Planet Technology VIP-100T User Manual
Trademarks
Copyright PLANET Technology Corp. 2003.
Contents subject to revise without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
FCC Warning
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the You will be required to correct the interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause
radio interference, in which case the You may be required to take adequate
measures.
Revision
PLANET IP Phone VIP-100T
QUICK INSTALLATION GUIDE
For model: VIP-100T
Part No.: EMQ-VIP100TV1
Table of Contents
Chapter 1 Overview 1
1.1 Before Startup 1
1.2 Physical Details 1
1.2.1 Front view and keypad function 2
1.2.2 Rear view 3
Chapter 2 Basic Configuration 5
2.1 Initialize VIP-100T 5
2.1.1 Start up 5
2.1.2 LCD configuration 6
2.1.2.1 System Configuration 8
(i) Connect Configuration 8
(ii) User Line Number 11
(iii) Firmware Update 12
(iv) Hardware Test 12
(v) Reboot 12
Chapter 3 Making Calls 13
3.1 IP address call (P2P mode) 13
3.1.1 P2P mode Operation Steps 13
3.2 GK mode Operation Steps 15
3.3 Quick Dial example 16
3.3.1 Dial to local in peer to peer (P2P) mode 16
3.3.2 Phone Book web configuration sample 17
Chapter 4 Quick Reference in CD-ROM Guide 19
Chapter 1
OVERVIEW
Thank you for purchasing PLANET IP Phone VIP-100T (VIP-100T, in the following terms).
You can now ease the cost of long distance call yet still enjoy the toll voice quality via
Internet.
1.1 Before Startup
Before your rst time start up, please check if the package comes with following items:
• VIP-100T
• Your manual CD
• Quick Installation Guide
• RJ-45 cable
And later, you are required to familiar your environment, your TCP/IP network and your
phone systems.
1.2 Physical Details
1
3
1.2.1 Front view and keypad function:
● C: Cancel and Clear
● áâ : Move to left /previous and right/next.
● OK: Press OK to confirm the modification.
● Direct Line (DL) Button 1 – 10: Speed dialing according to phone book data
1-10.
● “+” and “- ” key: Adjust voice volume in communication.
● X : Speaking without picking up handset.
● MUTE: Mute the voice of MIC and let others can’t hear from You in communica-
tion.
● HOLD: To hold a call with H.450 function.
● SPEED: Press SPEED and number (Phone book index) to do speed dial accord-
ing to phone book data.
● FORWARD: Forward an incoming call to another IP device by H.450 forward
function.
● MESSAGE and its indicated LED light: When missing the incoming calls,
the message LED will be flashing. You can know the information of miss call by
pressing the message button.
● TRANSFER:
1. Transfer a call by H.450 transfer function. Press TRANSFER button in com-
munication and press phone No. which You want to transferred to can trans-
fer this call .
2. Change characters to be capital or lowercase: when press TRANSFER before
press letters can switch type of letters.
● REDIAL: Redial the last outgoing call.
● Number 1 –10, * and #: The function is as the same as the general phone
set.
2
● Corresponding list of keypad and symbol:
1 “Space” ; “,” ; “.” ; “!” ; “1”
2 “A” ; “ B” ; “C” ; “2”
3 “D” ; “E” ; “F” ; “3”
4 “G” ; “H” ; “I” ; “4”
5 “J” ; “K” ; “L” ; “5”
6 “M” ; “N” ; “O” ; “6”
7 “P” ; “Q” ; “R” ; “S” ; “7”
8 “T” ; “U” ; “V” ; “8”
9 “W” ; “X” ; “Y” ; “Z” ; “9”
“-“ ; “?” ; “*”
Ü
0 “0”
# “_” ; “@” ; “#”
1.2.2 Rear view
9V DC 9V DC Power input outlet
LAN RJ-45 connector, connected directly to Switch/
Hub through straight CAT-5 cable.
PC RJ-45 connector, connected directly to the PC
through straight CAT-5 cable
LED Display Two LED indicated lights; LNK/ACT and 100 for
LAN port and PC port. When network status is
in normal, LED of LNK/ACT will be flashing;
when transmit rate is in 10 Mbps/100Mbps,
LED of 100 will light off/on.
3
4
5
