Playcraft PCF1074 Installation & Assembly

FOR SHUFFLEBOARD

INSTRUCTION MANUAL

2

3

1

2

3

#24

1 pc

Shuffleboard speed wax

2

3

1

2

3

6pcs

Climate adjuster

Washer 3/8"*25mm

72 pcs

#23

72 pcs

Screw 5/16"*2-1/4"

#22 #21

PARTS LIST

Leg < 02 >

#1

1 pc

Board Leg < 01>

2 pcs

. 1 .

#2 #3 #4 #5

2 pcs

#8

#7

#6

#10

2 pcs

16 pcs

Bolt 5/16"*3"

#14

#12

#11

Washer 5/16"*23mm

32 pcs

40 pcs

Screw F4*1-1/4" Screw F3*12mm

4 pcs

6 pcs

Leg levelerRed and blue puck

each 8 pcs

#18 #17 #16

Leg shelf

Metal cover

1 pc

16 pcs

Nut 5/16"

Wiper

1 pc

#19

8 pcs

#20

#26

1 pc

2 pc

#25

1 pc

#27

4 pcs

36pcs

Screw F4*1-1/2"

2pcs

#28

Cabinet half<01>

Cabinet half<02>

Tenon

Frame panel

Wrench

1 pc

#9

#15

Wrench

1 pc

#13

1 pc

#25

#16

ASSEMBLY INSTRUCTION

#26

#27

#28

#25

#1

#2

#11

Step 1:Assembly of cabinet frame Fix table frame panels (#25, #26,#27,#28,#11) with screw (#10), it has scorer control panel cut out in panels#26 and #27, make sure they are on same side. Then fix table frames on bottom of cabinet halves (#1 and #2) with screw (#16).

. 2.

#10

ASSEMBLY INSTRUCTION

. 3 .

#16

#4

#6

#5

#4

#8

#13

#12

#14

#13

#12

#14

#13

Step 2: Assembly of Legs

1.Insert leg shelf(#6) into slot of leg(#4) and fix with screw(#16).

2. Fix legs on table frame with blot(#12), washer(#13) and nut(#14) . Note: Fix center leg (#5) on one table half with 1 blot(#12), 1 washer (#13) and 1 nut(#14) for each of its leg post only.

3. Screw in leg levelers(#8) on legs.

#23

#3

#21

#22

#20

#1

#2

ASSEMBLY INSTRUCTION

. 4 .

#13

#12

#14

#13

Step 3:Assembly of table.

1. Turn table halves right side up and line them up together with tenon (#20).

NOTE: Do not allow the weight of the table to rest on the side of the legs. Have two person or more to turn the table right side up.

3. Fix center leg to another table half with bolt (#12), washer(#13) and nut (#14).

1. Fix climate adjuster (#23) on bottom of board with screw(#22) and washer(#23) .

Step 4: Assembly of Board

ASSEMBLY INSTRUCTION

. 5 .

#3

3

2

1

3

2

3

1

2

3

#17

#18

Step 5: Fix metal cover (#18) with screw (#17) on center part of cabinet side.

2. Place board onto the cabinet . Note: Lift up the board high enough so that the climate adjusters don't hit the table cabinet.
