Plextor 8220 User Manual

Page 1

Models: PX-W8220Ti (Internal)

PX-W8220Te (External)

Congratulations!

Thank you for purchasing the PlexWriter 8/2/20, a reliable, high-performance CD rewriter, recorder and reader. We appreciate the confidence you have shown in us. Our goal is to put you—and keep you—on the leading edge of CD technology.

To get you there, we first have to help you install your PlexWriter drive properly and operate it correctly. After that, the responsibility is yours to seek the applications that make rewritable CD such a powerful and exciting addition to your system.

Page 2

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is

•

connected. Consult the dealer or an experienced radio/TV technician for help.

•

For External Model Users:

drive. Using other signal cables may exceed the limits of the Class B Part 15 of the FCC Rules.

Any changes or modifications should be approved by the party responsible for compliance of FCC Rules; otherwise, the user loses authority to operate the equipment.

CAUTION

specified herein may result in hazardous radiation exposure.

The laser beam emitted from the optical pickup is invisible. Accordingly:

•

: Use of controls or adjustments or performance of procedures other than those

Do not open the optical pickup housing. Obtain service only from Plextor-authorized personnel.

Please use the external shielded SCSI cables supplied with this CD-ROM

LASER INFORMATION

These products have been designed and manufactured according to IEC 825-1 on the Safety of Laser products. This product comes under “Class 1 Laser Products.” A Laser Caution Marking is attached on the top of the internal drive model: “Caution: Invisible laser radiation when open. Avoid direct exposure to beam.”

CAUTION VORSICHT

Zur Einhaltung der Funk-Entstörung von nicht selbständig betreibbaren Hochfrequenzgeräten (periphere Anlagenkomponenten).

Dieses Gerät entspricht als Einzelgerät den Funk-Entstöranforderungen der Postverfügung Nr. 243/1991. Wird das Gerät innerhalb einer Anlage zusammen mit anderen Geräten betrieben. So mub bei Inanspruchnahme der “Allgemeinen (Betriebs-) genehmigung” nach der BMPT-AmtsblVfg Nr. 243/1991 die gesamte Anlage folgenden Richtlinien entsprechen:

•

: To disconnect the CD-ROM drive from an electrical current, pull out the power plug.

: DIE TRENNUNG VOM NETZ ERFOLGT DURCH ZIEHEN DES NE TZSE CKES.

ÜG-Vfg.243

Grenzwertklases B der EN55022 Auflagen nach § 2 der BMPT-AmtsblVfg 243/1991

Dies ist bei der Zusammensetzung einer Anlage (z.B. Computersystem) aus nur einzein geprüften Geräten nicht immer erfüllt.

PlexWriter 8/2/20 Operation Manual

Page 3

Table of Contents

1. Getting Started.................................................................................................1

About this Manual..............................................................................................1

Meet Your PlexWriter 8/2/20............................................................................. 1

What the PlexWriter 8/2/20 Does...................................................................1

What You Can Do with the PlexWriter 8/2/20...............................................2

Save Your Box!..............................................................................................3

What's in the Box ...............................................................................................3

PlexWriter Drive Features and Controls ............................................................5

Front Panel—Internal and External Drive...................................................... 5

Rear Panel—Internal Drive............................................................................ 6

Rear Panel—External Drive........................................................................... 7

What Else Do You Need? ..................................................................................8

About Pre-mastering Software........................................................................... 10

Precautions .........................................................................................................10

2. Installing Your PlexWriter..............................................................................11

Quickstart Installation—For Experienced PC Users Only............................. 11

Set Drive Switches or Jumpers........................................................................... 11

Do I Have to Change My PlexWriter's SCSI ID number? .............................12

Do I Have to Change My PlexWriter's Termination Setting?........................ 13

Do I Have to Change Other PlexWriter Settings?..........................................15

Setting Jumpers on an Internal PlexWriter Drive........................................... 15

Setting Switches on an External PlexWriter Drive.........................................18

Install a SCSI Interface Board............................................................................ 19

How to Choose a SCSI Board........................................................................ 20

Install the SCSI Board.................................................................................... 20

Install an Internal PlexWriter Drive ...................................................................22

Record the Serial Number .............................................................................. 22

Mount the PlexWriter Drive........................................................................... 22

Install an External PlexWriter Drive .................................................................. 28

Connect a Single Drive...................................................................................28

Connect Multiple Drives ................................................................................29

Using Sound Boards and Audio Cables .............................................................30

Audio Cables.................................................................................................. 30

3. Installing and Using Software.........................................................................33

Quick Installation in Windows 95/98................................................................. 33

Install or Update SCSI Support..........................................................................34

Plextor Drive with Software Kit..................................................................... 34

Plextor Drive with PCI SCSI Kit....................................................................34

Install Device Drivers.........................................................................................35

Install Plextor Applications Software.................................................................36

Plextor Manager 2000.................................................................................... 36

CD Res-Q....................................................................................................... 36

PlexWriter 8/2/20 Operation Manual

iii

Page 4

Other Applications Software.............................................................................. 37

4. Using Your PlexWriter ....................................................................................39

What Media to Use.............................................................................................39

Tray Loading and Operation...............................................................................39

Handling CD Media .......................................................................................40

Cleaning Discs................................................................................................40

Playing Audio CDs.............................................................................................41

Connections for Playing Audio CDs ..............................................................41

Playing a CD ..................................................................................................41

Writing to CD-R and CD-RW Media.................................................................42

5. Maintenance and Troubleshooting .................................................................43

Upgrading Firmware ..........................................................................................43

Troubleshooting..................................................................................................43

Using SCSI Interface Messages .....................................................................43

Troubleshooting SCSI Problems ....................................................................44

Troubleshooting for Macintosh Users............................................................ 46

Troubleshooting Performance Problems ........................................................47

Troubleshooting Audio Problems...................................................................47

Troubleshooting Disc Problems .....................................................................49

6. Frequently Asked Questions about Recording ..............................................53

Appendix A: PlexWriter Specifications..............................................................55

Appendix B: Installing SCSI Support in Windows ...........................................59

Installing in Windows 95/98 ..............................................................................59

Install Hardware .............................................................................................59

Install SCSI Drivers for Windows 95/98........................................................59

Troubleshooting Windows 95/98 Installations............................................... 60

Installation in Windows NT ...............................................................................62

Install Hardware .............................................................................................62

Getting NT Drivers for Your SCSI Board......................................................62

Install SCSI Drivers for Windows NT............................................................62

Troubleshooting Windows NT Installations...................................................63

Appendix C: Technical Support..........................................................................65

How to Contact Us .............................................................................................65

Before You E-mail/Log On/FAX/Call ...............................................................66

Returns................................................................................................................66

Appendix D: Helpful Contacts............................................................................67

Index......................................................................................................................69

PlexWriter 8/2/20 Operation Manual

Page 5

1. Getting Started

This manual explains how to install and use your PlexWriter 8/2/20 internal or external drive. For those of you with PCs, the installation process may seem a bit complicated (Mac people have it easy). Fear not. We have successfully walked through the installation process with millions of customers who previously had lived in mortal terror of the innards of their computer.

