8-Port Web Smart PoE Switch
SW-0008FP
Planex Communications Inc.
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with this user’s guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will
be required to correct the interference at his or her own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be required
to take adequate measures.
VCCI Warning
This is a product of VCCI Class A Compliance.
TABLE OF CONTENT
About This Guide................................................................................. 1
Purpose ............................................................................................ 1
Terms/Usage .................................................................................... 1
Introduction.......................................................................................... 3
Fast Ethernet Technology ................................................................ 3
Switching Technology .....................................................................4
VLAN (Virtual Local Area Network).............................................. 5
Power over Ethernet (PoE) .............................................................. 5
Features............................................................................................ 6
Unpacking and Installation .................................................................. 7
Unpacking........................................................................................ 7
Installation ....................................................................................... 7
Connecting Network Cable .............................................................. 8
AC Power......................................................................................... 8
Identifying External Components ...................................................... 11
Front Panel..................................................................................... 11
Rear Panel......................................................................................12
Understanding LED Indicators .......................................................... 13
Power and System LEDs ............................................................... 13
Ports 1~8 LEDs.............................................................................. 13
Configuration ..................................................................................... 15
Installing the Web Management Utility ......................................... 15
Discovery List................................................................................ 16
i
Monitor List ................................................................................... 17
Device Setting................................................................................ 19
Toolbar........................................................................................... 20
Configuring the Switch .................................................................. 21
Login.............................................................................................. 22
Setup Menu .................................................................................... 24
Configuring Setup Setting.............................................................. 24
Port Settings............................................................................... 25
VLAN Settings (Virtual Local Area Network) .......................... 26
Trunk Setting ............................................................................. 28
Mirror Setting............................................................................. 28
QoS Setting ................................................................................ 29
PoE Setting ................................................................................ 32
Device Status .............................................................................33
Statistic....................................................................................... 34
System Setting ........................................................................... 35
Trap Setting................................................................................ 36
Set Password .............................................................................. 37
Backup Setting ........................................................................... 38
Reset Setting .............................................................................. 38
Logout............................................................................................ 39
Technical Specifications .................................................................... 39
ii
ABOUT THIS GUIDE
Congratulations on your purchase of the SW-0008FP. This Switch
integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network
capabilities in a highly flexible package. Since this switch’s Port-1 to
Port-8 is Power over Ethernet (PoE) ports, it will automatically detect
the presence of IEEE 802.3af-compliant devices and provides power
through the Port-1 to Port-8. The switch provides 15.4W per port and
can be used to WLAN access point, IP phone, video camera and other
PD devices. The Switch will automatically detect the network
appliance’s requirements, and the switch will supplies the required
power current to each appliance.
Purpose
This guide discusses how to install your SW-0008FP.
Terms/Usage
In this guide, the term “User’s Manual” refers to your SW-0008FP
and “User’s Manual” refers to other Ethernet switches.
1
INTRODUCTION
This chapter describes the features of the SW-0008FP and some
background information about Ethernet/Fast Ethernet switching
technology.
Fast Ethernet Technology
The growing importance of LANs and the increasing complexity of
desktop computing applications are fueling the need for high
performance networks. A number of high-speed LAN technologies
have been proposed to provide greater bandwidth and improve
client/server response times. Among them, 100BASE-T (Fast
Ethernet) provides a non-disruptive, smooth evolution from the
current 10BASE-T technology. The non-disruptive and smooth
evolution nature, and the dominating potential market base, virtually
guarantees cost-effective and high performance Fast Ethernet
solutions.
100Mbps Fast Ethernet is a standard specified by the IEEE 802.3
LAN committee. It is an extension of the 10Mbps Ethernet standard
with the ability to transmit and receive data at 100Mbps, while
maintaining the CSMA/CD Ethernet protocol. Since the 100Mbps
Fast Ethernet is compatible with all other 10Mbps Ethernet
environments, it provides a straightforward upgrade and takes
advantage of the existing investment in hardware, software, and
personnel training.
