Plantronics V815 User Manual

BLUETOOTH® HEADSET
User Guide
Guía del Usuario
TABLE OF CONTENTS
Welcome 3
What is Bluetooth? 3
Package Contents & Features 4
Charging 5
Pairing 6
Custom Fit 8
Headset Controls 11
Indicators 13
Range 13
Hands-Free Features 14
Multipoint (Using more than one Bluetooth device) 15
Optional Accessories 16
Troubleshooting 17
Product Specifications 18
Technical Assistance 18
Limited Warranty 18
Important Safety and Operational Information 19
Regulatory Notices 21
2
Plantronics Voyager 815
WELCOME
Thank you for choosing the Plantronics Voyager™ 815 headset. To get the most from your new headset, we recommend that you take the following steps:
Read this User Guide, including all the safety information at the end of this
1.
guide, before you use your headset.
If you need assistance, please do the following:
2.
Follow the steps in the “Troubleshooting” section on page 17.
•
Contact the Plantronics Technical Assistance Center at 866-363-BLUE (2583)
•
or visit www.plantronics.com/support.
Visit www.plantronics.com/productregistration to register your headset online,
3.
so we can provide you with the best possible service and technical support.
NOTE: If you are considering returning the product, please contact the Technical
Assistance Center first.
WHAT IS Bluetooth?
Bluetooth wireless technology provides a way for devices to communicate with each other using short-range radio frequency instead of wires. Any two Bluetooth devices can communicate as long as they both have Bluetooth turned on, they are within range, and they have been paired–a quick “handshake” that connects the two devices.
Bluetooth range is up to 33 feet (10 meters). Obstructions, such as walls or other electronic devices, can cause interference or shorten the effective range. For optimal performance, place your headset and phone on the same side of your body.
Plantronics Voyager 815
3
PACKAGE CONTENTS & FEATURES
1
5
4
6
7
2
3
Call control button (on/off)
1.
Mute microphone button
2.
Volume up/down
3.
Extendable boom
4.
Microphone port
5.
Ear loop stabilizer
6.
Noise isolating ear buds
7.
(small, medium, and large)
AC Charger 100 – 240V
8.
8
4
Plantronics Voyager 815
CHARGING
Before you use your headset for the first time, charge it for at least 1 hour. It takes approximately 3 hours to fully charge your headset.
Connect the charger cable to the headset.
1.
Plug the charger into a power outlet.
2.
While your headset is charging the indicator glows red. When your headset is fully charged, the indicator turns off.
WARNING: Do not use your headset while it is connected to the charger.
CHECK THE CHARGE LEVEL
When your headset is on, simultaneously press and hold the call control button and the volume down button for about two seconds. The indicator flashes red to show the charge level.
Red Flashes Battery Level
1 More than 2/3 full 2 1/3 to 2/3 full 3 Less than 1/3 full
Plantronics Voyager 815
5
PAIRING
Pairing is the process of introducing your headset to your phone. Before using your headset for the first time, you must pair it with your Bluetooth phone. Normally you need to pair your headset with your phone only once. To see a demo of the pairing process, visit www.plantronics.com/easytopair.
QUICKPAIR™ TECHNOLOGY
Your new headset includes Plantronics QuickPair technology to simplify the Bluetooth setup process. The first time you turn your headset on, your headset automatically enters pairing mode for 10 minutes. Once paired successfully, your headset stays on for instant use.
If not successfully paired after 10 minutes, your headset automatically powers off. When you turn the headset on again, it automatically goes into pairing mode until successfully paired with a Bluetooth phone.
To pair your headset for the first time:
Turn ON the Bluetooth feature on your phone.
1.
2
3
1
4
TIP: For most phones, select Settings/Tools > Connections > Bluetooth > On.
See your phone’s user guide for more information.
Press and hold the call control button to turn on your headset. (The indicator
2.
flashes red/blue to show that the headset is on and in pairing mode.)
TIP: If you don’t see the red/blue flash, press and hold the call control
button to turn your headset off, and then press and hold the call control button again until you see the red/blue flash.
Use the commands on your phone to locate your headset.
3.
TIP: For most phones, select Settings/Tools > Connections > Bluetooth >
Search > 8XXPlantronics. See your phone’s user guide for more information.
When prompted for the passkey, enter 0000.
4.
When pairing is successful, the red/blue indicator on your headset turns off. Your headset is now connected and ready to use.
6
Plantronics Voyager 815
SUBSEQUENT PAIRING
If you’ve already paired your headset with another device, follow these steps:
Turn ON the Bluetooth feature on your phone.
1.
TIP: For most phones, select Settings/Tools > Connections > Bluetooth >
On. See your phone’s user guide for more information.
Turn the headset off by pressing and holding the call control button until the
2.
indicator turns red and then turns off.
Turn the headset back on by pressing and holding the call control button until
3.
the indicator flashes red/blue. The headset remains in pairing mode for 3 minutes.
Use the commands on your phone to locate your headset.
4.
TIP: For most phones, select Settings/Tools > Connections >
Bluetooth > Search > 8XXPlantronics. See your phone’s user guide for more information.
When prompted for the passkey, enter 0000.
5.