About this Manual

Please read this manual carefully and keep it handy for easy reference. Use the manual for installation, operation, and troubleshooting. See your dealer or call Plextor’s Technical Support Department should your drive require repair or service.

In this manual you should find all the information you need to successfully install, operate and troubleshoot your drive. If you run into an unsolvable problem, however, please contact us. (See “Appendix C: Technical Support” for the different ways you can contact us). You will be connected to our friendly, helpful band of tech support engineers who know their stuff. What might seem like an uncooperative PlexWriter drive to you could very well be a 30-second fix to them. But we will never know unless you contact us.

Meet Your PlexWriter 8/2/20

The PlexWriter 8/2/20 is a CD-ReWritable drive that provides professional quality CD performance for writing, rewriting, and reading.

What the PlexWriter 8/2/20 Does

The PlexWriter 8/2/20 writes to CD-R (recordable CD) media at 8X speed, or to CDRW (rewritable CD) media at 2X speed. It reads all CD media—at a minimum of 9X and a maximum of 20X speed, with an average access time of 170 milliseconds.

Reliable writing is virtually guaranteed, thanks to unique circuitry that automatically detects the type of media being recorded and adjusts the PlexWriter 8/2/20 to provide the optimum laser power and length of burn. The PlexWriter 8/2/20 features Fast SCSI read and write, with burst transfer rates of 10 megabytes per second.

NOTE:

Only newer CD-ROM drives can read CD-RW discs. Drives manufactured before 1997 cannot read them. Plextor CD-ROM drives starting with the 12/20PleX or newer can read CD-RW discs.

The PlexWriter 8/2/20 is fully MMC-compliant, supporting writing features such as Disc-at-Once, Track-at-Once, and Session-at-Once, as well as variable and fixed packet writing. And it supports the UDF writable file system implemented through packet writing.

PlexWriter 8/2/20 Operation Manual

Page 6

Section 1. Getting Started

The PlexWriter 8/2/20 supports running OPC, and is compatible with Windows Plug and Play. Flash memory allows upgrading the PlexWriter 8/2/20 to the latest firmware revision (available from the Plextor web site) without opening the drive. And Plextor backs up this remarkable drive with a one-year full warranty on parts and labor, and unlimited toll-free tech support.

What You Can Do with the PlexWriter 8/2/20

Just look at some of the things you can do with your PlexWriter 8/2/20:

•

Record audio onto writable or rewritable CD media.

•

Play music CDs.

•

Periodically back up your computer's hard disk, including operating system, hardware configuration, registry, program files, and data. (Plextor's CD Res-Q™ software makes this easy!) You can even make a bootable CD.

•

Save photos and other images on rewritable CDs or writable CDs.

•

Create a “CD sneakernet” to share information with colleagues—just use software such as Adaptec DirectCD to drag and drop a file onto CD-R or CD-RW media, then continue adding files and sharing the same CD disc.

•

Archive images and video to CD.

•

Master new software programs on CD.

PlexWriter 8/2/20 Operation Manual

Page 7

What's in the Box

What you find in your Plextor box depends on two factors:

•

What configuration you purchased; and

•

What the company that sold you the box put in—or took out— while the Plextor drive was in their possession.

Plextor currently sells its PlexWriter 8/2/20 drives in these configurations:

• Drive with Software Kit:

Includes the PlexWriter drive with CD-R and CD-RW media and bundled software, such as:

CD-mastering software for PC

Packet writing software

CD Res-Q™, Plextor’s own software for hard disk backup and disaster recovery

Plextor Manager 2000, Plextor's utility software for getting the best performance from your PlexWriter drive

Other utilities, which we'll add as needed

• Drive with PCI SCSI Kit:

Includes the PlexWriter drive, the CD-R and CD-RW media and software listed above, and the following:

SCSI interface board

SCSI cable

Audio cables for sound board

The configuration you received is indicated by stickers applied to your box. Your drive may also have been integrated into a computer system or subsystem sold by a third party.

Section 1. Getting Started

Save Your Box!

Be sure to save the box after you have installed your PlexWriter drive. The box and its packaging material were designed and drop tested to ensure that your PlexWriter can endure rough treatment and still arrive in working order. Also, please save the red shipping insert that is used for shipping protection. It should be placed inside the drive, on the tray, before shipping the PlexWriter.

We hope you will never have to ship your drive back to us. If you do, however, it's best to send it packaged in the original box. Some of our customers have not held on to their boxes and have had to resort to less-than-secure methods to get drives back to us.

We cannot assume liability for any damage your drive sustains during shipment. Therefore, please ship your drive in the safest manner possible.

Before shipping your drive, refer to the Plextor web site for pointers. The web site is at: http://www.plextor.com

If you did not receive a box (for example, your drive came pre-installed in a computer), we recommend you pay a packaging store (such as Mail Boxes Etc.) to ship your drive. If you don’t have a packaging store in your area, ask our Technical Support Department for packaging pointers when you call to get an RMA number before returning any drive.

PlexWriter 8/2/20 Operation Manual

Page 8

Section 1. Getting Started

NOTE:

Look at the security sticker on top of your box. If the sticker is cut, there may be a good reason: for example, a dealer may have purchased one configuration from Plextor, then added other components or software. Carefully check the contents to ensure nothing has been removed. If something is missing, contact the party from whom you purchased the box for an explanation.

Use this table to check the contents of your box:

Here's What Should Be In Your PlexWriter Box

PX-W8220Ti Internal

Drive

Item Drive

with

Software

Kit

CD-RW drive X X X X 4 mounting screws X X Approved CD-RW media (1 piece) Approved CD-R media (1 piece) Plextor CD with bundled software, Plextor Manager, and CD Res-Q SCSI interface board and quick install guide* Audio cable* X (2) X (1) Power cable X X SCSI cable* X X Plextor operation manual* Warranty registration card Plextor Manager 2000 manual CD Res-Q manual X X X X Extra jumpers for setting drive switches

XXXX XXXX XXXX

Drive with

PCI SCSI

Kit

PX-W8220Te External

Drive

Drive with

Software

Kit

Drive with

PCI SCSI

Kit

* See Appendix D for locations to purchase additional or replacement accessories.

