection and notebook computer

startup procedure as well as the operation that follows startup. Please consult the instruction manual of your notebook computer or the on­line help.

E-17

Connecting Personal Computers and Video Equipment

To Output the External Output Signal of a Notebook Computer

When projection will be with a notebook computer connected, knowledge will be required for the cable connection and notebook
computer startup procedure as well as the operation that follows notebook startup. Please consult the instruction manual of your
notebook computer or the on-line help while performing the following procedure.

Check whether a signal is being sent from the notebook computer to the projector.

1

An indication appearing on the liquid crystal display of the notebook computer does not necessarily mean that an external
output signal is being output.
REFERENCE: When “Resolution” or “Frequency” is not displayed under “Info.” on the menu of the projector, this means that
the external output signal is not being output from the personal computer. See “Resolution/Frequency” on Page E-60.

Should a sign not be output from the notebook computer, please try the operation described below.

2

For an IBM PC/AT compatible computer, press the [Fn] key plus any one of the [F1] to [F10] keys. (See the table below.)

Manufacturer Model Key

DELL All computers Fn + F8

EPSON All computers Fn + F8

FUJITSU All computers Fn + F10

iiyama All computers Fn + F3

IBM All computers Fn + F7

NEC All computers Fn + F3

Panasonic All computers Fn + F3

SHARP All computers Fn + F5

SONY All computers Fn + F7

SOTEC All computers Fn + F3–F5

TOSHIBA All computers Fn + F5

Victor All computers Fn + F10

Note: Table information is current to December 2003.

Note:

When the liquid crystal display of the notebook computer and the projector are displayed at the same time, the projected image might not be
correct even though the liquid crystal display shows a correct indication. Should this occur, stop the simultaneous display of the notebook
computer and try the mode with external output only. Try an operation such as that described in aforementioned Step 2 and try closing the
liquid crystal panel which might result in external output only.

E-18

Connecting Personal Computers and Video Equipment

Connections with Composite Signals

Applicable Projector: U5-632h/U5-732h/U5-532h

Video Equipment with VIDEO Connectors

• The input setting of the VIDEO connector has been set to “Auto” at the factory; however, if the projector does not project, please

change the input setting to “Your Country’s Television Broadcast System” using the menu sequence of [Setup] → [Input Format]
→ [Video].
See “Input Format” on Page E-56.

Video Equipment with S-VIDEO Connectors

• Make the connection to the S-VIDEO connector of the projector using the supplied S-video cable.

• The input setting of the S-VIDEO connector has been set to “Auto” at the factory; however, if the projector does not project,

please change the input setting to “Your Country’s Television Broadcast System” using the menu sequence of [Setup] → [Input
format] → [S-Video].
See “Input Format” on Page E-56.

Video deck, DVD player, document
camera, etc.

VIDEO

S-VIDEO

Video cable (Supplied item)

S-Video cable (Suppled item)

E-19

Connecting Personal Computers and Video Equipment

Connections with Component Signals

When the Video Equipment Has a YCbCr Connector or YPbPr Connector

• The projector has been set to “Auto” at the factory; however, if it does not project, please change the input setting to “Compo-

nent” using the menu sequence of [Setup] → [Input Format] → [RGB].
See “Input Format” on Page E-56.

• When projecting the YCbCr signal or YPbPr signal, if the color of the overall image strongly leans toward being greenish or

another color, change the setting under the menu of [Color] → [Color Space].
See “Color Space” on Page E-50.

Component cable (Available as an option)
Order code: 28-690

Green

Blue

Red

Green

Blue

Red

Component cable (Available as an option)
Order code: 28-690

COMPONENT

CrCbY

COMPONENT

PrPbY

E-20

Connecting Personal Computers and Video Equipment

Connections with the AUDIO Jack

* Make the connection to the projector’s AUDIO jack using the supplied audio cable. When the audio jack of the equipment that

is to be connected is of the RCA phono type, make connection via the supplied audio conversion adapter.

* The built-in speaker of the projector provides monaural audio. To enjoy convincing audio reproduction, please connect the

audio output of the video equipment to your audio system.

* The built-in speaker outputs the audio of the equipment connected to the AUDIO jack.

Audio cable (Supplied item)

Applicable Projector: U5-632h/U5-732h/U5-532h

White

Audio conversion adapter
(Supplied item)

Red

AUDIO OUT

L

R

Audio cable (Supplied item)

E-21

Connecting Personal Computers and Video Equipment

Connections with the RGB OUT Connector

• The image from the computer connected to the RGB connector is output.

• The image of the connector selected with the input selection function is output.

• If an input other than RGB is selected with the input selection function, the output does not switch.

• While controlling the personal computer in front of you, the same screen can be projected with the projector. This allows

personal computer control even from a position at which the projector image cannot be viewed.

Image projected to the screen

Applicable Projector: U5-512h

RGB connector of
the monitor
(Mini D-Sub 15-pin)

E-22