When pairing is successful, the indicator on your headset turns off. Your headset is now connected and ready to use.
Plantronics Voyager 815
7
CUSTOM FIT
The Plantronics Voyager 815 headset comes with three sizes of noise isolating ear buds. We recommend that you try all three ear buds to find the one that fits snugly in your ear. For added comfort and stability you can add the optional ear loop.
TIPS:
For optimum performance and a secure and comfortable fit, the headset
•
should sit snugly in your ear canal with the microphone pointing towards the corner of your mouth.
If the ear bud is too big or too small, the headset may not stay in your ear, or
•
you may have difficulty hearing.
PUT ON THE HEADSET
Hold the headset with the boom pointing directly at your cheekbone and the
1.
ear bud placed comfortably in your ear canal.
Gently twist the headset downward while pressing it into your ear canal.
2.
TIP: For optimal voice clarity, point the boom towards the corner of your
mouth. The ear bud should be fully seated to the speaker post to ensure secure attachment.
WARNING: Select an ear bud that inserts comfortably in the ear canal.
The ear bud should seal but not be forced down the ear canal. If the ear bud becomes lodged in the ear canal, seek medical attention immediately.
8
Plantronics Voyager 815
CHOOSE AN EAR BUD THAT FITS
When the ear bud fits properly, it should be sealed in your ear so that you feel a slight amount of resistance when you remove the headset from your ear.
Remove the headset from your ear.
1.
Gently twist the ear bud while pulling it off the speaker post.
2.
Press a different ear bud onto the speaker post with the stem side of the ear
3.
bud facing downward.
Plantronics Voyager 815
9
USE THE OPTIONAL EAR LOOP STABILIZER
For increased stability, you can attach the optional ear loop stabilizer.
TIP: You can attach the ear loop stabilizer on either side of your headset,
so that you can wear the headset on your right or left ear.
Insert the ear loop tab into the slot on the under side of the headset until you
1.
feel it click into place.
Guide the loop behind your ear.
2.
Gently twist headset downward while pressing it into your ear.
3.
TIP: To remove the ear loop stabilizer from your headset, gently pull the
ear loop straight out of its slot.
10
Plantronics Voyager 815
HEADSET CONTROLS
Action Steps
Turn on the headset
Turn off the headset
Answer a call Briefly press the call control button, or slide the boom to
Press and hold the call control button until the indicator glows blue.
NOTE: When your headset is in standby mode, the indicator is off.
To confirm that your headset is on, press any button or slide the boom out. You should see a blue light flash or hear a tone.
Press and hold the call control button until the indicator glows red. When the power is off, the indicator stays off.
the open position.
End a call Briefly press the call control button, or slide the boom to
Make a call The call automatically transfers to your headset after you
Toggle mute on/off
Turn off the online indicator
Adjust volume
WARNING: Do not use headphones / headsets at high volumes for an extended
period of time. Doing so can cause hearing loss. Always listen at moderate levels. See www.plantronics.com/healthandsafety for more information on headsets and hearing.
the closed position.
enter the number on your phone and press send.
Press the mute button.
Press and hold mute for 2 seconds while the headset is on. Headset will flash blue 4 times. Repeat action to activate online indicators. Headset will flash blue 2 times.
During an active call, press the volume button:
Volume up Volume down
Plantronics Voyager 815
11
TIPS
If you’re wearing the headset, you hear ascending tones when the power turns
•
on and descending tones when the power turns off.
When you receive a call, your phone may ring before your headset rings. Wait
•
until you hear the ring in your headset to press the call control button and
answer the call.
To reject a call and send the caller to voice mail, press the call control button for
•
about 2 seconds.
If your phone supports voice dialing see “Hands-Free Features” on page 14 and
•
the instructions that came with your phone.
When mute is on, a low tone plays every 60 seconds.
•
12
Plantronics Voyager 815
INDICATORS
Action Light Tone
Charging Solid red None Fully charged None None Low battery
Pairing Flashes red and blue 1 low tone Paired Flashes blue 1 low tone Turning on Solid blue for 2 seconds Ascending tones Standby None None Incoming call 3 blue flashes every 2 seconds 3 low tones every
Call in progress 1 blue flash every 2 seconds None
Missed call 3 purple flashes every 10 seconds None Out of range None 1 high tone Back in range None 1 low tone Turning mute on None 1 low-high tone Mute is active None 1 low tone every
Unmute None 1 high-low tone Turning off Solid red for 4 seconds Descending tones
NOTE: To turn off the online indicator, see “Headset Controls” on page 11.
3 red flashes every 10 seconds
3 high tones every 10 seconds
2 seconds
60 seconds
RANGE
To maintain a connection, keep your headset within 33 feet (10 meters) of the Bluetooth device. If there are obstacles between your headset and the device you may experience interference. For optimal performance, place your headset and phone on the same side of your body.
As you move out of range, audio quality degrades. When you are far enough away to lose the connection, you hear a high tone in the headset. The headset attempts to reconnect after 30 seconds. If you move back in range later, you can manually reconnect by pressing the call control button.
NOTE: Audio quality is also dependent upon the device with which the headset is
paired.
Plantronics Voyager 815
13
