User Manual
1
Let’s get started ............................................................ 4
Getting to know your phone ........................................... 4
Key definitions
Screen control ............................................................ 5
Open and switch applications .................................. 5
Home Screen .............................................................. 6
Switch to sleep mode ................................................ 7
Wake up your phone .................................................. 7
Make and answer calls ................................................... 8
Make a call
Answer a call .............................................................. 8
Reject a call ................................................................ 9
End a call ..................................................................... 9
Adjust the volume ....................................................... 9
Turn the speaker on or off ......................................... 9
Add one call ................................................................ 9
Open the dialing keypad ........................................... 9
Contacts ............................................................................ 9
Add new contact
Delete contacts ......................................................... 10
Edit contact details ................................................... 10
Search contacts ........................................................ 10
Add a contact to Favorites ...................................... 10
Create a group of contacts ..................................... 11
Accounts .................................................................... 11
Import/Export contacts ............................................ 11
Share a contact ........................................................ 11
Messaging ...................................................................... 12
Send messages
Receive messages ................................................... 12
Message thread ........................................................ 13
Settings ...................................................................... 13
Email ............................................................................... 13
Set up Email account
Send Emails .............................................................. 14
Check Emails ............................................................ 14
Gmail ............................................................................... 14
Contents
............................................................ 4
.................................................................. 8
....................................................... 10
........................................................ 12
............................................... 13
2
Set up an Gmail account for the first time ............ 15
Send Gmails ............................................................. 15
Replying to or forwarding email messages in Gmail ... 15
Network Applications .................................................... 15
Network connection
Wi-Fi ........................................................................... 16
Browser...................................................................... 17
Bluetooth® ................................................................. 17
Settings ........................................................................... 18
Airplane mode
Device ........................................................................ 19
Accounts and sync ................................................... 20
Language .................................................................. 21
Date & time ............................................................... 21
About phone .............................................................. 21
Experiencing Multimedia .............................................. 21
Camera
Music Player ............................................................. 22
Videos Player ............................................................ 23
Gallery ....................................................................... 23
Sound Recorder ....................................................... 24
FM radio .................................................................... 24
More Applications .......................................................... 25
Filemanager
Clock .......................................................................... 25
Calculator .................................................................. 25
Calendar .................................................................... 26
Downloads ................................................................ 27
Maps .......................................................................... 27
Navigation ................................................................. 27
Manage applications ..................................................... 27
Install new applications
Uninstall applications ............................................... 28
................................................. 16
.......................................................... 18
...................................................................... 21
.............................................................. 25
........................................... 27
3
Let’s get started
Thanks for choosing theV765M. It’s a WCDMA
Digital Mobile Phone, which we’ll simply call
‘phone’ from now on. Powered by Android
phone supports 3G high-speed internet access, which
brings you brand new experiences.
To ensure proper phone operation and longevity,
please read this guide carefully.
And don’t worry if the pictures we use to
demonstrate your phone’s functions look a little
different from what you see on its screen. It’s the
functions they show that matter.
This user manual is to introduce the phone’s
functions. For detailed precautions, installation
descriptions, authentication information, please refer
to the Quick Start Guide.
TM
, the
Getting to know your phone
Key definitions
Menu key
Home key
Back key
Power key
Touch it to open a menu with items that
affect the current screen or application.
Touch it to open the home screen. If
you’re viewing the left or right
extended home screen, Press it to open
the central home screen.
Touch it to open the previous screen you
were working in.
If the onscreen keyboard is open, touch
it to close the keyboard.
Press it to turn on/off the display.
Long press it to open a menu with
options for Airplane mode, for Silent
mode, for Vibration mode, and for
powering off and for rebooting the
phone.
4
Vol ume
keys
Screen control
You can control your phone through a series of
operations on the screen.
- Touch: You can touch the items on the screen to
select, to open the applications or to use the
keyboard to input characters.
- Swipe or slide: Quickly move your finger across the
surface of the screen, without pausing when you first
touch (so you don't drag something instead).
- Touch & hold: You can touch & hold some items to
get the item’s available menu.
- Drag: You can drag some items on the screen to
realize some operations.
- Switch between landscape mode and portrait
mode: You can switch to the landscape mode by
rotating your phone. The landscape mode is only
valid under some interfaces, such as the text input
interface, the message viewing interface, etc.
