Planet Technology FSD-Series User Manual
Trademarks
Copyright PLANET Technology Corp. 2004
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners. Contents in this document are subject to revision without prior notice.
FCC Class A Appliance
This equipment generates and uses radio frequency energy. If it is not installed
and used properly in strict accordance with the manufacturer‘s instructions,
it may cause interference to radio and television reception. It has been typetested and found to comply the specications in sub-part J of Part 15 of FCC
Rules, which are designed to provide reasonable protection against such interference in a residential installation. There is no guarantee that interference will
not occur in a particular installation. If this equipment does cause interference
to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Re-orient the receiving antenna
Relocate the computing device with respect to the receiver
Move the computer away from the deceiver
Plug the computer into a different outlet so that compute and receiver are on
different electrical circuits.
If necessary the user should consult the dealer or an experienced radio or
television technician for additional suggestions.
CE Mark Warning
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
WEEE Warning
To avoid the potential effects on the environment and human health as
a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should
understand the meaning of the crossed-out wheeled bin symbol. Do not
dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
The information in this manual is subject to change without notice.
User's manual for PLANET 8/16-port 10/100Mbps Fast Ethernet Switch
Model: FSD-800/1600/801/1601SC & ST
Rev: 4.0 (July. 2004)
Part No. 2010-000004-003
Table of Contents
Chapter 1 General Introduction 1
1.1 Checklist 1
1.2 Introduction 1
1.3 Features 2
Chapter 2 Hardware Description 3
2.1 Front Panel 3
2.1.1 FSD-800/FSD-801 3
2.1.2 FSD-1600/FSD-1601 4
2.2 Rear Panel 5
2.3 Hardware Installation 7
Chapter 3 Configuration and Application 8
3.1 The Switch Operation 8
3.2 The Smart Function (16-port model) 9
3.2.1 TP or Fiber-optic selection (for FSD-1601 only) 9
3.2.2 Port-based VLAN 10
3.2.3 Port-Trunking 10
3.2.4 IP ToS/DS (DiffServ), VLAN Tag Based QoS 10
3.2.5 Port-based priority 11
3.3 Application 11
3.3.1 Basic 100Mbps Server, PCs to 10/100Mbps Switch 11
3.3.2 Connect to 100Base-FX Switch/Device (Model: FSD-801/1601)
12
3.3.3 Set up the workgroup and uplink to the backbone (Model: FSD-
1600/1601) 13
Chapter 4 Troubleshooting 14
Appendix A Specifications 15
Appendix B RJ-45 Pin Specification 17
Chapter 1
General Introduction
1.1 Checklist
Check the contents of your package for following parts:
• The Fast Ethernet Switch
• User’s Manual
• Power Cord
If any of these pieces are missing or damaged, please contact your dealer immediately, if
possible, retain the carton including the original packing material, and use them against
to repack the product in case there is a need to return it to us for repair.
1.2 Introduction
The 8/16-port 10/100Mbps Ethernet Switch is designed to allow simultaneous
transmission of multiple packets via an internal high-speed data channel. This means that
it can partition a network more efciently than bridges or routers in most environments.
This Switch is a highly reliable network switch and is the ideal device for bridging Ethernet
to Fast Ethernet workgroups or networks. Simple and cost-effective, the Switch complies
to IEEE802.3u, IEEE802.3, 100Base-TX, and 10Base-T. Therefore, the Switch will be the
fast being recognized as one of the most important building blocks for today networking
technology. Choice of 100Base-FX optic-ber ST/SC interface,
The FSD-801/1601ST&SC are also ideal to extend the network distance up to 2 kilometers
away as a link to your remote backbone.
The Switch also provide rack-mounting kits option for being installed On 10-inch or 19inch rack to ease the placement and management effort.
Compact in size and designed for Plug and Play installation, the Switch allows the network
administrator to simply connect the network and power cables and the switching/bridging
functions begin automatically. No hardware or software congurations are required.
The front panel of the Switch provides LED indicators for easy recognition of the switch
operation status and for troubleshooting. These LED indicators display the power status
for the system and link/activity, speed, and full-duplex status for each port.
With 8/16-port Fast Ethernet Switching designed specically for connecting workgroup
devices and desktops, companies no longer have to invest in expensive and inexible
switches engineered primarily for backbone implementations. Instead, companies can
deploy scaleable, affordable switches that increase the aggregate bandwidth of the
network by boosting throughput to the workgroups that need it most.
