Plantronics TRISTAR N81 User Manual

PARTS & ACCESSORIES

Cushions
for
Belltips

SMALL LARGE
P/N 29955-05 P/N 29955-06

Ear cushions should be replaced every
six months (or sooner, if soiled).

Cable to
Quick
Disconnect

P/N 26716-01

Connects amplifier to headset.
Replace when worn.

Stabilizer Cushion

P/N 41925-01

Improves general comfort
of headset by better securing
earloop behind ear.

Softip

SMALL LARGE
P/N 29955-01 P/N 29955-02

Available in packages of 4 or 10

.

Clothing Clip

P/N 29961-01

Attaches to headset cord, keeping
headset stabilized and comfortably
in place.

Extension
Cord

P/N 40703-01

For extra long
reach and mobility– connects in
seconds to quick disconnect modules.

SMALL LARGE

P/N 29955-03 P/N 29955-04

FCC Requirements—Part 68

This equipment complies with Part 68 of the FCC rules.
On the baseline underside is a label that contains, among
other information, the FCC registration number and ringer
equivalence number (REN) for this equipment. If requested,
this information must be provided to the telephone company.
The telephone company may make changes in its facilities,
equipment, operation or procedures that could affect the
operation of the equipment. If this happens, the telephone
company should provide you advance notice in order for you
to make the necessary modifications to maintain
uninterrupted services.

If you experience problems with your headset, please refer to
the warranty section for information on warranty and repair
service. If the problem is causing harm to the telephone
network, the telephone company may request that you
remove the equipment until the problem is resolved. In
extreme cases, the telephone company may be forced to
disconnect your service before notifying you of the problem.

Plantronics Technical Assistance Center

The Plantronics Technical Assistance Center (TAC) is ready to
assist you! Dial [phone] x5538 Sunday 5 p.m. through
Friday, 5 p.m. Pacific Standard Time or visit the Support section
of our website at www.plantronics.com.

For accessibility information also call the Technical Assistance
Center (TAC).

FCC REGISTRATION & INFORMATION

H81N

Noise-Canceling Model

H81

Standard Model

MAINTENANCE/TROUBLESHOOTING

Maintenance Hints for Optimum Performance

■

Replace voice tube every 6-9 months (voice tube models only).

■

Replace earbuds every six months.

■

Clean cable with a moist cloth once a month. (Do not use solvents

or a wet cloth.)

Troubleshooting

Callers cannot hear me

■

For voice tube models determine if the voice tube is positioned

improperly. Try various other positions.

■

To determine if the voice tube is clogged, remove the voice tube

and see if the caller can hear you. If the caller can hear you the

voice tube was clogged.

For a temporary solution to a clogged voice tube, gently rinse

warm water through the voice tube for a minute then manually

swing or shake it dry. Make sure the voice tube is completely dry

before reattaching. Plantronics recommends replacing the voice

tube every 6-9 months.

■

For noise-canceling models make sure the microphone is facing

your mouth and positioned properly.

■

Verify that the transmit volume control of the amplifier is

set properly.

I cannot hear callers

■

Verify that the Quick Disconnect is connected.

■

Make sure the earbud is positioned properly.

■

Make sure the modular adapter is installed correctly.

■

Turn up the volume control on the amplifier.

■

Change the amplifier's configuration switch to a different position.

Earpiece is uncomfortable

■

Determine if the earloop is properly positioned on your ear.

■

Remove the optional stabilizer cushion.

■

Try other earbuds for optimal fit.

■

Try all possible adjustments for the receiver arm (side to side,

up and down, in and out).

WARRANTY AND SERVICE

Voice Tube

P/N 29960-01

The voice tube should be replaced
every six to nine months.

Belltip
with
Cushion

Information on Accessories

Call Plantronics or visit our website at www.plantronics.com
Plantronics Inc. 345 Encinal Street, Santa Cruz, CA 95060

[phone] www.plantronics.com

© 2000-2002 Plantronics, Inc. All rights reserved. Plantronics, the logo design,
Plantronics and the logo design combined, Quick Disconnect, TriStar, the voice tube
clear color trade dress and shape trade dress are trademarks or registered
trademarks of Plantronics, Inc.
Patents: U.S. 5,259,780, 5,761,298, D375,959 and D379,990; Canada 78200;
China 95319003.X; Germany M9508557.2; Japan 971359; UK 2051288

Printed in USA. 49697-01 (08-02)

Headset

Type

Model

H81 H81N P81 P81N

Standard

Voice Tube

Headset

Noise-

Canceling

Headset

Polaris*

Voice Tube

Headset

Polaris*

Noise-Canceling

Headset

* Polaris models connect directly to most headset ready telephones.

to the

TriStar Family

of Headsets

WELCOME

H81

H81N

P81

P81N

Quick Start User Guide

TRISTAR

®

Family of Headsets

What does this warranty cover?