- Pinch: In some apps (such as Maps and Gallery),
you can zoom in and out by placing two fingers on the
screen at once and pinching them together (to zoom
out) or spreading them apart (to zoom in).
Open and switch applications
Open and close the All Apps screen
On the home screen, touch the
All Apps screen. You can slide the All Apps screen left
or right to view more applications.
After opening the All Apps screen, touch an icon to
enter the corresponding application. Touch the Back
key to return to the previous screen. Touch the Home
key to return to the home screen.
Switch to a recently used application
On the home screen, touch & hold the Homekey,
opens a list of thumbnail images of apps you've
Adjust the volume.
Long press it to quickly adjust the ring
tone volume to maximum or minimum.
icon to open the
5
worked with recently. To open an app, touch it. To
remove a thumbnail from the list, swipe it left or right.
Home Screen
Arrange & work with apps
From All Apps, you can:
- Explore your widgets: Touch the widgets tab at the
top of any All Apps screen.
- Get more apps: Touch the Play Store icon at the top
of any All Apps screen.
Manage notifications
- Open notifications panel: When a new notification
appears on the notification bar, you can drag the
notification bar down from the top of the screen to
open notifications panel when your phone has been in
idle mode or lock the screen.
- Respond to a notification: Touch it.
- Dismiss a notification: Swipe it sideways.
- Close notifications panel: Drag the tab at the
bottom of the notification panel to the top of the
screen.
Display area
The home screen can be extended to exceed the
screen’s width in order to provide more space for
newly added shortcuts, widgets, etc.
On the home screen, slide your finger on the screen
to extend to the left or right.
Place an app icon on a Home screen
Touch & hold the app icon, slide your finger, and lift
your finger to drop the icon in place.
Delete items on the homepage
Touch & hold the app icon, slide your finger toward
the top of the screen, and drop the app over the
Remove icon.
Use folders
You can combine several app icons in a folder. Drop
one app icon over another on a Home screen, and the
two icons will be combined.
From any Home screen, you can
6
- Open a folder: Touch it. The folder opens:
- Rename a folder: Touch its name.
- Move icons around your Home screens: Touch,
hold and slide.
Favorites tray
The app icons you keep in the favorites tray remain
visible on every Home screen.
- Place an app icon in the Favorites tray: Touch,
hold, & slide to move one of the Favorites icons out of
the tray. Then use the same technique to move
another one into the same position.
The All Apps icon
you can't move it.
Change wallpaper
1. Touch & hold anywhere that’s not occupied on
the home screen. A list of options appears.
2. Select wallpaper from Gallery/ LiveWallpapers/
Wallpapers.
Switch to sleep mode
Sleep mode is a kind of power saving mode,which
also helps to prevent inadvertent operations. If your
phone has been in idle mode for a while, it will
automaticallyswitch to sleep mode.
You can also press the Powerkey to turn off the
screen and enable sleep mode.
Wake up your phone
After the phone switches to the sleep mode, the
screen will be turned off and locked. In this case,
please awake your phone and unlock the screen if
you want to use your phone.
1. Press the Powerkey to turn on the screen.
2. Drag the
screen.
If you've set anunlockpattern or password, youneed to
draw the unlock pattern or input the password to enter
the main interface. (For details, please see
Systemsettings> Security> Screenlock).
in the center is permanent,
icon to the right tounlock the
7
Make and answer calls
Make a call
Directly make a call
On the home screen or in the All Apps screen, touch
the
the numeric buttons to input the telephone number
and touch the
Make the call from Contacts
On the home screen or in the All Apps screen, touch
the
the phone number to dial it.
Make the call from Call
On the home screen or in the All Apps screen,touch
the
button, notice the three tabs at the top of the
phone, the call log tab
Touch the phone icon in a call log to return it.
Make an international call
On the home screen or in the All Apps screen, touch
the
& hold the “0” key until “+” appears on the
screen, then dial the country code or region code, city
code and phone number.
Dial from Messaging
1. On the home screen or in the All Apps screen,
touch the Messaging icon
2. Select and open one message or conversation.
3. Touch the
Answer a call
Your phone will ring or vibrate (depends on the
current mode and settings) upon an incoming call.
button to display the dialing keypad. Touch
button to make the call.
icon, touch the desired contact and touch
log
shows recent calls.
button to display the dialing keypad. Touch
icon at the top of the phone to dial.
8
- Slide the icon from middle to right to answer
the call.
