10/100Mbps Desktop
Fast Ethernet Switch
SW-504 / SW-804
User's Manual
Trademarks
Copyright © PLANET Technology Corp. 2007.
Content subjects to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other
trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work
properly in all environments and applications, and makes no warranty
and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s Manual is
accurate; PLANET disclaims liability for any inaccuracies or omissions
that may have occurred.
Information in this User’s Manual is subject to change without notice
and does not represent a commitment on the part of PLANET. PLANET
assumes no responsibility for any inaccuracies that may be contained in
this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right
to make improvements to this User’s Manual and/or to the products
described in this User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect, misleading, or
incomplete, we would appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the Instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at its own expense.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to
take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human health
as a result of the presence of hazardous substances in electrical and
electronic equipment, end users of electrical and electronic equipment
should understand the meaning of the crossed-out wheeled bin symbol.
Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
Revision
PLANET 5/8-Port Desktop Fast Ethernet Switch User's Manual
FOR MODELS: SW-504, SW-804
Rev: 1.0 (November. 2007)
Part No.: 2011-A33200-000
Table of Contents
1. INTRODUCTION ........................................................................ 5
1.1 Package Contents ............................................................... 5
1.2 How to Use This Manual ..................................................... 5
1.3 Product Features ................................................................. 6
1.4 Product Specications ......................................................... 7
2. INSTALLATION ..........................................................................
2.1 Product Description ............................................................. 8
2.1.1 Product Overview ....................................................... 8
2.1.2 Switch Front Panel ..................................................... 9
2.1.3 LED Indicators ..........................................................10
2.2 Installing the Switch ..........................................................10
2.2.1 Desktop Installation ...................................................11
3. SWITCH OPERATION .................................................................
3.1 Address Table ....................................................................12
3.2 Learning ...........................................................................12
3.3 Forwarding & Filtering ........................................................12
3.4 Store-and-Forward .............................................................12
3.5 Auto-Negotiation ................................................................13
4. TROUBLESHOOTING .................................................................
Appendix A ...................................................................................15
A.1 Switch’s RJ-45 Pin Assignments ..........................................15
A.2 RJ-45 Plug, Jack pin out .....................................................15
12
14
8
1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for following parts:
● Desktop Fast Ethernet Switch x 1
● User’s manual x 1
● Power adapter x 1
If any of these are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need to return it to us for repair.
1.2 How to Use This Manual
This Desktop Fast Ethernet Switch User Manual is structured as follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical
installation of the Switch.
Chapter 3 Switch operation
The chapter explains the Switch transmit operation.
Chapter 4 Troubleshooting
The chapter explains the troubleshooting of the Switch.
Appendix A
This chapter contains cable information of the Switch.
In the following section, the term “Desktop Fast Ethernet Switch”
means the two Switch devices, ie. SW-504 and SW-804; term of
“switch” can be any third switches.
5
1.3 Product Features
● Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
● 5/8-Port 10/100Mbps Auto-Negotiation ports - 10/20Mbps (Half-
duplex), 100/200Mbps (Full-duplex) Auto-sensing
● Compact size design for wall mount or desktop placement
● High performance Store-and-Forward Switching Architecture
● Runt and CRC ltering
● Flow control (Back Pressure) supports in half-duplex mode
● 1K MAC Address Table, automatically learning and aging
● LED indicators array for easy diagnostic, troubleshooting
● Plug-and-Play Installation
● Auto-MDI/MDIX on each port
● FCC Part 15 Class B, CE
6
1.4 Product Specications
Model SW-504 SW-804
Hardware Specication
Network Ports
Dimensions
(W x D x H)
Weight (KG) 0.17 KG
Power
Requirement
Switch Specication
Switch
Architecture
Address Table 1K entries, auto learning/ageing
Switch
Throughput
Switch Fabric 1Gbps 1.6Gbps
Shared Buffer 384K 768K
Flow Control IEEE 802.3x full duplex operating and ow control
Packet Control Runt & CRC ltering, Broadcast storm control
Standard Conformance
Network
Standards
Operation
Temperature
Humidity 5% to 90% (Non-condensing)
Regulation
Compliance
5 10/100Base-TX
RJ-45 MDI/MDI-X ports
184 x 110 x 30mm
External Power adapter DC 9V 700 mA
Store-and-Forward
0.74Mpps 1.19Mpps
IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet)
and IEEE 802.3x (ow control)
0~50ºC (operating); -20~70ºC (storage)
FCC Part Class B, CE
8 10/100Base-TX RJ-45
MDI/MDI-X ports
7
2. INSTALLATION
This section describes the functionalities of the Desktop Fast Ethernet
Switch’s components and guides how to install it on the desktop.
