Ultrafast, Dynamic
and A thing of Beauty
M8Se Series M.2 2280 NVMe SSD
Eye-catching, advanced specifications designed with
dynamically streamlined technology, the M8Se offers the best
cost-performance ratio with the NVMe high-speed transmission
interface support and high performance TLC NAND flash
adoption. On top of that, the exclusive performance boosting
Product Feature
firmware, PlexNitro, is also included.
PCIe Gen 3 x4
•Supports the latest generation
of NVMe High-Speed
Transmission Standard
•Sequential read/write
speed of 2,450/1,000 MB/s;
random read/write speeds of
210,000/175,000 IOPS
•Latest generation of LDPC to
guarantee accuracy and stability
during data transmission
•Exclusive PlexNitro cache
technology
•Available in HHHL and M.2 form
factors
•Comes in 4 capacities:
128/256/512 GB and 1TB
•3 year extended warranty to
guarantee a worry-free user
experience.
Streamlined and Efficient Heat Sink Design
Plextor's M8Se series is packed with highly advanced and efficient features in an
elegant, highly-streamlined design comparable to the wind tunnel test for race cars.
The streamlined heat sink dons a stylish blue and black design provides unparalleled
heat conduction capabilities that rapidly expels heat generated by super high-speed
data transmission. This effectively helps optimize system resources to deliver
full-speed operating conditions.
A New Generation of High-Speed Transmission Standards
The M8Se series is powered by the latest generation NVMe PCIe Gen 3x 4 super
high-speed transmission interface that delivers high bandwidth and low that allows
sequential read/write access speeds of 2,450/1,000 MB/s and random read/write
speeds of 210,000/175,000 IOPS. Whether it’s for work, fun, or multimedia
applications, the M8Se is the perfect solution to speed up your system and provide
the ultimate user experience.
Superior Quality TLC Device and Firmware Technology
The keys to Plextor's high quality M8Se series is the TLC NAND flash and flagship
controller chip, LDPC error correction technology and the exclusive PlexNitro, write
acceleration technology, all combined to provide amazing performance, durability,
and stability. Plextor offers advanced TLC SSDs to satisfy consumers' demand for
the best cost-performance ratio on the market.
Plextor's Flawless Quality Control
The M8Se series maintains the high standard for flawless quality set by Plextor; it
has passed rigorous inspections with the most advanced SSD testing laboratory in
the world allowing not a single error or fault (Zero Error). The "Plextor endurance
testing mechanism" simulates a range of professional read-write scenarios which
guarantees the product of its astonishing 1.5 million hours of mean time between
failures (MTBF). Plextor offers a three-year extended warranty and technical
support for provide users with a peace of mind.
M8Se Series M.2 2280 PCIe Gen 3 x4 with NVMe SSD
Specification
Environment and Reliability
Compatibility
Package Content
Model PX- 128M8SeGN PX- 256M8SeGN PX- 512M8SeGN PX- 1TM8SeGN
Capacity 128 GB 256 GB 512 GB 1 T B
Cache 512MB LPDDR3 512MB LPDDR3 1024MB LPDDR3 2048MB LPDDR3
Control ler
NAND Fl ash
T OSHIBA 15nm Super High Performance T LC
Performance (Under Windows NTFS)
Sequential Read Speed (MB/s)* Up to 1,850 Up to 2,400 Up to 2,450 Up to 2,450
Sequential Write Speed (MB/s)* Up to 570 Up to 1,000 Up to 1,000 Up to 1,000
Random Read Speed (IOPS)* Up to 135,000 Up to 205,000 Up to 210,000 Up to 210,000
Random W rite Speed (I
OPS)* Up to 80,000 Up to 160,000 Up to 175,000 Up to 175,000
Marvel l 88SS1093
Pow er Requirement
T emperature
MT BF
DC 3.3V 3.0A (Max.)
0°C ~ 70°C / 32°F ~ 158°F (Operating)
>1,500,000 Hours
Endurance (TBW) 80 160 320 640
Warranty
Operating System Supported
Agency Approval
Command Set Support
Interface
Firmware Upgrade
Microsoft Window s 8.1, 10/ Linux OS
UL, T UV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
T RIM, S.M.A.R.T, IO queue, NVMe command
M.2 PCIe Gen 3 x4 with NVM Express
3 years
Supported
Form Factor and Connectors
Form Factor
Pow er Connector
Data Connector
M.2 connector for DC 3.3V input
M.2 2280
M.2 Connector
Dimension and Weight
Dimension (L/W/H)
Weight (Max.)
Drive
80 x 22 x 2.3 mm / 3.15 x 0.87 x 0.09 inch
10g / 0.35oz
128GB / 256GB / 512GB / 1T B SSD
80 x 22 x 3.65 mm /
3.15 x 0.87 x 0.15 inch
Specifications subject to change without notice.
Actual performance may vary based on hardware, software, and overall system configuration.
* Performance measured using CrystalDiskMark ver.3, IOMETER with queue depth set to 32.
Test Platform: Motherboard: ASUS Z170-Deluxe (Microsoft Windows 10 Professional x64)
Lite-On Technology Corporation
12F, 392, Ruey Kuang Road
Neihu Dist., Taipei 114
Taiwan, R.O.C
For more information, please visit
www.PLEXTOR.com
© 2016 Plextor.
Plextor branded products are developed and sold by Lite-On Technology Corporation.