- If the earphone is inserted, press the key on the
earphone to answer the call.
Reject a call
Slide the
call.
End a call
Touch the
the call.
Adjust the volume
In a call, you can raise or lower the volume by using
the volume keys.
Turn the speaker on or off
In a call, touch the
and touch it again to turn off speaker.
Add one call
In a call, touch the
and touch the phone icon to add one call and put the
current caller on hold. This function requires the
support of the network operator.
Open the dialing keypad
In a call, you can touch the
dialing keypad to input additional numbers.
icon from middle to left to reject the
button to hang up
button to turn on the speaker,
button then dial a number
button to open the
Contacts
You can place calls from the Phone app , the
People app
display contact information. Wherever you see a
, or other apps or widgets that
9
phone number, you can usually touch it to dial.
The contacts interface can be divided into the
following tab pages:
- Caller groups: Groups of callers you have created.
- Contacts: View the list of contacts.
- Favorites: Display the numbers you usually call.
All of your contacts are displayed alphabetically in a
scrollable list. You can slide your finger up or down to
scroll quickly.
Add new contact
1. In People, touch the add contacts icon
the bottom right hand corner of the screen.
2. Select a memory location.
3. Input all contact information. Slide up to move to
the next field or touch Next.
4. Touch the
Delete contacts
1. In People, touch the Menu keyand then select
Delete contact.
2. Touch the contacts you want to delete, then select
OK.
Edit contact details
1. In People, touch the contact whose details you
want to edit.
2. Touch the Menu key and then select Edit.
3. Edit the contact information.
Search contacts
1. In People, touch the
2. Type a key word of a contact name. The phone will
automatically list all matched contacts.
Add a contact to Favorites
You can tap the contact you want to add to favorites in
the contact interface, and then touch
upper right corner to add it to Favorites directly.
You can only add the contacts stored on the phone to
icon to save your contact.
icon.
at
in the
10
the Favorites.
Create a group of contacts
By creating groups of contacts, you can manage
multiple contacts and send a message to an entire
group.
1. In People, touch the
2. Touch the
3. Select a memory location.
3. Enter the group’s name and type the person’s
name or touch
want to add to the group, then touch
4. Press the Menu key then touch Edit to add
members to the group.
5. Touch
Accounts
You can synchronize contacts information to your
phone from multiple Google
Exchange ActiveSync accounts or other kinds of
accounts, depending on the applications installed on
your phone.
In People, touch the Menu key and then select
Accounts.
Import/Export contacts
1. In People, touch the Menukey to select
Import/export.
2. You can select your Google account, your SIM
Card, Phone contact, Phone storage and SD Card.
Share a contact
You can share a contact with someone.
1. In People, tap the contact you want to share.
2. Touch the Menukey and then touch Share.
3. Select application with which to share (Bluetooth
Email, Gmail, MMS, SMS and SD Card).
tab.
icon at the bottom of the screen.
icon to select the contacts you
.
TM
Accounts, Microsoft
.
®
11
,
Messaging
In Messaging, you can send or receive text
messages and multimedia messages.
On the home screen or in the All Apps screen, touch
the Messaging icon to open.
Send messages
1. In Messaging, touch the
2. Input your desired telephone number in Type name
or number.
You can also touch the
you want to send message from the People and then
touch OK.
3. You can touch the
videos or audio file and the phone will convert the
message to a multimedia message.
4. Input some text in Typetext message. You can
touch the Menu key to select:
- Addsubject: Add a message subject.
- Insertquick text: Insert a quick text.
- Insert contact: Insert contact information.
5. After that, touch the
message.
Receive messages
1. In idle mode, you will be reminded about the new
messages in the notification area. Slide down to open
the notification panel to view.
2. Touch the message.
3. Directly input text to reply to the message.
4. Touch the
directly call back. Touch & hold the text to pop up the
Messageoptions menu, you can Copy, Forward,
Lock/Unlock or Delete the message, etc.
icon.
button to select contacts
icon attach pictures,
icon to send the
icon at the top of the phone to
12
Message thread
The messages from one contact or number will be
aligned in one message thread in chronological order.
You can manage these threads in the messaging
interface.
On the Messaging screen, touch the Menu key and
then touchDelete all threads to delete all threads.
Settings
In Messaging, touch the Menu keyand then touch
Settings to perform relevant settings.
Email
You can receive and send Emails.
In the All Apps screen, touch the Email icon to open
Email.