3
Switching Technology
Another approach to pushing beyond the limits of Ethernet technology
is the development of switching technology. A switch bridges
Ethernet packets at the MAC address level of the Ethernet protocol
transmitting among connected Ethernet or Fast Ethernet LAN
segments.
Switching is a cost-effective way of increasing the total network
capacity available to users on a local area network. A switch increases
capacity and decreases network loading by dividing a local area
network into different segments, which don’t compete with each other
for network transmission capacity.
The switch acts as a high-speed selective bridge between the
individual segments. The switch, without interfering with any other
segments, automatically forwards traffic that needs to go from one
segment to another. By doing this the total network capacity is
multiplied, while still maintaining the same network cabling and
adapter cards.
Switching LAN technology is a marked improvement over the
previous generation of network bridges, which were characterized by
higher latencies. Routers have also been used to segment local area
networks, but the cost of a router, the setup and maintenance required
make routers relatively impractical. Today switches are an ideal
solution to most kinds of local area network congestion problems.
4
VLAN (Virtual Local Area Network)
A VLAN is a group of end-stations that are not constrained by their
physical location and can communicate as if a common broadcast
domain, a LAN. The primary utility of using VLAN is to reduce
latency and need for routers, using faster switching instead. Other
VLAN utility includes:
Security, Security is increased with the reduction of opportunity in
eavesdropping on a broadcast network because data will be switched
to only those confidential users within the VLAN.
Cost Reduction, VLAN can be used to create multiple broadcast
domains, thus eliminating the need of expensive routers.
802.1Q VLAN, The VLAN tagging option is a standard set by the
IEEE to facilitate the spanning of VLANs across multiple switches
(Reference: IEEE Std 802.1Q-1998 Virtual Bridged Local Area
Networks).
Power over Ethernet (PoE)
Power over Ethernet (PoE) integrates power and data onto one single
cabling infrastructure, eliminating the need to have AC power
available at all locations.
Power and Data is integrated onto the same cable, supporting category
5/5e up to 100 Meters, PoE will provide power to PoE compatible
device, such as IP telephones, wireless LAN access points and IP
security cameras.
PoE is already widely adopted in the market, saving up to 50% of
overall installation costs by eliminating the need to install separate
electrical wiring and power outlets.
5
Features
8×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports with
PoE function
Compliant with IEEE 802.3af specification
Supports PoE power maximum 15.4W for each PoE ports
Supports PoE Powered Device (PD) classification identify
Each port supports auto MDI/MDIX, so there is no need to use
cross-over cables or an up-link port
Full/half duplex transfer mode for each port
Wire speed reception and transmission
Store-and-Forward switching scheme capability to support rate
adaptation and ensure data integrity
Up to 4K unicast addresses entities per device, self-learning, and
table aging
256KBytes packet buffer
Supports IEEE 802.3x flow control for full-duplex mode ports
Supports Back-pressure flow control for half-duplex mode ports
Supports 802.1Q VLAN
Supports Port based QoS, IEEE 802.1p based QoS, ToS based
QoS and DSCP based QoS.
Supports Port based Trunking
Supports Port-mirroring
Supports Port-setting for Speed/Disable, Flow control
Support Port based bandwidth rate control (Ingress rate and
Egress rate)
Easy configuration via WEB Browser
Easy setting via Web Management Utility
Compact size
6
UNPACKING AND INSTALLATION
This chapter provides unpacking and installation information for the
Switch.
Unpacking
Open the shipping cartons of the Switch and carefully unpacks its
contents. The carton should contain the following items:
One SW-0008FP
One AC power cord, suitable for your area’s electrical power
connections
Four rubber feet to be used for shock cushioning
Screws and two mounting brackets
CD-Rom with Web Management Utility and User’s Guide
If any item is found missing or damaged, please contact your local
reseller for replacement.
Installation
The site where you install the hub stack may greatly affect its
performance. When installing, consider the following pointers:
Install the Switch in a fairly cool and dry place. See Technical
Specifications for the acceptable temperature and humidity operating
ranges.
Install the Switch in a site free from strong electromagnetic field
generators (such as motors), vibration, dust, and direct exposure to
sunlight.
