Planet Technology FT-801, FT-802, FT-803, FT-802S15, FT-802S35 User Manual
...
Copyright
Copyright © PLANET Technology Corp. 2004.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. The information in this manual is subject to
change without notice. All other trademarks belong to
their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware
will work properly in all environments and applications,
and makes no warranty and representation, either
implied or expressed, with respect to the quality, performance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s
Manual is accurate; PLANET disclaims liability for any
inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change
without notice and does not represent a commitment on
the part of PLANET. PLANET assumes no responsibility
for any inaccuracies that may be contained in this User’s
Manual. PLANET makes no commitment to update or
keep current the information in this User’s Manual, and
reserves the right to make improvements to this User’s
Manual and/or to the products described in this User’s
Manual, at any time without notice.
If you nd information in this manual that is incorrect,
misleading, or incomplete, we would appreciate your
comments and suggestions.
FCC Warning
This equipment has been tested and found to comply
with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated in
a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this user’s guide,
may cause harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case the
user will be required to correct the interference at his
own expense.CE mark Warning
This is a Class A product. In a domestic environment,
this product may cause radio interference, in which case
the user may be required to take adequate measures.
CE Mark Warning
This is a Class A product. In a domestic environment,
this product may cause radio interference, in which case
the user may be required to take adequate measures.
Revision
User’s manual for PLANET Fast Ethernet Converter
Multi-mode: FT-801, FT-802, FT-803
Single-mode: FT-802S15, FT-802S35, FT-802S50,
FT-806A20, FT-806B20
Rev 6.0 (September. 2004)
Part No. 2010-000002-005
Table of Contents
Chapter 1 Overview 1
Chapter 2 Model List 1
Chapter 3 Checklist 2
Chapter 4 Product Outlook 2
Chapter 5 Link Fault Pass through (LFP) 3
Chapter 6 Installing the Converter 6
Chapter 7 Duplex Mode setting 7
Chapter 8 LED indication 8
Chapter 9 Cable Connection Parameter 9
Chapter 10 FT-80X Technical Specifications 10
Chapter 11 Power information 11
Chapter 1
Overview
Thank you for purchasing PLANET FT-80X family 10/100Mbps
Ethernet Twisted pair to 100Base-FX Fiber-optic Bridge Converter.
This converter is used to convert one type media signal to other
type equivalent that allows two type segments connect easily,
efciently and inexpensively. This converter can be used as a
standalone unit or as a slide-in module to the 10”/19” media
chassis (up to 15 units) for a TP and Fiber combined networks at a
central wiring closet. Please contact with your sales representative
for more about the 19” media chassis.
Chapter 2
Model List
Your Fast Ethernet Converter comes with one of the following
models.
ð FT-801: on board ST fiber connector
ð FT-802/S: on board SC fiber connector
ð FT-803: on board MTRJ fiber connector
ð FT-806A20: on board single SC fiber connector
ð FT-806B20: on board single SC fiber connector
Models with last character “S” indicate the ber-port is with
“Single-Mode” optic ber connector and followed with a number
indicates the maximum wiring distance.
In the following sections, the term “FT-80X” indicates the product
family above.
1
3
Chapter 3
Checklist
Your FT-80X carton should contain the following items:
ð The Fast Ethernet Bridge Converter
ð AC-DC Power Adapter (Output: 5VDC, 2 A max.)
ð This user’s manual
If any item is missing or damaged, please consult the dealer from
whom you purchased your Fast Ethernet Converter.
Chapter 4
Product Outlook
Right View
There are one RJ-45 Twisted-Pair jack (Auto-MDI/MDI-X), one
ber-optic connector (vary by model) and six LED indicators.
Left View
One DIP switch for Fiber-optic operating mode selection, FDX for
full-duplex, and HDX for half-duplex.
2