Set up Email account
Set up an Email account for the first time
You need to set up an Email account when you use
Email for the first time.
1. Input the Email address and password.
2. Touch Next or, if you need to enter Email account
settings that the wizard can’t configure for you,
touch Manual setup.
- If you touch Next, Email attempts to communicate
with your Email service provider to validate your
account for sending and receiving mail, using just
your Email address and password. This is sufficient
for most Email services.
- If the wizard determines that your service provider
requires additional information, you’re prompted to
enter your Email account details.
3. Select POP3, IMAP or Exchange.
4. Set the relevant parameters for the receiving server
according to the prompts.
5. Create a name for Emails and set the display name
of sending Emails.
6. Touch Next.
13
Set multiple Email accounts
After you setup an Email account in the Email
interface, you can also setup multiple Email accounts.
1. Touch the Menu key > Settingsand then touch
ADDACCOUNT to enter the Email account setting
interface.
2. Please refer to the settings in Set up an Email
account for the first time.
Send Emails
After the setting of an Email account is completed,
your phone will automatically enter the inbox of this
Email account.
1. Touch the icon
- Input the Email address of a recipient in the To field.
- Touch Subject to input a subject.
- Touch Compose email to input contents of the mail.
- Touch the Menu key and then touch Add Cc/Bcc to
input a Cc or Bcc address.
- Touch the Menukeyand then touchAttach file. You
can add photos, videos, music, contacts, calendar or
files from the SD card.
2. Touch
Check Emails
1. Open Email.
2. Select the mail box you want to check.
3. Touch the Refreshicon
into the inbox.
4. Touch the emails to view them.
Tip：
When reading Emails, touch the Menukey to reply all,
forward, move it or to enter the Settings.
in the lower left hand corner.
to send.
to update new emails
Gmail
You can use Gmail to read and write email from any
mobile device or browser. All your email is always up
14
to date and available no matter where you check it
from.
On the home screen or in the All Apps screen, touch
the Gmail icon to open Gmail.
Set up an Gmail account for the first time
You need to set up an Gmail account when you use
Gmail for the first time.
1. If you already have a Gmail account, touch
Existing, then enter the Gmail address and
password.
2. Otherwise, touch New and follow the prompts to
create a new Gmail account.
Send Gmails
After the setting of a Gmail account is completed,
your phone will automatically enter the inbox of this
Gmail account.
1. In the inbox of the Gmail account you want to use,
touch
2. Fill in one or more recipients. You can touch the
Menu key to add Cc/Bcc.
3. Enter the email subject and then compose your
message.
4. If you want to attach a photo or video, Touch the
Menu key > Attach picture/Attach video.
5. Touch
Replying to or forwarding email messages in
Gmail
1. In the Gmail inbox, touch the email message.
2. To reply to the sender, touch
choose whether to Reply all or Forward.
3. If you selected Reply all, enter your reply message.
If you selected Forward, specify the message
recipients.
4. Touch
.
to send.
to send.
. or Touch and
Network Applications
15
Network connection
Your phone can connect to the Internet, so you may
need to pay for some data service. For details, please
consult your network service provider.
Ways of Connecting to the Internet
Your phone’s networking capabilities allow you to
access the Internet via the mobile network’s
GSM/WCDMA connection and Wi-Fi.
GSM/WCDMA data connection
Different locations may have different mobile
networks available. Initially, your phone is configured
to use the fastest mobile network available for data.
You can also configure your phone to access a
different set of networks entirely, or to behave in
special ways when roaming.
The icons on the Status bar indicate which kind of
data network you’re connected to.
On the home screen, touch the Menukey and then
touch System settings> More…>
Mobilenetworksto perform relevant settings.
Wi-Fi
Turn on/off Wi-Fi
1. On the home screen, touch the Menukey and then
touch System settings.
2. To turn on Wi-Fi, touch OFF and slide it to the right.
Touch ON and slide to the left to turn off Wi-Fi.
Connect to Wi-Fi
1. On the home screen, touch the Menukey and then
touch System settings.
2. Turn on Wi-Fi.
3. Touch Wi-Fi. Your phone will automatically search
for all nearby Wi-Fi networks.
4. Select the network you would like to connect to
from the list.
- If you’ve selected an open network, your phone
will automatically connect to it.
- If you’ve selected a security network, you need to
16
input the password.
