Plastic Oddities PRODUCT CATALOG

Friend of the Plumber

PRODUCT CATALOG

This symbol identifies products that have been invented and brought to the market exclusively by

Plastic Oddities, the Original “Friend of the Plumber”

Order by Phone:

Order by fax: [phone]

800-438-5327

www.PlasticOddities.com

291 Shiloh Road, Forest City, NC 28043

Description on page 117

TABLE OF CONTENTS

Flanges ............................................................................................. 5

Shower Drains ............................................................................... 17

Economy Drains ............................................................................ 29

General Purpose Drains ................................................................ 37

Light Commercial Drains .............................................................. 51

Floor Sinks ..................................................................................... 63

Roof Drains .................................................................................... 79

Cleanouts ....................................................................................... 91

Backwater Valves ......................................................................... 103

Saddle Tees ................................................................................... 107

Boxes & Pans ............................................................................... 111

Specialty Products ....................................................................... 115

Replacement Parts ....................................................................... 123

Friend of the Plumber

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

3

Quick Reference Replacement Strainers List .............................. 133

Part Number Index ...................................................................... 135

Products Sales Terms and Conditions ......................................... 144

Shipping Times ............................................................................ 146

Friend of the Plumber

www.plasticoddities.com

4

Order by Phone: [phone] Order by Fax: [phone]

“Friend of the Plumber”

Flanges

F

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

3” x 4” Fit

Offset Closet Flange

x The original 3”x 4” closet flange with up to 2” offset
x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Allows at least a 2” margin of error for rough-in plumbing for a water closet

PART #

PVC ABS SIZE DESCRIPTION

POF100 AOF101 3”x 4” 2” Offset Flange Only

Offset Closet Flange Kit

x The original 3” x 4” closet flange with up to 2” offset
x Kit includes offset flange, No-Wax gasket, and hardware

PART #

PVC ABS SIZE DESCRIPTION

PPK100 APK101 3”x 4” 2” Offset Flange Kit

Flush-Fit Closet Flange

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Mounting slots on four sides of flange to allow precise alignment of water closet
x Pipe may be cut flush with floor
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PFF102
IS UPC LISTED

PFF102 AFF103 3”x 4” Flush-Fit Flange
PFF104 AFF105 3”x 4” Flush-Fit Flange with Test Cap

Flush-Fit Closet Flange Kit

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Kit includes Flush-Fit flange, No-Wax gasket, and hardware

PART #

PVC ABS SIZE DESCRIPTION

PPK102 APK103 3”x 4” Flush-Fit Flange Kit

Flush-Fit Closet Flange with Pop-Top Removable Knockout

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Metal Pop-Top lid is easily removable with no need for tools

See Page 15

for illustration

x Eliminates jagged edges and drain-clogging debris associated with standard plastic knockouts
x Available with adjustable aluminum ring

PART #

PVC ABS SIZE DESCRIPTION

PTP160 ATP161 3”x 4” Flange with Pop-Top
PTP160AR ATP161AR 3”x 4” Flange with Pop-Top and Adjustable Aluminum Ring

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

7

3” x 4” Fit

Adjustable Flush-Fit Closet Flange

x Fits over 3” or inside 4” Schedule 40 DWV pipe

x Radial mounting slots extend 130˚ on each side to allow precise alignment of water closet

x Pipe may be cut flush with floor

x Four countersunk holes for secure attachment to floor

1.90/

2.75

x Long version to accommodate foam core pipe

PART #

PVC ABS SIZE DESCRIPTION

PAF120 AAF121 3”x 4” Flange
PAF122 AAF123 3”x 4” Flange with Test Cap
PAF120L AAF121L 3”x 4” Flange (Long Version)
PAF122L AAF123L 3”x 4” Flange (Long Version) with Test Cap

Closet Flange with Adjustable Aluminum Ring

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Non-corrosive marine grade aluminum ring is 360˚ adjustable
x Also available in brass
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PAR340A AAR341A 3”x 4” Flange with Aluminum Ring

PAR340A
IS UPC LISTED

PAR340AK AAR341AK 3”x 4” Flange with Aluminum Ring and Test Cap
PAR340B AAR341B 3”x 4” Flange with Brass Ring
PAR340BK AAR341BK 3”x 4” Flange with Brass Ring and Test Cap

Closet Flange with Adjustable Threaded Bushing

x Bushing fits over 3” or inside 4” Schedule 40 DWV pipe
x 3.5” IPS flange allows adjustment to desired floor level
x Radial mounting slots extend 130˚ on each side to allow precise alignme nt of

water closet

x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PAB144 AAB145 3”x 4” Adjustable Flange
PAB146 AAB147 3”x 4” Adjustable Flange with Test Cap

8

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Inside Pipe Fit Closet Flange

3” Fit Only

x Fits inside 3” Schedule 40 DWV pipe
x Mounting slots on four sides to allow precise alignment of water closet
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PCF134 ACF135 3” Flange without Test Cap
PCF136 ACF137 3” Flange with Test Cap

Inside Pipe Fit Closet Flange with Adjustable Aluminum Ring

x Fits inside 3” Schedule 40 DWV pipe
x Non-corrosive marine grade aluminum ring is 360˚ adjustable
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PCF134A ACF135A 3” Flange with Aluminum Ring
PCF136A ACF137A 3” Flange with Aluminum Ring and Test Cap

Spigot Closet Flange

x Fits inside 3” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Mounting slots on four sides to allow precise alignment of water closet
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PCF130 ACF131 3” Flange
PCF132 ACF133 3” Flange with Test Cap

Spigot Closet Flange with Adjustable Aluminum Ring

x Fits inside 3” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Non-corrosive marine grade aluminum ring is 360˚ adjustable
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PCF130A ACF131A 3” Flange with Aluminum Ring
PCF132A ACF133A 3” Flange with Aluminum Ring and Test Cap

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

9

4” Fit Only

Flush-Fit Full Flow Closet Flange

x Fits over 4” Schedule 40 DWV pipe
x Pipe may be cut flush with floor
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PFF106 AFF107 4” Full Flow Flange
PFF108 AFF109 4 ” Full Flow Flange with Test Cap

Full Flow Closet Flange With Aluminum Ring

x Fits over 4” Schedule 40 DWV pipe
x Non-corrosive marine grade aluminum ring is 360˚ adjustable
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PFF106A AFF107A 4” Flange with Aluminum Ring
PFF108A AFF109A 4” Flange with Aluminum Ring and Test Cap

Flush-Fit Spigot Closet Flange

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Mounting slots on four sides to allow precise alignment of water closet
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PFF110 AFF111 4” Spigot-style Flange
PFF112 AFF113 4” Spigot-style Flange with Test Cap

Spigot Closet Flange with Aluminum Ring

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Non-corrosive marine grade aluminum ring is 360˚ adjustable
x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PFF110A AFF111A 4” Flange with Aluminum Ring
PFF112A AFF113A 4” Flange with Aluminum Ring and Test Cap

10

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

4” Fit Only

(Continued)

Metric

Urinal Flanges - 2”

Closet Flange with Adjustable Threaded Bushing

x Bushing fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, reducer, etc.)
x 3.5” IPS flange allows adjustment to desired floor level
x Radial mounting slots extend 130˚ on each side of flange to allow precise

alignment of water closet

x Four countersunk holes for secure attachment to floor

PART #

PVC ABS SIZE DESCRIPTION

PAF144 AAF145 4” Adjustable Flange
PAF146 AAF147 4” Adjustable Flange with Test Cap

Metric Flush-Fit Flange with Knockout

x Fits inside 100mm metric pipe
x Mounting slots on four sides
x Pipe may be cut flush with floor

PART #

PVC ABS SIZE DESCRIPTION

PMF100 AMF101 100mm Metric Flange with Test Cap

Over Pipe Fit Adjustable Urinal Flange

x Fits over 2” Schedule 40 DWV pipe
x Horizontal slots accommodate urinals with 4” to 6” flange mount centers
x Kit includes bolts, nuts, washers, and spud gasket

PART #

PVC ABS SIZE DESCRIPTION

PKT112 AKT113 2” Slotted Adjustable Urinal Flange Only

2.50/

2.75/

7.00

1.60

PKT110 AKT111 2” Slotted Adjustable Urinal Flange Kit

Spigot Adjustable Urinal Flange

x Fits inside 2” Schedule 40 DWV hub (elbow, tee, coupling, reducer, etc.)
x Horizontal slots accommodate urinals with 4” to 6” flange mount centers
x Kit includes bolts, nuts, washers, and spud gasket

PART #

PVC ABS SIZE DESCRIPTION

PKT116 AKT117 2” Slotted Adjustable Urinal Flange Only

2.50/

2.75/

7.60

2.10

PKT114 AKT115 2” Slotted Adjustable Urinal Flange Kit

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

11

Urinal Flanges - 2”

(Continued)

Adjustable Threaded Urinal Flange

x Accepts galvanized, cast iron, and plastic 2” pipe threads
x Horizontal slots accommodate urinals with 4” to 6” flange mount centers
x Kit includes bolts, nuts, washers, and spud gasket

PART #

PVC ABS SIZE DESCRIPTION

PTU112 ATU113 2” Threaded Urinal Flange Only
PTU110 ATU111 2” Threaded Urinal Flange Kit

Radially Adjustable Urinal Flange

x Fits over 2” Schedule 40 DWV pipe
x Radial slots allow positive alignment of hanger if error occurs in mounting of flange
x Accommodates 4” or 6” flange mount centers
x Kit includes bolts, nuts, washers, and spud gasket

PART #

PVC ABS SIZE DESCRIPTION

PUR106 AUR107 2” Radially Adjustable Urinal Flange Kit
PUR108 AUR109 2” Radially Adjustable Urinal Flange Only

Cast Threaded Urinal Flange With Slots

x Accepts galvanized, cast iron and plastic 2” pipe threads
x Horizontal slots accommodate urinals with 4” to 6” flange mount centers
x Kit includes bolts, nuts, washers, and spud gasket

PART# SIZE DESCRIPTION

BKT112 2” Threaded Brass Urinal Flange Only
BKT110 2” Threaded Brass Urinal Flange Kit

Cast Threaded Urinal Flange

x Accepts galvanized, cast iron and plastic 2” pipe threads
x Kit includes bolts, nuts, washers, and spud gasket

PART# SIZE DESCRIPTION

BTU112 2” Threaded Bra s s Flange Only
BTU110 2” Threaded Brass Flange Kit

12

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Miscellaneous Flange Products

Closet Flange Spacer Kit

x Builds up existing flange when a new subfloor or tile leaves the flange at or below

floor level

x Includes 2 No-Wax flexible gaskets, 1 slab ring, 2 - 3.5” closet bolts, 2 washers, 2

plastic shims, 2 nuts

PART# SIZE DESCRIPTION

CFSKP 4” With PVC Slab Ring
CFSKA 4” With ABS Slab Ring
CFSKB 4” With Brass Slab Ring

Over Pipe Fit Closet Flange Ring

x Fits over 3” or over 4” Schedule 40 DWV pipe
x Provides a quick flange installation on concrete slabs without chipping concrete or other

advance preparation

PART #

PVC ABS SIZE DESCRIPTION

PSR3 ASR3 3” Closet Flange Ring
PSR4 ASR4 4” Closet Flange Ring

No-Wax Flexible Toilet Seal Gasket

x Replaces conventional wax gaskets
x Completely reusable
x Holes in gasket hold closet bolts in place during installation
x Tapered sealing ring on gasket opening provides a seal around toilet outlet and throat of flange
x Feathered ribs on gasket surface allow weight of toilet and tightening of closet bolt to seal voids

and irregularities on bottom of toilet

PART# DESCRIPTION

BG7 No-Wax Gasket
BG7K No-Wax Gasket (Packaged)

Plastic Wedge Shims

x Provides an economical means to support or level a water closet due to irregularities in

concrete or finished floor

x 1/8” height adjustment
x Can be stacked for greater height adjustment

PART# DESCRIPTION

PWS1 Plastic Wedge Shims (Bag of 120)
PWK1 Plastic Wedge Shims (Bag of 12)
PWS1B Plastic Wedge Shims (Individual)

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

13

Miscellaneous Flange Products

(Continued)

Form-A-Space Foam Collar

x Forms a 1/2” void around pipe in a concrete slab
x Eliminates chipping of concrete when closet flanges, drains, etc. must be installed over the pipe

PART# SIZE DESCRIPTION

FAS3 3” Form-A-Space Collar
FAS4 4” Form-A-Space Collar
FAS34 3” & 4” Form-A-Space Collar Kit

Reusable Universal Flange Cover

x Keeps debris out of drain during remodeling or construction
x Universal size will fit any standard flange

PART# DESCRIPTION

UFC1 Universal Flange Cover

Spud Gasket

Tank Bolt Kit

x Kit includes 1 spud gasket, 2 nuts, 2 bolts and 2 washers

PART# DESCRIPTION

TBK041 Tank Bolt Kit

Closet Bolt Kit

x Kit includes 2 nuts, 2 - 3.5” bolts, 4 wood screws, and 4 washers

PART# DESCRIPTION

CBK042 Closet Bolt Kit

x Made of corrosive resistant flexible PVC
x For toilet tank or urinal installation

PART# DESCRIPTION SIZE

SP41 Flexible PVC Spud Gasket 3.5”

14

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Description on page 7

“Friend of the Plumber”

Shower Drains

S

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

Fiberglass Shower Drain - 1.5”

Fiberglass Shower Drains

x Fits over 1.5” Schedule 40 DWV pipe
x 4.25” diameter strainer available in a variety of finishes and cast metal
x Weep slots molded into receptor base
x Sealing and friction gaskets provide positive seal to shower base

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PFG620 AFG621 1.5” W/ Stamped SS Strainer SP-12
PFG624 AFG625 1.5” W/ Polished Brass Strainer SP-12PB
PFG624SS AFG625SS 1.5” W/ Stamped Polished Gold Strainer SP-12SPB
PFG626 AFG627 1.5” W/ Nickel Strainer SP-12N
PFG628 AFG629 1.5” W/ Antique Brass Strainer SP-12AB
PFG628SS AFG629SS 1.5” W/ Stamped Antique Gold Strainer SP-12SAB

Fiberglass Shower Drain - 2”

x Fits over 2” Schedule 40 DWV pipe
x 4.25” diameter strainer available in a variety of finishes and cast metal
x Weep slots molded into receptor base
x Sealing and friction gaskets provide positive seal to shower base

PART #

PVC ABS SIZE DESCRIPTION STRAINER

BFG600 N/A 2” BLACK PVC W/ Stamped SS strainer SP-12
GFG600 N/A 2” GOLD PVC W/Stamped SS strainer SP-12

GRF600 N/A 2” GREY PVC W/Stamped SS strainer SP-12
PFG600 AFG601 2” W/ Stamped SS Strainer SP-12

BFG600
PFG600 / AFG601
PFG604 / AFG605
PFG606 / AFG607
PFG608 / AFG609
ARE UPC LISTED

PFG604 AFG605 2” W/ Polished Brass Strainer SP-12PB
PFG604SS AFG605SS 2” W/ Stamped Polished Gold Strainer SP-12SPB
PFG606 AFG607 2” W/ Nickel Strainer SP-12N
PFG608 AFG609 2” W/ Antique Brass Strainer SP-12AB
PFG608SS AFG609SS 2” W/ Stamped Antique Gold Strainer SP-12SAB

Quick-Fix Drain Extension

x Quick-Fix fiberglass shower stall drain extension allows cutting drain line

same height every time

PART # SIZE DESCRIPTION

PQF150 1.5”x 2” PVC Drain Extension
PQF200 2” PVC Drain Extension

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

19

Fiberglass Shower Drains

(Continued)

No-Caulk Brass

Offset Fiberglass Shower Stall Drain - 2”

x Fits over 2” Schedule 40 DWV pipe
x 4.25” diameter strainer available in a variety of finishes and cast metal
x Weep slots molded in barrel
x Sealing and friction gaskets provide positive seal to shower base
x Allows margin of error for rough-in plumbing for a shower stall

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PFG610 AFG611 2” W/ Stamped SS Strainer SP-12
PFG614 AFG615 2” W/ Polished Brass Strainer SP-12PB
PFG614SS AFG615SS 2” W/ Stamped Polished Gold Strainer SP-12SPB

