Page 1
BackBeat FIT 3100 Series
User Guide
Page 2
Contents
Controls overview 3
Power, pair and charge 4
Power on the case 4
Pair
first time 4
Pair mode 4
Charge 4
Install the app 6
The Basics 7
Power on/off your earbuds 7
Adjust the volume 7
Play or pause audio 7
Track selection 7
Make/Take/End Calls 7
Use Siri, Google Now 8
DeepSleep mode 8
Switch controls for better audio 8
Support 9
2
Page 3
R
L
:02
x1
x2
x3
x1
Siri
Google Now
™
:04
:04
:02
:04
:02
Controls overview
Right Primary earbud (pairs to phone)
Play/pause * Click 1 time
Next track * Click 2 times
Previous track * Click 3 times
Call answer/end Click 1 time
Siri/
Google
Now
Left Secondary earbud (connects to right earbud)
NOTE *Functionality varies by application. May not function with web-based apps.
Click and hold 2 seconds
Power on Click and hold 2 seconds
Power off Click and hold 4 seconds
Pair With the earbud powered off, click and hold 4 seconds
Reconnect to left earbud Tap each earbud 3 times
Volume up Tap to increase levels (touch sensor)
Volume down Touch and hold
Power on Click and hold 2 seconds
Power off Click and hold 4 seconds
Reconnect to right earbud Tap each earbud 3 times
3
Page 4
:02
PLT BBFIT
3100 Series
R
Power, pair and charge
Power on the case
Pair first time
Your charge case is shipped from the factory in a Deepsleep mode to conserve battery. Power on
your charge case to power your earbuds for first use.
Click and hold the charge case button for two seconds to power it on.
The charge case LEDs light up.
The first time you take your earbuds out of the charge case, the pairing process begins.
1 Take the earbuds out of the case. The LED, located on the right earbud, flashes red and white to
indicate pairing mode.
2 Activate Bluetooth
• iPhone Settings > Bluetooth > On*
• Android™ Settings > Bluetooth: On > Scan for devices*
NOTE * Menus may vary by device.
3 Select "PLT BBFIT3100 Series."
Once successfully paired, you hear “pairing successful” and the earbud LED stops flashing.
Pair mode
Charge
With the headset powered off, click and hold the right earbud until you hear "pairing."
To charge your earbuds, place them in the charge case. Charge the case by plugging it into a
computer or USB charging device. For fastest charging, plug them into a wall charger.
®
on your phone and set it to search for new devices.
4
Page 5
=
=
NOTE If the charge case has no charge, first charge the case separately, then charge the earbuds.
LEDs on earbuds/case
Earbuds charging On
Case charging Flashing
Earbuds fully charged Off
Case fully charged Off
5
Page 6
Install the app
Get the most from your earbuds by downloading our free app, BackBeat for iOS/Android.
With this app, you can:
• Stream a playlist, use a stopwatch, customize volume settings and more on your earbuds (My
Tap)
• Change earbud language
• Turn settings on/off
• Switch earbud controls from the right earbud to the left earbud
• Find MyHeadset
• View the user guide
6
Page 7
R
L
:02
x1
x2
x3
x1
Siri
Google Now
™
:04
:04
:02
:04
:02
The Basics
Power on/off your
earbuds
Adjust the volume
You can automatically or manually power on/off the earbuds.
• Automatic Taking the earbuds out of the case, automatically powers your earbuds on. Conversely,
putting them back in the case automatically powers them off and starts charging them.
• Manual Click and hold the earbud button for 2 seconds to manually power it on. To manually
power them off, click and hold for four seconds.
NOTE Turning off the right earbud, turns off the left earbud. To power on, power the earbuds on
individually.
Power transfer
If your right earbud loses power, all functions and audio transfers to the left earbud.
The left earbud has a touch sensor button. Only a light touch is required.
1 To increase volume, tap the left earbud.
2 To decrease volume, touch and hold the left earbud.
Play or pause audio
Track selection
Make/Take/End Calls
Click the right earbud.
NOTE Functionality varies by application.
Double-click the right earbud to skip to the next track or triple-click the right earbud to play the
previous track.
NOTE Functionality varies by application. May not function with web-based apps.
Answer or end a call
Click the right earbud.
7
Page 8
Answer a second call
First, click the right earbud to end current call, then click the right earbud again to answer new
call.
Use Siri, Google Now
DeepSleep mode
Switch controls for better
audio
Your earbuds support Virtual Personal Assistants (VPA) such as Siri and Google Now.
Click and hold the right earbud for two seconds to use your device's VPA.
If you leave your earbuds powered on but out of range of your paired device, they conserve power
by entering DeepSleep mode after 120 minutes and power off mode after 7 days.
To exit DeepSleep mode, choose:
• After 120 minutes, power on each earbud.
• After 7 days, reset by powering off and on.
For best Bluetooth performance, keep your phone/audio device on the same side of your body as
the primary earbud.
Your right earbud is the primary earbud by default. It pairs to your phone/audio device and the
left earbud automatically connects to the right.
If your prefer having your phone/audio device on the left side of your body, use the Switch
Primary Earbud feature in the BackBeat app to make the left earbud the primary earbud. This
moves the Bluetooth connection as well as primary controls to the left earbud and move the
volume and My Tap controls to the right earbud.
8
Page 9
Support
NEED MORE HELP?
plantronics.com/support
Plantronics, Inc.
345 Encinal Street
Santa Cruz, CA 95060
United States
©
2018 Plantronics, Inc. BackBeat and Plantronics are trademarks of Plantronics, Inc. registered in the US and other countries, and Plantronics Hub is a
trademark of Plantronics, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics, Inc. is under license. All other
trademarks are the property of their respective owners.
Patents pending.
213298-06 (08.18)
Plantronics B.V.
Scorpius 171
2132 LR Hoofddorp
Netherlands