7
Leave at least 10cm of space at the front and rear of the hub for
ventilation.
Install the Switch on a sturdy, level surface that can support its weight,
or in an EIA standard-size equipment rack. For information on rack
installation, see the next section, Rack Mounting.
When installing the Switch on a level surface, attach the rubber feet to
the bottom of each device. The rubber feet cushion the hub and
protect the hub case from scratching.
Connecting Network Cable
The Switch support 8 10/100M Ethernet and PoE Enable ports, these
PoE port will automatically activated when a compatible terminal is
identified, the Switch will supply power through the Ethernet port to
the connected PoE device.
For the Legacy devices that are not yet compatible, the PoE port will
not offer the power to this device. This feature allows users to freely
and safely mix legacy and Power over LAN compatible devices on
their network.
The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and
it runs both in half and full duplex mode using two pair of Category 5
cable.
These RJ45 ports are Auto-MDI type port. The Switch can auto
transform to MDI-II or MDI-X type, so you can just make an easy
connection that without worrying if you are using a standard or
crossover RJ45 cable.
AC Power
The Switch used the AC power supply 100-240V AC, 50-60 Hz. The
power switch is located at the rear of the unit adjacent to the AC
8
power connector and the system fan. The switch’s power supply will
adjust to the local power source automatically and may be turned on
without having any or all LAN segment cables connected.
9
IDENTIFYING EXTERNAL COMPONENTS
This chapter describes the front panel, rear panel, and LED indicators
of the Switch.
Front Panel
The figure below shows the front panels of the Switch.
Figure 3. Front panel of SW-0008FP
Reset:
The Reset button is to reset all the setting back to the factory default.
Note: Be sure that you recorded the setting of your device, else all
the setting will be erased when pressing the ì Resetî button.
LED Indicator:
Comprehensive LED indicators display the status of the switch and
the network (see the LED Indicators chapter below).
PoE Ports :
These ports are PoE Enable ports, the PoE port will automatically
activated when a compatible terminal is identified, the Switch will
supply power through the Ethernet port to the connected PoE device.
For the Legacy devices that are not yet compatible, the PoE port will
not offer the power to this device. This feature allows users to freely
and safely mix legacy and Power over LAN compatible devices on
their network
11
These ports support network speeds of either 10Mbps or 100Mbps,
and can operate in half- and full- duplex transfer modes. These ports
also supports automatic MDI/MDIX crossover detection function
gives true “plug and play” capability, just need to plug-in the network
cable to the hub directly and don’t care if the end node is NIC
(Network Interface Card) or switch and hub.
Note: When the port was set to “Forced Mode”, the Auto
MDI/MDIX will be disabled.
Rear Panel
Figure 4. Rear panel of the Switch
AC Power Connector:
This is a three-pronged connector that supports the power cord. Plug
in the female connector of the provided power cord into this connector,
and the male into a power outlet. Supported input voltages range from
100-240V AC at 50-60Hz.
12
UNDERSTANDING LED INDICATORS
The front panel LEDs provides instant status feedback, and, helps
monitor and troubleshoot when needed.
Figure 5. LED indicators of the Switch
Power and System LEDs
POWER: Power Indicator
On : When the Power LED lights on, the Switch is receiving power.
Off : When the Power turns off or the power cord has improper connection.
SYSTEM: Management Indicator
Blinking : When the CPU is working, the System LED is blinking.
On/Off : The CPU is not working.
Ports 1~8 LEDs
Link/ACT: Link/Activity
On :
When the Link/ACT LED lights on, the respective port is successfully
connected to an Ethernet network.
13
Blinking :
When the Link/ACT LED is blinking, the port is transmitting or
receiving data on the Ethernet network.
Off : No link.
100M
On :
When the 100Mbps LED lights on, the respective port is connected to a
100Mbps Fast Ethernet network.
Off : When the respective port is connected to a 10Mbps Ethernet network
POWER GOOD
Green :
When the PoE device was connected and the port supplies power
successfully.
