This manual includes security measures and correct operating methods. For personal safety, please
make sure to read this manual before using. Thank you!
The machine adopts capacitive touch screen, you can just touch it by finger or click with capacitive
pen for operation. (Never use the sharp objects to click the screen, or the touch screen may be
damaged).
Do not put the device at any high temperature, high humidity or dusty place.
Do not drop or crash the device to prevent the violent impacting between the display and the
capacitive touch screen. Or the customers have to take the consequence by themselves.
Please choose the suitable volume and never make the too loud volume .If you feel uncomfortable
please turn down the volume or stop to use the device soon.
Please charge if you meet those situations as below:
A、Low battery on the battery icon. B、The system turns off automatically.
C、The keys do not work. D、“ ” is battery charging.
【Note】
:Don’t use the different type charger or it may make the device burned. We assume no
liability for the damage.Please contact with our agent if you need the original adaptor.
In the charging process，the device may be warning up a little (not too hot), this is normal, and it
won’t effect functions.
Do not disconnect the device while formatting, downloading or uploading, or it may make the error.
Do not dismantle this device by yourself, and do not polish it with alcohol, dilution, or benzene.
Do not use this device where electronics is forbidden, such as on the airplane.
Do not use this device while walking and driving, avoiding traffic accident.
USB is for transferring data.
For any support needed for this device please contact the company or the authorized distributor.
Any unauthorized dismantling of the device will make the warranty null and void.
Key points：
1
Page 4
Packing List:
Please check box for the following items
1. Tablet Device
2. User Manual
3. Earphone
4. Power Adaptor
5. USB Cable
Product Specification
CPU MTK 8312 Cortex-A7, Dual-core Max 1.3GHz
OS Google Android 4.2.2 Jelly Bean
Display: 7"capacitive touch panel (1024*600 Resolution)
RAM 1GB DDRIII
Memory 16GB
SD Slot: Micro SD(TF card) up to 32GB
WIFI 802.11 b/g/n
3G : Support (850.900.1900.2100 MHz)
2G: 850 900 1800 1900MHz
Camera : Front 2.0M px；Rear 8.0M px
FM: 87.5MHZ-108MHZ
Bluetooth: 2.4GHZ-3.0GHZ
GPS: 1.575GHz
Music format: MP3,WMA,FLAC,AAC,OGG,WAV,APE etc.
Video format: VP8,RMVB,RM,MOV,MPG,MP4,AVI,3GP,DAT, FLV
,MKV etc.
Picture format: JPEG, BMP, GIF,PNG etc.
Battery : 3000 MAH
2
Page 5
【TIPS 】：1. When the battery is low, it will power off automatically.
2. Shutdown illegally, when you restart, device would scan and repair the disk. The
screen will stay at the progress bar for a long time .
1
2
3114
5
6
7
8
9
10
Device description
1 Touch screen:You can click and drag in the touch screen.
2 Front Camera:You can take photos and videos etc..
3 :Earphone jack: 3.5mm standard earphone jack.
4 :Micro USB, Micro-5 pin connector & Connect the power
able to charge to the device.
5 Rear Camera:You can take photos and videos etc..
6 Glittering:Will flash when taking pictures
7 Speaker
8 Micro SD/TF card:Micro SD/TF card slot.
9 POWER：Keep pressing button over 2 seconds
for power on/ off, press button once to turn on
screen from sleep mode .
10 Volume +:Turn up the volume
Volume -:Turn down the volume
11 SIM Card:Insert/Pull out SIM Card
3
Page 6
Setting up for the first time
Charging your device：
For first-time use, you need to charge the device for ten hours.
After that you can recharge the device as needed.
Connect the DC-in jack to your device and plug the AC
adapter into any AC outlet.
【TIPS】:
1. This device adopts built-in polymer battery. Only the specified
charger should be used.
2. It is normal for the device’s surface to become warm during
charging or long
periods of use. All devices are factory tested before release.
3. If you do not use this set for a long time, please charge/release it once
one month to avoid deep discharge. The damage caused by battery over-consuming is not included
in the warranty.
Battery Saving
To save battery running life, please see below key points. With below suggestions, battery can run
longer time after fully charged
each time.