PFG616 AFG617 2” W/ Nickel Strainer SP-12N
PFG618 AFG619 2” W/ Antique Brass Strainer SP-12AB
PFG618SS AFG619SS 2” W/ Stamped Antique Gold Strainer SP-12SAB

No-Caulk Fiberglass Shower Stall Drain

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4.25” diameter strainer available in a variety of finishes and cast metal
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain and 2 ” pipe
x Weep slots molded in the receptor base
x Sealing and friction gaskets provide positive seal to shower base
x No tools or solvent required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC650 NC651 2” W/ Stamped SS Strainer SP-12
NC654 NC655 2” W/ Polished Brass Strainer SP-12PB
NC654SS NC655SS 2” W/ Stamped Polished Gold Strainer SP-12SPB
NC656 NC657 2” W/ Nickel Strainer SP-12N
NC658 NC659 2” W/ Antique Brass Strainer SP-12AB
NC658SS NC659SS 2” W/ Stamped Antique Gold Strainer SP-12SAB

No-Caulk Brass Shower Drain

x Snap-In stainless steel strainer
x Drain body installs from top side of shower while locknut threads into body from base using

friction rings

x Compression gasket tightens around 2” Schedule 40 DWV pipe with inner nut and wrench
x Cast brass body

PART # SIZE DESCRIPTION

BNC650 2” W/ Stamped SS Strainer

20

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

(Check for Availability)

Fiberglass Shower Drains

(Continued)

2” - No Caulk Low Profile

No-Caulk Low Profile Fiberglass Shower Drain

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4.25” diameter strainer available in a variety of finishes and cast metal
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain and 2” pipe
x Weep slots molded in the receptor base
x Sealing and friction gaskets for positive seal to shower base
x No tools or solvent required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC600 NC601 2” W/ Stamped SS Strainer SP-12
NC604 NC605 2” W/ Polished Brass Strainer SP-12PB
NC604SS NC605SS 2” W/ Stamped Polished Gold Strainer SP-12SPB
NC606 NC607 2” W/ Nickel Strainer SP-12N
NC608 NC609 2” W/ Antique Brass Strainer SP-12AB
NC608SS NC609SS 2” W/ Stamped Antique Gold Strainer SP-12SAB

No-Caulk Low Profile Bolt-Down Drain

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain a nd 2” pipe
x 2” IPS plastic strainer barrel allows adjustment to desired finished level
x No tools or solvent required
x Key-hole slots in clamping collar allo w clamping of membrane without removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC406 NC407 2” W/ Stamped SS Strainer SP-1
NC408 NC409 2” W/ Nickel Strainer SP-2N
NC420 NC421 2” W/ Polished Brass Strainer SP-2PB
NC420SS NC421SS 2” W/ Stamped Polished Gold Strainer SP-1SPB
NC424 NC425 2” W/ Antique Brass Strainer SP-1AB
NC424SS NC425SS 2” W/ Stamped Antique Brass Strainer SP-1SAB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

21

2” - No Caulk Low Profile

(Continued)

No-Caulk Low Profile Bolt-Down Drain with Metaring

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4” diameter cast metal strainer available in a variety of finishes with round or square metaring
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain and 2 ” pipe
x 2” IPS plastic strainer barrel allows adjustment to desired finished level
x No tools or solvent required
x Key-hole slots in clamping collar allow clamping of membrane withou t removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC408R NC409R 2” Round Ring w/ Nickel Strainer SP-2N
NC408RS NC409RS 2” Square Ring w/ Nickel Strainer SP-2N
NC420R NC421R 2” Round Ring w/ Polished Brass Stra iner SP-2PB
NC420RS NC421RS 2” Square Ring w/ Polished Brass Strainer SP-2PB
NC424R NC425R 2” Round Ring w/ Antique Brass Strainer SP-2AB
NC424RS NC425RS 2” Square Ring w/ Antique Brass Strainer SP-2AB

No-Caulk Low Profile Bolt-Down Drain with Metal Tailpiece

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4” diameter cast metal strainer available in a variety of finishes
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain a nd 2” pipe
x 2” IPS cast metal strainer barrel allows adjustment to desired finished level
x No tools or solvent required
x Key-hole slots in clamping collar allow clamping of membrane withou t removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC410 NC411 2” W/ 4” Stamped SS Strainer, Nickel Tailpiece SP-1
NC410PB NC411PB 2” W/ 4” Stamped SS Strainer, Brass Tailpiece SP-1
NC412 NC413 2” W/ 4” Nickel Strainer & Tailpiece SP-2N
NC412PB NC413PB 2” W/ 4” Polished Brass Strainer & Tailpiece SP-2N
NC414 NC415 2” W/ 5” Nickel Strainer & Tailpiece SP-2PB
NC414PB NC415PB 2” W/ 5” Polished Brass Strainer & Tailpiece SP-2PB
NC416 NC417 2” W/ 6” Nickel Strainer & Tailpiece SP-2AB
NC416PB NC417PB 2” W/ 6” Polished Brass Strainer & Tailpiece SP-2AB

22

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

2” x 3” Low Profile

Low Profile Bolt-Down Shower Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR406 ABR407 2”x 3” W/ Stamped SS Strainer SP-1
PBR408 ABR409 2”x 3” W/ Nickel Strainer SP-2N

PBR406 / ABR407
PBR408 / ABR409
PBR420 / ABR421
PBR424 / ABR425
PBR420SS
ARE UPC LISTED

PBR420 ABR421 2”x 3” W/ Polished Brass Strainer SP-2PB
PBR420SS ABR421SS 2”x 3” W/ Stamped Polished Gold Strainer SP-1SPB
PBR424 ABR425 2”x 3” W/ Antique Brass Strainer SP-2AB
PBR424SS ABR425SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB

Low Profile Bolt-Down Shower Drain with Metaring

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter cast metal strainer available in a variety of finishes with round or square metaring
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allows clamping of membrane without removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR408R ABR409R 2”x 3” Round Ring w/ Nickel Strainer SP-2N
PBR408RS ABR409RS 2”x 3” Square Ring w/ Nickel Strainer SP-2N
PBR420R ABR421R 2”x 3” Round Ring w/ Polished Brass Strainer SP-2PB
PBR420RS ABR421RS 2”x 3” Square Ring w/ Polished Brass Strainer SP-2PB
PBR424R ABR425R 2”x 3” Round Ring w/ Antique Brass Strainer SP-2AB
PBR424RS ABR425RS 2”x 3” Square Ring w/ Antique Brass Strainer SP-2AB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

23

2” x 3” Low Profile

(Continued)

2” x 3” Ultra Low Profile

Low Profile Bolt-Down Shower Drain with Metal Tailpiece

x Fits over 2” or inside 3” Schedule 40 DWV pipe

x 4” diameter cast metal strainer available in a variety of finishes

x 2” IPS cast metal strainer barrel allows adjustment to desired finish level

x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts

x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR410 ABR411 2”x 3” W/ 4” Stamped SS Strainer, Nickel Tailpiece SP-1
PBR410PB ABR411PB 2”x 3” W/ 4” Stamped SS strainer, Brass Tailpiece SP-1

PBR410 / ABR411
PBR412 / ABR413
ARE UPC LISTED

PBR412 ABR413 2”x 3” W/ 4” Nickel Strainer & Tailpiece SP-2N
PBR412PB ABR413PB 2”x 3” W/ 4” Polished Brass Strainer & Tailpiece SP-2PB
PBR414 ABR415 2”x 3” W/ 5” Nickel Strainer & Tailpiece SP-4N
PBR414PB ABR415PB 2”x 3” W/ 5” Polished Brass Strainer & Tailpiece SP-4PB
PBR416 ABR417 2”x 3” W/ 6” Nickel Strainer & Tailpiece SP-8N
PBR416PB ABR417PB 2”x 3” W/ 6” Polished Brass Strainer & Tailpiece SP-8PB

Ultra Low Profile Bolt-Down Shower Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Total drain height 3”
x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PLP406 ALP407 2”x 3” W/ Stamped SS Strainer SP-1
PLP408 ALP409 2”x 3” W/ Nickel Strainer SP-2N
PLP420 ALP421 2”x 3” W/ Polished Brass Strainer SP-2PB
PLP420SS ALP421SS 2”x 3” W/ Stamped Polished Gold Strainer SP-1SPB
PLP424 ALP425 2”x 3” W/ Antique Brass Strainer SP-2AB
PLP424SS ALP425SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB

24

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

2” x 3” Ultra Low Profile

(Continued)

Ultra Low Profile Bolt-Down Shower Drain with Metaring

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter cast metal strainer available in a variety of finishes with round or square metaring
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Total drain height 3”
x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PLP408R ALP409R 2”x 3” Round Ring w/ Nickel Strainer SP-2N
PLP408RS ALP409RS 2”x 3” Square Ring w/ Nickel Strainer SP-2N
PLP420R ALP421R 2”x 3” Round Ring w/ Polished Brass Strainer SP-2PB
PLP420RS ALP421RS 2”x 3” Square Ring w/ Polished Brass Strainer SP-2PB
PLP424R ALP425R 2”x 3” Round Ring w/ Antique Brass Strainer SP-2AB
PLP424RS ALP425RS 2”x 3” Square Ring w/ Antique Brass Strainer SP-2AB

Ultra Low Profile Bolt-Down Shower Drain with Metal Tailpiece

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter cast metal strainer available in a variety of finishes
x 2” IPS cast metal strainer barrel allows adjustment to desired finish level
x Total drain height 3”
x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PLP410 ALP411 2”x 3” W/ 4” Stamped SS Strainer, Nickel Tailpiece S P-1
PLP410PB ALP411PB 2”x 3” W/ 4” Stamped SS Strainer, Brass Tailpiece SP-1SPB
PLP412 ALP413 2”x 3” W/ 4” Nickel Strainer & Tailpiece SP-2N
PLP412PB ALP413PB 2”x 3” W/ 4” Polished Brass Strainer & Tailpiece SP-2PB
PLP414 ALP415 2”x 3” W/ 5” Nickel Strainer & Tailpiece SP-4N
PLP414PB ALP415PB 2”x 3” W/ 5” Polished Brass Strainer & Tailpiece SP-4PB
PLP416 ALP417 2”x 3” W/ 6” Nickel Strainer & Tailpiece SP-8N
PLP416PB ALP417PB 2”x 3” W/ 6” Polished Brass Strainer & Tailpiece SP-8PB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

25

2” x 3” Normal Profile

Bolt-Down Shower/Floor Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allow clamping of membrane without removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR400 ABR401 2”x 3” W/ Stamped SS Strainer SP-1
PBR402 ABR403 2”x 3” W/ Nickel Strainer SP-2N

PBR400 / ABR401
ARE UPC LISTED

PBR490 ABR491 2”x 3” W/ Polished Brass Strainer SP-2PB
PBR490SS ABR491SS 2”x 3” W/ Stamped Polished Gold Strainer SP-1SPB
PBR494 ABR495 2”x 3” W/Antique Brass Strainer SP-2AB
PBR494SS ABR495SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB

Bolt-Down Shower/Floor Drain with Metaring

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter cast metal strainer available in a variety of finishes with round or square metaring
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allow clamping of membrane withou t removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR402R ABR403R 2”x 3” Round Ring w/Nickel Strainer SP-2N
PBR402RS ABR403RS 2”x 3” Square Ring w/ Nickel Strainer SP-2N
PBR490R ABR491R 2”x 3” Round Ring w/ Polished Brass Strainer SP-2PB
PBR490RS ABR491RS 2”x 3” Square Ring w/ Polished Brass Strainer SP-2PB
PBR494R ABR495R 2”x 3” Round Ring w/ Antique Brass Strainer SP-2AB
PBR494RS ABR495RS 2”x 3” Square Ring w/ Antique Brass Strainer SP-2AB

Aluminum 2” IPS Extension For PBR/PLP Series Shower Drains

x Extends the drain 2” to 3” to eliminate tear-outs

PART # SIZE DESCRIPTION

SPX406A 2” IPS Extension

26

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

2” x 3” Normal Profile

(Continued)

Threaded Ring Shower/Floor Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Threaded hex head clamping collar eliminates the need for bolts
x Threaded barrel and collar allow for height adjustment

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PTR200 ATR201 2”x 3” W/ Stamped SS Strainer SP-1
PTR202 ATR203 2”x 3” W/ Nickel Strainer SP-2N
PTR204 ATR205 2”x 3” W/ Polished Brass Strainer SP-2PB
PTR204SS ATR205SS 2”x 3” W/ Stamped Polished gold Strainer SP-1SPB
PTR208 ATR209 2”x 3” W/ Antique Brass Strainer SP-2AB
PTR208SS ATR209SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB

Threaded Ring Shower/Floor Drain with Metaring

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter cast metal strainer available in a variety of finishes with round or square metaring
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Threaded hex head clamping collar eliminates the need for bolts
x Threaded barrel and collar allow for height adjustment

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PTR202R ATR203R 2”x 3” Round Ring With Nickel Strainer SP-2N
PTR202RS ATR203RS 2”x 3” Square Ring With Nickel Strainer SP-2N
PTR204R ATR205R 2”x 3” Round Ring With Polished Brass Strainer SP-2PB
PTR204RS ATR205RS 2”x 3” Square Ring With Polished Brass Strainer SP-2PB
PTR208R ATR209R 2”x 3” Round Ring With Antique Brass Strainer SP-2AB
PTR208RS ATR209RS 2”x 3” Square Ring With Antique Brass Strainer SP-2AB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

27

“Friend of the Plumber”

Economy Drains

E

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

Fiberglass Shower Drains

Fiberglass Shower Drain - 1.5”

x Fits over 1.5” Schedule 40 DWV pipe
x 4.25” diameter plastic strainer available in a variety of colors
x Weep slots molded into receptor base
x Sealing and friction gaskets provide positive seal to shower base

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PFG620P AFG621P 1.5” W/ Bone-colored PVC Strainer SP-12P
PFG624P AFG625P 1.5” W/ Gold-colored PVC Strainer SP-12PG
PFG626P AFG627P 1.5” W/ Nickel-colored PVC Strainer SP-12PN

Fiberglass Shower Drain - 2”

x Fits over 2” Schedule 40 DWV pipe
x 4.25” diameter plastic strainer available in a variety of colors
x Weep slots molded into receptor base
x Sealing and friction gaskets provide positive seal to shower base

PART #

PVC ABS SIZE DESCRIPTION STRAINER

BFG600P N/A 2” BLACK PVC w/Bone-colored PVC Strainer SP-12P
BFG604P N/A 2” BLACK PVC w/Gold-colored PVC Strainer SP-12PG
BFG606P N/A 2” BLACK PVC w/Nickel-colored PVC Strainer SP-12PN
PFG600P AFG601P 2” W/ Bone-colored PVC Strainer SP-12P
PFG604P AFG605P 2” W/ Gold-colored PVC Strainer SP-12PG
PFG606P AFG607P 2” W/ Nickel-colored PVC Strainer SP-12PN

Offset Fiberglass Shower Stall Drain - 2”

x Fits over 2” Schedule 40 DWV pipe
x 4.25” diameter plastic strainer available in a variety of colors
x Weep slots molded in barrel
x Sealing and friction gaskets provide positive seal to shower base
x Allows margin of error for rough-in plumbing for a shower stall

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PFG610P AFG611P 2” W/ Bone-colored PVC Strainer SP-12P
PFG614P AFG615P 2” W/ Gold-colored PVC Strainer SP-12PG
PFG616P AFG617P 2” W/ Nickel-colored PVC Strainer SP-12PN

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

31

Fiberglass Shower Drains

(Continued)

Shower Drains

No-Caulk Fiberglass Shower Stall Drain

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4.25” diameter plastic strainer available in a variety of colors
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain and 2” pipe
x Weep slots molded in the receptor base
x Sealing and friction gaskets provide positive seal to shower base
x No tools or solvent required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC650P NC651P 2” W/ Bone-colored PVC Strainer SP-12P
NC654P NC655P 2” W/ Gold-colored PVC Strainer SP-12PG
NC656P NC657P 2” W/ Nickel-colored PVC Strainer SP-12PN

No-Caulk Low Profile Bolt-Down Drain

x Fits over 2” Schedule 40 DWV PVC, ABS, and cast iron pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x Exclusive “one-way” design of gasket provides a guaranteed seal between drain and 2 ” pipe
x 2” IPS plastic strainer barrel allows adjustment to desired finished level
x No tools or solvent required
x Key-hole slots in clamping collar allow clamping of membrane withou t removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