Red :
When the PoE port have the following failure happens:
9 PoE power short circuit
9 PoE Power over current
9 PoE Power fault
Off : No Powered Device is detected
14
CONFIGURATION
Through the Web Browser you can configure the Switch such as
VLAN, Trunking, and QoS… etc.
With the attached Web Management Utility, you can easily discover
all the Web Management Switch, assign the IP Address, changing the
password and upgrading the new firmware.
Installing the Web Management Utility
The following gives instructions guiding you through the installations
of the Web Management utility.
1. Insert the Utility CD in the CD-Rom Drive.
2. From the Start menu on the Windows desktop, choose Run.
3. In the Run dialog box, type D:\Web Management
Utility\setup.exe (D:\ depends where your CD-Rom drive is
located) and click OK.
4. Follow the on-screen instructions to install the utility.
5. Upon completion, go to Program Files ->
web_management_utility and execute the Web Management
utility. (Figure 6.)
15
Figure 6. Web Management Utility
The Web Management Utility was divided into four parts, Discovery
List, Monitor List, Device Setting and Toolbar function, for details
instruction, follow the below section.
Discovery List
This is the list where you can discover all the Web management
devices in the entire network.
By pressing the “Discovery” button, you can list all the Web
Management devices in the discovery list.
Double click or press the “Add to monitor list” button to select a
device from the Discovery List to the Monitor List.
16
System word definitions in the Discovery List:
z MAC Address: Shows the device MAC Address.
z IP Address: Shows the current IP address of the device.
z Protocol version: Shows the version of the Utility protocol.
z Product Name: Shows the device product name.
z System Name: Shows the appointed device system name.
z Location: Shows where the device is located.
z Trap IP: Shows the IP where the Trap to be sent.
z Subnet Mask: Shows the Subnet Mask set of the device.
z Gateway: Shows the Gateway set of the device.
Monitor List
All the Web Smart Device in the Monitor List can be monitored; you
can also receive the trap and show the status of the device.
System word definitions in the Monitor List:
z S: Shows the system symbol of the Web-Smart device,
represent for device system is not alive.
z IP Address: Shows the current IP address of the device.
z MAC Address: Shows the device MAC Address.
z Protocol version: Shows the version of the Utility protocol.
z Product Name: Shows the device product name.
z System Name: Shows the appointed device system name.
z Location: Shows where the device is located.
z Trap IP: Shows the IP where the Trap to be sent.
z Subnet Mask: Shows the Subnet Mask set of the device.
z Gateway: Shows the Gateway set of the device.
17
View Trap: The Trap function can receive the events that happen
from the Web Management Switch in the Monitor List.
There is a light indicator behind the “View Trap” button, when the
light indicates in green, it means that there is no trap transmitted, and
else when it indicates in red, it means that there is new trap
transmitted, this is to remind us to view the trap. (Figure 7)
Figure 7.
When the “View Trap” button is clicked, a Trap Information window
will pop out, it will show the trap information including the Symbol,
Time, Device IP and the Event occurred. (Figure 8)
The symbol “
” represents the trap signal arise, this symbol will
disappear after you review and click on the event record.
Figure 8.
Note: In order to receive Trap information, switch has to be configured with Trap
IP and Trap Events in Web browser, which are available in the Trap Setting
Menu (see Page 36 for detail).
Add Item: To add a device to the Monitor List manually, enter the IP
Address of the device that you want to monitor.
Delete Item: To delete the device in the Monitor List.
18
Device Setting
You can set the device by using the function key in the Device Setting
Dialog box.
Configuration Setting: In this Configuration Setting, you can set the
IP Address, Subnet Mask, Gateway, Set Trap to (Trap IP Address),
System name and Location.
Select the device in the Discovery list or Monitor List and press this
button, then the Configuration Setting window will pop out as Figure
9, after filling up the data that you want to change, you must fill up the
password and press the “Set” to process the data changed immediately.
Figure 9. Configuration Setting
Password Change: You can use this Password Change when you
need to change the password, fill in the password needed in the dialog
box and press “Set” button to precede the password change
immediately.