NOTE

: If your drive came pre-installed, the rails, cables, interface boards and other parts shown in the table may have been installed and may not be separately available. Other accessories, especially software, may not have been purchased from Plextor and thus may be different from those sold in Plextor retail packages.

PlexWriter 8/2/20 Operation Manual

Page 9

Section 1. Getting Started

PlexWriter Drive Features and Controls

Before proceeding, become familiar with the controls and features of your PlexWriter drive. Match the parts of your drive to the illustrations below.

Front Panel—Internal and External Drive

Figure 1: Front Panel of the PlexWriter 8/2/20 Drive

Tray front door: Attached to tray drawer.

•

• Headphone jack: Stereo mini-jack for headphones and powered speakers.

Volume control: Controls volume of headphone jack. This control has no effect

•

on the rear panel audio outputs.

• DISC indicator: Green when disc is in the drive and power is ON.

• ON/READ indicator: Green when power is ON and no disc is in drive. Green

flashing when disc is being accessed.

• WRITE L indicator: Orange when recording CD-R discs at 1X, 2X, or 4X

speed.

PlexWriter 8/2/20 Operation Manual

Page 10

Section 1. Getting Started

• WRITE H indicator: Orange when recording CD-R discs at 8X speed.

Both WRITE H and WRITE L indicators are turned on (orange) when recording CD-RW discs at 2X speed.

CD-Audio play/skip forward but ton: With an audio CD in the drive, push once

•

to put the drive in CD-Audio play mode. Push button once during CD play mode to skip tracks. Push and hold down this button more than one second to fast forward.

Stop/Eject button: Push to eject tray. During CD play mode, press once to stop

•

playback; press twice to eject the disc.

• Emergency eject hole: Insert emergency eject stick, paper clip, or other thin,

rigid object to eject tray if automatic eject button does not work. Turn OFF power before using this feature.

Rear Panel—Internal Drive

Figure 2: Rear Panel of the PlexWriter 8/2/20 Internal Drive

• Audio output connector: Outputs stereo analog signal. Use to connect to sound

board or audio amplifier. Use standard MPC-3 type, 4-pin connector.

• Jumpers: Use to select SCSI ID, parity, SCSI termination, or block size. Leave

these jumpers at their factory settings unless one or more of the following situations pertains to you:

SCSI ID: If you are using more than one SCSI peripheral, you may have to change your SCSI ID number; see page 16 for details.

PRTY: Parity. In some cases, you may need to turn parity off; see page 15.

TERM: SCSI termination. In some situations, you may need to set this jumper to turn the PlexWriter's SCSI termination off; see page 17 for details.

PlexWriter 8/2/20 Operation Manual

Page 11

Section 1. Getting Started

TEST: For factory use only. Do not change this setting.

BLOCK: Block size. You may need to change this setting if you are working in a UNIX environment and want to boot from your PlexWriter; see page 15.

SCSI interface connector: Connects to SCSI interface board using

•

50-pin-to-50-pin flat ribbon SCSI cable.

Power connector: Connects to your computer’s power supply to provide

•

DC +5V and +12V to the PlexWriter.

Rear Panel—External Drive

Figure 3: Rear Panel of the PlexWriter 8/2/20 External Drive

• SCSI ID: Use this dial to designate SCSI ID numbers. Rotate the dial to change

the number. If you are using more than one SCSI peripheral, you may need to change your SCSI ID number; see page 18.

• DIP switches: Use to select parity, SCSI termination or block size. Leave these

switches at their factory settings unless one or more of the following situations pertains to you:

PRTY: Parity. In some cases, you may need to turn parity off; see page 15.

TERM: SCSI termination. In some situations, you may need to set this jumper to turn the PlexWriter's SCSI termination off; see page 17 for details.

TEST: For factory use only. Do not change this setting.

PlexWriter 8/2/20 Operation Manual

Page 12

Section 1. Getting Started

BLOCK: Block size. You may need to change this setting if you are working in a UNIX environment and want to boot from your PlexWriter; see page 15.

Power switch: To turn power the drive's power ON or OFF.

•

• AC power input: Use the power cord supplied with your drive.

• Audio output connectors: Output stereo analog signal. Use to connect to sound

board or audio amplifier. Use standard RCA jack connectors.

• SCSI-In and SCSI-Out interface connectors: Use one connector to link your

PlexWriter to your SCSI interface board. Use the other to link your PlexWriter to another SCSI peripheral in a chain; see page 28. You may use either connector for either purpose.

What Else Do You Need?

Use this table to determine what else you'll need to install your PlexWriter.

Internal or external PlexWriter, in Plextor box labeled "Drive Kit with PCI SCSI Interface":

What You Have What Else You

Need

Internal or external PlexWriter, in Plextor box labeled "Drive Kit with PCI SCSI Interface" Internal PlexWriter in box labeled "Drive with Software Kit"

An existing SCSI interface board.

PlexWriter 8/2/20 Operation Manual

Nothing; everything is included in the box you purchased.

SCSI ribbon cable. (Use an existing ribbon cable or purchase a new one.)

You may need to update your device drivers.

You may still need a new SCSI board, if your existing one is old.

Important Notes

Your cable must have at least as many connectors as you have SCSI peripheral devices (including your PlexWriter), plus one additional connector to attach to the interface board.

Use only high-performance, busmastering SCSI interface boards. PIO SCSI interfaces may not properly support high speed (8X) CD recording.

Page 13

Section 1. Getting Started

What You Have What Else You

Need

External PlexWriter

in box labeled

"Drive with

Software Kit"

External SCSI cable. (Use a SCSI cable you may already have or purchase a new

An existing SCSI

one.)

interface board.

You may need to update your device drivers.

You may still need a new SCSI board, if your existing one

is old. Internal PlexWriter in box labeled

SCSI interface

board "Drive with Software Kit"

SCSI interface board in your computer.

SCSI ribbon cable.

External PlexWriter in box labeled

SCSI interface

board "Drive with Software Kit"

SCSI interface board in your computer.

Important Notes

Make sure at least one end of the cable has the same kind of SCSI connector as your PlexWriter. The other end of the cable must have the proper connector to fit your SCSI interface board or another chained external SCSI device.