NC406P NC407P 2” W/ Bone-colored PVC Strainer SP-1P
NC408P NC409P 2” W/ Nickel-colored PVC Strainer SP-1PN
NC420P NC421P 2” W/ Gold-colored PVC Strainer SP-1PG

Low Profile Bolt-Down Shower Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allows clamping of membrane without removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR406P ABR407P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PBR408P ABR409P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PBR420P ABR421P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

32

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Shower Drains

(Continued)

Ultra Low Profile Bolt-Down Shower Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x 2” IPS plastic strainer barrel allows adjustment to desired finish level
x Total drain height 3”
x Key-hole slots in clamping collar allows clamping of membrane wit ho ut removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PLP406P ALP407P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PLP408P ALP409P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PLP420P ALP421P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

Bolt-Down Shower/Floor Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Key-hole slots in clamping collar allow clamping of membrane without removing bolts
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBR400P ABR401P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PBR402P ABR403P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PBR490P ABR491P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

Threaded Ring Shower/Floor Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x 3” IPS plastic strainer barrel allows adjustment to desired finish level
x Threaded hex head clamping collar eliminates the need for bolts
x Threaded barrel and collar allow for height adjustment

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PTR200P ATR201P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PTR202P ATR203P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PTR204P ATR205P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

33

General Purpose Drains

2” x 3” Pipe Fit General Purpose Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer
x Available in regular and short version

2.06/

1.19

PGP300P AGP301P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PGP302P AGP303P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PGP390P AGP391P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

PGP300SP AGP301SP 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PGP302SP AGP303SP 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PGP390SP AGP391SP 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

PART #

PVC ABS SIZE DESCRIPTION

SHORT VERSION

STRAINER

4” Over Pipe Fit General Purpose Drain

x Fits over 4” Schedule 40 DWV pipe
x 6” diameter plastic strainer available in a variety of colors
x For general purposes drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGP510 AGP511 4” W/ Gold-colored PVC Sundial Strainer SP-8PGOLD
PGP512 AGP513 4” W/ Gray-colored PVC Sundial Strainer SP-8PGRAY

2” Over Pipe Fit Adjustable General Purpose Drain

x Fits over 2” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA708P AGA709P 2” W/ Bone-colored PVC Strainer SP-1P
PGA710P AGA711P 2” W/ Nickel-colored PVC Strainer SP-1PN
PGA712P AGA713P 2” W/ Gold-colored PVC Strainer SP-1PG

34

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

General Purpose Drains

(Continued)

2” x 3” Pipe Fit Adjustable General Purpose Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA230P AGA231P 2”x 3” W/ Bone-colored PVC Strainer SP-1P
PGA232P AGA233P 2”x 3” W/ Nickel-colored PVC Strainer SP-1PN
PGA242P AGA243P 2”x 3” W/ Gold-colored PVC Strainer SP-1PG

3” x 4” Pipe Fit Adjustable General Purpose Drain

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x 6” diameter plastic strainer available in a variety of colors to match strainer barrel
x 3.5” IPS plastic strainer barrel allows adjustment to desired finished level
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PAB736 AAB737 3”x 4” W/ Gold-colored PVC Sundial Strainer SP-8PGOLD
PAB738 AAB739 3”x 4” W/ Gray-colored PVC Sundial Strainer SP-8PGRAY

4” Inside Hub Fit Adjustable General Purpose Drain

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x 6” diameter plastic strainer available in a variety of colors to match strainer barrel
x 3.5” IPS plastic strainer barrel allows adjustment to desired finished level
x For general purpose drainage requirements where clamping of a waterproofing membrane

4.75”/

5.50”

is not required

x Threaded metal inserts for attaching strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA736 AGA737 4” W/ Gold-colored PVC Sundial Strainer SP-8PGOLD
PGA738 AGA739 4” W/ Gray-colored PVC Sundial Strainer SP-8PGRAY

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

35

General Purpose Drains

(Continued)

3” Inside Pipe Fit Adjustable General Purpose Drain

x Bushing fits inside 3” Schedule 40 DWV pipe
x 4” diameter plastic strainer available in a variety of colors to match strainer barrel
x 2” IPS plastic strainer barrel allows adjustment to desired finished level
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PSI280P ASI281P 3” W/ Bone-colored PVC Strainer SP-1P
PSI282P ASI283P 3” W/ Nickel-colored PVC Strainer SP-1PN
PSI284P ASI285P 3” W/ Gold-colored PVC Strainer SP-1PG

36

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

“Friend of the Plumber”

General Purpose Drains

G

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

Non - Adjustable

2” x 3” Pipe Fit General Purpose Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer
x Available in regular and short version

2.06/

1.19

PGP300 AGP301 2”x 3” W/ Stamped SS Strainer SP-1
PGP302 AGP303 2”x 3” W/ Nickel Strainer SP-2N
PGP302R AGP303R 2”x 3” Round Ring W/ Nickel Strainer SP-2N
PGP302RS AGP303RS 2”x 3” Square Ring W/ Nickel Strainer SP-2N
PGP390 AGP391 2”x 3” W/ Polished Brass Strainer SP-2PB
PGP390R AGP391R 2”x 3” Round Ring W/ Polished Brass Strainer SP-2PB
PGP390RS AGP391RS 2”x 3” Square Ring W/ Polished Brass Strainer SP-2PB
PGP390SS AGP391SS 2”x 3” W/ Stamped Polished Gold Strainer SP-1SPB
PGP394 AGP395 2”x 3” W/ Antique Brass Strainer SP-2AB
PGP394R AGP395R 2”x 3” Round Ring W/ Antique Brass Strainer SP-1SAB
PGP394RS AGP395RS 2”x 3” Square Ring W/ Antique Brass Strainer SP-1SAB
PGP394SS AGP395SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB

PGP300S AGP301S 2”x 3” W/ Stamped SS Strainer SP-1
PGP302S AGP303S 2”x 3” W/ Nickel Strainer SP-2N
PGP302SR AGP303SR 2”x 3” Round Ring W/ Nickel Strainer SP-2N

PGP302SRS AGP303SRS 2”x 3” Square Ring W/ Nickel Strainer SP-2N
PGP390S AGP391S 2”x 3” W/ Polished Brass Strainer SP-2PB
PGP390SR AGP391SR 2”x 3” Round Ring W/ Polished Brass Strainer SP-2PB
PGP390SRS AGP391SRS 2”x 3” Square Ring W/ Polished Brass Strainer SP-2PB
PGP390SSS AGP391SSS 2”x 3” W/ Stamped Polished Gold Strainer SP-1SPB
PGP394S AGP395S 2”x 3” W/ Antique Brass Strainer SP-2AB
PGP394SR AGP395SR 2”x 3” Round Ring W/ Antique Brass Strainer SP-2AB
PGP394SRS AGP395SRS 2”x 3” Square Ring W/ Antique Brass Strainer SP-2AB
PGP394SSS AGP395SSS 2”x 3” W/ Stamped Antique Gold Stra iner SP-1SAB

PART #

PVC ABS SIZE DESCRIPTION

SHORT VERSION

STRAINER

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

39

Non - Adjustable

(Continued)

3” x 4” Pipe Fit General Purpose Drain

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x 5” diameter strainer available in a variety of finishes and cast metal
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGP500 AGP501 3”x 4” W/ Nickel Strainer SP4N
PGP500R AGP501R 3”x 4” Round Ring w/ Nickel Strainer SP4N
PGP500RS AGP501RS 3”x 4” Square Ring w/ Nickel Strainer SP4N
PGP502 AGP503 3”x 4” W/ Stamped SS Strainer SP3
PGP590 AGP591 3”x 4” W/ Polished Brass Strainer SP4PB
PGP590R AGP591R 3”x 4” Round Ring w/ Polished Brass Strainer SP4PB
PGP590RS AGP591RS 3”x 4” Square Ring w/ Polished Brass Strainer SP4PB
PGP594 AGP595 3”x 4” W/ Antique Brass Strainer SP4AB
PGP594R AGP595R 3”x 4” Round Ring w/ Antique Brass Strainer SP4AB
PGP594RS AGP595RS 3”x 4” Square Ring w/ Antique Brass Strainer SP4AB
PGP520 AGP521 3”x 4” W/ Nickel Sundial Strainer SP6N
PGP520R AGP521R 3”x 4” Round Ring w/ Nickel Sundial Strainer SP6N
PGP520RS AGP521RS 3”x 4” Square Ring w/ Nickel Sundial Strainer SP6N

4” Over Pipe Fit General Purpose Drain

x Fits over 4” Schedule 40 DWV pipe
x 6” diameter strainer available in a variety of finishes and cast metal
x For general purposes drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGP508 AGP509 4” W/ Nickel Strainer SP8N
PGP508R AGP509R 4” Rou nd Ri ng w/ Nickel Strainer SP8N
PGP508RS AGP509RS 4” Square Ring w/ Nickel Strainer SP8N
PGP510 AGP511 4” W/ Gold Plastic Strainer SP8P
PGP510R AGP511R 4” Rou nd Ri ng w/ Gold Plastic Strainer SP8P
PGP510RS AGP511RS 4” Square Ring w/ Gold Plastic Strainer SP8P
PGP690 AGP691 4” W/ Polished Brass Strainer SP8PB
PGP690R AGP691R 4” Rou nd Ri ng w/ Polished Brass Strainer SP8PB
PGP690RS AGP691RS 4” Square Ring w/ Polished Brass Strainer SP8PB
PGP694 AGP695 4” W/ Antique Brass Strainer SP8AB
PGP694R AGP695R 4” Rou nd Ri ng w/ Antique Brass Strainer SP8AB
PGP694RS AGP695RS 4” Square Ring w/ Antique Brass Strainer SP8AB

40

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Adjustable - 2”

2” Over Pipe Fit Adjustable General Purpose Drain

x Fits over 2” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA708 AGA709 2” W/ Stamped SS Strainer SP-1
PGA710 AGA711 2” W/ Nickel Strainer SP-2N
PGA710R AGA711R 2” Round Ring w/ Nickel Strainer SP-2N
PGA710RS AGA711RS 2” Square Ring w/ Nickel Strainer SP-2N
PGA712 AGA713 2” W/ Polished Brass Strainer SP-2PB
PGA712R AGA713R 2” Round Ring w/ Polished Brass Strainer SP-2PB
PGA712RS AGA713RS 2” Square Ring w/ Polished Brass Strainer SP-2PB
PGA714SS AGA715SS 2” W/ Stamped Polished Gold Strainer SP-1SPB
PGA716 AGA717 2” W/ Antique Brass Strainer SP-2AB
PGA716R AGA717R 2” Round Ring w/ Antique Brass Strainer SP-2AB
PGA716RS AGA717RS 2” Square Ring w/ Antique Brass Strainer SP-2AB
PGA718SS AGA719SS 2” W/ Stamped Antique Gold Strainer SP-1SAB

2” x 3” Pipe Fit Adjustable General Purpose Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x 4” diameter strainer plate available in a variety of finishes and cast metal
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA230 AGA231 2”x 3” W/ Stamped SS Strainer SP-1
PGA232 AGA233 2”x 3” W/ Nickel Strainer SP-2N
PGA232R AGA233R 2”x 3” Round Ring w/ Nickel Strainer SP-2N
PGA232RS AGA233RS 2”x 3” Square Ring w/ Nickel Strainer SP-2N
PGA242 AGA243 2”x 3” W/ Polished Brass Strainer SP-2PB
PGA242R AGA243R 2”x 3” Round Ring w/ Polished Brass Strainer SP-2PB
PGA242RS AGA243RS 2”x 3” Square Ring w/ Polished Brass Strainer SP-2PB
PGA242SS AGA243SS 2”x 3” W/ Polished Gold Strainer SP-1SPB
PGA246 AGA247 2”x 3” W/ Antique Brass Strainer SP-2AB
PGA246R AGA247R 2”x 3” Round Ring w/ Antique Brass Strainer SP-2AB
PGA246RS AGA247RS 2”x 3” Square Ring w/ Antique Brass Strainer SP-2AB
PGA246SS AGA247SS 2”x 3” W/ Stamped Antique Gold Strainer SP-1SAB
PGA250B AGA251B 2”x 3” W/ Polished Brass Strainer SP-2PB
PGA250N AGA251N 2”x 3” W/ Nickel Strainer SP-2N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

41

Adjustable - 3” x 4”

3” x 4” Pipe Fit Adjustable General Purpose Drain

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x 5” and 6” diameter strainer available in a variety of finishes and cast metal
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

WITH 5” STRAINER

PAB720 AAB721 3”x 4” W/ Stamped SS Strainer SP-3
PAB722 AAB723 3”x 4” W/ Nickel Strainer SP-4N
PAB722R AAB723R 3”x 4” Round Ring w/ Nickel Strainer SP-4N
PAB722RS AAB723RS 3”x 4” Square Ring w/ Nickel Strainer SP-4N
PAB760 AAB761 3”x 4” W/ Polished Brass Strainer SP-4PB
PAB760R AAB761R 3”x 4” Round Ring w/ Polished Brass Strainer SP-4PB
PAB760RS AAB761RS 3”x 4” Square Ring w/ Polished Brass Strainer SP-4PB
PAB764 AAB765 3”x 4” W/ Antique Brass Strainer SP-4AB
PAB764R AAB765R 3”x 4” Round Ring w/ Antique Brass Strainer SP-4AB
PAB764RS AAB765RS 3”x 4” Square Ring w/ Antique Brass Strainer SP-4AB

WITH 6” STRAINER

PAB736 AAB737 3”x 4” W/ Plastic Sundial Strainer SP-8PGOLD
PAB740 AAB741 3”x 4” W/ Nickel Strainer SP-8N
PAB740R AAB741R 3”x 4” Round Ring w/ Nickel Strainer SP-8N
PAB740RS AAB741R 3”x 4” Square Ring w/ Nickel Strainer SP-8N
PAB742 AAB743 3”x 4” W/ Polished Brass Strainer SP-8PB
PAB742R AAB743R 3”x 4” Round Ring w/ Polished Brass Strainer SP-8PB
PAB742RS AAB743RS 3”x 4” Square Ring w/ Polished Brass Strainer SP-8PB
PAB746 AAB747 3”x 4” W/ Antique Brass Strainer SP-8AB
PAB746R AAB747R 3”x 4” Round Ring w/ Antique Brass Strainer SP-8AB
PAB746RS AAB747RS 3”x 4” Square Ring w/ Antique Brass Strainer SP-8AB

42

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Adjustable - 3” x 4”

(Continued)

Adjustable - 4”

3” x 4” Pipe Fit Adjustable General Purpose Drain with Cast Metal Tailpiece

4” Over Pipe Fit Adjustable General Purpose Drain with Cast Metal Tailpiece

5.00/ 6.00/ 8.00/ 10.00

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x Cast metal strainer available in a variety of sizes and finishes
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PAB750 AAB751 3”x 4” W/ 5” Nickel Strainer, Tailpiece SP-4N
PAB750PB AAB751PB 3”x 4” W/ 5” Polished Brass Strainer, Tailpiece SP-4PB
PAB752 AAB753 3”x 4” W/ 6” Nickel Strainer, Tailpiece SP-8N
PAB752PB AAB753PB 3”x 4” W/ 6” Polished Brass Strainer, Tailpiece SP-8PB
PAB754 AAB755 3”x 4” W/ 8” Nickel Strainer, Tailpiece S P-10N
PAB754PB AAB755PB 3”x 4” W/ 8” Polished Brass Strainer, Tailpiece SP-10PB
PAB756 AAB757 3”x 4” W/ 10” Nickel Strainer, Tailpiece SP-11N
PAB756PB AAB757PB 3”x 4” W/ 10” Polished Brass Strainer, Tailpiece SP-11PB

x Bushing fits over 4” Schedule 40 DWV pipe
x 6” diameter cast metal strainer also available with 7” square metaring
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA400B AGA401B 4” W/ Polished Brass Strainer SP-8PB
PGA400BRS AGA401BRS 4” W/ Polished Brass Strainer, Square Metaring SP-8PB
PGA400N AGA401N 4” W/ Nickel Strainer SP-8N
PGA400NRS AGA401NRS 4” W/ Nickel Strainer, Square Metaring SP-8N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

