Planet Technology POE-1200, POE-2400 User Manual
User’s Manual
POE-1200
POE-2400
IEEE 802.3af
12 / 24-Port Power over Ethernet
Web Management Injector Hub
Trademarks
Copyright © PLANET Technology Corp. 2008.
Contents subject to which revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective
owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications,
and makes no warranty and representation, either implied or expressed, with respect to the quality, performance,
merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any
inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change without notice and does not represent a commitment on the
part of PLANET. PLANET
Manual. PLANET makes no commitment to update or keep current the information in this User’s Manual, and
reserves the right to make improvements to this User’s Manual and/or to the products described in this User’s
Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we w
comments and suggestions.
assumes no responsibility for any inaccuracies that may be contained in this User’s
ould appreciate y
our
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the Instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at whose own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the
user may be required to take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately
Revision
PLANET IEEE 802.3af Power over Ethernet Injector Hub User's Manual
FOR MODELS: POE-1200 / POE-2400 (Hardware version 2)
REVISION: 2.0 (APRIL.2008)
Part No.: 2080-A31120-004
2
TABLE OF CONTENTS
1. INTRODUCTION........................................................................................................................................... 1
1.1 PACKAGE CONTENTS .................................................................................................................................. 1
1.2 PRODUCT DESCRIPTION.............................................................................................................................. 1
1.3 HOW TO USE THIS MANUAL......................................................................................................................... 2
1.4 PRODUCT FEATURES .................................................................................................................................. 3
1.5 PRODUCT SPECIFICATIONS.......................................................................................................................... 4
2. INSTALLATION ............................................................................................................................................ 5
2.1 HARDWARE DESCRIPTION ........................................................................................................................... 5
2.1.1 Injector Front Panel.............................................................................................................................................5
2.1.2 LED Indicators.....................................................................................................................................................6
2.1.3 Injector Rear Panel .............................................................................................................................................6
2.2 INSTALLING THE POE INJECTOR HUB ........................................................................................................... 7
2.2.1 Desktop Installation.............................................................................................................................................7
2.2.2 Rack Mounting....................................................................................................................................................8
2.2.3 Network Application Installation...........................................................................................................................9
2.2.4 Power over Ethernet Powered Device...............................................................................................................10
3 MANAGEMENT............................................................................................................................................ 11
3.1 OVERVIEW................................................................................................................................................ 11
3.2 REQUIREMENTS........................................................................................................................................ 11
3.3 MANAGEMENT METHOD............................................................................................................................. 11
3.3.1 Web Management.............................................................................................................................................11
3.3.2 PLANET Smart Discovery Utility.......................................................................................................................13
4 WEB CONFIGURATION.............................................................................................................................. 15
4.1 MANIN MENU............................................................................................................................................ 15
4.2 WEB PANEL.............................................................................................................................................. 16
4.3 SYSTEM.................................................................................................................................................... 16
4.3.1 System Information...........................................................................................................................................17
4.3.2 IP Configuration ................................................................................................................................................17
4.3.3 Password Setting..............................................................................................................................................18
4.4 POE......................................................................................................................................................... 19
4.5 TOOLS...................................................................................................................................................... 21
4.5.1 System Reboot..................................................................................................................................................21
4.5.2 Configuration Setting.........................................................................................................................................22
4.5.3 Alert Trap Configuration.................................................................................................................................... 24
4.5.4 Firmware Upgrade.............................................................................................................................................25
4.6 LOGOUT ................................................................................................................................................... 26
5. POWER OVER ETHERNET OVERVIEW................................................................................................... 28
6. THE POE PROVISION PROCESS............................................................................................................. 30
6.1 LINE DETECTION....................................................................................................................................... 30
6.2 CLASSIFICATION........................................................................................................................................ 30
6.3 START-UP................................................................................................................................................. 31
6.4 OPERATION .............................................................................................................................................. 31
6.5 POWER DISCONNECTION SCENARIOS......................................................................................................... 31
7 TROUBLESHOOTING................................................................................................................................. 32
APPENDIX A................................................................................................................................................... 33
A.1 MDI SETTINGS......................................................................................................................................... 33
A.2 POWER DEVICE CLASSIFICATION VALUES................................................................................................... 33
A.3 DATA OUT POE INJECTOR RJ-45 PORT PIN ASSIGNMENTS...................................................................... 34
APPENDIX B................................................................................................................................................... 36
B.1 POWER OVER ETHERNET COMPATIBILITY TEST........................................................................................... 36
3
1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for follow i ng parts:
● IEEE 802.3af Power over Ethernet Injector Hub x1
● User’s Manual x1
● Quick installation guide x1
● 19” rack mounting kit x1
● Power cord x1
● Rubber feet x 4
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
1.2 Product Description
The PLANET POE-1200 / POE-2400 are 12 / 24-Port IEEE 802.3af Power over Ethernet Mid-Span injector hub complies
with IEEE 802.3, IEEE 802.3u and IEEE 802.3af standards. It is equipped with 12 / 24 10/100Base-TX Fast Ethernet ports
that support full 48VDC power for any remote IEEE802.3af powered device (PD) like Wireless LAN Access Point, IP phone,
LAN Camera or any other network devices. With support for 130 / 260 watts power supply, POE-1200 / POE-2400 should
provide the sufficient power to the 12 / 24 remote devices.