1. When device is not in use, press power button once to go to sleep mode.
2. Shut down the applications when not in use.
3. Turn off WLAN when not in use
4. Shut off application sync selection
5. Set a shorter time for display backlight
6. Reduce brightness of display
4
Page 7
Connecting to a PC:
• You can connect with PC by USB cable attached with the device.
You can transfer your personal data to the PC.
• Connect the PC and the device, it will change to
the USB mode,in this state, realize the files transfer
function between the PC and the device
Connecting a USB device:
• USB devices are supported, such as a keyboard, mouse
through the USB port.
• View media files on USB storage with installed photo,
music or video
applications.
【Caution】: Before removing this USB storage,make sure
your device is not accessing data from the USB storage
.
5
Page 8
Inserting the MicroSD card :
You may install a Micro SD card to expand your device’s
storage space.
1. This device supports Micro SD card up to 32GB capacity.
2. Insert the Micro SD card as shown.
【Note】: Ensure that the Micro SD card is inserted all the
way into the card slot.
【Caution】: Before removing this card, make sure your device
is not accessing data on the card.
Connecting to the Network:
Wi-Fi wireless setup:
Enter the setting interface, and turn on the Wi-Fi item.
The device will automatically search any accessible
nearby wireless networks.
6
Page 9
Power On
Keep pressing power button over 2 seconds, device will start up opening screen, Android system is
activating and enter the main screen.
Sleep Mode
After devise is on, press power button once and it goes to sleep mode. The screen is now on standby
and under low battery consumption. To wake up device, press one more time power button.
Power off and Forced Shut down
When you are not using the device, keep pressing power button over 2 seconds,the screen will
display “shut down” , select “Yes” to power off unit completely. If device is hanging, use a small pin to
press Reset hole, it will forced shut down and the device will power on again.
Operation of Touch Panel
Click -- Use finger or capacity panel pen to touch once, so as to select or activate function, or select
menu or turn on applications.
7
Page 10
Tap and hold -- Tap over 2 seconds, it will turn on option list
Slide -- Slide up, down, left or right for fast scrolling browsing page and display screen
Drag – drag an icon and relocate the position
8
Page 11
Double Click – Double click to enlarge or shrink the display size of picture or under browsing
webpage.
Shut --Use two fingers at same time on touch panel, to enlarge or to shrink the display scale.
9
Page 12
① Google Search
② Click to turn on voice search, it will search according to voice input ( Make sure WIFI is on )
③ List of last running applications
④ Back to Home screen
⑤ Back to previous screen
⑥ Display of icons and device status, click to turn on notification screen
⑦ Shortcut to application
⑧ Enter applications page
Home Screen
1
6
8
7
2
5
3
4
10
Page 13
Home screen with a set of 5 screens, slide left/ right to view individual screen
� Change of Wallpaper
1. Tag home screen, it will pop-up wallpaper selection
2. Select preloaded wallpapers or picture as wallpaper
3. Click “setup” to confirm
� Add shortcut on Home screen
1. Enter in application page, tag the icon of application
2. Locate the icon to designated position or locate it in another screen
� Add Widget in Home Screen
1. Enter application page and slide to Widget page
2. Slide left / right to select widget
3. Tag designated widget and locate it in home screen
Remark：Some widgets is linked to internet service, be careful it will occur data cost
Some widgets might only be used in certain countries or under assigned service providers
� Relocate the shortcut on Home screen
1. Tag the application icon and move
2. Move icon to the designated position
� Cancel shortcut on Home screen
1. Tag the application icon, recycle bin displays on upper screen
2. Drag icon to recycle bin
3. When icon changes to red, let go
11
Page 14
� Notification screen
In home screen or under running application, select right side notification screen, check device status
and set up below options：
Icon Icon Description
WiFi signal Wifi connection, icon is full under strong signal
Battery Status of battery or if device is being charged
USB Connection To show if USB port is connected
Soft keyboard Turn on soft keyboard, for word typing
Screen shot After taking screen shot, show picture saved
Applications
Internet Browsing
Browse internet and bookmark the website
Remark ：Web browser and bookmark might be different in different countries or different service
providers
12
Page 15
� Browsing webpage
1. Enter application page, select ”Browser” Icon
2. To brows certain webpage, select URL and input website address, and select “confirm”
3. See below browsing options：
① Open new window
② Shut down current webpage
③ Go to Next or Previous webpage
④ Accessing webpage, icon becomes “X” when webpage shows
⑤ Detail message of webpage
⑥ Enter webpage address or related words
⑦ Bookmark current page
⑧ Search message
⑨ Open bookmark and current visited webpage
⑩ Option list of browser
1
7
8
10
9
2
5
3
4
13
Page 16
� Browser setting
When browsing webpage，click upper right corner“ ”，adjust setting in the option menu
� Current visited webpage
1. Enter application page, click ”Browser”
2. Select bookmark current visited history
3. Select webpage
Email
Send and Receive email
� Setting of email account
1. Enter application page and click ”Email”
2. Enter email address and password
3. Select next step ( for personal email account) or manual setting (for commercial email account)
4. Follow and input the requested setting
5. For setting more than one email account, select � setting �
add email account, repeat steps
2-4.