Use only high-performance, busmastering SCSI interface boards. PIO SCSI interfaces may not properly support high speed (8X) CD recording. Purchase a SCSI interface board from a local or mail-order computer store. Use only highperformance, bus-mastering SCSI interface boards. PIO SCSI interfaces may not properly support high speed (8X) CD recording.

Your cable must have at least as many connectors as you have SCSI peripheral devices (including your PlexWriter), plus one additional connector to attach to the interface board. Purchase a SCSI interface board from a local or mail-order computer store. Use only highperformance, bus-mastering SCSI interface boards. PIO SCSI interfaces may not properly support high speed (8X) CD recording.

External SCSI cable.

PlexWriter 8/2/20 Operation Manual

Page 14

Section 1. Getting Started

About Pre-mastering Software

In order to create CD-R and CD-RW discs you will need to have pre-mastering software installed on your computer system. You can check our web site (www.plextor.com) for an updated list. We provide pre-mastering software kits in retail packaging for your convenience.

Precautions

Like the rest of your computer system, your PlexWriter requires reasonable care in its installation and use.

•

Do not put your computer monitor (or anything weighing more than 30 lbs.) on top of a PlexWriter external drive.

•

Do not place your drive in direct sunlight, on heating units, or near electrical appliances that draw large amounts of current, such as a high-power audio amplifier, microwave oven, toaster, etc.

•

Keep the area around your drive clean from dust, smoke, and other contaminants.

•

Use a soft, dust-free cloth for cleaning your drive. Do not allow moisture or liquids, including water or cleaning fluids, to touch the drive. Thinner, benzene, or alcohol-based solvents can mar your drive’s surface.

•

Do not drop or jolt the drive.

•

Do not attempt to open the drive and service it yourself. Removing the cover may expose you to harmful electrical voltages or the laser beam. For your safety, entrust service to Plextor-authorized service personnel only.

•

Keep your CD-ROM discs free of dirt or other contaminants, by storing them in jewel cases. Use only industry-standard discs. Do not insert dirty, warped, poorly balanced, or cracked discs into the drive.

•

Do not clean discs using a circular motion. Instead, use a radial motion: start at the center of the disc and proceed to the outer edge.

PlexWriter 8/2/20 Operation Manual

Page 15

2. Installing Your PlexWriter

This chapter explains how to physically install your PlexWriter in your computer (internal drive), or how to attach the PlexWriter (external drive). The steps you'll need to do are as follows:

1. Turn OFF your computer system.

2. Set the SCSI ID for your new PlexWriter drive.

3. Set the PlexWriter's termination. (By default, termination is enabled.)

4. If you have a new PCI SCSI interface board, insert it into an available PCI slot in your computer.

5. If you have an internal model Plextor drive, mount the drive into an available drive bay inside the computer system.

6. Make all necessary cabling connections: SCSI cable, power cable, and audio cable.

7. Turn your computer system ON.

The following pages give more details for this procedure.

Quickstart Installation—For Experienced PC Users Only

If you’ve installed computer peripherals before, you’re in luck with the PlexWriter drive. Use this “quickstart” installation designed to get you up and running quickly.

Scenario 1: You purchased a Plextor Drive with SCSI Kit, the PlexWriter is your only SCSI peripheral, and you have Windows 95 or Windows 98. What to do: Install the SCSI board, plug in the PlexWriter, and go. Windows will recognize the board. After the SCSI board drivers are installed, the drive’s drivers will automatically be installed by the operating system.

Scenario 2: You have a SCAM SCSI board installed, the PlexWriter is your only SCSI peripheral, and you have Windows 95 or 98. What to do: Plug in the PlexWriter, and go. Windows will recognize the drive and install the correct drivers automatically.

Set Drive Switches or Jumpers

Your PlexWriter needs to be flexible enough to work with the variety of computer systems and a number of other SCSI peripherals. To provide this flexibility, Plextor lets you specify the drive's settings before it is installed. On an internal drive, you determine settings by the position of jumpers on the jumper block at the rear of the drive. On an external drive, you determine settings by the position of DIP switches and the rotary dial on the rear panel of the drive.

PlexWriter 8/2/20 Operation Manual

Page 16

Section 2. Installing Your PlexWriter

Your drive ships from our factory with its jumpers, switches, and/or dial set to work in the most commonly found environment. You should leave those switches and jumpers at their factory settings, unless: 1) you plan to use another SCSI peripheral (e.g., CD-ROM, hard disk, scanner) with your computer system in addition to your PlexWriter; or 2) you find it necessary to change the block size setting (most likely in an older UNIX system).

Do I Have to Change My PlexWriter's SCSI ID number?

Your PlexWriter is shipped from the factory with its SCSI ID number set to 4. The SCSI interface lets you chain several SCSI peripheral devices to a single SCSI interface board, or to the SCSI port of an Apple computer with no loss of performance. However, each peripheral must have a unique SCSI ID number—your PlexWriter can have any of 8 numbers (0-7). SCSI ID 7 is typically reserved by the SCSI interface board.

Quickstart Installation (Continued)

Scenario 3: You have a SCSI board that is not Plug and Play/SCAM-capable, and you have Windows 95 or 98. What to do: Set a unique SCSI ID number for the PlexWriter, and make sure all other peripherals have their own SCSI numbers. Set the termination of each peripheral OFF; except set the termination of the last peripheral devices on each side of the chain to ON.

Other scenarios, or if you have problems: Better take a closer look at

this chapter and at “Appendix B: Installing in Windows.”

NOTE:

The cable length of all SCSI chai n cables should not exceed 1.5 meters.

You probably don't need to physically set the SCSI ID if:

Your PlexWriter drive is the only SCSI peripheral: In this case, don't change

•

the SCSI ID. Leave it set to the original factory setting of 4. You have a PlexWriter Drive with PCI SCSI Kit: If you bought a Plextor kit

•

with a SCSI interface board, both the drive and the board are SCAM-compliant. This means each time you turn on your computer, the SCSI interface board will detect whether there is SCSI ID conflict between multiple devices. Because your PlexWriter also supports SCAM, the drive automatically resets its SCSI ID internally to avoid any conflict with other devices. (This overrides any hardware settings.) So you don't have to worry about setting SCSI ID numbers.

• You have a SCAM-compliant SCSI board: Your Plextor drive is also SCAM-

compliant, so if you have Windows 95 or 98, you don't have to worry about setting SCSI ID numbers.