43

Adjustable - 4”

(Continued)

4” Inside Hub Fit Adjustable General Purpose Drain

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x 5” and 6” diameter strainer available in a variety of finishes and cast metal
x 3.5” IPS plastic strainer barrel allows adjustment to desired finished level
x For general purpose drainage requirements where a clamping of a waterproofing membrane

is not required

4.75”/

5.50”

x Threaded metal inserts for attaching strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

WITH 5” STRAINER

PGA720 AGA721 4” W/Stamped SS Strainer SP-3
PGA722 AGA723 4” W/Nickel Strainer SP-4
PGA722R AGA723R 4” Round Ring w/ Nickel Strainer SP-4
PGA722RS AGA723RS 4” Square Ring w/ Nickel Strainer SP-4
PGA760 AGA761 4” W/Polished Brass Strainer SP-4PB
PGA760R AGA761R 4” Round Ring w/ Polished Brass Strainer SP-4PB
PGA760RS AGA761RS 4” Square Ring w/ Polished Brass Strainer SP-4PB
PGA764 AGA765 4” W/Antique Brass Strainer SP-4AB
PGA764R AGA765R 4” Round Ring w/ Antique Brass Strainer SP-4AB
PGA764RS AGA765RS 4” Square Ring w/ Antique Brass Strainer SP-4AB
PGA726 AGA727 4” W/Nickel Sundial Strainer SP-6N

WITH 6” STRAINER

PGA736 AGA737 4” W/ Gold Sundial Strainer SP-8PGOLD
PGA740 AGA741 4” W/ Nickel Strainer SP-8N
PGA740R AGA741R 4” Round Ring w/ Nickel Strainer SP-8N
PGA740RS AGA741RS 4” Square Ring w/ Nickel Strainer SP-8N
PGA742 AGA743 4” W/ Polished Brass Strainer SP-8PB
PGA742R AGA743R 4” Round Ring w/ Polished Brass Strainer SP-8PB

PGA742RS AGA743RS 4” Square Ring w/ Polished Brass Strainer SP-8PB
PGA746 AGA747 4” W/ Antique Brass Strainer SP-8AB
PGA746R AGA747R 4” Round Ring w/ Antique Brass Strainer SP-8AB
PGA746RS AGA747RS 4” Square Ring w/ Antique Brass Strainer SP-8AB

44

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Adjustable - 4”

(Continued)

Adjustable - 6”

Utility Drains

4” Inside Hub Fit Adjustable General Purpose Drain with Cast Metal Tailpiece

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Cast metal strainer available in a variety of sizes and finishes
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA750 AGA751 4” W/ 5” Nickel Strainer, Tailpiece SP-4N
PGA750PB AGA751PB 4” W/ 5” Polished Brass Strainer, Tailpiece SP-4PB
PGA752 AGA753 4” W/ 6” Nickel Strainer, Tailpiece SP-8N
PGA752PB AGA753PB 4” W/ 6” Polished Brass Strainer, Tailpiece SP-8PB
PGA754 AGA755 4” W/ 8” Nickel Strainer, Tailpiece SP-10N
PGA754PB AGA755PB 4” W/ 8” Polished Brass Strainer, Tailpiece SP-10PB
PGA756 AGA757 4” W/ 10” Nickel Strainer, Tailpiece SP-11N
PGA756PB AGA757PB 4” W/ 10” Polished Brass Strainer, Tailpiece SP-11PB

6” Over Pipe Fit Adjustable General Purpose Drain with Cast Metal Tailpiece

x Bushing fits over 6” Schedule 40 DWV pipe
x 10” cast metal strainer
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PGA60100B AGA60101B 6” W/ Brass Strainer, Tailpiece SP-11B
PGA60100N AGA60101N 6” W/ Nickel Strainer, Tailpiece SP-11N

General Purpose Utility/Pool Deck Drain

x Fits over 2” or inside 3” schedule 40 DWV pipe
x Threaded strainer screws down flush with body
x All plastic drain has no metal parts to rust or corrode
x Load tested to 3000 lbs.

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PTS206 ATS207 2”x 3” All Plastic Utility Drain PUM212/AUM213

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

45

Utility Drains

(Continued)

Snap & Lok Area Drain

x Fits over 1.5” or inside 2” hub Schedule 40 DWV, or over 2” or inside 3” Schedule 40 DWV,

or over 3” or inside 4” Schedule 40 DWV pipe

x Four pegs in strainer allow positive positioning to base
x 6” diameter base with 1.75” deep sump allows greater drainage
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PSL564 ASL565 1.5”x 2” hub Snap & Lok Area Drain PSL560L/ASL561L
PSL566 ASL567 2”x 3” Snap & Lok Area Drain PSL560L/ASL561L
PSL568 ASL569 3”x 4” Snap & Lok Area Drain PSL560L/ASL561L

General Purpose Square Utility Drain

x 6”x 6” utility drain fits over 1.5” or 2” spigot Schedule 40 DWV or over 2” or

inside 3” Schedule 40 DWV pipe

x 9”x 9” utility drain fits over 3” or inside 4” Schedule 40 DWV pipe, or over

4” Schedule 40 DWV pipe

x For general purpose drainage requirements where clamping of a waterproofing

2.90/

4.25

7.00/9.00

5.00/7.70

2.40/3.00/

4.00/5.00

membrane is not required

x Threaded metal insert for attaching hinged strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PUT64 AUT65 1.5”x 2” hub 6”x 6” Utility Drain PSP62/ASP62
PUT66 AUT67 2”x 3” 6”x 6” Utility Drain PSP62/ASP62
PUT96 AUT97 3”x 4” 9”x 9” Utility Drain PSP63/ASP63
PUT98 AUT99 4” 9”x 9” Utility Drain PSP63/ASP63

General Purpose Bell Trap Drain

x 6”x 6” bell trap drain fits over 1.5” or 2” spigot Schedule 40 DWV, or over 2” or

inside 3” Schedule 40 DWV pipe

x 9”x 9” bell trap drain fits over 3” or inside 4” Schedule 40 DWV pipe, or over

4” Schedule 40 DWV pipe

x Molded in bell trap

2.90/

4.25

7.00/9.00

5.00/7.70

2.40/3.00/

4.00/5.00

x For general purpose drainage requirements where clamping of a waterproofing

membrane is not required

x Threaded metal insert for attaching hinged strainer

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PBT6004 ABT6005 1.5”x2” hub 6”x 6” Bell Trap Drain PSP64/ASP64
PBT6006 ABT6007 2”x 3” 6”x 6” Bell Trap Drain PSP64/ASP64
PBT9009 ABT9010 3”x 4” 9”x 9” Bell Trap Drain PSP65/ASP65
PBT4009 ABT4010 4” 9”x 9” Bell Trap Drain PSP65/ASP65

46

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

Utility Drains

(Continued)

Snap-In® Series Drains

Shallow Sump General Purpose Drain

x Fits over 2” or inside 3” Schedule 40 DWV pipe or over 3” or inside 4” Schedule 40 DWV pipe
x 9.5” diameter full grate available in cast metal
x Interior surfaces are sloped and smooth to allow maximum flow
x Threaded metal inserts for attaching strainer

PART #

PVC ABS SIZE DECRIPTION GRATE

3.00/

4.00

3” Inside Pipe Fit Adjustable General Purpose Drain

PGP9230A AGP9231A 2”x 3” W/ Full Aluminum Grate SP11LFA
PGP9230B AGP9231B 2”x 3” W/ Full Brass Grate SP11LFB
PGP9230N AGP9231N 2”x 3” W/ Full Nickel Grate SP11LFN
PGP9340A AGP9341A 3”x 4” W/ Full Aluminum Grate SP11LFA
PGP9340B AGP9341B 3”x 4” W/ Full Brass Grate SP11LFB
PGP9340N AGP9341N 3”x 4” W/ Full Nickel Grate SP11LFN

x Bushing fits inside 3” Schedule 40 DWV pipe
x 4” diameter strainer available in a variety of finishes and cast metal
x 2” IPS plastic strainer barrel allows adjustment to desired finished level
x For general purpose drainage requirements where clamping of a waterproofing membrane

is not required

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PSI280 ASI281 3” W/ Stamped SS Strainer SP-1
PSI282 ASI283 3” W/ Nickel Strainer SP-2N
PSI282R ASI283R 3” W/ Nickel Strainer & Metaring SP-2N
PSI284 ASI285 3” W/ Polished Brass Strainer SP-2PB
PSI284R ASI285R 3” W/ Polished Brass Strainer & Metaring SP-2PB
PSI284SS ASI285SS 3” W/ Stamped Polished Gold Strainer SP-1SPB
PSI294 ASI295 3” W/ Antique Brass Strainer SP-2AB
PSI294R ASI295R 3” W/ Antique Brass Strainer & Metaring SP-2AB
PSI294SS ASI295SS 3” W/ Stamped Antique Brass Strainer SP-1SAB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

47

Snap-In Series Drains

(Continued)

Snap-In General Purpose Drain

x Fits inside 3” or 4” Schedule 40 DWV pipe
x Allows cutting pipe flush with floor
x May be solvent welded or simply inserted inside pipe

3.50/

4.50

3.00/

4.00

x May also be utilized as a strainer for vent stack or air inlet

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PSI306 ASI307 3” W/ 3.5” Stamped SS Strainer SP-23
PSI308 ASI309 4” W/ 4.5” Stamped SS Strainer SP-24

Snap-In General Purpose Plastic Drain

x Fit inside 2”, 3”, or 4” Schedule 40 DWV pipe
x Allows cutting pipe flush with floor
x May be solvent welded or simply inserted inside pipe
x May also be utilized as a strainer for vent stack or air inlet

2.50/

3.50/

4.50

2.00/

3.00/

4.00

PSI304 ASI305 2” All plastic
PSI310 ASI311 3” All plastic

PART #

PVC ABS SIZE DESCRIPTION

PSI312 ASI313 4” All plastic

Cast Snap-In Strainer

0.15/

0.18/

0.25

2.35/

3.42/

4.50

x Fits directly into 2”, 3”, or 4” pipe
x Easy installation
x Available in cast aluminum, brass, or nickel

PART# SIZE DESCRIPTION

CSI200A 2” Aluminum Snap-In strainer
CSI200B 2” Brass Snap-In strainer

0.65/

0.80/

CSI200N 2” Nickel Snap-In strainer

1.05

CSI300A 3” Aluminum Snap-In strainer
CSI300B 3” Brass Snap-In strainer
CSI300N 3” Nickel Snap-In strainer
CSI400A 4” Aluminum Snap-In strainer
CSI400B 4” Brass Snap-In strainer
CSI400N 4” Nickel Snap-In strainer

48

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

Miscellaneous General Purpose Drains

P-Trap Drain

x Fits over 2” Schedule 40 DWV pipe
x Round plastic utility drain comes complete with P-trap assembly
x Round backflow prevention ball installed beneath drain
x Also available without cleanout assembly

PART #

PVC SIZE DESCRIPTION ABS

PTD200 2” P-Trap Drain With Removable Ball ATD201
PTDC200 2” P-Trap Drain With Ball & Cleanout ATDC201

Funnel Drain

x Fits inside 3” or 4” Schedule 40 DWV pipe
x Round funnel can “Piggy-Back” onto an existing drain
x Available with spring style hose holder
x Hardware available

PART #

PVC ABS SIZE DESCRIPTION

PRF3600 ARF3601 3” Round Funnel Only
PRF3800 ARF3801 4” Round Funnel Only
PRS3602 ARS3603 3” W/ Spring Hose Holder
PRS3802 ARS3803 4” W/ Spring Hose Holder

“Piggy Back” Funnel Drain Assembly

x Fits over 3” or inside 4” Schedule 40 DWV pipe or over 4” Schedule 40 DWV pipe
x Drain and “Piggy-Back” round funnel come assembled
x Available with spring style hose holder
x Hardware available

PART #

PVC ABS SIZE DESCRIPTION

PPB5600 APB5601 3”x 4” W/ Round Funnel Only
PPB7800 APB7801 4” W/ Round Funnel Only
PPS5602 APS5603 3”x 4” W/ Spring Hose Holder
PPS7802 APS7803 4” W/ Spring Hose Holder

Overflow Dome Drain

x SMV30 fits inside 3” Schedule 40 DWV pipe
x SMV40 fits inside 4” Schedule 40 DWV pipe

3.50/

3.90

3.00/

4.00

Order by Phone: [phone] Order by Fax: [phone]

PART# SIZE DESCRIPTION

SMV30 3” Overflow Dome Drain
SMV40 4” Overflow Dome Drain

49

www.plasticoddities.com

Miscellaneous General Purpose Drains

PVC Overflow Drain

x Fits over 3” or 4” or inside 6” Schedule 40 DWV pipe
x Overflow drain with clamping collar includes dome with secondary strainer
x 6” standard overflow height, other lengths available upon request

PART #

PVC ABS SIZE DESCRIPTION

POD892 AOD893 3” 3” Extended Overflow Dome Drain
POD894 AOD895 4” 4” Extended Overflow Dome Drain
POD896 AOD897 6” 6” Extended Overflow Dome Drain

(Continued)

50

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

“Friend of the Plumber”

Light Commercial

Drains

L

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

3” Over Pipe Fit Heavy Duty Adjustable Floor Drain

Adjustable Floor Drains - 3”

5.00/ 6.00

x Fits over 3” Schedule 40 DWV pipe
x 3.5” IPS plastic strainer barrel allows adjustment to desired finish level
x 5” and 6” cast metal strainers available with round or square metaring
x PVC clamping collar
x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar and strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

WITH 5” STRAINER

PHD820 AHD821 3” W/ Stamped SS Strainer SP-3
PHD822 AHD823 3” W/ Nickel Strainer SP-4N
PHD822R AHD823R 3” W/ Nickel Strainer & Round Ring SP-4N
PHD822RS AHD823RS 3” W/ Nickel Strainer & Square Ring SP-4N
PHD832 AHD833 3” W/ Nickel Sundial Strainer SP-6N
PHD832R AHD833R 3” W/ Nickel Sundial Strainer & Round Ring SP-6N
PHD832RS AHD833RS 3” W/ Nickel Sundial Strainer & Square Ring SP-6N
PHD840 AHD841 3” W/ Polished Brass Strainer SP-4PB
PHD840R AHD841R 3” W/ Pol. Brass Strainer & Round Ring SP-4PB
PHD840RS AHD841RS 3” W/ Pol. Brass Strainer & Square Ring SP-4PB
PHD854 AHD855 3” W/ Antique Brass Strainer SP-4AB
PHD854R AHD855R 3” W/ Ant. Brass Strainer & Round Ring SP-4AB
PHD854RS AHD855R 3” W/ Ant. Brass Strainer & Square Ring SP-4AB

WITH 6” STRAINER

PHD860 AHD861 3” W/ Nickel Strainer SP-8N
PHD860R AHD861R 3” W/ Nickel Strainer & Round Ring SP-8N
PHD860RS AHD861RS 3” W/ Nickel Strainer & Square Ring SP-8N
PHD860P AHD861P 3” W/ Gold Plastic Strainer SP-8PGOLD
PHD860PRS AHD861PRS 3” W/ Gold Plastic Strainer & Square Ring SP-8PGOLD

PHD844 AHD845 3” W/ Polished Brass Strainer SP-8PB
PHD844R AHD845R 3” W/ Pol. Brass Strainer & Round Ring SP-8PB
PHD844RS AHD845RS 3” W/ Pol. Brass Strainer & Square Ring SP-8PB
PHD868 AHD869 3” W/ Antique Brass Strainer SP-8AB
PHD868R AHD869R 3” W/ Ant. Brass Strainer & Round Ring SP-8AB
PHD868RS AHD869RS 3” W/ Ant. Brass Strainer & Square Ring SP-8AB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

53

Adjustable Floor Drains - 4”

Adjustable Floor Drains - 3”

(Continued)

3” Over Pipe Fit Heavy Duty Adjustable Floor Drain With Metal Tailpiece

x Fits over 3” Schedule 40 DWV pipe
x Cast metal strainer available in a variety of sizes and finishes
x PVC clamping collar
x Available tapped for trap primer

