Tournament Foosball table
Model: FBTOCH
ASSEMBLY INSTRUCTIONS
Page 2
Congratulaons on selecng a Playcra Milan foosball table. Please contact us toll free at
(888) 367-3095 or via email at support@playcra.com should you require any assistance.
Please carefully read all safety instrucons and direcons before proceeding
1) Your table is designed for use indoors in a climate controled environment only.
Damage can occur if the table is exposed to water, dampness, high humidity,
freezing temperatures, etc.
2) The foosball table is heavy. Two or more people are required for assembly.
3) Only use the table for its intended purpose.
4) Damaged or worn parts may be dangerous for users and the integrity of the table.
Replace worn or damaged components immediately and do not use the table unl any
issues have been resolved. For best results, use only spare parts supplied by Playcra.
5) Unauthorized repairs or altering the table’s design or funcons may be dangerous and
will void the warranty.
6) Check all screws, bolts, etc. on a regular basis to ensure that they are in good working
condion and have not loosened over me.
7)
8)
9)
10)
Please keep the balls,lubricant and other parts out of children’s reach.
Don’t spray the lubricant to any person or animal.
This is not a child’s toy. Adult supervision is required for children playing this game.
please take care to avoid injuring any thing or person when you push and pull the player
rods .
page 1
Page 3
PARTS LIST
10
(Add a Check (√ ) to the box
1
TABLE BODY
1438*756*400mm
1 PC
4
7
GOALIE ROD
1086mm 1254mm
2 PCS
5PLAYERS ROD
1010mm
2 PCS 18 PCS
2
5
8
11
SCREWS
F4*35mm
to indicate receipt of each part.)
LEGS-LEFT
660*100*80mm
2 PCS
2PLAYERS ROD
2 PCS
BEARINGS
Ø57*48.5mm
3
6
9
12
BOLTS
10*65mm
LEGS-RIGHT
660*100*80mm
2 PCS
3PLAYERS ROD
1124mm
2 PCS
BEARTNG NUTS
57*6mm
18 PCS
LEG LEVELERS
Ø90*50mm
13
14
17
20
4 PCS
SCORER
300*25*21mm
NOTE: There are 8 sets of Bearings (#8 & #9) have already
been aached on the Table Body(#1).
16 PCS
2 PCS
ADDITIONAL PRE-INSTALLED PARTS. (FOR REFERENCE ONLY.)
TOOLS
1 SET
ROLL PIN
4.2*35mm
6 PCS
BOLTS
10*65mm
15
18
21
SOCCER BALLS
Ø35mm
8 PCS
ROLL PIN
4.2*28mm
2 PCS
ROLL PIN PUNCH
4*80mm
16
19
22
4 PCS
LUBRICANT
50ml
1 PC
PLAYER
108*35mm
2 PCS
MATERIAL
SAMPLE
2 PCS
1 PC1 PC
page 2
Page 4
ASSEMBLY INSTRUCTIONS:
We recommend that two adults work together to assemble this table.
•
The table must be turned over before assembling its Legs, then turn it over again to assemble player rods .
•
We suggest that you use the packing EPE as clean flat work area to protect the table.
12
FIG. 1
3
HOLD TABLE
SOSTENGA
LA MESA
2
11
CABINET
GABINETE
DO NOT HOLD THE LEGS
NO SOSTENGA LAS PATAS
DO NOT LEAN THE
TABLE ON ITS LEGS
NO APOYE LA MESA
EN SUS PATAS
2
3
1
CAUTION:
1. Lift the table off the ground.
2.
3. Place it on all four feet at the same time on the ground.
Two strong adults are recommended
to turn the
Turn the table over.
table over as shown.
FIG. 1: LEG ASSEMBLY
Attach the Legs (#2 & #3) between the Side and End Aprons with four Bolts (#11) per Leg as shown in Fig.1. Use the
•
Allen Key (#14) provided.
NOTE:
•
•
Please twist the four Bolts(#11) into one leg at the same schedule when you assemble the Legs . (Don’t twist the
Bolts very tightly at once .) .
Insert the Leg Levelers (#12) into the bottom of the Legs (#2 & #3) . See Fig.1.