1
3
1.3 Features
• 8/16-port 10/100base-TX Auto-Negotiation Ethernet Switches
• One optional 100Base-FX fiber port for extending up to 2km
• Complies with the IEEE802.3 Ethernet and IEEE802.3u Fast Ethernet stan-
dard
• Features Store-and-Forward architectures with wire-speed filtering and for-
warding rates
• Provide rack-mounting kit option for 10-inch and 19-inch Rack
• Full/Half-Duplex capability on every TX ports, total bandwidth is up to
200Mbps/port
• Support up to 1K/8K Uni-cast address, Layer 2 address resolution-Self Learn-
ing
• IEEE802.3x compliant full-duplex flow control
• Back pressure half-duplex flow control
• Runt and CRC Filtering eliminates erroneous packets to optimize the network
bandwidth
• Provide internal power supply
• LED indicators for simple diagnostics and management
• Auto- MDI and MDI-X detect for easily connecting to PC or hub/Switch uplink
• DIP Switch for smart function (16-port model only)
2
Chapter 2
Hardware Description
This section describes the hardware features of the Switch. For easier management and
control of the Switch, familiarize yourself with its display indicators, and ports. Front panel
illustrations in this chapter display the unit LED indicators. Before connecting any network
device to the hub, read this chapter carefully.
2.1 Front Panel
The unit front panel provides a simple interface monitoring the Switch. It includes a power
indicator for each port.
2.1.1 FSD-800/FSD-801
Figure 2-1 Front Panel of FSD-800 / FSD-801
LED indicators
Printing Color Description
Power
(PWR)
LNK/
ACT
100 Green
This indicator lights green when the Switch is receiving
Green
power, otherwise it is off.
This indicator green when the port is connected to a either
10Mbps Ethernet or 100Mbs Fast Ethernet station, If the
station to which the Switch connected is powered off, or if
Green
there is a problem with the link, the LED will remain off.
And the indicator blinking green when the data will be re-
ceived to all other connected ports.
This indicator green when the port is connected to a
100Mbps Fast Ethernet station. If the station to which the
Switch is connected is powered off, a 10Mbps Ethernet
station, or if there is a problem with the link, the LED will
remain off.
3
5
Lit: Full duplex operation
Unlit: Half duplex operation
FDX/
COL
NOTE:
DIP Switch (FSD-801)
Printing Description
FDX (default)
HDX The port is operating in half-duplex mode.
NOTE:
Blink: indicates data collisions on the respective Ethernet
Amber
segment of this port. Whenever a collision is detected, the
respective COL indicator will briefly blink.
This is normal when the network is busy.
Port # 8 of FSD-801 is a shared port. Either Twisted Pair port
or Fiber-optic port can operate in one time. Please power off
FSD-801 before switching the share port to different con-
nection type.
The 100Base-FX fiber port of the switch is operating in full-
duplex mode.
check the opposite end is using the same transmit mode
before make the connection. If you want to adjust the DIP
switch, please power off FSD-801 first.
2.1.2 FSD-1600/FSD-1601
Figure 2-2 Front Panel of FSD-1600/ FSD-1601
4
LED indicators
Printing Color Description
Power
(PWR)
LNK/
ACT
100 Green
FDX/
COL
Amber
This indicator lights green when the Switch is receiving
Green
power; otherwise, it is off.
This indicator green when the port is connected to a either
10Mbps Ethernet or 100Mbs Fast Ethernet station , If the
station to which the Switch is connected is powered off, or if
Green
there is a problem with the link, the LED will remain off.
And the indicator blinking green when the data will be re-
ceived to all other connected ports.
This indicator green when the port is connected to a
100Mbps Fast Ethernet station. If the station to which the
Switch is connected is powered off, a 10Mbps Ethernet
station, or if there is a problem with the link, the LED will
remain off.
Lit: Full duplex operation
Unlit: Half duplex operation
Blink: indicates data collisions on the respective Ethernet
segment of this port. Whenever a collision is detected, the
respective COL indicator will briefly blink
This is normal when the network is busy.
NOTE:
Port # 16 of FSD-1601 is a shared port. Either Twisted Pair
port or Fiber-optic port can operate in one time.
2.2 Rear Panel
There is one power socket on the back of the switch, 100~240VAC, 50/60Hz. And one
more DIP-switch for FSD-1600 and FSD-1601 for smart function.
Figure 2-3 Rear Panel of the FSD-800/801
Figure 2-4 Rear Panel of the FSD-1600/1601
5