Browser
You can use Browserto view web pages and to
search for information on the web.
Open Browser
1. On the home screen or in the All Apps screen,
touch the Browser icon.
2. Touch the URL field at the top to input a web
address.
3. Enter a new address and then touch Go.
You can touch the Menukey > Bookmarks/History to
select the bookmark you want to open, and touch
SAVED PAGES or HISTORY to open other web
pages.
Browse web
After opening a web page, you could slide your finger
on the screen to view other parts of the page.
Zoom in or out
You can use two fingers to zoom in or out. Spread
your fingers apart or pinch them together to zoom in
or out.
Browse options
When you’re browsing web pages, touch the
Menukey to select:
You can perform more operations such as Save to
bookmarks, Save for offline reading, Share page,
Find on page, Request desktop site, etc.
Settings
You can choose settings that will affect how page
content is displayed and privacy and security
preferences to suit your browse style.
On the Browser screen, touch the Menukey >
Settings to enter the settings interface.
Bluetooth®
Via the Bluetooth
with other Bluetooth devices that are within a short
distance. Because Bluetooth
through radio waves; interference might exist due to
®
function, you can exchange data
®
devices communicate
17
obstacles or other electronic devices.
Turn on/off Bluetooth
1. On the home screen, touch the Menukey and then
touch System settings.
2. Slide the ON/OFF button next to Bluetooth
it on or off.
Pairing
1. Touch Bluetooth
search for devices. Your phone will scan for and
display all Bluetooth
2. Touch the ID of the desired device.
Send files via Bluetooth
To send files via Bluetooth
1. Select a file or item, such as a contact or a media
file from an appropriate application or File manager.
2. Open it, touch the Menu key and choose Share, or
touch and hold it, choose
icon.
3. Search for and pair with a Bluetooth
device.
Change your phone’s Bluetooth
1. On the home screen, touch the Menukey and then
touch System settings>Wireless & networks.
2. If the Bluetooth
3. Touch Bluetooth
phone to edit the name of your device, then touch
Rename.
4. Touch the name of the phone to toggle it to
Visibility timeout so that other Bluetooth
can find your device.
®
when it is on to automatically
®
devices it finds.
®
®
, do as follows:
then touch the
®
function is not turned on, turn it on.
®
, thenthe Menukey> Rename
®
name
®
to turn
®
-enabled
®
devices
Settings
Airplane mode
In areas where the use of mobile devices is restricted,
you can activate the Airplane mode to disable phone
18
function but still use other functions of your phone
such as calendar, music and games. You will not be
able to make/answer calls, send/receive messages in
Airplane mode.
1. On the home screen, touch the Menukey and then
touch System settings>More….
2. Check the box for Airplane mode. The phone will
turn off all wireless connections when Airplane mode
is enabled.
Tip:
On the home screen, you can press and hold the
Powerkey, then select Airplane mode.
Device
Audio profiles
Touch the Menu key and then touch System
settings > Audio profiles, you can set the
predefined profiles.
General: Touch
ringtones, alarms and notifications, set the ringtone
for voice calls & video calls and set the default
notification ringtone, etc.
Silent: Silence all sounds (including call and
notification ringtones) except the audio from music,
videos, and other media or any alarms you have set.
Meeting: Make your phone vibrate only upon
incoming calls.
Outdoor: Make your phone vibrate and ring upon
incoming calls.
Display
Touch System settings > Display.
Lock screen notifications: Select to show
notifications on lock screen.
Wallpaper: Choose a wallpaper.
Auto-rotate screen: Set the interface to rotate
automatically when you rotate the device.
Brightness: Adjust the brightness of the screen.
Font size: Set the font size.
, you can set volume for
19
Sleep: Choose the delay before the screen
automatically turns off.
Storage
To copy files between a PC and your phone’s SD
card, you should set the SD card as USB mass
storage.
1. Connect your phone to your PC with the USB
cable.
2. Touch Turn on USB storage.
During this time, you can’t access the SD card from
your phone, so you can’t use applications that rely
on the SD card, such as Camera, Gallery and Music.
Safely remove the SD card
Just flick down the notification panel and touch Tur n
off USB storage.
Check space on the SD card
1. On the home screen, touch the Menukey and then
touch System settings.
2. Touch Storage.
Erase the SD card
1. On the home screen touch the Menukey and then
touch System settings.
2. Touch Storage > Erase SD card.
Accounts and sync
Adding your accounts
1. Touch System settings > Accounts> Add
account.