PlexWriter 8/2/20 Operation Manual

Page 17

Section 2. Installing Your PlexWriter

You may have to physically set the SCSI ID if you have more than one SCSI peripheral device and:

Your SCSI board is not SCAM -compliant: If you separately purchased or

•

already own a SCSI interface board, it may not be SCAM-compliant. In this case, you should determine the SCSI IDs of all peripheral devices and change the PlexWriter's ID to a unique number.

• You don't know if your SCSI board is SCAM-compliant: In this case, to be on the safe side, determine the SCSI IDs of all peripheral devices and change the PlexWriter's ID to a unique number.

• You may have an older driver: Since SCAM was not a requirement when Plugand-Play specifications were written, original Windows 95 CDs may not include a SCAM-compliant driver for your SCSI interface board. In this case, you should determine the SCSI IDs of all peripheral devices and change the PlexWriter’s ID to a unique number.

Do I Have to Change My PlexWriter's Termination Setting?

The PlexWriter is shipped from the factory with its SCSI termination set ON.

You can leave the PlexWriter's SCSI termination setting to ON if:

Your PlexWriter drive is the only SCSI peripheral: In this case, don't change

•

the SCSI termination setting. Leave it set to the original factory setting of ON.

• Your PlexWriter drive is the last peripheral in a chain: If you are using multiple SCSI peripherals with your computer and the PlexWriter is positioned as the last peripheral in a chain, don't change the PlexWriter's termination setting. Leave it set to ON.

NOTE

: The PlexWriter uses active termination.

You should change the PlexWriter's SCSI termination setting to OFF if:

• Your PlexWriter is in the middle of a chain: If you have multiple SCSI peripherals and the PlexWriter drive is not the last device in the chain, set its SCSI termination to OFF. (In this case, remove, disable, or turn off termination for all devices between the SCSI board and the last peripheral on the opposite end of the chain. Set the termination of the last device in the chain to on.)

PlexWriter 8/2/20 Operation Manual

Page 18

Section 2. Installing Your PlexWriter

Figure 4: What Termination Settings to Use

REMEMBER

enabled. If you have any SCSI devices chained after your PlexWriter, you must disable or turn OFF the PlexWriter’s SCSI termination using the instructions later in this chapter.

: Only the last SCSI peripheral in the chain should have termination

Termination Power

Some interface boards and peripherals have the ability to disable and enable termination power. This should not be confused with termination itself. Termination power can and should be provided by at least one device attached to your SCSI interface board. Your Plextor drive automatically supplies termination power. Any additional devices supplying termination power will not cause any problems.

PlexWriter 8/2/20 Operation Manual

Page 19

Section 2. Installing Your PlexWriter

Do I Have to Change Other PlexWriter Settings?

You probably won't have to change any of the other settings on your PlexWriter drive's switches or jumpers. Use this table to help decide.

Switch or

Jumper

Setting

PRTY Parity setting. Leave this ON. The parity check provided by the

ON setting enhances the reliability of the SCSI bus. Set to OFF only if your computer system or SCSI interface board specifically requests that parity be disabled.

TERM Termination setting. This enables or disables (turns ON or OFF)

SCSI termination. Factory setting is enabled (ON). See page 13 for an explanation of SCSI termination and to determine if you

need to change this setting. TEST Leave this OFF. It is for factory use only. BLOCK Block size. Leave this OFF, unless you are working in a UNIX

environment and want to boot from your PlexWriter drive. If so,

set this switch/jumper ON.

Where to Set It

Setting Jumpers on an Internal PlexWriter Drive

Use this procedure if you have a PlexWriter internal drive. (However, if you already have a SCSI board installed, an internal PlexWriter is the only SCSI peripheral you will use with your computer, and you do not need to change any settings, skip now to “Install an Internal PlexWriter Drive” on page 19.)

PlexWriter 8/2/20 Operation Manual

Page 20

Section 2. Installing Your PlexWriter

Factory Jumper Settings

Figure 5 shows the factory settings of the jumpers. The functions shown are ON if the jumpers are installed and OFF if the jumpers are removed.

Figure 5: Factory Settings for Jumpers at the Rear of the Internal Drive

Changing Jumper Settings

To remove a jumper, pull it off with your fingers or a pair of needle-nose pliers.

CAUTION

: Ensure power to the drive is OFF before installing or removing jumpers.

To add a jumper, push it onto the jumper pins. In addition to the three jumpers already installed at the factory, extra jumpers are supplied with the PlexWriter drive.

Figure 6: Install Jumpers Across Vertical Pairs of Pins

PlexWriter 8/2/20 Operation Manual

Page 21

Section 2. Installing Your PlexWriter

CAUTION

pin switch to another by installing the jumpers lengthwise (horizontally). Doing so could result in damage to the drive.

: Install jumpers across each pin as shown (vertically). Do not connect one

Changing the SCSI ID

If you already have another SCSI peripheral whose SCSI ID is set to 4, you must change the SCSI ID number of either that peripheral or that of the PlexWriter drive. (But see “Do I Have to Change My PlexWriter's SCSI ID number?” on page 12 before proceeding.)

The SCSI ID number of the internal PlexWriter drive is determined by the placement of jumpers on Pins 1, 2, and 3. (To find the location of Pin 1, Pin 2, and Pin 3, refer to the jumper diagram above.) To change the SCSI ID number, follow the chart below.

Jumper Installed Across

SCSI ID Number Pin 1 Pin 2 Pin 3

0 OFF OFF OFF 1ONOFFOFF 2 OFF ON OFF 3 ONONOFF 4 (Factory setting) OFF OFF ON 5ONOFFON 6 OFF ON ON 7 ONONON

For example, the factory setting for SCSI ID 4 is made by installing a jumper across Pin 3 of the jumper block, leaving Pin 1 and 2 uncovered. To set the SCSI ID at 3, you would install a jumper across Pin 1, another jumper across Pin 2, leaving Pin 3 uncovered. To set the SCSI ID at 2, you would install a jumper across Pin 2, leaving Pins 1 and 3 uncovered.

Changing the SCSI Terminatio n Set ting

The PlexWriter internal drive is shipped from the factory with its SCSI termination enabled (ON).

If you have to disable (turn OFF) SCSI termination on your PlexWriter drive, remove the jumper from Pin 5. Factory setting is enabled (ON). See page 12 for an explanation of SCSI termination and to determine if you need to change this setting.

If your drive is already installed in your computer, be sure to turn off your computer before removing (or reinstalling) the jumpers. We recommend that you retain the jumpers so you can reinsert them onto the termination pins if you later need to turn the drive’s SCSI termination ON.