Figure 10. Password Change
19
Firmware Upgrade: When the device has a new function, there will
be a new firmware to update the device, use this function to update.
Figure 11.
Web Access: Double click the device in the Monitor List or select a
device in the Monitor List and press this “Web Access” button to
access the device in Web browser.
Toolbar
The toolbar in the Web Management Utility have four main tabs, File,
View, Options and Help.
In the “File TAB”, there are Monitor Save, Monitor Save As, Monitor
Load and Exit.
Monitor Save: To record the setting of the Monitor List to the
default, when you open the Web Management Utility next time, it
will auto load the default recorded setting.
Monitor Save As: To record the setting of the Monitor List in
appointed filename and file path.
20
Monitor Load: To manually load the setting file of the Monitor List.
Exit: To exit the Web Management Utility.
In the “View TAB”, there are view log and clear log function, this
function will help you to show trap setting.
View Log: To show the event of the Web Management Utility and
the device.
Clear Log: to clear the log.
In the “Option TAB”, there are Refresh Time function, this function
helps you to refresh the time of monitoring the device. Choose 15 secs,
30 secs, 1 min, 2 min and 5 min to select the time of monitoring.
In the “Help TAB”, there is About function, it will show out the
version of the Web Management Utility.
Configuring the Switch
The SW-0008FP has a Web GUI interface for smart switch
configuration. The Switch can be configured through the Web
Browser. A network administrator can manage, control and monitor
the switch from the local LAN. This section indicates how to
configure the Switch to enable its smart functions including:
Port Setting (Speed/Disable, Flow Control and Port Bandwidth
Rate Ingress/Egress)
VLAN Setting (802.1Q VLAN)
Trunking
Port Mirroring
QoS Setting
PoE Setting
System Setting
21
Device status and Statistic
Login
Before you configure this device, note that when the SW-0008FP is
configured through an Ethernet connection, make sure the manager
PC must be set on same the IP network. For example, when the
default network address of the default IP address of the Web Smart
Switch is 192.168.1.254, then the manager PC should be set at
192.168.1.x (where x is a number between 1 and 253), and the default
subnet mask is 255.255.255.0.
Open Internet Explorer 5.0 or above Web browser.
Enter IP address
http://192.168.1.254 (the factory-default IP address
setting) to the address location.
Figure 12.
Or through the Web Management Utility, you do not need to
remember the IP Address, select the device shown in the Monitor List
of the Web Management Utility to settle the device on the Web
Browser.
When the following dialog page appears, remain enter the default
password "admin" and press Login to enter the main configuration
window.
22
Figure 13.
After entering the password, the main page comes up, the screen will
display the device status.
Figure 14. Device Status
23
Setup Menu
When the main page appears, find the Setup menu in the left side of
the screen (Figure 15). Click on the setup item that you want to
configure. There are eleven options: Port Settings, VLAN Settings,
Trunk Settings, Mirror Settings, QoS Settings, PoE Settings, Device
Status, Statistic, System Settings, Trap Setting, Password Settings,
Backup Settings and Reset Settings as shown in the Main Menu screen.
Figure 15. Setup menu
Configuring Setup Setting
Find that there are six items, including Port Settings, VLAN Settings,
Trunk Settings, Mirror Settings, QoS Settings and PoE Settings in
Setup menu.
24
Port Settings
In Port Settings menu (Figure 16), this page will show each port’s
status, press the ID parameter to set each port’s Speed, Flow Control,
Rate Control Ingress and Egress. When you need to renew the posted
information, press the “Refresh” button.
The Link Status in the screen will show the connection speed and
duplex mode; else this dialog box will show down when the port is
disconnected.
Figure 16. Port Configuration
To change the port setting, click on the ID parameter to enter to the
selected port to configure its Speed/Disable, Flow control and Port
Bandwidth Rate Control Ingress and Egress.
Figure 17.
Speed/Disable:
This setting has six modes—100M Full, 100M Half, 10M Full, 10M
Half, Auto and Disable—for speed or port disable selections.