Basic knowledge of networking is assumed. Please read this chapter
completely before continuing.
2.1 Product Description
With concepts of “Easy to Install and use”, “Compact-sized
design”, and “Simple troubleshooting”, PLANET SW-504/SW-804
provides cost-conscious business and home users with the foundation
of an integrated system of small-ofce / home-ofce networking. The
SW-504/SW-804 is the fancy-shape plastic models and just right for
your network of 10 to 50 users.
The SW-504/SW-804 Desktop Fast Ethernet Switch is a Simple
and cost-effective, highly reliable network Switch. And it is the ideal
device for bridging Ethernet to Fast Ethernet workgroups or networks.
Therefore, the Switches will be the fast being recognized as one of the
most important building blocks for today networking technology.
To segment the network, ease the network trafc, the 5/8-Port
10/100Mbps are useful for the SOHO switched networks as the friendly
network backbone. Provides array LED indicators, the network status
can be monitored at a glance.
2.1.1 Product Overview
PLANET SW-504/SW-804 are Desktop Fast Ethernet Switches with
5/8 RJ-45 10/100Mbps ports for high-speed network connectivity. The
Switches can also automatically identify and determine the correct
transmission speed and half/full duplex mode of the attached devices
with its 5/8 ports.
This Desktop Fast Ethernet Switch also supports store-and-forward
forwarding scheme to ensure low latency and high data integrity,
eliminates unnecessary trafc and relieves congestion on critical
network paths. With an intelligent address recognition algorithm, the
switches could recognize up to 1K different MAC address and enables
ltering and forwarding at full wire speed.
8
2.1.2 Switch Front Panel
1 2
3 5 64 87
SW-804
LNK/ACT
Figure 2-1 & 2-2 show the front panel and rear panel of SW-504
Figure 2-1 SW-504 front panel
Figure 2-2 SW-504 rear panel
Figure 2-3 & 2-4 show the front panel and rear panel of SW-804
Figure 2-3 SW-804 front panel
9
Figure 2-4 SW-804 rear panel
Note
2.1.3 LED Indicators
LED Color Function
PWR Green
LNK/ACT Green
Power Notice:
1. The device is a power-required device, it means, it will not work till
it is powered. If your networks should active all the time, please
consider using UPS (Uninterrupted Power Supply) for your device. It
will prevent you from network data loss or network downtime.
2. In some area, installing a surge suppression device may also help
to protect your Switch from being damaged by unregulated surge or
current to the Switch or the power adapter.
Lights to indicate that the Switch is powered
on.
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the Switch is actively
sending or receiving data over that port.
2.2 Installing the Switch
This part describes how to install your Desktop Fast Ethernet Switch
and make connections to it. Please read the following topics and
perform the procedures in the order being presented.
This Switch does not need software configuration.
10
2.2.1 Desktop Installation
Note
Note
To install the Switch on desktop, simply follow the next steps:
Step1: Attach the rubber feet to the recessed areas on the bottom
of the Switch.
Step2: Place the Switch on desktop near a DC power source.
Step3: Keep enough ventilation space between the Switch and the
surrounding objects.
When choosing a location, please keep in mind the
environmental restrictions discussed in Chapter 1,
Section 1.4 Product Specification.
Step4: Connect your Switch to network devices.
A. Connect one end of a standard network cable to the 10/100
RJ-45 ports on the Back of the Switch.
B. Connect the other end of the cable to the network devices
such as printer servers, workstations or routers…etc.
Connection to the Switch requires UTP Category 5
network cabling with RJ-45 tips. For more information,
please see the Cabling Specification in Appendix A.
Step5: Supply power to the Switch.
A. Connect one end of the power cable to the Switch.
B. Connect the power plug of the power cable to a standard wall
outlet.
When the Switch receives power, the Power LED should remain solid
Green.
11
3. SWITCH OPERATION
3.1 Address Table
The Switch is implemented with an address table. This address table
composed of many entries. Each entry is used to store the address
information of some node in network, including MAC address, port
no, etc. This information comes from the learning process of Ethernet
Switch.
3.2 Learning
When one packet comes in from any port, the Switch will record the
source address, port no. And the other related information in address
table. This information will be used to decide either forwarding or
ltering for future packets.