PlexWriter 8/2/20 Operation Manual

Page 22

Section 2. Installing Your PlexWriter

If you have internal SCSI peripherals only, then you should be using an internal ribbon cable. In this case, all devices between the SCSI host adapter and the last peripheral on the opposite end of the ribbon cable should have their termination removed, disabled, or turned off.

If you have both internal and external SCSI peripherals (both the internal and external connectors of your host adapter are used), then the termination of your SCSI interface board should be removed, disabled or turned OFF. The last peripheral on your internal cable and the last peripheral on your external SCSI chain should retain their termination (have it set ON). All other SCSI peripherals connected to the host adapter should have their termination removed, disabled, or turned off.

NOTE:

The SCSI interface board that is bundled in the Plextor kits has Auto Termination, so turning off its termination is unnecessary. However, you still must sometimes specify termination ON or OFF on the PlexWriter drive, as discussed on page 13.

Setting Switches on an External PlexWriter Drive

Use this procedure if you have a PlexWriter external drive. (However, if you already have a SCSI board installed, an external PlexWriter is the only SCSI peripheral you will use with your computer, and you do not need to change any settings, skip now to “Install an External PlexWriter Drive” on page 28.)

Factory Switch Settings

A rear-panel rotary dial controls the SCSI ID setting of the external PlexWriter drive, and other settings are controlled by DIP switches. Figure 7 shows the factory settings of the rear-panel dial and switches.

Figure 7: Factory Settings for the Dial and DIP Switches on the External Drive

CAUTION

or the DIP switches.

PlexWriter 8/2/20 Operation Manual

: Turn the drive’s power OFF before changing the setting of the SCSI dial

Page 23

Section 2. Installing Your PlexWriter

Changing the SCSI ID

To change the SCSI ID number of the external PlexWriter drive, rotate the dial’s arrow to a different SCSI ID number.

Changing the SCSI Terminatio n Set ting

The PlexWriter external drive is shipped from the factory with its SCSI termination enabled (ON). If you have to disable SCSI termination on your PlexWriter drive, set DIP switch 2 to OFF.

If you are using external SCSI peripherals only, then you should be using an external SCSI cable (or cables). In this case, all devices between the SCSI host adapter and the last peripheral on the end of your SCSI chain, should have their termination removed, disabled, or turned off.

If you have both internal and external SCSI peripherals (both the internal and external connectors of your host adapter are used), then the termination of your SCSI host adapter should be removed, disabled or turned OFF. The last peripheral on your internal cable and the last peripheral on your external SCSI chain should retain their termination (have it set ON). All other SCSI peripherals connected to the host adapter should have their termination removed, disabled, or turned off.

NOTE:

Install a SCSI Interface Board

By itself, your PlexWriter is incapable of communicating with your computer. You must use a hardware link that enables your drive to “talk” with the rest of your computer. The PlexWriter uses a SCSI interface as its link.

SCSI board already installed? Even if you already have a SCSI board in your computer, it may not be adequate for use with your high-performance PlexWriter drive. See “How to Choose a SCSI Board” for more details. Then, if your SCSI board is suitable, you can go directly to “Install an Internal PlexWriter Drive” on page 22; or to “Install an External PlexWriter Drive” on page 28.

PlexWriter 8/2/20 Operation Manual

Page 24

Section 2. Installing Your PlexWriter

How to Choose a SCSI Board

Plextor's technical support engineers have developed these recommendations for choosing and installing a SCSI board that gives the best performance with your PlexWriter drive:

•

Use a high performance bus-mastering SCSI interface board, preferably a PCI board. (If you purchased a PlexWriter Drive with PCI SCSI Kit, this board is included.)

•

Connecting the PlexWriter to a parallel-to-SCSI interface, or to the SCSI interface on a sound board will slow the PlexWriter's performance and is not recommended. With this configuration, you will not be able to achieve 8X writing speed.

•

If you have a desktop PC, do not connect your PlexWriter drive to a non-busmastering interface board (PIO). You will not be able to achieve 8X writing speed with this configuration.

•

If you have a laptop computer, you can use a PIO PCMCIA card; however, these cards can write at 4X speed at best. To achieve full 8X writing performance, use a CardBus PCMCIA card.

Install the SCSI Board

This is a PlexWriter installation and operation manual—it is not a SCSI interface board operation manual. Unless you purchased a SCSI interface board (and its accompanying manual) bundled in the same box with a PlexWriter, we have no way of knowing which type of board you elect to use. There are dozens of SCSI interface boards on the market, and each is installed somewhat differently.

Use the instructions for this section only as guidelines. For more detailed instructions on how to properly install your SCSI interface board, refer to the operation manual you received when you purchased the board.

CAUTION

killer. Just a small jolt to one of the chips on your interface board may render it useless with no apparent damage. To guard against static electricity, position your computer in a location wi thout a carpet underfoot. Also, use common sense—for example, don't walk on a carpeted floor in stocking feet just before you install your SCSI board or PlexWriter drive.

PlexWriter 8/2/20 Operation Manual

: Be very careful not to cause static electricity. Static electricity is a silent

Page 25

Section 2. Installing Your PlexWriter

To install the SCSI board:

1. Before proceeding, make sure the power to your computer and any external

peripherals is OFF and your computer is UNPLUGGED from its power source.

Figure 8: Removing a Typical Computer's Cover

2. Remove your computer’s cover, following the directions provided by your

computer’s manufacturer. Typically, this involves loosening or removing several screws on the back panel of your computer and sliding off the cover. See Figure 8 for details.

3. Carefully remove the SCSI interface board from its packaging.

CAUTION

grounded object before you remove the host adapter from its packaging.

: Discharge any static elec tricity you may have on your body by touching a

4. Select a vacant slot in your computer where you will install the board (refer to the

manual packaged with your interface board for instructions as to which slot in your system to use). If your PlexWriter is an internal drive, try to pick a slot that is closest to where the drive will be installed.

5. Remove the cover plate for this slot from the back panel of your computer. Keep

the screw from the cover plate nearby, as you will need it in a moment. Save the cover plate in case you need it at a later date.

PlexWriter 8/2/20 Operation Manual

Page 26

Section 2. Installing Your PlexWriter

Figure 9: Removing the Cover Plate

6. Plug the SCSI interface board into the slot you have selected. Rock the board from end to end to ensure that it seats firmly in the slot. Don’t force it. If you cannot push the board down completely into the slot, remove the board and try again.