5.00/ 6.00/ 8.00/ 10.00

4” Over Pipe Fit Heavy Duty Adjustable Floor Drain With Metal Tailpiece

x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PHD800 AHD801 3” W/ 5” Nickel Strainer, Tailpiece SP-4N
PHD800PB AHD801PB 3” W/ 5” Polished Brass Strainer, Tailpiece SP-4PB

PHD802 AHD803 3” W/ 6” Nickel Strainer, Tailpiece SP-8N
PHD802PB AHD803PB 3” W/ 6” Polished Brass Strainer, Tailpiece SP-8PB
PHD804 AHD805 3” W/ 8” Nickel Strainer, Tailpiece SP-10N
PHD804PB AHD805PB 3” W/ 8” Polished Brass Strainer, Tailpiece SP-10PB
PHD814 AHD815 3” W/ 10” Nickel Strainer, Tailpiece SP-11N
PHD814PB AHD815PB 3” W/ 10” Polished Brass Strainer, Tailpiece SP-11PB

x Fits over 4” Schedule 40 DWV pipe
x Cast metal strainer available in a variety of sizes and finishes
x PVC clamping collar
x Available tapped for trap primer

5.00/ 6.00/ 8.00/ 10.00

x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PHD806 AHD807 4” W/ 5” Nickel Strainer, Tailpiece SP-4N
PHD806PB AHD807PB 4” W/ 5” Polished Brass Strainer, Tailpiece SP-4PB
PHD808 AHD809 4” W/ 6” Nickel Strainer, Tailpiece SP-8N
PHD808PB AHD809PB 4” W/ 6” Polished Brass Strainer, Tailpiece SP-8PB
PHD810 AHD811 4” W/ 8” Nickel Strainer, Tailpiece SP-10N
PHD810PB AHD811PB 4” W/ 8” Polished Brass Strainer, Tailpiece SP-10PB
PHD812 AHD813 4” W/ 10” Nickel Strainer, Tailpiece SP-11N
PHD812PB AHD813PB 4” W/ 10” Polished Brass Strainer, Tailpiece SP-11PB

54

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Adjustable Floor Drains - 4”

(Continued)

4 ” Over Pipe Fit Heavy Duty Adjustable Floor Drain

5.00/ 6.00

x Fits over 4” Schedule 40 DWV pipe
x 3.5” IPS plastic strainer barrel allows adjustment to desired finish level
x 5” and 6” cast metal strainers available with round or square metaring
x PVC clamping collar
x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar and strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

WITH 5” STRAINER

PHD826 AHD827 4” W/ Stainless Steel Strainer SP-3
PHD828 AHD829 4” W/ Nickel Strainer SP-4N
PHD828R AHD829R 4” W/ Nickel Strainer & Round Ring SP-4N

PHD828RS AHD829RS 4” W/ Nickel Strainer & Square Ring SP-4N
PHD838 AHD839 4” W/ Nickel Sundial Strainer SP-6N
PHD838R AHD839R 4” W/ Nickel Sundial Strainer & Round Ring SP-6N
PHD838RS AHD839RS 4” W/ Nickel Sundial Strainer & Square Ring SP-6N
PHD842 AHD843 4” W/ Polished Brass Strainer SP-4PB
PHD842R AHD843R 4” W/ Polished Brass Strainer & Round Ring SP-4PB
PHD842RS AHD843RS 4” W/ Polished Brass Strainer & Square Ring SP-4PB
PHD856 AHD857 4” W/ Antique Brass Strainer SP-4AB
PHD856R AHD857R 4” W/ Antique Brass Strainer & Round Ring SP-4AB
PHD856RS AHD857RS 4” W/ Antique Brass Strainer & Square Ring SP-4AB

WITH 6” STRAINER

PHD862 AHD863 4” W/ Nickel Strainer SP-8N
PHD862R AHD863R 4” W/ Nickel Strainer & Round Ring SP-8N
PHD862RS AHD863RS 4” W/ Nickel Strainer & Square Ring SP-8N
PHD862P AHD863P 4” W/ Gold Plastic Strainer SP-8PGOLD
PHD862PRS AHD863PRS 4” W/ Gold Plastic Strainer & Square Ring SP-8PGOLD
PHD846 AHD847 4” W/ Polished Brass Strainer SP-8PB
PHD846R AHD847R 4” W/ Pol. Brass Strainer & Round Ring SP-8PB
PHD846RS AHD847RS 4” W/ Pol. Brass Strainer & Square Ring SP-8PB
PHD870 AHD871 4” W/ Antique Brass Strainer SP-8AB
PHD870R AHD871R 4” W/ Ant. Brass Strainer & Round Ring SP-8AB
PHD870RS AHD871RS 4” W/ Ant. Brass Strainer & Square Ring SP-8AB

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

55

Adjustable Floor Drains - 6”

6” Inside Pipe Fit Heavy Duty Adjustable Floor Drain

x Fits inside 6” Schedule 40 DWV pipe
x 3.5” IPS plastic strainer barrel allows adjustment to desired finish level
x 5” and 6” cast metal strainers available with round or square metaring
x PVC clamping collar

5.00/ 6.00

x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar and strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

WITH 5” STRAINER

PHD620 AHD621 6” W/ Stamped SS Strainer SP-3
PHD622 AHD623 6” W/ Nickel Strainer SP-4N

PHD622R AHD623R 6” W/ Nickel Strainer & Round Ring SP-4N
PHD622RS AHD623RS 6” W/ Nickel Strainer & Square Ring SP-4N
PHD632 AHD633 6” W/ Sundial Nickel Strainer SP-6N
PHD632R AHD633R 6” W/ Sundial Nickel Strainer & Round Ring SP-6N
PHD632RS AHD633RS 6” W/ Sundial Nickel Strainer & Square Ring SP-6N
PHD640 AHD641 6” W/ Polished Brass Strainer SP-4PB
PHD640R AHD641R 6” W/ Polished Brass Strainer & Round Ring SP-4PB
PHD640RS AHD641R 6” W/ Polished Brass Strainer & Square Ring SP-4PB
PHD654 AHD655 6” W/ Antique Brass Strainer SP-4AB
PHD654R AHD655R 6” W/ Antique Brass Strainer & Round Ring SP-4AB
PHD654RS AHD655RS 6” W/ Antique Brass Strainer & Square Ring SP-4AB

WITH 6” STRAINER

PHD660 AHD661 6” W/ Nickel Strainer SP-8N
PHD660R AHD661R 6” W/ Nickel Strainer & Round Ring SP-8N

PHD660RS AHD661RS 6” W/ Nickel Strainer & Square Ring SP-8N
PHD660P AHD661P 6” W/ Gold Plastic Strainer SP-8PGOLD
PHD660PRS AHD661PRS 6” W/ Gold Plastic Strainer & Square Ring SP-8PGOLD

PHD644 AHD645 6” W/ Polished Brass Strainer SP-8PB
PHD644R AHD645R 6” W/ Polished Brass Strainer & Round Ring SP-8PB
PHD644RS AHD645RS 6” W/ Polished Brass Strainer & Square Ring SP-8PB
PHD668 AHD669 6” W/ Antique Brass Strainer SP-8AB
PHD668R AHD669R 6” W/ Antique Brass Strainer & Round Ring SP-8AB
PHD668RS AHD669RS 6” W/ Antique Brass Strainer & Square Ring SP-8AB

56

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Grate Drains

Adjustable Floor Drains - 6”

(Continued)

6” Inside Pipe Fit Heavy Duty Adjustable Floor Drain with Metal Tailpiece

x Fits inside 6” Schedule 40 DWV pipe
x Cast metal strainers available in a variety of sizes and finishes
x PVC clamping collar
x Available tapped for trap primer

5.00/ 6.00/ 8.00/ 10.00

x Threaded metal inserts for attaching clamping collar and strainer plate

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PHD600 AHD601 6” W/ 5” Nickel Strainer, Tailpiece SP-4N
PHD600PB AHD601PB 6” W/ 5” Polished Brass Strainer, Tailpiece SP-4PB
PHD602 AHD603 6” W/ 6” Nickel Strainer, Tailpiece SP-8N
PHD602PB AHD603PB 6” W/ 6” Polished Brass Strainer, Tailpiece SP-8PB
PHD604 AHD605 6” W/ 8” Nickel Strainer, Tailpiece SP-10N
PHD604PB AHD605PB 6” W/ 8” Polished Brass Strainer, Tailpiece SP-10PB
PHD614 AHD615 6” W/ 10” Nickel Strainer, Tailpiece SP-11N
PHD614PB AHD615PB 6” W/ 10” Polished Brass Strainer, Tailpiece SP-11PB

3” Over Pipe Fit Grate Floor Drain

x Fits over 3” Schedule 40 DWV pipe
x 8.5” diameter grate available in plastic and cast metal with 24 sq. inch flow area
x Available with or without sediment bucket
x PVC clamping collar with molded in weep slots
x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION GRATE

PSB950 ASB951 3” W/ Plastic Grate and Sediment Bucket PSP-54
PSB954 ASB955 3” W/ Cast Iron Grate and Sediment Bucket SP-54C
PSB954A ASB955A 3” W/ Aluminum Grate and Sediment Bucket SP-54A
PSB954N ASB955N 3” W/ Nickel Grate and Sediment Bucket SP-54N

Sediment

Bucket

Solid Sediment

Bucket

PSB954B ASB955B 3” W/ Brass Grate and Sediment Bucket SP-54B
PSB950S ASB951S 3” W/ Plastic Grate and Solid Sediment Bucket PSP-54
PSB954S ASB955S 3” W/ Cast Iron Grate and Solid Sediment Bucket SP-54C
PSB954AS ASB955AS 3” W/ Aluminum Grate and Solid Sediment Bucket SP-54A
PSB954NS ASB955NS 3” W/ Nickel Grate and Solid Sediment Bucket SP-54N
PSB954BS ASB955BS 3” W/ Brass Grate and Solid Sediment Bucket SP-54B
PSD960 ASD961 3” W/ Plastic Grate only PSP-54
PSD964 ASD965 3” W/ Cast Iron Grate only SP-54C
PSD964A ASD965A 3” W/ Aluminum Grate only SP-54A
PSD964N ASD965N 3” W/ Nickel Grate only SP-54N

PSD964B ASD965B 3” W/ Brass Grate only SP-54B

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

57

Grate Drains

(Continued)

4” Over Pipe Fit Grate Floor Drain

x Fits over 4” Schedule 40 DWV pipe
x 8.5” diameter grate available in plastic and cast metal with 24 sq. inch flow area
x Available with or without sediment bucket
x PVC clamping collar with molded in weep slots
x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION GRATE

PSB952 ASB953 4” W/ Plastic Grate and Sediment Bucket PSP-54
PSB956 ASB957 4” W/ Cast Iron Grate and Sediment Bucket SP-54C
PSB956A ASB957A 4” W/ Aluminum Grate and Sediment Bucket SP-54A

Sediment

Bucket

Solid Sediment

Bucket

PSB956N ASB957N 4” W/ Nickel Grate and Sediment Bucket SP-54N
PSB956B ASB957B 4” W/ Brass Grate and Sediment Bucket SP-54B
PSB952S ASB953S 4” W/ Plastic Grate and Solid Sediment Bucket PSP-54
PSB956S ASB957S 4” W/ Cast Iron Grate and Solid Sediment Bucket SP-54C
PSB956AS ASB957AS 4” W/ Aluminum Grate and Solid Sediment Bucket SP-54A
PSB956NS ASB957NS 4” W/ Nickel Grate and Solid Sediment Bucket SP-54N
PSB956BS ASB957BS 4” W/ Brass Grate and Solid Sediment Bucket SP-54B
PSD962 ASD963 4” W/ Plastic Grate PSP-54
PSD966 ASD967 4” W/ Cast Iron Grate SP-54C
PSD966A ASD967A 4” W/ Aluminum Grate SP-54A
PSD966N ASD967N 4” W/ Nickel Grate SP-54N
PSD966B ASD967B 4” W/ Brass Grate SP-54B

58

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Used With Grate Drains & Floor Sinks

Grate Drains

(Continued)

6” Inside Pipe Fit Grate Floor Drain

x Fits inside 6” Schedule 40 DWV pipe
x 8.5” diameter grate available in plastic and cast metal with 24 sq. inch flow area
x Available with or without sediment bucket
x PVC clamping collar with molded in weep slots
x Available tapped for trap primer
x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION GRATE

PSB980 ASB981 6” W/ Plastic Grate and Sediment Bucket PSP-54
PSB982 ASB983 6” W/ Cast Iron Grate and Sediment Bucket SP-54C
PSB982A ASB983A 6” W/ Aluminum Grate and Sediment Bucket SP-54A

Sediment

Bucket

Solid Sediment

Bucket

PSB982N ASB983N 6” W/ Nickel Grate and Sediment Bucket SP-54N
PSB982B ASB983B 6” W/ Brass Grate and Sediment Bucket SP-54B
PSB980S ASB981S 6” W/ Plastic Grate and Solid Sediment Bucket PSP-54
PSB982S ASB983S 6” W/ Cast Iron Grate and Solid Sediment Bucket SP-54C
PSB982AS ASB983AS 6” W/ Aluminum Grate and Solid Sediment Bucket SP-54A
PSB982NS ASB983NS 6” W/ Nickel Grate and Solid Sediment Bucket SP-54N
PSB982BS ASB983BS 6” W/ Brass Grate and Solid Sediment Bucket SP-54B
PSD990 ASD991 6” W/ Plastic Grate only PSP-54
PSD992 ASD993 6” W/ Cast Iron Grate only SP-54C
PSD992A ASD993A 6” W/ Aluminum Grate only SP-54A
PSD992N ASD993N 6” W/ Nickel Grate only SP-54N
PSD992B ASD993B 6” W/ Brass Grate only SP-54B

Cast Indirect Waste Funnel

x Especially used with grate drains and floor sinks, and easily adapts to fit

other drains

x Made of durable cast aluminum which will not rust

PART# DESCRIPTION

AFD1 Aluminum Funnel Drain

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

59

60

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Swimming Pool Deck Drains

General Purpose Utility/Pool Deck Drain

x Fits over 2” or inside 3” schedule 40 DWV pipe
x Threaded plastic strainer screws down flush with body
x All plastic drain has no metal parts to rust or corrode
x Load tested to 3000 lbs

PART #

PVC ABS SIZE DESCRIPTION STRAINER

PTS206 ATS207 2”x 3”

All Plastic Utility Drain

PTS206B ATS207B 2”x 3” Plastic Utility Drain w/ Brass Strainer SP10B

Call for Details

PTS206N ATS207N 2”x 3” Plastic Utility Drain w/ Nickel Strainer SP10N

4” Over Pipe Fit Grate Floor Drain

x Fits over 4” Schedule 40 DWV pipe
x 8.5” diameter grate available in plastic and cast metal with 24 sq. inch flow area
x Available with or without sediment bucket
x PVC clamping collar with molded in weep slots
x Available tapped for trap primer

PUM212/AUM213

x Threaded metal inserts for attaching clamping collar

PART #

PVC ABS SIZE DESCRIPTION GRATE

PSB952W ASB953W 4” W/ WHITE Plastic Grate and Sediment Bucket PSP-54W
PSB956 ASB957 4” W/ Cast Iron Grate and Sediment Bucket SP-54C
PSB956A ASB957A 4” W/ Aluminum Grate and Sediment Bucket SP-54A
PSB956N ASB957N 4” W/ Nickel Grate and Sediment Bucket SP-54N

Sediment

Bucket

PSB956B ASB957B 4” W/ Brass Grate and Sediment Bucket SP-54B
PSB956G ASB957G 4” W/ Brass Grate, Gold Collar and Sediment Bucket SP-54B

Shallow Sump Floor Sink With Secondary Strainer

x Fits over 2” or inside 3” Schedule 40 DWV pipe or over 3” or inside 4” Schedule 40 DWV pipe
x 12” diameter grate available as Full, 1/2, and 3/4 grate in aluminum, brass, or nickel

3.00/

4.00

For Additional

Information:

Reference Page 68

x Medium duty drain with 4” height for slab installation
x Interior surfaces are sloped and smooth to allow maximum flow
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DECRIPTION GRATE STRAINER

PFS9230FB AFS9231FB 2”x 3” W/ Full Brass Grate SP-11LFB PSI304/ASI305
PFS9340FB AFS9341FB 3”x 4” W/ Full Brass Grate SP-11LFB PSI310/ASI311