2. Touch the account type you want to add.
3. Follow the onscreen instructions to enter your
account information.
Most accounts require a username and password, but
the details depend on the kind of account and the
configuration of the service you're connecting to.
Depending on the kind of account, you may be asked
to configure what kinds of data you want to sync,
name the account, and other details.
When you're finished, the account is added to the list
in Accounts & sync. Depending how you configured
20
the account, email, contacts, and other information
may start syncing to your device.
Language
You can choose the language your phone displays.
On the home screen, touch the Menukey and then
touch System settings > Language & input >
Language.
Voice input & output settings
On the home screen, touch the Menukey and then
touch System settings > Language & input >and
look under SPEECHto configure the Android voice
input feature and the text-to-speech synthesizer, for
applications that can take advantage of it.
Date & time
You can set the format of date and time.
On the home screen touch the Menukey and then
touch System settings > Date & time.
About phone
You can check the phone’s status, legal information,
software version, etc.
On the home screen touch the Menukey and then
touch System Settings > About phone.
Experiencing Multimedia
Camera
Your phone has a camera, which can be used to take
photos and record video clips.
Note:
Please respect others’ rights and abide by the local
regulations and customs when taking photos.
Take photos
1. In the All Apps screen, touch the Camera icon to
open the camera.
2. Tap the
satisfactory.
To view it, slide the screen to the left or just tap the
picture in the right corner of the screen.
icon to take photos after the view is
21
Record video clips
You can use
to Camcorder or vice versa.
Tap the
icon to end.
After a video is recorded, you can slide the screen to
the left or touch the frame in the corner to view the
video.
Camera settings
On the camera screen, touch the
touch
to set GPS location info, Exposure,
Color effect, Scene mode, White balance and
Anti-flicker. Touch
timer, Continuous shot, Picture size and Preview
size. Touch
Time lapse intervaland Video quality.
Touch the
camera.
Music Player
You can listen to music saved on the memory card
with the music player.
Open the music player
First copy music files to a mounted memory card.
In the All Apps screen, touch Music to open.
Listen to music
1. Touch Artists / Albums / Songs / Playlists to find
the music file you want to play.
2. Touch the file to start playing it.
Create playlists
In order to manage your music files conveniently, you
can create some playlists.
1. Touch Songs.
2. Select the music file(s) you want to add to a playlist
and touch & hold it until the shortcut menu pops up.
icon to change from Camera
icon to start recording and touch the
icon, and then
to set Face Detection, Self
to set Microphone, Audio mode,
icon to change to the back or front
22
3. Touch Add to playlist.
4. Touch New.
5. Input the name for a new playlist.
6. Touch Save. In this case, the music files you
selected will be automatically added to the newly
created playlist.
Manage playlists
1. In Music, touch Playlists.
2. Select the playlist you want to edit or play from the
list and touch & hold it until the shortcut menu pops
up.
- Play: Play the music in the playlist.
- Rename: Change the name of the playlist. You can
rename self-created playlists only.
- Delete: Delete the playlist. You can delete
self-created playlists only.
Add music to playlists
1. In Music, touch Songs.
2. Select the music file you want to add to playlist and
touch & hold it until the shortcut menu pops up.
3. Touch Add to playlist.
4. Select the playlist you want to add to.
Set music as phone ringtone
1. In Music, touch Songs or Playlists.
2. Select the music file and touch & hold it until the
shortcut menu pops up.
3. Touch Use as phone ringtone.
Videos Player
You can watch video files saved on the SD card
through the video player.
1. In the All Apps screen, touch the Gallery icon to
open the list of files.
2. Select the video file you want to play, and touch
Gallery
The Gallery categorizes your pictures and videos by
storage location and stores these files in folders. Tap
icon to play.
23
a folder to view the pictures or videos inside.
Sound Recorder
You can record audio files through sound recorder.
Open the sound recorder
Before opening the sound recorder, please insert a
memory card.
In the All Apps screen, touch the Sound Recorder
icon to open it.
Record audio files
1. Put the microphone close to your mouth and touch
to start recording.
2. Touch
3. Touch Save to save the recording or touch Discard
not to save it.
FM radio
With the FM Radio, you can search for radio channels,
listen to them, and save them on your phone.
Note that the quality of the radio broadcast depends
on the coverage of the radio station in your area.