7. Once you have successfully inserted the board, fasten it in place using the cover plate screw that you removed earlier.

Install an Internal PlexWriter Drive

This section explains how to install an internal PlexWriter drive in a PC. If you have an external drive, go to the section titled “Install an External PlexWriter Drive” on page 28.

Before proceeding, double-check your SCSI number setting, SCSI termination setting, and other jumper-controlled settings.

Record the Serial Number

Record the serial number and TLA code of your drive on the inside front cover of this manual.

Mount the PlexWriter Drive

You can mount your internal PlexWriter drive in any available bay. You must remove the small panel that covers the bay that you want to use.

CAUTION

performance in a vertical position.

PlexWriter 8/2/20 Operation Manual

: Install your PlexWriter horizontally. Plextor does not guarantee drive’s

Page 27

Section 2. Installing Your PlexWriter

You must make a minimum of two cable connections to your PlexWriter. The two cable connections that you must make are:

•

SCSI cable

•

Power cable

A third cable connection will need to be made if you are using a sound board in your computer and plan to connect the PlexWriter’s audio output to the audio connector on the sound board.

Choose a SCSI Ribbon Cable

The SCSI cable you will need is a standard 50-pin flat-ribbon cable. The cable may have a termination on it.

Figure 10: Internal SCSI Ribbon Cable

You may need to add or change a SCSI ribbon cable. Use these guidelines to help decide on what internal SCSI cable you will use.

You purchased an internal Plextor Drive SCSI Kit: Use the SCSI cable that

•

came with the kit.

• The SCSI cable in your PC has a free connector: Use that SCSI cable.

• The SCSI cable in your PC does not have a free connector: If you already

have one other SCSI peripheral (such as a hard disk) and your existing cable has only two connectors, remove the cable and replace it with a cable with additional connectors. You will need to purchase this cable.

Do You Need a Power Cable?

In most computers, you will find free power connectors in the computer that are ready for your use. When you open the computer, check the cable running from your power supply to your hard disk and see if it has extra connectors on it. If so, you can plug one of these into the power connector found on the rear panel of the PlexWriter.

If you do not find any additional connectors (either because they were not supplied or they are all in use), you will have to buy a “splitter” or a “Y-connector.” These can also be found at most retail and mail-order computer stores.

PlexWriter 8/2/20 Operation Manual

Page 28

Section 2. Installing Your PlexWriter

To mount the PlexWriter drive:

1. Make sure the power to your computer and any external peripherals is OFF and your computer is UNPLUGGED from its power source.

2. If you haven't already removed your computer's cover, remove it now, following the directions provided by your computer’s manufacturer. Typically, this involves loosening or removing several screws on the back panel of your computer and sliding off the cover. See Figure 8 for details.

3. Remove the cover panel from the bay that will hold the PlexWriter drive. To remove the cover panel, pop it out by pressing outward lightly. (In some older computers, you may have to remove screws that hold the panel in place.)

Figure 11: Removing the Cover Panel from a Bay

4. Determine if you must install mounting rails on the sides of your drive. To do so, insert the drive into the open bay. If the drive fits tightly with little or no clearance on either side of the drive, you will not have to use mounting rails. The drive can be mounted directly into your computer. Go to step 6.

NOTE:

Plextor does not provide rails. If you need rails, you can obtain them from the

computer manufacturer or from a computer supply retail or mail-order store.

5. If you must use mounting rails, fasten the rails to the lower pair of holes as shown in Figure 12. (In some instances, you may need to fasten the rails to the upper set of holes.) After fastening the rails, check their positioning by sliding the drive into the bay before you mount the drive or connect any cables.

PlexWriter 8/2/20 Operation Manual

Page 29

Section 2. Installing Your PlexWriter

Figure 12: Installing Mounting Rails (if Needed)

6. Plug a free connector on the SCSI cable into the SCSI connector on the rear panel of the drive before you insert the drive into your computer. Then thread the cable through the front of the open bay you plan to use and back toward the SCSI interface board. The drive should slide smoothly into the bay. If it does not, check for obstructions in the bay and ensure the side rails (if needed) are attached properly.

7. If not already connected, attach one end of the SCSI ribbon cable to the connector on the SCSI board.

PlexWriter 8/2/20 Operation Manual

Page 30

Section 2. Installing Your PlexWriter

Figure 13: Connecting the SCSI Ribbon Cable

CAUTION

both your drive and SCSI interface board. Be sure you match the red stripe along on e side of the SCSI cable to Pin 1 on the interface board and Pin 1 on the drive. Each connector on the ribbon cable has a “key” in the middle. This key should fit into a slot in the middle of each connector of the SCSI interface board, your PlexWriter, and any other internal SCSI peripherals.

: It is easy to accidentally plug your SCSI ribbon cable upside down into

8. Double-check your work. You must ensure the side of the SCSI cable with the red stripe is matched to Pin 1 on the interface board and on the drive.

Figure 14: Power and SCSI Connections for an Internal PlexWriter Drive

PlexWriter 8/2/20 Operation Manual

Page 31

Section 2. Installing Your PlexWriter

9. Connect a power cable from the computer to the DC INPUT connector of the PlexWriter drive. In most computers, you will find free power connectors that are ready for your use.

Check the cable running from your power supply to your hard disk and see if it has extra connectors on it. If so, you can plug one of these into the power connector found on the rear panel of the PlexWriter.

10. Connect the audio cable if you want to use a sound board in your system. This cable runs from the four-pin audio output connector on the rear panel of your PlexWriter drive to your sound board. See “Using Sound Boards and Audio Cables” on page 30 for more information about audio cables.

11. Mount the PlexWriter drive in the computer using the four screws were supplied with your drive. Use only these screws.

CAUTION:

supplied by Plextor. You may damage the drive if you insert screws that are too long.

Do not mount your drive in your computer using screws other than those

SCSI Cable Connection Hints

If you have more than one peripheral device (the PlexWriter drive and one other peripheral), connect the two peripherals to the other two connectors. The device farthest from the SCSI must have its termination set to ON. (Refer to page 13 of this manual for information about SCSI termination.)

PlexWriter 8/2/20 Operation Manual

Page 32

Section 2. Installing Your PlexWriter

Install an External PlexWriter Drive

To install an external drive, decide which cables you use, and whether you need to change the switch, dial, and terminator settings on your PlexWriter and other peripherals.

Before proceeding, double-check your SCSI number setting, SCSI termination setting, and other switch-controlled settings.

