JP1/A-H
JP2/A-E
CN1
CN2
CN3
ROMBOOT
PLANET TECHNOLOGY CORPORATION
S M A R T C O M I S A ( E N W - 2 4 0 0 P-T/2T )
NIC Type
Network Transfer Rate
Data Bus
Topology
Wiring Type
Boot ROM
Ethernet
10Mbps
16-bit ISA
Linear Bus, Star
Unshielded twisted pair
AUI transceiver via DB-15 port
RG-58A/U 50ohm coaxial
Available
CONNECTIONS
RG-58A/U 50ohm coaxial portCN1Unshielded twisted pair port
CN3AUI transceiver via header
USER CONFIGURABLE SETTINGS
INTERRUPT SELECTION
LabelFunctionLabelFunction
CN2
PositionLabelFunction
OpenJP1/Hí PnP mode
ClosedJP1/HJumper mode
JP1/GJP1/FJP1/EIRQ
OpenOpenOpen2/9
ClosedOpenOpen3
OpenClosedOpen4
ClosedClosedOpen5
OpenOpenClosed10
ClosedOpenClosed11
OpenClosedClosed12
ClosedClosedClosed15
Continued on next page. . .
PLANET TECHNOLOGY CORPORATION
S M A R T C O M I S A ( E N W - 2 4 0 0 P-T/2T )
BASE I/O ADDRESS SELECTION
ROM ADDRESS SELECTION
TECHNICAL NOTE
Note: The exact purpose and location of JP3 is unidentified.
. . . continued from previous page
JP1/EJP1/CJP1/BJP1/ASetting
OpenOpenOpenOpen300h
ClosedOpenOpenOpen320h
OpenClosedOpenOpen340h
ClosedClosedOpenOpen360h
OpenOpenOpenClosed380h
ClosedOpenOpenClosed3A0h
OpenClosedOpenClosed3C0h
ClosedClosedOpenClosed3E0h
OpenOpenClosedOpen200h
ClosedOpenClosedOpen220h
OpenClosedClosedOpen240h
ClosedClosedClosedOpen260h
OpenOpenClosedClosed280h
ClosedOpenClosedClosed2A0h
OpenClosedClosedClosed2C0h
ClosedClosedClosedClosed2E0h
JP2/EJP2/DJP2/CJP2/BJP2/AAddress
OpenOpenOpenOpenOpenDisabled
OpenOpenOpenClosedOpenC0000h, 32KB
ClosedOpenOpenClosedOpenC8000h, 32KB
OpenClosedOpenClosedOpenD0000h, 32KB
ClosedClosedOpenClosedOpenD8000h, 32KB
OpenOpenClosedClosedOpenC0000h, 64KB
ClosedOpenClosedClosedOpenD0000h, 64KB
OpenOpenOpenOpenClosedC0000h, 16KB
ClosedOpenOpenOpenClosedC4000h, 16KB
OpenClosedOpenOpenClosedC8000h, 16KB
ClosedClosedOpenOpenClosedCC000h, 16KB
OpenOpenClosedOpenClosedD0000h, 16KB
ClosedOpenClosedOpenClosedD4000h, 16KB
OpenClosedClosedOpenClosedD8000h, 16KB
ClosedClosedClosedOpenClosedDC000h, 16KB