The wired headset that comes with your phone works
as an antenna, so always connect the headset when
using the radio. When you receive an incoming call
while listening to the radio, the radio will be turned off.
To tune in, plug your headset into your phone.
In the All Apps screen, press theFM Radio icon to
open it. The FM radio scans and saves available
stations automatically.
- Tap
- Tap
MHz.
- Press the Volume Keys to adjust the volume.
- Touch
- Touch
to stop recording.
or to scan for available FM channels.
/ to change the frequency by +/–0.1
to select preset list.
to switch off the radio.
24
- Touch to search radio channels, choose the
sound from speaker and record FM.
- Touch
favorites.
to add to favorites/remove from
More Applications
Filemanager
In the All Apps screen, touch the File Managericon.
You can view all files saved in the phone or on the
memory card.
Clock
In the All Apps screen, touch the Clock icon.
Adding an Alarm
1. Touch
2. Touch the
Turning on/off an Alarm
On the Alarms screen, slide the ON/OFF button next
to an alarm to turn it on or off.
Stopwatch
1. On the Clock screen, touch
2. Touch START to start timing, press STOP to pause.
CountDown
1. On the Clock screen, touch
2. Set the length of time to count down.
2. Touch START to begin.
3. When the timer expires, touch STOP to stop the
alert.
Calculator
In the All Apps screen, touch the Calculator icon.
On the Calculator screen, slide the screen to the
right or left to switch between Advanced paneland
Basic panel.
Tip:
Tap and hold the Calculator
.
icon at the top of the screen.
.
.
’
s display to open a
25
menu where you can copy what you’ve entered and
access other tools.
Calendar
Touch the Calendaricon in the All Apps screen.
Creating a new Event
1. On the calendar screen, touch the Menukey and
then touch New event.
2. Enter the event name and location.
3. To set the duration for the event, touch FROM and
TO.
4. Enter the event time zone and description.
5. If you have more than one calendar, select the
calendar where you want to save the event.
6. Select the REPETITION.
7. Set the time of the reminder in REMINDERS.
8. Touch DONE.
On the calendar screen, touch an event to view its
details.
Changing your calendar view
On the calendar screen, touch the date at the top and
choose Day, Week, Month, or Agenda.
Swipe to scroll vertically or horizontally. In the Day or
Week views, spread your fingers apart or pinch them
together to zoom in or out.
Displaying and synchronizing calendars
Initially, all calendars that you create or subscribe to in
TM
Calendar on the web are available to
Google
synchronize and display in Calendar on your phone.
You can select which Google calendars to keep
synchronized and which to show.
1. On the calendar screen, touch theMenu key and
then touch Calendars to display.
2. Touch which calendars you would like to be
displayed.
3. If you have more calendars you would like to
synchronize and display, touch Calendars to sync,
then touch the checkbox next to the calendar(s) you
would like to synchronize, touch OK, and then you are
26
returned to the Calendars to display screen where
what you chose is now displayed and where you can
choose which to display in the calendar.
Downloads
With Downloads, you can manage logs of files you
have downloaded from the web.
Touch the Downloadsicon in the All Apps screen.
Maps
You use Maps to find your current location; to view
real-time traffic conditions; to get detailed directions
by foot, public transportation, bicycle, or car.
1. Touch Maps on the home screen or in the All Apps
screen.
2. Touch
box on the top to find the location you need.
Navigation
You can use Google Navigation to get turn-by-turn
driving directions, both spoken and displayed on your
screen.
1. On the home screen touch the Menu key and touch
System settings > Location access.
2.Slide the ON/OFF button next to GPSsatellitesto
turn it on or off.
3. In the All Apps screen, touch Navigation icon.
, and then tap the Search Maps search
Manage applications
You can view and manage applications installed in
your phone.
Install new applications
You can install applications from the Play Store or
from elsewhere. When installing applications that are
not from the Play Store, make sure the software is
suitable for your phone.
Installing applications from the Play Store
1. On the home screen or in the All Apps screen,
touch the Play Store icon.
2. Search for the applications you want to install.
27
Installing applications not in the PlayStore
1. Copy the application to the SD card and find the file
from File manager.
2. Check Unknown sources.
3. Touch the file and complete the installation
according to the wizard.
Uninstall applications
1. On the home screen, touch the Menukey and then
select System settings > Apps.
2. Scroll the list and touch the application you want to
uninstall.
28
Loading...