The POE-1200 / POE-2400 is installed between a regular Ethernet switch and the powered devices, injecting pow
affecting the data transmit. It offer a cost effective solution and quickly way to upgrade network system to IEEE 802.3af
Power over Ethernet, without replace the existing Ethernet switch.
There are 24 / 48 RJ-45 STP ports on the front panel of hub, 12 / 24 of them on lowe
/ 24 ports on upper stack are "Data + Power output" port. Each of the "Data + Power output" port on upper stack functions
as an injector which inserts DC Voltage into the CA T 5 cable allow ing the cable betw een the Injector and Splitter to transfer
data and power simultaneously.
To manage your powered devices, POE-1200 / POE-2400 provides both Web management interfaces in wh
administrators can manage functions such as port Enable/Disable, port priority, system configuration, and
Username/Password changing and with smart feature for powered device, the Hub can auto detect the power status on
each port and show massages Web management interface. These features also provide a cost-effective way to manage
the devices from Internet whenever you are at work or at home.
r stack are "Date" port and the other 12
er without
ich
Power over Ethernet Applications
For the places hard to find the power outlet, it provides the easiest way to power your Ethernet devices such as PLANET
Internet Cameras and outdoor Wireless Access Point installed on the top of the building.
To control the power system of your networking devices, they can directly
telephony network in the office. Besides, it can be directly deployed to connect the third party 802.3af devices like wireless
AP and PoE switches installed 100 meters away.
co-work with PoE IP Phone to build VoIP
1
Figure 1-1 Power over Ethernet Application
1.3 How to Use This Manual
This Web Smart Power over Ethernet Injector Hub User Manual is structured as follows:
Section 2, Installation
It explains the functions of POE-1200 / POE-2400 and how to phy
Section 3, Management
It contains information about the software function of the POE-1200 / POE-2400.
Se
ction 4, Web Configuration
The section explains how to manage the POE-1200 / POE-2400 through Web interface.
Sectio
Section 6, Po
Section 7, Troubleshooting
Appendix A
n 5, Power over Ethernet overview
T
he section explains the IEEE 802.3af Powe
E power Provision Process
The section explains the PoE power provision process.
The section contains troubleshooting guide of the POE-1200 / POE-2400.
It contains cable information of POE-1200/2400.
r over Ethernet theories.
sically install the POE-1200 / POE-2400.
A
ppendix B
T
his section contains the Power over Ethernet compatibility
In the following section, terms “PoE Injector Hub” with upper case mean the two injectors, i.e. POE-1200 or POE-2400.
T
erms with lower case “injector” means any 802.3af power injectors. “PD” means the abbreviated from 802.3af powered
device.
information of the POE-1200 / POE-2400.
2
1.4 Product Features
Interface
24 / 48-Port RJ-45 STP
¾ 12 / 24-Port “Da
12 / 24-Port “Data + Pow
¾
1 10/100Base-TX Management port
PoE
Complies with IEEE 802.3af Power over Ethernet Mid-Span PSE
Up to 12/24 IEEE 802.3af devices powered
Support PoE Powe
Auto detect powered device (PD)
Circuit protection prevent power interference betw
Remote power feeding up to 100m
PoE Ma
Total PoE power budget control
Pert port PoE function enable/disable
PoE Port Power feeding priority
Per PoE port power limit
PD classification detection
Ma
Web interface for remote management
Firmware upgrade through Web interface
PLANET Smart Discovery utility automatically
SNMP Trap for alarm notification of events
Hardw
19-inch rack mountable; 1U height
Reset button for reset to default setting and system reboot
Standard Compliance
IEEE 802.3u 100Base-TX
IEEE 802.3af Power over Ethernet
nageme
nagement
are
LED indicators for POE ready and POE activity
IEEE 802.3 10Base-T
FCC Part 15 Class A, CE
nt
ta input”
er output”
r up to 15.4 wa
tts for each PoE ports
een ports
finds PLANET devices on the network
3
1.5 Product Specifications
Product POE-1200 POE-2400
Hardware Specification
“Data”
Input Ports
Interface
LED System: Power x 1
Network Cable • 10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100 m (328ft)
Dimensions (W x D x H) 440 x 200 x 44 mm (1U height)
Weight 2.7kg 3.3kg
Cooling Fan x 1 Fan x 2
Power Requirement 100-240V AC, 50/60 Hz
Power Consumption 130 watts max. 260 watts max.