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

61

“Friend of the Plumber”

Floor Sinks

F

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

Floor Sinks - 2”

2” Square Deep Sump Receptor Drain

1/2 & 3/4 Plastic
Grates Av ailable

x Fits over 2” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE

PDS2000 ADS2001 2” W/ no Grate
PDS2000F ADS2001F 2” W/ Full Plastic Grate PDSG100/ADSG100
PDS2000FA ADS2001FA 2” W/ Full Aluminum Grate SDSG100A
PDS2000FB ADS2001FB 2” W/ Full Brass Grate SDSG100B
PDS2000FN ADS2001FN 2” W/ Full Nickel Grate SDSG100N
PDS2000H ADS2001H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50
PDS2000T ADS2001T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75

2” Round Deep Sump Receptor Drain

x Fits over 2” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE

RDS2000 RDS2001 2” W/ no Grate
RDS2000F RDS2001F 2” W/ Full Plastic Grate PDSG100/ADSG100
RDS2000FA RDS2001FA 2” W/ Full Aluminum Grate SDSG100A
RDS2000FB RDS2001FB 2” W/ Full Brass Grate SDSG100B
RDS2000FN RDS2001FN 2” W/ Full Nickel Grate SDSG100N
RDS2000H RDS2001H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50
RDS2000T RDS2001T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

65

Floor Sinks - 2”

(Continued)

2” Floor Sink With Secondary Strainer

x Fits over 2” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

1/2 & 3/4 Plastic
Grates Av ailable

PFS200 AFS201 2” W/ no Grate PSI304/ASI305
PFS200F AFS201F 2” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
PFS200FA AFS201FA 2” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
PFS200FB AFS201FB 2” W/ Full Brass Grate SDSG100B PSI304/ASI305
PFS200FN AFS201FN 2” W/ Full Nickel Grate SDSG100N PSI304/ASI305
PFS200H AFS201H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
PFS200T AFS201T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

2” Round Floor Sink With Secondary Strainer

x Fits over 2” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic

1/2 & 3/4 Plastic
Grates Av ailable

x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RFS200 RFS201 2” W/ no Grate PSI304/ASI305
RFS200F RFS201F 2” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
RFS200FA RFS201FA 2” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
RFS200FB RFS201FB 2” W/ Full Brass Grate SDSG100B PSI304/ASI305
RFS200FN RFS201FN 2” W/ Full Nickel Grate SDSG100N PSI304/ASI305
RFS200H RFS201H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
RFS200T RFS201T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

66

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Floor Sinks - 2”

(Continued)

2” Floor Sink With Aluminum Beehive Strainer

1/2 & 3/4 Plastic
Grates Av ailable

x Fits over 2” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

PBH200 ABH201 2” W/ no Grate SPB1A
PBH200F ABH201F 2” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
PBH200FA ABH201FA 2” W/ Full Aluminum Grate SDSG100A SPB1A
PBH200FB ABH201FB 2” W/ Full Brass Grate SDSG100B SPB1A
PBH200FN ABH201FN 2” W/ Full Nickel Grate SDSG100N SPB1A
PBH200H ABH201H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
PBH200T ABH201T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

2” Round Floor Sink With Aluminum Beehive Strainer

x Fits over 2” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RBH200 RBH201 2” W/ no Grate SPB1A
RBH200F RBH201F 2” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
RBH200FA RBH201FA 2” W/ Full Alumin um Grate SDSG100A SPB1A
RBH200FB RBH201FB 2” W/ Full Brass Grate SDSG100B SPB1A
RBH200FN RBH201FN 2” W/ Full Nickel Grate SDSG100N SPB1A
RBH200H RBH201H 2” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
RBH200T RBH201T 2” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

67

Floor Sinks - 3”

3” Square Deep Sump Receptor Drain

x Fits over 3” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE

PDS3000 ADS3001 3” W/ no Grate
PDS3000F ADS3001F 3” W/ Full Plastic Grate PDSG100/ADSG100
PDS3000FA ADS3001FA 3” W/ Full Aluminum Grate SDSG100A
PDS3000FB ADS3001FB 3” W/ Full Brass Grate SDSG100B
PDS3000FN ADS3001FN 3” W/ Full Nickel Grate SDSG100N
PDS3000H ADS3001H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50
PDS3000T ADS3001T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75

3” Round Deep Sump Receptor Drain

x Fits over 3” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE

RDS3000 RDS3001 3” W/ no Grate
RDS3000F RDS3001F 3” W/ Full Plastic Grate PDSG100/ADSG100
RDS3000FA RDS3001FA 3” W/ Full Aluminum Grate SDSG100A
RDS3000FB RDS3001FB 3” W/ Full Brass Grate SDSG100B
RDS3000FN RDS3001FN 3” W/ Full Nickel Grate SDSG100N
RDS3000H RDS3001H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50
RDS3000T RDS3001T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75

68

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Floor Sinks - 3”

(Continued)

3” Floor Sink With Secondary Strainer

x Fits over 3” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PFS300 / PFS300F
PFS300T / PFS300H
ARE UPC LISTED

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

1/2 & 3/4 Plastic
Grates Av ailable

PFS300 AFS301 3” W/ no Grate PSI304/ASI305
PFS300F AFS301F 3” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
PFS300FA AFS301FA 3” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
PFS300FB AFS301FB 3” W/ Full Brass Grate SDSG100B PSI304/ASI305
PFS300FN AFS301FN 3” W/ Full Nickel Grate SDSG100N PSI304/ASI305
PFS300H AFS301H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
PFS300T AFS301T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

3” Round Floor Sink With Secondary Strainer

x Fits over 3” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RFS300 RFS301 3” W/ no Grate PSI304/ASI305
RFS300F RFS301F 3” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
RFS300FA RFS301FA 3” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
RFS300FB RFS301FB 3” W/ Full Brass Grate SDSG100B PSI304/ASI305
RFS300FN RFS301FN 3” W/ Full Nickel Grate SDSG100N PSI304/ASI305
RFS300H RFS301H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
RFS300T RFS301T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

69

Floor Sinks - 3”

(Continued)

3” Floor Sink With Aluminum Beehive Strainer

x Fits over 3” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

1/2 & 3/4 Plastic
Grates Av ailable

PBH300 ABH301 3” W/ no Grate SPB1A
PBH300F ABH301F 3” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
PBH300FA ABH301FA 3” W/ Full Aluminum Grate SDSG100A SPB1A
PBH300FB ABH301FB 3” W/ Full Brass Grate SDSG100B SPB1A
PBH300FN ABH301FN 3” W/ Full Nickel Grate SDSG100N SPB1A
PBH300H ABH301H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
PBH300T ABH301T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

3” Round Floor Sink With Aluminum Beehive Strainer

x Fits over 3” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic

1/2 & 3/4 Plastic
Grates Av ailable

x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RBH300 RBH301 3” W/ no Grate SPB1A
RBH300F RBH301F 3” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
RBH300FA RBH301FA 3” W/ Full Aluminum Grate SDSG100A SPB1A
RBH300FB RBH301FB 3” W/ Full Brass Grate SDSG100B SPB1A
RBH300FN RBH301FN 3” W/ Full Nickel Grate SDSG100N SPB1A
RBH300H RBH301H 3” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
RBH300T RBH301T 3” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

70

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Floor Sinks - 4”

4” Square Deep Sump Receptor Drain

1/2 & 3/4 Plastic
Grates Av ailable

x Fits over 4” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE

PDS4000 ADS4001 4” W/ no Grate
PDS4000F ADS4001F 4” W/ Full Plastic Grate PDSG100/ADSG100
PDS4000FA ADS4001FA 4” W/ Full Aluminum Grate SDSG100A
PDS4000FB ADS4001FB 4” W/ Full Brass Grate SDSG100B
PDS4000FN ADS4001FN 4” W/ Full Nickel Grate SDSG100N
PDS4000H ADS4001H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50
PDS4000T ADS4001T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75

4” Round Deep Sump Receptor Drain

x Fits over 4” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE

RDS4000 RDS4001 4” W/ no Grate
RDS4000F RDS4001F 4” W/ Full Plastic Grate PDSG100/ADSG100
RDS4000FA RDS4001FA 4” W/ Full Aluminum Grate SDSG100A
RDS4000FB RDS4001FB 4” W/ Full Brass Grate SDSG100B
RDS4000FN RDS4001FN 4” W/ Full Nickel Grate SDSG100N
RDS4000H RDS4001H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50
RDS4000T RDS4001T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

71

Floor Sinks - 4”

(Continued)

4” Floor Sink With Secondary Strainer

x Fits over 4” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PFS400 / PFS400F
PFS400T / PFS400H
ARE UPC LISTED

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

1/2 & 3/4 Plastic
Grates Av ailable

PFS400 AFS401 4” W/ no Grate PSI304/ASI305
PFS400F AFS401F 4” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
PFS400FA AFS401FA 4” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
PFS400FB AFS401FB 4” W/ Full Brass Grate SDSG100B PSI304/ASI305
PFS400FN AFS401FN 4” W/ Full Nickel Grate SDSG100N PSI304/ASI305
PFS400H AFS401H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
PFS400T AFS401T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

4” Round Floor Sink With Secondary Strainer

x Fits over 4” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Plastic secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RFS400 RFS401 4” W/ no Grate PSI304/ASI305
RFS400F RFS401F 4” W/ Full Plastic Grate PDSG100/ADSG100 PSI304/ASI305
RFS400FA RFS401FA 4” W/ Full Aluminum Grate SDSG100A PSI304/ASI305
RFS400FB RFS401FB 4” W/ Full Brass Grate SDSG100B PSI304/ASI305
RFS400FN RFS401FN 4” W/ Full Nickel Grate SDSG100N PSI304/ASI305
RFS400H RFS401H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50 PSI304/ASI305
RFS400T RFS401T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75 PSI304/ASI305

72

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Floor Sinks - 4”

(Continued)

4” Floor Sink With Aluminum Beehive Strainer

x Fits over 4” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

1/2 & 3/4 Plastic

Grates Av ailable

PBH400 ABH401 4” W/ no Grate SPB1A
PBH400F ABH401F 4” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
PBH400FA ABH401FA 4” W/ Full Aluminum Grate SDSG100A SPB1A
PBH400FB ABH401FB 4” W/ Full Brass Grate SDSG100B SPB1A
PBH400FN ABH401FN 4” W/ Full Nickel Grate SDSG100N SPB1A
PBH400H ABH401H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
PBH400T ABH401T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

PART #

PVC ABS SIZE DESCRIPTION GRATE STRAINER

4” Round Floor Sink With Aluminum Beehive Strainer

x Fits over 4” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x Aluminum beehive secondary strainer
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE STRAINER

RBH400 RBH401 2” W/ no Gra te SPB1A
RBH400F RBH401F 4” W/ Full Plastic Grate PDSG100/ADSG100 SPB1A
RBH400FA RBH401FA 4” W/ Full Alumin um Grate SDSG100A SPB1A
RBH400FB RBH401FB 4” W/ Full Brass Grate SDSG100B SPB1A
RBH400FN RBH401FN 4” W/ Full Nickel Grate SDSG100N SPB1A
RBH400H RBH401H 4” W/ 1/2 Plastic Grate PDSG50/ADSG50 SPB1A
RBH400T RBH401T 4” W/ 3/4 Plastic Grate PDSG75/ADSG75 SPB1A

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

73

Floor Sinks - 6”

6” Square Deep Sump Receptor Drain

x Fits over 6” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

(Check for Availability)

1/2 & 3/4 Plastic
Grates Av ailable

PDS6000 ADS6001 6” W/ no Grate
PDS6000F ADS6001F 6” W/ Full Plastic Grate PDSG100/ADSG100
PDS6000FA ADS6001FA 6” W/ Full Aluminum Grate SDSG100A
PDS6000FB ADS6001FB 6” W/ Full Brass Grate SDSG100B
PDS6000FN ADS6001FN 6” W/ Full Nickel Grate SDSG100N
PDS6000H ADS6001H 6” W/ 1/2 Plastic Grate PDSG50/ADSG50
PDS6000T ADS6001T 6” W/ 3/4 Plastic Grate PDSG75/ADSG75

PART #

PVC ABS SIZE DESCRIPTION GRATE

6” Round Deep Sump Receptor Drain

x Fits over 6” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

(Check for Availability)

1/2 & 3/4 Plastic
Grates Av ailable

PART #

PVC ABS SIZE DESCRIPTION GRATE

RDS6000 RDS6001 6” W/ no Grate
RDS6000F RDS6001F 6” W/ Full Plastic Grate PDSG100/ADSG100
RDS6000FA RDS6001FA 6” W/ Full Aluminum Grate SDSG100A
RDS6000FB RDS6001FB 6” W/ Full Brass Grate SDSG100B
RDS6000FN RDS6001FN 6” W/ Full Nickel Grate SDSG100N
RDS6000H RDS6001H 6” W/ 1/2 Plastic Grate PDSG50/ADSG50
RDS6000T RDS6001T 6” W/ 3/4 Plastic Grate PDSG75/ADSG75

74

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Floor Sinks - 8”

8” Square Deep Sump Receptor Drain

1/2 & 3/4 Plastic
Grates Av ailable

x Fits over 8” Schedule 40 DWV pipe
x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 or 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DESCRIPTION GRATE

PDS8000 ADS8001 8” W/ no Grate
PDS8000F ADS8001F 8” W/ Full Plastic Grate PDSG100/ADSG100
PDS8000FA ADS8001FA 8” W/ Full Aluminum Grate SDSG100A
PDS8000FB ADS8001FB 8” W/ Full Brass Grate SDSG100B
PDS8000FN ADS8001FN 8” W/ Full Nickel Grate SDSG100N
PDS8000H ADS8001H 8” W/ 1/2 Plastic Grate PDSG50/ADSG50
PDS8000T ADS8001T 8” W/ 3/4 Plastic Grate PDSG75/ADSG75

(Check for Availability)

8” Round Deep Sump Receptor Drain

x Fits over 8” Schedule 40 DWV pipe
x 12” diameter top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel, and 1/2 and 3/4 plastic
x 5.5” deep sump area
x Interior surfaces are smooth and sloped for maximum flow (no corners or flat areas)
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate

PART #

1/2 & 3/4 Plastic
Grates Av ailable

PVC ABS SIZE DESCRIPTION GRATE

RDS8000 RDS8001 2” W/ no Grate
RDS8000F RDS8001F 8” W/ Full Plastic Grate PDSG100/ADSG100
RDS8000FA RDS8001FA 8” W/ Full Aluminum Grate SDSG100A
RDS8000FB RDS8001FB 8” W/ Full Brass Grate SDSG100B
RDS8000FN RDS8001FN 8” W/ Full Nickel Grate SDSG100N
RDS8000H RDS8001H 8” W/ 1/2 Plastic Grate PDSG50/ADSG50
RDS8000T RDS8001T 8” W/ 3/4 Plastic Grate PDSG75/ADSG75

(Check for Availability)

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

75

Floor Sinks - Shallow Sump

Shallow Sump Floor Sink With Secondary Strainer

x Fits over 2” or inside 3” Schedule 40 DWV pipe or over 3” or inside 4” Schedule 40 DWV pipe

x 12” diameter top, 54” square flow area

x 12” diameter grate available as Full, 1/2, and 3/4 grate in aluminum, brass, or nickel

x Medium duty drain with 4” height for slab installation

x Plastic secondary strainer

x Interior surfaces are sloped and smooth to allow maximum flow

3.00/

4.00

x Made of corrosive resistant plastic

x Threaded metal inserts for attaching grate

PART #

PVC ABS SIZE DECRIPTION GRATE STRAINER

PFS9230 AFS9231 2”x 3” W/ No Grate PSI304/ASI305
PFS9230FA AFS9231FA 2”x 3” W/ Full Aluminum Grate SP-11LFA PSI304/ASI305
PFS9230HA AFS9231HA 2”x 3” W/ 1/2 Aluminum Grate SP-11LHA PSI304/ASI305
PFS9230TA AFS9231TA 2”x 3” W/ 3/4 Aluminum Grate SP-11LTA PSI304/ASI305
PFS9230FB AFS9231FB 2”x 3” W/ Full Brass Grate SP-11LFB PSI304/ASI305
PFS9230HB AFS9231HB 2”x 3” W/ 1/2 Brass Grate SP-11LHB PSI304/ASI305
PFS9230TB AFS9231TB 2”x 3” W/ 3/4 Brass Grate SP-11LTB PSI304/ASI305
PFS9230FN AFS9231FN 2”x 3” W/ Full Nickel Grate SP-11LFN PSI304/ASI305
PFS9230HN AFS9231HN 2”x 3” W/ 1/2 Nickel Grate SP-11LHN PSI304/ASI305
PFS9230TN AFS9231TN 2”x 3” W/ 3/4 Nickel Grate SP-11LTN PSI304/ASI305