25
Flow Control:
This setting determines whether or not the Switch will be handling
flow control. Set FlowCtrl to Enable for avoiding data transfer
overflow. Or it sets to Disable; there is either no flow control or other
hardware/software management.
When the 10/100M port is set to full duplex mode, then the flow
control will automatically set to disable; and if the 10/100M port is set
to half duplex mode, the flow control will automatically set to enable.
Bandwidth Control Ingress/Egress rate:
This Switch support the Port Bandwidth Rate Control, and will work
only on the auto mode.
VLAN Settings (Virtual Local Area Network)
A VLAN is a collection of switch ports that make up a single
broadcast domain. You can configure a VLAN for a single switch, or
for multiple switches. When you create a VLAN, you can control
traffic flow and ease the administration of moves, adds, and changes
on the network, by eliminating the need to change physical cabling.
On VLAN settings, there are two main settings, VID Table Setting
and Port VLAN Setting.
VID: select the VID group that you set.
When you select VID Table Setting, press “Add new VID” to create
new VID group, from port 01 ~ port 08, select Untag Port, Tag Port or
Not Member for each port. To save the VID group, press “Apply”
button. To remove the selected VID group, select the VID group and
press “Remove the VID” button. To modify the VID group setting,
26
select the VID group and change the setting, and press “Apply” button
to save the settings.
Figure 18.
When you select Port VID setting, fill in each port’s PVID value
between 1 and 511, Priority value between 0 and 7.
Figure 19.
27
Trunk Setting
The Trunk function enables to cascade two devices with a double
times bandwidth (up to 800Mbps in full duplex mode).
There are 3 selection for the trunk setting, port “01, 02”, port
“01,02,03,04” or select “disable” for closing this function.
Figure 20. Trunk Settings
Be sure that the selected trunk setting port must connect to the device
with a same VLAN group.
Mirror Setting
Port Mirroring is a method of monitoring network traffic that forwards
a copy of each incoming and/or outgoing
packet from one port of a
network
switch to another port where the packet can be studied. It
enables the manager to keep close track of switch performance and
alter it if necessary.
Configuring the port mirroring by assigning a source port from which
to copy all packets and a sniffer port where those packets will be sent.
The selection of the sniffer mode is as follow:
TX (transmit) mode: this mode will duplicate the data transmit from
the source port and forward to the sniffer port.
28
RX (receive) mode: this mode will duplicate the data that send to the
source and forward to the sniffer port.
Both (transmit and receive) mode: this mode will duplicate both the
data transmit from and data that send to the source port, then it will
forward to the sniffer port.
Figure 21.
QoS Setting
There are five selections in QoS setting, Disable QoS, Port Based,
IEEE 802.1p Based, ToS Based and DSCP Based.
Figure 22.
WRR: Sent packets in different ratio according to different priority
level.
29
STRICT: The high priority packets sent before low priority packets.
Disable QoS: to disable the QoS function of the Switch.
Figure 23.
Port Based: to set the Switch QoS by port based, select the ports
which is High or Normal.
Figure 24.
IEEE 802.1p Based: to set the Switch QoS base on IEEE 802.1p,
select the priority chosing from Lowest, Low, Normal, and High.
Figure 25.
ToS Based: to set the Switch QoS base on ToS, select the priority
chosing from Lowest, Low, Normal, and High.
30
Figure 26.
DSCP Based: to set the Switch QoS base on DSCP, select the priority
chosing from Lowest, Low, Normal, and High.
31
Figure 27.
PoE Setting
When click on the PoE Setting, the status of the PoE will present on
the screen, it will show the PoE Enable, Priority, Power (W), Voltage
(V), Current (mA), classification and Status.
32
Figure 28.
Press “Refresh” button to refresh the status of the PoE.
Press click on the ID parameter to enter to the selected port to
configure the PoE settings, select enable to activate the PoE function
from port 1 to port 8, and disable to deactivate the PoE function. Click
“Apply” button to save the setting.
Figure 29.
Device Status
Click on the “Status” to present the device status on this screen, it will
show the System Status, Port Status, VLAN Status, Trunk Status,
Mirror Status, QoS Status and PoE Status.