After email account setting, message will be received in device. For more than one email account,
switch email account for operation,to receive and send out message.
14
Page 17
� Sending outgoing message
1.Enter application page and select ”Email”�
2.Type in Recipients ;Manual input email address，use ” ;” or ” ,” to separate more than one
recipients
3.Type in Subject
4.Type in message in content
5.Select for attachments
6.Select and send out message
Remark ：If user is offline，message cannot be sent out
Check email message
In email account, user can check downloaded message, go online to check new messages.
15
Page 18
Audio player
Click “Play Music”in application page.
Music will be categorized by artists, album, and play list. It will display all music inside“Songs”.
Click the song and it will play automatically.
Video player
Click “Video”in application page.
Video player will search for all supported video files in the device, click the designated video
file to play.
16
Page 19
Camera
The built-in front camera can take picture and video file.
� Take picture
1. Click“Camera”in application page, device is default at picture taking, icon is“ ”
2. To take picture，click “ ”
3.When take the photos, it can be zoom
option by two finger freely
� Video shooting
1. Select recording in video file，click“ ”
2. Click “ ” to record video file.
3. Click “ ” again to stop recording
� Camera Setting
In camera mode，click“ ” for set up，click“ ” to select set up options
1-3X
17
Page 20
File Manager
File manager will copy, cut, delete, rename the documents or the folder in the TF card, it also will
share the files, install apk etc.In the main menu or desktop, click the document manager icon
to enter into documents manager.
A.Copy, cut, delete, rename the files and folder: choose the file or folder, long pressthe file or folder
to enter into the interface as Picture 9.4, you can operate the file or folder.
B.Paste the file or folder you copy or cut: in the catalogue you want to paste, choose icon
in right top, as Picture
C.Share file: choose any file, long click this file, choose icon in right top, it willl show
A
B
C
18
Page 21
FM Radio
Click in the main interface or desktop to enter into FM radio interface:
[Note]: Use FM radio, you need to insert earphone, if no antenna, you can’t search radio frequency
2
3
4
5
6
7
8
1
1.Open outer voice
2.Channel list
3.Menu
4.Save button
5.Current frequency
6.Next channel
7.Play/pause
8.Previous channel
Click search to scan FM frequency
19
Page 22
1.Call history
2.Phonebook
3.Display phone numbers
4.The area of dial phone
5.Function key
6.Dial phone numbers
7.Hide number keyboard
2
3
4
5
6
7
Phone
Click Phone application procedure
1
20
Page 23
Text Message
1.Enter into main menu, choose application procedure.
2.Click “Edit new message”
Contact List
1.Click Contact list in the main interface, enter into
the contact list.
2.Search contact: click button, enter into search function
3.Add contact: click button, enter into add contact
interface.
2
3
4
5
1
1.Directly input phone number
2.Attach picture/videos/audio/calenter
/contact/capture video etc.
3.Search information
4.Add receiver
5.Send message
21
Page 24
Commonly used settings
SIM Card Management
Click setting application in main menu; choose SIM management
Wi-Fi: Click ON or OFF to open or close Wi-Fi. When open
Wi-Fi,the system will scan the wifi signal around automatically.
Meanwhile, users could add network manually as well.
Bluetooth:1. Click setting application in main menu interface
2.Click bluetooth and open it.
3.Click search device in right above, then MID will automatically
search the bluetooth device nearby
4.Click search to get Bluetooth device, it will popup match
request window, click match.