This warranty covers any defects in workmanship or materials

in this product purchased in the U.S. or Canada. For warranty

information in other countries, contact your local distributor.

How long does the coverage last?

This warranty runs for two years from the date of purchase.

What will Plantronics do?

If the product is found defective, we will exchange it at no charge.

How do you get service?

To obtain service in the U.S. contact Plantronics at [phone]

and in Canada call [phone].

How do state laws apply?

This warranty gives you specific legal rights, and you may also

have other rights, which vary from state to state.

What does this warranty NOT cover?

Damage caused by, or performance problems resulting

from,using this product with a non-Plantronics amplifier

and/orconnector cable, accident, abuse, misuse, or an act

of God (such as a flood) are not covered. Implied

warranties, including those of merchantability, fitness for

a particular purpose and non-infringement shall (a) have

no duration greater than two years from the date of

purchase, (b) terminate automatically at the end of that

period, and (c) to the extent permitted by law, be

excluded. Consequential and incidental damages,

including without limitation, loss of property and those

arising from breach of any express or implied warranty,

are not the responsibility of Plantronics, and to the extent

permitted by law, are excluded. Some states do not allow

exclusion or limitation of incidental or consequential

damages, so the above exclusion may not apply to you.

Thank you for selecting the TriStar headset. It is designed to

be used with Plantronics amplifiers that have Quick Disconnect

™

connector or compatible headset ready telephones and consoles.

You will experience a level of comfort and on-the-job freedom

that will make your job easier than ever before. Worn on one ear,

the TriStar headset features a unique three contact support

system for a secure fit no matter how much you move around.

And it's lightweight for maximum comfort throughout the day.

Open this user guide to the Quick Start instructions to set up your

headset and ready it for use. Later you can use the Maintenance

and Troubleshooting section for further guidance and assistance.

H81/N Final 9/17/02 4:44 PM Page 1

PARTS & ACCESSORIES

Cable to Quick

Disconnect (QD)

P/N 26716-01

Connects amplifier to

headset. Replace when

worn (10 ft.).

Extension Cable

P/N 40703-01

For extra long reach

and mobility–connects in seconds to

Quick Disconnect modules

(10 ft.).

Information on Accessories

Call Plantronics or visit our website at www.plantronics.com

FCC Requirements—Part 68

This equipment complies with Part 68 of the FCC rules.

On the baseline underside is a label that contains, among

other information, the FCC registration number and ringer

equivalence number (REN) for this equipment. If requested,

this information must be provided to the telephone company.

The telephone company may make changes in its facilities,

equipment, operation or procedures that could affect the

operation of the equipment. If this happens, the telephone

company should provide you advance notice in order for you

to make the necessary modifications to maintain uninterrupted

services.

If you experience problems with your headset, please refer

to the warranty section for information on warranty and

replacement service. If the problem is causing harm to the

telephone network, the telephone company may request

that you remove the equipment until the problem is resolved.

In extreme cases, the telephone company may be forced to

disconnect your service before notifying you of the problem.

Plantronics Technical Assistance Center

The Plantronics Technical Assistance Center (TAC) is ready to

assist you! Dial [phone] x5538 Sunday 5 p.m. through

Friday, 5 p.m. Pacific Standard Time or visit the Support section

of our website at www.plantronics.com.

For accessibility information also call the Technical Assistance

Center (TAC).

FCC REGISTRATION & INFORMATION

MAINTENANCE/TROUBLESHOOTING

Maintenance for Optimum Performance

■

Replace voice tube every 6-9 months (voice tube models only).

■

Replace ear cushion every six months.

■

Clean cable with a damp cloth once a month. (Do not use
solvents or wet cloth.)

Troubleshooting

Callers cannot hear me

■

For voice tube models determine if the voice tube is positioned improperly.
Try various other positions.

■

To determine if the voice tube is clogged, remove the voice tube and see if

the caller can hear you. If the caller can hear you the voice tube is clogged.
For a temporary solution to a clogged voice tube, gently rinse

warm water through the voice tube for a minute then manually swing or
shake it dry. Make sure the voice tube is completely dry before reattaching.

Plantronics recommends replacing the voice tube every 6-9 months.

■

For noise-canceling models make sure the microphone boom is facing

your mouth and positioned properly.

■

Verify that the transmit volume control of the amplifier is set properly.

I cannot hear callers

■

Verify that the Quick Disconnect is connected.

■

Make sure the headset is positioned properly.