Press “Refresh” when you need to renew the posted information.
33
Statistic
The Statistic Menu screen will show the status of each port packet
count.
Figure 30. Statistic
For Detail packet information, click on the ID parameter as Figure 31.
Figure 31.
34
System Setting
The System Setting includes the Web Server Port, System name,
Location name, Login Timeout, IP Address, Subnet Mask and
Gateway. Through the Web Management Utility, you can easily
recognize the device by using the System Name and the Location
Name.
The Login Timeout is to set the idle time-out for security issue, when
there is no action when running the Web Smart Utility and the time is
up, you must re-login to Web Smart Utility before you set the Utility.
Fill up the IP Address, Subnet Mask and Gateway for the device.
Figure 32.
35
Trap Setting
The Trap Setting enables the device to monitor the Trap through the
Web Management Utility, set the Trap IP Address of the manager
where the trap to be sent.
Figure 33. Trap Setting
System Events: Monitoring the system’s trap.
Device Bootup: a trap when booting up the system.
Illegal Login: a trap when there is using a wrong password login,
and it will record from where the IP to be login.
Twisted Pair Port Events: Monitoring the copper port status.
Abnormal* Receive Error: a trap when there are receive data
error in copper port.
36
Abnormal* Transmit Error: a trap when there are transmit data
error in copper port.
Abnormal*: 50 error packet count within 10 seconds.
PoE Events: Monitoring the PoE ports status.
PoE Power fail: a trap when the port’s power source is fail or the
SW-0008FP is fail.
Power on/Power down: a trap when the PoE port’s power is on
and down.
Power over current: a trap when the PoE port’s power is over
current.
Power short circuit: a trap when the PoE port’s power circuit was
short.
Set Password
Password is the invaluable tool for the manager to secure Web
Management Switch, use this function to change the password.
If you forget the password, press the “Reset” button in the rear panel
of the Switch, the current setting includes VLAN, Port Setting… etc.
will be lost and the Switch will restore to the default setting.
Figure 34. Set Password
37
Backup Setting
The backup tools help you to backup the current setting of the Switch.
Once you need to backup the setting, press the “Backup” button to
save the setting.
To restore a current setting file to the device, you must specify the
backup file and press “Restore” button to proceed the setting of the
recorded file.
Figure 35. Backup Setting
Note: when restoring a recorded file, the current password will not be erased.
Reset Setting
The Factory Reset button helps you to reset the device back to the
default setting from the factory. Be aware that the entire configuration
will be reset, the IP address of the device will be set to default setting
192.168.1.254.
Figure 36. Reset Setting
38
Logout
When press this function, the web configuration will go back to first
Login page.
Figure 37. Logout
39
TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3af compliant
Protocol CSMA/CD
Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex)
Topology Star
Network Cables 10BASET: 2-pair UTP Cat. 3, 4, 5; up to 100m
100BASE-TX: 2-pair UTP Cat. 5; up to 100m
Number of Ports 8 x 10/100M PoE Ethernet ports (port 1 ~ port 8)
Power over Ethernet
Standard IEEE 802.3af
Power current Up to 15.4W per port
PD Classification Auto PD classification identify
PoE pin assignment
Power(+): pin 3 & pin 6 in RJ45
Power(-): pin 1 & pin 2 in RJ-45
Safety protection
Over current protect
Circuit shortage protect
39
Physical and Environmental
AC inputs 100-240V AC, 50-60 Hz internal universal power supply
Power
Consumption
9Watts (max. no PD Device connected)
108Watts (max. with 7 x 15.4 w PoE Device connected)
Temperature
Operating: 0° ~ 40° C, Storage: -10° ~ 70° C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 280 x 180 x 44 mm (W x H x D)
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Performance
Transmits Method: Store-and-forward
Filtering Address
Table:
4K entries per device
Packet
Filtering/Forwardin
g Rate:
10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
MAC Address
Learning:
Automatic update
Transmits Method: Store-and-forward
RAM Buffer: 256K bytes per device
40
Loading...
