Revolutionize your
Gaming Battlefield
M9Pe
The M9PeGN features superior performance to cater to the
needs of every PC gamer and the like. It supports the latest generation NVMe and adopts advanced 3D NAND flash memory
with flagship controller chip. The exclusive performance boosting technology, PlexNitro, releases the M9Pe’s full potential.
Features
・Supports NVMe PCIe Gen 3 x 4
・Sequential read / write up to 3,200 /
2,100 MB/s, random read / write up to
400,000 / 300,000 IOPS
・Latest generation of LDPC error
Designed for the Best Gaming Experience
With the adoption of the latest NVMe PCIe Gen 3 x 4 super high-speed transmission
interface, the new M9Pe delivers low latencies, sequential read/write speeds up to
3,200 / 2,100 MB/s and random read/write speeds up to 400,000 / 300,000 IOPS. No
matter what you use it for, work, entertainment ,or extreme PC gaming, the M9Pe is
undoubtedly the best choice you will ever make.
GN
M9Pe series M.2 2280 NVMe SSD
PCIe Gen 3x4
correction technology
・Exclusive firmware technology for
cache acceleration - PlexNitro
M9PeY M9PeG M9PeGN
Heat sink
Gaming
Performance
Finely selected
components
Colorful RGB
LED
●
●
●
●
●
●
●
●
●
Superior Quality 3D NAND and firmware technologies
The Plextor M9Pe series is equipped with high-performance 64-layer 3D NAND flash
and flagship controller chip. Combined with the latest LDPC error correction
technology and proprietary cache optimization technology, PlexNitro, the M9Pe
delivers ultra high-performance, durability, and stability and reliability.
Flexible Storage Options
For various upgrade and assembly requirements of desktop and laptop PCs, the
M9Pe series launches M.2 2280 (with and without heatsink) and HHHL (with
heatsink) form factors and three (3) capacity options - 256 GB, 512 GB, and 1 TB.
Plextor's Flawless Quality Control
The M9Pe series undergoes high standard flawless quality control. Each SSD is
demanded to pass rigorous inspections from the world-class advanced SSD testing
laboratory to ensure error-free performance. The "Plextor endurance testing
mechanism" simulates a range of professional read-write scenarios which proudly
promises reliability with astonishing 1.5 million hours of mean time between
failures (MTBF).
M9PeGN
Specification
Model
Capacity
Cache
Controller
NAND Flash
Performance (Under Windows NTFS)
Sequential Read Speed (MB/s)
Sequential Write Speed (MB/s)
Random Read Speed (IOPS)
Random Write Speed (IOPS)
Environment and Reliability
Power Requirement
Temperature
MTBF
Endurance (TBW)
Warranty
Compatibility
Operating System
Supported
Agency Approval
Command Set Support
Interface
Form Factor and Connectors
Form Factor
Power Connector
Data Connector
Dimension and Weight
Dimension (L x W x H)
Weight (Max.)
Package Content
Drive
M.2 connector for DC 3.3V input
M.2 Connector
M9Pe series SSD
PX-256M9PeGN
256 GB
512 MB LPDDR3
Up to 3,000
Up to 1,000
Up to 180,000
Up to 160,000
0℃ ~70℃ / 32℉ ~ 158℉ (Operating)
160 320 640
Microsoft Windows 8.1, 10/ Linux OS
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
TRIM, S.M.A.R.T, IO queue, NVMe command
M.2 PCIe Gen 3 x 4 with NVM Express
80.00 x 22.00 x 2.30 mm / 3.15 x 0.87 x 0.09 inch
PX-512M9PeGN
512 GB
512 MB LPDDR3
Marvell 88SS1093
TOSHIBA BiCS3 3D TLC
Up to 3,200
Up to 2,000
Up to 340,000
Up to 280,000
DC 3.3V 2.5A (Max.)
>
1,500,000 Hours
5 years
Supported
M.2 2280
10g / 0.35oz
256GB / 512GB / 1TB SSD
80.00 x 22.00 x 3.65mm / 3.15 x 0.87 x 0.15 inch
PX-1TM9PeGN
1 TB
1024 MB LPDDR3
Up to 3,200
Up to 2,100
Up to 400,000
Up to 300,000
Specification subject to change without notice.
Actual performance may vary according to hardware, software and overall system configuration.
Performance measured by CrystalDiskMark ver. 5.0.2, IOMETER 1.1.0
Test Platform: Motherboard ASUS Z270 Mark 1, Win 10 professional x64
www.PLEXTOR.com
LITE-ON Technology Corporation
12F, 392, Ruey Kuang Road
Neihu Dist., Taipei 114
Taiwan, R.O.C
© 2017 Plextor.
Plextor branded products are developed and sold by Lite-On Technology Corporation.