PFS9340 AFS9341 3”x 4” W/ No Grate PSI310/ASI311
PFS9340FA AFS9341FA 3”x 4” W/ Full Aluminum Grate SP-11LFA PSI310/ASI311
PFS9340HA AFS9341HA 3”x 4” W/ 1/2 Aluminum Grate SP-11LHA PSI310/ASI311
PFS9340TA AFS9341TA 3”x 4” W/ 3/4 Aluminum Grate SP-11LTA PSI310/ASI311
PFS9340FB AFS9341FB 3”x 4” W/ Full Brass Grate SP-11LFB PSI310/ASI311
PFS9340HB AFS9341HB 3”x 4” W/ 1/2 Brass Grate SP-11LHB PSI310/ASI311
PFS9340TB AFS9341TB 3”x 4” W/ 3/4 Brass Grate SP-11LTB PSI310/ASI311
PFS9340FN AFS9341FN 3”x 4” W/ Full Nickel Grate SP-11LFN PSI310/ASI311
PFS9340HN AFS9341HN 3”x 4” W/ 1/2 Nickel Grate SP-11LHN PSI310/ASI311
PFS9340TN AFS9341TN 3”x 4” W/ 3/4 Nickel Grate SP-11LTN PSI310/ASI311

76

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Catch Basin Drain

Plastic Catch Basin Drain

10.00

x 14” x 14” square top, 54” square flow area
x 12” diameter grate available in full plastic, aluminum, brass or nickel
x Made of corrosive resistant plastic
x Threaded metal inserts for attaching grate
x Provides maximum site drainage
x Can be formed to cement, clay and cast iron pipe
x Applications include parking lot corners, swimming pool wash-down areas, golf courses, or

other areas where heavy water drainage is expected

PART #

PVC ABS DESCRIPTION GRATE

PCB1200 ACB1201 W/ plastic grate PDSG100/ADSG100
PCB1200A ACB1201A W/ aluminum grate SDSG100A
PCB1200B ACB1201B W/ brass grate SDSG100B
PCB1200N ACB1201N W/ nickel grate SDSG100N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

77

“Friend of the Plumber”

Roof Drains

R

Order by Phone: [phone]

Order by fax: [phone]

www.plasticoddities.com

Roof Drains - 3”

Standard Roof Drain

x Fits over 3” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PRD900 ARD901 3” Roof drain w/ cast iron dome SP-61C

3.50

4.00

4.00

PRD900P ARD901P 3” Roof drain w/ plastic dome SP-61P
PRD900A ARD901A 3” Roof drain w/ aluminum dome SP-61A
PRD900B ARD901B 3” Roof drain w/ brass dome SP-61B
PRD900N ARD901N 3” Roof drain w/ nickel dome SP-61N

Standard Overflow Roof Drain

x Fits over 3” Schedule 40 DWV pipe

3.50

4.00

x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

7.20

x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp
x Available tapped for trap primer

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PRD900WD ARD901WD 3” Overflow roof drain w/ cast iron dome SP-61C
PRD900PWD ARD901PWD 3” Overflow roof drain w/ plastic dome SP-61P
PRD900AWD ARD901AWD 3” Overflow roof drain w/ aluminum dome SP-61A
PRD900BWD ARD901BWD 3” Overflow roof w/ brass dome SP-61B
PRD900NWD ARD901NWD 3” Overflow roof drain w/ nickel dome SP-61N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

81

Roof Drains - 3”

(Continued)

Roof Drain With Plastic Receiver Pan

x Fits over 3” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

4.00

3.50

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9001 AWF9011 3” Roof drain w/ cast iron dome SP-61C
PWF9001P AWF9011P 3” Roof drain w/ plastic dome SP-61P
PWF9001A AWF9011A 3” Roof drain w/ aluminum dome SP-61A
PWF9001B AWF9011B 3” Roof drain w/ brass dome SP-61B
PWF9001N AWF9011N 3” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Plastic Receiver Pan

x Fits over 3” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan

7.20

x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)
x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp

4.00

3.50

4.00

x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9001WD AWF9011WD 3” Overflow roof drain w/ cast iron dome SP-61C
PWF9001PWD AWF9011PWD 3” Overflow roof drain w/ plastic dome SP-61P
PWF9001AWD AWF9011AWD 3” Overflow roof drain w/ aluminum dome SP-61A
PWF9001BWD AWF9011BWD 3” Overflow roof w/ brass dome SP-61B
PWF9001NWD AWF9011NWD 3” Overflow roof drain w/ nickel dome SP-61N

82

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Roof Drains - 3”

(Continued)

Roof Drain With Receiver Pan & Under-deck Clamp

x Fits over 3” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and under-deck clamp
x Available tapped for trap primer

4.00

3.50

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9002 AWC9012 3” Roof drain w/ cast iron dome SP-61C
PWC9002P AWC9012P 3” Roof drain w/ plastic dome SP-61P
PWC9002A AWC9012A 3” Roof drain w/ aluminum dome SP-61A
PWC9002B AWC9012B 3” Roof drain w/ brass dome SP-61B
PWC9002N AWC9012N 3” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Receiver Pan & Under-deck Clamp

11.22

3.50

4.00

x Fits over 3” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

4.00

x Threaded metal inserts for attaching dome, water dam, and under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9002WD AWC9012WD 3” Overflow roof drain w/ cast iron dome SP-61C
PWC9002PWD AWC9012PWD 3” Overflow roof drain w/ plastic dome SP-61P
PWC9002AWD AWC9012AWD 3” Overflow roof drain w/ aluminum dome SP-61A
PWC9002BWD AWC9012BWD 3” Overflow roof w/ brass dome SP-61B
PWC9002NWD AWC9012NWD 3” Overflow roof drain w/ nickel dome SP-61N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

83

Roof Drains - 4”

Standard Roof Drain

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PRD902 ARD903 4” Roof drain w/ cast iron dome SP-61C

4.50

5.00

4.20

PRD902P ARD903P 4” Roof drain w/ plastic dome SP-61P
PRD902A ARD903A 4” Roof drain w/ aluminum dome SP-61A
PRD902B ARD903B 4” Roof drain w/ brass dome SP-61B
PRD902N ARD903N 4” Roof drain w/ nickel dome SP-61N

Standard Overflow Roof Drain

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

7.20

x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp
x Available tapped for trap primer

4.20

4.50

5.00

PRD902WD ARD903WD 4” Overflow roof drain w/ cast iron dome SP-61C
PRD902PWD ARD903PWD 4” Overflow roof drain w/ plastic dome SP-61P
PRD902AWD ARD903AWD 4” Overflow roof drain w/ aluminum dome SP-61A
PRD902BWD ARD903BWD 4” Overflow roof w/ brass dome SP-61B
PRD902NWD ARD903NWD 4” Overflow roof drain w/ nickel dome SP-61N

PART #

PVC ABS SIZE DESCRIPTION DOME

84

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Roof Drains - 4”

(Continued)

Roof Drain With Plastic Receiver Pan

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

4.20

4.50

5.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9021 AWF9031 4” Roof drain w/ cast iron dome SP-61C
PWF9021P AWF9031P 4” Roof drain w/ plastic dome SP-61P
PWF9021A AWF9031A 4” Roof drain w/ aluminum dome SP-61A
PWF9021B AWF9031B 4” Roof drain w/ brass dome SP-61B
PWF9021N AWF9031N 4” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Plastic Receiver Pan

4.50

5.00

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan

7.20

x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)
x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp

4.20

x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9021WD AWF9031WD 4” Overflow roof drain w/ cast iron dome SP-61C
PWF9021PWD AWF9031PWD 4” Overflow roof drain w/ plastic dome SP-61P
PWF9021AWD AWF9031AWD 4” Overflow roof drain w/ aluminum dome SP-61A
PWF9021BWD AWF9031BWD 4” Overflow roof w/ brass dome SP-61B
PWF9021NWD AWF9031NWD 4” Overflow roof drain w/ nickel dome SP-61N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

85

Roof Drains - 4”

(Continued)

Roof Drain With Receiver Pan & Under-deck Clamp

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and under-deck clamp
x Available tapped for trap primer

4.00

3.50

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9022 AWC9032 4” Roof drain w/ cast iron dome S P-6 1C
PWC9022P AWC9032P 4” Roof drain w/ plastic dome SP-61P
PWC9022A AWC9032A 4” Roof drain w/ aluminum dome SP-61A
PWC9022B AWC9032B 4” Roof drain w/ brass dome SP-61B
PWC9022N AWC9032N 4” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Receiver Pan & Under-deck Clamp

x Fits over 4” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

11.22

3.50

4.00

4.00

x Threaded metal inserts for attaching dome, water dam, and under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9022WD AWC9032WD 4” Overflow roof drain w/ cast iron dome SP-61C
PWC9022PWD AWC9032PWD 4” Overflow roof drain w/ plastic dome SP-61P
PWC9022AWD AWC9032AWD 4” Overflow roof drain w/ aluminum dome SP-61A
PWC9022BWD AWC9032BWD 4” Overflow roof w/ brass dome SP-61B
PWC9022NWD AWC9032NWD 4” Overflow roof drain w/ nickel dome SP-61N

86

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Roof Drains - 6”

Standard Roof Drain

x Fits inside 6” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PRD908 ARD909 6” Roof drain w/ cast iron dome SP-61C

5.50

6.00

4.00

PRD908P ARD909P 6” Roof drain w/ plastic dome SP-61P
PRD908A ARD909A 6” Roof drain w/ aluminum dome SP-61A
PRD908B ARD909B 6” Roof drain w/ brass dome SP-61B
PRD908N ARD909N 6” Roof drain w/ nickel dome SP-61N

Standard Overflow Roof Drain

x Fits over 3” Schedule 40 DWV pipe

5.50

6.00

x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

7.20

x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp
x Available tapped for trap primer

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PRD908WD ARD909WD 6” Overflow roof drain w/ cast iron dome SP-61C
PRD908PWD ARD909PWD 6” Overflow roof drain w/ plastic dome SP-61P
PRD908AWD ARD909AWD 6” Overflow roof drain w/ aluminum dome SP-61A
PRD908BWD ARD909BWD 6” Overflow roof w/ brass dome SP-61B
PRD908NWD ARD909NWD 6” Overflow roof drain w/ nickel dome SP-61N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

87

Roof Drains - 6”

(Continued)

Roof Drain With Plastic Receiver Pan

x Fits inside 6” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and optional under-deck clamp
x Available tapped for trap primer

4.80

5.50

6.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9081 AWF9091 6” Roof drain w/ cast iron dome SP-61C
PWF9081P AWF9091P 6” Roof drain w/ plastic dome SP-61P
PWF9081A AWF9091A 6” Roof drain w/ aluminum dome SP-61A
PWF9081B AWF9091B 6” Roof drain w/ brass dome SP-61B
PWF9081N AWF9091N 6” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Plastic Receiver Pan

x Fits inside 6” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan

7.20

x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)
x Threaded metal inserts for attaching dome, water dam, and optional under-deck clamp

4.80

5.50

6.00

x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWF9081WD AWF9091WD 6” Overflow roof drain w/ cast iron dome SP-61C
PWF9081PWD AWF9091PWD 6” Overflow roof drain w/ plastic dome SP-61P
PWF9081AWD AWF9091AWD 6” Overflow roof drain w/ aluminum dome SP-61A
PWF9081BWD AWF9091BWD 6” Overflow roof w/ brass dome SP-61B
PWF9081NWD AWF9091NWD 6” Overflow roof drain w/ nickel dome SP-61N

88

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Roof Drains - 6”

(Continued)

Roof Drain With Receiver Pan & Under-deck Clamp

x Fits inside 6” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/gravel guard
x 16” diameter receiver pan
x Threaded metal inserts for attaching dome, gravel guard, and under-deck clamp
x Available tapped for trap primer

4.00

3.50

4.00

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9082 AWC9092 6” Roof drain w/ cast iron dome SP-6 1C
PWC9082P AWC9092P 6” Roof drain w/ plastic dome SP-61P
PWC9082A AWC9092A 6” Roof drain w/ aluminum dome SP-61A
PWC9082B AWC9092B 6” Roof drain w/ brass dome SP-61B
PWC9082N AWC9092N 6” Roof drain w/ nickel dome SP-61N

Overflow Roof Drain With Receiver Pan & Under-deck Clamp

11.22

3.50

4.00

x Fits inside 6” Schedule 40 DWV pipe
x Dome available in plastic, cast iron, aluminum, nickel, or brass
x Dome free area 50 sq. inches
x Dome bolted to clamping collar/water dam
x 16” diameter receiver pan
x Water dam available in 2” high plastic or 1”, 2” or 3” high aluminum (Specify when ordering)

4.00

x Threaded metal inserts for attaching dome, water dam, and under-deck clamp
x Available tapped for trap primer

PART #

PVC ABS SIZE DESCRIPTION DOME

PWC9082WD AWC9092WD 6” Overflow roof drain w/ cast iron dome SP-61C
PWC9082PWD AWC9092PWD 6” Overflow roof drain w/ plastic dome SP-61P
PWC9082AWD AWC9092AWD 6” Overflow roof drain w/ aluminum dome SP-61A
PWC9082BWD AWC9092BWD 6” Overflow roof w/ brass dome SP-61B
PWC9082NWD AWC9092NWD 6” Overflow roof drain w/ nickel dome SP-61N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

89

Miscellaneous Roof Drain Products

Water Dam For Overflow Roof Drains

x Converts roof drain to an overflow roof drain
x Made of cast aluminum in 1”, 2”, and 3” heights
x Plastic available in 2” only

PART# DESCRIPTION

1.00/

2.00/

3.00

MWD100A Aluminum 1” Water Dam for Roof Drains
MWD200A Aluminum 2” Water Dam for Roof Drains

MWD300A Aluminum 3” Water Dam for Roof Drains
PSP50WD Plastic 2” Water Dam for Roof Drains

16” Diameter Roof Drain Receiver Pan

x 16” receiver pan converts basic roof drain to a wide flange, flat pan assembly

PART# SIZE DESCRIPTION

PRD16 16” PVC Roof Drain Receiver Pan

ARD16 16” ABS Roof Drain Receiver Pan

Under-Deck Clamp Kit For 3” & 4” Roof Drains

x Kit includes 2 piece black styrene clamp, 4 threaded studs, 4 nuts,

and 4 washers

PART# DESCRIPTION

UDC990 Under Deck Clamp Kit

Under Deck Clamp Kit For 6” Roof Drains

x Kit includes 2 piece metal clamp, mounting collar, 4 threaded

studs, 4 nuts, and 4 washers

PART# DESCRIPTION

UDC996 Clamp Kit for 6” Roof Drai ns

Roof Drain Gravel Guard

x Plastic gravel guard for roof drains

PART # DESCRIPTI ON

PSP60 Plastic Gravel Guard

90

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Cleanouts

“Friend of the Plumber”

Order by Phone: [phone]

Order by fax: [phone]

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

www.plasticoddities.com

91

General Purpose Access

3” x 4” Pipe Fit General Purpose Access with Cover

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 5” diameter cast metal covers available with round or square ring
x Cover also available in nickel

PART #

5.00

PVC ABS SIZE DESCRIPTION COVER

PGI512 AGI513 3”x 4” W/ 5” Scoriated Brass Cover SP-7BS
PGI512R AGI513R 3”x 4” W/ 5” Scoriated Brass Cover, Round Ring SP-7BS

3.50

4.00

PGI512RS AGI513RS 3”x 4” W/ 5” Scoriated Brass Cover, Square Ring SP-7BS

3” x 4” Pipe Fit General Purpose Cleanout with Cover

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 5” diameter cast metal covers available with round or square ring
x Cover also available in nickel