5.After matching successfully, find the device name you want
to operate, click icon, enter into interface
22
Page 25
Data Usage:1.View SIM Card data usage
2.View data usage
More...
1.Airplane mode
Airplane mode can quickly turn off WIFI and GSM card function,
when you open airplane mode, WIFI and GSM can’t read any
signal, machine will resume to previous state when you close
airplane mode.
VPN Tethering and portable hotspot
23
Page 26
Contextual mode
Open setting, click contextual mode then you have different
choices.Click General to enter.
1.Vibrate:click vibrate, the device will remind you have
incoming calls by vibrating.
2.Volume:click volume, you can adjust rings, notice and alarm
volume
3.Voice/Video call ringtones
click voice/video call ringtones to choose incoming voice/video
call ringtone
24
Page 27
Display
Scene:1.Click setting application.
2.Click display, click scene.
3.System will have different scenes for option
Wallpaper
1. Click setting application.
2. Click display, click wallpaper
3. You can choose different wallpaper as your perference
dynamic wallpaper---gallary/wallpaper/video,live wallpaper
Theme
1. Click setting application
2. Click display, click theme, there are four different styles
of theme for option
Sleep
1. Click setting application.
2. Click display,
3. Click “sleep”.
4. Popup screen standby time setting, choose the standby
time you want to set
25
Page 28
Storage
Open setting application, choose storage,
and choose default storage.View SD card and MID space.
Battery：Click setting function, choose battery, you can
view battery usage situation.
Application
1.Choose Setting procedure in the application procedure list.
2.Choose application, after entering, you can manage and
delete installed applications
Location Access
1.WIFI and mobile network location
2.GPS satellite
3.GPS Auxiliary
4.GPS EPO setting
5.A-GPS
6.A-GPS setting
26
Page 29
Language and Input Method
Click setting, choose language and input method, choose
language to switch language type.
Backup and Reset
Click backup my data, when WIFI is connected and login Google
account, system will copy your data into Google server. If you
wish to reset factory setting, please click restore factory reset.
Add Account
1.Click Setting application.
2. Click Add account.
3. Choose email type you want to login.
4. If login successfully, sync function will auto open.
Date&time
when the internet is connected,turn on- Automatic Date & Time
the device can obtain the real date and time from the internet.
27
Page 30
Scheduled power on and off
1.Enter into setting application.
2.Click scheduled power on and off selection.
3.Operation as right Picture
Accessibility
1.Large text
Click it to make system font become large.
2.Press power key to end call
Click call, press power key to end call, but won’t sleep.
3.Touch and hold delay
4.Add webpage accessibility function
Developer options
28
Page 31
About Tablet
1.Click about tablet to view status information, model,
Android version, and version information.
2.Click status message to view battery state, electric
volume, SIM state, IMEI number, IP address
Visit Application Procedures.
Click button, enter into main menuchoose the
application procedure you want to visit.
USB Connection
1. Connect the MID and computer by USB cable,
the reminder column will show the remind information.
2.Open the reminder board.
3.In the reminder board, click the “USB Connected”,
then click “open USB storage configuration”.
4.Now the USB is connected successfully.
29
Page 32
Troubles Shooting
1.The first startup of MID is slow
After the MID system upgraded, the first startup need to install the pre-installed application
softwares, the lead time is around 2-3 minutes, the startup afterwards will be much quicker.
2.MID can’t connect Wi-Fi
�Make sure the wireless router of internet service can work in normal.
�Ensure the MID and wireless router in certain distance, and no wall or other barrier between them.
�Ensure the user name and password both correct.
3.MID feels hot
When many application procedures are used in meanwhile, or the brightness of screen open to
the lightest or under charging, MID may feel fever. It is normal.
4.Email can’t be set or Registeration of application procedure.
�Ensure your internet is well connected.
�Make sure your email setting way is correct.
�Keep your system time and local time consitent.
5. The system is abnormal and can’t work.
When you install some third party application procedure, it may cause abnormal work, you can
press Reset key(next to power port) to reset the system.
6. The webpage can’t be opened
1.Please keep the distance between from route to MID in effective range.
2.Please restart WIFI and try again.
7. MID works terribly slow sometimes
It is normal phenomenon. Please turn off some application you don’t need in advanced task
management, or uninstall some third party application to release more system resources.
30
Loading...