Connect a Single Drive

If you are installing a single external PlexWriter drive, connect it as shown in Figure

15.

Figure 15: Connecting a Single External PlexWriter to a PC

PlexWriter 8/2/20 Operation Manual

Page 33

Section 2. Installing Your PlexWriter

Connect Multiple Drives

If you are installing more than one PlexWriter external drive (or one PlexWriter and other external SCSI peripherals), connect them as shown in Figure 16.

Figure 16: Connecting Multiple Drives or Peripherals to a PC or Macintosh

NOTE

: Performance of SCSI devices may suffer if total cable length in the SCSI chain plus cabling in the external case exceeds 1.5 meters. (Assume cabling in the external case equals about 20 cm when adding up total cable length.) Quality of cabling is also important. Use shielded cables when possible.

PlexWriter 8/2/20 Operation Manual

Page 34

Section 2. Installing Your PlexWriter

Using Sound Boards and Audio Cables

Whichever category your sound board falls into, you will find that the best source of information about installing the sound board in your computer is the board's manual. Once you have successfully installed the sound board in your computer, you can continue below for a description of the different cable connections that need to be made.

NOTE:

board to control your PlexWriter. You may not be able to utilize high speed recording (8X) due to the performance of the board.

Plextor strongly suggests you not use the SCSI connection on your sound

Audio Cables

Plextor provides audio cables in kits which also include SCSI interface boards because we are assuming this will be the primary, or possibly the first, SCSI CDROM in your system.

Your PlexWriter Kit Audio Cables You

Received

Drive with Software Kit No audio cables; you will

have to purchase these cables.

Internal Drive with PCI SCSI Kit

1 MPC-compliant audio cable

1 Sound Blastercompatible audio cable

How to Connect Audio

Purchase the appropriate cables and connect them as for the Drive with PCI SCSI Kits detailed below.

Connect to MPC audio source, and to audio output connector at the rear of the PlexWriter.

Connect to Sound Blastercompatible audio board and to audio output connector at the rear of the PlexWriter (Figure 14).

If you purchased an internal drive SCSI interface kit and you have a sound board other than Sound Blaster that is not MPC-compliant, you will have to purchase a different audio cable from a computer supply store. We can help by recommending several vendors who offer audio cables; see page 67 of this manual.

PlexWriter 8/2/20 Operation Manual

Page 35

Section 2. Installing Your PlexWriter

Figure 17: Connecting Audio Cables to an External PlexWriter Drive

PlexWriter 8/2/20 Operation Manual

Page 36

Section 2. Installing Your PlexWriter

This page intentionally left blank.

PlexWriter 8/2/20 Operation Manual

Page 37

3. Installing and Using Software

There's one more step before you can begin to use your PlexWriter drive: you need to install special software on your computer. There are three software types:

SCSI support: Software that allows your SCSI board to operate with your

•

computer and the PlexWriter drive. Even if your SCSI board is already installed and operational, you may need to update this software.

• Device driver: Software program that allows your computer to interact with the

PlexWriter drive. Drivers are included in Windows 95/98 and NT that let you operate your PlexWriter as a CD-ROM device (reader). If you are using Windows 3.x or MS-DOS, you may have to install drivers yourself. Application software: Software programs for specific tasks, such as pre-

•

mastering CDs, backing up your hard disk or files, capturing audio, duplicating CDs, and more. Some of these applications are supplied with your PlexWriter, while others are available from other vendors.

Quick Installation in Windows 95/98

Use this section for a quick installation of your PlexWriter drive in a Windows 95 or Windows 98 system. If you encounter any problems, refer to “Appendix B: Installing in Windows.”

Windows 95/98 should automatically recognize and support your SCSI interface board and PlexWriter drive. Microsoft has included a generic CD-ROM device driver in the operating system. This driver also supports the PlexWriter as a reader. Microsoft has also included numerous controller-specific drivers on the Windows 95/98 CD-ROM.

• Previously installed SCSI interface board: If you connect your PlexWriter

drive to a previously installed and operating SCSI interface board, Windows 95/98 will recognize it automatically. You will need to install third party software to use the PlexWriter as a recorder.

• PlexWriter Drive with PCI SCSI Kit: If you purchased your SCSI interface

board in a Plextor kit, use the Plextor-provided CD-R software CD to access the necessary drivers.

• New SCSI controller board: If you purchased your new SCSI interface board

from another source, consult the documentation provided by the manufacturer of the SCSI interface board for installation instructions.

You will soon be using the highest performance CD-RW drive around. If you have any problems at all, our technical support staff will help you.

PlexWriter 8/2/20 Operation Manual

Page 38

Section 3. Installing and Using Software

Install or Update SCSI Support

The software to allow your SCSI board to operate depends on your operating system and on which Plextor kit you purchased.

Plextor Drive with Software Kit

This kit does not include a SCSI interface board. If you already have a SCSI board installed in your computer, or you are purchasing one separately, make sure the SCSI driver is up to date.

If you have Windows 95/98: You need a mini-port driver file (.MPD) that

•

allows your SCSI board to operate with Windows 95/98. Many mini-port drivers are included with Windows 95/98. However, if your SCSI board was released recently, it may not be supported by your version of Windows 95/98. In this case, contact the SCSI board manufacturer at their web site for the required .MPD file. If you have Windows NT: You need a .SYS file that allows your SCSI board to

•

operate with Windows NT. Some .SYS files are included with Windows NT. However, if your SCSI board was released recently, it may not be supported; in this case, contact the SCSI board manufacturer at their web site for the required .SYS file.

• If you have DOS or Windows 3.x: You need an ASPI manager file for

DOS/Windows 3.x to support your SCSI board. ASPI managers are provided by SCSI board manufacturers. Even if you have an ASPI manager file, it may need to be updated to work with your PlexWriter drive. Contact the SCSI board manufacturer at their web site for the latest driver version.

To install or update SCSI suppo r t for an existing SCSI board:

1. Try using the SCSI interface with your PlexWriter drive. If it works, you probably don't need to install or update the SCSI driver.

2. If you need to install or update SCSI support in your computer, follow the installation instructions supplied by the SCSI manufacturer.

Plextor Drive with PCI SCSI Kit

If you bought a PlexWriter Drive with PCI SCSI Kit, Plextor has included the applicable MPD, SYS and ASPI manager files. These are on your Plextor software disc.

To install SCSI support for the new SCSI board:

•

Follow the instructions in “Appendix B: Installing in Windows.”

PlexWriter 8/2/20 Operation Manual