5.00

3.00

3.50

4.00

x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

PGI516 AGI517 3”x 4” W/ 5” Scoriated Brass Cover SP-7BS
PGI516R AGI517R 3”x 4” W/ 5” Scoriated Brass Cover, Round Ring SP-7BS
PGI516RS AGI517RS 3”x 4” W/ 5” Scoriated Brass Cover, Square Ring SP-7BS

4” Over Pipe Fit General Purpose Access with Cover

x Fits over 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 6” diameter cast metal covers available with round or square ring
x Cover also available in nickel

PART #

6.00

4.50

5.00

PVC ABS SIZE DESCRIPTION COVER

PGI612 AGI613 4” W/ 6” Scoriated Brass Cover SP-9BS
PGI612R AGI613R 4” W/ 6” Scoriated Brass Cover, Round Ring SP-9BS
PGI612RS AGI613RS 4” W/ 6” Scoriated Brass Cover, Square Ring SP-9BS
PGI614 AGI615 4” W/ 6” Scoriated Plastic Cover SP-9P
PGI614R AGI615R 4” W/ 6” Scoriated Plastic Cover, Round Brass Ring SP-9P
PGI614RS AGI615RS 4” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

93

General Purpose Access

(Continued)

4” Over Pipe Fit General Purpose Cleanout with Cover

x Fits over 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 6” diameter cast metal covers available with round or square Ring
x Cover also available in nickel

5.00

x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

3.00

3.50

4.00

PGI622 AGI623 4” W/ 6” Scoriated Brass Cover SP-9BS
PGI622R AGI623R 4” W/ 6” Scoriated Brass Cover, Round Ring SP-9BS
PGI622RS AGI623RS 4” W/ 6” Scoriated Brass Cover, Square Ring SP-9BS
PGI624 AGI625 4” W/ 6” Scoriated Plastic Cover SP-9P
PGI624R AGI625R 4” W/ 6” Scoriated Plastic Cover, Round Brass Ring SP-9P
PGI624RS AGI625RS 4” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

Snap-In Access with Cover

x Fits inside 2”, inside 3” or inside 4” Schedule 40 DWV pipe
x Allows cutting pipe flush with floor
x Available as an all-plastic unit or a plastic body with stamped stainless steel cover

PART #

2.38/ 3.50/ 4.50

2.00/ 3.00/ 4.00

1.00/

1.75/

1.75

PVC ABS SIZE DESCRIPTION COVER

PAC3060 AAC3070 3” W/ Stamped SS Cover SP-230
PAC3080 AAC3090 4” W/ Stamped SS Cover SP-240

PAC3040 AAC3050 2” All plastic
PAC3100 AAC3110 3” All Plastic
PAC3120 AAC3130 4” All Plastic

Stainless Steel Cleanout Access Cover with Screw

x Made of stainless steel
x 1/4" x 2" screw included

PART # SIZE DESCRIPTION

SSA300 3" Stainless Steel Cover w/ Screw
SSA400 4" Stainless Steel Cover w/ Screw
SSA500 5" Stainless Steel Cover w/ Screw
SSA600 6" Stainless Steel Cover w/ Screw
SSA800 8" Stainless Steel Cover w/ Screw

94

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Exposed Plug Cleanouts

Snap-In Pipe-Fit Cleanout with Plug

x Fits over 2” or inside 3” Schedule 40 DWV pipe or over 3” or inside 4” Schedule 40 DWV pipe
x Available with recessed head plastic plug, recessed head brass plug, or raised head brass plug

PART #

PVC ABS SIZE DESCRIPTION

PSC23 ASC23 2”x3” W/ Recessed Head Plastic Plug
PSC23BP ASC23BP 2”x3” W/ Recessed Head Brass Plug

1.75/

2.50

PSC23BH ASC23BH 2”x3” W/ Raised Head Brass Plug

2.50/ 3.50

3.00/ 4.00

PSC34 ASC34 3”x4” W/ Recessed Head Plastic Plug
PSC34BP ASC34BP 3”x4” W/ Recessed Head Brass Plug
PSC34BH ASC34BH 3”x4” W/ Raised Head Brass Plug

Snap-In Flush-Fit Cleanout with Plug

x Fits flush inside 3” or 4” Schedule 40 DWV pipe
x Available with recessed head plastic plug, recessed head brass plug, or raised head brass plug

PART #

PVC ABS SIZE DESCRIPTION

PSC3 ASC3 3” W/ Recessed Hea d Plastic Plug
PSC3BP ASC3BP 3” W/ Recessed Head Brass Plug

1.25/ 1.50

3.00/ 4.00

PSC3BH ASC3BH 3” W/ Raised Head Brass Plug
PSC4 ASC4 4” W/ Recessed Hea d Plastic Plug
PSC4BP ASC4BP 4” W/ Recessed Head Brass Plug
PSC4BH ASC4BH 4” W/ Raised Head Brass Plug

Snap-In Hub Fit Cleanout with Plug

x Fits inside 2”, 3”, or 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x Eliminates cutting and installing additional pipe when using conventional cleanouts
x Available with recessed head plastic plug, recessed head brass plug, or raised head brass plug

PART #

PVC ABS SIZE DESCRIPTION

PCA2 ACA2 2” W/ Recessed Head Plastic Plug
PCA2BH ACA2BH 2” W/ Raised Hea d Brass Plug
PCA2BP ACA2BP 2” W/ Recessed Head Brass Plug
PCA3 ACA3 3” W/ Recessed Head Plastic Plug
PCA3BH ACA3BH 3” W/ Raised Hea d Brass Plug
PCA3BP ACA3BP 3” W/ Recessed Head Brass Plug
PCA4 ACA4 4” W/ Recessed Head Plastic Plug
PCA4BH ACA4BH 4” W/ Raised Hea d Brass Plug
PCA4BP ACA4BP 4” W/ Recessed Head Brass Plug

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

95

Adjustable Cleanouts - 2” x 3”

Exposed Plug Cleanouts

(Continued)

Over Pipe Fit General Purpose Cleanout with Plug

x Fits over 4” or over 6” Schedule 40 DWV pipe
x Available with raised or recessed head brass plug for heavy-duty applications

PART #

PVC ABS SIZE DESCRIPTION

PSC400 ASC400 4” W/ Recessed Head Plastic Plug
PSC400BP ASC400BP 4” W/ Recessed Head Brass Plug

3.50/

5.00

PSC400BH ASC400BH 4” W/ Raised Head Brass Plug

4.50/ 6.75

5.00/ 7.25

PSC600BP ASC600BP 6” W/ Recessed Head Brass Plug
PSC600BH ASC600BH 6” W/ Raised Head Brass Plug

Plastic Utility Cleanout with Access Cover

x Fits over 2” or inside 3” Schedule 40 DWV pipe

x All plastic construction with no metal parts to rust or corrode

x 6” diameter cover with 4” threads screws flush into body

x Load tested to 6500 lbs.

PART #

PVC ABS SIZE DESCRIPTION COVER

PTC208 ATC209 2”x 3” All Plastic Cleanout PUM216/AUM217

Adjustable Cleanout with Cover

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x For general purpose access requirements
x 4” diameter cast metal covers available with round or square ring
x Cover also available in nickel
x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

PCO230 ACO231 2”x 3” W/ 4” Scoriated Brass Cover SP-5BS
PCO230R ACO231R 2”x 3” W/ 4” Scoriated Brass Cover, Round Ring SP-5BS

PCO230RS ACO231RS 2”x 3” W/ 4” Scoriated Brass Cover, Square Ring SP-5BS

Adjustable Cleanout with Cover and Metal Tailpiece

x Fits over 2” or inside 3” Schedule 40 DWV pipe
x For general purpose cleanout requirements
x 4” diameter cast metal cover
x Comes with a 1.5" brass recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

PCO240B ACO241B 2”x 3” W/ 4” Scoriated Brass Cover SP-5BS
PCO240N ACO241N 2”x 3” W/ 4” Scoriated Nickel Cover SP-5N

96

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Adjustable Cleanouts - 4”

Adjustable Cleanouts - 3” x 4”

Adjustable General Purpose Cleanout with Cover

4” Inside Hub Fit Adjustable Cleanout with Cover

x Fits over 3” or inside 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 6” diameter cast metal covers available with round or square ring
x Cover also available in nickel
x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

PCO734 ACO735 3”x 4” W/ 6” Scoriated Brass Cover SP-9BS
PCO734R ACO735R 3”x 4” W/ 6” Scoriated Brass Cover, Round Ring SP-9BS
PCO734RS ACO735RS 3”x 4” W/ 6” Scoriated Brass Cover, Square Ring SP-9BS
PCO736 ACO737 3”x4” W/ 6” Scoriated Plastic Cover SP-9P
PCO736RS ACO737RS 3”x4” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

x Fits inside 4” Schedule 40 DWV hub (elbow, tee, coupling, etc.)
x For general purpose access requirements
x 6” diameter cast metal covers available with round or square ring
x Cover also available in nickel
x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

PCO700 ACO701 4” W/ 6” Scoriated Brass Cover SP-9BS

PCO700 / PCO702
ARE UPC LISTED

PCO700R ACO701R 4” W/ 6” Scoriated Brass Cover, Round Ring SP-9BS
PCO700RS ACO701RS 4” W/ 6” Scoriated Brass Cover, Square Ring SP-9BS
PCO702 ACO703 4” W/ 6” Scoriated Plastic Cover SP-9P
PCO702RS ACO703RS 4” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

4” Over Pipe Fit Adjustable Cleanout with Cover and Metal Tailpiece

x Fits over 4” Schedule 40 DWV pipe
x For general purpose access requirements
x 6” diameter cast metal covers available with round or square ring
x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

MCO400B MCO401B 4” W/ 6” Scoriated Brass Cover SP-9BS
MCO400BRS MCO401BRS 4” W/ 6” Scoriated Brass Cover & Square Ring SP-9BS
MCO400N MCO401N 4” W/ 6” Scoriated Nickel Cover SP-9N
MCO400NRS MCO401NRS 4” W/ 6” Scoriated Nickel Cover & Square Ring SP-9N

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

97

Adjustable Heavy Duty Cleanouts

Adjustable Cleanouts - 6”

6” Over Pipe Fit Adjustable Cleanout with Cover

x Fits over 6” Schedule 40 DWV pipe
x For general purpose access requirements
x 8” diameter cast metal cover
x Comes with plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

MCO600B MCO601B 6” W/ 8” Scoriated Brass Cover SP-750BS

MCO600N MCO601N 6” W/ 8” Scoriated Nickel Cover SP-750N

3” Over Pipe Fit Heavy Duty Cleanout with Clamping Collar and Cover

x Fits over 3” Schedule 40 DWV pipe
x Threaded barrel and clamping collar allow for height adjustment
x 6” cast metal covers available with round or square ring
x Cover also available in nickel
x Plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

3.50

4.00

4.00

PHC630 AHC631 3” W/ 6” Scoriated Brass Cover SP-9BS
PHC630R AHC631R 3” W/ 6” Scoriated Brass Cover and Round Ring SP-9BS
PHC630RS AHC631RS 3” W/ 6” Scoriated Brass Cover and Square Ring SP-9BS
PHC650 AHC651 3” W/ 6” Scoriated Plastic Cover SP-9P
PHC650RS AHC651RS 3” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

4” Over Pipe Fit Heavy Duty Cleanout with Clamping Collar and Cover

x Fits over 4” Schedule 40 DWV pipe
x Threaded barrel and clamping collar allow for height adjustment
x 6” cast metal covers available with round or square ring
x Cover also available in nickel
x Plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

4.50

5.00

4.20

PHC640 AHC641 4” W/ 6” Scoriated Brass Cover SP-9BS
PHC640R AHC641R 4” W/ 6” Scoriated Brass Cover and Round Ring SP-9BS
PHC640RS AHC641RS 4” W/ 6” Scoriated Brass Cover and Square Ring SP-9BS
PHC652 AHC653 4” W/ 6” Scoriated Plastic Cover SP-9P
PHC652RS AHC653RS 4” W/ 6” Scoriated Plastic Cover, Square Brass Ring SP-9P

98

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]

Cleanout Plug

Adjustable Heavy Duty Cleanouts

(Continued)

6” Inside Pipe Fit Heavy Duty Cleanout with Clamping Collar and Cover

x Fits inside 6” Schedule 40 DWV pipe
x Threaded barrel and clamping collar allow for height adjustment
x 6” diameter cast metal covers available with round or square ring
x Cover also available in nickel
x Plastic recessed head cleanout plug

PART #

PVC ABS SIZE DESCRIPTION COVER

5.50

6.00

4.85

PHC662 AHC663 6 ” W/ 6” Scoriated Brass Cover SP-9BS
PHC662R AHC663R 6” W/ 6” Scoriated Brass Cover and Round Ring SP-9BS
PHC662RS AHC663RS 6” W/ 6” Scoriated Brass Cover and Square Ring SP-9BS

PHC664 AHC665 6” W/ 6” Scoriated Plastic Cover SP-9P
PHC664RS AHC665RS 6” W/ 6” Scoriated Plastic Cover and Square Ring SP-9P

Plastic Recessed Head Cleanout Plug

x Recessed slot is designed to accept t-slot tool or 3/4” drive ratchet
x Also available with metal insert to allow mounting an access cover

PART #

PVC ABS SIZE DESCRIPTION

PRP2 ARP2 2” Plastic Plug
PRP25 ARP25 2.5” Plastic Plug
PRP3 ARP3 3” Plastic Plug
PRP35 ARP35 3.5” Plastic Plug
PRP4 ARP4 4” Plastic Plug

PIP2 AIP2 2” Plastic Plug w/ Metal Insert
PIP25 AIP25 2.5” Plastic Plug w/ Metal Insert
PIP3 AIP3 3” Plastic Plug w/ Metal Insert
PIP35 AIP35 3.5” Plastic Plug w/ Metal Insert
PIP4 AIP4 4” Plastic Plug w/ Metal Insert

Brass Recessed Head Cleanout Plug

x Made of cast brass
x Recessed head with square slot

PART # SIZE DESCRIPTION

BRP150 1.5” Recessed Head Plug

BRP200 2” Recessed Head Plug
BRP250 2.5” Recessed Head Plug
BRP300 3” Recessed Head Plug
BRP350 3.5” Recessed Head Plug
BRP400 4” Recessed Head Plug
BRP600 6” Recessed Head Plug

Order by Phone: [phone] Order by Fax: [phone]

www.plasticoddities.com

99

Test Caps and End Caps

Cleanout Plugs

(Continued)

Brass Recessed Head Cleanout Plug with Tap

x Made of cast brass
x Recessed head with square slot
x Threaded center section to allow mounting an access cover

PART # SIZE DESCRIPTION

BIP150 1.5” Recessed Plug w/ Threaded Center

BIP200 2” Recessed Plug w/ Threaded Center
BIP250 2.5” Recessed Plug w/ Threaded Center
BIP300 3” Recessed Plug w/ Threaded Center
BIP350 3.5” Recessed Plug w/ Threaded Center
BIP400 4” Recessed Plug w/ Threaded Center
BIP600 6” Recessed Plug w/ Threaded Center

Brass Raised Head Cleanout Plug

x Made of cast brass
x Raised head provides easy access

PART # SIZE DESCRIPTION

BRH150 1.5” Raised Head Plug

BRH200 2 ” Raised Head Plug
BRH250 2.5” Raised Head Plug
BRH300 3 ” Raised Head Plug
BRH350 3.5” Raised Head Plug
BRH400 4 ” Raised Head Plug
BRH600 6 ” Raised Head Plug

Dual Fit Test Cap

PDF152

PDF314

x Fits over 1.5” or 2” or over 3”or 4” Schedule 40 DWV pipe
x Rim is 0.5” deep and wall sections are 0.5” thick to withstand

greater test pressure

PART #

PVC ABS SIZE DESCRIPTION

PDF152 ADF153 1.5”x 2” Dual Fit Test Cap (Bag of 50)
PDF314 ADF315 3”x4” Dual Fit Test Cap (Bag of 25)

Knock-Out Test Cap

x Finger-hold molded in for ease of solvent applicatio n

PART# SIZE DESCRIPTION

STP020 2” Knock Out Test Cap, Bag of 100
STP030 3” Knock Out Test Cap, Bag of 50
STP040 4” Knock Out Test Cap, Bag of 50

100

www.plasticoddities.com

Order by Phone: [phone] Order by Fax: [phone]