3.3 Forwarding & Filtering
When one packet comes from some port of the Ethernet Switching,
it will also check the destination address besides the source address
learning. The Ethernet Switching will lookup the address-table for the
destination address. If not found, this packet will be forwarded to all
the other ports except the port, which this packet comes in. And these
ports will transmit this packet to the network it connected. If found,
and the destination address is located at different port from this packet
comes in, the Ethernet Switching will forward this packet to the port
where this destination address is located according to the information
from address table. But, if the destination address is located at the
same port with this packet comes in, then this packet will be ltered.
Thereby increase the network throughput and availability.
3.4 Store-and-Forward
Store-and-Forward is one type of packet-forwarding techniques. A
Store-and-Forward Ethernet Switching stores the incoming frame in
an internal buffer, do the complete error checking before transmission.
Therefore, no error packets occurrence, it is the best choice when a
network needs efciency and stability.
12
The Ethernet Switch scans the destination address from the packetheader, searches the routing table provided for the incoming port
and forwards the packet, only if required. The fast forwarding makes
the switch attractive for connecting servers directly to the network,
thereby increasing throughput and availability. However, the switch is
most commonly used to segment existing hubs, which nearly always
improves overall performance. An Ethernet Switching can be easily
congured in any Ethernet network environment to signicantly boost
bandwidth using conventional cabling and adapters.
Due to the learning function of the Ethernet switching, the source
address and corresponding port number of each incoming and outgoing
packet are stored in a routing table. This information is subsequently
used to lter packets whose destination address is on the same
segment as the source address. This connes the network trafc to its
respective domain, reducing the overall load on the network.
The Switch performs “Store and Forward” therefore, no error packets
occur. More reliably, it reduces the re-transmission rate. No packet loss
will occur.
3.5 Auto-Negotiation
The STP ports on the Switch have built-in “Auto-negotiation”. This
technology automatically sets the best possible bandwidth when a
connection is established with another network device (usually at Power
On or Reset). This is done by detect the modes and speeds at the
second of both device is connected and capable of, both 10Base-T and
100Base-TX devices can connect with the port in either Half- or Full-
Duplex mode.
If attached device is: 100Base-TX port will set to:
• 10Mbps, no auto-negotiation 10Mbps
• 10Mbps, with auto-negotiation 10/20Mbps (10Base-T/Full-Duplex)
• 100Mbps, no auto-negotiation 100Mbps
• 100Mbps, with auto-negotiation
100/200Mbps
(100Base-TX/Full-Duplex)
13
4. TROUBLESHOOTING
This chapter contains information to help you solve issues. If Desktop
Fast Ethernet Switch is not functioning properly, make sure the Desktop
Fast Ethernet Switch was set up according to instructions in this
manual.
Some stations cannot talk to other stations located on the other
port Solution:
The address table may contain older information than of the address
table of that node. Please power down to refresh the address
information.
Performance is bad Solution:
Check the speed duplex mode of the partner device. If the partner is
set to half duplex, then the performance will be poor.
Why the Switch doesn’t connect to the network Solution:
Check the LNK/ACT LED on the Switch
Try another port on the Switch
Make sure the cable is installed properly
Make sure the cable is the right type
Turn off the power. After a while, turn on power again
14
Appendix A
A.1 Switch’s RJ-45 Pin Assignments
When connecting your Desktop Fast Ethernet Switch to another switch,
a bridge or a hub, a straight or crossover cable is necessary. Each port
of the Switch supports auto-MDI/MDI-X detection. That means you can
directly connect the Switch to any Ethernet devices without making a
crossover cable. The following table and diagram show the standard RJ45 receptacle/ connector and their pin assignments:
RJ-45 Connector pin assignment
Contact
4, 5 Not used
7, 8 Not used
Media Dependant Interface
1 Tx + (transmit) RX + (receive)
2 Tx - (transmit) RX - (receive)
3 Rx + (receive) TX + (transmit)
6 RX – (receive) TX – (transmit)
MDI
The standard cable, RJ-45 pin assignment
A.2 RJ-45 Plug, Jack pin out
MDI-X
Media Dependant
Interface - Cross
The standard RJ-45 receptacle/.connector
There are 8 wires on a standard UTP/STP cable and each wire is color-
15
coded. The following shows the pin allocation and color of straight cable
and crossover cable connection:
Figure A-1 Straight-Through and Crossover Cable
Please make sure your connected cables are with same pin assignment
and color as above picture before deploying the cables into your
network.
16
Loading...