Operating Temperature 0ºC ~ 50ºC
Storage Temperature -40ºC ~ 70ºC
Humidity 5% to 95% (Non-condensing)
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / Mid-Span PSE
PoE Power supply Type Mid-Span
Number of 802.3af device can be
powered
PoE Power Output Per Port 48V DC, 350mA . Max. 15.4 watts
Power Pin Assignment 4/5(+), 7/8(-)
Power Budget 110Watts 240Watts
Standards Conformance
Standards Compliance IEEE 802.3 10Base-T Ethernet
Regulation Compliance FCC Part 15 Class A, CE
“Data+Power”
Output Ports
Management Port 1 x RJ-45; 10/100Base-TX, auto-negotiation, auto-MDI
12 x RJ-45 STP 24 x RJ-45 STP
12 x RJ-45 STP 24 x RJ-45 STP
Per PoE Port: PoE in Use x 1
• 100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100 m (328ft)
• EIA/TI A- 568 100-ohm STP (100 m)
12 24
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3af Power over Ethernet
4
2. INSTALLATION
This section describes the hardware features and installation of these PoE Injector Hub on the desktop or rack mount. For
easier management and control of the PoE Injector Hub familiarize y
panel illustrations in this chapter display the unit LED indicators. Before deploy the PoE Injector Hub please read this
chapter completely.
2.1 Hardware Description
The section describes the hardware of the POE-1200 / POE-2400 and gives a physical and functional overview.
2.1.1 Injector Front Panel
The unit front panel provides a simple interface monitoring the PoE Injector Hub . Figure 2-1 & 2-2 shows front panel of the
POE-1200 / POE-2400.
Front Panel of POE-1200
ourself with its display indicators, and ports. Front
Figure 2-1 POE-1200 front panel
ront Panel of POE-2400
F
Figure 2-2 POE-2400 front panel
utton
■ Reset b
At the left of front panel, the reset button is designed for reboot the PoE Injector Hub without turn off and on the pow
Figure 2-3 Reset button of POE-1200 / POE-2400
er.
5
The following is the summary table of Reset button functions:
Reset Button Pressed and Released Function
About 1 second Reboot the PoE Injector Hub
Reset the PoE Injector Hub to Factory Default configuration.
The PoE Injector Hub will reboot and load the default IP
settings as below:
Until the SYS LED lit off
To press the RESET button about 10 seconds and then release. The PoE Injector Hub will back
to the factory default mode. Be sure that you backup the current configuration of PoE Injector
Hub; else the entire configuration will be erased when pressing the “RESET” button.
。 Default Passw
。 Default IP address: 192.168.0.100
。 Subnet mask: 255.255.255.0
。 Default Gatewa
ord: admin
192.168.0.254
y:
2.1.2 LED Indicators
The front panel LEDs indicates instant status of system power, Management port Link/Active and PoE port links, helps
monitor and troubleshoot when needed.
LED Color Function
POWER Green Lights to indicate power on.
Lights to indicate the port is running in 100Mbps speed
Amber
Manage
Green
Blink: indicate that the PoE Injector Hub is actively sending or receiving data over
that port.
Lights to indicate the port is running in 10Mbps speed
Blink: indicate that the PoE Injector Hub is actively sending or receiving data over
that port
PoE In-use Green Lights to indicate that the port is in use and supplying 48V DC power
2.1.3 Injector Rear Panel
The rear panel of the PoE Injector Hub indicates an AC inlet power socket, which accepts input power from 100 to 240V
AC, 50/60Hz.
Figure 2-3 POE-1200 Rear Panel
6
Figure 2-4 POE-2400 Rear Panel
1. The device is a power-required device, it means, it will not work till it is powered. If your networks
should active all the time, please consider using UPS (Uninterrupted Power Supply) for your device. It
Power
Notice:
will prevent you from network data loss or network downtime.
2. In some area, installing a surge suppression device may also help to protect your
damaged by unregulated surge or current to the PoE Injector Hub or the power adapter.
device from being
2.2 Installing the PoE Injector Hub
This section describes how to install your POE-1200 / POE-2400 802.3af Power over Ethernet Injector Hub and make
connections to the PoE Injector Hub. Please read the following topics and perform the procedures in the order being
presented. PLANET PoE Injector Hub do not need software configuration. To install the PoE Injector Hub on a desktop or
shelf, simply complete the following steps.
