OPERATING MANUAL

COPYRIGHT © 2019 Pliant Technologies, LLC. All rights reserved. Pliant®, MicroCom™, and the Pliant “P ” are trademarks of Pliant
Technologies, LLC. All other trademarks are property of their respective owners.
Document Reference: D0000511 _C

Pliant Technologies, LLC
205 Technology Parkway
Auburn, Alabama 36830 USA

Phone [phone]
Toll-Free 1.844.475.426 8 or 1.844.4PLIANT
Fax [phone] www.plianttechnologies.com

CONTENTS

Introduction .............................................................................................................................................1

What’s Included with MicroCom 900M? ...............................................................................................1

Controls ....................................................................................................................................................2

Setup ........................................................................................................................................................2

Operation .................................................................................................................................................3

Battery .....................................................................................................................................................3

Menu Settings .........................................................................................................................................4

Device Specifications ..............................................................................................................................6

Product Care and Maintenance .............................................................................................................7

Product Support ......................................................................................................................................7

License Information.................................................................................................................................8

Pliant Warranty Statement ....................................................................................................................9

INTRODUCTION

We at Pliant Technologies want to thank you for purchasing MicroCom 900M. MicroCom 900M is
a compact, economical wireless intercom system that operates in the 900MHz frequency band to
provide excellent range and performance. The system features small, lightweight belt packs and
provides excellent sound quality, ease-of-use, and long-life battery operation.

In order to get the most out of your new MicroCom 900M, please take a few moments to read this
manual completely so that you better understand the operation of this product. This document
applies to model PMC-900M. For questions not addressed in this manual, feel free to contact the
Pliant Technologies Customer Support Department.

PRODUCT FEATURES

• Economical single-channel
system

• Simple to operate

• Up to 5 full-duplex users

• Unlimited listen-only users

• 900MHz frequency band

• Encrypted FHSS technology

• Small and lightweight

• Water-resistant construction

• Long, 10-hour battery life

• Low latency (less than 35 ms)

WHAT’S INCLUDED WITH MICROCOM 900M?

• Holster

• Neck Strap

• USB Charging Cable

OPTIONAL ACCESSORIES

• PAC-USB5-CHG: MicroCom 5-Port USB
Charger

• PAC-MC-5CASE: IP-67-rated hard travel case

• PHS-SB11LE-DM: SmartBoom® LITE Single
Ear Pliant headset with Dual Mini connector
for MicroCom

• PHS-SB110E-DM: SmartBoom PRO Single Ear
Pliant headset with Dual Mini connector for
MicroCom

• PHS-IEL-M: MicroCom in-ear headset, single
ear, left only

• PHS-IELPTT-M: MicroCom in-hear headset
with push-to-talk (PTT) button, single ear, left
only

• PHS-LAV-DM: MicroCom lavalier microphone
and eartube

• PHS-LAVPTT-DM: MicroCom lavalier
microphone and eartube with PTT button

• PHS-SB210E-DM: SmartBoom PRO Dual Ear
Pliant headset with Dual Mini connector for
MicroCom

• PHS-HH-DM: MicroCom hardhat/helmet
headset

1 / 9

CONTROLS

Antenna

Talk/State LED

Charging LED

LCD Screen

Power Button

Volume +/–

Buttons

Mode Button

Talk Button

USB Charger

Connection

Headset
Connection

SETUP

1. Connect a headset to the belt pack. The belt pack headset connection supports dual mini

and single mini headsets. Dual mini connectors can be inserted in either direction. Single mini
connectors can be inserted in either port of the headset connection.

2. Power on. Press and hold the POWER button for three (3) seconds, until the screen turns on.

3. Select a Group. Press and hold the MODE button for 3 seconds, until
the “GRP” symbol is blinking on the LCD. Then, use the VOLUME +/−
buttons to select a group number from 0–51. Short-press MODE to save
your selection and proceed to ID setting.

Important: Radios must have the same group number to communicate.

4. Select an ID. When “ID” begins to blink on the LCD, use the VOLUME
+/− buttons to select an ID number. Press and hold MODE to save your
selection and exit the menu.

a. Pack IDs range from 00–05.

b. One pack

for proper system function. “MR” designates the master pack on its
LCD.

c. Listen-only packs must use the “05” ID. You may duplicate ID “05” on

multiple belt packs if setting up listen-only users. (See “Receiving
Mode Selection” on page 4 for more information about that
process.)

must always

use the “00” ID and serve as the master pack

Figure 1: Group Edit Screen

Figure 2: ID Edit Screen

Figure 3: ID Edit Screen (Master ID)

2 / 9