■

Make sure the modular amplifier, if used, is installed correctly.

■

Turn up the volume control on the amplifier, if used.

■

Change the amplifier's configuration switch to a different position.

Fit is uncomfortable

■

For over-the-ear configurations, determine if the earloop
is properly positioned on your ear.
For over-the-head configurations, make sure the headband length is
correct so the stabilizer bars rest gently just above the ear.

■

Try all possible adjustments for the headset receiver in all the
configurations. See Section 4, Adjust the Headset on the inside
of this brochure for more information.

LIMITED WARRANTY

Voice

Tube

P/N 29960-01 P/N 29960-50

The voice tube should be replaced

every six to nine months.

Plantronics Inc. 345 Encinal Street, Santa Cruz, CA 95060

[phone] www.plantronics.com

© 2001-2002 Plantronics, Inc. All rights reserved. Plantronics, the logo design,

Plantronics and the logo design combined, DuoPro, Quick Disconnect, the

voice tube clear color trade dress and shape trade dress are trademarks or

registered trademarks of Plantronics, Inc.

Patents: U.S. D455,732 and D457,155; Australia 146644 and146645; UK

2104918 and 2104921

Printed in USA. 60908-01 (08-02)

Earloop

P/N 60965-01

Attaches to headset and used to

keep the headset stabilized and

comfortable for over-the-ear use.

Headband

P/N 60966-01

Attaches to headset

and used to keep the headset

stabilized and comfortable for

over-the-head use.

Ear Cushion Foam Pad

P/N 60967-01

Covers, protects, and makes

the headset comfortable against

the ear. Replace every six months.

What does this warranty cover?

This warranty covers any defects in workmanship or materials
in this product purchased in the U.S. or Canada. For warranty
information in other countries, contact your local distributor.

How long does the coverage last?

This warranty runs for two years from the date of purchase.

What will Plantronics do?

If the product is found defective, we will exchange it at no charge.

How do you get service?

To obtain service in the U.S. contact Plantronics at [phone]
and in Canada call [phone].

How do state laws apply?

This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state.

What does this warranty NOT cover?

Damage caused by, or performance problems resulting
from, using this product with a non-Plantronics amplifier
and/or connector cable, accident, abuse, misuse, or an act
of God (such as a flood) are not covered. Implied warranties,
including those of merchantability, fitness for a particular
purpose and non-infringement shall (a) have no duration
greater than two years from the date of purchase,
(b) terminate automatically at the end of that period,
and (c) to the extent permitted by law, be excluded.
Consequential and incidental damages, including without
limitation, loss of property and those arising from breach of
any express or implied warranty, are not the responsibility
of Plantronics, and to the extent permitted by law, are
excluded. Some states do not allow exclusion or limitation
of incidental or consequential damages, so the above
exclusion may not apply to you.

Clothing Clip

P/N 43220-01

Attaches to headset cable to keep

headset stabilized and comfortably

in place.

For Polaris models, Cable to QD

P/N 27190-01

Connects directly to headset port of

compatible headset ready telephones

(10 ft.).

H161N

Over-the-Head

(OTH) Configuration

H181N

Behind-the-Head

(BTH) Configuration

H151

Over-the-Ear

(OTE) Configuration

Clear

Peaceful

Purple

Thank you for selecting the DuoPro headset in one or more

of its three possible wearing configurations. It is designed to be used
with Plantronics amplifiers that have Quick Disconnect

™

or compatible

headset ready telephones and consoles.

Open this user guide to the Quick Start instructions to set up your
headset and ready it for use. Later you can use the Maintenance and
Troubleshooting section for further guidance and assistance. No tools

are required to change wearing configurations.

Headset

Type

Voice

Tube

H151

H151N

P151

P151N

H161

H161N

P161

P161N

H171

H171N

P171

P171N

H181

H181N

P181

P181N

Noise-

Canceling

Polaris*

Voice Tube

Polaris*

Noise-Canceling

Over-the-Ear

(OTE)

Headset

Over-the-Head

(OTH)

Headset

Convertible
(OTE & OTH)

Headset

Behind-the-Head

(BTH)

Headset

* Polaris models connect directly to most headset ready telephones.

Neckband

P/N 62800-01

Attaches to headset

and used to keep the headset

stabilized and comfortable for

behind-the-head use.

4

2

11

7

14

H151

H151N

P151

P151N

H161

H161N

P161

P161N

H171

H171N

P171

P171N

H181

H181N

P181

P181N

Quick Start User Guide

DUOPRO

®

Family of Headsets

to the
DuoPro Family
of Headsets

WELCOME

4

7

9

5

2

11

12

1

H151 Final 9/19/02 9:32 AM Page 1