2.2.1 Desktop Installation
To install an PoE Injector Hub on a desktop or shelf, simply complete the following steps:
Step1: Attach the rubber feet to the recessed areas on the bottom of the PoE Injector Hub.
Step2: Place the PoE Injector Hub o
Step3: Keep enough ventilation space between the PoE Injector Hub and the surrounding objects.
When choosing a location, please keep in mind the environmental restrictions discussed in Chapter
1, Section 4, in Specification.
Step4: Connect y
A. Connect one end of a standard network cable to the upper stack 10/100 RJ-45 ports on the front of the PoE
Injector Hub.
B. Connect the other end of the cable
IP camera, splitter, or switch…etc.
C. Connect the one end of a standard network cable to the relative lowe
PoE Injector Hub.
D. Connect the other end of the cable to the port of switch.
our PoE Injector Hub to network 802.3af powered devices (PD) and Switch.
n a desktop or shelf near an AC power source.
to the 802.3 powered devices (PD) such as IP phone, wireless access point,
r stack 10/100 RJ-45 port on the front of the
Connection to the PoE Injector Hub requires UTP Category 5 network cabling with RJ-45 tips. For
more information, please see the Cabling Specification in Appendix A.
7
Step5: Supply power to the PoE Injector Hub.
A. Connect one end of the power cable to the PoE Injector Hub.
B. Connect the power plug of the pow
When the PoE Injector Hub receives power, the Power LED should remain solid Green.
er cable to a standard w
all outlet.
2.2.2 Rack Mounting
To install the PoE Injector Hub in a 19-inch standard rack, follow the instructions described below.
Step1: Place your PoE Injector Hub on a hard flat surface, with the front panel positioned towards your front side.
Step2: Attach a rack-mount bracket to each side of the PoE Injector Hub with supplied screws attached to the package.
Figure 2-5 shows how to attach brackets to one side of the PoE Injector Hub.
Figure 2-5 Attaching the brackets to the PoE Injector Hub
You must use the screws supplied with the mounting brackets. Damage caused to the parts by
using incorrect screws would invalidate the warranty.
Step3: Secure the brackets tightly.
Step4: Fo
Step5: After the brackets are attached to the Injector, use suitable screws to securely attach the brackets to the rack, as
llow the same steps to attach the second bracket to the opposite side.
shown in Figure 2-6.
8
Figure 2-6 Mounting thePoE Injector Hub in a Rack
Step6: Proceeds with the steps 4 and steps 5 of session 2.2.1 Desktop Installation to connect the network cabling and
supply power to your PoE Injector Hub.
2.2.3 Network Application Installation
The PoE Injector Hub is not equipment with data switching function between data ports. To inject PoE power and transmit
data packets to PDs, the PoE Injector Hub is usually link to an Ethernet switch. Typically, the Mid-Span Injector is installed
between regular Ethernet switch and PDs, and mostly it is located close to the Ethernet switch side.
To install an PoE Injector Hub on a network environment, simply complete the following step
Step1: Power on the PoE Injector Hub and connect the RJ-45 cable from the “data” port to the Ethernet switch port.
Step2: Connect the RJ-45 cable from the “d
Step3: Check the link status on both PD and Ethernet switch, once the Injector start to deliver 48V power over RJ-45 cables
to PDs, the PoE In-Use LED of the PoE Injector Hub lights.
ata + po
wer” ports to the PDs, such as VoIP phone, IP camera.
s:
9
Figure 2-7 Network application installation
The PoE Injector Hub supports Data passive mode, that is, even the PoE Injector Hub is manual power off, the data
D
between “
ATA” port and “DATA+PoE” port can still be transmitted without data loss.
The POE-1200 / POE-2400 Mid-Span Injector Hub doesn’t support Gigabit data rate. The Ethernet
switches or PoE PDs with Gigabit interface will operate at 100Mpbs Full Duplex mode w hen connect
to the Mid-Span Injector Hub.
2.2.4 Power over Ethernet Powered Device
Voice over IP phones
Enterprise can install POE VoIP Phone, AT
end-devices to the central where UPS
3~5 watts
6~12 watts
10~12 watts
and power control system.
Wireless LAN Access Points
Museum, Sightseeing, Airport, Hotel, Campus, F
the Access Point any where with no hesitation
IP Surveillance
Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera w
limits of install location – no need electrician to install AC sockets.
A and other Ethernet/non-Ethernet
is installed for un-interrupt power system
Warehouse can install
actory,
ithout
3~12 watts
PoE Splitter
PoE Splitter split the PoE 48V DC over
output. It frees the device deployment from restrictions due to power
power
outlet locations, which eliminate the costs for additional AC wiring and reduces
the installation time.
the Ethernet cable into 5/9/12V DC
10
Loading...