Lift the table assembled from the floor by two strong adults,turn it over, and set table on its legs in the location where
you will play.
page 3
Page 5
FIG. 2FIG. 2
6
7
10
13
4
5
7
8
6
13
8
ORDER OF PLAYERS
/ ORDEN DE JUGADORES
9
5
4
FIG. 3
EACH TEAM SHOULD BE HEAD
a
FIG. 2: PLAYER / BEARING / SCORER ASSEMBLY
•
Carefully slide the grip end of Player Rod (#6) through the inside of Side Apron to outside ( unll the Player touch the
b
Side Apron ) , then slide another end of the Player Rod ( #6 ) through the directly opposite hole in the opposite Side
Apron .
= BLACK,
, ,
= YELLOW
IMPORTANT!
UP AND FACING THEIR OWN
GOAL
Slide the Player Rods(#4-#7) through the Side Apron in the order shown . See Fig .2 .
•
Aach all the Bearings in the accessory kits to the Side Aprons as shown Bearing (#8) in Fig.2.
•
Aach the Scorer Assemblies(#13) in the middle of each Top Slat Board using two Screws(#10) per Scorer.See Fig.2 .
•
Spray the Lubricant (#16) in a clean , so cloth first , then use this cloth to wipe the Player Rods . See Fig.3 .
•
page 4
Page 6
TABLE
SURFACE
RODS
TABLE MAINTENANCE
Keep your table covered . If there is dust on the playfield or the aprons , use a vacuum or wipe with a
clean , so cloth to remove . Do not sit on the table and do not use the table outside .
Occasionally wipe the rods with a clean , so cloth . Never li the table by the rods . Do not spin or
press the rods too agggressively , as this may cause damage . We recommend the use of lubricant to
wipe the Player Rods and Bearings from the outside of the game so as not to drip onto the playfield .
LEGS
FIG. 2FIG.4
Check that the leg bolts are ght. When moving the table,li table off of its legs and place it down
squarely on the legs, do not drag the table .
17
21
FIG. 4: PLAYER MAINTENANCE
•
Take down the Player Rod ,knock the Roll Pin (#17) out , then aach the spare Players and Roll Pin to this
Player Rod . See Fig.4. Use the Roll Pin Punch (#21) provided .
page 5
Page 7
Basic Foosball Rules
Flip A Coin - A coin flip decides who serves the foosball to start the foosball game. Aer the first goal
is scored, the rule is that the team who was last scored on gets to serve the next ball. This rule keeps the
game fair for both opponents. The foosball must be touched by a man before the ball goes into a goal for
a legal goal to occur.
No Spinning - A spin is a rule for when the rod completes a 360 degree rotaon without touching the ball.
This is deemed an illegal move in the rules of foosball.
No Jarring - Jarring is a rule for when a player slams his or her rods against the wall of the foosball table in
an aempt to distract or jar the foosball loose from the other player's possession. The rule is that there is
no jarring allowed at any point during a game. This is not the same as when a player on the opposite team
moves his or her foosball rods back and forth in an aempt to play defense. The key this rule is when a
player hits the wall of the table with enough force to jar the ball or distract the opponent. That is why this
is a subjecve rule that may be called more strict by certain foosball players.
Dead Balls - If a foosball stops in the middle of two opposing team rods, the ball must be picked up and
reserved. The serve goes back to the team that was last scored on. If a dead ball occurs on the defensive
side of the table behind the defensive 2 bar, the defensive player must move the ball back into playing
posion. This rule is in place so players don't cause a dead ball on purpose in order to force a reserve.
Out of Play - If a ball comes off the table area or hits a top rail and comes back into the table area, the
ball is ruled out of play and must be reserved by the team that was last scored on.
5 Bar Passing - These 5 bar passing rules are a lile complex if you have never played tournament foosball.
These passing rules do not apply to the other foosball rods, just the 5 bar. You are required to pass the ball
within a 10 second me period from your 5 bar rod to the 3 bar rod directly aer a serve. Aer the inial
serve, you then are allowed 15 seconds to pass from the 5 bar. A ball cannot be completely stopped on the
5 bar and passed forward to the 3 bar, it must be moving and touch 2 men on the 5 bar before being
advanced. Addionally, the ball can only touch the wall a total of 2 mes in a row (before touching a man
again on the 5 bar) before being advanced. However, it can touch the ball a 3rd me if it is part of the pass.
page 6
Page 8
Customer Service
For quesons on assembly or for missing or damaged parts, please contact us toll free at
(888) 367-3095 or via email at support@playcra.com. Please visit our website at
www.playcra.com to see more industry leading Playcra and Playcra Sport game tables.
Thank you for choosing Playcra!
Global Merchants, Inc.
12 Lunar Drive
Woodbridge, CT 06525
page 7
